Design and Testing of an Online Fertilizing Amount Detection Device
Based on the Moment Balance Principle

 Chuanke Yang1, Jianian Li1, Xiaocheng Wang1, Daoran Li1 & Guoxuan Wang1

1 Faculty of Modern Agricultural Engineering, Kunming University of Science and Technology, Kunming, China
Correspondence: Jianian Li, Faculty of Modern Agricultural Engineering, Kunming University of Science and
Technology, Kunming, China. Tel: 86-18288654908. E-mail: ljn825@163.com

Received: October 22, 2022   Accepted: October 27, 2022   Online Published: October 28, 2022

The research is financed by (National Natural Science Foundation of China (52069008), Basic Research Project
of Yunnan Province (202101AT070113).

Abstract
Based on the principle of moment balance, this paper designs a fertilizer application amount online detection
device, which is mainly composed of two major parts: the fertilizer guide mechanism and the fertilizer metering
and discharging mechanism.Under the electromagnetic reversing and buffering of the fertilizer guide mechanism,
the fertilizer discharged into the device falls alternately into the storage box of the two metering units of the
metering and discharging mechanism. Once the gravity of the fertilizer in the storage box is greater than the suction
of the electromagnetic sucker, the fertilizer discharging board is automatically opened for fertilizer discharge, and
the metering pulse signal is accumulated once. Meanwhile, the fertilizer guide plate is driven by the
electromagnetic commutator to reverse the material, and then another storage box is started for fertilizer storage
and metering. In this approach, online detection of fertilizer flow can be realized by repeatedly guiding and
reversing and metering the incoming fertilizer. According to the single metering fertilizer quality and the number
of metering pulse signals, the fertilization amount can be calculated in real-time.The performance of the device
was verified by bench test. The test results indicated that: The established fertilizer application detection model is
a quadratic function (R2>0.98), and the verification error was less than 3.73% in the detection of alternating cycle
fertilizer discharge; the coefficient of determination (R2) and the root mean square error (RMSE) reached 0.992
and 9.858 respectively, indicating high detection accuracy of the device is.
Keywords: fertilization amount, fertilizer mass flow, mechanical fertilization, moment balance principle, fertilizer
guide mechanism, fertilizer discharging mechanism
1. Introduction
Variable fertilizer application is an important part of precision agriculture because it can improve fertilizer
utilization, increase crop yield, and reduce soil and water pollution, thus promoting sustainable agricultural
development and reducing agricultural surface source pollution (Zhu and Jin, 2013; Kamilaris et al., 2017;
de Araujo Zanella et al., 2020; Li et al., 2021; Jia et al., 2021). In the process of mechanical fertilization,
online monitoring of fertilizer mass flow is a key link and technical prerequisite for precise variable fertilization
contro (Chen et al., 2017; Hong et al., 2015; Chen et al., 2013; Zhai et al., 2022; Liu et al., 2020).
Currently, the main methods of fertilizer mass flow detection include the capacitance method, the mass method,
the imaging method, the photoelectric method, and the indirect measurement of the fertilizer discharge shaft. The
capacitance method uses fertilizer as a dielectric and designs an online detection system for fertilizer application
based on the difference in the dielectric properties of fertilizer and air, thus achieving individual monitoring of
fertilizer application in each discharge pipe (Zhou et al., 2010, 2017). Also, capacitive sensors consisting of
adjacent electrode plates can be sued to detect the decline degree in the fertilizer tank level, and the relationship
between the capacitance value between adjacent electrodes and the amount of fertilizer applied can be established,
thereby enabling real-time detection of fertilizer flow (Zhao et al., 2019a, 2019b). The quality method realizes
the real-time flow of fertilizer at the discharge port and the amount of fertilizer per unit area of the fertilizer
applicator according to the difference between the total mass of fertilizer and the current residual mass by designing
a dynamic weighing system (van Bergeijk et al., 2001) or a fertilization performance detection device based
on belt scale (Yu et al., 2016). The imaging method uses a CCD (Charge Coupled Device) camera to obtain



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 38       Published by IDEAS SPREAD


images of the falling of granular fertilizer, and then it adopts image recognition technology to obtain the diameter
and quantity of fertilizer particles and combines fertilizer density information to achieve online monitoring of the
mass flow of discharged fertilizer (Back et al., 2014). The photoelectric method mainly uses photoelectric
sensors to realize online monitoring of fertilizer particle flow. For example, Swisher et al. (2002) designed a sensor
for measuring the flow condition of fertilizer particles in the airflow by using a laser generator and a photoelectric
sensor; Grift et al. (2001) investigated the relationship model between the output pulse width of the near-infrared
photoelectric detector and fertilizer flow rate, and then the detection accuracy of photoelectric flow sensors was
verified in the laboratory under different density and flow rate conditions. The indirect measurement method of
fertilizer discharge shaft mainly uses Hall sensors and encoders (Zhao et al., 2010), etc. to monitor the rotation
circumference and angle of the fertilizer discharge shaft in real time and establishes their relationships with the
amount of fertilizer discharged to indirectly achieve real-time monitoring of fertilizer mass flow.
The comprehensive analysis of the existing fertilizer mass flow detection methods shows that the capacitance
method is less costly and more sensitive, but it is susceptible to electromagnetic interference, changes in fertilizer
moisture content, and environmental humidity; the mass method has high measurement accuracy, but it cannot
well adapt to practical applications; the photoelectric and image methods are fast, but their detection equipment is
susceptible to fertilizer powder; the indirect measurement of the fertilizer discharge shaft is simple and easy to
implement, but it suffers from a large measurement error. Besides, most of the above-mentioned detection methods
require pre-assembly or have a high correlation with the mechanical fertilizer discharge structure (Gao, 2016;
Yang et al., 2020; Jin et al., 2018). Aiming at the above problems, this paper designs an online fertilizer
application amount device based on the moment balance principle. This device can be connected with the discharge
pipe of the existing fertilizer application machinery to realize online real-time monitoring of fertilizer application
amount in a low-cost universal post-installation way. It can provide real-time feedback to the fertilizer application
machinery for precise variable fertilizer application control, thus improving the intelligence of the existing small
and medium-sized fertilizer application machinery.
2. Structure Design
2.1 Overall Structure Design
The overall structure of the fertilizer amount online detection device and its prototype are shown in Figure 1. It is
mainly composed of two parts: a fertilizer guide mechanism and a metering and discharging mechanism. The
fertilizer guide mechanism is connected with the fertilizer discharge pipe of the external fertilizer applicator
through its inlet port, and it is used to introduce the fertilizer into the device and change the flow direction,
discharge, and buffering of the fertilizer. The metering and discharging mechanism detects and discharges the
imported fertilizer in real-time, and it maintains the continuity of the fertilizer discharge through the device to the
greatest extent.



(a) (b)

Figure 1. The structure and picture of the device. (a) The structure (b) The picture of the device




as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 39       Published by IDEAS SPREAD


2.2 Design of Key Components
2.2.1 Fertilizer Guide Mechanism
The fertilizer guide mechanism is mainly composed of a feed fertilizer inlet, a fertilizer guide plate, two fertilizer
guide tubes, and two electromagnetic commutators. Its structure is illustrated in Figure 2. The fertilizer guide plate
is installed between the fertilizer inlet and the guide fertilizer pipe through the rotating shaft, and the fertilizer can
only flow into one of the guide fertilizer pipes within a certain period. Through the installation of the fertilizer
guide plate on both sides of the electromagnetic commutator (model XRN-19X42TL, energized to generate
instantaneous thrust, power-off self-reset, voltage 12VDC, stroke 10 mm), fertilizer is fed into the switch two
guide fertilizer pipe to drive the fertilizer guide plate to control the left and right commutation and guide fertilizer
pipe embedded slope to buffer.


Figure 2. The schematic diagram of the guide fertilizer mechanism structure. 1. Fertilizer inlet 2.

Electromagnetic commutator Ⅰ 3. Electromagnetic commutator Ⅱ 4. Guide fertilizer pipe Ⅰ 5. Guide fertilizer pipe
Ⅱ 6. Fertilizer guide plate 7. rotating shaft


2.2.2 Metering and Discharging Mechanism
The metering and discharging mechanism is composed of two identical units set side by side, each of which
includes a fertilizer storage box, a fertilizer discharging board, an electromagnetic sucker, a reset motor for the
fertilizer discharging board, a measurement and control circuit, a PWM voltage regulating module, etc. The
schematic diagram of the structure is presented in Figure 3. The inlets of the two fertilizer storage boxes are
connected with the outlets of the two guide fertilizer pipes respectively. The bottom of the fertilizer storage box is
an open structure, and it is blocked by the fertilizer discharging board. The fertilizer discharging board is designed
as a ‘seesaw’ structure that rotates counterclockwise around a fixed rotating shaft (with a maximum rotation angle
of 78.6°). One end of the fertilizer discharging board is embedded with a magnetic sheet. Under the suction of a
fixed electromagnetic sucker (model XDA-08/20, voltage range 0~12 V, suction range 0~150 g), the fertilizer
discharging board is in a horizontal state, and the other end of the plate is completely enclosed at the bottom of the
fertilizer storage box. Only when the gravity of fertilizer in the storage box is greater than the suction force of the
electromagnetic disk, the horizontal state of the fertilizer drainage plate is broken, and a counterclockwise rotation
is generated, which makes the bottom of the storage box open for fertilizer drainage. Because the fertilizer storage
box is designed of 6.2, 4.0, and 3.6 cm and the fertilizer bulk density is about 900~1200 kg/cm³, the maximum
fertilizer storage capacity is 80.3~107 g. To adapt to different fertilizer application requirements and not affect the
fertilizer application continuity, a PWM voltage regulating module is designed to adjust the suction force of the
electromagnetic sucker, which in turn changes the single metering and fertilizer discharge of the fertilizer storage
box, thus adjusting the quality of the fertilizer.
Meanwhile, a photoelectric fertilizer leakage detection sensor is designed on the inner wall of the housing in the
rotation path of the fertilizer discharging board. The detection sensor is triggered when the fertilizer discharging
board rotates counterclockwise and outputs a counting pulse, indicating that a mass measurement of the fertilizer
storage box has been performed. Also, a limit-type detect the fertilizer guide sensor is designed under the fertilizer
discharging board to detect the fertilizer discharge situation of the fertilizer discharging board, thus controlling the
operation of the electromagnetic commutator and driving the fertilizer discharging board to change the direction
of fertilizer flow from the left to right. In this way, fertilizer is alternately introduced into the fertilizer storage box
to realize alternate metering and storage and discharge of fertilizer in the two units; a limit-type reset detection



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 40       Published by IDEAS SPREAD


sensor is designed on the rightmost side of the fertilizer storage box to determine whether the fertilizer discharging
board is reset to the horizontal after the fertilizer storage box is emptied. If the fertilizer discharging board is not
reset, it will control the fertilizer discharging board reset motor to drive the drive rod to rotate, forcibly reset the
fertilizer discharging board to the horizontal state, and make the fertilizer discharging board reset motor to return
to the initial state, thus ensuring that the fertilizer discharging board can be reset properly next time.



Figure 3. The structure diagram of the metering and fertilizer discharging mechanism. 1. Fertilizer leakage
detection sensors 2. Reset detection sensors 3. Magnetic sheet 4. Discharge fertilizer board reset lever 5. Detect

the fertilizer guide sensor 6. Electromagnetic sucker 7. PWM voltage regulating module 8. Circuit control box 9.
Fertilizer outlet 10. Fertilizer discharging board 11. Rotating shaft 12. Reset motor 13. Fertilizer storage box 14.

Buffer plate Ⅰ 15. Buffer plate Ⅱ 16. Guide fertilizer pipe


3. Detection Principle
According to the design structure, after the discharge fertilizer from the fertilizer applicator falls into this device,
online real-time detection of fertilizer application can be realized through alternate metering and discharge of
fertilizer by two metering units under the synergistic action of the fertilizer guide mechanism and the metering and
discharging mechanism, as shown in Eq. (1). Q m f m f                                      (1)
where Q is the detected value of fertilizer application volume (unit: g); m1 and m2 are the single fertilizer discharge
mass of the two fertilizer storage boxes at a specific metering voltage (unit: g), and their values are set by the PWM
voltage regulating module, i.e., by adjusting the electromagnetic sucker suction force; f1 and f2 are the pulse signal
counts of the two fertilizer storage boxes for fertilizer drainage.
The single measurement and discharge of fertilizer in each fertilizer storage box is conducted according to the
principle of moment balance. Specifically, during the operation of the device, the fertilizer discharging board takes
the rotating shaft as the rotating fulcrum, one end of which is subjected to the suction of the electromagnetic sucker,
and the other end is subjected to the gravity of the fertilizer in the fertilizer storage box. When the gravity of the
fertilizer is equal to the suction of the electromagnetic sucker, the moment reaches a critical equilibrium state, as
shown in Formula (2). Once the gravity in the fertilizer storage box is greater than the suction of the
electromagnetic sucker, the critical equilibrium state is broken, and the metering and discharging of the fertilizer
are started. Figure 4 shows the stress analysis diagram of the fertilizer discharging board during fertilizer detection.



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 41       Published by IDEAS SPREAD




Figure 4. The schematic diagram of the force analysis of the fertilizer discharging board during fertilizer
quality detection

 mg F                                        (2)
where m is the mass of fertilizer in the storage box (unit: kg); g is the coefficient of gravity (unit: N/kg); F is the
electromagnetic suction force (unit: N). The specific value is closely related to the suction cup electromagnet
structure and material (Jia et al., 2012; Liang et al., 2021; Tang et al., 2019; Ning et al., 2021; Ding
et al., 2021), as shown in Eq. (3). F ²                                         (3)

where S is the effective area of the suction surface (unit: mm2); μ0 is the vacuum permeability, 4π×10-7N/A2; B is
the magnetic induction intensity of the air gap between the contact surfaces (unit: T), and its value is calculated by
Eq. (4). B nIμ                                        (4)
where n is the number of turns of the coil, and I is the circuit current (unit: A). According to Equations (1) to (4)
and Ohm's law, the calculation method of fertilizer application detection is derived and shown in Eq. (5). Q ² ²  f  u f  u                               (5)

Since n,μ0, s, and R are constants, the fertilizer application quantity Q is only related to the drainage fertilizer pulse
signal count f and metering voltage u. Usually, the metering voltage u is set by the PWM voltage regulating module
before the device works, and once it is set, it determines the electromagnetic sucker suction force and thus the
single discharge mass of the fertilizer storage box, i.e., establishes the correspondence between the metering
voltage u and the single discharge mass of the fertilizer storage box. Therefore, online detection of fertilizer
application can be achieved by detecting the number of pulses of the corresponding discharge signal of two
fertilizer storage boxes at a specific metering voltage.
4. Online Detection System Design
4.1 Hardware Circuit Design
The hardware circuit mainly includes a power supply, signal acquisition circuit, an ATmega328 micro-controller
main controller, metering and the control circuit of the metering and guide fertilizer mechanism, the reset circuit
of the discharge board, an LCD module, etc., as shown in Figure 5.



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 42       Published by IDEAS SPREAD



Figure 5. The diagram of the Device core control circuit


12V linear DC stabilized voltage power supply is used, and it provides a stable operating voltage after step-down
for each circuit unit. The main control system of the ATmega328 single-chip microcomputer is exploited to collect
the measurement voltage and the signal of each sensor, realize interrupt counting, calculate fertilizer amount, and
drive the electromagnetic commutator to control the commutation of the guide plate, thus controlling the reset of
the stepper motor and driving the LCD. The LCD module is used to display the relevant information of the online
detection of fertilizer amount.
The signal acquisition circuit mainly includes the infrared photoelectric sensor and the limit sensor to detect the
fertilizer discharge action of the fertilizer discharging board (each time the fertilizer is discharged, a counting pulse
is output), the reset situation, and the measurement suction cup to control signal. The control circuit of the metering
and fertilizer guide mechanism is composed of a PWM voltage regulating module, an RC filter circuit, an
electromagnetic commutator, and a sensor. It controls the power acquisition of the metering sucker, guides fertilizer
application with the electromagnetic commutator, and resets the fertilizer discharging board. The reset circuit of
the fertilizer discharging board consists of a 12V stepping motor and its driver DRV8825 When the main controller
detects that the fertilizer discharging board is not reset, the reset stepper motor is controlled to rotate 78.6°
clockwise to drive the fertilizer discharging board to quickly reset to the initial position. Besides, the control and
execution of the mechanism are assisted by a control 4-way 12V relay.
4.2 Software Design
Based on the Arduino IDE development environment, the design is implemented with C++ programming language
in a modular approach. Its main functions include system initialization, real-time acquisition and processing of
metering voltage, calling delay function, real-time acquisition of sensor signal, interrupt signal detection and
interrupt counting, fertilization calculation based on the detection model, and driving the OLED LCD screen to
display fertilization information in real-time. The main program flow is presented in Figure 6.



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 43       Published by IDEAS SPREAD


Start

System initialization and
parameter configuration

Set metering voltage

Fertilizer discharge plate I start?

Metering unit Ⅰpulse count plus 1

Trigger fertilizer guide signal Ⅰ

Leakage fertilizer plate I has been reset?

Fertilizer discharge plate II start?

Metering unit II pulse count plus 1

Trigger fertilizer guide signal II

Leakage fertilizer plate II has been reset?

Start the reset motor

Does the reset motor start within 5s?

Start the reset motor again

Start the reset motor

Does the reset motor
start within 5s?

Start the reset motor again

Calling the model to calculate the
fertilizer amount

Display fertilizer amount
information

N

Y

N

Y

Y

Y

Y

Y

N

N

N

N


Figure 6. The program flow of the fertilizing amount detection system


After the system is powered on and initialized, the metering voltage is obtained in real-time through the A/D
conversion port of the single-chip microcomputer. Meanwhile, the single-discharge fertilizer quality of the current
two fertilizer storage boxes is determined according to the mathematical relationship between the metering voltage
obtained by the experiment and the single-discharge fertilizer quality of the two fertilizer storage boxes. Then, the
fertilizer discharge is detected in real-time, and fertilizer discharging board I and II are set: when the fertilizer
discharge signal of fertilizer discharging board I is detected, the pulse signal of the metering unit I is added to 1 by
interrupt counting, and fertilizer guide signal I is triggered to drive the fertilizer discharging board to guide the
material. Also, reset and the corresponding control are performed according to the detection of fertilizer
discharging board I; when the reset situation of fertilizer discharging board I is not detected within 5s, the delay
function is called, and the reset motor is energized to forcibly reset fertilizer discharging board I. The measurement
and control of the discharge and reset of fertilizer discharging board Ⅱ is the same as that of fertilizer discharging
boardⅠ. Finally, the number of pulses of metering units Ⅰ and Ⅱ are substituted into the calculation model of fertilizer
application amount based on Eq. (5) and the experiment, and the real-time information of fertilizer application
amount can be obtained and displayed on the OLED LCD screen.
5. Test results and Analysis
5.1 Test Materials and Methods
To test the performance of the device designed in this paper, a test bench shown in Figures 7 and 8 was built with
a uniform and non-clumping granular compound fertilizer commonly used in agricultural production.



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 44       Published by IDEAS SPREAD




Figure 7. The test bench of the online fertilizer application amount detection device


Figure 8. Performance verification test bed for fertilizer application amount detection


In the test bench, the electric fertilizer discharge device with adjustable speed (Xingbang, 12V/50W) driven by a
stepping motor is used to feed the detection device for the amount of fertilizer, and the multi-channel adjustable
DC regulated power supply (Suzhou Guwei Electronics GPC-3060D, 30V/3A) is used to supply power to the
fertilizer device. By adjusting the power supply voltage, the rotation speed and the fertilizer amount of the fertilizer
applicator are changed to test the fertilizer detection performance of the device at different rotation speeds, and the



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 45       Published by IDEAS SPREAD


test bench is placed on the conveyor belt device to carry out the fertilizer detection performance verification test.
The experiments were mainly conducted in three aspects: the influence of fertilizer discharging speed of the
fertilizer applicator on the detection device, the mathematical relationship between fertilizer quality and metering
voltage, and the fertilizer application volume detection model and its performance verification.
Through the test bench shown in Figure 7, the influence of the fertilizer discharge speed of the fertilizer applicator
on the detection device and the mathematical relationship between the fertilizer quality and the measurement
voltage were investigated. The measurement voltage of the detection device was verified by the bench-type digital
multimeter (model GDM-8352). The quality of the fertilizer flowing through the detection device was measured
by the mass weighing method, i.e., the fertilizer quality collected at the electronic scale (model SL4001, 4000±0.1
g) was used for confirmatory measurement.
Since the device is used to detect the fertilizer mass flow rate of the external fertilizer applicator, the performance
of fertilizer application amount detection is verified by the test bench shown in Figure 8 according to the
'Fertilization Machinery Quality Evaluation Specification' (NY/T1003-2006) and the 'Fertilization Machinery Test
Method' (GB/T20346.2-2006, Part2: Standards for Inter-row Fertilizer Applicators). During the test, the tape
measure was used to measure the length of the strip, the 6236P tachometer was used to detect the speed of the
conveyor belt (Lai et al., 2022; Chen et al., 2015; Ding et al., 2019), and the stopwatch was used for
fertilizer timing.
5.2 Test Results and Analysis
5.2.1 Effect of the Rotation Speed of Fertilizer Applicator on Detection Performance
According to the field operation speed of the machine, the fertilizer discharging speed of the fertilizer applicator
is generally 10-60 r/min (its discharging fertilizer mass range is about 200-900 g/min) (Chen et al., 2015; Ding
et al., 2019). To test the effect of fertilizer applicator discharge speed on the detection performance of the device,
the fertilizer applicator discharge speed was set to 10 r/min, 25 r/min, 35 r/min, 45 r/min, 55 r/min, and 60 r/min,
respectively. Meanwhile, the working voltage range of the metering electromagnetic sucker is 0-12 V. After the
pre-test, it was found that when the metering voltage of the electromagnetic sucker is set below 4 V, the single
fertilizer metering value of the metering unit is smaller than 10 g, and there is a large detection error. When the
metering voltage is set to 10 V or higher, the single fertilizer measurement value of the metering unit is larger than
40 g, and the continuity of the fertilizer discharge after the fertilizer application volume detection does not meet
the fertilization requirement. Therefore, the working voltage range of 4-10 V, 5 V, 7 V, and 9 V were selected as
the metering voltage of metering units I and II, respectively. Then, the single-factor test was conducted, and the
significance of the influence of the rotation speed of the fertilizer under each metering voltage was analyzed. Each
test was repeated six times, and the average value was taken as the final test result. During the test, the fertilizer
flow direction was manually controlled and switched, the two metering units were tested under different metering
voltages, and the fertilizer metering values of the two metering units were weighed and compared one at a time.
As indicated by the ANOVA in Table 1, the P values among the groups are 0.13, 0.76, 0.14, 0.55, 0.28, and 0.49,
and they are all greater than 0.05. This demonstrates that the guide mechanism of the device has a good buffering
effect on fertilizer falling at different speeds and achieves good applicability and detection performance within the
conventional discharge speed (10-60 r/min) of the fertilizer applicator. Thus, the influence of the external fertilizer
applicator speed on the detection of fertilizer applied to the device is not significant and can be ignored.





as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 46       Published by IDEAS SPREAD


Table 1. Analysis of variance results for different metering voltages in metering units I and II
metering unit metering voltage  SS df MS F P-value F crit

Ⅰ 5V Inter-group 2.73 7 0.39 1.71 0.13 2.25
Within Group 9.13 40 0.23
Grand total 11.86 47

7V Inter-group 5.71 7 0.82 0.59 0.76 2.25
Within Group 55.21 40 1.38
Grand total 60.93 47

9V Inter-group 4.76 7 0.68 1.69 0.14 2.25
Within Group 16.13 40 0.40
Grand total 20.89 47

Ⅱ


5V Inter-group 4.40 7 0.63 0.86 0.55 2.25
Within Group 29.32 40 0.74
Grand total 33.71 47

7V Inter-group 7.16 7 1.02 1.29 0.28 2.25
Within Group 31.72 40 0.79
Grand total 38.88 47

9V Inter-group 2.44 7 0.35 0.94 0.49 2.25
Within Group 14.82 40 0.37
Grand total 17.26 47


5.2.2 Establishment of Fertilization Amount Detection Model
According to the structure of the metering unit of the device and the principle of fertilizer application detection,
determining the correspondence between the metering voltage of the metering unit and the mass of a single
discharge of fertilizer in the storage box is the basis and key to establishing the fertilizer application detection
model. Basically, the detection performance of the fertilizer amount of the device is not affected by the rotation
speed of the external fertilizer applicator, so the test was conducted under the condition that the rotation speed of
the fertilizer applicator is 40 r/min according to the requirements of the conventional operation. Before the test,
the measurement voltage was set by the PWM voltage regulating module, and the working voltage of the
electromagnetic sucker was set at a step of 0.5 V in the range of 4-10 V. During the test, for each metering voltage,
the selected fertilizer was gradually poured into the testing device from small to large in the range of 10-90 g until
the mass of the poured fertilizer is equal to the critical discharge volume of the fertilizer discharging board (i.e.,
thus triggering the fertilizer discharging board discharge action). This process was repeated 10 times, and the
average value was taken as the test result. To avoid the error caused by the manufacturing difference between the
electromagnetic sucker and the metering unit, two metering units were tested respectively. The test results are
presented in Figure 9. Generally, the mathematical models between the metering voltage of the two metering units
and the critical discharge amount of the fertilizer discharging board are the same, and only the coefficients are
different.



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 47       Published by IDEAS SPREAD




(a) (b)
Figure 9. The relationship between critical fertilizer discharge and metering voltage for fertilizer discharging

boards. (a)metering unit Ⅰ(b) metering unit Ⅱ


Based on the test results in Figure 9, Eq. (5), and the principle of fertilizer application detection, the fertilizer
application detection model shown in Eqs. (6) ~ (8) can be obtained. 𝑚 1.63𝑢 12.64𝑢 40.25 𝑓                             (6) 𝑚 1.1𝑢 11.07𝑢 42.75 𝑓                              (7)

M=𝑚 +𝑚                                        (8)

where m1 and m2 are the critical fertilizer discharge of the discharge plate of metering units I and II, respectively
(unit: g); u1 and u2 are the metering voltage of metering units I and II, respectively, (unit: V); f1 and f2 are
respectively the pulse number of discharge plate fertilizer action counting of metering units I and II; m is the
amount of fertilizer detected by the device (unit: g).
5.2.3 Fertilization Detection Performance Verification
Following the design structure and the detection principle, based on the single detection amount of the two
metering units (i.e., the critical fertilizer discharge amount of the fertilizer discharging board), the device realizes
online detection of the fertilizer mass flow according to the pulse number of the fertilizer discharge action of the
fertilizer discharging board, which does not affect the fertilizer discharge effect of the fertilizing machine.
Therefore, the test was mainly conducted from two aspects: the amount of fertilizer online detection and fertilizer
performance verification.
The fertilizer application amount online detection test includes a single detection amount of the metering unit and
an online detection test of the fertilizer mass flow rate of the device. It is shown above that the fertilizer discharge
speed of the external fertilizer applicator has no significant effect on the detection performance, and the detection
of fertilizer amount is closely related to the metering voltage. Thus, in the verification test of single detection and
online detection of fertilizer mass flow, the rotation speed of the fertilizer applicator was set to 40 r/min, and the
test was conducted under three measurement voltages of 5 V, 7 V, and 9 V. For each metering voltage, each test
was repeated 10 times, and the mean value was taken as the test result. The accuracy of fertilizer application
detection was verified by the weighing method. The accuracy verification results of online detection of fertilization
amount are listed in Tables. 2 and 3.





as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 48       Published by IDEAS SPREAD


Table 2. The verification results of metering unit single test accuracy
Metering unit Metering voltage/v Measuring mass/g Real mass/g Relative error/%

Ⅰ
5V 18.93 19.58 3.32
7V 33.24 33.95 2.09
9V 54.45 55.58 2.03

Ⅱ
5V 16.68 16.1 3.60
7V 25.57 24.78 3.19
9V 38.75 37.4 3.61


Table 3. Fertilizer mass flow online testing accuracy verification results

Metering voltage/v Experiment serial number Measuring mass/g Real mass/g Relative error/%




5V




7V




9V




1
2
3

1
2
3

1
2
3



163.24
276.04
341.34


285.02
386.38
456.1


271.56
452.6
511.1


169.58
283.36
330.25


275.15
374.72
470.28


279.36
462.82
518.72


3.73
2.58
3.35


3.58
3.11
3.01


2.79
2.2

1.46


Table 2 presents the verification result of the single detection accuracy of the two metering units, and the detection
error is less than 3.61 %. Table 3 presents the verification results of the online detection accuracy of the fertilizer
mass flow rate of the device, and the detection error is less than 3.73 %. These results indicate that the device has
high detection accuracy and can be well applied to online detection of fertilizer mass flow of fertilization machinery.
The fertilizer discharge performance test includes the fertilizer discharge effect test of the device, and the fertilizer
application amount detection accuracy analysis test. In the first test, the height of the falling fertilizer point and
the drive belt was set to 30 mm; meanwhile, the fertilizer applicator discharge speed was set to 40 r/min, and the
drive belt speed was set to 0.37 m/s so that the two speed paces are consistent. Besides, the fertilizer metering
values were set to 20 g, 25 g, and 35 g, and the unit metering voltage values corresponding to the two metering
units were set to 5.5 V, 6.3 V, 7.3 V, and 7.2 V, 8.1 V, 9.3 V respectively. Let the fertilizer applicator and the drive
belt work in a unit of 1 m and a normal cumulative travel of 10 m, and then the test section of the broken strips
was observed and recorded.



(a) (b) (c)

Figure10. Fertilizer discharge effect of the fertilizer application detection device. (a) 20 g (b) 25 g (c) 35 g


By observing the measuring area of the fertilizer discharge uniformity test with fertilizer metering values of 20 g,
25 g, and 35 g, the continuity of fertilizer discharge was obtained according to the broken strips of the fertilizer.



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 49       Published by IDEAS SPREAD


The field fertilization standards indicate that there is no fertilizer during normal operations of the machine section
length greater than 10cm above identified as broken bars. The fertilizer discharge effect of the device is illustrated
in Figure 10. The test results show that the fertilization broken strips rate is 0, indicating that the detection device
does not affect the fertilizer discharge performance of the external fertilization machine when the fertilizer mass
flow is carried out.
In the accuracy analysis test of fertilizer application amount detection, the parameters were set the same as the
above, and the online detection results of single detection amount and fertilizer mass flow rate were analyzed.
Then, the fertilizer application amount detection results of the detection device shown in Figure 11 were compared
with the mass obtained by the weighing method.





(a) (b)

Figure 11. Comparison of the actual quality and detection quality. (a) Comparison of the actual quality and single
detection quality (b) Comparison of the actual quality and detection quality of alternating discharge fertilizer

quantity by a measurement unit


It can be seen from Figure 11 that the amount of fertilizer detected by the device is consistent with the actual
amount of fertilizer. For the single detection amount, the determination coefficient R2 and the root mean square
error RMSE are 0.995 and 0.873, respectively; for the fertilizer mass flow rate detection, the determination
coefficient R2 and root mean square error RMSE reached 0.992 and 9.858 g/g, respectively, indicating that the
device has high detection accuracy.
6. Conclusion
(1) Based on the moment balance principle, this paper designs an online detection device for fertilizer application
rate, which has a simple structure and no need for pre-installation. It can be installed on the fertilizer discharge
port of fertilization machinery to realize online detection of fertilizer mass flow, and the single detection amount
of the metering unit can be adjusted according to the actual operation requirements to ensure the continuity of its
fertilization.
(2) The fertilizer guide mechanism has a good buffering effect on the fertilizer falling at different speeds. For the
commonly used fertilizer discharge speed (10~60 r/min) of the fertilizer applicator, the metering units I and II were
measured at 5 V, 7 V, and 9 V, respectively. The P values between the groups of the rotation speed of the fertilizer
are 0.13, 0.76, 0.14, 0.55, 0.28, and 0.49 respectively, which are greater than 0.05, indicating that the rotation speed
of the external fertilizer applicator has no significant effect on the detection performance of the fertilizer
application rate of the device. Thus, the device has good applicability and consistency of detection performance.
(3) The fertilizer detection model (R2 > 0.98) was established, and the detection performance of the device was
verified through experiments. The test results showed that the single detection error of the two metering units is
less than 3.61 %, and the detection error of fertilizer mass flow is less than 3.73 %. The determination coefficient
(R2) and the root mean square error (RMSE) reached 0.992 and 9.858, respectively. When the fertilizer
measurement value of the metering unit was less than 35 g, the fertilization broken strips rate was 0, indicating



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 50       Published by IDEAS SPREAD


that the fertilizer discharge effect of the external fertilization machinery was not affected. Therefore, the device
can be well applied to the online detection of fertilizer mass flow of fertilization machinery.
In this paper, the principle of moment balance is adopted to realize the online detection of fertilizer. At present, the
uneven field in the mechanical fertilization process will lead to the bump and jitter of the fertilizer applicator. In
the previous test, the influence of the bump and jitter of the working fertilizer applicator on the detection device is
not considered. Therefore, in the follow-up study, we will investigate the anti-shake of the detection device to
improve the detection device’s adaptability.
Acknowledgments
Funding received from National Natural Science Foundation of China (52069008), Basic Research Project of
Yunnan Province (202101AT070113).
References
Back, S. W., Yu, S. H., Kim, Y. J., Chung, S. O., & Lee, K. H. (2014). An image based application rate measurement

system for a granular fertilizer applicator. Transactions of ASABE, 57, 679-687.
https://doi.org/10.13031/trans.57.10605

Chen, G., Ma, L., & Chen, H. (2013). Research status and development trend of precision fertilization technology.
Journal of Jilin Agricultural University, 35, 253-259. (in Chinese).
https://doi.org/10.13327/j.jjlau.2013.03.012

Chen, J., Zhao, B., Yi, S., Ge, T., & Xiao, Y. (2017). Research on present situation and the development
countermeasures of variable rate fertilization technology in China. Journal of Agricultural Mechanization
Research, 39, 1-6. (in Chinese). https://doi.org/10.13427/j.cnki.njyi.2017.10.001

Chen, M., Shi, Y., Wang, X., Sun, G., & Li, Y. (2015). Design and experiment of variable rate fertilizer applicator
based on crop canopy spectral reflectance. Transactions of the Chinese Society for Agricultural Machinery,
46, 26-32. (in Chinese). https://doi.org/10.6041/j.issn.1000-1298.2015.05.005

De Araujo Zanella, R. A., da Silva, E., & Pessoa Albini, L. C. (2020). Security challenges to smart agriculture:
Current state, key issues, and future directions. Array, 8, 100048.
https://doi.org/org/10.1016/j.array.2020.100048

Ding, X., Cui, D., Liu, T., Wang, S., & Zhao, L. (2019). Optimization design and experiment of precision variable
fertilizer device. Journal of Chinese Agricultural Mechanization, 40, 5-12. (in Chinese).
https://doi.org/10.13733/j.jcam.issn.2095-5553.2019.01.02

Ding, Y., Liu, Z., Chen, C., Liu, H., Luo, J., & Yu, H. (2021). Functional detection method of application rate based
on principle of dynamic weighing. Transactions of the Chinese Society for Agricultural Machinery, 52, 146-
154. (in Chinese). https://doi.org/10.6041/j.issn.1000-1298.2021.10.015

Gao, F. (2016). Optimization and experimental study on seeding and fertilizing Performance of suction maizeno-
till seeder. Shenyang: Shenyang Agricultural University. (in Chinese). Retrieved from
https://kns.cnki.net/KCMS/detail/detail.aspx?dbname=CMFD201701&filename=1016149299.nh

Grift, T. E., Walker, J. T., & Hofstee, J. W. (2001). Mass flow measurement of granular materials In aerial
application part2: Experimental model validation. Transactions of the ASAE, 44, 27-34.
https://doi.org/10.13031/2013.2299

Hong, C., Liu, M., & Li, W. (2015). Evaluation on the policies of non-point pollution control of chemical fertilizer
in China. Journal of Arid Land Resources and Environment, 29, 1-6. (in Chinese).
https://doi.org/10.13448/j.cnki.jalre.2015.107

Jia, H., Li, M., & Lu, J. (2012). Research and application of object center of gravity measuring system based on
torque balance theory. Weighing Apparatus, 41, 5-9. (in Chinese).    https://doi.org/10.3969/j.issn.1003-
5729.2012.08.003

Jia, H., Wen, X., Wang, G., Liu, H., & Guo, H. (2020). Design and experiment of mass flow sensor for granular
fertilizer. Transactions of the Chinese Society for Agricultural Machinery, 51, 130-136. (in Chinese).
https://doi.org/10.6041/j.issn.1000-1298.2020.S1.015

Jin, X., Li, Q., Yuan, Y., Qiu, Z., Zhou, L., & He, Z. (2018). Design and test of 2BFJ-24 type variable fertilizer and
wheat precision seed sowing machine. Transactions of the Chinese Society for Agricultural Machinery, 49,
84-92. (in Chinese). https://doi.org/10.6041/j.issn.1000-1298.2018.05.010



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 51       Published by IDEAS SPREAD


Kamilaris, A., Kartakoullis, A., & Prenafeta-Boldú, F. X. (2017) A review on the practice of big data analysis in
agriculture. Computers and Electronics in Agriculture, 143, 23-37.
https://doi.org/10.1016/j.compag.2017.09.037

Lai, Q., Jia, G., Su, W., Zhao, L., Qiu, X., & Lv, Q. (2022). Design and test of chain-spoon type precision seed-
metering device for ginseng based on DEM-MBD coupling. Transactions of the Chinese Society for
Agricultural Machinery, 53, 91-104. (in Chinese). https://doi.org/10.6041/j.issn.1000-1298.2022.03.009

Li, P., Liang, C., Wang, Z., Wang, S., Wang, P., & Zhang, R. (2021). Research status and suggestions of precision
variable rate fertilization technology in China. Agricultural Engineering, 11, 31-34. (in Chinese).
https://doi.org/10.3969/j.issn.2095-1795.2021.11.008

Liang, H., Zhu, X., Zhang, K., You, J., & Xie, Y. (2021). Research on relation between electromagnetic force and
coil ampere turns of direct-acting electromagnetic mechanism. Low Voltage Apparatus, 1, 22-28+35. (in
Chinese). https://doi.org/10.3969/j.issn.1001-5531.2021.01.004

Liu, C., Lin, H., Li, Y., Gong, L., & Miao, Z. (2020). Analysis on status and development trend of intelligent
control technology for agricultural equipment. Transactions of the Chinese Society for Agricultural
Machinery, 51, 1-18. (in Chinese). https://doi.org/10.6041/j.issn.1000-1298.2020.01.001

Ning, J., Zhang, C., Li, Y., Li, T., Zhou, Q., & Zheng, W. (2021). Research on residual magnetic attraction of the
Electromagnet Disk. Small & Special Electrical Machines, 49, 26-28. (in Chinese).
https://doi.org/10.3969/j.issn.1004-7018.2021.01.007

Swisher, D. W., Borgelt, S. C., & Sudduth, K. A. (2002). Optical sensor for granular fertilizer flow rate
measurement. Transactions of the ASAE, 45, 881-888. https://doi.org/10.13031/2013.9934.

Tang, J., Zhu, Z., Han, W., Qiu, Z., Xi, J., Yi, Y., & Yang, J. (2019) Optimal simulation design of DC solenoid
electromagnet. Low Voltage Apparatus, 22, 36-39. (in Chinese). https://doi.org/10.16628/j.cnki.2095-
8188.2019.22.007

van Bergeijk, J., Goense, D., van Willigenburg, L. G., & Speelman, L. (2001). PA—Precision Agriculture:
Dynamic weighting for accurate fertilizer application and monitoring. Journal of Agricultural Engineering
Research, 80, 25-35. https://doi.org/10.1006/jaer.2001.0714

Yang, L., Huang, J., Zhang, J., Hu, H., Liu, G., & Lv, S. (2020). Mass flow measurement system of granular
fertilizer based on microwave doppler method. Transactions of the Chinese Society for Agricultural
Machinery, 51, 210-217. (in Chinese). https://doi.org/10.6041/j.issn.1000-1298.2020.S1.024

Yu, H., Ding, Y., Tan, X., Bi, W., Wang, B., & Ding, W. (2016). Design and experiments on equipment for detecting
performance of fertilizer applicator. Journal of Nanjing Agricultural University, 39, 511-517. (in Chinese).
https://doi.org/10.7685/jnau.201508024

Zhai, C., Yang, S., Wang, X., Zhang, C., & Song, J. (2022). Status and prospect of intelligent measurement and
control technology for agricultural equipment. Transactions of the Chinese Society for Agricultural
Machinery, 53, 1-20. (in Chinese). https://doi.org/10.6041/j.issn.1000-1298.2022.04.001

Zhao, B., Kuang, L., & Zhang, W. (2010). Seed and fertilizer intelligent Gauging and monitoring system of suction
precision seeder. Transactions of the CSAE, 26, 147-153. (in Chinese). https://doi.org/10.3969/j.issn.1002-
6819.2010.02.025

Zhao, M., & Wang, X. (2019a). Design and experiment of on-line measuring device for fertilizer box allowance
based on capacitance method. China Southern Agricultural Machinery, 1, 52, 60. (in Chinese).
https://doi.org/10.3969/j.issn.1672-3872.2019.01.036

Zhao, M., Wang, X., Qi, Z., & Tian, Y. (2019b) Design and test of electrode for material level detection sensor
based on COMSOL. China Agricultural Mechanization, 40, 158-163. (in Chinese).
https://doi.org/10.13733/j.jcam.issn.2095-5553.2019.04.28

Zhou, L., Ma, M., Yuan, Y., Zhang, J., Dong, X., & Wei, C. (2017). Design and test of fertilizer mass monitoring
system based on capacitance method. Transactions of the CSAE, 33, 44-51. (in Chinese).
https://doi.org/10.11975/j.issn.1002-6819.2017.24.006

Zhou, L., Zhang, X., & Yuan, Y. (2010). Design of capacitance seed rate sensor of wheat planter. Transactions of
the Chinese Society of Agricultural Engineering, 26, 99-103. (in Chinese).
https://doi.org/10.3969/j.issn.1002-6819.2010.10.015

Zhu, Z., & Jin, J. (2013). Fertilizer use and food security in china. Plant Nutrition and Fertilizer Science, 19, 259-



as.ideasspread.org   Agricultural Science Vol. 4, No. 2; 2022

 52       Published by IDEAS SPREAD


273. (in Chinese). https://doi.org/10.11674/zwyf.2013.0201

Copyrights
Copyright for this article is retained by the author(s), with first publication rights granted to the journal.
This is an open-access article distributed under the terms and conditions of the Creative Commons Attribution
license (http://creativecommons.org/licenses/by/4.0/).


















<<
  /ASCII85EncodePages false
  /AllowTransparency false
  /AutoPositionEPSFiles true
  /AutoRotatePages /None
  /Binding /Left
  /CalGrayProfile (Dot Gain 20%)
  /CalRGBProfile (sRGB IEC61966-2.1)
  /CalCMYKProfile (U.S. Web Coated \050SWOP\051 v2)
  /sRGBProfile (sRGB IEC61966-2.1)
  /CannotEmbedFontPolicy /Error
  /CompatibilityLevel 1.4
  /CompressObjects /Tags
  /CompressPages true
  /ConvertImagesToIndexed true
  /PassThroughJPEGImages true
  /CreateJobTicket false
  /DefaultRenderingIntent /Default
  /DetectBlends true
  /DetectCurves 0.0000
  /ColorConversionStrategy /CMYK
  /DoThumbnails false
  /EmbedAllFonts true
  /EmbedOpenType false
  /ParseICCProfilesInComments true
  /EmbedJobOptions true
  /DSCReportingLevel 0
  /EmitDSCWarnings false
  /EndPage -1
  /ImageMemory 1048576
  /LockDistillerParams false
  /MaxSubsetPct 100
  /Optimize true
  /OPM 1
  /ParseDSCComments true
  /ParseDSCCommentsForDocInfo true
  /PreserveCopyPage true
  /PreserveDICMYKValues true
  /PreserveEPSInfo true
  /PreserveFlatness true
  /PreserveHalftoneInfo false
  /PreserveOPIComments true
  /PreserveOverprintSettings true
  /StartPage 1
  /SubsetFonts true
  /TransferFunctionInfo /Apply
  /UCRandBGInfo /Preserve
  /UsePrologue false
  /ColorSettingsFile ()
  /AlwaysEmbed [ true
  ]
  /NeverEmbed [ true
  ]
  /AntiAliasColorImages false
  /CropColorImages true
  /ColorImageMinResolution 300
  /ColorImageMinResolutionPolicy /OK
  /DownsampleColorImages true
  /ColorImageDownsampleType /Bicubic
  /ColorImageResolution 300
  /ColorImageDepth -1
  /ColorImageMinDownsampleDepth 1
  /ColorImageDownsampleThreshold 1.50000
  /EncodeColorImages true
  /ColorImageFilter /DCTEncode
  /AutoFilterColorImages true
  /ColorImageAutoFilterStrategy /JPEG
  /ColorACSImageDict <<
    /QFactor 0.15
    /HSamples [1 1 1 1] /VSamples [1 1 1 1]
  >>
  /ColorImageDict <<
    /QFactor 0.15
    /HSamples [1 1 1 1] /VSamples [1 1 1 1]
  >>
  /JPEG2000ColorACSImageDict <<
    /TileWidth 256
    /TileHeight 256
    /Quality 30
  >>
  /JPEG2000ColorImageDict <<
    /TileWidth 256
    /TileHeight 256
    /Quality 30
  >>
  /AntiAliasGrayImages false
  /CropGrayImages true
  /GrayImageMinResolution 300
  /GrayImageMinResolutionPolicy /OK
  /DownsampleGrayImages true
  /GrayImageDownsampleType /Bicubic
  /GrayImageResolution 300
  /GrayImageDepth -1
  /GrayImageMinDownsampleDepth 2
  /GrayImageDownsampleThreshold 1.50000
  /EncodeGrayImages true
  /GrayImageFilter /DCTEncode
  /AutoFilterGrayImages true
  /GrayImageAutoFilterStrategy /JPEG
  /GrayACSImageDict <<
    /QFactor 0.15
    /HSamples [1 1 1 1] /VSamples [1 1 1 1]
  >>
  /GrayImageDict <<
    /QFactor 0.15
    /HSamples [1 1 1 1] /VSamples [1 1 1 1]
  >>
  /JPEG2000GrayACSImageDict <<
    /TileWidth 256
    /TileHeight 256
    /Quality 30
  >>
  /JPEG2000GrayImageDict <<
    /TileWidth 256
    /TileHeight 256
    /Quality 30
  >>
  /AntiAliasMonoImages false
  /CropMonoImages true
  /MonoImageMinResolution 1200
  /MonoImageMinResolutionPolicy /OK
  /DownsampleMonoImages true
  /MonoImageDownsampleType /Bicubic
  /MonoImageResolution 1200
  /MonoImageDepth -1
  /MonoImageDownsampleThreshold 1.50000
  /EncodeMonoImages true
  /MonoImageFilter /CCITTFaxEncode
  /MonoImageDict <<
    /K -1
  >>
  /AllowPSXObjects false
  /CheckCompliance [
    /None
  ]
  /PDFX1aCheck false
  /PDFX3Check false
  /PDFXCompliantPDFOnly false
  /PDFXNoTrimBoxError true
  /PDFXTrimBoxToMediaBoxOffset [
    0.00000
    0.00000
    0.00000
    0.00000
  ]
  /PDFXSetBleedBoxToMediaBox true
  /PDFXBleedBoxToTrimBoxOffset [
    0.00000
    0.00000
    0.00000
    0.00000
  ]
  /PDFXOutputIntentProfile ()
  /PDFXOutputConditionIdentifier ()
  /PDFXOutputCondition ()
  /PDFXRegistryName ()
  /PDFXTrapped /False

  /CreateJDFFile false
  /Description <<
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
    /BGR <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>
    /CHS <FEFF4f7f75288fd94e9b8bbe5b9a521b5efa7684002000410064006f006200650020005000440046002065876863900275284e8e9ad88d2891cf76845370524d53705237300260a853ef4ee54f7f75280020004100630072006f0062006100740020548c002000410064006f00620065002000520065006100640065007200200035002e003000204ee553ca66f49ad87248672c676562535f00521b5efa768400200050004400460020658768633002>
    /CHT <FEFF4f7f752890194e9b8a2d7f6e5efa7acb7684002000410064006f006200650020005000440046002065874ef69069752865bc9ad854c18cea76845370524d5370523786557406300260a853ef4ee54f7f75280020004100630072006f0062006100740020548c002000410064006f00620065002000520065006100640065007200200035002e003000204ee553ca66f49ad87248672c4f86958b555f5df25efa7acb76840020005000440046002065874ef63002>
    /CZE <FEFF005400610074006f0020006e006100730074006100760065006e00ed00200070006f0075017e0069006a007400650020006b0020007600790074007600e101590065006e00ed00200064006f006b0075006d0065006e0074016f002000410064006f006200650020005000440046002c0020006b00740065007200e90020007300650020006e0065006a006c00e90070006500200068006f006400ed002000700072006f0020006b00760061006c00690074006e00ed0020007400690073006b00200061002000700072006500700072006500730073002e002000200056007900740076006f01590065006e00e900200064006f006b0075006d0065006e007400790020005000440046002000620075006400650020006d006f017e006e00e90020006f007400650076015900ed007400200076002000700072006f006700720061006d0065006300680020004100630072006f00620061007400200061002000410064006f00620065002000520065006100640065007200200035002e0030002000610020006e006f0076011b006a016100ed00630068002e>
    /DAN <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>
    /DEU <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>
    /ESP <FEFF005500740069006c0069006300650020006500730074006100200063006f006e0066006900670075007200610063006900f3006e0020007000610072006100200063007200650061007200200064006f00630075006d0065006e0074006f00730020005000440046002000640065002000410064006f0062006500200061006400650063007500610064006f00730020007000610072006100200069006d0070007200650073006900f3006e0020007000720065002d0065006400690074006f007200690061006c00200064006500200061006c00740061002000630061006c0069006400610064002e002000530065002000700075006500640065006e00200061006200720069007200200064006f00630075006d0065006e0074006f00730020005000440046002000630072006500610064006f007300200063006f006e0020004100630072006f006200610074002c002000410064006f00620065002000520065006100640065007200200035002e003000200079002000760065007200730069006f006e0065007300200070006f00730074006500720069006f007200650073002e>
    /ETI <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>
    /FRA <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>
    /GRE <FEFF03a703c103b703c303b903bc03bf03c003bf03b903ae03c303c403b5002003b103c503c403ad03c2002003c403b903c2002003c103c503b803bc03af03c303b503b903c2002003b303b903b1002003bd03b1002003b403b703bc03b903bf03c503c103b303ae03c303b503c403b5002003ad03b303b303c103b103c603b1002000410064006f006200650020005000440046002003c003bf03c5002003b503af03bd03b103b9002003ba03b103c42019002003b503be03bf03c703ae03bd002003ba03b103c403ac03bb03bb03b703bb03b1002003b303b903b1002003c003c103bf002d03b503ba03c403c503c003c903c403b903ba03ad03c2002003b503c103b303b103c303af03b503c2002003c503c803b703bb03ae03c2002003c003bf03b903cc03c403b703c403b103c2002e0020002003a403b10020005000440046002003ad03b303b303c103b103c603b1002003c003bf03c5002003ad03c703b503c403b5002003b403b703bc03b903bf03c503c103b303ae03c303b503b9002003bc03c003bf03c103bf03cd03bd002003bd03b1002003b103bd03bf03b903c703c403bf03cd03bd002003bc03b5002003c403bf0020004100630072006f006200610074002c002003c403bf002000410064006f00620065002000520065006100640065007200200035002e0030002003ba03b103b9002003bc03b503c403b103b303b503bd03ad03c303c403b503c103b503c2002003b503ba03b403cc03c303b503b903c2002e>
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
    /HRV (Za stvaranje Adobe PDF dokumenata najpogodnijih za visokokvalitetni ispis prije tiskanja koristite ove postavke.  Stvoreni PDF dokumenti mogu se otvoriti Acrobat i Adobe Reader 5.0 i kasnijim verzijama.)
    /HUN <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>
    /ITA <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>
    /JPN <FEFF9ad854c18cea306a30d730ea30d730ec30b951fa529b7528002000410064006f0062006500200050004400460020658766f8306e4f5c6210306b4f7f75283057307e305930023053306e8a2d5b9a30674f5c62103055308c305f0020005000440046002030d530a130a430eb306f3001004100630072006f0062006100740020304a30883073002000410064006f00620065002000520065006100640065007200200035002e003000204ee5964d3067958b304f30533068304c3067304d307e305930023053306e8a2d5b9a306b306f30d530a930f330c8306e57cb30818fbc307f304c5fc59808306730593002>
    /KOR <FEFFc7740020c124c815c7440020c0acc6a9d558c5ec0020ace0d488c9c80020c2dcd5d80020c778c1c4c5d00020ac00c7a50020c801d569d55c002000410064006f0062006500200050004400460020bb38c11cb97c0020c791c131d569b2c8b2e4002e0020c774b807ac8c0020c791c131b41c00200050004400460020bb38c11cb2940020004100630072006f0062006100740020bc0f002000410064006f00620065002000520065006100640065007200200035002e00300020c774c0c1c5d0c11c0020c5f40020c2180020c788c2b5b2c8b2e4002e>
    /LTH <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>
    /LVI <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>
    /NLD (Gebruik deze instellingen om Adobe PDF-documenten te maken die zijn geoptimaliseerd voor prepress-afdrukken van hoge kwaliteit. De gemaakte PDF-documenten kunnen worden geopend met Acrobat en Adobe Reader 5.0 en hoger.)
    /NOR <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>
    /POL <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>
    /PTB <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>
    /RUM <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>
    /RUS <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>
    /SKY <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>
    /SLV <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>
    /SUO <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>
    /SVE <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>
    /TUR <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>
    /UKR <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>
    /ENU (Use these settings to create Adobe PDF documents best suited for high-quality prepress printing.  Created PDF documents can be opened with Acrobat and Adobe Reader 5.0 and later.)
  >>
  /Namespace [
    (Adobe)
    (Common)
    (1.0)
  ]
  /OtherNamespaces [
    <<
      /AsReaderSpreads false
      /CropImagesToFrames true
      /ErrorControl /WarnAndContinue
      /FlattenerIgnoreSpreadOverrides false
      /IncludeGuidesGrids false
      /IncludeNonPrinting false
      /IncludeSlug false
      /Namespace [
        (Adobe)
        (InDesign)
        (4.0)
      ]
      /OmitPlacedBitmaps false
      /OmitPlacedEPS false
      /OmitPlacedPDF false
      /SimulateOverprint /Legacy
    >>
    <<
      /AddBleedMarks false
      /AddColorBars false
      /AddCropMarks false
      /AddPageInfo false
      /AddRegMarks false
      /ConvertColors /ConvertToCMYK
      /DestinationProfileName ()
      /DestinationProfileSelector /DocumentCMYK
      /Downsample16BitImages true
      /FlattenerPreset <<
        /PresetSelector /MediumResolution
      >>
      /FormElements false
      /GenerateStructure false
      /IncludeBookmarks false
      /IncludeHyperlinks false
      /IncludeInteractive false
      /IncludeLayers false
      /IncludeProfiles false
      /MultimediaHandling /UseObjectSettings
      /Namespace [
        (Adobe)
        (CreativeSuite)
        (2.0)
      ]
      /PDFXOutputIntentProfileSelector /DocumentCMYK
      /PreserveEditing true
      /UntaggedCMYKHandling /LeaveUntagged
      /UntaggedRGBHandling /UseDocumentProfile
      /UseDocumentBleed false
    >>
  ]
>> setdistillerparams
<<
  /HWResolution [2400 2400]
  /PageSize [612.000 792.000]
>> setpagedevice
