Abstract: Correctly identifying when a hemorrhagic patient needs immediate medical attention to prevent acute
hypotensive episode (AHE) is vital in the short- and long-term care, but is often complicated due to the physiological
responses in the sympathetic and parasympathetic nervous systems that mask symptoms until a significant amount
of blood loss has occurred. These physiological responses affect the arterial blood pressure waveform, changing
both dynamics and waveform morphology. Through the use of Markov chain analysis of the arterial blood pressure
waveform, we first analyzed patient blood pressure waveforms from a challenge dataset published by Computing
in Cardiology 2009 and the MIMIC III database. Markov chain analysis was applied to 20-second intervals over
the entirety of a patient’s known acute hypotensive episode. Each interval or segment is one second apart from
the previous segment with a nineteen second overlap. The mixing rate (2nd largest eigenvalue of the transition
probability matrix) was determined for all segments. A subset of patients showed a Pearson correlation coefficient
with shock index (SI), i.e., with the ratio of heart rate and systolic blood pressure, similar to a previous swine study.
These patients (mean correlation coefficient -0.423 ± 0.32, median -0.352) were found to have been administered
pressors (vasoconstrictors), compared to patients who were not administered pressors (mean correlation coefficient
0.392 ± 0.29, median 0.447). Patients were also analyzed based on diagnoses of gastrointestinal bleeding by the ICD-
9 code, and mixing rate results were compared between patients in this subgroup and found to have no significance
as a metric of predicting acute hypotensive episodes.

Aisthesis      Volume 9,  201837

Second Largest Eigenvalue of the Transition Probability Matrix for
the Markov Chain Constructed from the Arterial Blood Pressure
Waveform is Not Correlated to Shock Index in Hemorrhagic
Human Subjects

by Brett Collar, Marvi Bikak, Paul Brown, Zachary Pitluk, and Mohammad
Adibuzzaman

Introduction
Hemorrhagic shock is a condition produced by

rapid and significant loss of intravascular volume,
which may lead sequentially to hemodynamic
instability, decreases in oxygen delivery, decreased
tissue perfusion, cellular hypoxia, organ damage,
and death. The primary goals are to stop the
bleeding and to restore circulating blood volume,
as hemorrhagic shock can rapidly become fatal.
Resuscitation may well depend on the estimated
severity of hemorrhage. Hemorrhage results in
over 80% of operating room deaths after major
trauma and almost 50% of all deaths in the first 24
hours of trauma care [1]. Identifying occurrence of
hemorrhage in a timely manner is the cornerstone of
medical and surgical management. However, one of
the major limitations in accurately identifying a state
of hemorrhage is the poor predictive ability of heart
rate, mean arterial pressure, and shock index [2].
These are the most commonly used physiological
parameters which help guide clinicians to diagnose
hemorrhage. In other words,  developing a method

to identify patients that require immediate medical
care is of critical importance [2].

Heart rate variability is one such method with the
potential to identify hemodynamic instability caused
by hemorrhage [3]. Previous literature suggests that
reductions in vagal activity assessed with heart rate
variability or baroreflex sequences may represent
identifiable early markers of hemorrhage [4].
Hypovolemia triggers a simultaneous reduction of
the parasympathetic nervous system and activation
of the sympathetic nervous system in an attempt
to increase heart rate and compensate the drop in
blood pressure. As a result, clinical signs present
during early stages of hemorrhage may be ignored
due to the mean arterial pressure remaining stable.
Only after a significant loss of blood will a change
in blood pressure be identified, at which point
medical interventions could be limited. Clinically,
abnormal shock index values, defined as the ratio
of heart rate (HR) to systolic blood pressure (SBP),
have been demonstrated to portend worse outcomes
in traumatically injured patients [5]. Markov chain



Second Largest Eigenvalue of the Transition Probability Matrix

Aisthesis      Volume 9,  201838

methods may describe changes in hemodynamic
instability prior to traditional vital signs, potentially
providing an early indicator of hemorrhage.

A Markov chain is defined as a system with
different states, where the transition probability from
one state to the next depends only on the current
state, the Markov assumption [6]. Regular Markov
chains have a limit distribution or steady state,
where the mixing rate of a Markov chain represents
how fast the system is approaching the steady state.
Eigenvalues of Markov chains display changes in
system dynamics that are not captured by other
nonlinear methods, such as Poincaré plots [4]. These
eigenvalues of Markov chains represent changes
in the dynamics of arterial blood pressure (ABP)
waveforms as the body attempts to compensate for
hypovolemia. An empirical Markov chain can be
constructed from ABP recordings. As the system
dynamics and waveform morphology change, the
system will approach steady state faster or slower
and this can be observed through the mixing rate.
An animal study on hemorrhagic swine showed
strong correlation with shock index and the mixing
rate of the arterial blood pressure [7].

We studied the applicability of the method in
hemorrhagic human subjects from the intensive care
unit using two different data sets. We hypothesized
that if a specific subset of patients was found to
exhibit strong correlations between mixing rate and
traditional biomarkers, these patients would share
a demographic detail that explained the behavior.
Additionally, a larger patient population collectively
sharing similar clinical diagnoses was analyzed
to determine whether specific conditions affected
clinical findings (mean correlation coefficient with SI
-0.0087 ± 0.19, median 0.0080). We also provide the
theoretical foundation for the change in the second
largest eigenvalue from time series data.

Methods
A. Previous Work

A protocol was approved and performed on a
swine model to test the efficacy of the Markov chain
mixing rate as a metric for detecting hemorrhage
prior to noticeable changes in traditional vital signs
[7]. Immature swine (N=7, female, 37.1 ± 15.1 kg
(mean ± SD)) were anesthetized and instrumented
with bilateral catheters in femoral arteries and

veins. Data were collected during a continuous
hemorrhage of 10 ml/kg over 30 minutes. Heart rate
and beat-by-beat blood pressures (systolic, diastolic,
mean) were calculated from the ABP waveform, with
shock index (SI) calculated by dividing heart rate by
systolic blood pressure.

Using a high-frequency (125 Hz) arterial blood
pressure waveform, an empirical Markov chain
was created from a 20-second period of data by
segmenting the range of blood pressures over a
fixed number of states, each covering an equal range
of pressures. From there, a transition probability
matrix was computed as the probability that blood
pressure will enter any state given only its current
state. The matrix was normalized by dividing each
row by the cumulative sum of the row to have a
probability distribution. Finally, eigenvalues were
determined from the transpose of the transition
probability matrix, and the eigenvalue with the
second largest magnitude was defined as the mixing
rate. The arterial blood pressure waveform was then
advanced by one second (125 samples), and the
process was repeated to find the next Markov chain
mixing rate. These mixing rates were collected in
a list and graphed with respect to time to compare
with traditional vital signs.

Pearson correlation coefficients were determined
between the mixing rate and each vital sign (heart
rate and systolic blood pressure). The mixing rate
and high-frequency ABP waveforms (determined at
125 Hz) were then smoothed using a moving average
filter (100 samples window) before computing
the correlation coefficients. In an anesthetized pig
model, the Markov chain mixing rate of the ABP
waveform is strongly correlated with the vital signs
(mean correlation coefficient with SI -0.889 ± 0.143,
median -0.95) [7]. The relationship between the
mixing rate and traditional vital signs suggests that
this new marker might be an indicator of impending
hemodynamic imbalance.

B. Computing in Cardiology Challenge Dataset
To evaluate the efficacy of the marker on humans

subjects, a dataset published by Computing in
Cardiology Challenge (CinC) 2009 and the Medical
Information Mart for Intensive Care – III (MIMIC
III) database was used [8, 9]. One limitation of
the challenge data set was that it does not have



Second Largest Eigenvalue of the Transition Probability Matrix

Aisthesis      Volume 9,  201839

information regarding hemorrhage in the data, and
acute hypotensive episode was defined as a 30-minute
period in which mean arterial pressure was less than
60 mmHg and greater than 10 mmHg for at least 90%
of the 30-minute period. A total of 30 patient blood
pressure waveforms were obtained and had mixing
rates calculated over a period immediately preceding
a known acute hypotensive episode (AHE).

As shown in Figure 1, ABP waveforms
corresponding to each episode were downloaded
over a 70 minute window; the first 10 minutes were
used as a noncritical observation window to establish
a baseline, and the AHE of interest occurred ~30
minutes into the proceeding 60-minute forecast
window. These data were analyzed using a MATLAB
script to compute Markov chain mixing rates, and
Pearson correlation coefficients were determined
between mixing rate and traditional vital signs
(HR, ABP). Additionally, the correlation coefficient
between mixing rate and shock index was calculated
as a metric of the predictive capabilities of mixing
rate against clinical triage criteria.

Fig. 1. An example of an arterial blood pressure waveform
analyzed for Markov chain mixing rates. A 10-min.
baseline was used, with the AHE occurring approximately
30 min. into the given 60-min. forecast window.

C. GI Bleeding Dataset

To find hemorrhagic patients based on clinical
diagnosis, and not by AHE (as was the case for the
challenge data set), a comprehensive search of the
MIMIC III database was performed in order to
identify and analyze additional patients suffering
from acute hypotensive episodes. Using ICD-9 codes
across the entire MIMIC III database, patients were
identified based on their respective diagnoses, and
data for patients with high-frequency waveform
were recorded. For this analysis, the ICD-9 code
578.9 (gastrointestinal bleeding) was chosen, as
GI bleeding was considered to be the most similar
in behavior to the controlled hemorrhage of the

previous swine study. However, while clinical data
may exist for individual patients, it is imperative
that high-frequency physiological signals, more
specifically, ABP, are also present in the waveform
database, as only a subset of the subjects from the
clinical data have their high frequency waveform data
in the matched subset [10]. After searching the entire
MIMIC III database, 938 patients were diagnosed
with ICD-9 code 578.9, and of those patient records,
162 contained matching high-frequency waveform
data.

The MIMIC:SciDB platform (v16.9, Paradigm4,
Waltham, MA), was created by Paradigm4 in
collaboration with Regenstrief Center for Healthcare
Engineering (RCHE) and hosted at RCHE.
Extensive cleaning of the MIMIC time series data
was necessary to ensure the integrity of the data and
flag missing data. MIMIC:SciDB stores the 10 TB
of time series data in arrays with dimensions [time,
intensity, patient ID]. Each cell in the 3-dimensional
array contains a value for ECG, HR, ABP, and SpO2,
among others. Using SciDB’s streaming API for
parallel distributed computation, an algorithm was
applied to a subject’s entire hospital stay waveform to
identify all episodes of acute hypotension, defined as
a 30-minute period during which the mean arterial
pressure was below 60 mmHg for at least 90% of the
time [11, 12]. An R program was created to locate the
corresponding high-frequency data and download
the relevant data over the identified window of
AHE, including a 30-minute baseline prior to AHE
onset. Mixing rate analysis was performed for each
episode, and correlation coefficients were calculated
between mixing rate and vital signs (HR, ABP), as
well as against shock index.

Results
A. Computing in Cardiology Challenge Dataset

Analysis of the corresponding results (Figure
2) showed a small subset of patients displayed
correlation coefficients similar to the previous animal
study, a result that could possibly be explained by the
administration of pressors (vasoconstrictors). Of
the selected cohort, patients who were administered
pressors accounted for 5 of the 7 largest decreases
in Markov chain mixing rate, as shown in Table 1
(see Appendix). Conversely, patients who were



Second Largest Eigenvalue of the Transition Probability Matrix

Aisthesis      Volume 9,  201840

not administered pressors accounted for 4 of the 6
smallest decreases in mixing rate, as shown in Table
2 (see Appendix).

The correlation coefficients between the
mixing rate and the vital signs of patients who
were administered pressors show a resemblance to
the results obtained in the previous animal study
of swine that were administered pressors and
underwent controlled hemorrhage. The mixing
rate was inversely correlated with heart rate and
shock index, and showed a positive correlation to
systolic blood pressure. In the subset of patients
who were not administered pressors, virtually none
of the previous findings hold true. Patients showed
a negative correlation with systolic blood pressure
and a positive correlation with shock index, with
no significant correlation between mixing rate and
heart rate.

Fig. 2. High-frequency mixing rate of patients provided by
the CinC Challenge dataset. The blue line is the average of
all patient data over the course of 60 minutes. Hemorrhage
starts at time 0 (red vertical line).

B. GI Bleeding Dataset
Of the 162 patients identified in the matched

subset, 47 were analyzed for heart rate variability. Of
those, 8 patients were found to suffer from episodes
of acute hypotension, with a total of 81 hypotensive
episodes identified within the patient subset.
However, after analyzing all hypotensive episodes,
correlation values greater than |±0.50| accounted for
4 out of 243 measurements (1.6%) between mixing
rate and HR, SBP, and SI. Additionally, correlations
values between |±0.25| and |±0.50| accounted for 19
out of 243 measurements (7.8%) between mixing
rate and HR, SBP, and SI.

Mathematical Justification
For the changes in the mixing rate, we

hypothesized that the mixing rate change is observed
in the Markov chain because of the changes in the
density (number of non-zero elements of the matrix
divided by the total number of elements) and the
self-transition probability (the summation of the
probabilities that each state will stay at the same
state) of the chain. We provide the mathematical
justification of the hypothesis using Gershgorin
circle theorem that describes the relationship
between eigenvalues and the structural properties of
the transition matrix [13].

Gershgorin Circle Theorem
Let B be an arbitrary matrix. Then the eigenvalues λ
of B are located in the union of the n disks,

Where bkk is the diagonal element (self-transition
probability) and bkj is the non-diagonal elements for
each row (related to density) of the matrix.

For the analysis, from equation (1), we get,

From (2) and (3),

The construction of the Markov chain is such
that the summation of each row is 1. As a result,




Second Largest Eigenvalue of the Transition Probability Matrix

Aisthesis      Volume 9,  201841

As more states transition to the other states,
the self-transition probability bkk decreases and
increases, resulting in a decrease in the lower
bound of this inequality. This is what we observed
in the empirical analysis after the hemorrhage. We
conclude that the lower bound for the second largest
eigenvalue decreases with progressive hemorrhage
in anesthetic swine, as captured by the algorithm.
But the same conclusion did not hold true for
hemorrhagic human subjects, as defined by our
study.

Discussion
In the CinC 2009 Challenge dataset, the Markov

chain mixing rate of the ABP waveform did not
match the results of the previous animal study.
However, the mixing rate has a higher correlation
coefficient with the shock index for the patients
who were administered pressors, suggesting patients
administered pressors benefit more from Markov
chain analysis than those not administered pressors.
For patients administered pressors, the mixing rate
had an average correlation of 0.43 with arterial blood
pressure, -0.194 with heart rate, and -0.423 with
shock index (5 patients analyzed). Among patients
not administered pressors (4 patients analyzed),
the mean correlation coefficient was -0.386 ABP,
-0.075 with heart rate, and 0.392 with shock index.
These correlations do not reflect the findings of the
previous study.

There are limitations for the data sets that we
used. For the challenge data set, the patients were
assumed to have an acute hypotensive episode as a
consequence of hemorrhage, which is not always true.
Oftentimes, diagnoses of coronary artery disease,
congestive heart disease, or similar complications
can lead to symptoms of hypotensive episodes. For
the GI bleeding data set, the patients were identified
using ICD-9 code for GI bleeding, and an algorithm
was applied to define the time for acute hypotensive
episode from arterial blood pressure data. It is possible
that a patient experiencing an acute hypotensive
episode was not having hemorrhage, but rather had
another clinical diagnosis, such as septic shock,
hypotension resulting from adrenal insufficiency, or
as a result of abdominal compartment syndrome. All
of the aforementioned conditions can be expected in
a patient with a GI bleeding diagnosis.

The relationship between higher correlation
coefficients for patients with the administration
of pressors might be a useful factor to consider for
future Markov chain analyses. Hypovolemia ensues
when intravascular plasma volume is considerably
low. This results in hypotension, which is clinically
managed by volume administration (e.g., saline
products or blood products). However, if this does
not resolve hypotension, pressors are administered,
increasing the systemic vascular resistance and
hence the blood pressure. Oftentimes, medications
administered for anesthesia can result in refractory
hypotension requiring pressors, meaning that the
patients who were administered pressors may have
been experiencing similar symptoms to the previous
animal study, leading to the comparable decreases
in mixing rate and correlation coefficients between
studies.

For the data analyzed of patients diagnosed
with ICD-9 codes for gastrointestinal bleeding,
correlation coefficients greater than ±0.50 accounted
for 1.6% of all vital sign measurements. Correlation
coefficients between ±0.25 and ±0.50 accounted for
7.8% of all vital sign measurements. From the data
currently analyzed within this patient subset, the
results do not provide enough evidence to support
the claim that mixing rate is a predictive metric for
hypotensive events.

References
[1] D. S. Kauvar, R. Lefering, and C. E. Wade,

“Impact of hemorrhage on trauma outcome: an
overview of epidemiology, clinical presentations,
and therapeutic considerations,” J Trauma, vol.
60, no. 6 Suppl, pp. S3-11, Jun 2006.

[2] M. Y. Rady, E. P. Rivers, and R. M. Nowak,
“Resuscitation of the critically ill in the ED:
responses of blood pressure, heart rate, shock
index, central venous oxygen saturation, and
lactate,” Am J Emerg Med, vol. 14, no. 2, pp. 218-
25, Mar 1996.

[3] J. F. Thayer, S. S. Yamamoto, and J. F. Brosschot,
“The relationship of autonomic imbalance, heart
rate variability and cardiovascular disease risk
factors,” International J of Cardiology, vol. 141,
no. 2, pp. 122-131, 2010.



Second Largest Eigenvalue of the Transition Probability Matrix

Aisthesis      Volume 9,  201842

[4] S. Merrill, “Markov chains for identifying
nonlinear dynamics,” Nonlinear Dynamical
Systems Analysis for the Behavioral Sciences Using
Real Data, pp. 401-423, 2010.

[5] C. M. Cannon, C. C. Braxton, M. Kling-Smith,
J. D. Mahnken, E. Carlton, and M. Moncure,
“Utility of the shock index in predicting mortality
in traumatically injured patients,” J Trauma, vol.
67, no. 6, pp. 1426-30, Dec 2009.

[6] S. Merrill and J. Cochran, “Markov chain
methods in the analysis of heart rate variability,”
Nonlinear Dynamics and Time Series, vol. 11, p.
11, 1997.

[7] M. Adibuzzaman, G. C. Kramer, L. Galeotti,
S. J. Merrill, D. G. Strauss, and C. G. Scully,
“The mixing rate of the arterial blood pressure
waveform Markov chain is correlated with shock
index during hemorrhage in anesthetized swine,”
(in eng), Conf Proc IEEE Eng Med Biol Soc, vol.
2014, pp. 3268-71, 2014.

[8] “Predicting Acute Hyptotensive Episodes:
A Challenge from PhysioNet and Computers
in Cardiology 2009” (2009). PhysioNet
[online]. Available: https://www.physionet.org/
challenge/2009/

[9] A. Johnson et al., “MIMIC-III, a freely accessible
critical care database,” Scientific Data, vol. 3,
2016.

[10] M. Adibuzzaman, K. Musselman, A. Johnson,
P. Brown, Z. Pitluk, and A. Grama, “Closing the
data loop: An integrated open access analysis
platform for the MIMIC database,” in 2016
Computing in Cardiology Conference (CinC),
2016, pp. 137-140.

[11] J. Lee and R. G. Mark, “An investigation
of patterns in hemodynamic data indicative
of impending hypotension in intensive care,”
Biomed Eng Online, vol. 9, p. 62, Oct 25 2010.

[12] P. Brown and M. Adibuzzaman, ed, 2018.

[13] W. D. James, Applied Numerical Linear Algebra.
Philadelphia, USA: SIAM, 1997.





Second Largest Eigenvalue of the Transition Probability Matrix

Aisthesis      Volume 9,  2018

Table 1. Correlation coefficients between mixing rate and vital signs during hemorrhage in patients who were
administered pressors.

Table 2. Correlation coefficients between mixing rate and vital signs during hemorrhage in patients who were not
administered pressors.

Appendix

43
