Climate change and some of  its impacts (irregular rainfall and flooding) negatively affect
hydraulic structures, especially in regions at risk of  extreme weather conditions. Thus, it
is critical to incorporate robust weather data in the design of  hydraulic structures such as
bridges. Therefore, this study evaluated extreme rainfall events and their implications for
hydrologic and hydraulic modeling at a proposed bridge site in Kano, Nigeria. Analysis of
2001–2019 rainfall data revealed annual maximum rainfall ranging from 44.43 mm to 114.89
mm, with a mean of  82.67 mm and a standard deviation of  19.22 mm, exhibiting a positively
skewed distribution. Frequency analysis using Hazen plotting positions estimated the
largest observed storm (114.90 mm) to have a 19-year return period, with projected rainfall
intensities reaching 135.45 mm, 174.83 mm and 212.67 mm for 50, 100 and 500-year return
periods, respectively. Goodness-of-fit (GOF) tests identified the log-normal distribution
as the best fit for estimating design storms. Intensity-Duration-Frequency (IDF) analysis
disaggregated 24-hour rainfall into durations as short as 10 minutes, yielding peak intensities
of  67.89 mm/hr for 2-year events and 221.34 mm/hr for 1000-year events. Hydrologic
modeling incorporating catchment characteristics such as curve numbers, slopes, and basin
areas simulated peak discharges of  78.34 m³/s, 142.67 m³/s and 186.45 m³/s for 2-year,
50-year and 100-year events, respectively at the proposed bridge location. The findings
underscore the importance of  robust rainfall modeling and hydrologic analysis in designing
flood-resilient infrastructure, especially in regions susceptible to extreme weather events.

Keywords
Bridge Design,  Climate Change,
Hydrologic Modeling, Rainfall

1 Department of  Civil Engineering, University of  Ibadan, Nigeria
2  Department of  Civil and Environmental Engineering, Bells University of  Technology, Ota, Nigeria
3  Department of  Mechanical Engineering, Bells University of  Technology, Ota, Nigeria
* Corresponding author’s e-mail: aiyelokuntobi@gmail.com

INTRODUCTION
The scientific study of  the ongoing movement,
control, and distribution of  water on Earth is known as
engineering hydrology. The design, building, and upkeep
of  engineering structures (open or closed channels)
necessary for properly distributing treating, retaining and
transporting water or other fluids is known as hydraulics
engineering (Nwaogozie & Ekwueme, 2017). When it
rains, the nearby trees’ stems and leaves typically catch
the first drops of  water that fall. This phenomenon is
frequently referred to as interception storage. But as the
downpour persists, the water that reaches the land starts
to seep into the soil, until the rainfall volume surpasses
the soil’s ability to absorb it (Akpan & Okoro, 2013). As a
result, ditches, surface puddles, and other existing surface
depressions are filled (depression storage), eventually
resulting in surface runoff  (Oladejo, 2014).
Sule & Ige (2016) claimed that the structure and the
soil moisture content (dependent on the previous dry
or rainfall season) greatly determine the infiltration
capacity of  the soil. Moreover, a dry soil has a large
initial infiltration capacity, but as the rainfall keeps on, the
capacity reduces continuously until it achieves the final
infiltration rate. Therefore, surface runoff  generation
will keep on if  the rainfall intensity surpasses the soil’s
infiltration capacity and will similarly end right away
the rainfall intensity falls below the infiltration rate.
Studies have verified that surface runoff  generation

could become a major environmental issue particularly
in communities where drainages, culverts, bridges and
other water holding structures which should channel
the runoff  generated into surface water bodies have not
been sufficiently provided (Obot et al., 2010; Antigha &
Ogarekpe, 2013).
According to Oladejo & Olanipekun (2018) asserted that
the pools of  water created become breeding grounds
for disease vectors when ditches and surface puddles are
filled up following rainfall without a sufficient channel
through which the water will be transported, so putting
the residents of  such communities effectively at risk of
waterborne diseases. Furthermore, such pools of  water
begin to create bad odour as a result of  facultative bacteria
feeding on the water’s limited dissolved oxygen, thereby
decreasing the community’s standard of  life (Olanipekun
& Idusuyi, 2023). Studies have revealed that these
conditions are the result of  inadequate environmental and
settlement planning, which is widespread impoverished
and developing countries such as Nigeria. Residents of
such communities endure multiple cases of  waterborne
infections each year, compared with developed countries
with superior environmental planning practices norms
(Fadipe et al., 2020; World Health Organization, 2022).
Thus third-world countries must address this
environmental anomaly by investing enough resources in
the design, construction, and maintenance of  hydrological
and hydraulic structures for water channelization.



Pa
ge


74

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

However, according to Ahmed et al. (2021), the design
of  hydraulic structures such as drainages, culverts, and
bridges necessitates a complete study of  available rainfall
data using a valid statistical method, which highly trained
technical professionals, carry out. This entails using
appropriate stochastic methods to determine rainfall
intensity (or depth), which is an important consideration
when designing hydraulic structures. Hydrologic
assessments give information on flood magnitudes and
frequency, allowing for safe and cost-effective hydraulic
structure design. An efficient and successful method for
estimating design flood is flood frequency analysis (Rasel
& Islam, 2015).
The method allows the user to estimate the probability
that a certain hydrological event will occur by fitting
a theoretical probability distribution to one that is
empirically obtained from recorded data.
Furthermore, also mentioned by Adewale & Isaac
(2017) are intensity-frequency (IDF) curves that define
the relationship between rainfall intensity, duration, and
return period or its inverse, likelihood of  exceedance.
Consequently, the design of  hydrologic, hydraulic, and
water resource systems makes regular use of  IDF curves,
often produced from frequency analysis of  rainfall
observations. Given this, this work calculated different
design storm estimates and the associated discharges
for five bridge crossings in Kano State of  Nigeria. This
was considered for varied durations and return periods
using the best available probability distribution model and
design flood estimation process.
The study developed IDF curves and design peak
discharge at 100-year return periods to simplify the
hydraulic analysis of  the proposed bridge crossing.
This was accomplished through the study’s objectives,
which included designating catchment regions for bridge
crossings and outlets, developing the IDF core of  the
project area, and computing the 100-year design flood for
the planned bridges in Kano State, Nigeria.

MATERIALS AND METHODS
Study Area and Hydrologic Modeling
This study was conducted in Kano, a city in Nigeria’s
northwest. According to Isah et al. (2020), the city resides
in the latitude 12°00’00.00”N and longitude 8º51’40.00”E.
It is also found between latitude 10°30’N and 13°N and
longitude 7°40’E and 10°35’E. Kano is adjacent to the
Sahara Desert, giving it dry and hot weather. However, the
city sees both the dry and rainy seasons every year. The
dry season lasts from October to April, while the rainy
season lasts from May to September. Like other Northern
cities, Kano has experienced severe flooding in the past,
and it is considerably more vulnerable now due to climate
change and the lack of  flood-resistant construction in the
majority of  the city’s hydraulic systems. The city contains
scrub vegetation in the north and woodland savanna in the
south. The Kano-Chalawa-Hadejia river system provides
drainage for Kano. As a result, the following methods
were used for hydrological and hydraulic simulation using

design peak flood computation for bridge design in Kano
State, Nigeria: extreme rainfall computation, probability
distribution, goodness 25 of  fit statistics and criteria,
IDF curve generation, and hydrologic simulations. The
hydrologic modeling and simulation of  peak floods
projected for the planned bridge crossings were also
carried out using the United States Army Corps of
Engineers, Hydrologic Engineering Centre - Hydrologic
Modeling System (HEC-HMS) version 4.11.

Extreme Rainfall Computation
Using the Integrated Multi-Satellite Retrievals for GPM
(IMERG), (https://gpm.nasa.gov/data/imerg), the
World Weather for Water Data Service (W3S) produced
19 years of  daily rainfall data from 2001 to 2019. The
gathered data were used to create a set of  one-day
severe showers. Moreover, concise information about
the produced series was given via statistical summaries
comprising mean, standard deviation, skewness, and
kurtosis. Hazen’s plotting position computed the
probability that the ranked maxima would be reached
or exceeded for any return interval; the produced 1-day
extremes were arranged in decreasing order of  magnitude
and shown in equation 1:
Tr=(m-0.5)/n              ....(1)
Where;
Tr is the return period,  m is the order or rank and n is the
number of  years of  study

Probability Distributions
Five probability distributions; Weibull, Gamma, Gumbel,
Log-normal, and Normal—were chosen based on first
analysis of  the 1-day extreme rainfall data. The probability
density functions (PDF) of  Weibull, Gamma, Gumbel,
Log-normal, and Normal distributions respectively are
represented by equations 2, 3, 4, 5, and 6.
ƒ(x; α, β) = (β/α) (α/x)β+1 e-(α/x)β), -∞ < x < ∞, α > 0
               ....(2)
ƒ(x, α, β)  = (1/(αβ Гβ)) xβ-1 e-(x/α) ), x, α, β > 0         ....(3)
f(x; α, β) = (e-(x-β)/α) e-e(-(x-β)/α)))/α, -∞<x<∞,α>0   ....(4)

      ....(5)

       ....(6)

Where;
the mean and standard deviation of  the series of  the
annual extreme rainfall are represented by µy and σy,
the scale and location parameters are shown by α and β
respectively; the mean and standard deviation of  the log-
transformed series of  annual extreme rainfall is shown by
µy and σy. Furthermore, the distribution parameters were
estimated in this work using the Maximum Likelihood
Method (MOM). Hassan et al. (2019) provided a
description of  the equations and theoretical vocabulary
for parameter estimate employing MOM of  the selected
distributions.



Pa
ge


75

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

Goodness of  Fit Statistics and Criteria
Along with GOF criteria, Akaike Information Criteria
(AIC) and Bayesian Information Criteria (BIC),
Kolmogorov-Smirnov (KS) test (Chowdhury et al., 1991),
and Cramer-von Mises (CM) test (Arnold and Emerson,
2011) were used to evaluate the fit of  the chosen
probability distributions.

Anderson-Darling (Ad) Test
More often used for outlier detection, the AD test
compares the cumulative distribution function of
empirical and probability distributions. Equation 7 gives
the AD test (A2);
A2 = - N - (1/N)∑N

i=1 (2i - 1)*(lnFe (Qi) + (ln(1-FD
(Qi))               ....(7)
Where;
The Anderson–Darling test statistic is A2; Fe is the
cumulative distribution function of  the designated
distribution; Qi is the ordered observed data.

Kolmogorov–Smirnov (Ks) Test
Equation 8 indicates the KS test, which is predicated on
the highest vertical deviation between the cumulative
distribution functions of  the empirical and theoretical
distributions.
KS = Max(F(Qi) - ((i-1)/N), (i/N) F(Qi))           ....(8)
Where;
F(Qi) is the theoretical cumulative distribution of
distribution being assessed.

Cramer-Von Mises (Cm) Test
Contrasting the first two GOF Statistics, the “CM test
considers an observed hydrological time series in an
increasing order” (Langat et al., 2019). This is represented
in equation 9 accordingly;
W2 = ∑N

i=1 (F(Qi) - (i - 0.5)/N)2 + 1/12N           ....(9)

Akaike Information Criterion
Regarding the established GOF criteria, the Akaike
information criterion is extensively utilized for the
selection of  appropriate stochastic models, as delineated
in equation 10;
AIC = n(logσ2 + 1) + 2p          ....(10)
Where;
σ2 and p presents the variance and the parameter count
of  the subset stochastic model. AIC generally gives
preference to models that minimize equation 10.

Bayesian Information Criterion (BIC)
BIC is intricately connected to AIC, as it is largely derived
from the likelihood function and is expressed by equation
11 appropriately.
-2 ∙ ln p(x | k) ≈ BIC = -2 ∙ ln L + k ln(n)        ....(11)
Where;
L represents the maximum value of  the likelihood
function, p(x | k) denotes the probability or likelihood of
parameters given the dataset, n signifies the sample size, k
indicates the number of  free parameters to be estimated,
and x refers to the observed data.

The extremely efficient AD test was used for final
selection when various goodness-of-fit statistics or
criteria supporting multiple distributions were considered
(Laio, 2004). The probability distribution with the lowest
Anderson-Darling statistic and a cumulative distribution
function closely resembling the actual distribution
was selected. The adequacy of  the distributions was
additionally validated by a graphical or qualitative
assessment method utilizing CDF plots.

Generation of  IDF Curve
Rainfall intensity is the total amount of  rainfall per time
(rainfall depth). Usually, it is expressed in millimeters per
hour, or inches per hour. Following the most suitable
probability distribution for modelling the annual peak
flood using the previous approaches, the disaggregated
rainfall depth for lower rainfall durations longer than 24
hours was calculated using the empirical reduction formula
supplied by the Indian Meteorological Department
(IMD), as reported by Laboya & Nwachukwu (2022);
pt = P24 (t/24)(1/3)          ....(12)
Where;
P24 is the daily rainfall depth (mm); Pt is the required
rainfall depth; t is the length of  rainfall for which the
rainfall depth is needed in (hr). Rainfall was calculated
for eight periods: five minutes, fifteen minutes, thirty
minutes, sixty minutes, one hundred and twenty minutes,
one hundred and eighty minutes, three hundred and sixty
minutes, seven hundred and twenty minutes, and one
thousand four hundred and forty minutes. Subsequently,
rainfall intensities were calculated for the calculated
rainfall depths at specified periods using equation 13 as
shown:
I = R/T            ....(13)
Where;
The rainfall intensity (mm/hr), R; is the total rainfall
(mm); T; is the rainfall duration (hr).

Hydrologic Simulations
The procedures adopted for the hydrologic design
calculations are presented accordingly;

Hydrologic design
The hydrological study aims to project the highest
discharges that would pass across the bridge crossings.
The study also took into account hydrology-related
subjects including IDF development and other factors
influencing the rainfall-runoff  correlation.

Catchment basins delineation
The physiographical features of  the upstream catchments
were ascertained using the available satellite photos and
elevation data in order to get all information concerning
areas, elevations, slopes, and morphometric parameters,
including information on main water course. Thereafter,
it was clear where the catchment area of  the watercourses
boarding or crossing the proposed bridge locations
rested. Moreover, the ArcMap GIS environment was
used for the delineation of  catchment areas; the five



Pa
ge


76

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

catchments’ boundaries were generated by using the
HEC-geoHMS program feature of  ArcMap GIS.
Developing the catchment models started with defining
the watershed limits and stream network of  the area of
interest. Usually referred to as terrain preprocessing, this
method depends just on the input (Digital Elevation
Model) DEM. Terrain preprocessing was done using a
12.5-metre pixel size developed by the Alaska Satellite
Facility (ASF), a component of  the University of  Alaska
Fairbanks (Alaska Satellite Facility, 2015), Advanced Land
Observing Satellite/Phased Array type L-band Synthetic
Aperture Radar (ALOS/PALSAR) DEM.
The following GRID files were derived from the DEM
by following the step by step functionality of  HEC-
geoHMS.
• Fill Sinks GRID: Empty sinks Based on the input

DEM, GRID generates a hydrologic-ally corrected
DEM which are either depression-less or otherwise. The
program also automatically raises any pit cell’s elevation
value to match the level of  the surrounding terrain
• Flow Direction GRID: This GRID came from the Fill

Sinks GRID. Every grid cell in the grid processing defines
the direction of  the sharpest fall to a neighboring cell
• Flow Accumulation GRID: Drawn from the flow

direction GRID, this GRID specifies the number of
upstream cells emptying into any specific grid cell
• Stream Definition GRID: This stage specified the

stream network’s constituent cells depending on a
threshold count of  cells that drain into a particular cell.
The criteria for the definition of  streams in this study
was one percent of  Ogun River Basin’s overall area. The
outcome was a GRID in which lines of  connected grid

cells all satisfy the threshold requirements, therefore
representing the stream network
• Stream Segmentation GRID: Splitting the streams

as stated in the stream definition GRID at any junction
produces this GRID.
• Catchment Grid: Every stream segment identified

by the stream segmentation GRID corresponds to a
demarcated watershed kept in a GRID file
Three vector layers were produced depending on the
results of  these computational phases to finish the terrain
preparation of  the basin, comprising;
• Catchment Polygons: This utility defines the limits of

every sub-basin using the catchment GRID as a vector
layer.
• Drainage Line: This converts the defined stream

segments based on the stream segmentation GRID into a
vector stream layer.
• Adjoint Catchment: Here the upstream sub-basins

are gathered at any stream confluence. Although it is
not hydrologic-ally relevant, this stage improves the
computational efficiency in the subsequent ones.

HEC-HMS methods and parameters
Using many computation methods, each with linked
input parameters, the HEC-HMS model characterizes
the hydrologic response process of  a basin. Graphical
representation of  the HEC-HMS processes, methods,
and associated parameters implemented for the research
area are shown in Figure 1. This study however ignored
base flow, canopy storage, surface depression storage and
channel loss.

Figure 1: Summary of  Processes, Methods, and Associated Data Requirements for HEC-HMS

Design storm
Conventional historical daily precipitation data for the
project site was lacking, hence satellite-based data was
chosen as described under extreme rainfall computation.

Thus, the modeling of  floods in HEC-HMS took
advantage of  the precipitation input in form of  design
storms produced from the created IDF curves. The
frequency of  a storm occurrence is the number of  times



Pa
ge


77

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

it passes during a given length of  time. The frequency
of  storm events determines the probability of  flooding
and  a low danger corresponds to a low frequency. Design
frequency depends on the hydraulic system installation
and the areas of  catchment that need to be drained. Table
1 includes the recommended design storm frequency
for the several hydraulic system components; since the
hydrologic assessment was done for bridges, the study
therefore used the design return period of  one hundred
years.

Table 1: Design Return Period
Type of  System Design Return

Period
Tertiary Drainage network and
secondary drainage system

5 years

Primary drainage system 10 years
Box Culverts 25 years
River, Bridges and Detention Ponds 100 years

Definition of  precipitation loss in a sub-basin
The precipitation loss process aims to ascertain the
proportion of  precipitation that passes through the
earth and the proportion that turns into runoff, thereby
influencing river flow. This study made use of  the Soil
Conservation Service (SCS) Curve Number approach.
The approach was chosen mostly because the necessary
characteristics for un-gauged watersheds are readily
available. Developed by the Soil Conservation Service,
the approach finds precipitation surplus (US Army Corps
of  Engineers, 2010) by combining soil cover, land use,
and antecedent soil moisture. Three input values; Curve
Number, Initial Abstraction, and Percentage Imperative
are needed by the technique. Considered as a function
of  land use and soil type, the main parameter of  the SCS
Curve Number Method is the Curve Number (𝐶𝑁). The
maximum precipitation the earth absorbs before runoff
starts is defined by initial abstraction (𝐼𝑎). Calculated as
a fraction of  the possible maximum retention (S), the
initial abstraction is a function of  the CN and represents
the maximum total precipitation the ground can absorb.
Equations 14 and 15 thus indicate the correlations
between curve number, possible maximum retention, and
initial abstraction in SI units;

Definition of  overland flow in a sub-basin
Termed the Transform Method in HEC-HMS, the
overland flow process illustrates how the volume of
excess precipitation is changed to runoff  at a given
location. This work applied the SCS Unit Hydrograph
method. This well-established empirical approach is
grounded, based on previous studies conducted in
agricultural watersheds in the United States of  America

by Bedient et al. (2008) and Kalyanapu et al. (2009). These
studies led to a relationship between the lag time and area
of  every sub-basin and the magnitude and timing of  the
peak hydrograph generated. HEC-GeoHMS computes
each sub-basin’s area. The lag time is the delay between
the centroid of  surplus precipitation and the peak of  the
produced hydrograph. Lag time can be obtained through
numerous methods; but the two widely used approaches
are the Snyder Method and the SCS Unit Hydrograph
Method. Therefore, this study was carried out by
applying the SCS Unit Hydrograph Method, expressed
mathematically in equation 16;

       ....(16)

Where;
tLag = Basin Lag Time (hrs)
l = length from sub-basin outlet to divide along longest
drainage path (ft)
y = Sub-basin slope (%)
S = 1000/CN -10 (in)
CN = Average curve number for sub-basin

Reach routing
Each real river and its tributaries were represented by
a “reach” in the model. The reach routing procedure
translates a hydrograph at the sub-basin’s upstream
border to a consequent hydrograph at the sub-basin’s
downstream boundary for each reach, accounting for
gains and losses (energy and mass) as the river moves
through that sub-basin. The form of  a hydrograph inside
a reach changes as it flows downstream, depending on
the river channel geometry and the roughness of  the
surface. These characteristics influence the degree of
energy loss, whereas a large channel and smooth surface
result in little energy loss. However, a restricted channel
with a rough surface might result in considerable energy
loss. Furthermore, a steep slope accelerates flow whereas
a moderate slope decelerates it. Due to time restrictions,
the Muskingum-Cunge parameters were determined
using the Lag technique after considerable fieldwork.
Equation 17 provides a mathematical description of  the
lag approach.

        ....(17)

Where;
Lag is time by which the inflow ordinate is to be lagged;
Ot is the outflow hydrographic ordinate at time t; It is the
ordinate hydrography.

RESULTS AND DISCUSSIONS
Statistical Description of  Annual Maximum Rainfall
Table 2 summarizes the statistics of  the project site’s
annual maximum rainfall for the period spanning between
2001 and 2019. It can be inferred that maximum daily
rainfall ranged from 44.43 mm to 114.89 mm and the
positive skewness of  0.804.



Pa
ge


78

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

Table 2: Statistical Summary of  Maximum Daily Rainfall
Statistics Values (mm)
Minimum 44.430
Maximum 114.896
Median 67.711
Mean 70.073
Standard Deviation 18.351
Skewness 0.804
Kurtosis 3.605

Table 3: Frequency Analysis of  Maximum Daily Rainfall
(2001-2019)
Annual
Maximum
Rainfall

M Return
period

Pr. Non-
Exceedance

114.90 1 19.0 0.05
99.57 2 9.5 0.11
90.90 3 6.3 0.16
81.81 4 4.8 0.21
80.31 5 3.8 0.26
80.04 6 3.2 0.32
76.51 7 2.7 0.37
70.97 8 2.4 0.42
68.34 9 2.1 0.47
67.71 10 1.9 0.53
66.35 11 1.7 0.58
62.16 12 1.6 0.63
60.38 13 1.5 0.68
59.87 14 1.4 0.74
58.12 15 1.3 0.79
53.41 16 1.2 0.84
50.37 17 1.1 0.89
45.26 18 1.1 0.95
44.43 19 1.0 1.00

Frequency Analysis of  Maximum Daily Rainfall
Table 3 shows the return periods calculated from the
Hazen plotting point of  the peak rainfall of  the rated
years between 2001 and 2019. With a low likelihood of
being equaled or exceeded of  0.05, the highest storm
magnitude of  114.90 mm for the research period was
calculated to have a nineteen (19) year return period.
Figure 1 also shows that whilst the probability of
exceedance falls as reported in Table 3, the degree of
peak rainfall increases as their return period grows. This
suggests that although significant magnitudes of  rainfalls
are not regularly seen in the project region, such storms
carry great hazards when they strike. Furthermore, Figure
2 demonstrates that although the plotting position was
sufficient in fitting the lower left tail of  the empirical
rainfall distribution, it underperformed in fitting the far-
right tail of  the empirical distribution, which is highly
crucial in reduction of  flood risk. This confirms even
more the importance of  fitting the empirical distribution
into accepted probability distribution models.

Figure 2: Probability Plot of  Design storm against Return Period

Performance of  Probability Distribution Models
To evaluate the adequacy of  the five chosen probability
distributions, GOF figures based on the AD, KS, and CM
tests as well as GOF criteria like the AIC and BIC were
used. In order to predict the design storms for the project
area, the log-normal probability distribution with the
lowest value in terms of  the Anderson-Darling statistic

was used, as seen in Table 4. Figure 3 shows the design
storms plot for two years to a thousand years. The five
return periods of  interest—five, ten, twenty-five, fifty,
and one hundred years—are expected to be 83.69 mm,
93.33 mm, 103.25 mm, 113.02 mm, and 130.92 mm,
respectively.



Pa
ge


79

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

Table 4: Summary of  Goodness of  Fit Statistics and Criteria
Goodness-of-fit statistics Fw Fg Fgum Flgn Fnor
Kolmogorov-Smirnov statistic 0.121 0.086 0.072 0.069 0.118
Cramer-von Mises statistic 0.055 0.021 0.017 0.017 0.042
Anderson-Darling statistic 0.384 0.161 0.133 0.132 0.296
Goodness-of-fit criteria
Akaike's Information Criterion 168.518 165.644 165.115 165.223 167.461
Bayesian Information Criterion 170.407 167.533 167.004 167.112 169.350

Fw=Weibull, Fg=Gamma, Fgum=Gumbel, Flgn=Log-normal, Fnor=Normal

Table 5: Summary of  Disaggregated 24hr Rainfall for different durations (Minute) and Return Period
Frequency (Return Period)
Duration 5-year 10-year 25-year 50-year 100-year
5min 12.90 14.38 15.91 17.42 18.64
10min 18.56 20.70 22.89 25.06 26.81
15min 16.24 18.12 20.04 21.94 23.47
30min 23.33 26.01 28.78 31.50 33.71
60min 29.32 32.70 36.18 39.60 42.37
120min 36.86 41.11 45.47 49.78 53.26
180min 42.14 46.99 51.98 56.91 60.88
360min 52.96 59.07 65.34 71.53 76.53
720min 66.58 74.25 82.14 89.91 96.20
1440min 83.69 93.33 103.25 113.02 120.93

Table 6: Summary of  Disaggregated 24hr Rainfall for different durations (Hour) and Return Period
Duration (Hours) 5-year 10-year 25-year 50-year 100-year
0.083 154.77 172.61 190.95 209.02 223.64
0.17 222.70 248.36 274.75 300.76 321.79
0.25 64.98 72.46 80.16 87.75 93.89
0.5 46.65 52.03 57.56 63.01 67.41

Figure 3: Probability Plot of  Design storm against Return Period based on Log-Normal Distribution

Establishment of  Rainfall Intensity and IDF Curve
Table 5 shows the several lengths of  the 24-hour
maximum daily design storms broken out. IDF normally
clarifies the connection among rainfall intensity, rainfall
length, and return period, thus this was done. It was

important to break down the design storms into smaller
periods since most rainfall statistics in Nigeria are linked
to a cumulative period of  24 hours. Table 5 displays the
outcome of  disintegrated design storms; while Table 6
provides the related intensities.



Pa
ge


80

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

1 29.32 32.70 36.18 39.60 42.37
2 18.43 20.55 22.74 24.89 26.63
3 14.05 15.66 17.33 18.97 20.29
6 8.83 9.84 10.89 11.92 12.76
12 5.55 6.19 6.84 7.49 8.02
24 3.49 3.89 4.30 4.71 5.04

Figure 4 shows the existing IDF curve for the project
area. The established IDF estimates and curves could
be further applied in hydrologic and hydraulic modeling,

which are useful for drainage and bridge designs with the
aim of  reducing the risk of  floods in the project area.

Figure 4: IDF curves for the catchment system of  the proposed bridge in Kano.

Hydrologic Modeling and Simulations
Table 7 summarizes the watershed parameters used in
the hydrologic simulation, and Figure 5 represents the
CN distribution for the basin. Furthermore, Figure 6
represents the HMS model structures for the project

region; Figure 7 depicts the hydrograph of  the 100-year
flood at the proposed bridge; and Table 7 summarizes the
peak design flood at the proposed bridges, which serves
as the hydraulic parameter for the bridge designs.

Table 7: Summary of  Catchment Parameters
Basin Name Length of  the

longest flow
path (meters)

Drainage Slope
(%)

Basin CN Basin Lag
(Hours)

Basin Slope (%) Basin Area
(Sq Km)

W200 10028.00 0.007 71.46 2.97 0.039 13.84
W210 17560.86 0.005 69.06 2.39 0.029 5.16
W220 11388.14 0.011 69.51 1.68 0.043 3.51
W230 11313.50 0.011 70.15 1.90 0.042 3.92
W240 10207.44 0.010 71.18 1.36 0.035 3.07
W250 16744.96 0.005 69.57 2.09 0.028 3.29
W260 7896.26 0.011 68.85 0.85 0.034 0.94
W270 8586.94 0.012 71.42 1.65 0.038 2.32
W280 13813.66 0.004 70.76 3.54 0.032 21.56
W290 4738.48 0.010 81.40 0.30 0.021 0.02
W300 12278.30 0.006 71.45 3.11 0.032 10.67
W310 6098.62 0.010 71.90 1.66 0.040 4.38
W320 5987.53 0.008 71.42 1.69 0.038 2.67
W330 2042.46 0.008 78.09 0.35 0.028 0.03
W340 2929.23 0.009 73.96 0.93 0.034 0.61
W350 3427.75 0.008 70.27 1.21 0.035 1.55



Pa
ge


81

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

W360 3944.18 0.007 70.70 1.83 0.031 2.22
W370 6843.01 0.008 69.37 1.90 0.034 2.70
W380 6988.57 0.008 67.24 2.16 0.031 3.22

Figure 5: Curve Number (CN) for the Catchment Areas of  the Proposed Bridge

Figure 6: Hydrologic Model of  Flood Discharged at the Proposed Bridge



Pa
ge


82

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

Figure 7: Hydrologic Model of  Flood Discharged at the Proposed Bridge

CONCLUSION
Along with the appropriate IDF curves for the same
return duration, this study produced rainfall depths for
several return periods: five years, ten years, twenty five
years, fifty years and one hundred years. The simulation
of  the peak flow of  every catchment with an outlet
suggested bridge location was driven by the known IDF
estimations, catchment characteristics, and CN. Based
on the gathered data, this study finds that the design
floods are relevant for the construction of  bridges in
Kano  State, Nigeria. Furthermore, the results obtained
fit the numbers reported by Ahmed et al. (2021) in an
earlier study conducted to determine the rainfall intensity,
rainfall duration, and return period in Abuja, Nigeria,
utilizing a dataset spanning 35 years.

REFERENCES
Adewale, F., & Isaac, A., (2017). Intensity, duration and

frequency of  rainstorms in Lokoja. Science World
Journal, 12(2), 36-40.

Ahmed, M. A., Olowosulu, A. T., Adeogun, B. K.,
Murana, A. A., Ahmed, H. A., & Sanni, I. M. (2021).
Development of  rainfall intensity-duration-frequency
(IDF) curve for Abuja,  Nigeria. Nigerian Journal of
Technology, 40(1), 154 -160.

Akpan, S., & Okoro, B. (2013). Development of  intensity-
duration frequency models for Calabar city, south-
south Nigeria. American Journal of  Engineering Research,
2(6), 19-24.

Alaska Satellite Facility. (2015). ASF Radiometrically
Terrain CorrectedALOS PALSAR products, Product
Guide, Revision 1.2, https://asf.alaska.edu

Antigha, R., & Ogarekpe, N. (2013). Development of
intensity-duration frequency curves for Calabar
metropolis, south-south Nigeria. International Journal
of  Engineering and Sciences, 2(3), 39-42.

Arnold, T. B., & Emerson, J. W. (2011). Nonparametric
goodness-of-fit tests for discrete null  distributions.
The R Journal. https://journal.r-project.org

Bedient, P. B., Huber, W. C., & Vieux, B. E. (2008).
Hydrology and floodplain analysis. Prentice-Hall, New
Jersey.

Chowdhury, J. U., Stedinger, J. R., & Lu, L. H. (1991).
Goodness-of-fit tests for regional generalized  extreme value
flood distributions. Water Resources Research. https://
ui.adsabs.harvard.edu

Fadipe, O. O., Adeosun, J. O., Adeyanju, K. O., &
Oguntola, M. O. (2020). Characteristics of  packaged
water under different storage conditions within
Osogbo metropolis. Uniosun Journal of  Engineering and
Environmental Sciences, 2(2), 87-97.

Hassan, A. S., Elgarhy, M., Mohamd, R. E., & Alrajhi,
S. (2019). On the alpha power transformed power
lindley distribution. Journal of  Probability and Statistics,
3(5), 45-61.

Ilaboya, I. R., & Nwachukwu, S. N. (2022). Development
of  intensity duration frequency (IDF) curves
for rainfall prediction in some selected states in
south-west Nigeria. Journal of  Energy, Technology and
Environment, 4(2), 69-82.

Isah, H. M., Sawyerr, H. O., Raimi, M. O., Bashir, B.
G., Haladu, S., & Odipe, O. E. (2020). Assessment
of  commonly used pesticides and frequency of  self-
reported symptoms on  farmers’ health in Kura,
Kano State, Nigeria. Journal of  Education and Learning
Management, 1(1), 31-54.

Kalyanapu, A. J., Burian, S. J., & McPherson, T. N. (2009).
Effect of  land use-based surface roughness on
hydrologic model output. Journal of  Spatial Hydrology,
4(9), 51-71.

Laio, F., (2004). Cramer-von Mises and Anderson-Darling
goodness of  fit tests for extreme value distributions



Pa
ge


83

https://journals.e-palli.com/home/index.php/ajec

Am. J. Environ. Clim. 4(2) 73-83, 2025

with unknown parameters. Water Resources Research,
40(9), 24-40.

Langat, P. K., Kumar, L., & Koech, R. (2019). Identification
of  the most suitable probability distribution models
for maximum, minimum and mean stream flow.
Water, 11(4), 734–756.

National Aeronautics and Space Administration. (2018).
Global precipitation measurement integrated multi-satellite
retrievals for gpm (IMERG). https://gpm.nasa.gov/
data/imerg

Nwaogozie, I. L., & Okonkwo, S. C. (2017).
Rainfall-intensity-duration-frequency modeling
and  comparative analysis of  developed models for
Abakaliki, Ebonyi State, Nigeria.  International Journal
of  Trends in Research and Development, 4(2), 45-53.

Nwaogozie, I., & Ekwueme, M. C. (2017). Rainfall
intensity-duration (IDF) models for Uyo city, Nigeria.
International Journal of  Hydrology, 1(3), 63-66.

Obot, N. I., Chendo, M., Udo, S., & Ewona, I. (2010).
Evaluation of  rainfall trends in Nigeria for 30 years
(1978-2007). International Journal of  the Physical Sciences,
5(14), 2217-2222.

Oladejo, O. S. (2014). Fundamentals of  environmental
engineering, handbook of  environmental engineering,
Ogbomoso, Oyo State. Olanrewaju Publishers.

Oladejo, O. S., & Olanipekun, A. A. (2018). Phyto-

remediation of  municipal run-off  using typha
orientalis and sorghum arundinaceum in sub-surface
constructed wetland system. International Research
Journal of  Advanced Engineering and Science, 3(1), 211–
215.

Olanipekun, A. A., & Idusuyi, D. U. (2023). Design
and construction of  bio-sand filtration system for
treatment of  influent obtained from a well and
stream. International Journal of  Scientific and Engineering
Research, 14(3), 1–15.

Rasel, M. M., & Islam, M. (2015). Generation of  rainfall-
intensity duration frequency relationship for north-
western region in Bangladesh. IOSR Journal of
Environmental  Science, Toxicology and Food Technology,
9(9), 41-47.

Sule, B. F., & Ige, K. (2016). Synthesis of  isopluvial maps
for Nigeria using IDF equations  derived from daily
rainfall data. Journal of  Scientific and Engineering Research,
3(3),  505-514.

U.S Army Corps of  Engineers (2010). Engineer research
and development center. Wetlands  Regulatory Assistance
Programme.  https://www.nap.usace.army.mil

World Health Organization. (WHO) (2022). Guidelines for
drinking-water quality, health criteria and other supporting
information. https://iris.who.int.
