Laurie LaRusso, MS, ELS

Chestnut Medical Communications, Walpole, MA

By Jerm Day-Storms, PhD, MWC
Successful medical writers can clearly communicate a

message to the intended audience. Many times, the written

word alone may not be the most effective method of com-

munication. The client may even ask the medical writer

for help in designing a visual aid or presentation. Graphic

design tools are available, but they may be cost-prohibitive

or have steep learning curves for mastery. Instead, medical

writers can use a familiar tool, Microsoft PowerPoint, for

graphic design.

WHAT IS GRAPHIC DESIGN?
Graphic design is the art of visual communication using

text, images, and symbols. Medical writers use the 3

aspects of graphic design—layout, color, and typography—

to help convey the message of the project. The layout

consists of how the information is organized as well as how

visual elements are placed on the page or slide. The colors

and typography used can enhance the visual appeal of

the work.

 Graphics work by medical writers can be diverse.

Medical writers may be asked to format, lay out, or design

slides or posters for presentations. They may create spe-

cific visual elements, such as charts, graphs, or diagrams.

Typically, a client provides a template and color palette,

but a medical writer may be required to design a simple

color palette and template. Medical writers often transfer

graphics from one format to another. For example, a single

graphic element may be required to be transferred across

manuscript, slide, and poster formats.

 When designing graphics, medical writers must

• keep it simple by sticking to the main points,

• remove superfluous information,

• avoid an overwhelming number of objects and

colors, and

• use a logical order to make the story easy to

understand.

CHOOSING THE RIGHT TOOL FOR THE JOB
Deciding which graphical element best explains the data

is important. Will the intended audience understand the

story better if conveyed as a table, graph, diagram, or chart?

Sometimes, text is the best option if it is formatted to make

it visually appealing, such as by varying color or font. Other

times, a medical writer may transform one less effective

method into a better one for a particular point. For exam-

ple, a table comparing 2 different treatments may be easier

to understand as a graph.

 Because medical writers must use graphics in a vari-

ety of projects, it is important to delve deeper into different

types of graphics that can be produced using tools from the

Microsoft Office suite.

Tables
Tables are the simplest graphical elements created by

medical writers. For manuscripts, tables are created in

Microsoft Word using the Table function of the Insert menu

bar. Likewise, for posters and slides, tables are created in

PowerPoint using the Table function. Tables created within

either Word or PowerPoint are easily transferred by copy-

ing and pasting as a table with reformatting, as necessary.

Tables never need to be recreated when information is

moved from one format to another.

 When using tables as a visual element in a project, it is

best practice to keep color formatting consistent. For exam-

ple, in a presentation or poster, the control group should

be presented in tables as one specific color and the exper-

imental group(s) in another throughout the project to

increase the visual appeal and flow. Another option is to

use different background shades (from the same color

palette, of course) for the control and experimental groups.

 Tables can also be used to make text easier to read. Data

from bulleted lists can be transformed into a table with

horizontal lines and light background, creating a visual

element that is more scannable. Similarly, tables can be

used to simplify potentially complex topics by using differ-

ent shades and/or symbols to help classify groups of data

(Figure 1).

Session Report
DIY Graphics for Medical Writers

CONFERENCE

http://www.amwajournal.org


AMWAJournal.org     21DIY Graphics for Medical Writers

Figures
PowerPoint offers built-in Excel functionality, including the

ability to create visually appealing charts and diagrams. For

figures that are data-driven, such as graphs and charts, the

data are stored within the embedded spreadsheet. The data

can be easily updated in the spreadsheet with the changes

automatically reflected in the slide’s graph. Also, the graph

can be reformatted within the slide.

 Figures created within one presentation can easily be

copied across different platforms, including manuscripts

using Word or posters using PowerPoint. When copying a

figure from a slide into a manuscript, it is best to paste the

figure as a picture to lock in the formatting. When copying

the figure into a different PowerPoint file, do not paste the

figure as a picture. From the Paste Options menu, choose

“Keep Source Formatting & Embed Workbook” for data-

driven graphs. For any figures that are not data-driven,

choose either “Keep source formatting” to keep the graph

formatting the same as in the original file or “Use destination

theme” if the desire is to have the format match the new file.

 Resizing figures can be simplified by using the sizing

function for uniform resizing. Locking the aspect ratio

maintains the same proportions of the original objects.

It also allows for resizing multiple figures to precisely the

same size.

 Available figure options include traditional bar graphs,

scatter plots, line graphs, and pie charts. Additionally, more

complex biostatics charts, such as Forest plots and Box and

Whisker plots, can be created or modified to help explain

data. Labels can be added to the data even for select data

points, if desired. Background shades or use of shapes can

help highlight important data.

 Creative use of shapes, graphs, and gradients can be

used to visually tell a story. For example, a pie chart with a

subchart can further sub-divide data into groups (Figure 2).

This example is created using 2 pie charts connected by a

trapezoid filled in with a gradient to indicate a faded zoom.

Slides
PowerPoint’s reputation for creating robust slide presenta-

tions is well-known and well-documented. Generally, the

basics of any slide presentation consist of template, color,

and graphics. The client will usually provide the medical

writer with a slide template containing the approved color

palette and appropriate layouts. Occasionally, the medical

writer may be tasked with developing a template which can

be accomplished either by using or modifying one of the

many theme templates from Microsoft or by creating a tem-

plate within the Slide Master menu of PowerPoint.

 Color can be used to organize information throughout

the presentation to aid in the flow and to make it easier for

the audience to understand. Colors can be chosen from a list,

gradient, or wheel, depending on the chosen menu. It may be

difficult to precisely match 2 colors. Each color has a unique

six-digit hex code. If the hex code is known, it can be entered

in to choose a color. However, if the hex code is unknown,

the eyedropper tool can easily be used to select and match

a desired color. This is helpful, for example, when trying to

match legend colors to specific colors within a figure.

 Slide presentations should be visually appealing, so

graphical elements should comprise at least 2 out of every 3

slides. Keep text at a minimum by converting as much text

as possible to graphical elements. Keep any bullet points

to a single line of text, and do not use more than 2 levels of

bullet points on a single slide.

 Boring bullet point slides can be transformed into visu-

ally appealing graphical elements. For example, the bullets

Figure 1. The table as a visual element. Tables can be used to create
visual elements for classifying data by using shading and/or symbols.

Figure 2. Complex figures to depict data. Using graphs and charts
with shapes and gradients can help tell the story of complex data.

http://www.amwajournal.org


AMWAJournal.org     22DIY Graphics for Medical Writers

could be changed into vertical boxes with different shades

of color to help each point stand out. Rather than having a

bulleted list of dates or events, a timeline figure can be cre-

ated from the simple chevron shape in PowerPoint. Insert

the chevron and stretch it out to create a timeline figure.

The figure can even be filled in with a gradient of colors to

help emphasize the passing of time or events. Likewise,

lines and icons can be added to the timeline. The color of

icons can even be altered to match the timeline color. Also,

a simple bulleted list can be turned into an eye-grabbing

visual aid with the addition of color and stock figures. For

example, see how the following list is radically changed

(Figure 3).

 Slide animations should be used sparingly. Do not use

animations as devices to transition from one slide to the

next, such as the spinning slide, because it can distract from

the presentation rather than enhance the story. Only use

animation to help the audience follow the story. For exam-

ple, a build can be used to show progression or highlight

important trends. If a graph, gel, or image contains large

amounts of data, then an animation can be used to help the

audience digest the information in smaller pieces.

Posters
Poster presentations can be created using PowerPoint’s

Slide Size menu function in which the poster is created

on a single slide of the appropriate poster dimension. The

poster layout, which plays a vital role in the presentation

organization, may be either portrait or landscape. For por-

trait posters, the presentation is divided into horizontal

sections whereas it is divided into vertical sections for land-

scape posters. Regardless, the largest section of the poster

organization should be reserved for the results. The title

and authors are always listed across the top of the poster.

Additional poster sections include introduction/back-

ground, methods, and conclusions/summary. One way

to economize space, if possible, is to move any acknowl-

edgments, references, and disclosures to the bottom of the

poster in a smaller font. Posters should be saved as a PDF.

 Like a slide presentation, color is an important aspect of

the graphic design. Use one main color with 2 accent colors

chosen from the color palette. Some graphs or figures that

contain more data may require additional colors. The colors

should be used consistently throughout the poster to main-

tain clarity and flow.

 Poster content should primarily be visual elements with

text at a minimum. The graphs, tables, and figures should

be easy to understand without requiring extraneous textual

details. Section headings, such as background and results,

should be one color with any subheadings in an accent

color to help visualize hierarchy.

MEDICAL WRITERS DO NOT NEED EXPENSIVE
TOOLS FOR DO-IT-YOURSELF GRAPHICS
Visually appealing, easy-to-follow graphical elements add

clarity to a presentation or manuscript. Medical writers can

successfully create their own graphics without using expen-

sive tools because Microsoft PowerPoint with its built-in

Excel function can create high-quality, editable visual ele-

ments. Usually, clients are familiar with Microsoft Office

Figure 3. Transforming bullets. Simple bulleted lists (top) can be
transformed into visually appealing graphical elements by using color
and images (bottom).

When creating graphics, remember
to keep it simple so that the intended
audience can follow the story and
to not distract from the message by
overloading with graphical elements
or an overabundance of colors.

http://www.amwajournal.org


AMWAJournal.org     23DIY Graphics for Medical Writers

products and are happy

that the graphics can be

easily transferred from one

format to another. When

creating graphics, remem-

ber to keep it simple so that

the intended audience can

follow the story and to not

distract from the message by

overloading with graphical

elements or an overabun-

dance of colors. By know-

ing which Microsoft Office

product can be used to create

the project and how to transfer

it (Figure 4), medical writers can design their own graphical

elements or projects at lower cost and lower learning curve

than an expensive graphics program when using a platform

that most clients use.

Jerm Day-Storms is the owner and Principal Medical Writer at
Day-Storms Medical Writing & Research, Lakeland, FL.

Author declaration and disclosures: The author notes no com-
mercial associations that may pose a conflict of interest in rela-
tion to this article.

Author contact: jerm@day-storms.com

Figure 4. Do-it-yourself graphics for medical writers. Medical writers can use inexpensive tools, such as
Microsoft PowerPoint, to create, transfer, and present graphical elements.
