Nomograms for calculating the safety factor of

homogeneous earth dams in long-term

stability


Rida Lakehal1*, Lakhdar Djemili1 and Larbi Houichi2


1
Department of Hydraulics, Badji Mokhtar University, Annaba, 23000 Annaba, Algeria.

2
Department of Hydraulics, Hadj Lakhdar University, Batna, 5000 Batna, Algeria.


Accepted 21 March, 2019


The slope stability analysis is routinely performed by engineers to evaluate the stability of embankment dams, road

embankments, river training works, excavations and retaining walls. To ensure the geotechnical safety of the dam,

the slope of embankment must be correctly designed and constructed. In this work, by applying the modified

method of Bishop, an attempt was made to construct sets of nomgrams for the calculation of the safety factor of

homogeneous earth dams under long term stability, which allow the user to get the optimal safety factor of the dam,

immediately, according the material classification and the parameters of design, height and slope.



Key words: Nomograms, safety factor, homogeneous earth dams.


INTRODUCTION


In the state of Annaba, Eastern Algeria, the construction of
homogeneous earth dams increased, especially in areas
dominated by agriculture. By considering the questions of
security, it is absolutely necessary to study their stability in
the various cases of loading especially in long-term case.
The most popular method for stability analysis of these
structures is the limit equilibrium method (LEM), this method
is widely used by engineers and researchers and it is a
traditional and well established method. Although the (LEM)
does not consider the stress strain relation of soil, it can
provide an estimate of the safety factor of a slope without
the knowledge of the initial conditions, with the result that the
(LEM) is favored by many engineers. The LEM is well known
to be a statically indeterminate problem, and assumptions on
the distributions of internal forces are required for the
solution of the safety factor (Cheng, 2006). A relatively large
number of methods have been developed. Among them, the
slices method. In this method, the material above the slip
surface being divided into a number of usually vertical slices.

Improvements in the methods have aimed on reducing
the error due to oversimplifying the shape of the slip




*Corresponding author. E-mail: lakehal@hotmail.fr. Tel: +213-
773-807526.






surface and the resulting incorrect determination of the
normal stress. The latter is potentially important for frictional
materials where the shear strength will depend on the
normal stress. The principal methods are described in the
papers of Fellenius (1936), Bishop (1955), Morgenstern
(1965), Janbu (1973), and Sarma (1979). In this work, by
applying the modified method of Bishop, an attempt was
made to construct sets of nomograms for calculating the
safety factor (SF) which characterizes the stability of these
homogeneous structures. As such, many calculations would
be carried out starting from the structure of simplified cross

of the dam. Lastly, nomograms remain a contribution
approach based on variations of the main properties in
the long-term stability (Lakehal, 2011).

METHODOLOGY


Data


The data used ar e r elat ed to the geometrical properties of the
works, mechanical properties of materials, and software employed
(Lakehal, 2008).

Geometrical properties of the works


In Figure 1, the simplified cross adapted for calculations, which
represent the inclination (1/X, X in meter) for the upstream and

mailto:lakehal@hotmail.fr






















Figure 1. Cross simplified adapted for calculations.




downstream slope, are 1/3 and 1/2.5, respectively. A filter of two
layers was seen for the upstream slope with a thickness of 0.2 m
fine sand and 0.3 m coarse sand, while a drain with length fixed at
1/3 of the width of dam with a thickness of (1 m) constituted the
three layers (0.3 m fine sand, 0.3 m coarse sand, 0.4 m gravel)
(Lakehal, 2008; Alonso,1996; Colomer, 2009). The geometrical
characteristics of the embankment taken into account are:

The width of the crest (b) corresponds roughly to the formula of
Knnapen,


b=1.65  H (1)


H: height of dam in meter, the unevenness {D = Hp + R}
(Alonso,1996; Lakehal, 2011).



Mechanical properties of materials

The materials used in construction of these homogenous structures
are intact or compacted fine materials, these materials have values
of cohesion (c’) and friction angle (φ') seldom out of the following
natural limits: (5 to 30 kPa for c’ and 15 to 40 for φ'), that is to say a
fork of 25 kPa and 25°. We can obtain characteristics which are
very poor (c' = 10 kPa and φ' = 20), excellent (c’ = 25 kPa and φ'
= 35) or average (c' = 20 kPa and φ' = 25) (Alonso, 1996; Degoutte,
2002; Duncan, 2005), the value of the density of these materials is
chosen as the average value (USBR, 2001). In this case the density

is taken as 20 kn/m
3
 (Alonso, 1996; Colomer, 2009).


Software used

The nomograms are results of several calculations by the Geostab
software (version 2004) based on limit equilibrium methods. The
method of calculation is that of Bishop modified (Géostab, 2004;
Hammouri, 2008).



Methods

In this work a series of nomograms for calculating the safety factor
of the slope of an homogenous earth dam have been produced
(Colomer, 2009).

The first set can be used for dams with height equal 10 m, 20 m and

30 m, with (1/2.5) value of inclination for downstream slope, the values

of materials properties varied between: 10° to 35° for effective
























friction angle (φ’), and 10 kps ,20kps and 30 kps for effective

cohesion (c’) (Alonso, 1996; Degoutte, 2002; Lakehal, 2008).
The second sets for height equal 10 to 30 m, with different

inclinations for downstream slope were analyzed, their values
being: 1/2 to1/4 (Lakehal, 2008; Colomer, 2009), with the type of
materials very poor (c' = 10 kPa and φ' = 20) and average (c' = 20
kPa and φ' = 25) (Degoutte, 2002; Lakehal, 2008) .

The nomograms developed in this study allow the user to know
immediately the safety factor (SF) of dam with a known height,
inclination and mechanical properties of materials.The value of
safety factor SF =1.5 is set as a minimum value to ensure the
stability of earth dam in long-term stability (Alonso, 1996; Degoutte,
2002). The stability of downstream slope should be analyzed (US
Army, 2003).The first nomograms are represented in Figure 2 for
downstream slope.

Figure 2 show results for embankments with a height of less than
30 m and inclination of (1/2.5), the nomograms have a decimal
scale to interpolate values of SF in the case when the interpolation
is required.The second nomograms are represented in Figure 3 for
downstream slope.

Figure 3 show the results for embankments with a height of less
than 30 m with different values of inclination (1/2.5 to 1/4), in this
case the user can determine the optimal safety factor from the
height of the dam, type of materials and the inclination of slope. It
can also determine the optimal inclination adopted for an optimal
safety factor in the opposite sense.




RESULTS AND DISCUSSION



Practical implementation



In Figure 2, four different nomograms are shown, in
which tow practical implementations have been applied:


(i) The implementation of the nomograms on an earth
dam with a height of 10 m, the inclination of downstream
slope is (1/2.5) and the width of the crest is 5 m, the
effective cohesion: c’ = 22 kps, effective friction angle: φ'
= 15°, the result of SF is located between: 1.9 to 2.1 and
by interpolation, the result of SF is 2.056. For the same
dam, we can obtain the optimal safety factor SF =1,5 with
the values of materials proprieties: c’ = 17 kps, φ' = 12°.

(ii) The implementation of the nomograms an earth dam









































































Figure 2. Set of nomograms for calculating the SF of earth dam between 10 to 30 m height.











































Figure. 3. Set of nomograms for calculating the SF of earth dam between 10 to 30 m height.






with a height of 20 m, the inclination of downstream slope
is (1/2.5) and the width of the crest is 7 m, the effective
cohesion: c’ = 22 kps, effective friction angle: φ' = 15°, the
result of SF is located between: 1.3 to 1,5, is lower than
1,5, to get a value of SF equal 1.5 or
higher one needs to increase the inclination of
downstream slope at (1/2.75). In Figure 3, the
implementation of the nomograms an earth dam with a
height of 20 m, the inclination of downstream slope is
(1/2.75) and the width of the crest is 7 m; with the type of
materials is very poor (c' = 10 kPa, φ' = 20°), the result of
SF is located between: 1.5 to 1.6 and, by interpolation,
the result of SF is 1.575, the process is similar as in other
nomograms.




Conclusion



The nomograms shown in this paper are a suitable tool
for quickly calculating the SF of homogenous earth dams
(up to thirty meters high). They do not need complicated
calculations or computer programs. It is only necessary







to know its mechanical and geometrical properties
(height and inclination of slope).

Every nomogram allows the inclination of the slope

in
a dam to be optimized. Hence, for a given height of dam,
and according to the type of material and optimal safety
factor, the nomogram will give the optimum inclination of
a slope that is stable. Although, the nomograms remain a
contribution approach based on variations of the main
properties in the long-term stability.



REFERENCES

Alonso B (1996).The effect on the stability of earth dams consistent with

the variation of key parameters. French Mag. Geotech., 63: 18-37.
Bishop AW (1955). The use of the slip circle in stability analysis of slopes.

Geotechnique, 1: 7-17.
Colomer M (2009). Safety factor normograms for homogeneous earth

dams less than ten meters high. J. Eng. Geol., 0013-7952, Elsevier,
pp. 65-73.

Cheng YM (2006). Three dimensional slope failure analysis by the
strength reduction and limit equilibrium methods. J. Comput.
Geotech. Elsevier, 36:65-73.

Degoutte G (2002). Small dams. Cemagref editions.179 p, ISBN. 2 85362-







551-6.
Duncan J (2005). Soil strength and slope stability, library of congress

cataloguing-in publication data. 450 p, ISSBN 0-471-69163-1.
Fellenius W (1936). Calculation of the stability of earth dams,
transaction. 2nd International Congress on Large Dams. ICLD,
Washington, DC., pp. 445-459.

Janbu N (1973). Slope stability computation. Embaankment dam
engennering-Cassagrande volume. John Wiley.

Hammouri N (2008). Stability Analysis of slope using the finite element
method and limiting equilibrium approach. Copyright Springer-Verlag.
J. Eng. Geol. Environ., pp. 80-88.

Géostab Software (2004). Manual de l’utilusateur.135 p.
Lakehal R (2008).Study contribution to the influence of geometric,

geotechnical and hydraulic stability of homogeneous earth dams.
Magister Thesis Badji Mokhtar University. Annaba. Algerie, p. 100.

Lakehal R (2011). A study of long term effect of geotechnical factors on
stability of homogenous earth dams. J. Geogr. Regional Plann., 4(5):
279-286.





Morgenstern NR, Price VE (1965). The analysis of the stability of

general slip surfaces. Geotechnique, 15(1): pp. 79-93.
Sarma  SK  (1979).  Stability  analysis  of  embankments  and  slopes.  J.

Geotech. Eng. DIV. ASCE., 105.N°GT12. pp. 1511-1524.
USBR (US. Bureau of reclamation) (2001). US. Bureau of Reclamation.

http://www.usbr.gov.
US Army (US Army Corps of Engineering) (2003). Engineering Manual.

Engineering and design - Slope stability. US Army Corps of
Engineering, 205 p.
