Carbonate rocks have a significant economic value as water and hydrocarbon reservoirs and
are essential elements for concrete and buildings. This study selected a total of  36 carbonate
rock samples, which were tested in the lab for electrical resistivity at 80 Hz, primary and
secondary ultrasonic wave velocity, and attenuation. Therefore, to understand the role of  mi-
crocrystalline calcite (micrite) on the geophysical properties, this study has proposed a new
systematic method by using image analysis techniques to quantify micrite and microstruc-
tural parameters such as macro porosity, solid grains, microporous micrite (porosity within
micrite), and calcite crystals (sparry calcite). The study findings suggest that porosity and
permeability have U-shape trends as a function of  micrite content due to leaching processes.
Thus, higher micrite content causes the elastic wave velocities to increase, making the rock
stiffer. When a dual porosity effect is present, the attenuation exhibits two peaks, and is at its
highest with micrite content. With minimal values between 10% and 30% of  micrite content
due to maximal porosity, the apparent formation factor exhibits a U-shape trend with micrite
content; as a result, the electrolyte conductivity is high. We concluded that knowledge of
micrite content and macro-porosity is of  paramount importance to interpret and model the
geophysical parameters and to develop a rock physics model.

Keywords
Attenuation, Elastic Wave Velocity,
Electrical Resistivity, Micrite
Content, Reservoir Carbonate

1 Department of  Earth and Environmental Sciences, Faculty of  Science, Kuwait University, Kuwait, Safat 13060, Kuwait
2 National Oceanography Centre, University of  Southampton Waterfront Campus, European Way, Southampton, SO14 3ZH, UK
3 Ocean & Earth Science, University of  Southampton Waterfront Campus, European Way, Southampton, SO14 3ZH, UK
* Corresponding author’s e-mail: aladwaninajeeb@outlook.com

INTRODUCTION
Carbonate rocks are major underground reservoirs
of  hydrocarbons and water (Chilingar et al., 1967) as
well as the primary supply of  cement for concrete and
buildings (Grasby & Betcher, 2002; Hawkins et al., 1996).
Understanding the physical characteristics of  carbonates,
particularly the impact of  microstructures, is therefore
relevant to many different specialized domains, such
as rock physics, hydrology, geotechnical engineering,
and tectonics, and is critical for better characterizing
reservoir resources. Carbonate rocks have complicated
geochemical, textural, and petrophysical features (most
critically for reservoir rocks, porosity and permeability),
which derive from their geological genesis (by bi oclasts,
ooids, and so on) and subsequent diagenetic processes
that frequently alter their mineralogy and pore networks.
There is a growing body of  literature that recognises the
microstructural complexity of  carbonates and the factors
that control elastic wave velocities (both Primary, or P-
wave, and Secondary, or S- wave) and the fluid transport
properties, porosity and permeability. Recently, the
researcher’s interest has increased in the contribution of
microcrystalline calcite, i.e., micrite, to the microstructural
configuration of  carbonate rocks (Cantrell & Hagerty,
1999; Husseiny & Vanorio, 2015; Lambert et al., 2006),
and its effect on elastic wave properties (Fournier &
Borgomano, 2009; Husseiny & Vanorio, 2015; Vanorio
& Mavko, 2011). In reservoir sandstones, the scatter
often seen in the velocity-porosity relation is frequently
attributed to the amount of  clay content in the rock (Han,

1986; Kowallis et al., 1984; D. Marion, 1992); indeed,
volumetric clay content is a second order control on
velocity after porosity. Here, we explore the hypothesis
that microcrystalline calcite (micrite) in carbonate rocks
has a similar influence to clay in sandstones on elastic
wave velocity.
Micrite content can be dependent on the energy level of
the depositional environment and is used for petrographic
and textural classification of  carbonates (Dunham,
1962; Folk, 1959). The micrite is a result of  diagenesis,
which prompts the recrystallisation of  previous rock
constituents, calcite and aragonite mud, for instance as
stated by (Lambert et al., 2006). The particles gathered
with microcrystalline calcite usually have a size between 1
and 4 μm, similar to clay. As a result, they are probably to
blame for carbonates’ micro porosity (Cantrell & Hagerty,
1999; Vanorio & Mavko, 2011).
The advancement of  digital image analysis techniques
has revitalised the way that modern petrographic
analysis is performed (Hamilton, 2010; Michael Denis
Higgins, 2006). Textural measurements such as shape,
size, and sorting of  crystals or grains can be quickly
and accurately acquired on 2D rock images (Michael D
Higgins & Roberge, 2007; Dougal A Jerram et al., 2009),
removing ambiguity in classifications. Images are typically
obtained from petrographic thin sections as transmitted
light photographs or SEM backscatter images. Three-
dimensional (3D) rock textures of  natural rock samples
images can be captured and analysed through the
application of  serial sectioning and X-ray computed



Pa
ge


23

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

tomography scan analysis (D A Jerram & Higgins, 2007;
Dougal A Jerram et al., 2009).
ImageJ (Rasband, 1997) is a widely used image-processing
software that was developed by the National Institutes
of  Health (NIH) in the USA. Image analysis techniques
have major advantages over conventional methods (e.g.,
manual point counting and visual descriptions), such
as the potential to automate and increase the capacity
of  standard measurements with more speed, precision
and accuracy than traditional methods. For example,
the measuring of  rock porosity from thin sections
impregnated with blue epoxy resin is a common method
in geosciences and is usually conducted by point counting
(Grove & Jerram 2011). However, point counting of  thin
sections requires special equipment, is laborious and very
slow, and human error must be considered. By contrast,
digital image analysis is far superior as it measures
millions of  points in the sample with speed, precision and
accuracy; therefore, it presents far superior datasets (Ceia
et al., 2017; Haines et al., 2015; Hamilton, 2010).
The objectives of  this study were to (1) suggest and establish
a method that allows us to extract key sedimentology-
related parameters of  interest from carbonate reservoir
rock samples, such as the volumetric microcrystalline
calcite (micrite) content and macro porosity and (2)
to investigate the effect of  microcrystalline calcite

(micrite) on important reservoir petrophysical (porosity,
permeability) and geophysical ( elastic wave velocity and
attenuation, and electrical resistivity)  properties.
Although a thin section is a two dimensional slice through
a three-dimensional rock, it was shown by Chayes (1956)
that the relative areas of  the constituents of  the sample
are equivalent to their relative volumes (Marks, 1994).

Description of  Rocks
This study selected 36 carbonate rocks, comprising 24
carbonate samples dataset from (North et al., 2013) et al.
(2012). Eleven oolitic limestone samples were taken from
three core samples of  bio clastic oolitic limestone from
the Jurassic Purbeck formation of  southern England, and
thirteen dolomite samples were taken from a single core
sample of  a microbial-laminated dolo-mudstone from
the Rotweil formation of  the Southern German basin
(Laurence (North et al., 2013) et al., 2013).
A suite of  12 new limestone samples was chosen to
expand the dataset of  (North et al., 2013) et al. (2012).
Eleven samples were from wells in Hampshire’s Wealden
Basin in southern England, comprising two samples from
Horndean lA (SU 71541260), six samples from Homdean
4 (SU 66301346), three samples from Humbly Grove-3
(SU 7054 4530) and one sample from Calub 1 in the
Ogaden Basin, south-eastern Ethiopia (Berhanu, 1994).

Figure 1: Schematic diagram of  the experimental setup, also showing the arrangement of  electrodes around the rock
sample. Scales are approximate (sample width is 5 cm). After Falcon-Suarez et al. (2017), North et al. (2013).

The Wealden Basin, southern England, comprises
several formations, for example, the Hesters Copse
Formation and the Great Oolite. The Hesters Copse
formation is divided into a wackestone unit (oolitic and

bioclastic), a dolomite unit (calcareous dolomite) and a
basal sandstone unit (fine-grained calcareous sandstone).
Next, the dominant component in the Great Oolite
formation is oolitic, skeletal and oncolytic grain stones



Pa
ge


24

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

and pack stones (Sellwood, Shepherd, Evans, & James,
1989). Overall, diagenetic processes in these rocks are
compaction, dissolution and late cementation (Berhanu,
1994). The limestones from the Ogaden Basin belong
to the Hamanlei Formation. The Hamanlei Formation
is composed of  several limestone facies like grainstones
(peloidal, oolitic and skeletal) to mudstones, dolostones
and evaporates (Berhanu, 1994).
A collection of  more than one hundred rock samples which
had previously been analyzed in a lab using an ultrasonic
pulse-echo device were used to choose the samples
(Berhanu, 1994b). The best samples for this investigation
were chosen using the findings of  petrophysical studies,
which included porosity, permeability, ultrasonic velocity,
and attenuation. For this study, new resistivity measurements
are essential because they enable the examination of  joint
elastic-electrical properties. Additionally, new ultrasound
measurements are crucial because they provide a cross-
check on the samples to determine whether they have
changed since the initial petrographic and ultrasonic
property measurements.

Thin-Sections Description
The thin-section 1 was taken in plane-polarised light of

sample RS08A, a limestone rock (grainstone according
to Dunham classification scheme). The field of  view is
mostly occupied by grains of  oolite, pellods and some
shell fragments, and the cement by large calcite crystals
with perfect rhombohedral cleavage. Most crystals show at
least one good cleavage.  The thin-section 1 is an example
of  a grain-supported (GS) microstructural texture
(micrite content less than 10%) with sparry cement and
grains forming tight arrangements of  mosaic-like texture.
 The thin-section 2 was taken in crossed-polarised light
of  sample RS08B, a limestone rock (grainstone according
to Dunham classification scheme). The field of  view is
occupied mostly by grains of  oolite, pelloids and some
shell fragments. The thin section was stained by the dye
Alizarin Red S so both macro pores and calcite crystal
show a yellowish colour, but in crossed-polarised light,
the macro pores turn black, as shown in thin sections
2 and 3. Under crossed-polarised light, the interference
colour for calcite crystals in a lower photograph in Figure
1, Thin-section 2, can be seen to be of  very high order
birefringence (the thin-section might be a slightly less
than normal 0.03 mm in thickness since in sections of
standard thickness the interference colour produced is a
high-order white (Mackenzie et al., 1980).

Figure 2: Thin selections optical images under the microscope. 1) The thin-section taken in plane-polarized light and
it is RS08A, limestone rock (grainstone according to Dunham classification scheme). (2) The thin-section taken in
plane-polarized light and it is RS08B, limestone rock (grainstone according to Dunham classification scheme). 3) The
thin-section taken in plane-polarized light and it is Base Bed 3, limestone rock (wackestone according to Dunham
classification scheme). 4) The thin-section taken in plane-polarized light and it is S-39446, limestone rock (wackestone
according to Dunham classification scheme).

Both the limestone and dolomite may show a twinkling
effect, which is caused by some minerals like calcite and
dolomite crystals showing a marked change in relief  when
the microscope stage is rotated (Anthony E Adams et al.,
2017; Mackenzie, W. S/ Guilford, 1980). The thin-section
2 is an example of  a fluid-supported (FS) microstructural

texture with a slightly higher number of  macro pores
(black colour) with sparry cement (micrite content less
than 10%) and grains forming tight arrangements of  a
mosaic-like texture.
Whereas, the thin-section 3 was taken in crossed-polarised
light of  sample Base Bed 3, a limestone rock (wackestone



Pa
ge


25

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

according to Dunham classification scheme). The field of
view is occupied mostly by grains of  oolite, pelloids and
some shell fragments and micrite matrix. The thin-section
3 is an example of  a fluid-supported (FS) microstructural
texture with a slightly higher number of  macro pores
(black colour). The micrite matrix, which is mainly
constituted of  aggregates of  rounded, micrite crystals,
confers a stiff  and tight texture to the rock (Vanorio &
Mavko, 2011).

Under plane-polarized light, sample S-39446-a limestone
rock classified as wackestone under the Dunham
categorization scheme-was examined in thin-section 4.
The majority of  the objects in the view’s field were oolite
grains, pelloids, micrite matrix, and a few shards of  shell.
An illustration of  a matrix supported (MS) microstructural
texture is thin-section 4. The micrite matrix, which is
mostly made up of  clusters of  spherical micrite crystals,
gives the rock a tight, hard feel (Vanorio & Mavko, 2011).

Table 1: Rock composition (from thin polished section)
Sample
name
(WELL-
DEPTH)

Fm. Facies Rock composition from thin section (%)
Grain Cement Matrix

(Mic.)
Mean
Grain dian
(μ m)

Ooid Inel Skel. Cal. Qz. Dol Mic Non mic
Well:H1A
S-39400 Great

Oolite
WKST 23 3 12 0 0 0 9 0 50 668

S-39415 WKST 46.4 0 3.1 0 0 0 17.9 0 15.9 480
WELL:H4
S-39433 Great

Oolite
PKST 41.3 0 7.7 1.2 0 0 39.4 0 2.1 692

S-39437 GRST 30.4 0 4.3 0 0 0 36.5 0.3 7 423
S-39438 GRST 34.9 0 22.1 13.9 0 0 16.1 0 0.6 787
S-39440 GRST 34.1 0 18.7 0 0 0 35.3 0 0.9 205
S-39446 WKST 24.4 0 24.4 2.8 0 0 16.9 0 24.4 603
S-39448 PKST 27.4 0 21 4.6 0 0 30 0 7.1 930
well: HG3
S-39454 HC  MST 0 0 0 0 43.7 7 42 0 5.3 68
S-39456 MST 0 0 0.3 1.7 33.7 2.6 37.8 0 10.4 98
S-39457 PKST 6.2 3.8 20.9 3.4 0.3 29.9 27.1 0 7.2 940

Note: GO=Great Oolite, HC=Hester’s Copse, GRST=Grainstone, PKST=Packstone, WKST=Wackestone and MST=Mudstone).
This table was adapted from (Berhanu, 1994)

MATERIALS AND METHODS
Experimental procedure
Every sample has been prepared using the normal
procedures outlined in (McCann, 1992; Han, 2011b).
The samples were cut to a length of  2 cm, having their
two end faces ground parallel and flat to within ± 0.01
mm. The samples were cleaned and cored as cylindrical
plugs with a 5 cm diameter. After placing them in an
oven set at 40 °C for three days, the samples were dried.
After the samples had been cleaned and dried, they were
evaluated, dimensions were recorded, and for three days
they were submerged in 35g/l of  brine at a pressure of  7
MPa. Subsequently, the saturated samples were placed in
a brine-filled tank and swiftly transferred into the high-
pressure rig for electrical and ultrasonic measurements.
For carbonate rocks, the pore fluid pressure was kept at 5
MPa. The geophysical parameters P- and S-wave velocity
and attenuation, as well as electrical resistivity, were
measured successively for each sample at each effective
pressure of  50, 40, 30, 20, and 10 MPa. The pressure

was given 30 minutes to equilibrate before measurements
were started. The temperature and relative humidity in
the laboratory were maintained at 19 ± 1°C and 50 ± 1%,
respectively.

Joint Ultrasound and Electrical Resistivity
Tomography (ERT) Rig
At frequencies ranging from 400 kHz to 800 kHz, P-
and S-wave velocities (Vp, Vs) and attenuations (Qp-1,
Qs-1) were measured using the ultrasonic pulse-echo
technique (Winkler, 1982; McCann, 1992). Researchers
employed a dual P- and S-wave transducer/receiver with
measurement accuracy of  ± 0.3% and ± 0.2 dB/cm
for the velocity and attenuation coefficient, respectively
(Best, 1992). Figure 1 shows the high-pressure rig, and in
accordance with (North et al., 2013), the sample assembly
was modified for resistivity tomography measurements.
The sample was encircled by a rubber sleeve that held
16 tetrapolar stainless steel electrodes spaced radially into
two rings for the purpose of  measuring the electrical



Pa
ge


26

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

resistivity tomography (Figure 1). The electrodes provided
a resistivity measurement error under typical working
circumstances of  < 0.1% at frequencies 1 - 500 Hz, with
a sample electrical resistivity range of  1 - 100 Ohm m.
The electrodes permitted current injection and boundary
voltage probing in many permutations.

Estimation of  Microstructural Parameters
While experimentation, the carbonate sample
microstructure was divided into five main parameters:
macro porosity, solid grains, microporous micrite
(porosity within micrite), micrite content (micrite
excluding any microporosity), and calcite crystals (sparry
calcite). Microporous micrite has a lower density than
solid calcite grains due to the presence of  microporosity.
As a result, the microporosity and solid micrite grains can
be separated according to the grey scale intensity contrast
in petrographic images. Consequently, image processing
techniques were also used that were suggested by Grove
and Jerram (2011) and Vanorio and Mavko ( 2011) to
quantify the five microstructural parameters from optical
microphotographs of  the carbonates and dolomite

samples. However, in practice, this was only feasible
for dolomite samples because the intensity contrast was
insufficient for the carbonate samples. The study used
Fuji/ImageJ software. Additionally, the study presented
an approach to estimate the uncertainty associated with
the quantified parameters.

Estimation of  Parameters From Optical Microscopy
The petrographic thin sections were blue resin-
impregnated to facilitate observation of  porosity from
optical microscopy images, and the dolomite samples
thin-sections were stained by the dye Alizarin Red S,
used here to differentiate calcite and dolomite (dolomite
shows original clear stain colour, while calcite shows a
pink tored–brown when stained). The dyes are dissolved
in a weak acid solution as dolomite does not react with
cold dilute acid, whereas calcite does. During the practical
experimentation, basically, two stages to process the
images were used and five different textural classes. To
illustrate the process, it was suitable to refer an example
images in Figures 4.2 – 4.7 and the microstructural
elements outlined in Table 4.2.

Table 4.2: Relative image intensity levels of  each microstructural element, and symbols used in text
Microstructural element Symbol Image intensity Grey levels Min/Max
Macro porosity 𝜙macro Black 0-40 (± 20)

Ooids, pelloids and shell fragments F bio Dark grey 40-90 (± 20)
Micrite Micrite Grey 90-160 (± 20)
Calcite, sparite F calcite Light grey 160-255 (± 20)
Microporosity in dolomite 𝜙micro White 120-225 (± 20)

However, figure 2 shows a flowchart for the key
operations used to extract the relevant measurement.
Digital image acquisition was achieved using a NIKON
D5600 DSLR Camera attached to a microscope to
acquire a digital image directly from the thin section. The
image was acquired with low magnification (5X zoom)
in an optical microscope to capture a large area so that

it will be representative of  the rock  (Croizé et al., 2010;
Fournier & Borgomano, 2009; Lambert et al., 2006;
Saxena, Hofmann, et al., 2017). Grove & Jerram (2011)
pointed out that some of  the images they acquired at
low magnification had distortion toward the edges of  the
frame (darker than the rest of  the frame). Still, the author
did not observe this in the low-magnification images.
A total of  five different locations were captured from the
thin section, and each optical microscopy image was used
to estimate the microstructural parameters of  interest.
It was determined that the overall microstructural
parameters for the rock by averaging the values obtained
from all five images. Figure 3 shows the workflow that
was used to estimate the microstructural parameters. The
first stage was colour thresholding the images to indicate
the macro porosity, which has a blue colour for blue
resin-impregnated thin sections, as shown in Figures 3A
& B, and appears yellow to black for thin sections stained
by Alizarin Red S dye in Figure 3C. For example, fenestral
porosity in a carbonate rock is pore space larger than the
normal grain-supported spaces, and it can be a different
size or shape depending on its origin (see Figure 3 C).



Pa
ge


27

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Figure 3: Workflow using stage1, colour thresholding within ImageJ to convert the blue colour to black. Screenshots
are shown for key operations. A)  Segmentation of  a thin section optical image (from sample S-39400, an oolitic
limestone) under the transmitted light microscope. B) Segmentation of  a thin section optical image (from sample
RS01-2, a sparry calcite) under the transmitted light microscope. C)  Segmentation of  a thin section optical image
(from sample GRN 2 a sparry calcite) under the transmitted light microscope.



Pa
ge


28

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Fenestrae with an elongated shape might be due to
entrapment of  fluid in a sediment during desiccation
(A E Adams et al., 1984). Using ImageJ, 24-bit colour
images are thresholded using an 8-bit colour conversion
tool (image>Type>8-Bit colour) set to 256 colours.
Then, converted the blue/yellow colour to black. One
of  the drawbacks of  using grey-intensity thresholding
is that the macro porosity in blue resin-impregnated and

Alizarin Red S dye-stained thin sections changes colour
to grey, giving a low contrast between macro porosity
and micrite aggregates, making it difficult to segment.
This can be avoided by changing the colour of  the macro
porosity from blue /yellow to black, so it can be easily
distinguished during the subsequent grey-scale intensity
thresholding. The image was then converted to a grey-
scale, as shown in Figure 4A.

Figure 4: Workflow using stage2, greyscale thresholding within ImageJ. Screenshots are shown for key operations. A)
image convert to 8-bit grey intensity. B) Shows greyscale thresholding the image and thresholder slide used to choose
the greys intensity for microstructural parameters and the results

The second stage of  the workflow was to use grey-scale
thresholding to segment the images. Table 4.2 shows the
different grey-scale intensities for the variety of  allochem
type clasts; for example, bioclasts and coated grains
(ooids), calcite (sparite), micrite, micro porosity and
macro porosity. This diversity in the intensity response
allowed us to segment the picture and obtain five different
distinct classes. It was judiciously selected a value for
thresholding based on a grey-scale intensity and geology
knowledge to segment the image. After that, it can be
calculated the fraction of  the classes associated with the
grey-scale intensities below the threshold. A two-step
segmentation scheme (i.e., two threshold values) allowed
to obtain the microstructural parameters as follows: (A)
the first threshold separates the macro porosity (i.e., black
regions in optical microscope image) from the rest of  the
image, (f1), is given by
f1 = ∅macro,                (1)
Where f1 is the first threshold and ∅macro is macroporosity.
Thereby calculating the macroporosity (𝜙macro) as
illustrated in Figures 5, (A), Figure 6 (A) and 4.7 (A). The
second threshold (f2) has a higher grey-intensity value

than the first threshold and separates the fbio and macro
porosity from the rest of  the image, as shown in Figure
5 B f2 is given by
f2 =∅macro+ fbio,                           (2)
Where f2 is the second threshold and fbio is a fraction
of  ooids, pelloids and shell fragments. The fraction of
calcite crystals (fcalcite) has a light grey colour, so to
calculate the sparry calcite only in ImageJ software, it
simply reverses the threshold to start from white to black,
and the results are added to solid grains (fgrains), see
Figure 5C and Figure 6C. fcalcite   is given by
fcalcite =f3,                  (3)
where fcalcite is the fraction of  calcite crystals (sparite), and
f3 is the third threshold.
The fraction fbio is given by
fbio =f2- ∅macro.                 (4)
The fraction of  solid grains  fgrains  is given by
fgrains =fbio + f3 ( fcalcite)                 (5)
The fraction of  micrite aggregate, i.e., solid micrite
crystals (fmicrite) + micro porosity (𝜙micro), is given by
fmicrite aggregate = 100 - (fgrtains+ ∅macro )               (6)
The micro-porosity cannot be estimated directly from



Pa
ge


29

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

optical microscope images due to the low magnification
used in the image acquisition. In a low magnification
image, the contrast in a grey intensity for the solid micrite
crystals and microporosity is too low to be thresholded.
Therefore, the micro-porosity was estimated indirectly
by subtracting the macro-porosity from the measured
helium porosity (𝜙); ∅micro  is given by
∅micro = ∅ - ∅macro, (7)
where ∅micro is microporosity, ∅ is measured helium
porosity and ∅macro is macroporosity. Finally, the micrite
content fmicrite is given by
fmicrite =f  micrite aggregate - ∅micro               (8)
The overall fraction of  microstructural parameters for

each rock sample was estimated in the five different
images and then averaged.
Figures 5 to 7 show examples of  the Stage 2 workflow:
grey-scale intensity thresholding of  the segmentation
output separating solid grains’ from macro porosity and
calcite crystals. Figure 5 is rock sample S-39400, an oolitic
limestone (Wackestone).
Figure 5A shows the final segmented image with macro
porosity in black. Figure 5B, shows macro porosity and
solid grains, which can be recognised in two forms:
allochems type clasts such as bioclasts and coated grains
(ooids) highlighted in red. Figure 5 C shows the calcite in
red colour.

Figure 5: Segmentation of  a thin section optical image (from sample S-39400, an oolitic limestone, Wackestone)
under the transmitted light microscope. A) The macroporosity is highlighted in black. B) Shows macroporosity and
bioclasts and coated grains (ooids) highlighted in red. C) Shows calcite in red colour

Figure 6 shows a sequence of  digital images of  a thin
section microphotograph of  sample RS01-2 (pack stone
according to Dunham classification scheme). The macro
porosity is shown in black in Figure 6 A. This sample
comprises entirely sparry calcite without any ooids, so
some adjustment has been made for the calculation of
microstructural parameters. The first threshold was
the macro porosity. The second threshold was macro
porosity and micrite aggregate. The micrite aggregate
can be calculated by subtracting f1 from f2. The third

threshold was calcite. The micro-porosity was calculated
using Equation 7.
Figure 7 shows sample ALG1.1, a dolomite rock
(microbial-laminated dolo-mudstone according to
Dunham classification scheme). Figure 7 A shows the first
threshold macro porosity. The second threshold was macro
porosity and micrite aggregate. The micrite aggregate can
be calculated by subtracting f2 from f1, as shown in Figure
7 B. The third threshold was the microporosity within
micrite aggregate, as shown in Figure 7 C.



Pa
ge


30

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Figure 6: Demonstrating of  the first stage segmentation of  thin section optical image (Packstone; sample No. RS01-2
under the microscope .A) The macroporosity is highlighted in black. B) Shows macroporosity and micrite highlighted
in red. C) Shows calcite in red colour

Figure 7: Demonstrating of  the segmentation of  thin section optical image under the microscope. The sample
ALG 1.1 a, dolomite rock (microbially- laminated dolo-mudstone according to Dunham classification scheme). (A)
The macroporosity was highlighted with red colour. (B) The micrite aggregate was highlighted in red colour. (d) The
micro-porosity was highlighted with red colou



Pa
ge


31

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Generally, the workflow is able to distinguish (visually)
quite well the different components of  calcite grains,
macroporosity and micrite aggregate (including micro-
porosity). However, it is not possible to resolve the actual
micro-porosity associated with the micrite aggregates
in limestone samples as micrite consists of  clay-size
particles (1 - 4 μm); we would need a higher magnification
to capture the micro-porosity.

Quantification of  Uncertainty Associated with
Parameters Estimation
Quantifying the uncertainty related with an estimation
of  microstructural parameters is important to indicate
the reliability of  rock-type classifications for theoretical
modelling. Table 4-3 shows an example of  the uncertainty
associated with the picking threshold when pushing the
limit of  what would be the correct thresholding to see
the sensitivity of  each parameter. Table 4-3 shows four
examples, one from each facies: mudstone, wackestone,
packstone and grainstone.
A semi-quantitative estimate of  confidence, as a measure
of  uncertainty, was determined by calculating the
estimated percentages of  the parameters of  interest
(macroporosity, oolitic grains, calcite and micrite) for the
chosen threshold grey scale value, and for this threshold
value plus or minus ten grey scale units. The results in
Table 4-3 show the variation in all parameters is less than
6% for all rock types. Thus, the uncertainty associated
with the picking threshold is within an acceptable range,
and the results still show similar trends for micrite content
as a function of  porosity, permeability and compressional
velocity as the results reported in the literature (Vanorio,
2011; El Husseiny, 2015).

Estimated Parameters and Associated Uncertainty
Figure 8 below shows a comparison between micrite
aggregate estimated using digital photomicrographs of
thin sections by an optical microscope and that estimated
from the point counting method for samples with
available data (only 10 samples). The results show that
the two techniques, in general, are comparable. Moreover,
figure 8 also shows micrite aggregate estimated by two

different techniques: by image analysis using ImageJ
software and by point counting. The most interesting
aspect of  this graph is that the two techniques, in general,
are comparable for the samples characterised by very
low or high microcrystalline calcite with micro-porosity.
In contrast, there is a mismatch for the samples with
intermediate micrite aggregate (30% - 50%). The vertical
bar corresponds to the standard deviation associated
with average reported micrite aggregate from optical
microscope image technique.

Figure 8: Plot of  micrite aggregate (i.e., solid micrite
crystals (fmicrite) + micro porosity (𝜙micro) estimated
from the optical image under the microscope versus that
obtained from point counting

In general, the mismatch might be due to the larger
number of  data points used in ImageJ image analysis than
used in point counting. Equally important, the parameter
standard deviations for these samples are relatively
high, indicating the samples are more heterogeneous.
Therefore, the two techniques are less likely to match.
Furthermore, in the next sections, the study also explored
the relations between the parameters measured from
image analysis, and in particular, the effect of  micrite
content on reservoir and geophysical properties.

Table 4-3: Semi-quantitative estimate of  confidence when using threshold and ± 10 is grey scale values
Samples Facies Macroporosity

(%)
Oolitic grains (%) Calcite (%) Micrite (%)

-10

T
hr

es
ho

ld +10 -10

T
hr

es
ho

ld +10 -10

T
hr

es
ho

ld +10 -10

T
hr

es
ho

ld +10

ALG1.3 Mudstone 5.09 8.13 12.72 0 0 0 0 0 0 87.28 91.87 94.91
Base Bed 3 Wackstone 0.41 3.31 8.35 53.74 58.63 64.21 4.71 5.81 7.53 28.24 32.25 38.11
S-39457 Packstone 0 1.37 6.88 23.39 25.37 27.92 32.87 42.15 50.21 28.45 31.11 34.72
RS08B Grainstone 0.33 1.05 5.68 58.2 61.48 64.57 27.01 30.11 33.42 4.26 7.36 10.67



Pa
ge


32

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

RESULTS AND DISCUSSION
The Effect of  Micrite Content on Reservoir Porosity,
Permeability and Geophysical Properties
Micrite and Porosity Relationships
Figure 9 shows a cross-plot of  the microcrystalline
calcite (micrite) and porosity on a log-linear scale for
all 21 limestone samples and 15 dolomite samples. For
limestones and dolomites in Figure 9, a U-shape was
observed where micrite content ranged from 0% to
10%, showing no relationship between micrite content
and porosity as a different range of  porosity was found
between 0% and 10% micrite content.

Figure 9, Sample 1, represents a grain supported (GS)
microstructural texture (micrite content less than 10%)
with sparry cement and grains forming tight arrangments
of  mosaic-like texture. Thin section 2 in Figure 1
corresponds to sample number 2 in Figure 9, which is
RS08B (a grain stone according to Dunham classification
scheme). Sample 2 represented fluid supported (FS) rock
which had a secondary porosity, like vugs, fenestral and
moldic porosity.
For limestones and dolomites in Figure 9, porosity
starts to increase for micrite content lower than 10%.
Thus, a possible mechanism for this behaviour could be
diagenesis; for example, as the grains and sparry cement of
sample 1 in Figure 9 become corroded and etched around
their boundaries, this could result in the textural features
seen in, for example, sample 2. The carbonate diagenesis
dissolution and leaching process may transform sample
1 grain stone supported texture to evolve toward a fluid-
supported texture, as seen in sample 2 in Figure 1.
Thin section 4 in Figure 1 corresponds to sample number
4 in Figure 9, which is S-39446 (wackestone according to
Dunham classification scheme). This sample has a matrix-
supported (MS) rock microstructure predominantly
constituted of  aggregates of  rounded, microcrystalline
calcite (micrite), conferring a stiff  and tight texture to the
rock. Hence, a significant portion of  the total porosity
is formed from small, rounded micro-pores of  micrite.
Thin section 3 in Figure 1 corresponds to sample number
3 in Figure 9, which is Base Bed 3 (wackestone according
to Dunham classification scheme). Thin-section 3 shows
significant numbers of  macropores.
For limestones and dolomites in Figure 9, porosity
decreases from the maximum around 10 – 30% micrite
as micrite content increases to 70%. The majority of
dolomite samples that have micrite content above 30
% were wackestone and pack stone and the dolomite
samples were mudstone. A possible mechanism for
this behaviour could be diagenesis, illustrated by, for
example, as sample 4 textures alter to textures seen in
sample 3 in Figure 9; it can be seen that some micrite
has been washed out from the intergranular space. The
carbonate diagenesis dissolution and leaching process
leads to micro-pores becoming more connected, and the
development of  molds, large vugs and channels, as seen
in sample 4 in Figure 1. That is, a matrix supported rock
evolves toward a fluid supported rock.
Figure 10 shows the cross-property relation between
macro porosity and micrite content. Note that micrite
content is inversely proportional to the amount of  macro
porosity (see equation 1). The micro-porosity in Figure
11 increases as micrite content increases and these data
agree with the literature (Baechle et al., 2004; Brigaud et
al., 2010; Cantrell & Hagerty, 1999; Eberli et al., 2003;
Fournier & Borgomano, 2009; Kazatchenko et al., 2006;
Norbisrath et al., 2015; Regnet et al., 2015; Vanorio &
Mavko, 2011; Weger et al., 2009).

Figure 9: Shows the variation of  porosity as a function
of  micrite content. Red data are the limestone samples,
and blue are the dolomite samples. The numbers in
black refer to values measured on the samples whose
microstructure is shown in Figure 1.

Vanorio and Mavko (2011) showed a similar trend to this
study of  porosity as a function of  micrite content. On
the other hand, (Husseiny & Vanorio, 2015; Dominique
Marion, 1990) reported an opposite trend of  porosity as a
function of  micrite content. The trend was from synthetic
micrite samples that lack macroporosity. Whereas, in
our study, and in that of  (Vanorio & Mavko, 2011), the
samples were from natural carbonate rocks which are
inherently populated with macro porosity and, secondary
porosity. The presence of  secondary porosity can be
derived from different diagenetic evolution of  porosity
in carbonates rocks.
The numbers in black in Figure 9 refer to values measured
on the samples whose microstructure is shown in Figure
1. A visual check of  the thin sections 1 to 4 in Figure 1
for limestone samples (dolomite samples showing similar
microstructures) shows a possible mechanism for the
trends in Figure 9 porosity with micrite content.
Thin section 1 in Figure 1 corresponds to sample
number 1 in Figure 9, which is sample RS08A (a grain
stone according to Dunham classification scheme).



Pa
ge


33

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Figure 10: Shows the variation of  macroporosity as a
function of  micrite content. Red data are the limestone
samples, and blue are the dolomite samples

Figure 11: Shows the variation of  macroporosity as a
function of  micrite content. Red data are the limestone
samples, and blue are the dolomite samples

Figure 1 supports the conceptual model of  Vanorio and
Mavko (2011) that describes the evolution of  the calcite
grain-micrite mixture in carbonates based on grain-
micrite-pore fraction and the above explanation of  the
variation of  porosity with respect to micrite fraction (see
section 1.2.3).

Micrite and Permeability Relationships
Figure 12 shows the cross-property relations between
permeability and micrite content on a log-linear scale.
For limestones and dolomites in Figure 12 , the micrite
content ranging from 0% to 10%, the permeability shows
no correlation with micrite fraction as permeability exists
in all ranges. The permeability shows a peak when micrite
content is around 10% and 30% and these samples
were limestone wackestone. Then, permeability starts to
decrease drastically for micrite content higher than 30%
and the facies straddle between limestone ( wackestone
and packstone) and the dolomite was the only mudstone.

Vanorio (2011) reported the variation of  permeability
with micrite did not appear to be large (permeability from
4.9 to 213.3 mD), and also noted a peak at 10% to 20%
micrite content. We see a much larger dependence of
permeability on micrite in our rock samples (permeability
from 0.01 to 824 mD).
The numbers in black in Figure 12 refer to values measured
on the samples whose microstructure is shown in Figure
1. A visual check of  thin sections 1 to 4 in Figure 1 for
limestone samples (dolomite samples showing similar
microstructures) suggests a possible mechanism for the
permeability-micrite trends seen in Figure 12.
Thin-sections 1 and 2 are grain-supported with sparry
cement. For limestones and dolomites in Figure 12,
permeability starts to increase with increasing micrite
content approximately up to 10%. Thus, a possible
mechanism for this behaviour could be due to diagenesis
as sample 1 goes to sample 2 in Figure 12, the grains and
sparry cement might become corroded and etched around
their boundaries. The carbonate diagenesis dissolution
and leaching process may transform sample 1 in Figure 1
grain stone supported to evolve toward fluid a supported
rock, for example, sample 2 in Figure 1.
For limestones and dolomites in Figure 12, permeability
starts to increase as micrite content deacreas from 70%
up to around 30%. Thus, a possible mechanism for
this behaviour could be diagenesis, as sample 4 goes to
sample 3 in Figure 12, which shows that some micrite is
washed out from the intergranular space. The carbonate
diagenesis dissolution and leaching process leads micro-
pores to become connected, with molds, large vugs and
channel development leading to sample 4 in Figure 1, i.e.
matrix supported evolves towards a fluid-supported rock,
for example, sample 3 in Figure 1.

Figure 12: Shows the variation of  permeability as a
function of  micrite content. Red data are the limestone
samples, and blue are the dolomite samples

Porosity and Permeability Relationships
Figure 13 shows the cross-property relations between
porosity and permeability for all 21 limestone samples
and 15 dolomite samples. In general, the permeability
increases as porosity increases, as expected, according



Pa
ge


34

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

to the literature for similar rocks. (Archilha et al., 2016;
Costa, 2006; Dvorkin, 2009; El Husseiny & Vanorio,
2017; Fabricius et al., 2010; R. Han et al., 2010; Lima
Neto et al., 2014; Mavko & Nur, 1997; Saxena, Mavko,
et al., 2017; Verwer et al., 2011; Vialle et al., 2013; Weger
et al., 2009) found that Kozeny-Carmen relation fitted
their observations using constant parameters B = 5, 0.5,
0.05, 0.005 overlain on Figure 13. This shows that our
data are in reasonable agreement with the literature for
similar oolitic limestone, sparry calcites and hydrothermal
dolomites. The Kozeny-Carmen relation is
k=B  ( ∅- ∅c)

2 )/(1+ ∅c- ∅)2 d2,              (9)
where k is permeability, B constant, d = 150 μm is
diameter, ∅c =36 % is critical porosity and ∅ is porosity.
Also, the data points are colour-coded for micrite content
and symbols for grain-supported dolomite (sparry calcite
cement), matrix-supported dolomite (micrite matrix),
grain-supported limestone (sparry calcite cement),
matrix-supported limestone (oolitic-micrite matrix) and
fluid-supported limestone (oolitic-micrite matrix with
large vugs, moldic, and fenestral porosity).
Limestone samples in figure 13 shows that fluid-supported
samples which was a result of  diagenesis dissolution have
a higher porosity-permeability than matrix-supported
samples and these samples have ooids and peloids for
grains. The grain-supported limestone has less than 10%
micrite content and follows matrix-supported samples
in porosity-permeability space. Dolomite samples show
that adding micrite content seems to reduce porosity
and permeability. In general, the sample with high macro
porosity also has high permeability due to pore space being
connected, as shown in Figure 13, with fluid-supported
samples (diamond shape), and the main processing was
diagenesis leaching and dissolution. However, samples
with critical porosity in which the pore space is filled
with micrite (matrix-supported) or sparry calcite (grain-
supported limestone) in Figure 13 has implications for
overall results as critical porosity samples have a high
porosity but low permeability as the pore space is not

connected. The critical porosity samples consider to be
poor reservoir as they have lower permeability which
makes the migration of  hydrocarbon low.
El Husseiny & Vanorio (2017) investigated the effect
of  micrite content and macro porosity on the porosity-
permeability relationships using analog samples created
in a laboratory in a dual porosity system. They showed
that adding micrite to grain-supported samples reduces
porosity and permeability drastically, up to approximately
30% micrite content. At higher micrite contents, the
sample became micrite-supported and adding more
micrite only affects porosity, not permeability.

The Effect of  Micrite on Elastic Wave Velocity
The variation of  P-wave velocity as a function of  micrite
content is shown in Figure 4-15. For limestones, the
velocity decrease with increasing micrite content, where
a minimum in velocity is observed around 10% and 30%
micrite content while the dolomites samples between 0 %
and 10 % show no relationship between micrite content
and velocity. Then, the velocity starts to increase with
increasing micrite content above 30% (S-wave velocity
shows similar).
Regarding the effect of  micrite between 0 and 30% on
elastic properties, we notice from a visual check of  thin
section 1 in Figure 1 and thin section 2 in Figure 1 that
the dominant process was leaching and dissolution. The
optical microscopy shows a carbonate microstructural
texture mainly represented by a grain-supported
framework with relatively low amounts of  lime-mud
interstitial material in Figure 1 and presence of  tight
spar cement and microcrystalline calcite forming crystal-
mosaic textures and interlocked arrangements.
Figure 12 reveals that carbonate rocks characterised
by micrite contents between 10% and 30% have a
higher fraction of  grains to micrite matrix. These
carbonate samples were characterised by higher macro
porosity in Figure 10, due to leaching and dispersing
of  microcrystalline calcite matrix that filling the grains’
interstices (Vanorio & Mavko, 2011). Thus, leading to
increasing of  total porosity in Figure 9, and low velocity
in this region.
For limestones and dolomites in Figure 15, velocity starts
to decrease for micrite content lower than 10%. Thus,
could be due to diagenesis as sample 1 goes to sample 2
in Figure 4.9, the grains and sparry cement might become
corroded and etched around their boundaries and the
facies of  limestone were grain stone and wackestone. The
carbonate diagenesis dissolution and leaching process
may transform sample 1 grain stone supported to sample
2 fluid supported rock.
Figure 15 shows velocity to decrease with decreasing
micrite content from 70% up to 30% and the dolomite
were only from one facies, and it was mudstone
while limestone was pack stone and wackestone. The
sample is matrix supported (MS) rock microstructure
predominantly constituted of  aggregates of  rounded,
microcrystalline calcite (micrite) crystals conferring a stiff

Figure 13: Shows the variation of  permeability as a
function of  porosity. Red data are the limestone samples,
and blue are the dolomite samples



Pa
ge


35

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Figure 15: Shows the variation of  (a) P-wave and (b) S-wave velocities as a function of  micrite content

Figure 16: Pressure sensitivity of  (a) P-wave and (b) S-wave velocities as function of  micrite content. Data are coded
as a function of  pressure

and tight texture to the rock. Hence, a significant portion
of  the total porosity is from small, rounded micro-pores
of  micrite (Vanorio & Mavko, 2011). Figure 15, Sample 3,
represent fluid supported (FS).
Thin sections 3 and 4 in Figure 1 suggest some micrite
was washed out from the intergranular space and this
factor leads total porosity to increase. Also, the removal
of  micrite might reduce the effective rock stiffness as
micrite (an aggregate of  rounded micro-crystals) is a stiff
microstructural component, therefore, both factors might
reduce the velocity. Thus, the main process that leads
velocity to decrease with micrite content from 70 % up to
30% is carbonate diagenesis dissolution and leaching.

Figure 16 shows the effect of  pressure on velocity and
micrite content. The limestone samples with micrite
content of  less than 10 % show very high-pressure
sensitivity. Then samples between 10 and 30 % micrite
content shows that the sensitivity of  velocity to pressure
was low. After that, the sensitivity of  velocity to pressure
start to slightly increase but it’s less than samples with less
than 10 % micrite content. The dolomite samples were
very tight and was independent of  pressure. Red data are
the limestone samples, and blue are the dolomite samples.
The numbers in black refer to values measured on the
samples whose microstructure is shown in Figure 1.

This phenomenon was due to micrite-rich samples being
stiffer than grain-supported samples even though micrite-
rich samples had higher velocities. This suggests that the
micrite-rich samples were tight, with few compliant pores,
whereas grain-supported samples had more compliant
pore structures. Red colour is limestone samples and blue
colour is dolomite samples. The differential pressure is
50MPa and 10MPa in plus sign.

 These results agree with (Husseiny & Vanorio, 2015), for
the relation between velocity and micrite content as they
made a synthetic carbonate rock of  two sets of  data, one
without cement and the other sets of  data with cement.
Husseiny & Vanorio et al., ( 2015) show that micrite-rich
samples characterised by larger acoustic velocities for both
the uncemented and cemented samples which suggests
that the presence of  cement was not the main controlling



Pa
ge


36

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

factor. Husseiny & Vanorio et al., ( 2015) explained this
phenomenon by velocity sensitivity to pressure as the
sensitivity of  velocity to pressure increases as the micrite
content decreases. In the contrary, while the sensitivity
of  velocity to pressure increases, the micrite content
decreases which indicate that grain-supported samples
have a more compliant structure.

The Effect of  Micrite on Attenuation
Seismic attenuation is a great attribute that can be utilised
as an indicator of  fracture, lithology, clay, fluid content

Figure 14: Shows the variation of  permeability as a function of  a) microporosity b) macroporosity. Red data are the
limestone samples, and blue are the dolomite samples

Figure 17: Shows the variation of  a) P-wave b) S-wave quality factors as a function of  micrite content. Red data are
the limestone samples, and blue are the dolomite samples

and pore structure in a reservoir rock (Parra, 2006). The
cross-property relations between micrite content and
Qp-1 and Qs-1 are shown in Figure 14 (a, b), respectively.
The data shows a non-linear relationship. Also, it is
sparse and scattered. However, the quality factors show
two peaks: the first peak was around 10% micrite content
and, the dominant facies were grainstone, and the second
peak was around 40% micrite content. The facies were
straddled between mudstone, packstone and wackstone,
forming a bell-shaped correlation between Qp-1 and
micrite (Qs-1 show similar results).

Figure 17 shows the sensitivity of  the attenuation to
pressure as a function of  micrite content. We notice
that the two peaks were more pressure sensitive, which
indicates the closure of  cracks and microcracks in these
samples from 10 MPa to 50 MPa. The possible mechanism
to explain the attenuation behaviour with respect to micrite
was Biot mechanism (Global fluid flow). Further, in the
two peaks, the closure of  cracks and the microcracks were
very high as shown in Figure 18 so another mechanism
is possible here and it is the Squirt-flow mechanism. The

squirt-flow mechanism focuses on the loss resulting from
the ‘local’ flow of  viscous fluid into and out of  microcracks
during the passage of  acoustic waves. Assefa, McCann and
Sothcott, (1999) studied the effect of  attenuation on facies
such as mudstone, wackestone, grainstone and packstone.
They concluded that when the attenuation reaches the
maximum values, the dual porosity system is developed,
indicating that the squirt-flow mechanism, which has
previously been shown to occur in shaley sandstones, also
operates in the limestones.



Pa
ge


37

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

The Effect of  Micrite on Electrical Resistivity
Electrical resistivity is affected by key characteristic which
is pore structure as the connectivity and size of  the pores
control the overall pore network connection, and the
pore throats will be affected by capillary forces. Many
controlling factors affect Electrical resistivity such as (1)
size of  the pore throats (Abousrafa et al., 2009), (2) on the
amount of  separate-vugs porosity (Lucia & Conti, 1987),
and (3) tortuosity (Saner et al., 1996).
Apparent electrical formation factor F* (defined as ρ0/
ρw, where ρw =0.213 Ωm for 35 g/l brine at a temperature
of  19°C) measured at 80 Hz versus microcrystalline
calcite for all 21 samples of  limestone and 15 samples
dolomite are shown in Figure 19 on a log-linear scale.
Apparent formation factor F* shows, in general, a
U-shape trend with a general decreasing trend with
increasing microcrystalline calcite for samples below
15% microcrystalline calcite margin. Apparent electrical
formation factor F* at the lowest value between 10
and 30 % microcrystalline calcite. Figure 19 shows an
increasing trend of  apparent formation factor F* with
microcrystalline calcite for the limestone samples above
30% microcrystalline calcite, and a steep decrease in F*
with micrite for dolomites. These data show the opposite
trend to the permeability data in Fig 4.12, as would be
expected, as F* is an analogous transport property.
Figure 19 shows apparent formation factors against
micrite content. The apparent formation factors start
to decrease when the micrite content below 10%. A
visual check of  the thin sections 1 and 2 in figure 19,
corresponds to sample number 1 and 2 in Figure 1, grain
stone and fluid supported respectively.
Thus, could be due to diagenesis as, sample 1 goes to
sample 2 in Figure 1, the grains and sparry cement might
become corroded and etched around their boundaries.
The carbonate diagenesis dissolution and leaching
process may transform sample 1 grain stone supported
to sample 2 fluid supported rock. This will lead porosity

to increase as shown in Figure 9 and the macro porosity
will be connected and form secondary porosity such as,
vugs, moldic and fenestral as shown in Figure 10.
The apparent formation factors have the lowest value
between micrite content 20-30 % due to the presence of
both, macro porosity (vugs) and micro porosity within
micrite content so the conductivity is high. Figure 19
shows the apparent formation factors increase as micrite
content increase above 30% micrite content with two
trends parallel to each other and oolitic limestone samples
higher than dolomite samples.
A visual check of  the thin sections 3 and 4 in Figure 1,
corresponds to sample 3 and 4 in Figure 19, which both
are oolitic limestone (wackestone) as shown in red colour
in Figure 19. Sample 3, represent fluid supported (FS)
and sample 4 represent matrix supported (MS). The red
colour samples above 30% micrite in Figure 19 shows
first trend and these samples are limestone characterised
by large grains (oolite) and fine grains (micrite). The
blue colour samples above 30% micrite in Figure 19
are dolomite samples with majority of  rocks are fine
grains (micrite) and they are matrix supported (MS) rock
microstructure predominantly constituted of  aggregates
of  rounded, microcrystalline calcite (micrite) crystals
conferring a stiff  and tight texture to the rock (Figure 7
A). Hence, a significant portion of  the total porosity were
from small, rounded micropores of  micrite (Vanorio &
Mavko, 2011).
For limestones and dolomites in Figure 19, the carbonate
samples above 30% micrite have higher apparent
formation factors as micrite seems to reduce the mean
pore size and the overall porosity and block the electrolyte
conduction due to a reduction in connectivity between
the pores.
The apparent formation factors start to decrease as
micrite content decreases from 70%  up to around 30 %.
The thin sections 3 and 4 in Figure 1 suggest a possible
mechanism for this behaviour, and it could be due to

Figure 18: Shows the pressure sensitivity of  a) P-wave b) S-wave quality factors as a function of  micrite content. Red
data are the limestone samples, and blue are the dolomite samples. The differential pressure is 50MPa and 10MPa in
plus sign



Pa
ge


38

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

diagenesis as, sample 4 goes to sample 3 in Figure 19,
which shows that some of  micrite is washed out from the
intergranular space.
The carbonate diagenesis dissolution and leaching
process lead micropores to become connected, molds,
large vugs, and channel might develop, leading sample
4 in Figure 1 matrix supported to evolve toward fluid-
supported rock, for example, sample 3 in Figure 1.  The
apparent formation factor data show the opposite trend
to the permeability data in Fig 12, and porosity data
in Fig 9 as would be expected, as F* is an analogous
transport property. Thus, the main factor that affect F*
in carbonate rocks seems to be the porosity and micrite
content, due to porosity and micrite content were highly
negatively correlated for the majority of  our samples.
The main process that leads apparent formation factors
to decreases with micrite content from 70 % up to 30% is
carbonate diagenesis dissolution and leaching.

macro porosity. The study also quantified the uncertainty
associated with the estimated parameters by using
standard deviation. The amount of  micrite aggregate
obtained was compared by two techniques: the point
counting method and image analysis using ImageJ
software. The error seems to be larger when micrite
aggregate is around (30% - 50%). The research findings
suggested that Carbonate samples with higher micrite
content and lower macroporosity have lower permeability
at any given porosity. Moreover, the study also quantified
the uncertainty associated with the estimated parameters
and found that optical microscope images can reproduce
microstructural parameters with an average root mean
square error of  6%.

REFERENCES
Abousrafa, E. M., Somerville, J. M., Hamilton, S.

A., Olden, P. W. H., Smart, B. D. G., & Ford, J.
(2009). Pore geometrical model for the resistivity
of  brine saturated rocks. Journal of  Petroleum Science
and Engineering, 65(3–4), 113–122. https://doi.
org/10.1016/j.petrol.2008.12.009

Adams, A E, Guilford, C., & MacKenzie, W. S. (1984).
Atlas of  sedimentary rocks under the microscope.

Adams, Anthony E, MacKenzie, W. S., & Guilford,
C. (2017). Atlas of  sedimentary rocks under the
microscope. Routledge.

Archilha, N. L., Missagia, R. M., Hollis, C., De Ceia, M. A.
R., McDonald, S. A., Lima Neto, I. A., Eastwood, D.
S., & Lee, P. (2016). Permeability and acoustic velocity
controlling factors determined from x-ray tomography
images of  carbonate rocks. AAPG Bulletin, 100(8),
1289–1309. https://doi.org/10.1306/02251615044

Assefa, S., McCann, C., & Sothcott, J. (1999). Attenuation
of  P- and S-waves in limestones. Geophysical Prospecting,
47(3), 359–392. https://doi.org/10.1046/j.1365-
2478.1999.00136.x

Baechle, G. T., Weger, R. J., Eberli, G. P., & Massaferro,
J. L. (2004). The role of  macroporosity and
microporosity in constraining uncertainties and in
relating velocity to permeability in carbonate rocks.
74th Ann. Internat. Mtg., January 2004, 1662–1665.
https://doi.org/10.1190/1.1845149

Berhanu, S. A. (1994a). Seismic and Petrophysical
Properties of  Carbonate.

Berhanu, S. A. (1994b). SEISMIC AND
PETROPHYSICAL PROPERTIES OF
CARBONATE.

Brigaud, B., Vincent, B., Durlet, C., Deconinck, J.-F.,
Blanc, P., & Trouiller, A. (2010). Acoustic Properties
of  Ancient Shallow-Marine Carbonates: Effects of
Depositional Environments and Diagenetic Processes
(Middle Jurassic, Paris Basin, France). Journal of
Sedimentary Research, 80(9), 791–807. https://doi.
org/10.2110/jsr.2010.071

Cantrell, D. L., & Hagerty, R. M. (1999). Microporosity in
Arab Formation Carbonates, Saudi Arabia. GeoArabia,
4(2), 129–154.

Figure 19: Shows the variation of  apparent formation
factors as a function of  micrite content. Red data are the
limestone samples, and blue are the dolomite samples

The matrix-supported samples having most of  the
porosity in the type of  microporosity and the grain-
supported samples having the most of  the porosity as
microporous and vugs, might suggest that microporosity,
pore network connectivity, pore size of  macro porosity
might a have a significant influence in F* rather than
pore size. Verwer et al. (2011) suggest that for carbonate
rocks, the significant controlling factor for resistivity
were both pore structure and the absolute number of
pores, regardless of  the size of  the pore throats based
on seventy-one plugs from boreholes and digital image
analysis.

CONCLUSION
The study presented a methodological approach to
estimate microstructural parameters such as micrite
content and macro porosity in a carbonate rock based
on image analysis obtained from the optical microscope.
The image analysis technique was an effective, accurate,
and easy method of  measuring Micrite aggregate and



Pa
ge


39

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Ceia, M., Neto, I. L., Missagia, R., Oliveira, G., Santos, V.,
Paranhos, R., & Archilha, N. (2017). Evaluation of
microporosity aspect ratio and shear wave velocity of
middle-east carbonates. 3755–3759.

Chilingar, G. V, Bissell, H. J., & Fairbridge, R. W. (1967).
Carbonate rocks. Elsevier.

Costa, A. (2006). Permeability-porosity relationship:
A reexamination of  the Kozeny-Carman equation
based on a fractal pore-space geometry assumption.
Geophysical Research Letters, 33(2), 1–5. https://doi.
org/10.1029/2005GL025134

Croizé, D., Ehrenberg, S. N., Bjørlykke, K., Renard,
F., & Jahren, J. (2010). Petrophysical properties of
bioclastic platform carbonates: Implications for
porosity controls during burial. Marine and Petroleum
Geology, 27(8), 1765–1774. https://doi.org/10.1016/j.
marpetgeo.2009.11.008

Dunham, R. J. (1962). Classification of  carbonate rocks
according to depositional textures.

Dvorkin, J. (2009). Kozeny-Carman equation revisited.
Pangea.Stanford.Edu/~jack/KC_2009_JD.Pdf,
1–16.

Eberli, G. P., Baechle, G. T., Anselmetti, F. S., & Incze,
M. L. (2003). Factors controlling elastic properties
in carbonate sediments and rocks. The Leading Edge,
22(7), 654–660. https://doi.org/10.1190/1.1599691

El Husseiny, A., & Vanorio, T. (2017). Porosity-
permeability relationship in dual-porosity carbonate
analogs. Geophysics, 82(1), MR65–MR74. https://doi.
org/10.1190/geo2015-0649.1

Fabricius, I. L., Bächle, G. T., & Eberli, G. P. (2010).
Elastic moduli of  dry and water-saturated carbonates
— Effect of  depositional texture, porosity, and
permeability. Geophysics, 75(3), N65–N78. https://doi.
org/10.1190/1.3374690

Folk, R. L. (1959). Practical petrographic classification of
limestones. AAPG Bulletin, 43(1), 1–38.

Fournier, F., & Borgomano, J. (2009). Critical porosity and
elastic properties of  microporous mixed carbonate-
siliciclastic rocks. Geophysics, 74(2), E93–E109.
https://doi.org/10.1190/1.3043727

Grasby, S. E., & Betcher, R. N. (2002). Regional
hydrogeochemistry of  the carbonate rock aquifer,
southern Manitoba. Canadian Journal of  Earth Sciences,
39(7), 1053–1063.

Grove, C., & Jerram, D. A. (2011). JPOR: An ImageJ
macro to quantify total optical porosity from blue-
stained thin sections. Computers and Geosciences,
37(11), 1850–1859. https://doi.org/10.1016/j.
cageo.2011.03.002

Haines, T. J., Neilson, J. E., Healy, D., Michie, E. A. H.,
& Aplin, A. C. (2015). The impact of  carbonate
texture on the quantification of  total porosity by
image analysis. Computers and Geosciences, 85, 112–125.
https://doi.org/10.1016/j.cageo.2015.08.016

Hamilton, C. W. (2010). Computers & Geosciences New
image processing software for analysing object size-
frequency distributions , geometry , orientation ,

and spatial distribution $. 36, 539–549. https://doi.
org/10.1016/j.cageo.2009.09.003

Han, D. (1986). Effects of  porosity and clay content on
wave velocities in sandstones. Geophysics, 51(11), 2093.
https://doi.org/10.1190/1.1442062

Han, R., Hirose, T., & Shimamoto, T. (2010). Strong
velocity weakening and powder lubrication of
simulated carbonate faults at seismic slip rates. Journal
of  Geophysical Research: Solid Earth, 115(3). https://doi.
org/10.1029/2008JB006136

Hawkins, P., Tennis, P. D., & Detwiler, R. J. (1996). The
use of  limestone in Portland cement: a state-of-the-
art review. Portland Cement Association.

Higgins, Michael D, & Roberge, J. (2007). Three magmatic
components in the 1973 eruption of  Eldfell volcano,
Iceland: Evidence from plagioclase crystal size
distribution (CSD) and geochemistry. Journal of
Volcanology and Geothermal Research, 161(3), 247–260.

Higgins, Michael Denis. (2006). Quantitative textural
measurements in igneous and metamorphic petrology.
Cambridge University Press.

Husseiny, A. El, & Vanorio, T. (2015). The effect of
micrite content on the acoustic velocity of  carbonate
rocks. 80(4). https://doi.org/10.1190/geo2014-
0599.1

Jerram, D A, & Higgins, M. D. (2007). 3D analysis of
rock textures: Quantifying igneous microstructures:
Elements, v. 3. https://doi.org/10, 239–245.

Jerram, Dougal A, Mock, A., Davis, G. R., Field,
M., & Brown, R. J. (2009). Lithos 3D crystal size
distributions : A case study on quantifying olivine
populations in kimberlites. LITHOS, 112, 223–235.
https://doi.org/10.1016/j.lithos.2009.05.042

Kazatchenko, E., Markov, M., Mousatov, A., & Parra, J.
(2006). Carbonate microstructure determination by
inversion of  acoustic and electrical data: Application
to a south Florida aquifer. Journal of  Applied
Geophysics, 59(1), 1–15. https://doi.org/10.1016/j.
jappgeo.2005.07.004

Kowallis, B. J., Jones, L. E. a., & Wang, H. F. (1984).
Velocity-porosity-clay content systematics of  poorly
consolidated sandstones. Journal of  Geophysical
Research, 89, 10355. https://doi.org/10.1029/
JB089iB12p10355

Lambert, L., Durlet, C., Loreau, J. P., & Marnier, G. (2006).
Burial dissolution of  micrite in Middle East carbonate
reservoirs (Jurassic-Cretaceous): Keys for recognition
and timing. Marine and Petroleum Geology, 23(1), 79–92.
https://doi.org/10.1016/j.marpetgeo.2005.04.003

Lima Neto, I. A., Misságia, R. M., Ceia, M. A., Archilha,
N. L., & Oliveira, L. C. (2014). Carbonate pore
system evaluation using the velocity-porosity-
pressure relationship, digital image analysis, and
differential effective medium theory. Journal of  Applied
Geophysics, 110, 23–33. https://doi.org/10.1016/j.
jappgeo.2014.08.013

Lucia, F. J., & Conti, R. D. (1987). Rock fabric, permeability,
and log relationships in an upward-shoaling, vuggy



Pa
ge


40

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

carbonate sequence.
Mackenzie, W. S/ Guilford, C. (1980). Atlas of  rocks-

Forming minerals in thin section. 93.
Mackenzie, W. S., Guilford, C., & Scientific, L. (1980).

Atlas of  rock-forming minerals in thin sections.
Marion, D., Nur, A., Yin, H., & Han, D. H. (1992).

Compressional velocity and porosity in sand-clay
mixtures. Geophysics, 57(4), 554-563. https://doi.
org/10.1190/1.1443269

Marion, Dominique. (1990). Acoustical, Mechanical, And
Transport Properties Of  Sediments And Granular
Materials. Geophysics, 39, 136.

Marks, S. G. (1994). Seismic wave attenuation from
vertical seismic profiles. University of  Reading.

Mavko, G., & Nur, A. (1997). Short Note The effect of  a
percolation threshold in the Kozeny-Carman relation
Gary Mavko * and Amos Nur *. Most, 62(5), 1480–
1482.

Norbisrath, J. H., Eberli, G. P., Laurich, B., Desbois, G.,
Weger, R. J., & Urai, J. L. (2015). Electrical and fluid
flow properties of  carbonate microporosity types
from multiscale digital image analysis and mercury
injection. AAPG Bulletin, 99(11), 2077–2098. https://
doi.org/10.1306/07061514205

(North et al., 2013), Laurence, Best, A. I., Sothcott, J., &
Macgregor, L. (2013). Laboratory determination of
the full electrical resistivity tensor of  heterogeneous
carbonate rocks at elevated pressures. Geophysical
Prospecting, 61(2), 458–470. https://doi.org/10.1111/
j.1365-2478.2012.01113.x

(North et al., 2013), LJ, Best, A., & Sothcott, J. (2012).
Pressure Sensitivity of  the Joint Elastic-electrical
Properties of  Carbonate Reservoir Rocks. 74th
EAGE Conference & Exhibition, June 2012,
4–7. http://www.earthdoc.org/publication/
publicationdetails/?publication=59270

Parra, J. O., & Hackert, C. L. (2006). Modeling and
interpretation of  Q logs in carbonate rock using a
double porosity model and well logs. Journal of  Applied
Geophysics, 58(3), 253–262. https://doi.org/10.1016/j.
jappgeo.2005.07.003

Rasband, W. S. (1997). ImageJ. US National Institutes of
Health, Bethesda, MD.

Regnet, J. B., Robion, P., David, C., Fortin, J., Brigaud, B.,
& Yven, B. (2015). Acoustic and reservoir properties
of  microporous carbonate rocks: Implication of
micrite particle size and morphology. Journal of
Geophysical Research: Solid Earth, 120(2), 790–811.

https://doi.org/10.1002/2014JB011313
Saner, S., Al-Harthi, A., & Htay, M. T. (1996). Use of

tortuosity for discriminating electro-facies to interpret
the electrical parameters of  carbonate reservoir rocks.
Journal of  Petroleum Science and Engineering, 16(4), 237–
249. https://doi.org/10.1016/S0920-4105(96)00045-
9

Saxena, N., Hofmann, R., Alpak, F. O., Dietderich, J.,
Hunter, S., & Day-Stirrat, R. J. (2017). Effect of
image segmentation & voxel size on micro-CT
computed effective transport & elastic properties.
Marine and Petroleum Geology, 86, 972–990. https://doi.
org/10.1016/j.marpetgeo.2017.07.004

Saxena, N., Mavko, G., Hofmann, R., & Srisutthiyakorn,
N. (2017). Estimating permeability from thin sections
without reconstruction: Digital rock study of  3D
properties from 2D images. Computers and Geosciences,
102(February), 79–99. https://doi.org/10.1016/j.
cageo.2017.02.014

Sellwood, B. W., Shepherd, T. J., Evans, M. R., & James,
B. (1989). Origin of  late cements in oolitic reservoir
facies: a fluid inclusion and isotopic study (Mid-
Jurassic, southern England). Sedimentary Geology,
61(3–4), 223–237. https://doi.org/10.1016/0037-
0738(89)90059-6

Vanorio, T., & Mavko, G. (2011). Laboratory
measurements of  the acoustic and transport
properties of  carbonate rocks and their link with the
amount of  microcrystalline matrix. Geophysics, 76(4),
E105–E115. https://doi.org/10.1190/1.3580632

Verwer, K., Eberli, G. P., & Weger, R. J. (2011). Effect of
pore structure on electrical resistivity in carbonates.
AAPG Bulletin, 95(2), 175–190. https://doi.
org/10.1306/06301010047

Vialle, S., Dvorkin, J., & Mavko, G. (2013). Implications of
pore microgeometry heterogeneity for the movement
and chemical reactivity of  in carbonates. Geophysics,
78(5), L69–L86. https://doi.org/10.1190/geo2012-
0458.1

Weger, R. J., Eberli, G. P., Baechle, G. T., Massaferro, J. L.,
& Sun, Y. F. (2009). Quantification of  pore structure
and its effect on sonic velocity and permeability in
carbonates. AAPG Bulletin, 93(10), 1297–1317.
https://doi.org/10.1306/05270909001

APPENDIX I
Petrophysical and Facies properties of  the 36 carbonate
samples

Sample ID Measured physical
properties

Microstructural parameters estimated from optical
microscopy images

Facies

Limestone Porosity
(%)

Permeability
(mD)

Φ macro (%) Φ micro (%) f  grains f  micrite Facies

Base Bed 2 21.747 458.000 12.310 9.437 55.773 22.480 WKST
Base Bed 3 21.410 569.000 13.190 8.220 57.600 20.990 WKST
Base Bed 4 22.646 824.000 12.250 10.396 55.024 22.330 WKST
BWB 2 21.615 452.000 11.800 9.815 56.655 21.730 WKST



Pa
ge


41

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Sample ID Measured physical properties Microstructural parameters estimated from
optical microscopy images

Dolomite Porosity (%) Permeability (mD) Φ macro (%) Φ micro (%) f  grains f  micrite Facies
Alg 1.1 23.788 12.860 2.310 21.478 25.962 50.250 MST
Alg 1.3 25.527 30.700 3.310 22.217 27.843 46.630 MST
Bio 1.1 19.631 3.980 2.350 17.281 29.249 51.120 MST
Bio 2.2 19.524 54.660 4.760 14.764 29.996 50.480 MST
BM 1 6.088 0.090 1.540 4.548 30.112 63.800 MST
BM 2 7.273 0.120 1.680 5.593 26.987 65.740 MST
BM 3 4.747 0.080 2.060 2.687 27.223 68.030 MST
BM 4 5.092 2.470 1.650 3.442 26.858 68.050 MST
BV 2 17.373 7.500 1.610 15.763 23.997 58.630 MST
GRN 1 3.332 7.300 3.100 0.232 92.818 3.850 GRST
GRN 2 12.349 161.000 9.119 3.230 81.191 6.460 GRST
GRN 3 12.454 155.000 10.044 2.410 82.726 4.820 GRST
GRN 4 16.440 250.200 13.000 3.440 76.680 6.880 GRST
S-39456 15.860 1.620 10.660 5.200 73.740 10.400 GRST
S-39457 14.860 1.600 1.020 13.840 26.230 58.910 PKST

BWB 3 21.111 393.000 11.990 9.121 63.469 15.420 WKST
BWB 4 22.004 723.000 11.900 10.104 59.566 18.430 WKST
Pond Free Stone 13.962 0.400 12.862 1.100 84.318 1.720 GRST
RS08A 17.200 0.250 15.110 2.090 79.230 3.570 GRST
RS08B 20.850 1.050 17.040 3.810 69.780 9.370 GRST
RS08C 15.910 0.330 12.310 3.600 77.530 6.560 GRST
WB 2 19.736 209.000 12.276 7.460 61.054 19.210 WKST
S-39400 3.200 0.090 2.690 0.510 37.800 59.000 WKST
S-39415 16.700 0.280 1.830 14.870 49.500 33.800 WKST
S-39433 5.400 0.950 2.710 2.690 53.100 41.500 PKST
S-39437 14.900 0.110 9.200 5.700 78.100 7.000 GRST
S-39438 17.300 0.210 14.020 3.280 76.500 6.200 GRST
S-39440 11.400 0.420 8.550 2.850 82.900 5.700 GRST
S-39446 6.600 0.100 1.620 4.980 52.100 41.300 WKST
S-39448 14.800 0.680 2.570 12.230 48.100 37.100 PKST
S-39454 15.860 785.000 1.890 13.970 36.840 47.300 WKST
S-39464 10.900 2.340 1.900 9.000 56.800 32.300 PKST

APPENDIX II: Joint Elastic-Electrical Measurement Results on the 36 Carbonate Samples Studied in This Paper
Sample 60 MPa 50 MPa

Vp Qp Vs Qs ρ F Vp Qp Vs Qs ρ F
Base Bed 2

41
84

61
.7

68

22
14

43
.8

73

3.
86

1

18
.1

25

41
79

70
.0

54

22
09

39
.9

58

3.
82

4

17
.9

54

Base Bed 3

41
64

64
.2

31

22
17

49
.2

44

3.
84

1

18
.0

34

41
54

67
.3

22

22
06

39
.8

34

3.
74

2

17
.5

67

Base Bed 4

41
49

27
.3

03

22
18

36
.2

77

3.
39

9

15
.9

57

41
44

28
.2

57

22
10

33
.2

82

3.
38

3

15
.8

82



Pa
ge


42

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

BWB 2

41
64

42
.7

15

22
02

29
.0

15

3.
91

9

18
.3

98

41
56

42
.7

33

21
97

28
.8

06

3.
89

5

18
.2

87

BWB 3

42
06

38
.2

99

22
46

31
.1

56

4.
27

5

20
.0

71

41
95

39
.6

66

22
41

32
.9

22

4.
24

7

19
.9

37

BWB 4

41
92

28
.6

05

22
50

26
.3

19

3.
83

8

18
.0

20

41
91

29
.8

54

22
49

23
.3

29

3.
78

8

17
.7

84

Pond Free
Stone

45
26

78
.0

47

24
54

11
4.

89
2

8.
86

0

41
.5

98

45
02

83
.9

82

24
41

10
2.

66
6

8.
81

2

41
.3

72

RS08A

42
18

27
.8

95

22
34

30
.0

72

7.
79

1

36
.5

79

41
70

25
.8

69

22
09

26
.9

55

7.
69

8

36
.1

41

RS08B

38
59

19
.6

26

18
73

17
.3

26

6.
48

4

30
.4

39

38
07

18
.9

39

18
33

17
.3

57

6.
43

0

30
.1

89

RS08C

47
86

12
.4

05

25
08

13
.9

95

13
.9

32

65
.4

08

47
37

11
.8

74

24
69

13
.1

68

13
.7

89

64
.7

37

WB 2

42
36

29
.5

12

23
69

36
.9

09

5.
03

1

23
.6

18

42
10

30
.4

22

23
65

34
.7

16

5.
00

1

23
.4

79

S-39400

      53
61

11
7.

09
0

27
15

20
.3

65

22
5.

22
1

10
57

.3
76

S-39415

      37
99

20
.1

37

24
35

17
.0

90

25
.6

38

12
0.

36
5

S-39433

      52
79

54
.4

59

29
00

32
.4

00

71
.2

96

33
4.

72
3

S-39437

      43
94

13
.4

47

23
35

27
.9

73

23
.6

75

11
1.

15
0

S-39438

      41
56

30
.8

36

25
12

32
.2

08

11
.9

98

56
.3

26

S-39440

      45
13

54
.2

88

24
03

58
.3

92

18
.0

03

84
.5

21

S-39446

      50
96

27
.0

10

26
90

21
.1

82

42
.2

04

19
8.

14
1

S-39448

      44
59

10
.4

11

23
86

10
.7

02

30
.6

85

14
4.

06
3

S-39454

      50
91

28
.7

87

26
85

43
.7

36

49
.0

68

23
0.

36
8

S-39464

      47
73

45
.6

12

24
49

28
.5

16

32
.3

01

15
1.

64
6



Pa
ge


43

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Alg 1.1

46
86

16
.8

32

26
15

16
.1

71

7.
27

5

34
.1

55

46
70

16
.9

52

25
95

13
.9

77

7.
09

5

33
.3

12

Alg 1.3

42
33

8.
98

4

23
78

10
.8

47

5.
78

8

27
.1

72

42
22

8.
98

9

23
37

10
.9

22

5.
64

1

26
.4

86

Bio 1.1

48
28

29
.3

51

26
35

32
.0

53

91
.5

64

42
9.

87
9

48
13

27
.9

46

26
29

28
.2

89

86
.9

15

40
8.

05
1

Bio 2.2

54
38

6.
12

2

25
92

13
.4

37

10
.1

11

47
.4

71

54
23

5.
91

7

25
98

12
.7

16

9.
95

3

46
.7

26

BM 1

59
55

38
.3

69

32
58

24
.2

06

54
.3

18

25
5.

01
4

59
42

37
.0

74

32
43

17
.5

62

52
.7

23

24
7.

52
6

BM 2

58
58

22
.7

44

32
16

12
.4

06

38
.2

92

17
9.

77
4

58
42

22
.9

05

32
14

12
.8

64

36
.3

61

17
0.

71
0

BM 3

62
84

67
.3

13

34
99

16
4.

73
1

85
.9

63

40
3.

58
2

62
62

72
.2

54

34
80

64
.4

58

83
.1

74

39
0.

48
8

BM 4

63
58

23
.9

27

35
35

32
.6

42

85
.8

11

40
2.

86
9

63
43

24
.5

34

35
21

29
.6

26

82
.7

45

38
8.

47
4

BV 2

49
69

23
.2

76

28
24

19
.1

22

13
.3

19

62
.5

32

49
58

24
.5

66

28
15

19
.9

20

12
.8

20

60
.1

88

GRN 1

66
59

96
.4

99

36
29

10
0.

42
9

23
1.

77
0

10
88

.1
22

66
39

10
0.

55
7

36
20

95
.8

41

21
1.

94
0

99
5.

02
3

GRN 2

55
66

11
1.

91
2

31
18

46
.6

62

24
.5

06

11
5.

05
2

55
56

11
8.

54
0

31
10

46
.7

86

23
.8

67

11
2.

05
2

GRN 3

54
78

54
.4

73

29
99

30
.2

08

19
.9

40

93
.6

15

54
64

56
.8

86

29
91

29
.6

70

19
.6

87

92
.4

27

GRN 4

49
01

18
.5

29

27
26

16
.9

89

8.
82

7

41
.4

42

48
78

17
.5

67

27
21

18
.9

99

8.
69

0

40
.7

96

S-39456

      59
63

12
3.

53
4

33
89

10
8.

92
6

19
.1

05

89
.6

92

S-39457

      62
85

73
.0

51

34
53

59
.0

61

88
.1

46

41
3.

83
1

Sample 40 MPa 30 MPa
Vp Qp Vs Qs ρ F Vp Qp Vs Qs ρ F

Base Bed 2

41
57

72
.1

56

21
94

37
.5

82

3.
78

6

17
.7

75

41
23

68
.2

74

21
74

34
.0

90

0.
00

0

0.
00

0

Base Bed 3

41
34

67
.4

19

21
95

47
.6

77

3.
68

7

17
.3

10

41
03

62
.9

31

21
74

32
.5

77

3.
67

4

17
.2

49

Base Bed 4

41
23

28
.5

53

22
00

33
.0

59

3.
37

4

15
.8

41

40
93

28
.2

55

21
81

27
.4

40

3.
36

8

15
.8

11



Pa
ge


44

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

BWB 2

41
28

40
.0

87

21
77

27
.8

49

3.
86

6

18
.1

49

40
94

38
.6

97

21
56

24
.3

93

3.
83

5

18
.0

05

BWB 3

41
77

40
.3

68

22
31

30
.3

61

4.
20

6

19
.7

45

41
39

36
.4

28

22
05

28
.0

87

4.
17

8

19
.6

15

BWB 4

41
85

31
.8

51

22
42

25
.9

97

3.
74

2

17
.5

68

41
82

35
.7

95

22
47

29
.3

08

3.
71

8

17
.4

54

Pond Free
Stone

44
77

91
.8

72

24
26

89
.9

46

8.
77

1

41
.1

78

44
28

89
.0

89

24
02

71
.4

26

8.
71

8

40
.9

31

RS08A

40
80

22
.2

29

21
49

19
.2

07

7.
46

6

35
.0

51

39
50

19
.2

54

20
42

16
.1

08

7.
59

2

35
.6

42

RS08B

37
34

17
.2

31

17
75

14
.9

29

6.
40

6

30
.0

77

36
26

15
.1

22

17
17

10
.0

60

6.
46

5

30
.3

53

RS08C

46
56

10
.8

62

24
31

12
.5

77

13
.6

93

64
.2

86

45
46

9.
61

9

23
81

9.
84

0

13
.5

25

63
.4

98

WB 2

41
79

29
.1

75

23
52

32
.1

62

4.
97

5

23
.3

55

41
38

28
.3

52

23
40

29
.9

91

4.
94

8

23
.2

30

S-39400

53
36

10
3.

27
1

27
09

17
.4

90

24
3.

59
6

11
43

.6
43

52
97

71
.9

27

26
94

16
.1

06

27
8.

89
6

13
09

.3
71

S-39415

37
65

17
.3

57

24
12

16
.0

28

24
.1

83

11
3.

53
7

37
08

14
.1

96

23
77

12
.6

02

25
.4

07

11
9.

28
1

S-39433

52
47

48
.8

76

28
56

24
.0

79

53
.6

39

25
1.

82
8

51
96

38
.9

17

27
58

20
.3

37

63
.5

16

29
8.

19
5

S-39437

43
42

12
.3

19

23
21

22
.6

31

23
.7

77

11
1.

62
9

42
47

10
.4

19

22
79

22
.1

69

22
.0

65

10
3.

59
0

S-39438

41
14

28
.7

66

24
79

18
.6

72

11
.9

05

55
.8

91

40
50

22
.7

25

23
67

17
.3

98

12
.0

45

56
.5

50

S-39440

44
82

46
.4

32

23
91

54
.7

39

17
.8

13

83
.6

27

44
22

32
.8

96

23
46

41
.7

62

17
.7

90

83
.5

22

S-39446

50
60

26
.4

35

26
48

18
.9

32

42
.0

46

19
7.

40
0

49
88

22
.5

59

25
84

15
.8

47

41
.7

99

19
6.

23
8

S-39448

44
09

10
.0

94

23
72

9.
80

6

31
.2

73

14
6.

82
2

43
31

9.
17

3

23
45

9.
54

6

30
.8

88

14
5.

01
5

S-39454

50
64

27
.5

04

26
75

40
.7

02

49
.7

57

23
3.

59
9

50
14

23
.7

49

26
25

28
.6

90

50
.0

67

23
5.

05
7

S-39464

47
36

41
.4

51

24
21

19
.3

84

32
.5

25

15
2.

70
0

46
69

32
.6

49

23
53

17
.0

42

30
.9

57

14
5.

33
8

Alg 1.1

46
38

17
.0

70

25
75

13
.7

80

6.
81

6

31
.9

98

45
97

17
.2

28

25
60

15
.5

13

6.
56

9

30
.8

41



Pa
ge


45

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Alg 1.3

42
03

8.
67

4

23
19

11
.4

89

5.
33

2

25
.0

32

41
68

8.
20

8

23
33

11
.7

08

5.
25

8

24
.6

86

Bio 1.1

48
06

36
.4

00

26
15

25
.9

88

81
.5

73

38
2.

97
2

47
90

31
.0

00

26
01

25
.7

09

73
.0

73

34
3.

06
8

Bio 2.2

54
08

5.
80

5

25
89

9.
81

5

9.
67

8

45
.4

38

53
60

5.
37

2

25
52

12
.0

99

8.
97

4

42
.1

30

BM 1

59
16

34
.9

93

32
06

18
.5

02

51
.1

65

24
0.

21
1

58
87

31
.2

20

32
05

20
.2

27

49
.5

56

23
2.

65
7

BM 2

58
13

23
.0

05

31
95

14
.3

34

34
.9

71

16
4.

18
1

57
68

21
.9

96

31
88

11
.9

00

33
.8

59

15
8.

96
3

BM 3

62
39

65
.4

64

34
59

74
.9

56

79
.8

76

37
5.

00
5

62
14

54
.3

09

34
55

84
.3

84

75
.8

30

35
6.

00
9

BM 4

63
19

23
.9

33

35
11

29
.6

65

79
.6

26

37
3.

83
1

62
93

21
.1

13

34
96

25
.9

37

74
.9

46

35
1.

85
9

BV 2

49
38

25
.1

37

28
09

17
.1

55

12
.7

84

60
.0

17

49
19

25
.2

54

27
75

17
.8

03

11
.7

28

55
.0

62

GRN 1

66
13

86
.0

26

36
06

79
.1

80

19
4.

14
0

91
1.

45
5

65
82

69
.1

44

35
81

72
.3

44

17
4.

93
0

82
1.

26
8

GRN 2

55
37

11
5.

10
7

31
04

43
.3

31

23
.5

90

11
0.

75
1

55
11

10
1.

02
8

30
87

35
.7

99

22
.7

94

10
7.

01
4

GRN 3

54
49

51
.7

69

29
81

28
.5

55

19
.1

87

90
.0

80

54
24

48
.9

53

29
69

27
.7

62

17
.2

38

80
.9

30
GRN 4

48
57

16
.9

34

27
07

18
.3

64

8.
61

1

40
.4

25

48
34

16
.2

43

26
90

18
.6

41

8.
52

3

40
.0

14

S-39456

59
24

73
.8

73

33
52

66
.2

37

20
.4

54

96
.0

28

58
62

41
.3

90

32
95

41
.6

88

17
.8

05

83
.5

90

S-39457

62
61

69
.9

57

34
29

51
.6

71

85
.8

85

40
3.

21
5

62
14

52
.0

24

33
93

48
.5

22

87
.0

54

40
8.

70
6

Sample 20 MPa 10 MPa
Vp Qp Vs Qs ρ F Vp Qp Vs Qs ρ F

Base Bed 2

40
81

60
.0

98

21
46

28
.7

61

3.
71

6

17
.4

46

39
89

39
.3

34

20
81

20
.0

07

3.
67

6

17
.2

57

Base Bed 3

40
63

53
.6

71

21
50

34
.8

89

3.
60

9

16
.9

45

40
11

39
.2

24

21
03

21
.7

60

3.
75

3

17
.6

20

Base Bed 4

40
53

27
.5

21

21
57

24
.8

10

3.
36

4

15
.7

91

39
82

21
.9

01

21
10

19
.9

58

3.
36

6

15
.8

03

BWB 2

40
47

35
.5

54

21
20

20
.3

20

3.
79

2

17
.8

00

39
46

26
.2

69

20
43

16
.5

82

3.
75

5

17
.6

31



Pa
ge


46

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

BWB 3

40
90

33
.8

03

21
82

23
.8

46

4.
13

4

19
.4

07

39
93

23
.8

08

21
10

16
.6

51

3.
95

7

18
.5

77

BWB 4

41
76

41
.1

99

22
48

22
.5

10

3.
66

9

17
.2

26

41
60

42
.8

62

22
35

25
.3

96

3.
58

7

16
.8

42

Pond Free
Stone

43
64

74
.4

34

23
69

54
.1

62

8.
65

1

40
.6

16

42
23

42
.9

02

22
89

24
.9

24

8.
60

6

40
.4

04

RS08A

37
83

16
.6

62

19
41

14
.9

35

7.
28

9

34
.2

18

35
76

9.
44

4

17
90

9.
04

6

6.
92

6

32
.5

14

RS08B

34
59

12
.1

53

16
20

11
.0

41

6.
37

4

29
.9

24

32
61

9.
94

7

14
89

10
.2

06

6.
12

1

28
.7

36

RS08C

43
89

8.
22

4

23
78

9.
12

2

13
.0

98

61
.4

93

42
26

7.
27

9

21
46

9.
17

2

12
.3

65

58
.0

52

WB 2

40
78

26
.2

66

23
18

25
.5

41

4.
89

9

23
.0

00

39
98

22
.0

95

22
88

20
.2

92

4.
84

0

22
.7

21

S-39400

52
48

45
.7

85

26
49

15
.6

45

18
4.

34
2

86
5.

45
5

51
76

26
.0

17

25
98

10
.4

80

15
4.

89
4

72
7.

20
2

S-39415

36
24

12
.0

52

23
34

10
.4

62

24
.5

37

11
5.

19
8

34
35

7.
79

3

21
96

9.
66

9

25
.3

76

11
9.

13
7

S-39433

51
13

27
.4

43

26
57

18
.5

60

39
.5

82

18
5.

83
2

49
42

16
.5

32

26
29

15
.1

13

43
.5

80

20
4.

60
3

S-39437

41
24

7.
38

7

21
82

21
.5

21

22
.5

91

10
6.

06
3

39
64

5.
56

6

20
96

19
.0

92

21
.3

91

10
0.

42
9

S-39438

39
61

18
.4

07

23
47

17
.3

08

11
.7

50

55
.1

62

37
79

12
.1

42

20
23

15
.3

83

10
.6

47

49
.9

86
S-39440

43
19

19
.7

53

22
81

33
.0

76

17
.4

14

81
.7

57

39
18

7.
27

3

21
37

13
.8

24

15
.3

79

72
.2

00

S-39446

48
62

16
.6

49

24
86

12
.3

00

39
.5

08

18
5.

48
4

46
25

10
.8

55

23
73

7.
73

5

34
.3

54

16
1.

28
6

S-39448

42
25

7.
95

9

23
32

9.
31

2

28
.4

49

13
3.

56
4

40
21

5.
43

4

22
42

9.
08

9

25
.0

78

11
7.

73
7

S-39454

49
39

18
.2

63

25
47

23
.9

92

47
.4

80

22
2.

90
8

47
67

11
.0

24

23
79

16
.6

09

39
.3

93

18
4.

94
4

S-39464

45
64

23
.3

09

23
07

16
.2

84

30
.2

86

14
2.

18
7

43
51

13
.3

27

22
34

12
.2

18

27
.4

66

12
8.

94
7

Alg 1.1

45
31

16
.1

33

25
49

13
.4

71

6.
24

9

29
.3

36

43
95

12
.4

45

24
28

13
.1

29

5.
87

5

27
.5

80

Alg 1.3

41
32

7.
60

4

23
66

10
.6

01

5.
33

0

25
.0

25

40
56

7.
44

8

23
60

8.
72

1

5.
20

4

24
.4

31



Pa
ge


47

https://journals.e-palli.com/home/index.php/ajgt

Am. J. Geo Spat. Technol. 4(1) 22-48, 2025

Bio 1.1

47
32

23
.0

71

25
67

19
.4

42

66
.4

10

31
1.

78
5

46
53

18
.0

91

25
30

17
.5

98

64
.0

52

30
0.

71
2

Bio 2.2
53

56

4.
98

1

25
57

12
.0

28

8.
70

8

40
.8

84

53
54

5.
91

7

23
40

8.
50

7

8.
44

8

39
.6

64

BM 1

58
43

26
.7

30

32
05

14
.6

48

46
.9

27

22
0.

31
5

57
61

21
.2

76

31
50

14
.3

21

43
.7

15

20
5.

23
5

BM 2

57
17

19
.5

52

31
73

8.
25

6

32
.0

70

15
0.

56
2

56
02

14
.8

12

29
86

10
.6

86

29
.5

90

13
8.

92
2

BM 3

61
82

45
.5

52

34
33

36
.0

36

70
.8

67

33
2.

70
9

61
18

36
.8

00

33
88

40
.6

02

65
.1

48

30
5.

85
9

BM 4

62
65

18
.8

22

34
72

23
.5

38

69
.2

65

32
5.

18
8

62
03

16
.4

31

34
48

21
.1

01

61
.8

81

29
0.

52
1

BV 2

48
69

23
.9

92

27
64

18
.5

78

11
.7

22

55
.0

31

47
87

21
.0

56

26
99

19
.0

12

10
.8

08

50
.7

40

GRN 1

65
43

56
.5

93

35
55

67
.4

22

15
0.

99
0

70
8.

87
3

64
66

43
.9

06

35
00

41
.3

45

12
5.

06
0

58
7.

13
6

GRN 2

54
78

80
.8

62

30
62

33
.8

84

21
.8

47

10
2.

56
8

53
92

50
.3

79

30
06

23
.2

49

20
.8

28

97
.7

84

GRN 3

53
81

41
.7

36

29
43

22
.4

43

17
.8

58

83
.8

40

52
95

29
.4

73

29
01

19
.3

04

17
.4

49

81
.9

20

GRN 4

47
90

16
.2

64

26
72

16
.9

54

8.
32

2

39
.0

71

47
03

13
.7

43

26
21

18
.4

88

8.
09

2

37
.9

89
S-39456

57
50

19
.5

90

32
15

21
.1

33

18
.5

05

86
.8

78

54
27

7.
43

0

31
63

17
.9

13

15
.8

63

74
.4

76

S-39457

61
47

35
.4

27

33
66

36
.8

83

80
.1

37

37
6.

22
8

60
53

24
.2

06

32
97

16
.1

78

61
.5

66

28
9.

04
1
