Simulation of Grain Quantity, Fan and Solar Collector Sizes for an Experimental
Forced Convection Grain Dryer


Booker Osodo1
Daudi Nyaanga2
Jeremiah Kiplagat3




( Corresponding Author)


1Lecturer, Department of Industrial and Energy Engineering, Egerton University, Kenya,


2Associate Professor, Department of Agricultural Engineering, Egerton University, Kenya.


3Director, Institute of Energy Research, Kenya Power, Nairobi, Kenya.




Abstract

Forced convection grain dryers are more efficient and achieve greater drying rates than natural
convection dryers. However, it is necessary to dry an appropriate grain layer thickness in such a
dryer for the drying process to occur efficiently and at an appropriate rate. A well sized fan is also
essential if the drying process is to proceed effectively. An oversize fan will be unnecessarily
expensive to buy and operate due to high fan power, while an undersized one will not be able to
supply adequate air flow. The solar collector must be properly sized if it is to heat the air to the
required temperature. All these factors need to be addressed during the design of a grain dryer.
Lengthy and expensive trial and error processes can be avoided by applying simulation in the
design process. This study developed an experimental grain dryer, addressing the above
mentioned issues in the process. Simulation of air flow within an initial model of the dryer was
done and the results used to size the fan and drying cabinet. The solar collector was also sized.
The experimental grain dryer developed consisted of a drying cabinet of dimensions 0.5 m x 0.5 m
x 1.0 m and was equipped with a 0.039 kW centrifugal fan. The solar collector area was of
dimensions 1.2 m x 1.8 m.


Keywords: Simulation, Forced convection dryer, Dryer sizing, Fan, Drying cabinet, Solar collector.


Citation | Booker Osodo; Daudi Nyaanga; Jeremiah Kiplagat
(2019). Simulation of Grain Quantity, Fan and Solar Collector Sizes
for an Experimental Forced Convection Grain Dryer. Agriculture
and Food Sciences Research, 6(1): 98-108.
History:
Received: 28 February 2019
Revised: 27 March 2019
Accepted: 1 May 2019
Published: 4 July 2019
Licensed: This work is licensed under a Creative Commons

Attribution 3.0 License
Publisher:  Asian Online Journal Publishing Group


Contribution/Acknowledgement: All authors contributed to the conception
and design of the study.
Funding: This study received no specific financial support.
Competing Interests: The authors declare that they have no conflict of
interests.
Transparency: The authors confirm that the manuscript is an honest,
accurate, and transparent account of the study was reported; that no vital
features of the study have been omitted; and that any discrepancies from the
study as planned have been explained.
Ethical: This study follows all ethical practices during writing.





Contents
1. Introduction ...................................................................................................................................................................................... 99
2. Materials and Methods ................................................................................................................................................................. 100
3. Results and Discussion ................................................................................................................................................................. 103
4. Conclusions ..................................................................................................................................................................................... 107
References ............................................................................................................................................................................................ 107










http://crossmark.crossref.org/dialog/?doi=10.20448/journal.512.2019.61.98.108&domain=pdf&date_stamp=2017-01-14
http://crossmark.crossref.org/dialog/?doi=10.20448/journal.512.2019.61.98.108&domain=pdf&date_stamp=2017-01-14
http://creativecommons.org/licenses/by/3.0/
http://creativecommons.org/licenses/by/3.0/
http://www.asianonlinejournals.com/index.php/AESR/article/view/125


Agriculture and Food Sciences Research, 2019, 6(1): 98-108

99
© 2019 by the authors; licensee Asian Online Journal Publishing Group





Contribution of this paper to the literature
This article demonstrates that it is possible to use simulation in sizing the various components of a solar
dryer. This will result in savings in time and resources which usually results from the normal design
process which involves design, fabrication and testing before a prototype is eventually made.


1. Introduction

A large proportion of food product is often lost between harvesting and consumption. Adebayo, et al. [1]
stated that loss of crop occurs in the field (15%), during harvesting (13-20%), as well as during processing and
storage (15-25%). Post-harvest loss of crop may be attributed to different causes. Pests, such as large grain borer
account for 10-20% loss, while 5-10% of the losses may be attributed to poor storage facilities. Diseases, on the
other hand, contribute to 5% of post-harvest crop loss [2]. The problem of post-harvest food loss is particularly
significant in developing countries, where food losses are estimated to be of the order of 40%, though this can rise
to be as high as 80% under very adverse conditions [3]. For example, incidences of post-harvest product loss in
Kenya have been estimated at 30%, and can rise to be as high as 100% with the advent of afflotoxin [4]. Post-
harvest loss of maize in Kenya in 2007 was 21.1% [5].  One reason for loss of grain after harvesting is spoilage
resulting from high moisture content. Moist and partly moist crop is prone to fungus infection, which renders it
unusable. High moisture content also encourages loss due to attacks by insects, pests and increased respiration.
Drying of grain is therefore necessary to avoid loss between harvesting and consumption Tiwari [6];Twidell and
Weir [7]. Barawal and Tiwari [8] reported that drying of crop helps to achieve better product quality, longer safe
storage and reduction of post-harvest loss hence ensuring more food is available for the growing world population.

Grain drying may be carried out using different sources of energy. However, solar energy is preferred to other
alternative sources of energy such as wind and shale since it is abundant, inexhaustible and non-polluting [9]. In
Forced Convection solar drying, a fan is used to force the air through the grain in order to enhance the circulation
of the heated air. Such dryers produce greater drying rates and make it easier to control the drying process [10,
11]. The performance of a dryer may also be evaluated based on other criteria such as drying and dryer efficiency,
uniformity of drying and quality of final product (extent of cracking and discoloration of grain) as well as total
drying time [12, 13].  Determination of an optimum design that will ensure best ventilation for any particular
application is essential to ensure best performance [14].

Although forced convection solar dryers achieve greater drying rates than natural convection dryers, their
performance is often not optimal. One reason for this is inadequate distribution of air flow, resulting in inadequate
drying air in some sections of the dryer and hence uneven drying of the grain. According to Misha, et al. [15]
uneven drying is the consequence of poor air flow distribution in the drying chamber. Product closer to the air inlet
is better dried than that further, due to reduced temperature and air velocity. Sometimes, the fan is undersized,
leading to insufficient air flow (and velocity), or oversized, leading to excessive energy consumption and in extreme
cases grain being blown upward. Also use of inappropriate grain layer thickness leads poor performance. If the
grain layer is too thick, some sections do not dry well as they receive air which is saturated with moisture. If too
thin, air exits while still having capacity to remove moisture, leading to low thermal efficiency. Design of dryers
that meet these criteria, without use of simulation, would require troublesome development stages, involving trial
and error, continued testing and use of prototypes, a process which would be expensive and time consuming.
Simulation, which is the imitation or reproduction of the behavior of a system or process [16] is useful in the
design process, as it saves on the time and resources that would otherwise be required to obtain optimal
performance. In this study, the process of simulation was used to improve on the dryer design and performance.
The objective of the study was to simulate the grain quantity, fan and solar collector sizes for an experimental
forced convection grain dryer.


1.1. Solar Thermal Collectors
A Solar thermal collector serves the purpose of trapping solar radiation which is then used for heating the

working fluid. It usually consists of a black surface, the absorber, and a transparent cover. The absorber does not
trap all the incident energy from the sun. It incurs losses due to reflection by the encapsulation (cover) or the
absorber itself, convection as a result of exchange with the surrounding air, as well as radiation from the hot
absorber surface. The efficiency of the collector depends on two factors: the extent to which solar radiation is
converted to heat, and the extent of heat losses to the surroundings [17].
For a flat plate collector, solar collector area Ac may be determined from Equation 1 used by Dabra, et al. [18] and
Aduewa, et al. [19].

𝐴𝑐 =
�̇�𝑎𝑐𝑝𝑎(𝑇𝑜−𝑇𝑎)

𝐼𝑐𝜂
                       (1)

In the equation, �̇�𝑎 and cpa represented air mass flow rate and specific heat capacity respectively, while 𝐼𝑐 and 𝜂
stood for maximum insolation on collector surface and solar collector efficiency, also respectively. To and Ta were
used to represent optimum dryer temperature and inlet temperature at ambient.


1.2. Pressure Drop
Jia, et al. [20] explain that air flow through packed material may be described using the Ergun Equation 2.

According to this equation, pressure drop , for fluid velocity  depends on particle diameter ( , length

of bed , fluid viscosity ( void space ( and fluid density (  The effect of cross sectional area (due to

container diameter) is ignored in this equation.

        (2)

Although there are many channels through packed material, fluid will normally only flow through a few of
them, a phenomenon called channeling. This leads to lack of distribution of fluid flow. Another limitation is that of
formation of hot spots, which leads to damage to the bed and packing materials [21]. The pressure drop in the



Agriculture and Food Sciences Research, 2019, 6(1): 98-108

100
© 2019 by the authors; licensee Asian Online Journal Publishing Group





drying chamber limits the number of trays that may be used. Due to high resistance to air flow through drying
product, only a few drying shelves can be used without significantly affecting air movement [22].


1.3. Fan Sizing
According to Wilcke and Morey [23] different crops have different airflow requirements for drying,

necessitating selection of a fan that will deliver airflows within the recommended range. Greater airflows will
require larger fans, leading to increased costs, while smaller ones may result in unacceptable crop quality. Also, the
fan must develop sufficient pressure to overcome resistance to airflow. Typical air flow rates range from 0.25-0.51
m3/s.m2 of perforated screen area, these flow rates creating relatively low static pressures of 0.249-1.25 kPa in
cross flow and mixed-flow dryers. The fan to be used for such a dryer must be of sufficient capacity to overcome
this static pressure, being the resistive force the fan works against while trying to push the air through the grain
column [24].

Fan power ( may be obtained either from manufacturers’ charts or from Equation 3 and 4 as suggested by

Wilcke and Morey [23] as well as Maier and Bakker-Arkema [24].

           (3)

           (4)

(V̇ is air volume flow rate while Ps  represents static pressure)
The equations are similar, although for Equation 4 an impeller efficiency of 60% has been assumed and

incorporated. Weiss and Buchinger [25] stated that fan efficiency ranges between 30 % and 70 %, hence the
assumption is reasonable to cater for most fans if cost of fan and that of power is the major consideration. In the
current study, Equation 4 was adopted to cater for a general situation where efficiency of fan does not have to be
used every time.


2. Materials and Methods
2.1. Research Site

The study was carried out in Njoro, Nakuru County, Kenya. Njoro is located 18 km South West of Nakuru
town. It lies at an altitude of 1800 m above sea level, and experiences temperature ranges between 17-22 ºC.
Nakuru County is a moderate to high solar energy potential area. The amount of available solar energy is season
dependent, with the December-February season receiving the highest amount of insolation of 678 kWh/m2. The
September-November season receives the least insolation of 602.6 kWh/m2. Harvesting is normally carried out
between August and December, depending on the type of grain [26-28].


2.2. Simulation to Estimate Grain Layer Thickness and Number of Trays
Simulation was carried out in order to determine the greatest grain layer thickness that would be penetrated by

the drying air. This was determined by observing the velocity profile for simulated air flow up different layer
thicknesses, with the expectation that air velocity would gradually increase up the layer. According to Ergun’s
Equation 2 the governing equation in the simulation process, fluid velocity increases as pressure drop increases.
The latter increases as fluid moves up the grain layer, hence fluid velocity is expected to vary in a similar manner.
Simulation was first carried out of hot air flowing through a single grain layer of 0.1 m thickness, at an air velocity
of 1 m/s. A parametric sweep was then carried out in order to simulate air flow through various grain layer
thicknesses ranging between 0.1 m – 0.3 m for air velocities ranging between 1 m/s - 5 m/s. A parametric sweep
enables simulation within the specified range of parameter values in one simulation process, without having to do it
for discrete values. The purpose of the parametric sweep was to determine the maximum grain layer thickness that
would allow the fan to overcome static resistance to airflow.

Once the maximum allowable layer thickness was determined, simulation of air flow up increasing number of
grain layers was carried out in order to determine the number of layers the air was able to penetrate. In this case,
variation of pressure up the drying cabinet with different grain layer numbers was observed. It was expected that
pressure would decrease gradually up the drying cabinet. Any behavior to the contrary would suggest air was not
able to penetrate.

The simulation process was carried out in two major stages: creation of the model and simulation of the model.
Before simulating air flow up the drying cabinet, a 2-D model of it had to be developed using the software
SolidWorks. Once created, the model was imported into the COMSOL MULTI-PHYSICS simulation software and
the process of simulation carried out. The simulation process was also in two major stages: pre-processing and
post-processing.  Figure 1 summarises the model creation process while Figure 2 summarises the preprocessing
stage of simulation.




Agriculture and Food Sciences Research, 2019, 6(1): 98-108

101
© 2019 by the authors; licensee Asian Online Journal Publishing Group






Figure-1. Model Creation.

                        Source: Osodo [29].



Figure-2. Flow Chart of Preprocessing Stage of Simulation.

                         Source: Osodo [29].


Once simulation was complete, post-processing, summarized in Figure 3, was carried out to extract the results
in various forms as required.



Figure-3. Post-processing Stage of Simulation.

                            Source: Osodo [29].


2.3. Sizing of Solar Dryer
2.3.1. Fan Power Determination

Having found the grain layer thickness that would allow penetration by the air, the simulated pressure drop for
this layer thickness was taken as being equivalent to the static pressure to be overcome by the suction fan. This

static pressure (𝑃𝑆) as well as the corresponding air flow rate (�̇�) was applied in Equation 4 to determine the power
of the appropriate fan.


2.3.2. Drying Cabinet and Solar Collector
i. Drying Cabinet

To determine the cross sectional area of the drying cabinet, a capacity of 18 kg per tray (a mass that an average
family would dry for milling, and also that can be carried comfortably when loading) was assumed. The volume
(Vgr), of grain per tray was determined using Equation 5 the grain density for maize being 0.76 g/cc. The cross



Agriculture and Food Sciences Research, 2019, 6(1): 98-108

102
© 2019 by the authors; licensee Asian Online Journal Publishing Group





sectional area of the drying cabinet Acb was then determined from Equation 6 the value of 𝑡𝑔𝑟 (maximum grain

layer thickness) having been determined as 0.1 m.

𝑉𝑔𝑟 =
𝑚𝑔𝑟

𝜌𝑔𝑟
             (5)

𝐴𝑐𝑏 =
𝑉𝑔𝑟

𝑡𝑔𝑟
            (6)

(mgr and 𝜌𝑔𝑟 represent mass and density grain respectively)

The height of the drying cabinet was sized to carry two trays, each holding a grain layer thickness equal to 𝑡𝑔𝑟.

The void space between the trays, having a height equal to that of the grain layer, and a plenum chamber, as well
as space above the second tray to accommodate the suction fan were also catered for.

ii. Solar Collector

The solar collector area (Ac) was determined using Equation 1. To find the air mass flow rate (�̇�𝑎) Equation 7
and 8 were used. Air velocity was measured at dryer exit, which had a diameter of 0.1 m, using a thermo-
anemometer, cabinet cross sectional area having been found as shown above.

𝑄 = 𝐴𝑣      (7)

�̇� = 𝑄𝜌𝑎             (8)

(Q = flow rate in m3/s, A= cross sectional area in m2, v = air velocity in m/s,  �̇� = mass flow rate in kg/s and 𝜌𝑎=
density of air in kg/m3)

Ti was taken to be 23°C (the ambient temperature measured in research area during drying period) and To as
58°C (the maximum temperature to maintain grain quality). A value of 1200 W/m2 was used as Insolation Ic

(estimated from measurements in the research area), while a solar collector efficiency (η) value of 83.28 % was used.
This solar collector efficiency was similar to that reported by Aduewa, et al. [19] at insolation of 1199.46 W/m2.


Plate-1. Side View of Experimental Solar Grain Dryer.
Source: Osodo [29].



Plate-2. Rear View of Experimental Solar Grain Dryer.

                      Source: Osodo [29].



Agriculture and Food Sciences Research, 2019, 6(1): 98-108

103
© 2019 by the authors; licensee Asian Online Journal Publishing Group





3. Results and Discussion
3.1. Grain Layer Thickness

In order to select the appropriate grain layer thickness, air flow up different layer thicknesses was simulated.
The expectation was that air velocity would increase gradually up the grain layer. Any variation from this
expectation would imply an inappropriate layer thickness. Figures 4 – 7 show velocity profiles for different layer
thicknesses.



Figure-4. Air Velocity up Single Grain Layer of Height 0.1 m & inlet Velocity 1 m/s.

                       Source: Osodo [29].



Figure-5. Air Velocity up Single Grain Layer of Height 0.2 m & inlet Velocity 1 m/s.

                            Source: Osodo [29].



Figure-6. Air Velocity up Single Grain Layer of Height 0.25 m & inlet Velocity 1 m/s.

                            Source: Osodo [29].




Agriculture and Food Sciences Research, 2019, 6(1): 98-108

104
© 2019 by the authors; licensee Asian Online Journal Publishing Group






Figure-7. Air Velocity up Single Grain Layer of Height  0.3 m & inlet Velocity 1 m/s.

                Source: Osodo [29].

It is evident that for grain layer thickness of 0.1 m, air velocity increased gradually up the entire grain layer,

leveling off at the top. This was according to expectations. This implied that 0.1 m would be an appropriate grain
layer thickness for this dryer, and that the suction fan would be able to overcome the static pressure i.e. resistance
to air flow, in this case. For other layer thicknesses, this was not the case. For example for grain layer thickness of
0.2 m at inlet velocities 1 m/s, velocity increased gradually up to a grain layer height of 0.04 m, before falling
sharply. Air velocity was again showed to be increasing sharply at the upper sections of the grain layer. The trend
at the section at a height between 0.07 m- 0.18 m did not show, making it difficult to explain what happened.
However, because the expectation was for the air velocity to rise steadily up the grain layer, it was concluded that
this was not an appropriate grain layer thickness to use.

For the velocity profile up 0.25 m grain layer thickness at 1 m/s, air velocity increased up the grain layer, but
only up to a height of 0.03 m before decreasing, showing again that this was not an appropriate grain layer
thickness to use. In the case of a 0.3 m grain layer thickness, once again air velocity increased up the grain layer,
but the increase was not sustained. The velocity dropped way before the top of the grain layer, at a height of about
0.2 m. This showed that this was not an appropriate grain layer thickness to use. Thus it was concluded that the
maximum grain layer thickness should be 0.1 m.


3.2. Number of Layers and Trays
Pressure profiles for simulated air flow up a drying cabinet with different numbers of grain layers are shown in

Figures 8- 12.



Figure-8. Variation of Pressure for Four (4) 0.1 m Thickness Grain Layers.

                     Source: Osodo [29].




Agriculture and Food Sciences Research, 2019, 6(1): 98-108

105
© 2019 by the authors; licensee Asian Online Journal Publishing Group






Figure-9. Variation of Pressure for Five (5) 0.1 m Thickness Grain Layers.

                       Source: Osodo [29].



Figure-10. Variation of Pressure for Eight (8) 0.1 m Thickness Grain Layers.

                             Source: Osodo [29].



Figure-11. Variation of Pressure for Eleven (11) 0.1 m Thickness Grain Layers.

                        Source: Osodo [29].




Agriculture and Food Sciences Research, 2019, 6(1): 98-108

106
© 2019 by the authors; licensee Asian Online Journal Publishing Group






Figure-12. Variation of Pressure for Sixteen (16) 0.1 m Thickness Grain Layers.

                  Source: Osodo [29].


It was found that beyond four (4) grain layers, the linear trend in pressure drop ceased. From five (5) grain

layers and above, there were sections where there was little or no change in pressure, suggesting that there was
little or no air flow. Sections where the curve remained horizontal indicated no pressure drop. This trend
intensified as number of grain layers increased, with the horizontal sections of the curve becoming longer,
indicating no pressure drop for greater distances up the grain layers. This continued to the extent that for sixteen
(16) grain layers and beyond, the graph was a horizontal line, showing that there was no pressure drop at all, hence
suggesting that no air flow through the grain layers occurred. It was therefore concluded that the grain dryer
should be loaded with at most four (4) trays, each with a maximum grain layer thickness of 0.1 m.


3.3. Sizing of Drying Cabinet and Solar Collector
Figure13 shows variation of pressure for simulated air flow up a single 0.1 m grain layer. It indicates that there

was a linear drop in pressure from the lower section of a grain layer upwards.



Figure-13. Variation of Pressure for a Single Layer of Thickness 0.1 m.

                                Source: Osodo [29].


As shown in Figure 13 the total pressure drop for a single 0.1 m thick layer was 1.28 x 104 Pa, this being the
difference between the highest (6.9533 MPa) and the lowest pressure (6.9405 MPa). For two layers or trays, the
total pressure drop would therefore be equal to twice this value. This was due to the assumption that pressure drop
would be the same for each layer, since they were of equal thickness. Equation 2 indicates that pressure drop
depends on length of bed and void space which were constant. The other variables, namely particle size, fluid
viscosity and density were also assumed to be constant. This yielded a total pressure drop of 2.56 x 104 Pa for two

(2) grain layers, which was found to be equivalent to a static pressure 𝑃𝑠  of 102.8 inches of water. Using Equation

5 – 8 the air volume flow rate 𝑉𝑠  was determined to be 1.984 cfm. By applying Equation 4 the fan power 𝑃𝑓  was

found to be 0.053 Hp (0.039 kW).







Agriculture and Food Sciences Research, 2019, 6(1): 98-108

107
© 2019 by the authors; licensee Asian Online Journal Publishing Group





3.3.1. Drying Cabinet Sizing
Although it was found that maximum number of trays should be four, the experimental dryer was designed to

carry two trays. Each drying tray with a capacity of 18 kg was sized to be of square cross section 0.5 m x 0.5 m.
using Equation 5 and 6. The lowest tray was to be placed 0.3 m from the bottom to allow for the plenum chamber,
and the second one 0.2 m above (0.1 m each for grain layer and void space). Leaving 0.3 m above the upper tray for
fitting the fan, this resulted in a total drying cabinet height of 1 m.


3.3.2. Solar Collector Sizing
Using an air velocity, v of 0.3 m/s (the lowest recommended for drying of grains) and drying cabinet cross

section 0.25 m2, the volume flow rate Q, through the collector was determined to be 0.075 𝑚3/s (mass flow rate �̇�
= 0.092 kg/s), using Equation 7 and 8. Assuming a maximum temperature To of 58°C (to maintain grain quality),
and an ambient temperature Ti of 23°C (measured in research area during drying period) as well as an insolation Ic

of 1200 W/m2, the required solar collector area was determined to be 3.25 m2 after applying Equation 1. A solar

collector efficiency η of 83.28 %, as achieved by Aduewa, et al. [19] at an insolation of 1199.46 W/m2 was used in
the determination.


4. Conclusions
As a result of this study, an experimental grain dryer shown in Figures 4-6 and Plates 1 and 2 was sized and

fabricated. Simulation led to the conclusion that the grain dryer should be loaded with at most four (4) trays, each
with a maximum grain layer thickness of 0.1. Having decided to design a dryer with two drying trays, a drying
cabinet of dimensions 0.5 m x 0.5 m x 1.0 m was adopted. It was designed to be equipped with a 0.039 kW
centrifugal fan. The solar air heater was designed to have a collector area of 3.25 m2.


References
[1] A. B. Adebayo, G. Ndunguru, P. Mamiro, B. Alenkhe, N. Mlingi, and M. Bekunda, "Post-harvest food losses in a

maize-based farming system of semi-arid savannah area of Tanzania," Journal of Stored Products Research, vol. 57, pp.
49-57, 2014. Available at: https://doi.org/10.1016/j.jspr.2013.12.004.

[2] C. Bett and R. Nguyo, "Post-harvest storage practices and techniques used by farmers in semi-arid Eastern and
Central Kenya," in African Crop Science Conference Proceedings, 2007, pp. 1023-1222.

[3] B. O. Bolaji and A. P. Olalusi, "Performance evaluation of a mixed mode solar dryer," AU Journal of Technology, vol.
11, pp. 225-231, 2008.

[4] J. Irungu, "Post harvest challenges to food security in Kenya," presented at the A paper presented at KCB Leadership
Center, Karen, Nairobi, 2010.

[5] R. Hodges, Supplying cereal grain postharvest losses information: The examples of ALPHIS (African postharvest Loss
information system). UK: Natural Resources Institute, 2009.

[6] G. N. Tiwari, Solar energy: Fundamentals, design, modeling and applications. Parybourne: Alpha Science International
Limited, 2002.

[7] J. W. Twidell and A. D. Weir, Renewable energy resources. London: English Language Book Society, 2006.
[8] P. Barawal and G. N. Tiwari, "Grape drying by using photovoltaic thermal (PV/T) green house dryer: An

experimental study of solar energy," Solar Energy, vol. 62, pp. 1131-1144, 2008.
[9] O. A. Akinona, A. A. Akinyemi, and B. O. Bolaji, "Evaluation of traditional and solar fish drying systems towards

enhancing fish storage and preservation in Nigeria," Fish International: Pakistan, vol. 1, pp. 44-49, 2006.
[10] D. G. Mercer, "A comparison of the kinetics of Mango drying in open-air, solar and forced air dryers," African Journal

of Food, Agriculture, Nutrition and Development, vol. 12, pp. 6835- 6852, 2012.
[11] Y. I. Sallam, M. H. Aly, A. F. Nassar, and E. A. Mohamed, "Solar drying of whole mint plant under natural and forced

convection," Journal of Advanced Research, vol. 6, pp. 171-178, 2013. Available at:
https://doi.org/10.1016/j.jare.2013.12.001.

[12] M. Mohanraj and P. Chandrasekar, "Performance of a forced convection solar drier integrated with gravel as heat
storage material for chili drying," Journal of Engineering Science and Technology, vol. 4, pp. 305-314, 2009.

[13] A. Kassem, M. A. Al-Sulaiman, A. Aboukarima, and S. Kassem, "Predicting drying efficiency during solar drying
process of grapes clusters in a box dryer using artificial neural network," Australian Journal of Basic and Applied
Sciences, vol. 5, pp. 230-241, 2011.

[14] J. K. Afriyie, H. Rajakaruna, M. A. Nazha, and F. Forson, "Simulation and optimisation of the ventilation in a
chimney-dependent solar crop dryer," Solar Energy, vol. 85, pp. 1560-1573, 2011. Available at:
https://doi.org/10.1016/j.solener.2011.04.019.

[15] S. Misha, S. Mat, M. A. M. Rosli, M. H. Ruslan, K. Sopian, and E. Salleh, "Simulation of air flow in a tray dryer by
CFD," Recent Advances in Renewable Energy Sources, vol. 1, pp. 29-34, 2013.

[16] C. A. Frangopoulos, M. R. Von Spakovsky, and E. Sciubba, "A brief review of methods for the design and synthesis
optimization of energy systems," International Journal of Applied Thermodynamics, vol. 5, pp. 151-160, 2002.

[17] J. Klaus, I. Olindo, H. M. S. Amo, A. C. Rene, and Z. Miro, "Solar energy: Fundamentals, technology and Systems,"
Delft University of Technology, 2014.

[18] V. Dabra, L. Yadav, and A. Yadav, "The effect of tilt angle on the performance of evacuated tube solar air collector:
experimental analysis," International Journal of Engineering, Science and Technology, vol. 5, pp. 100-110, 2013. Available
at: https://doi.org/10.4314/ijest.v5i4.9.

[19] T. O. Aduewa, A. S. Ogunlowo, and S. T. Ojo, "Development of hot air supplemented solar dryer for white yam
(Dioscorea Rutundata) slices," IOSR Journal Of Agricultural And Veterinary Services, vol. 7, pp. 114-123, 2014. Available
at: https://doi.org/10.9790/2380-07122114123.

[20] Y. Jia, Y. Li, and D. Hlavka, "Flow through packed beds." Available: http:/
www.me.rochester.edu/courses/ME241/11-sand.pdf. [Accessed 14th September 2014], 2009.

[21] S. Sachdeva, S. Pareek, B. Mahadevan, and A. Deshapande, "Modeling and simulation of single phase fluid flow and
heat transfer in packed bed," in Proceedings of 2012 COMSOL Conference, Bangalore, 2012.

[22] W. Aissa, M. El-Sallak, and A. Elhakem, "Performance of solar dryer chamber used for convective drying of sponge-
cotton," Thermal Science, vol. 18, pp. 451-462, 2014. Available at: https://doi.org/10.2298/tsci110710084a.

[23] W. F. Wilcke and R. V. Morey, "Selecting fans and determining airflow for crop drying, cooling and storage.
Available: http://www.extension.umn.edu/agriculture/crops. [Accessed 15th September 2015], 2015.

http://www.me.rochester.edu/courses/ME241/11-sand.pdf
http://www.extension.umn.edu/agriculture/crops


Agriculture and Food Sciences Research, 2019, 6(1): 98-108

108
© 2019 by the authors; licensee Asian Online Journal Publishing Group





[24] D. E. Maier and F. W. Bakker-Arkema, "Grain drying systems," in Paper Presented at Facility Design Conference of
Grain Elevator and Processing Society held on July 28-31 in St Charles, Illinois, USA, 2002.

[25] W. Weiss and J. Buchinger, Solar drying. Training course within the scope of the project establishment of a production, sales
and consulting infrastructure for solar thermal plants in Zimbabwe. Australia: Australian Development Cooperation,
Institute of Sustainable Technologies, 2012.

[26] L. M. Omwando, "Assessment of solar energy potential for Nakuru, Kenya," Unpublished Masters Thesis, Jomo
Kenyatta University of Agriculture & Technology, Kenya, 2012.

[27] D. Walubengo, "Community-led actions in building resilience to climate change: A Kenya case study. Retrieved from
pubs.iied.org/pdfs/go2310pdf . [Accessed 30th November 2015]," 2007.

[28] H. Maloba, W. Shivonga, M. Muchiri, and S. N. Miller, "Use of benthic macro-invertebrates as indicators of water
quality in Njoro River, Kenya," in Proceedings of TAAL 2007: the 12th World Lake Conference, 2008, pp. 2161-2168.

[29] B. O. Osodo, "Simulation and optimisation of a drying model for a forced convection grain dryer." Unpublished PhD
Thesis, Kenyatta University, Kenya, 2018.
























































Asian Online Journal Publishing Group is not responsible or answerable for any loss, damage or liability, etc. caused in relation to/arising out of the use of the content.
Any queries should be directed to the corresponding author of the article.
