Insights for Farmer Training Programs from System Dynamics:
A Case Study from Northern Michigan


L. S. Olabisi1, O. Elegbede2, M. R. Raven3






Abstract
Training programs for new farmers have been proposed as a solution to rural food insecurity, rural
development, and the recruitment and training of younger farmers simultaneously. However,
evaluation of these programs and evidence for their individual or collective impact is sparse. In this
paper, we use in-depth interviews combined with a system dynamics model to evaluate the current
and potential effectiveness of a farmer training program in Michigan’s Upper Peninsula. We use the
model to represent the theoretical progression of farmers through three subsequent stages of skill
acquisition: training, new farmer (practicing skills on land owned by the program) and experienced
(farming on their own). We find that recruitment, access to local markets, rapidity of skill acquisition,
and access to start-up costs are all important factors that facilitate trainees’ transition to farming on
their own, but of these, start-up costs for independent farming appear to be the most significant
barrier. While this model is exploratory and not predictive, these insights can inform the design of
effective programs for training farmers who will ultimately go on to start their own operations. In
addition, this study also demonstrates how systems dynamics can be a valuable method to evaluate
and maximize the effectiveness of training programs.

Keywords
Training, Systems modeling, evaluation, rural livelihoods, adoption









Keywords

Keyword, keyword (make sure they match what is in the system)



Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  2

Introduction and Problem Statement

Food insecurity and a lack of affordable, nutritious foods are persistent problems in the rural
United States (Denney et al., 2017; Ramirez et al., 2017). The farming population in the United
States is aging, with one quarter of farm operators being 65 or older, compared with only 8% of
the general population (United States. Congress. Senate. Special Committee on, 2008). Training
programs for new farmers have been proposed as a solution to rural food insecurity, rural
development, and the recruitment and training of younger farmers simultaneously. However,
evaluation of these programs and evidence for their individual or collective impact is sparse.

The Upper Peninsula of Michigan is a rural region that exemplifies the linked challenges of
economic insecurity, an aging farmer population, and a supply for locally produced fruits and
vegetables that does not meet consumer demand. According to a 2011 survey conducted by
Michigan State University Extension (MSUE) on a sample of 108 Upper Peninsula (U.P.) farmers,
only 8% of the respondents derive all of their income from their farms. For most, the farm
generated up to 10% of the household income. Nearly three-quarters (70%) were over the age
of 51 and three-quarters (75%) indicated they did not have someone to take over for them
when they stop farming. Nearly half of the respondents (48%) indicated they wanted to expand
their operations. Many producers indicated they needed additional help and technical support.
The report pointed out that as interest in local food continues to increase so will the pressures
on U.P. producers to keep pace with the demand. Furthermore, the report concluded that a
vibrant local food economy was integral to the health of small rural communities (Lantz & Walk,
2011).

As a solution to these documented challenges, Michigan State University’s Upper Peninsula
Research and Extension Center has developed formal and non-formal research-based
educational programs targeting beginning farmers and avocational growers to increase the
number of farmers in the U.P. growing nutrient dense food, thereby proposing to fill the gap
between supply and demand for healthy local foods. The program provides access to
organically managed land, equipment and hand tools, and shared infrastructure (hoop houses,
transplant greenhouses, germination chamber, a tractor, etc.). In addition, the program
provides subsidized on-site housing, access to markets, training in National Organic Program
and USDA Good Agricultural Practices record keeping, guidance with farm business plans, and
networking opportunities with other farmers and educational workshops. If successful, the
farmer training program could be a model for other such programs in the United States seeking
to improve healthy local food access by equipping aspiring farmers.

Despite the potential benefits of the farmer training program, the enrollment and graduation
rates have been low. In the four years since the program was established, six farmers have
participated in the program, while the original target completion number was between 12 and
24. We conducted a qualitative evaluation of the program, combined with an exploratory
system dynamics model, to understand the barriers and opportunities involved in recruiting
farmers to the program, supporting them in completing the program and in their transition to



Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  3

independent farming, and assessing the potential extent of the impact on agriculture in the U.P.
In this work, we seek to capture the complex interactions and dynamic feedbacks between the
educational program for beginning farmers, challenges to technology implementation, and
economic barriers to entry into farming. Consequently, we are using system dynamics modeling
to represent these dynamics (Meadows, 2008).

System dynamics modeling was developed in the 1960s and has been used in a wide variety of
fields to investigate how complex systems behave over time (Forrester, 1968). It is a
quantitative modeling technique based on a series of differential equations, but it is also
capable of representing qualitative information gleaned from interviews and focus groups
through causal logic (Scott et al., 2013). System dynamics has been proposed as a useful tool for
conducting program evaluation, because it can demonstrate potential impacts of a program
into the future, and of outlining the effects of programmatic changes (Merrill et al., 2013). It
has also been commonly used to represent technology adoption (Amelia et al., 2014; Fisher et
al., 2000). We drew on the technology adoption models for this study, because we are
representing a group of farmers acquiring and then using a set of technologies for growing
nutrient dense produce in the U.P. As represented in the model, potential farmers learn about
the program from educational workshops offered by the North Farm at the Upper Peninsula
Research and Extension Center.  The farmers trained in a suite of technologies demonstrated in
the program, including walk behind tractors, seeders, hoes, price planning and assessments,
etc. Then the farmers decide whether to implement these technologies or not. The process of
recruiting new trainees is driven by information exchange between potential farmers and those
who have gone through the program, as posited by diffusion theory (Rogers, 2003).

Famers that graduate from the program are assumed to be more skilled at growing nutrient
dense produce using appropriate technology, and more skilled at developing a business plan
that will help with their future farms. We used a system dynamics model to model these
patterns of adoption and the ways in which the technologies could diffuse through the farming
population of the Upper Peninsula. The research question we sought to answer with this
model: what programmatic interventions would be most effective in increasing the
recruitment, graduation, and establishment of beginning farmers relative to the training
program?


Methods

We conducted semi-structured scoping interviews with beginner farmers to understand their
current farming operations, goals, technology and methods learned from the program,
profitability, productivity, challenges and constraints they face and benefits from the program.
We carried out the study at the North Farm in Chatham, located in the Upper Peninsula of
Michigan, and at Michigan State University, East Lansing Michigan. The study sample consisted
of six farmers that were in the program for at least a year. The farmers in program range in
experience from beginners to experienced farmers. We used a survey that had both structured
and semi-structured questions, as well as an exploratory approach in the survey to get more



Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  4

information that might not have been revealed in the structured questions (Glesne, 2010).
Some of the data was collected face-to-face and the rest was collected over the phone. In
addition, we used data generated from the MSU Upper Peninsula Research and Extension
Center: North Farm Apprentice Farmer Program Evaluation Summary report that was
conducted in December 2018. The survey along with the report contributed to a deeper
understanding of the issues related to the program.

We used information from the scoping interviews and the 2018 evaluation report from the
North farm to create and parameterize the system dynamics model, using Vensim® software.
The logical framework follows Rogers’ diffusion of innovation model (Rogers, 2003) (Figure 1).

Figure 1
Structure of System Dynamics Model



Note. Model structure depicting the progression of farmers through training, to establishment of a ‘new’ farm on
land provided by the training program, to experienced farmer status on their own land.

Potential farmers (farmers who join the training program) advance through three stages of skill
acquisition: training, new farmer (practicing skills on land owned by the North Farm) and
experienced (farming on their own). Their ability to advance through these stages is both
mediated and facilitated by factors discovered through the interviews. Once the structural logic
of the model was established, values for the parameters were derived from the interviews and
the North Farm evaluation report. For example, we asked interviewees how many months they
estimated for the transition from ‘new farmer’ to ‘experienced farmer’ (successfully farming on



Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  5

their own upon completion of the North Farm program), and the average response was 40
months.

Findings

Interviews
The skills acquired through the North Farm program allowed beginner farmers to learn how to
start a business and transition to the ‘training farmers’ category. As described by the
interviewees, these skills included networking, creating invoices for customers, and developing
avenues to sell their products at local restaurants and through community-supported
agriculture, in partnership with the North Farm. Trainees also learned about viable farm
business models, including price planning, price assessment, calculations of labor, and soft
skills, as well as soil management and safe produce handling. In addition, the farmers were
provided with technology for sustainable production practices, such as harvesting tools, water
wheel planters, rotor tillers, walk-behind tractors, drip irrigation systems, and hand cultivators.
All of these factors were added into the system dynamics model as variables conditioning the
transition rate of farmers between ‘training’, ‘new’, and ‘experienced’ categories.

Model
The baseline behavior of the system dynamics model depicting adoption of the North Farm
technologies by the training population followed a typical S-curve growth pattern over the 30
years of the model run (Figure 2).

By the end of the model run, thirteen total farmers had successfully transitioned to farming on
their own land, representing the cumulative impact of the North Farm program. The number of
farmers in the ‘training farmer’ category grew as they were trained at the North Farm, then
declined as these farmers successfully transitioned to farming on their own land. In the baseline
model run, we assumed that all farmers entering the program had access to materials they
needed for training: access to organically managed land, subsidized housing, access to
equipment and hand tools, access to markets, educational workshops, business plan guidance,
and supervised training under the guidance of a program manager. This baseline run mirrors
the setup of the North Farm Apprentice Farmer Program, which provides this support to
enrolled farmers.














Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  6

Figure 2
System Dynamics Model Output



Note. System dynamics model results depicting number of farmers in the ‘training farmers’ category (top) and the
‘experienced farmers’ category (farmers who have successfully transitioned to farming on their own land, bottom)
over the 15-year model run under baseline conditions.

The flow of farmers into the program is ultimately limited by the amount of contact and
positive word of mouth generated by the trainees enrolled in the program. In the context of the
North Farm model, this was represented by the number of workshops held, driving interest
from potential farmers in enrolling in the program. When the number of workshops was
increased from one per quarter to one per month, this had the effect of sending a greater



Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  7

‘pulse’ of farmers through the system initially. Without additional support for farmers to
transition into successfully starting their own operations, however, this did not result in
substantially greater numbers of farmers becoming independent (Figure 3).

Figure 3
Model Output: Results of Program Interventions



Note. System dynamics model results depicting number of farmers in the ‘training farmers’ category (top), number
of farmers in the ‘new farmers’ category (farming on land provided by the training program, middle) and the
‘experienced farmers’ category (farmers who have successfully transitioned to farming on their own land, bottom)
over the 15-year model run under four scenarios: ‘high workshop’ (farmers are recruited to the training program
through monthly rather than quarterly workshops); ‘start up’ (startup costs for farmers starting their own
operations are subsidized); ‘experience’ (time for farmers starting their own operations to gain the necessary
experience is reduced from 3.5 years to 1 year) and ‘more CSA’ (a 2x increase in the number of CSA customers).



Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  8


Another scenario involved decreasing start-up costs for farmers to start their own farm
operations after training in the program. This scenario had the greatest impact on the number
of experienced farmers by the end of the model run (increasing this number to 75), but had
minimal impact on the number of farmers in the training program or the number of new
farmers (Figure 3). Decreasing the amount of time needed for farmers to gain the experience to
start their own operation from 3.5 years to 1 year also increased the number of experienced
farmers by the end of the model run above the baseline, but did not have as great an impact on
increasing this number as did a decrease in start-up costs.

Finally, increasing direct sales of vegetables through community-supported agriculture (i.e.
doubling the enrollment in CSAs from 25% of the population to 50%) did not have a substantial
impact on number of farmers progressing through the system (Figure 3). This is because, in the
absence of trainees being recruited into the program, there are not enough farmers to take
advantage of increased CSA sales. CSA sales are also split between the new farmers and the
experienced farmers, and new farmers are better able to take advantage of them because of
the land and resources they can access through the North Farm program. This is a cautionary
insight for the design of such programs, which should take care not to place their trainees and
their graduates in competition for limited market share. This may be more important for
programs that are large in scope relative to their local markets.

When all interventions to boost the number of experienced farmers were combined into one
model run (increasing workshops, decreasing startup costs and experience needed to start
one’s own operation, and increasing CSAs), the number of experienced farmers after 30 years
reached 203. This is a substantial impact for one training program at one location and could
potentially transform the food landscape in the Upper Peninsula region, especially if duplicated
at other sites (Figure 4).





Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  9

Figure 4
Model Output: Number of Experienced Farmers




Note. System dynamics model results depicting number of farmers in the experienced farmer category under
baseline conditions, and with all interventions to increase number of farmer recruited and trained (more workshop
recruitment, reduced startup costs, increased CSA customers, and reduced time to gain experience).

This is an exploratory model, based on an in-depth qualitative study of one farmer training
program, and is useful for gaining general systemic insights rather than crafting detailed
predictions. For example, without a larger survey of farmer training programs across the
country with different training models, it is difficult to place weights indicating relative
importance on the different components of the program that allow for successful training (e.g.,
access to tools, subsidized housing, supervised training, etc.). In our model, we assumed the
same weight for all of these elements, even though interviewees highlighted the supervisory
guidance of a program manager as being particularly important to their learning process, which
would imply that the selection of the person to lead the training program is particularly
important for its success. Similarly, we were not able to generate detailed market scenarios to
guide where new farmers might gain the best advantage in selling their products (e.g. to
restaurants, CSAs, or farmers’ markets). A detailed economic analysis of produce markets in
Michigan’s Upper Peninsula would be necessary to provide this type of guidance.

Nevertheless, the model provided substantive insights into the design of successful farmer
training programs, and we were able to use it to test commonly proposed interventions for
increasing the flow of new farmers into the farming population. We found that decreasing
start-up costs for farmers striking out on their own (e.g. through loans, subsidized land
purchase and/or leasing arrangements) would be particularly effective in transitioning farmers



Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  10

from a training period to establishing their operations. At the same time, increased recruitment
of farmers into a training program will not ultimately result in more local farmers unless their
transition into farming on their own is also facilitated, for example through reduced or
subsidized start-up costs, as described above.


Conclusions, Discussion, and Recommendations

Using a system dynamics model, we were able to depict the training of new farmers producing
vegetables for local markets in the Upper Peninsula of Michigan as a pipeline, with barriers to
entry and opportunities for intervention. The model represents each stage of progression from
farmers in training, to new farmers operating on land provided by the training program, to
experienced farmers running their own operations. We built the model using in-depth
interviews with farmers in the North Farm Apprentice Farmer Program, combined with a
system dynamics framework depicting adoption of new technologies. While this model is
exploratory and not predictive, we were able to glean insights around the design of effective
programs for training farmers who will ultimately go on to start their own operations. To
increase the number of experienced farmers, more programs will be needed to ease the startup
costs for farmers starting their own operations. Recruiting more farmers into a training
program will not result in more farmers that are independent unless this startup ‘bottleneck’ is
addressed. Programs should be careful not to engender competition for customers between
farmers in training and farmers who have graduated the program to start their own operations.
While modest in size, training operations like the North Farm Apprentice Farmer Program could
have a substantive impact on recruiting and establishing new farmers over time. Finally, this
study also demonstrates how systems dynamics can be a valuable method to evaluate and
maximize the effectiveness of training programs.


References

Amelia, D. F., Kopainsky, B., & Nyanga, P. H. (2014). Exploratory model of conservation

agriculture adoption and diffusion in Zambia: A dynamic perspective. Paper presented at
the 32nd International Conference of the System Dynamics Society, Delft, Netherlands.


Denney, J. T., Kimbro, R. T., Heck, K., & Cubbin, C. (2017). Social Cohesion and Food Insecurity:

Insights from the Geographic Research on Wellbeing (GROW) Study. Matern Child
Health J, 21(2), 343-350. https://doi.org/10.1007/s10995-016-2119-5


Fisher, D. K., Norvell, J., Sonka, S., & Nelson, M. J. (2000). Understanding technology adoption

through system dynamics modeling: implications for agribusiness management. The
International Food and Agribusiness Management Review, 3(3), 281-296.
https://doi.org/10.1016/S1096-7508(01)00048-9


Forrester, J. W. (1968). Principles of Systems. Pegasus Communications.




Olabisi et al.  Advancements in Agricultural Development


https://doi.org/10.37433/aad.v1i2.33  11

Lantz, N., & Walk, M. (2011). Upper Peninsula agriculture assessment. Retrieved from East
Lansing MI:


Meadows, D. (2008). Thinking in Systems: A Primer. Chelsea Green.

Merrill, J. A., Deegan, M., Wilson, R. V., Kaushal, R., & Fredericks, K. (2013). A system dynamics

evaluation model: implementation of health information exchange for public health
reporting. Journal of the American Medical Informatics Association : JAMIA, 20(e1),
e131-e138. https://doi.org/10.1136/amiajnl-2012-001289


Ramirez, A. S., Diaz Rios, L. K., Valdez, Z., Estrada, E., & Ruiz, A. (2017). Bringing Produce to the

People: Implementing a Social Marketing Food Access Intervention in Rural Food
Deserts. J Nutr Educ Behav, 49(2), 166-174 e161.
https://doi.org/10.1016/j.jneb.2016.10.017


Rogers, E. (2003). The Diffusion of Innovations. The Free Press.

Scott, R. J., Cavana, R. Y., & Cameron, D. (2013, July 21-25, 2013). Evaluating long-term impact

of qualitative system dynamics workshops on participant mental models. Paper
presented at the 31st International Conference of the System Dynamics Society,
Cambridge, MA.


United States. Congress. Senate. Special Committee on, A. (2008). Harvest over the horizon

[electronic resource]: the challenges of aging in agriculture : hearing before the Special
Committee on Aging, United States Senate, One Hundred Tenth Congress, first session,
Washington, DC, June 21, 2007.






© 2020 by authors. This article is an open access article distributed under the terms and conditions of
the Creative Commons Attribution license (http://creativecommons.org/licenses/by/4.0/).
