American Journal of
Life Science and Innovation (AJLSI)

Development and Performance Evaluation of  a Tractor-Drawn Multi-Crop Planter
Bedasa Waldaho1*, Adesoji M. Olaniyan2

Volume 2 Issue 3, Year 2023
ISSN: 2833-1397 (Online)

DOI: https://doi.org/10.54536/ajlsi.v2i3.2151
https://journals.e-palli.com/home/index.php/ajlsi

Article Information ABSTRACT

Received: October 10, 2023

Accepted: November 07, 2023

Published: November 14, 2023

The study was undertaken development and performance   of  the planter capable of
planting maize, common bean and sorghum seeds at predetermined spacing and depths.
Physical properties of  seeds involved in the study were investigated to optimize the design
of  the planter’s components. The planter, consists of  a frame, seed hopper, seed metering
devices, seed tube, adjustable furrow opener, adjustable furrow covering device, and drive
wheels. The investigation revealed that the sphericity of  maize, common bean and sorghum
were 64.8, 72.4 and 81%, respectively. Percentages of  mechanically seed damaged by the
planter were zero for all crops. Germination test was conducted to assess the magnitude
and extent of  invisible seed damage inflicted by the planter indicated mean percentage seed
germination of  98.5, 94.5 and 97.3% for maize, common bean, and sorghum, respectively.
The reduction in percentage germination of  maize, common bean and sorghum were zero,
when compared with that did not passes through the machine for all the seeds tested. Based
on the above results, it is concluded that the planter can be efficiently and effectively used by
the majority of    the farmers and other stakeholders in the study area.

Keywords

Capacity, Efficiency, Multi-Crop,
Planter

INTRODUCTION
Planting is an art of  placing seeds in the soil to have good
germination. It was began with the use of  hands and later
the use of  stones, hand tools and mechanized form of
planting (Yasir et al., 2012). Manual methods of  planting
resulted in low seed placement, low spacing efficiency,
and health issues for the farmer considering the size of
the farm land (Kumar et al., 2015; Soyoye et al., 2016).
Seed planting machine is a device which helps in sowing
seeds in a desired position, there by assisting the farmers
in saving time and reducing cost.
 The basic objective of  sowing operation is to put the
seed in rows at desired depth and seed to seed spacing,
cover the seeds with soil and provide proper compaction
over the seed (Soyoye et al., 2016). However, in fabricating
the form of  this mechanized planting equipment, some
properties of  the plant which is to be planted must be
determined in order to accurately specify the design
considerations ( Jouki and Khazaei, 2012). The physical
properties such as seed size, shape, axial dimensions,
roundness and sphericity helps to determine the
maximum size of  the cup in the seed plate, the weight
help in the material selection for the frame of  the planter,
the bulk density and moisture content helps to know the
interaction between the seed and the material used for the
hopper of  the planter at maximum heat level (Jayan and
Kumar, 2004).
The basic objective of  sowing operation is to put the seed
in rows at desired depth and seed to seed spacing, cover the
seeds with soil and provide proper compaction over the
seed (Soyoye et al., 2016). However, in fabricating the form
of  this mechanized planting equipment, some properties
of  the plant which is to be planted must be determined
in order to accurately specify the design considerations

(Jouki and Khazaei, 2012). The physical properties such
as seed size, shape, axial dimensions, roundness and
sphericity helps to determine the maximum size of  the
cup in the seed plate, the weight help in the material
selection for the frame of  the planter, the bulk density
and moisture content helps to know the interaction
between the seed and the material used for the hopper
of  the planter at maximum heat level (Jayan and Kumar,
2004).  The design and manufacture of  tractor-mounted
planters has eliminated most of  the limitation attached
to the manual methods. Thus, the need for appropriate
technology to deliver optimal yield while using fewer
resources is very essential. Hence, this research project
is intended to bridge the existing technology gaps in the
area of  crop establishment. The objectives of  this thesis
research was to develop and characterize the physical
properties of  selected seeds  for  tractor- drawn multi-
crop planter and evaluate performance of  the machine.

MATERIALS AND METHODS
Experimental Site and Experimental Crops
Fabrication of  the prototype planter was done at Fadis
Agricultural Research Center (FARC) metal workshop
(Harar) maize, common bean and sorghum seeds were
used to design the planter that was fabricated at FARC
metal workshop. The crops, maize, common bean and
sorghum, were selected for the study because of  their
dominance among row planted crops in the study areas.
Hence, the planting machine was designed to plant
these seeds. The varieties of  maize, common bean and
sorghum seeds were Melkassa-2, Awash-2 and Melkem,
respectively. Selected seeds were taken from Fedis
Agricultural Research Centre, crop research process and
the seeds had germination percentages of  98.5%, 94.5%,

1 Oromia Agricultural Research Institute, Fades Agricultural Research Centre P.O. Box 904, Harar, Ethiopia
2 Haramaya University Institute of  Technology P.O. Box 38 Dire-dawa, Ethiopia
* Corresponding author’s e-mail: bedasawaldawo12@gmail.com



Pa
ge


31

https://journals.e-palli.com/home/index.php/ajlsi

Am. J. Life Sci. Innov. 2(3) 30-38, 2023

and 97.33%, for maize, common bean and sorghum,
respectively.

The Planting Machine
The machine was designed for four wheels 30 hp tractor
and has three different replaceable seed metering cups
that were designed to handle maize, common bean and
sorghum seeds. Since the planter was designed for three
different crops and was adjustable as particular crop’s row
spacing requirements.

Physical Properties of  Selected Crops
The physical properties of  seeds are important factors
for the design of  crop planter. Performance of  seed
metering mechanism in terms of  picking, metering and
dropping was influenced by the physical and Mechanical
properties of  seeds. Therefore, seed properties relevant
to the design of  planter were identified and determined.
The general procedure was used in determining seed
physical parameters i.e. Geometric mean diameter (Ds),
Sphericity (S) and Volume were computed by taking a
specified number of  randomly selected seed. Then their
three principal diameters (major, intermediate and minor
lengths) denoted as mean length (L), mean width (W) and
mean thickness (T) respectively were measured using a
micrometer of  0.01 mm accuracy. The measured values
were then used to determine Geometric mean diameter
(Ds) using equation (1) by (Singh et al., 2005) as well as
Mean volume (V) and mean seed sphericity (Sm). Thirty
(30) grain samples were selected randomly from the
sample and dimensions were measured. Length, width
and thickness of  the seed were taken using digital vernier
caliper. The mean and standard deviation of  dimensions
were calculated.

Size, Sphericity and Surface Area
The volume and sphericity of  the individual seeds were
calculated using the measured larger diameter, medium
diameter and smaller diameter of  the seeds and equations
given below (El-Raie et al., 1996).
Physical property, that is, geometrical mean
Dg = ∛(L×W×T)                (1)
V = π/6  (L×W×T)                (2)
Sm = (∛(L×W×T)/L)×100               (3)
Where:
L=Length (mm)
W = width (mm)
T = Thickness (mm)
V = volume (mm3)
Dg = geometric diameter (mm)
Sm = seed sphericity

Bulk Density of  the Crops
The bulk density was found by taking crops in a container
of  cylindrical shape. The volume of  the container was
found by measuring diameter and height for cylindrical
container. The weight of  the grain in the container was
found separately. The bulk density was calculated, three

samples from each   selected crops were taken and
average bulk density was calculated (Varnmakasti et al.,
2007) as shown equation (4)
Bd = (WC )/VC                (4)
Where:
Bd = Bulk density in kg/m3 or g/cm3

Wc = Weight of  sample in kg or g
Vc =   Volume of  sample in m3 or cm3

Angle of  Repose of  the Crops
The equipment used for measuring angle of  repose
consisted of  a funnel with an adjustable throat opening
mounted on a stand. The funnel was filled with seeds
by keeping its adjustable throat closed. The throat was
fully opened to allow free flow of  seeds over and around
the plate mounted beneath the funnel. At the end of
process, a heap-cone of  the seed was formed on the
plate. From the heap-cone, base diameter and height of
cone were measured. For free-flowing agricultural grains,
angle repose is assumed to be approximately 28. For
free-flowing grains the angle of  repose can be assumed
to be equal to that of  the angle of  internal friction. The
angle of  repose was calculated using the equation (6),
(Varnmakasti et al., 2007)
θ = tan-1(2H/D)                 (5)
Where:
𝜃 = is angle of  repose, degree
H =is height of  cone, mm
D =is base diameter of  cone, mm

Thousand Grain Mass
In the laboratory thousand (1000) grains were selected
randomly and then weighed on the sensitive weight
balance to obtain the thousand grain mass in gram. The
ten sample of  each crop was weighed and mean thousand
grain mass of  each crop was found out.
Moisture content of  soil
The samples were collected from 0 to 15 cm depth of
soil surface before operations for determination of
moisture content and bulk density. The soil moisture
was determined by oven dry method. Five samples were
collected randomly from the test plots. The samples were
kept in oven for 24 hours at temperature of  105°C and
weighed before and after drying. The moisture content
(Dry basis) was determined by the following formula
(Rangapara, 2014).
Mc (%) =  (Ws-Wd)/Wd *100              (6)
Where:
Mc=Moisture content of  the Soil sample
Ws= Weight of  the soil sample, and
Wd= Weight of  dry soil sample

Bulk Density of  Soil
To determine bulk density of  a soil, metallic core sampler
was used to take sample from field having 8cm diameter
and 12 cm height. The samples were weighed and dry
weights of  the samples were calculated with the help of
moisture content (d.b.). The ratio of  dry weight of  soil



Pa
ge


32

https://journals.e-palli.com/home/index.php/ajlsi

Am. J. Life Sci. Innov. 2(3) 30-38, 2023

to the volume gave the bulk density. Bulk density of  soil
was calculated by using following formula (Rangapara J,
2014).
Bds = (WS (g))/(VS)               (7)
Where :
Bds= Bulk dencity of  soil in ( g/cm3 )
Ws = weight of  soil samples (g)
Vs= volume of  soil in core sampler (cm3)

Description of  the Machine and Design Considerations
Overall Structure of  the Machine
The developed Tractor drawn multi-crop planter consists
of  the frame, seed hoppers, drive/ transport wheels, seed
metering devices seed discharge tubes, furrow openers,
and furrow covering devices. Tractor drawn multi crop

planter was designed as a functional and experimental
unit. The design of  machine components were based
on the principles of  operations. It was compared with
the conventional method, to give a correct shape of  the
planter components. The mechanical design details were
also given with due attention so that it gaves adequate
functional strength for the design of  the machine. To
achieve the best performance from the planter, the
important factors were optimized by proper design
and selection of  the components required to suit the
requirements of  the crop needs and Figure 1 and Figure
2 shows assembly parts and detail views of  the planter
respectively. 1) Ground wheel (2) Hopper (3) Frame (4)
Furrow covering (5) Tractor hitching position (6) Ground
wheel shaft.

Figure 1: Assembly drawing of  the prototype planter.

Figure 2: Detail views (Top, front and side) of  the prototype planter

Working Principles of  the Machine
The seed metering mechanism of  the planter is a cup
type vertical drive. As the tractor moved forward the
seed-metering device is rotated by a chain-sprocket
arrangement through drive wheels. One operator was
required to operate the machine. Seed to seed spacing in
the field is regulated by the rate of  rotation of  the seed-
metering plates. As the metering plate rotated i.e. the seed

spacing of  crops were maintained by the planter drive
wheel diameter and the size of  sprockets attached to the
planter drive wheel and shaft of  the seed-metering plate
and the teeth ratio was 2:1 drive to driven sprocket.

Design Considerations for the Machine
The following factors were considered in the design of  the
planter, such as the physical properties of  the agricultural



Pa
ge


33

https://journals.e-palli.com/home/index.php/ajlsi

Am. J. Life Sci. Innov. 2(3) 30-38, 2023

material like length, width, thickness etc. which varies
in shape, density and size. The ease of  fabrication of
component parts, the safety of  the operator, Resistivity
of  metering device to corrosion and, the operation of  the
machine shall be simple for small scale or rural farmers.
Availability of  the component parts shall also be available
at the local market.

Performance Test and Evaluation
After development and assembly of  the prototype a
preliminary test run was conducted to check that the
machine is functionally acceptable or not . Fortunately,
the planter had good stability in terms of  operation and
performed for the intended job accordingly. Two sets of
tests were performed; laboratory investigation to calibrate
the machine in terms of  seed rate, seed damage, and seed
spacing, and field test carried out to obtain actual overall
performance of  the machine.

Laboratory Tests
Calibration of  the Machine
The multi-crop planter was calibrated in the laboratory
to determine the seeding rate, and mechanical damage of
crops for a particular area. The calibration of  the planter
was conducted to test and adjust the planter to obtain
desired plant population. The diameter of  the ground
wheel was 72 cm. The nominal width of  the planter was
calculated by:
W= n×RS                (8)
W= 4×0.7m=2.8 m
Where :
W= width of  the implement
n= number of  furrow opener
RS= row spacing

Evaluation of  Seed Damage
Each of  the hoppers was loaded with 4 kg of  seeds
and drive wheels were rotated 20 times with speed of
corresponding to 1.6 m/s. A stop watch was used to
measure the time taken to complete the revolutions.
Paper bags were placed on each of  the seed tubes/
spouts to collect the seeds metered and discharged. The
seeds collected in the paper bags at the end of  the 20th
revolution of  the wheel were examined for any external
damage or visible crack to establish the performance of
the metering cups. Germination test, on randomly selected
seed samples, were conducted at Fedis Agricultural
Research Center laboratory to assess the level of  internal
damage by the metering mechanism. Percentage external
seed damage was determined by equation given below.
Md = (Stds/Sns) ×100               (9)
Where:
Md = percentage damaged seed
Stds = total number of  damaged seeds (external)
Sns = total number of  seeds

Field Performance Evaluation
Evaluation of  Seed Spacing/Distribution
The prototype planter was evaluated in the field using

seeds of  maize, common bean and sorghum at forward
speeds of  2, 4 and 6 km/h.  At the end of  each test
run, measurement of  successive seed spacing was made,
seeds spacing were measured from the soil surface
and preparation for the subsequent tests. Each test
run was replicated three times over a distance of  2 m.
Measurements made were used to calculate the mean
seed spacing, seed miss index, seed multiple index, quality
of  feed index and precision in spacing. Mean values and
standard deviation of  seed spacing were determined to
pattern and uniformity of  seed distribution in the rows
(Kachman and Smith, 1995).
Theoretical spacing, xref, in the design of  wheels and
metering devices was used as actual seed spacing and the
measured and its mean values of  spacing were compared
against the theoretical values.The observed spacing were
classified into five divisions:-
Division I = 0 to 0.5 of  xref, this indicated multiple seeds
dropped at the same spot or seed spacing less than or
equal to half  of  the desired spacing.
Division II = 0.5 to 1.5 of  xref, this indicate single seed
spacing close to the theoretical  seed spacing.
Division III =1.5 to 2.5 xref, these are single skips.
Division IV = 2.5 to 3.5 xref, these are double skips.
Division V = over 3.5 xref, these are triple skips etc.
Seed spacing accuracy estimation was based on the
following parameters and equations (Kachman and
Smith, 1995):

Missing Index (MISI)
 The missing index was estimated using distance measured
between seeds dropped in the row and spaced at a
distances greater than 1.5 times the theoretical (nominal)
spacing and calculated using the equation below:
MISI (%) = (nIII+n(Iv)+nv/N)×100             (10)
Where:
MISI = missing index
nIII, nIV, nV = the number of  spacing in division III, IV,
and V
N = total number of  spacing

Multiples Index (MULI)
The multiple index was estimated by measuring the
distance between consecutive seeds, the spacing less than
or equal to half  of  the theoretical (nominal) spacing and
calculated as follows:
MULI (%) =  (nI/N)×100                  (11)
Where:
MULI = multiple index
nI = the number of  spacing in region I and
N = total number of  spacing

Quality of  Feed Index (QFI)
Quality of  feed index, as an indicator of  uniformity of
seed distribution in the row, was estimated using the data
obtained by measuring the consecutive distance between
seeds in the row with spacing more than half  but no more
than 1.5 times the theoretical spacing and calculated using
the equation given below:



Pa
ge


34

https://journals.e-palli.com/home/index.php/ajlsi

Am. J. Life Sci. Innov. 2(3) 30-38, 2023

QTF I (%) =  (nII/N)×100             (12)
Where:
QTFI = quality of  feed index
nII = the number of  spacing in division II and
N = total number of  spacing

Precision Index (PREC)
Precision index is the coefficient of  variation of  the
spacing between the nearest seeds in a row that were
classified as singles after omitting the outliers consisting
of  misses and multiples (Singh et al., 2005). Precision is
similar to a coefficient of  variation for the spacing that
are classified as singles (i.e. seeds in division II). The
percentage precision in spacing was calculated as follows:
PREC (%) =  (SII/Xref  )×100            (13)
Where:
PREC = precision
SII = the standard deviation of  the n observations in zone II
Xref  = the theoretical spacing.

Field Performance and Capacity
Field test was conducted on a soil prepared using disc
plough and harrowed by disc harrow. The depth of
planting was measured along the row at a distance of
2m at three randomly selected locations/points. The
Planter was operated without covering mechanism. Field
capacity and efficiency were determined in accordance to
the recommendation made by Kepner (1978) and using
relevant parameters that included effective operating
time, turning time and time losses due to obstructions on
the field. A plot of  20 m by 30 m was used for each crop,
on average, about nine passes with inter-row spacing of
0.7 m was used to assess field capacity and field efficiency
for both maize and sorghum. From the data gathered,
working speed (km/h), effective field capacity (ha/h) and
field efficiency (%) were estimated using   equations  104,
105 and  106.

Field Capacity and Field Efficiency
When the implement has been satisfactorily set, each test
plot should be completed without stopping unless this is
necessary due to adjustments, breakdowns. Measurements
are made of  draft, forward speed and wheels lip. Where
applicable, width and depth of  work and total working
area and time should be recorded.
The time lost in the field due to turning and other factors
including failure to use the full width of  the implement
will affect field efficiency (FAO, 1994). This is calculated
as follows:

Field Capacity
Field capacity was determined using the following
formula (Hunt, 1995)
Theoretical field capacity, Cth = (W×S/10), (ha/h)     (14)
Where:
W = rated width of  the planter (m)
S = rated forward speed of  machine (km/h)
Effective field capacity, Ceff  = A/10,000T, (ha/h)       (15)
Where:

T = total time for the planting operation, hr
A = total area planted, ha
Field Efficiency
Field efficiency,(%) e =(Ceff/Cth )×100            (16)
Where :
e= field efficiency
Cth= theoretical field capacity
Ceff  = effective field capacity

Wheel Slip
The wheel slip was calculated by recording total number
of  revolutions at no load and total number of  revolutions
at full load. Wheel slip represents a loss of  forward
motion of  the implement and it represents the loss of
power. Wheel slip for any given load is determined by the
expression of  (Rangapara J., 2014).
Wheel slip=(mo-m1/mo) ×100            (17)
Where:
mo = wheel revolution with no load
m1 = wheel revolution with load

Experimental Design
The experimental design was a split-plot design according
to the principle of  factorial experiment with three
replications. The three levels of  seed types was assigned to
main plot,  and the three levels of  forward speed of  planter
was assigned to sub plot, and each with three replications.
The experiment design was laid as 32 with three replications
and had total of  27 test runs (3x3 x3 = 27).

Statistical Analysis
The data were subjected to analysis of  variances following
a procedure appropriate for the design of  the experiment
and using SAS statistical software. The treatment means
that were different at 5% levels of  significance were
separated using least significant difference (LSD 5%) test.
The least significant difference (LSD) test was performed
for the mean values of  actual seed spacing, seed miss index,
seed multiple index, quality of  feed index and precision
spacing in relation to seed type, and forward speed.

RESULTS AND DISCUSSIONS
This study was undertaken to develop and the performance
evaluation of  the planter capable of  planting maize,
common bean and sorghum seeds at predetermined
spacing and depths. Physical properties of  seeds involved
in the study were investigated to optimize the design of
the planter’s component parts. Performance indicators
such as spacing indices that include seed multiple index
(MULI), seed miss index (MISI), quality of  feed index
(QTFI) and precision (PREC) in seed spacing were used
to assesses performance of  the  planter. This section
provides the physical properties of  the seeds, soil and the
results of  the performance evaluation of  the machine.

Physical Properties of  Soil of  Experimental Site
Moisture Content and Bulk Density of  Soil
During conducting the experiments, the soil conditions
of  the experimental field were studied and different



Pa
ge


35

https://journals.e-palli.com/home/index.php/ajlsi

Am. J. Life Sci. Innov. 2(3) 30-38, 2023

parameters were calculated (Table 1). Moisture content on
dry basis of  soil was measured by oven dry method. Five
soil samples were taken randomly at 5 different locations
in the plot using core sampler of  8.0 cm diameter and 12
cm height.
Moisture content at 5 different places was found to be
17.43, 18.18, 17.8, 18 and 18% on wet basis. The average
moisture content of  the experimental field was 17.88%.
Bulk density of  soil was calculated from data obtained by

core sampler. Bulk density of  soil was found to be 1.41,
1.48,1.47, 1.48 and 1.48 gm/cm3, respectively (Table:3).
Average value of  bulk density of  experimental plot was
obtained 1.46gm/cm3

Physical Properties of  the Seeds
The varieties of  crops used in the study were Melkassa-2
(maize), Awash 2 (common bean) and Melkem (sorghum).
Table 2 gives the mean values and the standard deviations

Table 1: Moisture content and bulk density of  soil
Observations Weight of  a soil(gm) Weight of  soil after

oven dried(gm)
MC (%) Bulk Density (gm/cm3)
%Wb %Db

1 875.25 712.05 17.43 21.1 1.41
2 892.26 730 18.18 22.2 1.48
3 886.2 728.5 17.8 21.65 1.47
4 890.32 729.5 18.0 22.04 1.48
5 892.2 731 18.0 22.05 1.48
Average 887.24 724.21 17.88 21.1 1.46
SD 9.08 8.26 0.23 0.81 0.31

Table 2: Physical properties of  maize, common bean and sorghum seeds
Physical properties Sample size Maize Common bean Sorghum Unit
Larger dia (x) 30 10.84±0.15 9.26±0.07 4.72±0.1 mm
Medium dia (y) 30 8.48±0.15 6.36±0.12 4. 27±0.18 mm
Smaller dia (z) 30 3.66±0.11 5.11±0.66 2.78±0.10 mm
Volume (V) 30 175.95±54.50 157.58±21.04 29.34±4.70 mm3

Geometric dia 30 6.95±0.46 6.70±0.29 3.83±0.16 mm
Sphericity 30 64.8± 7.14 72.4±2.87 81±2.8 %
Thousands seed weight 10 294±3.14 161±1.44 29±0.70 gm

of  Length, width, thickness, volume, geometric diameter,
sphericity, and thousands seed weight.
The sphericity of  maize, common bean and sorghum were
64.8, 72.4 and 81 %, respectively (Table 2), indicating that
all seeds had more or less spherical shape. Hence, it was
decided to have metering devices with cells of  circular
shape with depths equal to the length or major diameters
of  the seeds of  the crops. In general, the dimensions of
metering device cells were dependent up on length or major
diameter of  maize, common bean and sorghum seeds.

Field Performance Evaluation
Seed Spacing
The Seed Missing Index
The analysis of  variance (ANOVA) revealed that the
planter forward speed and the interaction of  planter
forward speed with seed type had significant effect (p <
0.05) on seed missing index. Table 3 show the effect of
speed of  operation, seed type and the combined effect of
speed on mean percent of  seed miss index.
Operational speed had significant effect on percent of

Table 3: Effects of  planter operating speed on missing index (MISI)
Parameter Source of  variation Measure of  differences

Speed level (km/hr) Crop type LSD (5%) SE
Maize Common bean Sorghum

Missing (%) 2 5.87a 2.70a 5.59ab 3.06 0.99
4 6.33bc 6.00b 5.10ab

6 10.77d 9.00cd 7.00bc

Means followed by the same letter (or letters) do not have significant difference at 5% level of  probability

missing index at p < 0.05. However, the level of  effect
varied with crop type. Increasing speed of  operation

from 2 km/hr. to 4km/hr. had no a significant   effect on
the percent missing index on both maize and sorghum



Pa
ge


36

https://journals.e-palli.com/home/index.php/ajlsi

Am. J. Life Sci. Innov. 2(3) 30-38, 2023

crops, while the effect of  increasing operational speed
from 2 km/hr to 6 km/hr  for  common beans and maize
had significant effect while  for sorghum did not show
statistically significant effect  on percent missing index
(Table 3). In general, increase in operational speed tended
to increases percent missing index when planting both
maize and common bean, while did not show significant
effect on sorghum seed using the planter. The highest
percent seed missing index of  10.77, 9.00, and 7.00% were
recorded with maize, common bean and sorghum seeds,
respectively, at the planter forward speed of  6 km/hr,
whereas the lowest percent seed missing index of  5.87, 2.70
and 5.10% were obtained from maize, common bean and

sorghum seeds, respectively, at the operational speed of  2
km/hr for maize and common bean ,while at 4km/hr for
sorghum crop. This clearly indicated that forward speeds
greater than 5 km/hr would result in percent missing index
of  approximately equal to ten and above  for maize which
exceeds the acceptable level of  percent missing index
(Chhinnan/ et al., (1975) and Karayel and Ozmerzi, 2001).

The Seed Multiple Index
The highest percent seed multiple index occurred at
operational speed of  6 km/hr for maize, common bean
and sorghum. The lowest values, of  the same, were
recorded at operational speed of  2 km/h. The planter

Table 4: Effects of  operational speed on multiple index (MULI, %)
Parameter Source of  variation Measure of  differences

Speed level (km/hr) Crop type LSD (5%) SE
Maize Common bean Sorghum

Missing (%) 2 9.6a 8.3a 13.0ab 10.02 5.44
4 11.7ab 12.67ab 13.93ab

6 15.37ab 21.1b 18.2ab

operating speed and the percentage seed multiple index
are directly related as that of  the percent seed missing
index (from the following results or Table 4).

The Quality of  Seed Feed Index
Appendix Table A3 shows the results of  statistical
analysis on the effects of  operational speed of  the planter,
and seed type on the quality of  seed feed index. The
analysis of  variance (ANOVA) revealed that , seed type
had significant effect (p <0.05) on quality of  feed index
whereas planter forward speed  and the interaction of
planter forward speed  and seed type  had no significant
effect (p > 0.05) on quality of  feed index. Table 5 shows
the effects of  operational speed of  the planter and seed
type on percent of  quality of  seed feed index. Figure 17
shows the relation between planter linear speed and seed
type and percent of  quality of  seed feed index. The forward
speed of  the planting machine had significant effect on the

percent quality of  seed feed index at the planter speed of  6
km/hr regardless of  the type of  seeds used.
The percent quality of  seed feed index decreased with
increasing planter forward speed for all types of  seeds
used in the study. However, the lowest reduction in
percent quality of  seed feed index was observed for
Sorghum seeds. The highest percent quality of  seed feed
index of  75.33, 71.67, and 68.87% were observed for
maize, common bean and sorghum, respectively, when
the planter was operated at forward speed of  2 km/hr.
The lowest percent quality of  seed feed index of  62.33,
63.00 and 59.94 were observed with maize, common
bean and sorghum, respectively; when the planter was
operated at speed of  6 km/hr. From results in Table 5, it
could be concluded that the planter at speeds greater than
or equal to 6 km/hr would reduce the plant population/
ha, hence could lead to reduction in yield at the end of
the day (Karayel, 2009).

Table 5: Effects of  operating speed, on quality of  feed index (QTFI, %)
Parameter Source of  variation Measure of  differences

Speed level (km/hr) Crop type LSD (5%) SE
Maize Common bean Sorghum

QTFI (%) 2 75.33a 71.67a 68.87a 6.17 3.27
4 72.87a 69.33a 66.87a

6 62.33b 63.00b 59.94b

Precision Index
Table 6 show the effects of  operational speed of  the
planter and seed type on mean percent seed precision
index.  The results indicated that seed type had significant
effect on the percent seed precision index; means that
variation, in seed spacing within a row, increased as
planter linear forward speed increased for maize, i.e. as
the speed of  operation is increased, one should expect

high variability in seed spacing, which is not a desired
trait. But for both common bean and sorghum does not
show direct relation. The combined effect of  seed type
and forward speed of  the planter, on the percent seed
precision index, was significantly difference at the planter
forward speed of  6 km/hr.
The percent seed precision index, at the planter linear
operating speeds of  2, 4 and 6 km/hr. were 1.77, 3.04



Pa
ge


37

https://journals.e-palli.com/home/index.php/ajlsi

Am. J. Life Sci. Innov. 2(3) 30-38, 2023

Table 6: Effects of  operating speed, on seed precision index (%)
Parameter Source of  variation Measure of  differences

Speed level (km/hr) Crop type LSD (5%) SE
Maize Common bean Sorghum

PRCE (%) 2 1.77a 7.54e 5.51cde 2.09 1.44

and 3.60; 7.54, 4.97 and 5.74; and 5.51, 4.25 and 5.45%
for maize, common bean and sorghum, respectively. This
particular result clearly indicated that planter forward
speed greater than 6 km/hr would result in seed spacing
variations of  over 3.60%, for maize and  the variations
for sorghum and common bean were greater than 5 %
at planter speed of  6 km/hr. However, a practical upper
limit for precision is 29%. Lower values for the precision
indicate better performance compared to higher values
(Kachman and Smith, 1995)and Table 7 below shows
planter performance indicators.
The mean field capacity and efficiency of  the planter
were 0.59 ha/hr. (1.73 hr. /ha) and 75.87 %, respectively.
This shows that the planter can plant a hectare of  land
in slightly in less than two working hours. In another
words, the planter can best suit majority of  the Ethiopian
farmers who have opportunity to use  the tractor. The
field efficiency of  the planter, as recommended by Kepner
et al. (1978) is within the acceptable level. The mean depth
of  planting was 5.95 cm with coefficient of  variation of

0.128 (12.8%).The time taken to finish one hectare of
land was 1:55 hr. that means by taking 8 hr. working hour
per day, the farmer can plant about 5.16 hectare of  land in
one day by using this planter.  Table  7 result the proposed
plant spacing was 20 cm-25cm and the maximum result
obtained from the experiments was 22.91 cm from Maize
so it is good in terms of  plant spacing which was with the
proposed range. This depth of  planting was greater than
the desired depth of  planting of  5 cm as recommended
for Maize by agronomists. Nonetheless, the deviation and
the variability being too small and with acceptable range,
also, it can be adjusted to the desired depth of  planting.
The stand count made after 15 days of  planting gave mean
number of  plants of  7.87,12 and 16 plants within rows
of  2 m length for maize, common beans, and sorghum,
respectively. The design or desired number of  plants,
within a row of  2 m long, for maize, common bean and
sorghum were 8, 13 and 10, respectively. Hence the planter
reasonably satisfied the requirement for the establishment
of  optimum plant population for all seed types.

Table 7: Field performance indicators of  the planter
Crop types Field

length(m)
Width
Field (m)

Time taken
(min)

Time lost
(min)

Theoretical
field capacity
(ha hr-1 )

Effective
Field capacity
(ha hr-1)

Field
efficiency
(%)

Maize 30 20  4.09 1.5  0.84 0.65 77.3
Common bean 30 20 5.52 2.15 0.64 0.46 71.8
Sorghum 30 20 4.23 1.23 0.84 0.66 78.5
Mean 30 20 4.61 1.63 0.77 0.59 75.87

CONCLUSION
This work focused on the development and performance
evaluation of  a tractor drawn multi-crop planting machine
that easy to use, easy to maintain, requires less labour and
costs. From the developed and results values obtained in the
study; it has been found that the developed planter gives:

• The planter works effectively in planting maize,
common bean and sorghum at a given study area.

• A significant field capacity was obtained by using the
developed machine when compared to manual planting
methods.

• This shows that the planter can plant a hectare of
land in slightly in less than two working hours.

• Therefore, the planter can best suit majority of  the
Ethiopian farmers who have opportunity to use the
tractor.

• Hence, one can note that the time requirement
per hectare is reduced by 1/16 amount and labour
requirement reduced by the same amount by using this
planter, when compared to manual planting.

• However, the speed of  the planter should be limited to
less than 6 km/hr in order not to seriously and negatively
affect the percentage of  recommended plant population
of  experimental crops.

REFERENCES
Chhinnan, M. S. Young, J. H. and Rohrbach, R.P.

1975. Accuracy of  seed spacing in peanut planting.
Transactions of  the ASAE, 18(1), 828-831.

El-Raie, A.E., Hendawy, N.A. and Taib, A.Z. (1996).
Study of  physical and engineering properties for
some agricultural products. Misr. Journal of  Agricultural
Engineering 13(1), 211-226.

FAO. (1994). Testing and evaluation of  agricultural
machinery and equipment: Principles and practices.

Jayan, P. R. and Kumar, V. J. F. (2004). Planter design in
relation to the physical properties of  seeds. Journal of
Tropical Agriculture, 42, 69-71.

Jouki, M. and Khazaei, N. (2012). Some physical
properties of  rice seed (Oryza sativa). Research journal



Pa
ge


38

https://journals.e-palli.com/home/index.php/ajlsi

Am. J. Life Sci. Innov. 2(3) 30-38, 2023

of  applied sciences, engineering and technology, 4(13), 1846-
1849.

Kachman, S. D. & Smith, J. A., (1995). Alternative
measures of  accuracy in plant spacing for planters
using single seed metering. Transaction of  the ASAE,
38(2), 379–387.

Karayel, D. (2009). Performance of  a modified precision
vacuum seeder for no-till sowing of  maize and
soybean. Soil & Tillage Research, 104, 121–125

Karayel, D. and Ozmerzi, A., (2002). Effect of  tillage
methods on sowing uniformity of  maize. Canadian
Biosystems Engineering, 44(2), 23-26.

Karayel, D., Wiesehoff, M., Ozmerzi, A. and Muller, J.
(2005). Laboratory measurement of  seed drill seed
spacing and velocity of  fall of  seeds using high-speed
camera systems. Computer and Electronics in Agriculture,
50(2), 89–96.

Kepner, R. A., Bainer, R., Barger, E. L. (1978). Principles
of  Farm Machinery, 3rd edition. Inc. AVI Publishing

Company, Westport, USA.
Khurmi, R. S. and Gupta, J. K. (2005). A Textbook of

Machine Design. Eurasia Publishing House (Pvt.) Ltd.,
Ram Nagar, New Delhi, India.

Kipchumba M. A. (2015). Design, Operation and
calibration of  a standard seed drill. Jomo Kenyatta
University of  Agriculture and Technology. Agricultural
machinery conference 75 paper.

Kumar, A., S. C. Moses, and K. Khan. (2015). A survey
on the design, fabrication and utilization of  different
types of  foods and vegetables dryer. IOSR Journal of
Agricultural and Veterinary Science I, 8(4), 2319–2372

Rangapara, D. & Jaimin, P. (2014). Performance
Evaluation of  Manually Operated Single Row Cotton
Planter. International Journal of  Engineering Sciences and
Research Technology, 3(9) 40-44.

Soyoye, B. O., O. C. Ademosun, and E. O. Olu-Ojo.
(2016). Manually operated vertical seed-plate maize
planter. CIGR Journal, 18(4), 70-80.
