Influence of the Perfective Working Body of Fiber Cleaning Machines

on the Aerodynamic Parameters



1
Alisher Abdusamatov, Ph.D,

2
Aybek Mavlyanov, Ph.D




1
Student, Tashkent institute of textile and light industry

2
 docent,


Tashkent institute of textile and light industry





Abstract: The modernization of process control methods, the development of automated methods for

designing equipment and technologies, and the development of automated control systems for the

cotton processing process. Currently, due to the improvement of machines for cleaning cotton fiber,

which are developed according to the technology of primary processing of cotton, one of the urgent

issues is to ensure the production of high-quality fiber. Taking this into account, it is necessary to

conduct a constructive analysis of the fiber cleaning equipment and develop an effective design. In

view of this, this study was aimed at improving the aerodynamic parameters of a fiber cleaner on the

basis of theoretical and applied research by creating and experimenting new saw blade construction.

In process of the research, methods are used optimization by theoretical statistics, evaluation and

target electronic programs, theoretical and applied mechanics, higher mathematics and vibration

theory. Aerodynamic equilibrium of a freely rotating saw cylinder due to the presence of friction

forces arising between the saw blades and air and atmospheric pressure cannot be overcome by

centrifugal forces acting on the air mass during rotation. This justification makes it possible to

explain the reason for the industry's refusal of the cleaning rate at 1000 min-1 and its transition to

1500 min-1. For the normal operation of the fiber cleaning machine, it is necessary that the saw

cylinder, taking air on the cleaning arc.

Keywords: fiber cleaner, saw cylinder, saw blade, air flow, and aerodynamic parameters.



Introduction. In developed countries, the modernization of process control methods, the

development of automated methods for designing equipment and technologies, and the development

of automated control systems for the cotton processing process [1-9]. Currently, due to the

improvement of machines for cleaning cotton fiber, which are developed according to the technology

of primary processing of cotton, one of the urgent issues is to ensure the production of high-quality

fiber. Taking this into account, it is necessary to conduct a constructive analysis of the fiber cleaning

equipment and develop an effective design [10-16].

To maintain the quality of fiber and seeds produced by researchers, cotton is repeatedly cleaned from

small impurities up to 32 times [17], although in fact that cotton can be cleaned from large impurities

up to four times and from small impurities up to 20 times [18]. Moreover, the cleaning efficiency of

the demand level is below 90-95%, and the amount of residual impurities in the fiber is not cleaned

at the required level. The complexity of the problem lies in the fact that now the maximum number

of cotton cleaners in the equipment for cleaning from small and large impurities in cotton factories

largely requires the installation of additional filters that increase the cleaning efficiency, leading to a

sharp increase in the number of impurities with fiber defects. Therefore, the efficiency of cotton

cleaning should be carried out without additional mechanical impact on it [19, 20].

In one of the scientific studies to improve the efficiency of cleaning cotton, which are on the

assembly machine, a special structural guide device is installed on the equipment in order to improve





American Journal of Science and  Learning for Development Volume 1, No 2|
Dec - 2022




Published by inter-publishing.com  |  All rights reserved. © 2022
Journal Homepage: http://inter-publishing.com/index.php/AJSLD

Page 25



the equipment for cleaning fibers used in cotton-cleaning mill. Recommendations were given for the

introduction of a directional device in a special design into production [21-23].

Other study presented the results of a fiber cleaner developed and implemented at the Buz cotton-

cleaning mill to determine the technological performance indicators depending on the rotation speed

of the saw cylinders and the aerodynamic mode of operation [24].

In addition, fiber cleaning in direct-flow cleaners takes place in aerodynamic flows; the

technological parameters of the machine depend on the aerodynamic mode of operation. The saw

cylinders of the fiber cleaner not only clean the fiber, but also perform a number of aerodynamic

functions associated with the interaction of several different air flows. Therefore, the scheme of

movement of air masses inside the fiber cleaner is a rather complex phenomenon and has not been

fully studied [25]. In view of this, this study was aimed at improving the aerodynamic parameters of

a fiber cleaner on the basis of theoretical and applied research by creating and experimenting new

saw blade construction [26, 27].

Materials and methods. The object of research is cotton cleaning mills, fiber cleaner (fig.1),

aerodynamic parameters. The properties of fibers in the composition of cotton fibers and semi-

finished products are determined using the laboratory equipment of AFIS PRO 2 of the company

“Oster”. At the same time in the laboratory equipment it is possible to determine the length L(n),

endings (Neps/g), the amount of thick fibers (SFC n, SFC w), linear density (Fineness), the amount

of mature (ripened) fiber (Muturity), the amount of dead fiber (IFC), the amount of dust (Duct Cnt),

pollution (Trash Cnt), visible large impurities (VFM). With the help of the above laboratory

equipment, the quality indicators of the cotton obtained from the existing and improved fibers are

studied [27].

The effect of the fiber on aerodynamic parameters of the working bodies in t cleaning process is

calculated based on the values contained in the tables 1, 2 below [28].

Table 1. Air density depending at different temperatures

t, °С -30 -20 -15 -10 -5 0 10 15 20 30

ρ, kg/m
3
 1,453 1,395 1,369 1,342 1,318 1,293 1,247 1,226 1,205 1,165



Table 2. Kinematic viscosity of air at different temperatures


t, °С -20 -15 -10 -5 0 10 15 20

ν·10
-6

, m
2
/s 11,61 12,02 12,43 12,86 13,28 14,16 14,61 15,06



In process of the research, methods are used optimization by theoretical statistics, evaluation and

target electronic programs, theoretical and applied mechanics, higher mathematics and vibration

theory, theory of mechanisms and machines, mathematical modeling of working processes of

technological machines, mathematical statistics and mathematical calculations [31].

Types of variables are independent – cotton fiber, dependent – saw cylinder (fig.2), controlled – fiber

cleaning machine 1ВП (fig.1).





American Journal of Science and  Learning for Development Volume 1, No 2|
Dec - 2022




Published by inter-publishing.com  |  All rights reserved. © 2022
Journal Homepage: http://inter-publishing.com/index.php/AJSLD

Page 26



Fig.2. Technological process scheme of 1ВП fiber cleaner

1-inlet pipe of fiber; 2, 7, 8-saw cylinder; 3-grinding brush; 4-fire-grate; 5-separating knife; 6. outlet

pipe of fiber; 9-chute of impurity; 10-guide; 11-air blind

Fig.2. Saw cylinder of fiber cleaning machine

1 – shaft; 2 – lock nut; 3 – taper washer; 4 – saw blade; 5 - inlay

Analysis of research results. In the process of studying the effect of working bodies on the

aerodynamic parameters of fiber cleaning machines, it is important to calculate the air flow

generated around the cylinder with the saw in the process.

The air flows formed in the fiber cleaner have a significant impact on the process of separating weed

impurities from the fibers. Consider the air flows created by the saw cylinder during its rotation. The

movement of the fiber strand depends on which flow is laminar or turbulent, which will directly

affect the cleaning process. During the rotation of the disk, air flows move along its side surfaces.

They have a laminar character at low rotational speeds, and at higher velocities – turbulent. Laminar

air flow over the disk is possible at a Reynolds number < 100000.

Re = ωr
2
/ν       (1)

where ω - the angular velocity of rotation of the disk, rpm; r - the current radius of the disk, m; ν -

the kinematic viscosity of the air, m
2
/s.

From formula (1), the maximum radius of the laminar flow zone will be

       (2)

Take ν = 15.06 •10
-6

, m
2
/s. Knowing that ω = πn/30, we rewrite equation (2)



When the fiber cleaner is in operation, the saw rotates at a frequency of n = 1500 rpm, with rmax =

0.153m = 153 mm (Fig.3).

As you can see, there is no laminar flow outside the saw blade ∅310 mm.


n, rpm 1000 1500 2000 2500 3000

rmax, m 0.176 0.153 0.124 0.111 0.102







American Journal of Science and  Learning for Development Volume 1, No 2|
Dec - 2022




Published by inter-publishing.com  |  All rights reserved. © 2022
Journal Homepage: http://inter-publishing.com/index.php/AJSLD

Page 27





Fig.3. Chart of the number of rotations and the linkage of the chainwheel rotation radius to the

fiber cleaning efficiency

This justification makes it possible to explain the reason for the industry's refusal of the cleaning rate

at 1000 min
-1

 and its transition to 1500 min
-1

. An increase in the number of revolutions gives an

increase in the cleansing effect, which has been proven by repeated experiments (Fig. 4).

An increasing in the number of revolutions gives an improve in the cleaning effect, which has been

proven by repeated experiments.

With the rotation speed of the saw cylinder over 1750 rpm, an unacceptable increase in its vibration

is observed.

Fig. 4. The increase in the cleaning effect as a result of a change in the number of rotation of the saw

cylinder depends on the amount of fiber contained in K and waste B

Equilibrium conditions of the fiber strands on the saw teeth with an arbitrary direction of the air flow

to the fiber (Fig. 6).



















American Journal of Science and  Learning for Development Volume 1, No 2|
Dec - 2022




Published by inter-publishing.com  |  All rights reserved. © 2022
Journal Homepage: http://inter-publishing.com/index.php/AJSLD

Page 28



Fig. 5. Determination of self-extracting γ angle of fiber

Applying the d'Alembert’s principle and projecting the forces acting on the fiber on the x and y axes,

we obtain for uniform rotation of the saw blade [35]



The aerodynamic equilibrium of a freely rotating saw cylinder due to the presence of friction forces

arising between the saw blades and air and atmospheric pressure cannot be overcome by centrifugal

forces acting on the air mass during rotation. In Fig. 5, the elementary volume of air can be

expressed as follows:



















Fig.5. Scheme for determining the volume of air in the suction cup

For the normal operation of the fiber cleaning machine, it is necessary that the saw cylinder, taking

air on the cleaning arc, has the ability to discharge it.

Discussion. With an increase in the rotation frequency of the saw cylinder, the diameter of the

laminar flow decreases, therefore, the saw teeth and grates are located in the boundary zone of the

turbulent flow. If the strand moved in the zone of a confident turbulent flow, then such a flow would

contribute to the unraveling of the strand of fibers, thereby facilitating the release of weed impurities

due to the strength of their connection with the fibers. Aerodynamic equilibrium of a freely rotating

saw cylinder due to the presence of friction forces arising between the saw blades and air and

atmospheric pressure cannot be overcome by centrifugal forces acting on the air mass during

rotation.

Conclusion. This paper shows that as a result of the influence of working bodies of fiber cleaning

machine on aerodynamic parameters. When the fiber cleaner is in operation, the saw rotates at a

frequency of n = 1500 rpm, with rmax = 0.153m ≈ 155 mm. As you can see, there is no laminar flow

outside the saw blade ∅310 mm. This justification makes it possible to explain the reason for the

industry's refusal of the cleaning rate at 1000 min
-1

 and its transition to 1500 min
-1

.

References

1. International cotton advisory committee. Washington, From the Secretariat of the ICAC.

https://icac.org/, emailsecretariat@icac.org.September 1, 2017.

2. Samuel Jackson Moisture handbook. Sam Jackson Technical Staff & Network. Originally

published February 2012. Information subject. Rejim

dostupa:http://static1.squarespace.com/static/5347080fe4b0d28409c17b4d/t/534

e8c00e4b06285ac58d2fc/1397656576993/2012+HB+Complete.pdf.

https://icac.org/
mailto:secretariat@icac.org
http://static1.squarespace.com/static/5347080fe4b0d28409c17b4d/t/534%20e8c00e4b06285ac58d2fc/1397656576993/2012+HB+Complete.pdf
http://static1.squarespace.com/static/5347080fe4b0d28409c17b4d/t/534%20e8c00e4b06285ac58d2fc/1397656576993/2012+HB+Complete.pdf




American Journal of Science and  Learning for Development Volume 1, No 2|
Dec - 2022




Published by inter-publishing.com  |  All rights reserved. © 2022
Journal Homepage: http://inter-publishing.com/index.php/AJSLD

Page 29



3. A Presentation by Mr. Lav Bajaj and Mr. M.K. Sharma, Bajaj Steel Industries Ltd., Nagpur

India. Future trends in cotton ginning and pressing technologies. 2012. Rejim

dostupa:http://bajajngp.com/images/technical/5th.pdf

4. Cotton: World Statistics. Bulletin of the International Cotton Advisory Committee, NY,

November 2015. http://www.ICAC.org. http://www.samiackson. com;

http://www.baiaingp.com;

5. W.S.Anthony and William D.Mayfield. Cotton ginning handbook. United States Department of

Agriculture. Desember 2016.

6. Ryszard M. Kozlowski. Handbook of natural fibres. Volume 2: Processing and applications.

Wood head Publishing Limited, 2012.

7. https://www.testextextile.com/ru/chto-takoye-svoystva-xlopkovogovolokna-iz-xlopkovogo-

volokna.

8. Shandong machine-building company for the production of cotton processing equipment

"Lebed". Instructions for the operation of the saw gin MY-171, pneumatic fiber cleaner

MKPKh3000, sawn fiber cleaner MKP 600x3000. China, Jinan. 2002. -32 c.

9. Jingshan Tian, Xuyi Zhang, Wangfeng Zhang. Fiber damage of machine-harvested cotton before

ginning and after fiber cleaning. «Journal of Integrative Agriculture». Vol.17, Issue 5, May 2018.

Pages 1120-1127.

10. Juraev A., Akhmedkhodjaev H.T., Bobomatov A. Improvement of designs and development of

methods for calculating the working bodies of cotton cleaners from fine litter. Ed: "Namangan”,

Namangan, 2016, 126 p

11. Bafaev D.H. Increasing the efficiency of straight-flow single-stage fiber cleaning machines

//Young exercises, 2016, No. 5 - from 14-16 .

12. Tursunov Kh.K. Mechanics of working bodies of fiber cleaning machines, Vol.: "Fan", 1997,

126 p..

13. http://tekhnosfera.com/teoreticheskie-osnovy-ochistki-hlopkovogo-volokna-i-

sovershenstvovanie-rabochih-organov-voloknoochistitelnyh-mashin#ixzz69JJHhJKf

14. Kuliev T.M., Djuraev A. Designing and methods of calculating parameters of a fibrous material

cleaner from large litter // International Journal of Advanced Science and Technology Vol. 29,

No. 8s, (2020), pp. 444-452.

15. Korabelnikov R.V., Lebedev D.A. Determination of aerodynamic drag forces in the process of

cleaning natural fibers // Scientific works of young students of KSTU, Vipusk 8, Kostroma,

2007, 19-23 pages.

16. Salimov A.M., Lugachev A.YE report this websiteT. Technology of preliminary processing of

cotton. "Spark of literature". Tashkent. 2018.- 184 p.

17.  I.K.Sobirov. Theoretical calculation of the length of cotton fiber in the process of two-stage

gining.// The problem of textiles. 2008. No.2. pp.78-80.

18. Handbook on the first processing of cotton. Under the general edition of F.B.Omonov. Tashkent,

“Voris nashriyot” , 2008 y., 416 p.

19. I.D.Madumarov, B.M.Mardonov, T.O.Tuichiev. Investigation of the movement of the cotton-sirs

fly in the zone of its interaction with the mesh surface // Textile problems.- 2017., No. 3– - from

21-26 p.

20. Korabelnikov A.R. The process of shock interaction of a fiber particle with a working organ /

A.R. Korabelnikov, D.A. Lebedev, R.V. KorAbelnikov // "Technology of textile industry".

Ivanovo. - 2003. - No. 1.

http://bajajngp.com/images/technical/5th.pdf
http://www.icac.org/
http://www.samiackson/
http://tekhnosfera.com/teoreticheskie-osnovy-ochistki-hlopkovogo-volokna-i-sovershenstvovanie-rabochih-organov-voloknoochistitelnyh-mashin#ixzz69JJHhJKf
http://tekhnosfera.com/teoreticheskie-osnovy-ochistki-hlopkovogo-volokna-i-sovershenstvovanie-rabochih-organov-voloknoochistitelnyh-mashin#ixzz69JJHhJKf




American Journal of Science and  Learning for Development Volume 1, No 2|
Dec - 2022




Published by inter-publishing.com  |  All rights reserved. © 2022
Journal Homepage: http://inter-publishing.com/index.php/AJSLD

Page 30



21. Hengyi Dong, Xingli Jiu, Yongchuan Yu, Zhan Zhao. Leaf adhesiveness affects damage to fiber

strength during seed cotton cleaning of machine-harvested cotton. «Industrial Crops and

Products» Vol. 107, Issue 15, November 2017. Pages 211-216.

22. Kuliyev T.M., Djuraev A. Creation of a design and justification of parameters of a single-stage

fiber cleaner // International Journal of Advanced Science and Technology Vol. 29, No. 5,

(2020), pp. 4522 – 4529.

23. Madrakhimov D.U., Muminov U.M. Influence of performance, velocity and aerodynamic modes

of the developed fiber cleaner on technological indicators // Universe: technical sciences:

electron. scientific. journal.2020.№9(78).-p.55-58.

https://7universum.com/ru/tech/archive/item/10727

24. Maksudov E.T., Aminov Kh.Kh., Murodov R.M. Improvement of a high-efficiency unit for

cleaning cotton fiber. Kursk, Russia. Modern materials, equipment and technologies. 2015

No.2(2) pp.115-120.

25. Aybek Palvanbayevich Mavlyanov, Alisher Abdugappar oʻgʻli Abdusamatov, Aʼlamjon Shavkat

oʻgʻli Aʼzamjonov. New saw blade for cleaning cotton Fiber//DOI:

10.48047/IJIEMR/V09/I12/35, IJIEMR Volume 09, Issue 12, Pages: 206-210

26. Alisher Abdugappar ugli Abdusamatov. Shavkat Sadridinovich Xoldorov, Ravshan Xasanovich

Maksudov, Aybek Palvanbaevich Mavlyanov. Analysis of mathematical model of single-stage

fiber cleaner machine aggregate//

International Engineering Journal For Research & Development, Vol. 6, Issue 3, 05.07.2021,

DOI:https://doi.org/10.17605/OSF.IO/3B8P9

27.  O.T.Olimov, S.H.Babajanov, M.M.Agzamov. Fiber cleaning production line for machine-picked

cotton// Actual problems of innovative technologies in the conditions of integration of Science,

Education and production, Republican scientific-practical conference, part I, Collection of

scientific articles, November 29-30, Tashkent-2013, 66-70 p

28.  https://en.wikipedia.org/wiki/Density_of_air

29. Todor Vlad, Dan Pitica, Lucian Man, Jano Rajmond. Optimized methods for theoretical and

practical training// Conference: Electronics Technology (ISSE), 2012 35th International Spring

Seminar, and May 2012. DOI:10.1109/ISSE.2012.6273146

30. B.M.Mardonov, F.X.Ibragimov, X.T.Axmedxodjayev, X.N.Sharipov, Sh.S.Xoldorov. Study Of

The Law Of Motion Of A Single Seed On The Rib// Textile Journal of Uzbekistan, Vol 8, Issue

1, 2019, 42-49 p

31. A.A.Abdusamatov. Analysis of the design scheme of the cleaner machine aggregate” Innovative

ideas and developments of young people living in conditions of modernization of technology of

cotton cleaning, textile, light industry, printing production", Republican scientific-practical

conference, October 20-21, Tashkent – 2021, 177-179 p.





https://7universum.com/ru/tech/archive/item/10727
https://www.ijiemr.com/public/uploads/paper/706491608527307.pdf
https://doi.org/10.17605/OSF.IO/3B8P9
https://en.wikipedia.org/wiki/Density_of_air
https://www.researchgate.net/profile/Todor-Vlad
https://www.researchgate.net/profile/Dan-Pitica
https://www.researchgate.net/scientific-contributions/Lucian-Man-74985023
https://www.researchgate.net/profile/Jano-Rajmond
http://dx.doi.org/10.1109/ISSE.2012.6273146
https://uzjournals.edu.uz/titli/vol8/iss1/6/
https://uzjournals.edu.uz/titli/vol8/iss1/6/
