Design and Development of  a Tractor-Drawn Cultivator with a Pulverizing Attachment
Husen Bona Wako1*, Adesoji Matthew Olaniyan2

Volume 3 Issue 2, Year 2024
ISSN: 2837-0295 (Online)

DOI: https://doi.org/10.54536/ajsts.v3i2.3337
https://journals.e-palli.com/home/index.php/ajsts

Article Information ABSTRACT

Received: August 02, 2024

Accepted: August 30, 2024

Published: September 03, 2024

Soil tillage is one of  the most critical processes in the agricultural production system,
requiring the greatest energy and time of  any operation. A cultivator with pulverizing
attachment was designed and developed to reduce secondary tillage operations to a single
pass to ensure timeliness in seedbed preparation. It consists of  a pulverizing roller as an
active unit and cultivator tynes as a passive unit. The implement has the following major
components; a frame, cultivator tines, and a pulverizing roller consisting of  central and
peripheral shafts on which discs are arranged. The cultivator tynes were fitted on the main
frame while the pulverizing roller was attached at the rear end of  the frame with the help
of  bearings. The pulverizing blades were welded on discs in such a way as to crush the soil
by impact force. In this way, the force exerted by the pulverizer on the clod is distributed
uniformly in the shaft which is used to hold the pulverizing roller. The pulverizer was
designed to break big clods formed during tillage operation and the implement was
attached to the tractor by three point hitch. In operation, the cultivator tynes open the
furrow, and the roller cuts and pulverizes the soil at optimum conditions for tillage. With
a production cost of  ETB 17,587.19, the implement is within the economic reach of  an
average smallholder farmer in Ethiopia.

Keywords
Clods, Cultivator, Draft,
Pulverizing Roller, Soil
Manipulation, Tillage

1 Agricultural Machinery Engineering Department, Oromia Agricultural Research Institute, Jimma Agricultural Engineering
  Research Center, Jimma, Ethiopia
2 Department of  Agricultural Engineering, Haramaya Institute of  Technology, Haramaya University, P. O. Box 138, Dire Dawa, Ethiopia
* Corresponding author’s e-mail: husenifnaan@gmail.com

INTRODUCTION
Tillage is the process of  mechanically manipulating soil
to make it more conducive to crop cultivation. Soil tillage
entails breaking the earth’s compact surface to a particular
depth and loosening the soil mass to allow crop roots
to penetrate and disseminate into the soil (Zhou et al.,
2020). It is the mechanical manipulation of  soil and plant
debris to prepare a seedbed for the planting of  seeds that
will produce grain for human use. Tillage also breaks up
the soil, improves the release of  soil nutrients for crop
growth, eliminates weeds, and improves water and air
circulation in the soil (Reicosky & Allmaras, 2003).
Tillage is considered one of  the most important processes
in agriculture, as it gives suitable conditions for root
growth, which in turn supports the growth of  plants, as it
reduces soil resistance, increases the ventilation process,
and eliminates weeds (Al-Shamiry et al., 2020). Tillage
in the traditional sense is one of  the least fuel-efficient
procedures. According to (Digman, 2012), just 20% of
diesel fuel energy is available at the tractor’s drawbar, but
only 4% of  that energy is transformed into soil-breaking
energy.
Tillage implements works based on two working motions,
sliding type, and rotating type. Devices like moldboard
plows and cultivators use sliding action to cut the soil.
By functioning in a rotational motion, disc plows, disc
harrows, clod crushers, and rollers cut and pulverize the
soil. Because of  the soil frictional force and the contact
area of  the implement, sliding-type implements consume
more drafts than rotating-type implements. A negative
draft was produced by rotary-type implements. As a result,

the concept of  combining sliding and rotary implements
saves a lot of  power, time, and money (Parmar & Gupta,
2001).
Tillage operations can be performed simultaneously
in a single pass by a combination tillage tool mounted
on a tractor. According to (Manian & Kathirvel, 2001),
combined tillage is a method of  manipulating the soil by
using two or more different tillage implements at the same
time to reduce the number and time of  field operations.
According to (Prem et al., 2016), combined tillage is the
use of  two or more implements at the same time to alter
the soil. Combined tillage, in a broad sense, refers to
the integrated management of  resources such as time,
energy, fuel, labor, soil, and water conservation while also
boosting output and better utilizing natural resources. It
also helps to maintain agricultural production.
Combined tillage implement reduced larger size clods in
the soil, improved aeration and moisture holding capacity,
and obtained medium uniformity of  soil and finer
pulverization modulus. The combination tool achieved
maximal soil loosening as evidenced by the low soil bulk
density range of  1.15 gcm-3 as opposed to the normal 1.4
gcm-3 encountered in conventional tools operated field.
The use of  combined tillage for seedbed preparation can
save 44 to 55% in cost and 50 to 55% in time (Kailappan
et al., 2001).
(Maheshwari et al., 2005) reported that soil aggregates of
size 12 to 14 mm in the final seedbed were acceptable for
sowing crops. Clod formation after plowing or disking is
a significant issue. Clods block the penetration of  seed
drill furrow openers and prevent close contact between



Pa
ge


26

https://journals.e-palli.com/home/index.php/ajsts

Am. J. Smart. Technol. Solutions 3(2) 25-33, 2024

seeds and soil. To avoid the aforementioned issues clods
must be pulverized. Because of  the time, efficiency, and
cost savings, combining implements and minimizing the
number of  passes is becoming more common (Alkhafaji,
2020).
In Ethiopia, farmers are using the conventional tillage
system which disturbs the soil more; increases soil
compaction increases erosion capacity by wind and water.
The combined tillage used was also imported from other
countries which is too expensive. The implementation did
not consider small-scale mechanization, affordable power,
high land agriculture, costly, and not scale appropriately.
The overall dimensions and weight of  the tillage tool
were heavy, not easily dismantled, or repaired and it was
complicated. Therefore, the objective of  this study was
to design and develop a tractor-drawn cultivator with a
pulverizing attachment that would be operated within
the techno-economic status of  smallholder farmers in
Ethiopia.

MATERIALS AND METHODS
Determination of  Physical Properties of  Soil
Moisture Content of  Soil
Before field activities, soil samples were taken from 0 to 20
cm below the soil surface to determine moisture content.
Three soil samples were randomly taken from test plots
and the weight of  each sample was determined using an
electronic balance. The samples were then maintained in

a hot air oven for 24 hours at a temperature of  105°C.
The moisture content (dry basis) was calculated using the
formula below (Javadi & Hajiahmad, 2006).
MC = (WW-Wd)/Wd ×100                                                (1)
Where, (i) MC = Moisture content of  the soil, % db; (ii)
WW = Weight of  wet soil, g; and  (iii) Wd = Weight of
oven-dry soil, g.

Determination of  Bulk Density of  Soil
The oven dry mass per unit volume of  the soil is known
as bulk density. It was determined by taking soil samples
from various sites throughout the field with a core
sampler. The formula was used to compute bulk density
(Javadi & Hajiahmad, 2006).
γd = M/V                                                                         (2)
Where, (i) γd = dry bulk density of  soil, g/cm3; (ii) M =
oven-dry mass of  soil, g; (iii) V = volume of  the core
sampler, cm3.

Overall Structure and Descriptions of  the Implement
A cultivator with pulverizing attachment was designed
to reduce the number of  secondary tillage operations to
single pass and enhance timeliness in seedbed preparation.
As shown in Figure 1, it consists of  the following main
components; frame with cultivator tynes, pulverizing
attachment having pulverizing blades, disc, and three-
point linkage unit.

Figure 1: Cultivator with Pulverizing Attachment

Design of  Major Components
Components of  the cultivator with pulverizing
attachment were designed, developed, and fabricated
based on parameters like functional requirements,
operational requirements, and strength. While fabricating
the tractor-drawn cultivator with a pulverizing attachment
the basic emphasis was the simplicity of  fabrication, the

use of  locally available materials, the minimum cost of
fabrication, and the ease of  assembling and dismantling
for repair were considered. The mechanical design details
were also given due attention so that it was given adequate
functional rigidity for the design of  the machine.
The implement was designed having in mind that the
frame should have sufficient strength to hold the tines



Pa
ge


27

https://journals.e-palli.com/home/index.php/ajsts

Am. J. Smart. Technol. Solutions 3(2) 25-33, 2024

and also withstand failure due to developed stresses and
bending moment in mind that it will work on heavy soils.
The assumptions made in the design of  a cultivator with
pulverizing attachment were as follows (Parmar & Gupta,
2001); (i) No draft was included for pulverizing attachment
because it is a rotating unit; (ii) The average speed of
operations of  the tractor in the field was kept at = 3
Km/h; (iii) Maximum soil resistance was considered as =
0.75 Kg/cm2; (iv) Co-efficient of  friction in unploughed
soil was taken= 0.85; (v) A seven-tyne cultivator having a
working depth of  30 cm was considered.

Design of  Frame
The frame members were welded together at the ends
since a fixed-type end connection was selected for the
frame. Euler’s theory for the crippling and buckling load
(pcr) under various end conditions is given by the equation
below (Khurmi & Gupta, 2005).
pcr = (π2 EI)/( Le/r)2                                                       (3)
Where, (i) E = modulus of  elasticity for the mild steel
material (E= 210 GPa); (ii) A = cross-section area for a
hollow rectangular shape, cm2; (iii) pcr = Euler’s critical
load, N; (iv) Le= effective length of  the frame, cm; (v) r
= radius of  gyration of  the cross-section; (vi) I = polar
moment of  the cross-section.
The frame was considered as a beam at the tyne and
hitch support portion and all components were loaded
vertically so it is considered as a column. Assuming, σy
= 250 MPa and comparing the critical load of  the frame
with yield strength, whether the frame is saved or not.
From the available data, let us determine the dimension
of  the frame. The actual length of  the frame, L = 160 cm,
equivalent length, Le = L=160 cm for the frame one end
fixed and another end free.
Le/r = π ×√(E/σy ) = √((210 Gpa)/(250 Mpa)) = 91.05
The crushing stress is given by
σcr = (π2E)/(Le/r)2 = (π2×210 Gpa)/91.052 = 250 Mpa
Le/r = 91.5, Le = 160 cm then r2 = Le/91.5
= (160 cm)/91.5 = 1.749 cm, and r2 = 3.06 cm2

Radius of  gyration  r2 =I/A = (bh3)/12hb = h2/12
Then h2 = 12×r2 = 12 × 3.06 cm2 = 3 6.71 cm2

h=6.59 cm, say h=6 cm
The dimensions of  the frame were made from mild steel
rectangular pipe which had h = 6 cm and thickness t = 0.4
cm and width = 7.5 cm.
The critical load is found as:
Pcr = (π2EI)/Le

2 = (π2×210(h3b)/12)/Le
2

= (π2×210×(603×75)/12)/1602 = 1,091.92×108  kN
Hence, critical stress
σcr = Pcr/A = Pcr/(b×h)
= (1,091.92×108 KN)/(45 cm2) = 242.65 Mpa
Comparing the critical stress wit h the yield strength of
the material, critical stress is less than the yield strength
of  the material (σcr ≪ σy). According to Euler’s theory
of  buckling, for slender columns, the critical buckling
stress is usually lower than the yield stress. Hence, the
designed frame was saved from buckling. The frame of
the cultivator was made from mild steel (M.S) rectangular

pipe shape of  6 × 7.5 sizes (cm) × 0.4 cm thickness cross-
section. All components of  the cultivator were assembled
and fitted on the frame.

Design of  Cultivator Tines
A cultivator was used to open the furrow at the desired
depth of  operation. The tine-type cutting blade was used
as uniform depth of  operation or plowing was required.
A cutting unit of  tine was fitted at one end of  the share
and the other end was attached with a frame by bolts and
nuts for adjusting depth. The thickness, width, and length
of  the tyne were decided on the assumption given by
(Sharma & Mukesh, 2010).
Let, b x h = bare cross-section area, cm2

L= length of  breast of  tine
The length of  the inclined part of  the tyne generally
ranges from 10 to 20 cm, and the radius of  curvature
R < 12 cm. The minimum clearance length of  tine (HI)
between the land surface and the lower edge of  the frame
was 20 cm. The height of  the tine was calculated as the
formula given below.
HT = amax + HI + ΔH                                                          (4)
= 10+35+15 = 60 cm
Where, (i) amax = depth of  tool, cm; (ii)  HI = length of
tyne, cm; (iii) ΔH = length of  tine used for fastening with
frame, cm.
Load angle was determined by;
tanα = 10/30 = 0.33                                                         (5)
α = tan-1 (0.73) = 36.12°
Now radius of  curvature was determined as;
RC = (Ha-l1 sinα)/cosα                                                        (6)
= (20-18sin36.12)/cos36.12 = 11.62 cm
Where, (i) l1 = length of  breast of  the share; (ii) Ha =
height of  the first curvature point of  the tyne from the
point of  share.
The cutting blade of  the tine was exposed first to bending
due to soil resistance. The soil resistance, FX is horizontal
and acts in the axis of  symmetry of  the tyne. Average
soil resistance was obtained by the formula given below
(Kumar et al., 2017) and Table 1.
FX= d × w × KO                                                              (7)
= 30×20×0.2 = 120×9.81 = 1,777.2 N
Where, (i) d = Effective working depth of  tine (cm); (ii) w
= Working width of  the tine (cm); (iii) KO = Specific soil
resistance (kg/cm2).

Table 1: Specific Soil Resistance at a depth of  15 cm
S/N Soil Type Specific resistance, kg/cm2

1 Light 0.12
2 Medium 0.15
3 Heavy 0.20
4 Very heavy 0.25

Source: (Dubey, 2003)

The draft force exerted on the cutting blade was
determined using the following equation;



Pa
ge


28

https://journals.e-palli.com/home/index.php/ajsts

Am. J. Smart. Technol. Solutions 3(2) 25-33, 2024

D = KO × n × w × d                                                      (8)
= 0.8×7×20×30 = 3,360 kgf  = 32,691.6 N
Where, (i)D = draft force, kgf; (ii) KO= soil resistance,
kg/cm2; (iii) w = width of  tine, cm; (iv) d = depth of  tine,
cm; (v) n = number of  tine.
Finally, the total draft required for operation and each
draft of  the tines was calculated by,
Dt = D × FOS × g                                                          (9)
Dt = 3,360 ×1.5×9.81 = 49,442.4 N
Where, (i) Dt = total draft, N; (ii) D = draft, N; (iii) FOS =
factor of  safety; (iv) g = force due to gravity, m/s2.
Di = (Draft (N))/(number of  rows)                                    (10)
= 32,961.6/7 = 4,708.8 N
It was assumed that the draft force on the tine was
determined and acting at a height of  h/3 from the
bottom of  the tine. The distance of  the draft application
on furrow opener tine (d) was calculated by the formula
given below (Sharma & Mukesh, 2010).
d = h/3                                                                         (11)
= 60/3 = 20 cm
Moment arm length = (h-d) = 60-20 = 40 cm                 (12)
The maximum bending moment was determined
according to the following formula.
Bending moment of  tyne (BM)
= Draft × moment arm length                                                           (13)
= 4,708.8 N×40 = 188,352 N m
Therefore, the maximum bending moment of  tine was
determined by multiplying the bending moment of  tine
with a factor of  safety. (take,  FOS=1.5)
Maximum bending moment
= bending moment × FOS                                            (14)
Mb = 188,352 Nm×1.5 = 282,528 Nm
Mild steel was used for the design of  tine and assuming
bending stress, σb = 56 N/mm2. Section modules of
each cutting blade (Z) were determined as the following
formula.
Z = ( Mb)/σb                                                                 (15)
= (282,528 )/56=5.05 cm3

Where, (i) Mb = maximum bending moment; (ii) σb =
bending stress; (iii) Z = section modulus of  tine; (iv) b =
width of  mild steel.
According to (Khurmi & Gupta, 2005), the Section
modulus of  tine of  a cultivator with pulverizing
attachment was calculated by using the formula,
Z = 1/6  × b3                                                               (16)
5.05 cm3 = 1/6×b3

b3 = 5.05  cm3×6 = 30.27 cm3

b = ∛(30,270.84) = 3.12 cm≈4 cm
So, the 4 cm ×4 cm size of  the share was developed from
a mild steel material.
Bending Stress, σb causing the tine to bend was calculated
by the expression(Kumar et al., 2017).
σb = (6Dt (H1+a))/(tb2 )                                                   (17)
= (6×49,442.4(35+20))/(0.6×402 ) = 16,995.82 N/cm2

Where, (i) Dt= draft at the tip of  tine, N; (ii) HI  = length
of  tine, cm; (iii) a = Effective working depth of  tine, cm;
(iv) t = thickness of  the tine, cm and (v) b = width of
tine, cm.
Torsional stress acting on the tine when turning the
openers inside the soil at headland is given by (Kumar et
al., 2017).
τ = (9Dt (Ww/4))/(2b2 )                                                 (18)
= (9×49,442.4(40/4))/(2(40)2)
= 4 ,449,816/3200 = 1,390.57  N⁄cm2

Where, (i) Ww = Effective working width of  tine, cm, and
(ii) b = width of  tine, cm
Then, the reduced stress is calculated as;
δ = √(σb2+4τ2)                                                             (19)
= √((16,995.82)2+(1,3902.57)2)
= 17,052.61  N⁄cm2 = 170.53 N/mm2

Where, (i) δ = Reduced stress, kg/cm2; (ii) σb =  bending
Stress, N/cm2 and (iii) τ = Torsional shear stress, N/
cm2. Since the calculated stress (170.53 N/ mm2) was less
than the allowable stress of  mild steel (200 N/mm2), the
design was safe and the tine can perform well.

Figure 2: Schematic Diagram of  Cultivator Tine



Pa
ge


29

https://journals.e-palli.com/home/index.php/ajsts

Am. J. Smart. Technol. Solutions 3(2) 25-33, 2024

Design of  Pulverizing Roller
Basic Design Parameters and Specifications
Pulverizing roller attachment to the cultivator pulverizes
the soil to a greater degree. The pulverizing roller consists
of  discs, a central shaft, and pulverizing members. The
pulverizing roller was designed for cutting, mixing, and
clod breaking which ultimately pulverizes the soil by
impact force. The cutting and clod-breaking action of
this unit provides better soil preparation.
Roller diameter = 45 cm
Length of  roller = 130 cm
Circumference = π×D                                                (20)
= 3.14×45=141.3 cm
Spacing between pulverizing blades was calculated by the
following formula (Prem et al., 2016).
Sb = (π×D)/Nb                                                             (21)
= 143.3/6 = 23.55 cm (taking, Nb=6)
Where, (i) Sb = Spacing between the pulverizing blade; (ii)
Nb = number of  pulverizing blade
Depending upon the type of  soil and moisture content
in the soil, the torque required to break big clods varies
between 0.5 Nm. Therefore, the power required to
operate the pulverizer generally ranges between 1-2 hp at
an operating speed of  1.1 m/s and 10% slippage (Prem
et al., 2016).
Speed = πDN                                                               (22)
1.1 = 3.14×45×N
N = 1.1/141.3 = 0.008≈1
We know that,
P = 2πNT/60                                                                 (23)
Where, (i) p = power required, W; (ii) N = rpm of  the
roller; (iii) T = torque applied, N-m
T = (p×60)/(2π×N)                                                      (24)
2 = (2×3.14×1.×T)/4500
T = (2×4500)/(2×3.14×1)=9000/6.28=1433.12 Nm
When the pulverizer was operated on the ground it was
subjected to a sudden load, therefore while designing, the
torque was taken as 2 times the rated torque.
Tmax= 2×T                                                                    (25)
Tmax= 2×1433.12=2866.24 Nm

Design of  Pulverizing Blades
Pulverizing blades were fabricated and fixed into the
disc at 900 in such a way that it has continuously come
in contact with soil. Pulverizing blades were designed as
follows.
AT = pL×Tb   (Parmar & Gupta,2001)                                                  (26)
= 130 cm×0.4 cm=52 cm2

Where, (i) AT = total area of  pulverizing blade striking
on soil, cm2;(ii) pL = pulverizing length, cm; (iii) Tb =
thickness of  blade, cm.
The maximum soil resistance = Total area of  pulverizing
blade × the specific soil resistance
Msr = AT×Ssr                                                                (27)
= 52 cm2×0.75  Kg⁄cm2 =39 Kgf
Where, (i) Msr= maximum soil resistance, Kgf; (ii)  AT=
total area of  the blade, cm2; Ssr = specific soil resistance
Kg/cm2.

The maximum bending moment in the blade was
calculated by the following formula.
Mb= Sr×Rd                                                                   (28)
= 39 Kg×22.5 cm=877.5 Kg cm
Where, (i)Mb= maximum bending moment, Kg cm; (ii)
Sr= soil resistance, Kg⁄cm2 ; (iii)Rd= radial distance, cm.
The maximum bending stress for mild steel is 700 MPa,
calculating actual bending stress as per the following
formula (Sharma & Mukesh, 2010).
σb = (Mb × y)/I                                                          (29)
700 = (877.5×12×w×2)/(2×0.4×w3)
w = √(21060/560)=6.14 cm≈7 cm=7 cm
Where, (i) Mb= maximum bending moment; (ii)σb= actual
bending stress, N/cm2 (iii) y = distance height, = d/2;
(iv) I = moment of  inertia,= bt3/12; (v) w = width of
pulverizing blades.
Hence design is safe. Mild steel flat with 7 cm width, 130
cm length, and 0.4 cm thick was selected for pulverizing
blades.

Design of  the Pulverizing Roller Drive Shaft
The design of  the shaft must involve the determination
of  the minimum diameter of  the shaft material to
ensure satisfactory strength and rigidity when the shaft is
transmitting power under various operating and loading
conditions. The shaft was initially decided to be fabricated
from ductile material (mild steel rod).
Hence, the design was based on ductile material whose
strength is controlled by the maximum shear stress. For a
shaft having little or no axial loading, the diameter of  the
shaft was obtained using the ASME code Equation (39),
(ASME, 1995) given as:
d3 = 16/πSs [(kbmb)

2+(kt mt)
2](1/2)                                   (30)

Where, (i) d = diameter of  the shaft, mm; (ii) Mt =
torsional moment, Nm; (iii) Mb = bending moment, Nm;
(iv) Kb = combined shock and fatigue factor applied to
bending moment; (v) Kt = combined shock and fatigue
factor applied to torsional moment; (vi) Ss = allowable
stress, MN/m2.
For rotating shafts when the load is suddenly applied with
minor shock (Khurmi & Gupta, 2005), recommended
that values of  Kb = 1.2 to 2.0 and Kt = 1.0 to 1.50 be
used. Furthermore, it was noted that for the shaft without
the keyway, the allowable stress (Ss) must be 55 MN/m2,
and for the shaft, with the keyway, the allowable stress (Ss)
should not exceed 40 MN/m2.
The torsional moment (Mt) on the shaft was calculated
using Eqn. below (Ryder, 1989).
Mt = (p×60)/(2π×N)                                                   (31)
p = V×F                                                                       (32)
Where, (i) P = power required to drive the pulverizer; (ii)
N = speed of  the shaft, (1 rev/sec.); (iii) V = forward
speed (0.833 m/s); (iv) F = force required to drive the
machine (2.4 N).
Figure 6 shows the load distribution on the shaft. The
maximum bending moment on the shaft was determined
from the following expressions.
Mb= (Mv

2+Mh
2 )                                                          (33)



Pa
ge


30

https://journals.e-palli.com/home/index.php/ajsts

Am. J. Smart. Technol. Solutions 3(2) 25-33, 2024

Where, (i) Mv = vertical bending momentum, Nm; (ii)
Mh= horizontal bending momentum, Nm
The reaction of  forces on the driven shaft is as shown
below for vertical forces
The total resultant components of  horizontal and vertical
bending moments on the shaft can be obtained as follows.
Mb = (Mv

2+Mh
2 )1⁄2 =62,655,333.955 Nmm

Mt = (p×60)/(2π×N)
= (2×60)/(2×3.14×1)=51,858.25 Nmm
d3 = 16/(3.14×55) [(2×62,655.33)2+(1.5×51.86)2 ]1/2

d3 = 6,768,148.8/172.7= 39,304 mm
d = ∛39,304= 34 mm
Mt = torsional moment; Nm
Mb = bending moment; Nm
Kb = 2;  Kt = 1.5, and Ss = 55 MN/m2

Therefore, the standard size of  50 mm shaft diameter was
used.
Since the actual diameter was greater than the calculated
diameter. Therefore, the shaft has proper strength for
operation.

Selection of  Bearing
The size of  a bearing to be used depends on the size of
the shaft required and the available space. In addition, the
bearing must have a high enough load rating to provide
an acceptable combination of  life and reliability.
The bearing size was determined using the maximum
load acting on it and the desired maximum lifespan. The
dynamic equivalent radial load (W) is calculated by the
equation given below.
W = X.V.WR+Y.WA                                                      (34)
W = 0.4 × WR+ 1.6 × WR=  2 × 20 × WR= 80 kN
WR = 40 KN
Where, (i) WA= dynamic axial load; (ii) WR= dynamic
radial load; (iii) X= radial load factor; (iv) Y= axial load
factor; (v) V = A rotation factor, 1, for all types of
bearings when the inner race is rotating. Dynamic load
rating can be determined using Eqn. 35.
C= W (L/106 )1/k                                                          (35)
= 40× (20,000/106 )1/3=11 kN
Where, (i) L = Rating life; (ii) C = Basic dynamic load
rating; (iii) W = Equivalent dynamic load, and k = 3, for
ball bearings, = 10/3, for roller bearings.
Therefore the maximum lifespan value of  20,000 hr
was selected to determine the basic dynamic load rating.
Bearing number 207 with a bore of  35 mm was selected
since the minimum shaft diameter has been determined
to be 35 mm. Hence, two bearings used for the shaft of
the cultivator with pulverizing attachment were selected
based on the general criteria for bearing selection.

Determination of  Weight and Power Requirements
Weight of  the Implement
To estimate the loads on every part of  the cultivator with
pulverizing attachment, it should be necessary to estimate
the weight of  all parts. Accordingly, the weights of  the

cultivator tyne, frame, pulverizing blade, share (cutting
unit of  the cultivator), and disc were estimated (ITSI-SU,
2011). The total weight of  the cultivator with a pulverizing
attachment including the weights of  the frame, pulverizer
blade, three-point linkage unit, cultivator tine, and share
of  the cultivator was 1331.48 N. Taking 2% margins
for weights of  welding, bolts, nuts, etc. Finally, the total
weight of  the cultivator with pulverizing attachment was
found 1358.11 N.

Draft Requirement
The draft requirement of  the tractor-operated cultivator
with a pulverizing attachment was estimated using factors
related to implement and the type of  soil. The specific
soil resistance of  medium black soil of  the area was 0.75
kgcm-2 (Parmar & Gupta, 2001).
Total working width of  the cultivator
= number of  tine × tine spacing                                      (36)
= 7 × 22.86 cm =160 cm or 1.6 m
Cross section area of  furrows = Total working width of
the cultivator x depth of  furrow                                 (37)
= 160 cm × 30 cm = 4800 cm2.
The maximum draft required to drive the cultivator is
calculated as follows.
D = CAC×SR×g×FOS                                                  (38)
= 4800 cm2 × 0.75 Kg/cm2 × 9.81 m/s2 × 1.5
= 52,974 N
Where, (i) D = Maximum draft; (ii) CAC= Cross-section
area of  the furrows; (iii) SR = maximum soil resistance;
(iv) g = force due to gravity; (v) FOS= factor of  safety

Power Requirement
The power required to pull the designed implement was
estimated as follows.
Pd = (D×S)/1000=(52,974×0.833)/1000=44.13kW    (39)
Where, (i) Pd = power required to drive the implement;
(ii) D = draft required to drive a cultivator; (iii) S = speed
of  operation.
The power required to operate the cultivator with
pulverizing attachment was calculated as follows;
P= (Power required to drive the implement)/(Coefficient
of  friction)                                                                 (40)
P= 44.13/0.85=51.82≈52 kW
Where, (i) P = power required to operate the implement;
(ii) D = draft requirement of  the implement; (iii) S =
forward speed of  the tractor.

Laboratory Testing of  Prototype
Preliminary performance tests were carried out to obtain
actual data on overall implement performance and
work capacity. Performance evaluation (in terms of  soil
tilling quality and machine parameters) was determined.
The parameters that were taken during the preliminary
test were; the mean weight diameter of  the soil, wheel
slippage,  soil inversion, draft, the width of  cut, and
volume of  soil handled.



Pa
ge


31

https://journals.e-palli.com/home/index.php/ajsts

Am. J. Smart. Technol. Solutions 3(2) 25-33, 2024

Figure 3: Prototype Cultivator with Pulverizing Attachment after Fabrication and during Testing

Mean Weight Diameter of  the Soil
Soil samples were collected randomly from the tilled plots,
with three replications, using an auger at 0-30 cm depth
after the tillage process to estimate the clod mean weight
diameter. At room temperature, the moist soil samples
were allowed to air. The air-dried soil samples were sieved
with a set of  sieves. Clod’s mean weight diameter was
calculated using the following formula.

 (41)

Where, wi=the weight of  soil on each special sieve (kg)
w = the total weight of  experimented soil (kg)
Di = Net diameter of  each sieve (mm)

Wheel Slippage
The distances the tractor traveled a head at every 10
revolutions under load and no load on the same surface
were measured after a mark was created on the tractor
drive wheel with colorful tapes. The speed reduction can
be calculated as follows.
Travel reduction = (M2-M1)/M2 ×100                          (42)
Where, M2 = Distance covered at every 10
revolutions of  a tractor drive wheel with no load (m)
M1 =Distance covered at every 10 revolutions of  tractor
drive wheel with load (m).

Width of  Cut
The width of  the tillage implement’s cut was taken by
measuring the width of  the furrow using a measuring
tape every 5 meters along its length. The width of  the cut
was determined by averaging ten readings.

Draft
The following equation was used to calculate the draft of
the implement (ASME, 1995).
D=Fi [A+B(S)+C(S)2 WT]                                             (43)
Where, D = drawbar pull, N
F= a dimensionless soil texture adjustment parameter
i = soil factor = (1 for fine, 2 for medium, and 3 for
coarse texture soils)
A, B & C = machine – specific parameters
S = forward speed, km/h

T = tillage depth (cm) for major tools
W = machine working width, m.

Soil Inversion
The number of  weeds or residues of  the previous crop
remaining on the soil surface after the operation was
compared to the number before the operation. For
counting weeds or stubbles, a square frame with sides of
100 cm was employed.
F(%) = (B-A)/B×100                                                  (44)
Where, F= indicator for soil inversion,%
B= number of  weeds or crop residue before operation
per unit area,
A = number of  weeds or crop residue exposed on the
surface after operation.

Volume of  Soil Handled
As shown in the equation below, the amount of  soil
handled was estimated by multiplying the field capacity
with depth of  cut.
V(m3/h) = 10000EFC DC                                                (45)
Where, V = Volume of  soil handled (m3 /ha)
EFC = Effective field capacity (ha/h)
DC = Depth of  cut (m)

RESULTS AND DISCUSSION
Physical Properties of  Soil
Moisture Content of  Soil
The mean data on soil moisture content before tillage
operations at 0-20 cm depth was recorded and presented
in Table 2. The moisture content of  the soil varied from
13.9 to 14.54% with an average value of  14.14%.

Table 2: Soil moisture content (dry basis)
Sample
No.

Mass of
wet
soil
(gm)

Mass
of  dry
soil
(gm)

Soil
Moisture
content
(%)

Average
(%)

1 256.68 220.8 13.98
14.142 265.26 226.69 14.54

3 244.52 210.5 13.91



Pa
ge


32

https://journals.e-palli.com/home/index.php/ajsts

Am. J. Smart. Technol. Solutions 3(2) 25-33, 2024

Bulk Density of  Soil
Values of  bulk density before tillage operations at 0-20
cm depth were recorded and presented in Table 3. The

Table 3: Bulk density (gm/cc)
Sample No. Mass of  wet

soil (gm)
Mass of  dry
soil (gm)

The volume of
the core sampler
(cc)

Bulk density (gm/
cc)

Average

1 256.68 220.8 147.2 1.5
1.49                                                              2 265.26 226.69 147.2 1.54

3 244.52 210.5 147.2 1.43

bulk density of  the soil was found to be in the range of
1.43 g/cm3 to 1.54 g/cm3 with an average value of  1.49
g/cm3.

Laboratory Testing Results
Mean Weight Diameter of  the Soil
The range of  the clod means weight diameter was
observed between 10.21 to 11.77 mm. Maximum clod
means weight diameter of  was at a tractor forward speed
of  2.5 km/hr. The minimum value of  clod means weight
diameter was at a tractor forward speed of  3.5 km/hr. It
is seen from the result that a smaller clod percentage was
produced as the tractor’s forward speed increased. The
bigger clod percentage decreased and the smaller clod
percentage increased.
The increase in speed that causes a decrease in bigger clod
percentage might be a result of  the vibrating effect of  the
implement associated with an increase in the operating
speed of  the tractor. More clods break into smaller ones
as the implement with higher speeds throws the soil. The
improved soil aggregation was attainable at higher tractor
forward speed.

Wheel Slippage
Maximum wheel slippage (12.85%) was obtained at 3.5
km/hr tractor forward speed. Minimum wheel slippage
(13.44%) was obtained at 2.5 km/hr tractor forward
speed. Wheel slippage increased negatively as the tractor’s
forward speed increased for the tested implement. The
negative increase in wheel slippage might be a result of
the rolling resistance of  the tractor tires and the rolling
action of  the implement that oppose the rotational
movement for the increased tractor forward speed. A
negative increase in slippage percentage was observed
with an increase in tractor forward speed.

Width of  Cut
The width of  cuts varied between 140.00 to 143.83 cm.
The width of  cuts was found maximum (143.83 cm) at
3.5 km/hr tractor forward speed while the minimum
width of  cuts (140.00) was obtained at 2.5 km/hr tractor
forward speed. The width of  cuts increased with the
tractor’s forward speed. The reason might be due to the
high soil thrown by the implement at a higher tractor
forward speed than a lower tractor forward speed.

Draft
The draft of  the implement ranged between 8.19 to 8.59
KN. The maximum draft was obtained at 3.5 km/hr
tractor forward speed. The minimum draft was observed

at 2.5 km/hr tractor forward speed. The draft requirement
of  the implement increased as the tractor’s forward speed
increased. The reason might be due to higher force
requirement at a higher speed than lower speed.

Soil Inversion
The maximum soil inversion (89.17%) was found at 3.5
km/hr tractor forward speed. Minimum soil inversion
(82.41%) was found at 2.5 km/hr tractor forward speed.
Soil inversion increased as the tractor’s forward speed
increased. There was an increase in the percentage of  soil
inverted as the tractor’s forward speed increased. It might
be a result of  the implement’s ability to turn and throw
the soil when at a higher speed than at a lower speed.

Volume of  Soil Handled
The amount of  soil handled varied from 671.07 to 672.09
m3/ha. The maximum volume of  soil handled was at 3.5
km/hr tractor forward speed. The minimum volume of
soil handled was observed at 2.5 km/hr tractor forward
speed. The volume of  soil handled increased as the
tractor’s forward speed increased. This might be due to
the increment of  effective field capacity as the tractor’s
forward speed increased.

CONCLUSION
A cultivator with pulverizing attachment was designed
and developed to reduce secondary tillage operations to
a single pass to ensure timeliness in seedbed preparation.
The cultivator tines were fitted on the frame and at the
back side of  the frame pulverizing, the roller was attached
with help of  bearings.
The pulverizing blades were welded on the discs, in
such a way that was crushed the soil by impact force. In
this, the force exerted by the pulverizer on the clod is
distributed uniformly in the shaft which is used to hold
the pulverizing roller.
The roller was attached to a frame that holds cultivator
tines and a three-point linkage unit. The pulverizer
was designed to break big clods formed during tillage
operation. The developed implement was attached to the
tractor by three point hitch. Cultivator tines open furrow
and operated roller cut and pulverize soil at optimum
condition for tillage.
The preliminary test of  the cultivator with pulverizing
attachment in terms of  the width of  cuts, draft



Pa
ge


33

https://journals.e-palli.com/home/index.php/ajsts

Am. J. Smart. Technol. Solutions 3(2) 25-33, 2024

requirement, wheel slippage, soil inversion, the volume
of  soil handled, and clod mean weight diameter was
evaluated. Maximum clod means weight diameter of
was observed at a tractor forward speed of  2.5 km/
hr. The minimum value of  clod means weight diameter
was observed at a tractor forward speed of  3.5 km/hr.
Maximum wheel slippage (12.85%) was obtained at 3.5
km/hr tractor forward speed. Minimum wheel slippage
(13.44%) was obtained at 2.5 km/hr tractor forward
speed.
The width of  cuts was found maximum (143.83 cm) at
3.5 km/hr tractor forward speed while the minimum
width of  cuts (140.00) was obtained at 2.5 km/hr tractor
forward speed. The maximum draft was obtained at 3.5
km/hr tractor forward speed while the minimum draft
was observed at 2.5 km/hr tractor forward speed.
The maximum soil inversion (89.17%) was found at
3.5 km/hr tractor forward speed while minimum soil
inversion (82.41%) was found at 2.5 km/hr tractor
forward speed. The amount of  soil handled varied from
671.07 to 672.09 m3/ha. The maximum volume of  soil
handled was at 3.5 km/hr tractor forward speed. The
minimum volume of  soil handled was observed at 2.5
km/hr tractor forward speed.

REFERENCES
Alkhafaji, A. J. (2020). Designing and testing of  triple

combination tillage implement. Plant Arch, 20(1),
2363-2366.

Al-Shamiry, F. M. S., Al-Qarni, A. M. and Munassar,
A. S. (2020). Effect of  Tillage Depth and Tractor
Forward Speed on Some Technical Indicators of
the Moldboard Plow. International Journal of  Progressive
Sciences and Technologies, 23(2), 28-37.

Askari, M. & Khalifahamzehghasem, S. (2013). Draft
force inputs for primary and secondary tillage
implements in clay loam soil. World Applied Sciences
Journal, 21(12), 1789-1794.

ASME. (1995). Design of  transition shafting. American
Society of  Mechanical Engineering, New York, USA.

Digman, M. (2012). Saving time and fuel during tillage.
2011 Wisconsin Crop Production Association Distinguished
Service Awards, 95.

Dubey, A. K. (2003). Design of  sowing machine. Teaching
material for training on computer-aided design and
design methodology for agricultural machinery.
Technical bulletin no CIAE/AMD/2003/296, 92-102.

ITSI-SU, (2011). Mass, volume, and density of  regularly
and irregularly shaped objects. Internet: <http://

www.pdesas.org/module/content/resources/14756/
view.ashx>.

Javadi, A. R. Z. H. A. N. G. & Hajiahmad, A. (2006).
Effect of  a new combined implement for reducing
secondary tillage operation. International Journal of
Agriculture and Biology, 8(6), 724-727.

Kailappan, R., Vijayaraghavan, N. C., Manian, R.,
Duraisamy, G. & Amuthan, G. (2001). Combination
tillage tool-I Design and development of  a
combination tillage tool. Agricultural Mechanization in
Asia Africa and Latin America, 32(3), 19-22.

Khurmi, R. S. & Gupta, J. K. (2005). Theory of  Machines.
Eurasia publishing house Ltd. New Delhi, 8th Edition.

Krutz, G. and Thompson, L. (1984). Design of  agricultural
machinery (No. 631.3 K7).

Kumar, A. A., Kumar, A. A., Vidhyadhar, V., Mohan, K.,
Suresh, C., Rao, A. S. & Ramana, M. V. (2017). Design
and development of  groundnut planter for power
weeder. AMA, Agricultural Mechanization in Asia,
Africa, and Latin America, 48(3), 25-30.

Maheshwari, T. K., Thakur, T. C. & Varshney, B. P. (2005).
Spiked clod crusher and planker performance under
different soil conditions. Agricultural Engineering Today,
29(3and4), 6-11.

Manian, R. & Kathirvel, K. (2001). Development and
evaluation of  an active-passive tillage machine.
Agricultural mechanization in Asia Africa and Latin
America, 32(1), 9-18.

Parmar, R. P. & Gupta, R. A. (2016). Development and
performance evaluation of  a powered pulverizing
unit with a cultivator. Agricultural Engineering Today,
40(2), 3-9.

Prem, M., Swarnkar, R., Kantilal, V. D. K., Jeetsinh, P.
S. K. & Chitharbhai, K. B. (2016). Combined tillage
tools-a review. Current Agriculture Research Journal, 4(2),
179.

Reicosky, D. C. & Allmaras, R. R. (2003). Advances in
tillage research in North American cropping systems.
Journal of  Crop Production, 8(1-2), 75-125.

Ryder G. H. (1989). Strength of  Materials, 3rd ed.
Macmillan, Nigeria.

Sharma, D. N., & Mukesh, S. (2010). Farm Machinery
Design: Principal and Problems. Jain Brothers. New
Delhi. 196-199.

Zhou, H., Zhang, C., Zhang, W., Yang, Q., Li, D., Liu, Z. &
Xia, J. (2020). Evaluation of  straw spatial distribution
after straw incorporation into the soil for different
tillage tools. Soil and Tillage Research, 196, 104440.
