American Journal of
Chemistry and Pharmacy (AJCP)

A Review on the Utilization and Environmental Concerns of  Coal Fly Ash
Saidu Kamara1, Edward Hingha Foday Jr2, Wei Wang1*

Volume 2 Issue 2, Year 2023
ISSN: 2834-0116 (Online)

DOI: https://doi.org/10.54536/ajcp.v2i2.1609
https://journals.e-palli.com/home/index.php/ajcp

Article Information ABSTRACT

Received: April 26, 2023

Accepted: June 10, 2023

Published: July 02, 2023

Coal is a well-known source of  electric power generation all over the globe. Pulverized coal
combustion and fluidized coal bed combustion are the two conventional methods involved
in the combustion of  coal in thermal power plants. Pulverized coal combustion is operated
at >14000C while the fluid bed is operated at a temperature between 850-9000C. The first
two reactions are the main reactions in the coal combustion process and they are exothermic
reactions. CO2 and CO are the first two combustion products. The inorganic minerals in
coal are released as waste products in the combustion plants in which fly ash made a large
part of  the waste materials. Fly ash is formed due to the incomplete combustion of  coal.
The fly ash from both methods contains SiO2, Al, etc, which are significant constituents.
High-grade coal has a higher SiO2 than the low grade. An experiment was conducted
by preparing four samples of  fly ash heated at 5000C, 6000C, 7000C, and 8000C, and one
unheated sample to investigate the chemical composition of  the fly ash obtained from
Xi’an Linyuan Silica Limited and to prove its suitability as raw material for the fabrication
of  refractory composites. SEM, EDS, XRD, and FTIR characterization were done on all
five samples to determine the chemical parameters of  the fly ash. According to the result
and analysis of  the four characterizations, it was discovered that the fly ash used in this
research contains SiO2. SEM/EDS morphological analysis reveals the presence of  spherical
and a few geometrical crystalline-shaped structures known as cenospheres. Cenospheres are
important components for the synthesis of  refractory composites. The EDS micrographs
show the percentages of  silicon and oxygen in the fly ash. The FTIR results show Si-O-Si
stretching in all the fly ash prepared samples. In the XRD, it was discovered that the fly ash
was purely SiO2.

Keywords
Characterization, Silica, Coal,
Combustion, Fly Ash

1 Department of  Chemical Engineering, School of  Water and Environment, Chang’an University, Xi’an, China
2 Key Laboratory of  Subsurface Hydrology and Ecology in Arid Areas, Ministry of  Education, Chang’an University, Xi’an, China
* Corresponding author’s e-mail: ksaidu2013@gmail.com

INTRODUCTION
The popular source of  electric power generation around the
world today is coal utilized in pulverized coal combustion
and fluid bed combustible conventional plants(S. H. Lee,
Lee, Jeong, & Lee, 2019; Miller, 2010). The two different
combustion methods operate at different temperatures
and therefore each method produces different fly ash with
different characteristics (Erol, Küçükbayrak, & Ersoy-
Mericboyu, 2008; L. Li, Wang, & Zhu, 2006; Molina &
Poole, 2004). The temperature range in the coal fluid
bed is 8500C-9000C while the temperature in pulverized
combustion is between 14000C-15000C. At temperatures
greater than 14000C (>14000C), minerals such as the
aluminosilicate present in coal disintegrate or decompose
(Mishra & Baliarsingh, 2008; Pavlish et al., 2003; Rios
Reyes, 2008). The disintegrated mineral particles form
hollow or spherical objects called cenospheres as a
result of  rapid cooling that takes place during the post-
combustion phase (Kim, 2002; Pundienė, Korjakins,
Pranckevičienė, & Kligys, 2018). High melting point
minerals sometimes remain unaltered. The physical and
chemical composition of  fly ash is significantly influenced
by the type of  coal used and the variation in combustion
temperatures (Adriano, Page, Elseewi, Chang, &
Straughan, 1980; Pedersen, Jensen, Skjøth-Rasmussen,
& Dam-Johansen, 2008; Ratafia-Brown, 1994). Both two
types of  combustion processes contain Al, SiO2, Fe, and
Ca which are the four most constituents in fly ash(Cheng

& Chen, 2003; Criado, Fernández-Jiménez, De La Torre,
Aranda, & Palomo, 2007). The fly ash produced from
coal fluidized beds (CBD) has no mullite and glass balls.
It contains high quantities of  unburnt carbon, calcium
carbonate, and calcium sulfate and it forms irregular
objects. Unburned carbon exists in both types of  fly
ash(Batra, Urbonaite, & Svensson, 2008; Maroto-Valer,
Taulbee, & Hower, 2001). Fly ash is among the popular
global raw material and one of  its most important
utilization is in the fabrication of  composites(Gollakota,
Volli, & Shu, 2019). In addition to the current global use
of  fly ash, further research and development are required
to enhance the management of  fly ash and bring out new
techniques to control the end products that result from
burning coal.
Harmful elements and compounds such as aromatic
compounds, carbon, silica, fine particulate matter,
etc., are aggregated in high concentrations during
combustion(Schwarze et al., 2006; Valavanidis, Fiotakis,
& Vlachogianni, 2008). Thermal power plants produce
enormous inorganic particles and emit combustible gases
into the atmosphere which negatively affects the health
of  residents around the thermal plants(Rahman, Farrok,
& Haque, 2022). The thermal industries have no use
for the ash generated and therefore regard it as a solid
waste product with the potential to negatively impact
the environment if  not properly regulated(Foday Jr et
al., 2017). A small amount ( ≈20%) of  the global fly ash

https://doi.org/10.54536/ajcp.v2i2.1609
https://journals.e-palli.com/home/index.php/ajcp
mailto:ksaidu2013%40gmail.com?subject=


Pa
ge


42

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

produced annually, is used for many purposes and the
rest reportedly contributes to the existing global pollution
trend.
Characterizations using SEM, EDS, XRD, FTIR, etc, to
determine the composition of  fly ash have been studied.
Several past works on the two types of  fly ash were
centered on their properties, morphology, and chemical
composition. In this study, the morphology and chemical
information of  the fly ash samples is determined by
SEM and EDS. The XRD reveals information about the
crystalline size and amorphous phase of  the samples. The
in-situ functional groups (Si-O-Si, C-O, Al-O, etc,) in fly
ash are accounted for by the Fourier transform infrared
spectroscopy (FTIR). These functional groups are the
typical determinants for the use of  fly ash as raw material
for the synthesis of  composites. This experiment,
therefore, studies the characterization of  purified fly ash
from the Xi’an Linyuan silica limited.
The major problem encountered in the characterization
of  fly ash is the amorphous phase of  the sample which
is normally not captured by the XRD. A more adequate
instrument is therefore required for the characterization
of  fly ash to identify its glass phase and interpret chemical
composition. EDS is the most common effective tool used
for this purpose but the contrasting characteristics of  fly
ash present a large scattered result that makes the analysis
very difficult.  In recent times, new EDS technology or
detectors have been invented with the capability to collect
the spectrums of  all pixels in not more than an hour.
The spectra collected are further processed into maps
that show the elemental intensities used to quantify the
chemical compositions of  the elements present.

LITERATURE REVIEW
Process and end products of  coal combustion
Coal constitutes inorganic minerals released as waste
products (fly ash, bottom ash, and slag) during the
burning of  coal. The greater part of  the waste products
in the combustion plant is made of  fly ash. Fly ash is
made of  fine light particles and has a density of  about
2.5g/cm3, bottom ash is composed of  coarse particles
while slag is the melted phase of  bottom ash(Bourtsalas,
2015; Bunge, 2015). The ash generated in the combustion
plant is made of  a large mass of  oxides (silica, alumina,
titanium oxide, magnesium oxide, calcium oxide,
sulfoxide, etc,) and heavy metals (zinc, lead, copper,
nickel, cobalt, cadmium, etc,)(Foday Jr, Bo, & Xu, 2021;
Halmann, 1995; Oves, Khan, Zaidi, & Ahmad, 2012). Fly
ash contains some quantities of  spherical matter called
cenospheres formed by the decomposed minerals in the
condensation or cooling stage (Blissett & Rowson, 2012;
Fenelonov, Mel’gunov, & Parmon, 2010; Oves et al., 2012;
Vassilev, Baxter, Andersen, & Vassileva, 2013).
Fly ash is formed due to the incomplete combustion
of  the mineral components in coal which subsequently
transform into some crystalline phases called quartz
(silica), magnetite, aluminosilicate glass (mullite), spinel,
etc. It is confirmed that fly ash is made of  over 80% of
silica (SiO2)(Criado et al., 2007; Joshi & Lohita, 1997;
Vassilev & Vassileva, 1996). The glass phase in fly ash
is formed from low-grade bituminous coals which
constitute lesser quantities of  silica and a higher amount
of  magnetite compared to high-grade bituminous coal
which composes high silica content. The process leading
to the formation of  fly ash is explained in figure 1 below:

Figure 1: A modified schematic diagram for the formation of  fly ash

The process begins with vaporizable components which
nucleate to produce new crystalline objects, form char
and release heavy metals by vaporization.

Reactions in coal combustion
The carbon in coal undergoes the following chemical
reaction with oxygen.

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


43

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

C + O2 = CO2                   ∆H=-393.7 kj/mol      (1)
C + 0.5O2 = CO               ∆H=-110.1kj/mol       (2)
C + CO2 = 2CO               ∆H=+172.6kj/mol      (3)
C + H2O = CO + H2       ∆H=+131.4kj/mol      (4)
CO + 0.5O2 = CO2          ∆H=-283.6kj/mol       (5)
H2 + 0.5O2 = H2O          ∆H=-242.4kj/ml        (6)
CO + H2O = CO2 + H2  ∆H=-41.2kj/mol          (7)
The reaction is exothermic when the enthalpy ∆H change
is negative (i.e. heat is given out during the reaction) while
a positive enthalpy ∆H means the reaction is endothermic
(i.e. heat is absorbed during the reaction). The first two
reactions are the main combustion reactions according
to their products. CO2 and CO are the first combustion
products and their ratios increase with an increase in
temperature and a decrease in pressure. The whole
combustion process leading to the formation of  a coal
boiler takes about two seconds.

Mathematical models for fly ash deposition in a
boiler tube
Mathematical models are employed to determine the
activity of  ash precipitation and to ameliorate the lapses
in industrial design (Fan, Zha, Sun, & Cen, 2001).  The
prediction of  ash deposition has been done by a good
number of  researchers using experimental notations but
it becomes misleading when taking into consideration
other operating factors (Fan et al., 2001; Zeng, Zheng,
Zhou, Fang, & Lou, 2016). The deposition of  ash in
boilers has been adequately studied with the application
of  numerical procedures. Fly ash data obtained from a
computer control scanning electron microscope has been
used to develop a fly ash prediction model (F. Lee &
Lockwood, 1999). The temperature, porosity, and rate of
deposition were simulated by Galen et al (Richards, Slater,
& Harb, 1993).

Particle Movement Expressions
Newton’s equation of  motion below is used to account
for the particle movement in a pulverized boiler.

The drag force Fd is given by
Fd= -3πdμ(v-u)f
where μg is the gas viscosity and f  is the drag force
coefficient that is used to revise the Stokes expression
and assuming that f=1.
Waldmann equation below is used to determine the
thermophoretic force (Waldmann & Schmitt, 1966)

Where
Ktr is the thermal conductivity of  the gas and
∆T is the temperature gradient.
The mean speed c of  gas molecules is given by

Particle Collision Forces
The particle equation is used to compute the collision
velocities of  fly ash deposition in a boiler. To ensure
efficient and smooth velocity collision, the particle in
motion must be spherically rigid, the interaction forces
and infinite forces should be impulsive and negligible
respectively, and the particle movement should be centered
and two-dimensional. The mathematical expression for a
particle is given below (Hoomans, Kuipers, Briels, & van
Swaaij, 1996).

where,
vi.0 and vi,1  is the pre-collisional and post-collisional
velocities of  particle i, and
vj,0 and vj,1 are the pre-collisional and post-collisional
velocities of  particle j.
In the absence of  particle-particle collision, we can also
find the sample position using the single-particle equation
at a time. The method of  Monte Carlo is exclusively used
to compute the particle-particle collision. If  particle i
collides with particle j in the time step, the post-collision
velocities of  particles are accounted for by taking into
consideration the dynamics of  the collisions. The
velocities after particle collision will now substitute the
initial particle velocities but the particles remain fixed in
their fixed positions. The particle i in a time step Δt is
determined by the probability of  the collision below(Bird,
1994; Tsuji, Tanaka, & Yonemura, 1998):


where
N is the number of  simulated particles in the cell,
n is the local particle number,
d is the particle diameter,
go is the radial distribution function,
vij v is the relative velocity between particle i and j, and
∆t is the time step.
The collision pairs searching is the key problem in the
calculation of
particle-particle collision.

Ash Deposition Model
During the process of  ash deposition, the large ash
particle causes an impact in the boiler tube and rebounds
while the smaller ones can stick onto the tube with
high adhesive energies(G. Li, Li, Huang, & Yao, 2015).
The formation of  the first layer improves the surface
sticking capability in the tub. The critical velocity model
is employed to ascertain if  a particle motion sticks or
rebounds in the boiler tube. The critical velocity equation
is written as:

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


44

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

Where,
W is the adhesion energy and
E is Young’s modulus (S. Li, Marshall, Liu, & Yao, 2011;
Liu, Li, & Yao, 2011).
According to the simulation of  the critical velocity (
Vcritical ) expression above, the impact of  the particle
velocity is compared with the critical velocity. When the
critical velocity of  a particle is larger than the velocity
impact, the particle clings to the surface.

MATERIALS AND METHOD
Five samples of  fly ash were measured on an electronic
weighing scale. Each sample weighs 4g. Four of  these
samples were heated at 5000C, 6000C, 7000C, and 8000C
for 3 hours in a muffle furnace and one remain unheated.
The samples were then taken for SEM, EDS, XRD, and
FTIR characterization. The aim was to determine the
elemental characteristics of  fly ash that make it a suitable
raw material to synthesize refractory composites.

Figure 2: Illustration of  instrumental setup and sample preparation

RESULT AND DISCUSSION
SEM Result
This technique is utilized by material scientists to
determine and interprete the microstructure of  materials.
The sample electrons are bombarded to produce a wide
range of  emissions (such as X-rays, visible photons, auger
electrons, secondary electrons, backscattered electrons,
etc). The SEM result of  the fly ash specimens is discussed
as follows:

Heated fly ash
Figures A and B below present the SEM results of  four
samples of  fly ash heated at 5000C, 6000C, 7000C, and
8000C. The images in figure (A) above are the results
of  sample sizes scanned at 100 um pixels while figure B
scanned image sizes at 20 um. The morphology of  the
images is based on the materials present in the fly ash
samples.

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


45

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

Figure 3: SEM images showing samples scanned at 100 um in (A) and at 20 um in (B).

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


46

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

All four sample images show un-interconnected irregular
oval structured layers in both figures A and B. Few
geometrically shaped structures are observed in sample
3. The agglomerated oval glassy and geometrically shaped
structures are typical of  the presence of  silica crystalline
structures in the sample materials. The balloon-shaped
crystals are indicative of  the presence of  cenospheres
in the fly ash samples. There are significant pore sizes
in the samples and are observed to be highly visible in
specimens 1, 2, and 4 but less in specimen 3. This shows
that there might be other materials present in the samples
but in less or insignificant quantities. All four samples
heated at various temperatures show that quartz or silica
is the dominant crystalline phase present in the fly ash
sample. The samples were heated at temperatures that
will lead to the elimination of  carbon contents present in
the fly ash with no chemical reaction taking place.

Figure 4: SEM images of  unheated raw fly ash at three
different magnifications

According to the micrographs, the oval crystalline
structures become more pronounced as the temperature
increases from 5000C, 6000C, 7000C, and 8000C.
Conversely, the dark fields observed in the micrographs
according to the morphology of  the sample become
lesser as the temperature is increased from sample one to
four. This can be attributed to the carbon content which
decreases as more temperature is applied to the fly ash.

Unheated fly ash sample
Figure 4 shows the SEM micrographs of  the unheated fly
ash specimen with image sizes scanned at 200 um, 30 um,
and 20 um pixels. The oval crystals are the same as those
of  the heated samples shown in figure 3 but are visibly
observed to be far apart from each other compared to
those seen in figure 3A above. This probably implies the
presence of  carbon content and other minor constituents
that occupies the spaces between the crystals.

EDS Result
This is a powerful analytical detector or tool used to
determine the chemical elements present in a sample

and estimate their relative abundance. It relies on the
interaction of  some source of  X-ray excitation and a
sample. The capability of  this tool is due to the fact or
principle that each element has its unique structure that
allows several peaks to display on its electromagnetic
emission spectrum (which is the main principle of  the
electromagnetic spectrum).
In the emission of  X-ray characteristics from a sample,
a beam of  electrons is focused on the sample under
investigation. At rest, an atom within the sample contains
ground state (or unexcited) electrons in discrete energy
levels or electron shells bound to the nucleus. The
incident beam may excite an electron in an inner shell,
ejecting it from the shell and forming a hole in the initial
position of  the electron. An electron from an outer,
higher-energy shell then fills the hole, and the difference
in energy between the higher-energy shell and the lower-
energy shell may be released in the form of  an X-ray. The
EDS is then used to measure the number and energy of
the X-rays emitted from the sample. The detector or tool
allows the elemental composition of  the sample to be
measured since the energies of  the X-ray are characteristic
of  the atomic structure of  the emitting element.

Figure 5: EDS result of  heated fly ash specimens 1,2,3
& 4

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


47

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

The EDS shown in figures 5 and 6 confirmed the
percentage weight and elemental composition of  both
heated and unheated fly ash samples. According to the
EDS result, oxygen and silicon are the predominating
elements present in all five prepared samples. The
percentage composition of  oxygen is greater than that
of  silicon in all five samples. It is also observed from
the elemental tables of  the EDS figures that the weight
percentage of  silicon is higher in the first, third, and
unheated samples than those of  oxygen atoms but lesser
in the second and fourth samples. The results and analysis

of  this work show that fly ash used is silica pure and
therefore a recommendable source for the fabrication of
refractory composite materials.

Cenospheres
According to the SEM and EDS results of  this research,
the hollow and spherical-shaped objects observed in
all five samples depict the presence of  cenospheres.
Cenospheres are one of  the end products in coal
combustion and are significant components for the
synthesis of  refractory composites. They are formed as
a result of  the decomposition of  the mineral matter in
coal at high temperatures >14000C. The disintegrated or
decomposed mineral matter form into spheres known as
cenospheres during the post-combustion phase or cooling
process. The decomposition of  calcium carbonate and
other compounds below 10000C produces gases that blow
up the minerals. The gases emitted during coal combustion
inflate the decomposed minerals to form cenospheres.
These objects are largely made of  mullite, quartz
(silica), aluminosilicate glass, calcite, sulfates, etc. Inside
the balloon-shaped structure of  the cenospheres
are gases while the outer membrane or layer is made
of  aluminosilicate, cristobalite, quartz, mullite, etc.
Cenospheres are discovered to be highly porous and can
therefore effectively absorb water.

Figure 6: EDS result of  unheated fly ash specimen

Figure 7: EDS and SEM micrographs showing cenospheres

The cenospheres discovered from the fly ash samples
in this experimental research can be used for electronic
and radar purposes due to their metallic and magnetic
properties. Cenospheres are useful to refractory industrial
engineers due to their low thermal conductivities and
high heat resistance. They also have properties that are
suitable to make lightweight composite materials used in
aerospace engineering.

FTIR Result
This technique is employed to study the vibrations
of  atoms in a molecule or compounds of  a particular
sample. The fractions of  absorbed incident radiation at a
particular energy are determined by passing Infrared (IR)
radiation through the specimen. The FTIR results and
analysis of  the prepared fly ash specimens are discussed
below.

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


48

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

Heated Samples
The figure below shows the FTIR spectra obtained from
the characterization of  fly ash samples heated at 5000C,
6000C, 7000C, and 8000C. According to the experimental
result of  the sample heated at 5000C, a strong appearance
of  O=C=O bending of  carbon dioxide compound is
observed at a wavenumber of  2349cm-1. Further, the
wavenumber 1083cm-1 depicts the appearance of  Si-
O-Si stretching vibrations and strong absorption peaks
while the 799cm-1 wavenumber shows Si-O symmetric
stretching of  quartz.
Analysis of  the FTIR experimental data for the sample
heated at 6000C also depicts the appearance of  O=C=O
at 2349cm-1 which indicates a strong vibrational stretching
of  the carbon dioxide compound. The wavenumbers

1090cm-1 and 807cm-1 indicate Si-O-Si and Si-O stretching
vibrations respectively.
In sample three, the wavenumber 2363cm-1 from FTIR
results shows O=C=O bending but does not fall at
2349cm-1 which is the strong absorption band for
O=C=O. Therefore, the appearance of  carbon dioxide
compound at 2363cm-1 can either be weak or medium. The
frequency range for the absorption of  O=C=O is 2400cm-

1–2000cm-1. The wavenumber1090cm-1 and 803cm-1 show
the stretching vibrations of  Si-O-Si and Si-O respectively.
The FTIR of  the fourth sample heated at 8000C shows
the absorption frequencies of  2369cm-1, 1123-1027cm-

1, and 798cm-1. The wavenumber 2369cm-1 shows weak
or medium O=C=O stretching vibrations while 798cm-1
depicts the Si-O symmetric of  quarts.

Figure 8: FTIR results of  four heated fly ash samples

Unheated samples
Figure 9 shows the FTIR result of  the unheated fly ash.
According to the analysis of  this result, the wavenumber
2349 cm-1 shows the appearance of  O=C=O stretching
vibrations, 1049 cm-1 indicates the strong appearance of
S=O stretching vibration of  sulfoxide while 801 cm-1
depicts the Si-O symmetric stretching vibration of  the
quartz. The frequency range for the strong absorption of
sulfoxide compounds is 1070-1030.
It is observed that the unheated fly ash shows a strong
appearance of  O=C=O and S=0 stretching. All five samples
(both heated and unheated) show O=C=O bending with
very strong stretching vibrations for the unheated sample
and those heated at 5000C and 6000C while the third and
fourth samples heated at 7000C and 8000C show a weak or
medium appearance of  O=C=O stretching. This suggests
that the more the temperature the greater the chances of
eliminating the carbon content in the fly ash. Samples 1,
2, and 3 heated at 5000C, 6000C, and 7000C respectively
also show the appearance of  Si-O-Si but not observed for
the unheated and the heated samples at 8000C. The Si-O

quartz appears in all five samples according to the FTIR
result. Finally, it is observed from the FTIR result of  this
work that sulfoxide functional group (S=O) only appears
in the unheated fly ash and is not seen in all the heated
samples. This is an indication that sulfoxide in the raw fly
ash easily disappears when subjected to a certain amount
of  heat.

Figure 9: FTIR result of  unheated fly ash sample

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


49

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

Table 1: Wave numbers of  different types of  functional groups
Wavenumber
(cm-1)

Compound Functional Reference

3454 Montmorillonite OH group of  absorbed water
dust-stretching

(Summer, 1995)

2923 Organic carbon C-H stretching vibration (Hlavay, Jonas, Elek, & Inczedy, 1978)
1629 Organic matter C=O carboxylate group (Langford, Hodson, & Banwart, 2011;

Matrajt et al., 2004)
1384 Nitrate species N-O stretching (Smidt, Böhm, & Schwanninger, 2011)
1097 Quartz Si-O-Si asymmetric stretching

vibration
(Katara, Kabra, Sharma, Hada, & Rani,
2013)

794 Quartz Si-O symmetric (Coates, 1977)
463 Feldspar Amorphous silica Si-O-Si band (Karr, 2013)
2517 Calcite Vibrational mode of  carbonate (Ramasamy, Rajkumar, & Ponnusamy, 2009)
1448 Calcite C-O stretching for carbonate (Ramasamy, Suresh, Meenakshisundaram,

& Ponnusamy, 2011)
1032 Kaolinite Si-O vibration of  clay mineral (Ramasamy, Rajkumar, & Ponnusamy, 2006)
873 Calcite C-O bending for carbonate (Dahlan, Mei, Kamaruddin, Mohamed, &

Lee, 2008)
795 Quartz Si-O symmetric (Coates, 1977)
712 Calcite Carbonate (Adler & Kerr, 1963)
466 Feldspar Si-O-Si bending (Dahlan et al., 2008)
1467 Calcite C-O stretching for carbonate (Ramasamy et al., 2011)
2520 Calcite Vibrational mode of  carbonate (Ramasamy et al., 2006)
796 Quartz Si-O symmetric (Coates, 1977)
800, 802 Quartz Si-O bending (Ramasamy et al., 2009)
1083, 1089 Si-O-Si stretching (Ramasamy et al., 2011)
1080, 1025 Si-O-Si stretching vibration (Ramasamy et al., 2011)
1020, 1090  Si-O-Si (Ramasamy et al., 2011)
910 - 830 Si-O stretching vibration (Ramasamy et al., 2006)
3550 - 3200 Alcohol O-H (Ramasamy et al., 2006)
1685 Conjugated ketone C=O stretching (Ramasamy et al., 2006)
1662-1626 Alkene C=C (Ramasamy et al., 2006)
1205 - 1124 Tertiary alcohol C-O stretching (Smidt et al., 2011)
1124 - 1087 Secondary alcohol C-O stretching (Smidt et al., 2011)
1070 - 1030 Sulfoxide S=O stretching (Ramasamy et al., 2006)
850 - 550 Halo compound C-Cl stretching (Ramasamy et al., 2006)
840 - 790 Alkene C=C (Ramasamy et al., 2006)
690 - 515 Halo compound C-Br stretching (Smidt et al., 2011)
600 - 500 Halo compound C-I stretching (Smidt et al., 2011)
1650 - 1556 Cyclic Alkene (Smidt et al., 2011)
2400 - 2000 Carbon dioxide O=C=O (Smidt et al., 2011)

XRD Result
Material scientists and solid-state chemists use the powdered
X-ray diffraction technique to determine the structure
of  a crystalline solid specimen under investigation. The
diffraction pattern is formed by the interaction of  the
X-ray and atomic structure. Brag’s law below is used to
explain the direction of  the scattered X-rays produced.
nnλ =2dsinθ

Where
n = an integer
λ = wavelength of  the X-ray
d = space between two layers of  atoms
θ = angle between the incoming x-ray and the atom layer

The XRD results obtained from four heated and one
unheated specimen of  fly ash samples are explained in the
figures below

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


50

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

Figure 10: XRD result of  heated fly ash

The XRD result in figures 10 and 11 shows the presence
of  SiO2 in all the fly ash samples. This information is in
line with the SEM/EDS and FTIR characterizations. The
results and analysis of  all the characterization in this work
confirmed that the purified fly ash obtained from Xi’an
Linyuan Silica Limited is pure silica.

CONCLUSION
Critical analysis of  the experimental results from the four
characterization techniques shows that fly ash purely
constitutes SiO2 which is a significant constituent for the
fabrication of  refractory composites. According to the
SEM/EDS results, the cenospheres discovered in the
specimens are useful to refractory industrial engineers due
to their low thermal conductivities and high heat resistance.

Acknowledgments
This work was supported by the National Natural Science
Foundation of  China. Thanks, and appreciation to Wang
Wei of  the chemical engineering department, school of
Water and Environment of  Chang’an University for the
adequate supervision and for providing the platform for
the successful conduct of  this work.

REFERENCES
Adler, Hans H, & Kerr, Paul F. (1963). Infrared spectra,

symmentry and structure relations of  some carbonate
minerals. American Mineralogist: Journal of  Earth and
Planetary Materials, 48(7-8), 839-853.

Adriano, DC, Page, AL, Elseewi, A A, Chang, AC, &
Straughan, I. (1980). Utilization and disposal of  fly
ash and other coal residues in terrestrial ecosystems:
a review. Journal of  Environmental quality, 9(3), 333-344.

Batra, Vidya S, Urbonaite, Sigita, & Svensson, Gunnar.
(2008). Characterization of  unburned carbon in
bagasse fly ash. Fuel, 87(13-14), 2972-2976.

Bird, Graeme A. (1994). Molecular gas dynamics and
the direct simulation of  gas flows. Molecular gas
dynamics and the direct simulation of  gas flows.

Blissett, RS, & Rowson, NA. (2012). A review of  the
multi-component utilisation of  coal fly ash. Fuel, 97,
1-23.

Bourtsalas, Athanasios. (2015). Processing the problematic
fine fraction of  incinerator bottom ash into a raw
material for manufacturing ceramics. Imperial College
London.

Figure 11: XRD result of  unheated fly ash

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


51

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

Bunge, Rainer. (2015). Recovery of  metals from waste
incinerator bottom ash. Removal, Treatment and
Utilisation of  Waste Incineration Bottom Ash; Holm,
O., Thome-Kozmiensky, E., Eds, 63-143.

Cheng, TW, & Chen, YS. (2003). On formation of
CaO–Al2O3–SiO2 glass–ceramics by vitrification of
incinerator fly ash. Chemosphere, 51(9), 817-824.

Coates, JP. (1977). The IR analysis of  Quartz and
Asbestos. Nelioth Offset Ltd., Chesham, England.

Criado, María, Fernández-Jiménez, Ana, De La Torre,
AG, Aranda, MAG, & Palomo, A. (2007). An XRD
study of  the effect of  the SiO2/Na2O ratio on the
alkali activation of  fly ash. Cement and concrete research,
37(5), 671-679.

Dahlan, IRVAN, Mei, GM, Kamaruddin, AZLINA
HARUN, Mohamed, ABDUL RAHMAN, & Lee,
KEAT TEONG. (2008). Removal of  SO2 and NO
over rice husk ash (RHA)/CaO-supported metal
oxides. Journal of  Engineering Science and Technology, 3(2),
109-116.

Erol, M, Küçükbayrak, S, & Ersoy-Mericboyu, A. (2008).
Comparison of  the properties of  glass, glass–ceramic
and ceramic materials produced from coal fly ash.
Journal of  Hazardous Materials, 153(1-2), 418-425.

Fan, JR, Zha, XD, Sun, P, & Cen, KF. (2001). Simulation
of  ash deposit in a pulverized coal-fired boiler. Fuel,
80(5), 645-654.

Fenelonov, Vladimir Borisovich, Mel’gunov, Maxim
Sergeevich, & Parmon, Valentin N. (2010). The
properties of  cenospheres and the mechanism
of  their formation during high-temperature coal
combustion at thermal power plans. KONA Powder
and Particle Journal, 28, 189-208.

Foday Jr, Edward Hingha, Bo, Bai, & Xu, Xiaohui. (2021).
Removal of  toxic heavy metals from contaminated
aqueous solutions using seaweeds: A review.
Sustainability, 13(21), 12311.

Foday Jr, Edward Hingha, Ramli, Nurul As’shikin,
Ismail, Hairu Nabilah, Malik, Nulhazwany Abdul,
Basri, Hazlami Fikri, Aziz, Fatihah Syahirah Abdul,
. . . Jumhat, Fairoz. (2017). Municipal solid waste
characteristics in Taman Universiti, Skudai, Johore,
Malaysia. Journal of  Advanced Research Design, 38, 13-20.

Gollakota, Anjani RK, Volli, Vikranth, & Shu, Chi-Min.
(2019). Progressive utilisation prospects of  coal fly
ash: A review. Science of  the Total Environment, 672, 951-
989.

Halmann, Martin M. (1995). Photodegradation of  water
pollutants: CRC press.

Hlavay, Jozsef, Jonas, K, Elek, S, & Inczedy, J. (1978).
Characterization of  the particle size and the crystallinity
of  certain minerals by IR spectrophotometry and
other instrumental methods—II. Investigations on
quartz and feldspar. Clays and Clay Minerals, 26, 139-
143.

Hoomans, BPB, Kuipers, JAM, Briels, Willem J, & van
Swaaij, Willibrordus Petrus Maria. (1996). Discrete
particle simulation of  bubble and slug formation in

a two-dimensional gas-fluidised bed: a hard-sphere
approach. Chemical Engineering Science, 51(1), 99-118.

Joshi, Ramesh C, & Lohita, RP. (1997). Fly ash in concrete:
production, properties and uses, 2, CRC Press.

Karr, Clarence. (2013). Infrared and Raman spectroscopy
of  lunar and terrestrial minerals: Elsevier.

Katara, S., Kabra, S., Sharma, A., Hada, R., & Rani, A.
(2013). Surface modification of  fly ash by thermal
activation: a DR/FTIR study. International Research
Journal of  Pure and Applied Chemistry, 3(4), 299-307.

Kim, Ann G. (2002). Physical and chemical characteristics
of  CCB. Paper presented at the Proceedings of
Coal Combustion By-Products and Western Coal
Mines: A Technical Interactive Forum. Allton, IL:
US Department of  the Interior, Office of  Surface
Mining.

Langford, H., Hodson, A., & Banwart, S. (2011). Using
FTIR spectroscopy to characterise the soil mineralogy
and geochemistry of  cryoconite from Aldegondabreen
glacier, Svalbard. Applied Geochemistry, 26, S206-S209.

Lee, FCC, & Lockwood, FC. (1999). Modelling ash
deposition in pulverized coal-fired applications.
Progress in Energy and Combustion Science, 25(2), 117-132.

Lee, See Hoon, Lee, Tae Hee, Jeong, Sang Mun, & Lee,
Jong Min. (2019). Economic analysis of  a 600 mwe
ultra supercritical circulating fluidized bed power
plant based on coal tax and biomass co-combustion
plans. Renewable Energy, 138, 121-127.

Li, Gengda, Li, Shuiqing, Huang, Qian, & Yao, Qiang.
(2015). Fine particulate formation and ash deposition
during pulverized coal combustion of  high-sodium
lignite in a down-fired furnace. Fuel, 143, 430-437.

Li, Lin, Wang, Shaobin, & Zhu, Zhonghua. (2006).
Geopolymeric adsorbents from fly ash for dye
removal from aqueous solution. Journal of  colloid and
interface science, 300(1), 52-59.

Li, Shuiqing, Marshall, Jeffrey S, Liu, Guanqing, &
Yao, Qiang. (2011). Adhesive particulate flow: The
discrete-element method and its application in energy
and environmental engineering. Progress in Energy and
Combustion Science, 37(6), 633-668.

Liu, Guanqing, Li, Shuiqing, & Yao, Qiang. (2011). A
JKR-based dynamic model for the impact of  micro-
particle with a flat surface. Powder Technology, 207(1-3),
215-223.

Maroto-Valer, MM, Taulbee, DN, & Hower, JC. (2001).
Characterization of  differing forms of  unburned
carbon present in fly ash separated by density gradient
centrifugation. Fuel, 80(6), 795-800.

Matrajt, G, Borg, J, Raynal, PI, Djouadi, Z, d’Hendecourt,
L, Flynn, G, & Deboffle, D. (2004). FTIR and Raman
analyses of  the Tagish Lake meteorite: Relationship
with the aliphatic hydrocarbons observed in the
diffuse interstellar medium. Astronomy & Astrophysics,
416(3), 983-990.

Miller, Bruce G. (2010). Clean coal engineering
technology: Elsevier.

Mishra, Barun, & Baliarsingh, Sandeep Kumar. (2008).

https://journals.e-palli.com/home/index.php/ajcp


Pa
ge


52

https://journals.e-palli.com/home/index.php/ajcp

Am. J. Chem. Pharm. 2(2) 41-52, 2023

Kinetics of  iron ore reduction by coal and charcoal.
Molina, A, & Poole, C. (2004). A comparative study using

two methods to produce zeolites from fly ash. Minerals
Engineering, 17(2), 167-173.

Oves, Mohammad, Khan, Mohammad Saghir, Zaidi,
Almas, & Ahmad, Ees. (2012). Soil contamination,
nutritive value, and human health risk assessment of
heavy metals: an overview: Springer.

Pavlish, John H, Sondreal, Everett A, Mann, Michael D,
Olson, Edwin S, Galbreath, Kevin C, Laudal, Dennis
L, & Benson, Steven A. (2003). Status review of
mercury control options for coal-fired power plants.
Fuel processing technology, 82(2-3), 89-165.

Pedersen, Kim Hougaard, Jensen, Anker Degn, Skjøth-
Rasmussen, Martin Skov, & Dam-Johansen, Kim.
(2008). A review of  the interference of  carbon
containing fly ash with air entrainment in concrete.
Progress in Energy and Combustion Science, 34(2), 135-154.

Pundienė, Ina, Korjakins, Aleksandrs, Pranckevičienė,
Jolanta, & Kligys, Modestas. (2018). Effect of  silicon
carbide aggregate, prepared by different methods,
on the properties of  refractory concrete with
cenospheres. Ceramics International, 44(13), 15944-
15953.

Rahman, A., Farrok, O., & Haque, M. M. (2022).
Environmental impact of  renewable energy
source based electrical power plants: Solar, wind,
hydroelectric, biomass, geothermal, tidal, ocean, and
osmotic. Renewable and Sustainable Energy Reviews, 161,
112279.

Ramasamy, V, Rajkumar, P, & Ponnusamy, V. (2006).
FTIR spectroscopic analysis and mineralogical
characterization of  Vellar river sediments. Bull. Pure
Appl. Sci, 25(1), 49-55.

Ramasamy, V, Rajkumar, P, & Ponnusamy, V. (2009).
Depth wise analysis of  recently excavated Vellar river
sediments through FTIR and XRD studies. Indian
journal of  physics, 83, 1295-1308.

Ramasamy, V, Suresh, G, Meenakshisundaram, V, &
Ponnusamy, V. (2011). Horizontal and vertical
characterization of  radionuclides and minerals in
river sediments. Applied Radiation and Isotopes, 69(1),
184-195.

Ratafia-Brown, Jay A. (1994). Overview of  trace element
partitioning in flames and furnaces of  utility coal-fired
boilers. Fuel Processing Technology, 39(1-3), 139-157.

Richards, Galen H, Slater, Peter N, & Harb, John N.

(1993). Simulation of  ash deposit growth in a
pulverized coal-fired pilot scale reactor. Energy &
Fuels, 7(6), 774-781.

Rios Reyes, Carlos A. (2008). Synthesis of  zeolites from
geological materials and industrial wastes for potential
application in environmental problems.

Schwarze, PE, Øvrevik, J, Låg, M, Refsnes, M, Nafstad,
P, Hetland, RB, & Dybing, E. (2006). Particulate
matter properties and health effects: consistency of
epidemiological and toxicological studies. Human &
experimental toxicology, 25(10), 559-579.

Smidt, Ena, Böhm, Katharina, & Schwanninger, Manfred.
(2011). The application of  FT-IR spectroscopy
in waste management. Fourier Transforms-New
Analytical Approaches and FTIR Strategies. Rijeka,
Croatia: InTech, 405-430.

Summer, ME. (1995). Hand book of  soil science,
University of  Georgia: Boca Raton Hondor press,
New York.

Tsuji, Y, Tanaka, Toshitsugu, & Yonemura, Shigeru.
(1998). Cluster patterns in circulating fluidized beds
predicted by numerical simulation (discrete particle
model versus two-fluid model). Powder Technology,
95(3), 254-264.

Valavanidis, Athanasios, Fiotakis, Konstantinos, &
Vlachogianni, Thomais. (2008). Airborne particulate
matter and human health: toxicological assessment
and importance of  size and composition of  particles
for oxidative damage and carcinogenic mechanisms.
Journal of  Environmental Science and Health, Part C, 26(4),
339-362.

Vassilev, Stanislav V, Baxter, David, Andersen, Lars K,
& Vassileva, Christina G. (2013). An overview of
the composition and application of  biomass ash.
Part 1. Phase–mineral and chemical composition and
classification. Fuel, 105, 40-76.

Vassilev, Stanislav V, & Vassileva, Christina G. (1996).
Mineralogy of  combustion wastes from coal-fired
power stations. Fuel Processing Technology, 47(3), 261-280.

Waldmann, L, & Schmitt, KH. (1966). Thermophoresis
and diffusiophoresis of  aerosols Aerosol science
(Vol. 137): Academic Press New York.

Zeng, Xiongwei, Zheng, Shu, Zhou, Huaichun, Fang,
Qingyan, & Lou, Chun. (2016). Char burnout
characteristics of  five coals below and above ash flow
temperature: TG, SEM, and EDS analysis. Applied
Thermal Engineering, 103, 1156-1163.

https://journals.e-palli.com/home/index.php/ajcp
