American Journal of  Environmental
Economics (AJEE)

Barriers to Adoption of  Energy-Efficient HVAC Systems in Middle-Class Households in
Pakistan

Muhammad Awais Javed1*, Usman Latif2, Muhammad Sajjad3

Volume 4 Issue 1, Year 2025
ISSN: 2833-7905 (Online)

DOI: https://doi.org/10.54536/ajee.v4i1.5433
https://journals.e-palli.com/home/index.php/ajee

Article Information ABSTRACT

Received: May 22, 2025

Accepted: June 30, 2025

Published: August 25, 2025

Buildings and additional structures utilize a significant helping of  the energy in the sphere.
HVAC systems are mostly responsible for building energy use in middle class households
in Pakistan. This study proposes a simulation-based optimization approach for efficiently
measuring HVAC systems choices in the early design stages to get the optimal configuration
in middle class households in Pakistan. This strategy is applied establishing HVAC systems
in middle class households in Pakistan. The ventilated Dunkel cycle performs better than the
other two designs for high COP systems in all three climate zones; nevertheless, ventilation
is the superior choice in middle class households in Pakistan. Systematic simulations can help
with the difficult process of  optimizing HVAC systems designs in middle class households
in Pakistan. This invention will assist HVAC systems design are selecting the optimal systems
configuration and design parameters during the early design phase by accounting for various
middle-class households in Pakistan.

Keywords

Energy Systems, HVAC System,
Middle Class Households’
Buildings, Pakistan,Ventilated
Dunkel Cycle

1 USchool of  Business, Los Angeles, International American University, Main Campus Los Angeles, 90010, CA, USA
2 Head of  Engineering Department, Bunny’s Limited Lahore Pakistan
3 Head of  Operations, AJRD Organization Lahore Pakistan
* Corresponding author’s e-mail: dr.mawaisjaved@gmail.com

INTRODUCTION
As global temperatures rise, Pakistan is experiencing
longer and more intense heat waves. Middle class
households increasingly rely on HVAC systems for
cooling, leading to higher electricity consumption,
frequent power shortages, and growing carbon emissions.
Although energy-efficient HVAC systems technologies—
such as inverter air conditioners, smart thermostats,
and solar-assisted cooling systems—are available,
their adoption remains limited among middle-class
households. Despite their potential for reducing energy
bills and environmental impact, energy-efficient HVAC
systems are not widely adopted in Pakistan’s middle-class
neighborhoods. Optimization of  traditional setups and
introduction of  efficient innovation of  HVAC systems
utilizing renewable energy resources is one approach
to the problem (McQuiston et al., 2000). Most of  the
expansion is taking place in developing nations that are
not members of  the OECD, particularly in Asia. Pakistan
and other developing nations accounted for 44% of  total
energy consumption in 2006–07. By 2030, home energy
use will have nearly doubled and accounted for the
lion’s share of  total energy consumption. However, by
2030, it could only account for 32% of  total final energy
in middle class households (Ellis & Mathews, 2002).
Growth in population, enhancement of  comfort demand,
global climate change, and time spent inside buildings
anticipated the growing trend of  energy consumption
in building industry. The middle-class household’s
residential energy demand is anticipated to expand at
an average pace of  1.1% per year from 2008 to 2035.
Similarly, the growth in commercial sector is predicted
to expand at an average rate of  1.5% each year from

2008 to 2035 (EIA, 2012). Therefore, due to increasing
energy needs, pricing, and environmental challenges,
the developed nations are focused on buildings sector
as the biggest opportunity for energy savings (BPIE,
2011). The buildings energy demands are the major
cause of  considerable rise in the power consumption
due to rising space heating, cooling, ventilation, and
refrigeration requirements in middle class households
in Pakistan (IEA, 2009). Energy usage in buildings is
closely associated with energy needs of  HVAC systems in
middle class households in Pakistan. HVAC is the greatest
energy end use both in the residential and non-residential
sector. The air-conditioning is responsible for 10% to
60% of  the overall building energy usage, depending on
the building type (Ellis & Mathews, 2002). In developed
countries, HVAC systems are the most energy consuming
devices, accounting for about 10–20% of  final energy
use (Perez-Lombard et al., 2008). The HVAC systems
configuration is a conceptual design of  HVAC systems
including the active components, airflow set-up, and the
control strategies with set points. Selection of  HVAC
systems configuration is typically decided in the early
stage of  the design process in middle class households
in Pakistan. The design phase of  heating, ventilation, and
air conditioning HVAC systems in a new building facility
presents the greatest opportunity for energy savings.
When compared to the cost of  upgrading an old building
with an efficient HVAC system, it is typically more cost-
effective to install energy-efficient heating, ventilation,
and air conditioning business equipment during the
construction of  a structure (Galitsky, 2007). This study
seeks to identify the economic, social, technical, and
informational barriers that prevent widespread uptake



Pa
ge


15

1

https://journals.e-palli.com/home/index.php/ajee

Am. J. Environ Econ. 4(1) 150-157, 2025

in middle class households in Pakistan. The study is
investigating the economic, cultural, and informational
factors which are used to prevent households from
switching to efficient cooling technologies in middle
class households in Pakistan. To identify key factors
influencing consumer choices in HVAC systems among
urban middle-income households. To analyze barrier to
adopt energy-efficient HVAC technologies in middle class
households in Pakistan. To assess awareness levels about
energy-efficient options and long-term cost savings. To
propose targeted policy and market-based interventions
that could boost adoption in middle class households in
Pakistan. This study addresses the intersection of  climate
adaptation, energy equity, and behavioural economics,
offering practical solutions to reduce energy consumption
and improve resilience to rising temperatures in middle
class households in Pakistan. In order to evaluate the
suggested strategy for the selection of  optimal HVAC
systems configuration through the use of  a real chilled
water systems, the goal is to establish an incremental
simulation-based optimization methodology for the
purpose of  designing a chilled water system. The study
provides the literature review to resolve the cost concerns,
trust in new tech, lack of  awareness, and installation
challenges in middle class households in Pakistan. The
results reveal that the clear insight into why middle-class
households hesitate to switch to efficient cooling systems.
Recommendations for policy makers, energy companies,
and NGOs to design targeted incentives in middle class
households in Pakistan.

LITERATURE REVIEW
Modelling techniques for HVAC components, modelling
approaches for HVAC control, and modelling approaches
for HVAC systems are the three categories that may be
used to classify the many modelling approaches for HVAC
in middle class households in Pakistan. In addition, the
methodologies for solving the HVAC systems simulation
model is categorized as simultaneous modular solution,
independent modular solution, and equation-based
solution employing manipulation (Trcka & Hensen,
2010). Within the realm of  HVAC modelling, there
were a number of  studies conducted at the component,
control, and systems levels in middle class households
in Pakistan. At the component level, models of  air- and
water-cooled chillers were constructed in TRNSYS in
order to analyze the performance of  these chillers using
a variety of  control techniques (Wang et al., 2004). In
a similar manner, simpler models of  cooling coil units
(Jin et al., 2007) and cooling towers (Wu et al., 2007)
were constructed for the purpose of  controlling and
optimizing HVAC systems in middle class households
in Pakistan. In another study, component models of  an
axial fan, air filter, and duct for a ventilation unit were
constructed in Simulink for the purpose of  analyzing
the performance of  the constant airflow management
scheme (Bertagnolio et al., 2008). At the systems level, a
combined building-HVAC systems model was provided.

This model included representations of  both the building
zone and the HVAC equipment. It was demonstrated
that the model might be useful for conducting energy
audits of  commercial buildings (Beccali, 2008). In order
to assess the efficacy of  desiccant and solar cooling
systems, a number of  desiccant wheel models were
created. To forecast the performance of  three distinct
kinds of  desiccant wheels made with various kinds of
solid desiccants, a psychrometric model for desiccant
wheels was created (Nia et al., 2006). Additionally, a
modelling and simulation method for desiccant wheels
was introduced in Simulink for a parametric analysis of
desiccant wheels. Simple correlations between the outlet
air conditions and physically quantifiable input variables
were developed using the modelling solutions (Haddad
et al., 2008). Another research showed simulation models
of  a hybrid HVAC systems that combined a desiccant
cooling systems with a traditional vapour compression
system. The hybrid systems’ ability to reduce power was
examined using the models in middle class households
in Pakistan (Zhang, 2005). Typically, each simulation’s
static variables are set systems design parameters. These
kinds of  issues include the design of  building envelopes,
HVAC systems and components, ducting and hydraulic
systems, and lighting in middle class households in
Pakistan (Zogou & Stamatelos, 2007). Over the past 10
years, a lot of  research has been done on optimization
approaches based on HVAC models. Transsystemsic was
used to optimize the thermal performance of  a ground
source heat pump systems in order to lower the energy
expenses associated with heating and cooling the building
in middle class households (Zogou & Stamatelos, 2007).
HVAC systems were also optimized and controlled in
real time using the created cooling coil unit and cooling
tower models (Bertagnolio et al., 2008). In a similar vein,
established component models were used to optimize the
entire HVAC systems globally (Lu et al., 2005). For the
best water-cooled chiller and cooling tower combination,
another optimization study was conducted in middle class
households. Condenser water flow rate, cooling tower
approach, and wet bulb design were identified as critical
characteristics for maximizing systems life cycle costs and
performance (Furlong & Morrison, 2005). Comparing
the packed direct expansion strategy to traditional
control measures, significant savings were expected (Huh
& Brandemuehl, 2008). A particle swarm optimization
technique was used to solve an integrated energy
optimization model of  an HVAC systems in middle class
households (Kusiak et al., 2010). An additional systems
optimization using a dynamic neural net study led to a
30% reduction in energy consumption in middle class
households HVAC systems (Kusiak & Xu, 2012).

MATERIALS AND METHODOLOGY
To address various characteristics in the initial design
phases and reduce energy requirements, model-based
systems evaluations are extensively employed, especially
in the construction industry in middle class households



Pa
ge


15

2

https://journals.e-palli.com/home/index.php/ajee

Am. J. Environ Econ. 4(1) 150-157, 2025

in Pakistan. Utilizing appropriate model-based simulation
and optimization tools facilitates the evaluation of  various
HVAC systems solutions in middle class households in
Pakistan.

Modelling and simulation of  HVAC systems designs
An automated simulation-based optimization method
is introduced in this study to automatically choose the
best HVAC systems configuration. The systems deliver
high-quality indoor conditions with minimal expense
and environmental effect when configured optimally
in middle class households in Pakistan. Modelica/
Dymola is used to develop the equation-based object-
oriented modelling and simulation technique, and
the combination of  Modelica/Dymola with GenOpt
guarantees the automated selection of  the best HVAC
systems. There are major and secondary components
in the HVAC systems model. A “component model”
in building systems simulation is a computer model of
a basic HVAC systems in middle class households in
Pakistan. Each component model in Modelica is visually
represented by an icon made up of  a collection of
distinct equations. Additionally, each component model
represents a real HVAC (cooling tower, boiler, chiller)
business device model with physical interface ports to
connection them to other component models. In order to
represent an entire HVAC system, different components
are coupled together via these interface ports in middle
class households in Pakistan. Various formations are
included in the overall HVAC systems model. The design
specifications, which specify the group of  parts and their
relationships, serve as the foundation for the model. The
generated model’s component models are all precisely
proportioned to satisfy the necessary building load
requirements. To mimic their performance in terms of
energy consumption, the model’s potential configurations
are then changed based on a predetermined criterion.

Inputs of  HVAC Systems Model
Design load and cooling/heating load profiles are
important for HVAC systems optimization and
assessment. The building’s load profile specifies the load’s
temporal fluctuation, whereas the design load details the
total installed systems capacity, which includes cooling
towers, chillers, pumps, and pipes. In addition, important
HVAC systems in particular need a load profile for
effective systems design and staging. All of  the design
decisions, such as the chillers’ unloading strategies, the
cooling towers’ and pumps’ use of  variable frequency
drives, and the equipment’s relative sizes, are part of  the
staging process. Climate, operating hours, base loads, and
other variables all have an impact on the building load
profile in middle class households in Pakistan. A number
of  factors, including external factors, the building’s
exterior, internal heat gains, and ventilation needs, go into
estimating peak load demands in middle class households
in Pakistan. The peak load needs are determined using
a variety of  methods, including calculations/simulations,

site measurements, and general guidelines in middle class
households in Pakistan.

Techniques for creating a model of  HVAC company
systems configurations
The primary goal of  this research is to develop a
method for automatically choosing the best HVAC
systems configuration during the design phase in middle
class households in Pakistan. Various HVAC systems
configurations will be evaluated as part of  the job.
Consequently, it is critical to create a physical model of
the systems that can mimic various HVAC systems in
middle class households in Pakistan. Furthermore, for
optimal performance at both the systems configuration
and design levels, the model should be able to change
the critical design parameters of  the component
models simultaneously. Two options for creating such a
systems model were identified following an exhaustive
examination of  Dymola/Modelica in middle class
households in Pakistan.

Initial Approach: Declaring component models
conditionally
Models of  individual subsystems make up the HVAC
systems as a whole. The many physical components of
an HVAC systems, like as pumps, chillers, boilers, and
cooling towers, are each represented by a separate model.
The development of  the overall model is accomplished by
carefully linking these sub-component models together
using connectors that extend from their individual
interface ports. The first approach uses conditional
declarations in the systems model to include sub-
component models. Both the building’s load needs and
the weather have a role in the conditional declaration in
middle class households in Pakistan. But, to avoid errors,
the model as a whole has to keep an even number of
equations and unknown variables throughout the process.
A Modelica function called “read-Real-Parameter” and
a package called “External Data” are used to apply the
approach in Dymola/Modelica. Importing the function
from the Modelica standard library into the overall HVAC
systems model is necessary for model development in
middle class households in Pakistan. Along with the name
of  the external file where these characters are created
and given suitable values, certain characters need to be
declared as parameters in the overall model. Such symbols
could represent HVAC systems design and configuration
characteristics. It is essential that the external file adheres
to the specified specifications for the component
model variation in terms of  configuration and design
parameters, with appropriate values supplied. The right
usage of  these configuration parameters with each sub-
component model using an if  statement followed by the
suitable logical condition is necessary for the conditional
declaration of  sub-component models.

Systems Sizing for HVAC Systems
Systems configuration and sizing are closely connected in



Pa
ge


15

3

https://journals.e-palli.com/home/index.php/ajee

Am. J. Environ Econ. 4(1) 150-157, 2025

HVAC systems in middle class households in Pakistan. The
HVAC systems model and its component models must be
correctly designed to meet building load needs in middle
class households in Pakistan. The current study’s HVAC
systems configuration optimization technique may change
systems configuration and design parameters. This paper
proposes two techniques to connect configuration and
size problems during HVAC systems model development.
Any component model in Modelica can have variable
component sizes by changing its design parameters. The
HVAC systems setup and sizing approach depends on
how component design characteristics may be modified.
The first technique is to create an HVAC systems model
that uses the same component model in different sizes for
a specific application. The ideal component size may be
established by simulating all component model sizes. If
a component model (CM) comes in three sizes, it will be
used three times in the systems model. For an application,
all three choices are simulated, and the CM with optimum
performance displays the ideal component size and is
selected. One CM can be employed in the systems model
in the second method. Creating a record of  all three
component sizes allows for implementation. To find the
best component size, the sizing choices can be connected
to the CM repeatedly throughout simulation.

Simulation of  HVAC Systems Model
The development of  an HVAC systems model involves
implementing a way to automatically modify systems
settings in middle class households in Pakistan. The
simulation technique involves model experiments to
anticipate its behaviour under actual settings. This study
uses Dymola/Modelica for HVAC systems modelling and
simulation. Dymola is powerful for charting, animation,
and experimentation. It has two modes: modelling
for systems model creation and simulation for model
experiments. Simulation mode includes setup, plot,
animation, and variable browser. The simulation setup has
three basic groups: simulation, output, and integration.

Refining the Setup of  Cooled Water Systems
The majority of  the energy consumed by HVAC systems
is produced by the chilled water systems, which comprise
the main components of  these systems, including
chillers, cooling towers, and pumps. The potential for
HVAC systems to save energy may be greatly increased
by optimizing chilled water during the early design stage.
But optimizing a chilled water systems isn’t a simple
feat, especially when it comes to optimizing the systems’
configuration or architecture. The method becomes more
intricate when both tiers are used together. Moreover,
the research details a strategy for optimizing chilled
water systems designs that has undergone incremental
evolution. Before optimizing the systems design in its
entirety, the best practice design criteria are confirmed
by first experimenting with the configuration parameters
of  the systems under fixed design conditions. In order
to determine the best configuration for the systems, the
simulation-based optimization method combines the
GenOpt generic optimization tool with the dynamic
modelling and simulation application Dymola/Modelica.
In order to test and replicate various chilled water systems
setups, a dynamic systems model is created. Using five
design factors, the chilled water systems may be optimized
at both the design and configuration levels. The layout
of  the systems is affected by two independent variables:
the quantity of  chillers and cooling towers. The demand
for building loads, the temperature differential across the
condenser, and the speed of  the cooling tower fan are
three other continuous factors that are relevant to the
design of  the systems.

Description of  the Chilled Water Systems
The systems are comprised of  three chillers of  identical
size, each with a cooling capacity of  2725 kW (775 tonnes),
as shown in Table 1. Five identically sized draw-through
cross-flow cooling tower cells, each with a capacity of
around 76 l/s (1200 gpm), make up the systems.

Table 1: Specifications of  the investigated chilled water systems
Compressor type Centrifugal
Nominal cooling capacity kW [tons] 2725 [775]
Nominal compressor power kW [tons] 446.4 [127]
Minimum cooling capacity kW [tons] 457 [130]
Design COP 6.1
Design chilled water supply/return temperature oC[oF] 6.7/12.2 [44/54]
Design chilled water flow rate l/s [gpm] 57 [900]
Design condenser water entering temperature oC[oF] 29.4 [85]
Design condenser water flow rate l/s [gpm] 111[1760]
Cooling towers:
Type Draw-through
Water flow rate l/s [gpm] 76 [1200]
Fan motor power kW [hp] 18.65 [25]
Design wet bulb temperature oC[oF] 17 [62.6]



Pa
ge


15

4

https://journals.e-palli.com/home/index.php/ajee

Am. J. Environ Econ. 4(1) 150-157, 2025

Design dry bulb temperature oC[oF] 26 [78.8]
Design approach temperatures oC[oF] 8.3[15]
Design range temperature oC[oF] 5.56 [10]
Pumps:
Rated power of  each chilled water pump kW [hp] 30 [40]
Rated power of  each condenser water pump kW [hp] 19 [25]
Design range temperature oC[oF] 5.56 [10]

In a headered configuration, three condenser water
pumps of  identical capacity are connected; each pump
may service one of  the chillers or tower cells, and their
combined flow rate is 111 l/s (1760 gpm). The motors
powering the pumps are 19 kW (25 hp). Also headered
are three chilled water pumps of  identical size, each with a
capacity of  57 l/s (900 gpm) and 30 kW (40hp). Standard
550/590-2003 of  the Air Conditioning and Refrigeration
Institute (ARI) and the test conditions established by
the Cooling Tower Institute (CTI) form the basis of  the
design conditions in middle class households in Pakistan.
The cooling tower model is based on the ASHRAE

standard 90.1-2004 climatic data for San Francisco, which
states that the design wet bulb temperature is 17oC [63oF]
and the dry bulb temperature is 26oC [78.8oF].

Constructing Systems Economically
Table 2 details the startup and installation costs of  water-
cooled centrifugal chillers and cooling towers, as well as
the cost of  piping, fittings, and valves. The computations
take into account an anticipated 25% contractor markup.
Costs associated with chillers, cooling towers, pipes,
labour, fittings, and valves needed for effective hydronic
design make up the initial cost for each setup.

Table 2: Summary of  initial costs
Description Cost/ton € [$] Total unit cost € [$]
Water-cooled centrifugal chiller (Nominal 775 tons each) 147 [180] 113925 [139500]
Chiller installation cost 37 [45] 28370 [34875]
Cooling Tower (Nominal 400 tons each) 106 [130] 42400 [52000]
Cooling tower installation cost 4.1 [5] 1640 [2000]
Piping/Fitting/Valve
a chilled water side --- 13015 [16000]
b condenser water side --- 19523 [24000]
c adding another chiller in the systems --- 4393 [5400]
d adding another cooling tower in the systems --- 2440 [3000]
Contractor Markup 25%
Estimated total baseline cost for 1 chiller and 1 cooling tower 273591[335469]
Estimated total cost for adding each chiller 183360 [224719]
Estimated total cost for adding each cooling tower 58100 [71250]

Nevertheless, the Pipe Size Optimization tool is used
to estimate the cost of  the chilled water system pipes,
fittings, and valves. Based on the flow rate for certain
piping segments, the tool determines the initial cost of
the pipe. Also included are the typical types and quantities
of  valves and fittings utilised in chilled water systems.
Additionally, we supply the prices of  various fittings and
valves according to the pipe size. Based on the reference
systems piping design, the quantity and kind of  valves
and fittings are determined in this investigation the
HVAC systems in middle class households in Pakistan.

Optimization Procedure
Total systems power consumption is the goal function in
the five-variable design process that optimizes the chilled
water systems as a whole. The quantity of  chillers (CH)

and cooling towers (CT) are two independent design
factors. Building load demand (Qload), temperature
differential across the condenser (ΔT), and cooling tower
fan speed (F) are three design factors that are constant.
The variables’ bounds are displayed in Table 3.
A direct search Hooke-Jeeves (HJ) method and a stochastic
population-based constriction coefficient algorithm
make up the hybrid global optimization algorithm. The
main benefit of  this algorithm is that, during the global
PSO search, the likelihood of  approaching the global
minimum is increased, as opposed to only reaching a local
minimum, and the search is then refined locally by the HJ
algorithm in middle class households in Pakistan. Table
4 summarizes the GPSPSOCCHJ algorithm parameters
that were used for the current investigation.



Pa
ge


15

5

https://journals.e-palli.com/home/index.php/ajee

Am. J. Environ Econ. 4(1) 150-157, 2025

Table 3: Design variables and boundaries
Tower Fan Speed, F
(%)

Temp. difference
condenser side,
ΔT (oC) [oF]

No. of  chiller, CH No. of  cooling
towers, CT

Building load
Qload

Minimum 0.3 (kW) [Tons] 1 3 1055 [300]
Maximum 1 15 [27] 3 18 7032 [2000]
Step 0.01 0.01 1 1
Initial 1 3 1 3

Table 5: Optimal values of  Ptotal and energy use of  all strategies (minimum values highlighted)
Qload (kW
[tons])

1st Strategy Ptotal
(kW) kW/ton

2nd Strategy
Ptotal (kW) kW/ton

3rd Strategy
Ptotal (kW) kW/ton

Percentage of
power saving (%)

7032 [2000] 2757.3 1.37 1808.4 0.9 1557.3 0.78 43.5
5274 [1500] 1498.8 0.99 1178.8 0.78 993.1 0.66 33.8
3516 [1000] 752.7 0.75 706.9 0.71 582.7 0.58 22.6
2461 [700] 479.7 0.68 479.7 0.68 394.9 0.56 17.6
1582 [450] 297.8 0.66 297.8 0.66 240.7 0.53 19.2
1055 [300] 207.4 0.69 207.4 0.69 171.6 0.57 17.3

Table 4: Optimization algorithm input parameters
Parameters Value
Neighborhood topology von-Neumann
Neighborhood size 5
Number of  particles 20
Number of  generations 5
Seed 1
Cognitive acceleration 2.8
Social acceleration 1.3
Max velocity gain continuous 0.5
Max velocity discrete 4
Constriction gain 0.5
Mesh size divider 2
Initial mesh size exponent 0
Mesh size exponent increment 1
Number of  step reductions 4

First, a baseline system with no more than five cooling
towers and a fixed design temperature difference across
the condenser at full fan speed; second, a modified
systems with an increased number of  cooling towers
according to the flow turndown limit; third, a modified
systems with varying systems design and configuration
parameters; and finally, a methodology is proposed for
design optimization of  the chilled water systems at the
initial design stage in middle class households HVAC
systems. A systematic method for optimizing chilled water
systems designs as a whole is defined by the third strategy,
whereas the previous two only validate the simulation
models and validate the best practices in the field. The
techniques take into account the upfront expenses of
equipment, such as cooling towers, pipes, fittings, and
valves. It is worth noting that adding more cooling towers
and chillers usually lowers the yearly energy costs and
payback period. According to Table 5, the best methods
for the whole systems in terms of  power consumption
and energy usage (in kW/ton) are shown.

The energy consumption figures (kW/ton) are in close
accordance with the usual figures for chilled water systems.
The improved systems with variable fan speed and
temperature differential across the condenser achieves the
lowest total power consumption and energy utilization.
Choosing the right mass flow rates and temperature
variations across the condenser is also crucial for chilled
water systems performance. To minimize overall systems
power consumption, the optimization method based
on simulations improves decision-making on the best
change of  these parameters. When running chilled water
systems at their optimal design and configuration settings,
significant power savings of  17% to 43.5% relative to
the baseline situation are possible. This research used an
EOO methodology based on open-source component

libraries to build a model of  a chilled water systems.
In order to optimize HVAC systems, it was necessary
to experiment with different configurations and design
characteristics of  individual components in middle class
households HVAC systems.

CONCLUSIONS
From 2009 to 2035, the global demand for energy is
expected to rise by over 50%, continuing a trend that
began a few decades ago in middle class households
in Pakistan. About 21% of  the world’s total energy
requirements are attributable to buildings, making their
contribution substantial to overall energy consumption
in middle class households in Pakistan. In middle class
households in Pakistan account for around 41% and



Pa
ge


15

6

https://journals.e-palli.com/home/index.php/ajee

Am. J. Environ Econ. 4(1) 150-157, 2025

40% of  overall energy use. In contrast, buildings account
up almost 44% in developing nations like Pakistan. The
HVAC systems that keep the intended comfort levels
are the primary contributors to the energy needs of
the building. Consequently, there is a lot of  room for
improvement in the building sector’s energy efficiency
through the optimization of  HVAC systems. A great
deal of  study is on improving HVAC systems. This study
optimizes HVAC systems in all their facets by conducting a
thorough literature evaluation in middle class households
in Pakistan. Based on what we can tell from the literature
survey, most research focusses on optimizing individual
components or operational controls at the systems level,
rather than systems configurations analysis. Additionally,
the best HVAC systems configuration could not be
determined using any kind of  systematic method in
middle class households in Pakistan. One of  the most
important things to consider during the first design phase
is the ideal configuration of  the HVAC systems, as this
has a major impact on the total energy needs of  the
building in middle class households in Pakistan. When
deciding on a systems design for an HVAC, it is important
to consider not only the HVAC systems’ economic and
environmental aspects, but also the systems type, the
kind and quantity of  components, and operational
control techniques. Various configurations for diverse
applications are being developed using components
of  the HVAC systems in middle class households in
Pakistan. Innovative and alternative systems designs
make use of  renewable energy resources, such as solar air
conditioning and desiccant cooling in a variety of  forms
in middle class households in Pakistan. The difficulty of
deciding on a suitable design for a given load demand in
a given environment was demonstrated by all of  these
setups. Assessment of  HVAC systems setup and design
choices in practice is reliant on the designer’s expertise
and experience in middle class households in Pakistan.
However, the knowledge and abilities of  a person or
team are sometimes constrained by the competence of
the systems that are created. Consequently, in order to get
the best possible automated selection of  HVAC systems
configuration, a method is created and tested that is based
on systematic optimization in middle class households
in Pakistan. The created method relies on Dymola/
Modelica, an environment for EOO modelling and
simulation that is built on equations. A number of  HVAC
systems’ physical component models make up the EOO
modelling and simulation in middle class households in
Pakistan.

Future Research Suggestions
Based on study and results, the following areas suggest
ways to improve the suggested technique. Dymola/
Modelica’s HAVC systems component models cannot
analyze all HVAC systems combinations in middle class
households in Pakistan. Additional contributions are
needed to improve the Modelica component library.
Thus, such models must be updated to estimate systems

performance in middle class households in Pakistan.
Second modelling requires additional study to upgrade
Modelica language to automatically modify component
model classes. Each component class change also affects
the parameter assigned values, requiring them to be
declared afresh in middle class households in Pakistan.

REFERENCES
Beccali, M., Butera, F., Guanella, R. A. R. S., & Adhikari,

R. S. (2003). Simplified models for the performance
evaluation of  desiccant wheel dehumidification.
International Journal of  Energy Research, 27(1), 17-29.

Bertagnolio, S., Masy, G., Lebrun, J., & André, P. (2008,
July). Building and HVAC System simulation with the
help of  an engineering equation solver. In SimBuild
Conference 2008 (Vol. 3, pp. 53-60). IBPSA-USA.

Buildings Performance Institute Europe (BPIE). (2011).
Europe ‘s buildings under the microscope, a country-by-country
review of  the energy performance of  buildings, 2011. Brussels.

Ellis, M. W., & Mathews, E. H. (2002). Needs and trends
in building and HVAC system design tools. Building
and environment, 37(5), 461-470.

Energy Information Administration (EIA). (2012).
International Energy Outlook 2011. Washington.

Furlong, J. W., & Morrison, F. T. (2005). Optimization of
water-cooled chiller-cooling tower combinations. CTI
journal, 26(2), 14.

Galitsky, C. (2007). Cut energy use through HVAC
improvements, California.

Haddad, K., Ouazia, B., & Barhoun, H. (2008, August).
Simulation of  a desiccant-evaporative cooling system
for residential buildings. In Proceedings of  the 3rd
Canadian Solar Building Conference (pp. 1-8).

Huh, J. H., & Brandemuehl, M. J. (2008). Optimization
of  air-conditioning system operating strategies for
hot and humid climates. Energy and Buildings, 40(7),
1202-1213.

Intentional Energy Agency (IEA). (2009). Electricity
information. Paris.

Jin, G. Y., Cai, W. J., Lu, L., Lee, E. L., & Chiang, A.
(2007). A simplified modeling of  mechanical cooling
tower for control and optimization of  HVAC systems.
Energy conversion and management, 48(2), 355-365.

Kusiak, A., & Xu, G. (2012). Modeling and optimization
of  HVAC systems using a dynamic neural network.
Energy, 42(1), 241-250.

Kusiak, A., Li, M., & Tang, F. (2010). Modeling and
optimization of  HVAC energy consumption. Applied
Energy, 87(10), 3092-3102.

Lu, L., Cai, W., Chai, Y. S., & Xie, L. (2005). Global
optimization for overall HVAC systems––Part I
problem formulation and analysis. Energy conversion
and management, 46(7-8), 999-1014.

McQuiston, F. C., Parker, J. D., Spitler, J. D., & Taherian,
H. (2000). Heating, ventilating, and air conditioning: analysis
and design. John Wiley & Sons.

Nia, F. E., Van Paassen, D., & Saidi, M. H. (2006).
Modeling and simulation of  desiccant wheel for air



Pa
ge


15

7

https://journals.e-palli.com/home/index.php/ajee

Am. J. Environ Econ. 4(1) 150-157, 2025

conditioning. Energy and buildings, 38(10), 1230-1239.
Pérez-Lombard, L., Ortiz, J., & Pout, C. (2008). A review

on buildings energy consumption information. Energy
and buildings, 40(3), 394-398.

Trčka, M., & Hensen, J. L. (2010). Overview of  HVAC
system simulation. Automation in construction, 19(2), 93-
99.

Wang, Y. W., Cai, W. J., Soh, Y. C., Li, S. J., Lu, L., & Xie,
L. (2004). A simplified modeling of  cooling coils for
control and optimization of  HVAC systems. Energy
Conversion and Management, 45(18-19), 2915-2930.

Wu, Z., Melnik, R. V., & Borup, F. (2007). Model-based
analysis and simulation of  airflow control systems of
ventilation units in building environments. Building
and environment, 42(1), 203-217.

Zhang, Y. (2005). Synthesis of  optimum HVAC system
configurations by evolutionary algorithm (Doctoral
dissertation, Loughborough University).

Zogou, O., & Stamatelos, A. (2007). Optimization of
thermal performance of  a building with ground
source heat pump system. Energy conversion and
management, 48(11), 2853-2863.
