Clinical and radiological assessment of the dental implantation technique in

patients with complete absence of teeth using the DICOM program.

Dustmatov J.E.
1
, Makhkamova F.T.

2
, Gulyamov S.S.

2

1- Tashkent State Dental Institute

2- Tashkent Pediatric Medical Institute

Corresponding author: pulatabilov1985@mail.ru

Abstract. According to data from various regions of Uzbekistan, patients with

a complete absence of teeth (POD) are encountered for the first time in the 45-49 age

group. By 2020, the number of patients with POI in Uzbekistan will exceed 15

million people, and then among our adult fellow citizens every five years, this
number is expected to increase by 3-5%.During follow-up (6-18 months) after

prosthetics, signs of peri-implant mucositis in the form of hyperemia, edema were

observed in the area of 4 out of 100 (4.00%). Such patients were prescribed Traumeel
S. During the study of suppuration, the presence of ulcerations, fistulas, pain was not

noticed, and complaints of these manifestations were absent, the phenomena of

mucositis could be quickly stopped. No cases of peri-implantitis were diagnosed.

Radiographically vertical bone atrophy, i.e. the appearance of peri-implant pockets
was not detected. Insignificant horizontal atrophy was observed in 2 implants by the

end of 18 months (2.00%) and averaged 0.62 ± 0.13 mm. In the control group (39

patients), 39 complete removable prostheses were made, supported by 98 implants.
During follow-up (6-18 months after prosthetics), signs of peri-implant mucositis in

the form of hyperemia and edema were observed in the area of 8 implants (8.10%).

At the same time, loosening was determined in 4 of them (4.08%). During the study,

no suppuration, the presence of fistulas, or pain was detected. There were no
complaints about these manifestations. The phenomena of mucositis could be quickly

stopped. But it should be added that 1 case of peri-implantitis was diagnosed in this

group.
Conclusions. The loss of bone tissue in the main group was at the level of 0.54

± 0.21 mm, while in the control group it was 0.74 ± 0.32 mm. Moreover, foreign

studies have shown that in the presence of 3 implants, bone loss ranged from 0.5 ±

0.46 mm to 0.7 ± 0.76 mm.
Keywords: DICOM program; complete absence of teeth; peri-implantitis;

mucositis; implants; dental computed tomography


Introduction. According to data from various regions of Uzbekistan, patients

with a complete absence of teeth (CAT) are encountered for the first time in the 45-

49 age group. At the age of 55-59 years, every fourth surveyed has the named
pathology, and for the age of 65-69 years this figure is already 42.8%. The overall

prevalence of complete absence of teeth for different regions of our country ranges

from 8.2 ± 0.46 to 9.3 ± 0.67. By 2020, the number of patients with CAT in
Uzbekistan will exceed 15 million people, and then among our adult fellow citizens

every five years, this number is expected to increase by 3-5%.

Abroad, the number of patients with CAT in the United States is 27 million,

and although the reduction in the prevalence of CAT is declared a major medical goal

mailto:pulatabilov1985@mail.ru


Art of Medicine           Volume-1

International Medical Scientific Journal       Issue-2

10.5281/zenodo.5533441

128

in the United States, according to forecasts for the first 3-5 decades of the 21st

century, this prevalence will grow steadily [5, 12, 23, 27, 30 , 38]. According to some
foreign authors, CAT occurs already in patients aged 34 years [1, 2, 4, 8, 14, 25, 31].

In modern conditions, patients with CAT have every opportunity to abandon

conventional removable prostheses in favor of non-removable prosthetic structures

supported by implants.
The manufacture of implant-supported dentures can significantly improve the

chewing function and improve the quality of life of patients with POP. The use of

complete removable dentures with implant fixation in comparison with conventional

removable prosthetics increases patient satisfaction with the results of treatment by
more than 2 times. Satisfaction of patients with CAT also significantly increases after

conditionally removable and fixed prosthetics [6, 11, 13, 17, 20-22, 28, 33, 34,

36,35].
Thus, dental implantation can be considered not only one of the most

promising options for orthopedic treatment of patients with POP, but also considered

as the basis for effective orthopedic treatment and improving the quality of life of this

category of patients [3, 7, 15, 19, 24, 29, 32, 39].
As you know, the installation of any implants requires increased attention and

absolute accuracy from the implantologist. The lack of a clear planning of the

placement of implants in the bone tissue, their installation depending only on the
clinical situation, which is assessed only visually on the basis of our own clinical

experience and X-ray data, can lead to incorrect implant placement. However, in

dental implantation, CT examination itself without specialized software and 3-D

modeling is not informative enough [9,10,16,18,26,37,40]. There are various
computer programs that allow the planning and placement of implants with a

predetermined result with the presence of parallel suprastructures. One of these

programs is DICOM (Implant-assistant).
The low quality of life of patients, especially those with complete loss of teeth,

against the background of a relatively high frequency of complications that occur

after the installation of dental implants, confirms the postulate that there is still a

shortage of methods with a high efficiency of choice of tactics and sequence of
orthopedic treatment of this pathology, indicating on the relevance of this study.

Purpose of the study. To evaluate the effectiveness of using the DICOM

program in patients with complete absence of teeth according to the data of dental
computed tomography at the stage of the dental implantation technique.

Materials and research methods. In total, we examined 80 patients with

complete loss of teeth, of which 29 were men, 51 were women. The age of the

patients was 51-66 years (mean age 58.5 ± 4.5 years).
Implant prosthetics was carried out at the Department of Advanced Training of

Prosthetic Dentistry TGSI. Implants from Osstem Implant (South Korea) were used.

All patients were divided into 2 groups: group 1 (main) - 41 patients, of whom
14 were men, 27 women (mean age 56.7 ± 4.2 years), group 2 (control) - 39 patients

were included 15 men, 24 women (mean age 59.5 ± 4.7 years).

Patients were separated by simple randomization.



Art of Medicine           Volume-1

International Medical Scientific Journal       Issue-2

10.5281/zenodo.5533441

129

All patients signed written consent to participate in the study.

Research methods.

1. Clinical - included a standard technique, which consisted of examination,

examination of the oral cavity. Clinical evaluation included determination of the

severity of gingival recession, the severity of the implant, bleeding of the peri-

implant cuff, inflammation, the level of oral hygiene and prostheses.
2. X-ray - performed using a dental computed tomograph PLANMECA

PROMAX 3D. Her data were used using the DICOM program to assess anatomical

and topographic landmarks, the risks of surgical intervention and planning for

implant insertion.
X-ray examination was performed before implantation, 6 months after the

prosthetics

1. Statistical - carried out using the methods of variation statistics of the
Student-Fisher test.

Research results. In the main group (41 patients), 41 complete fixed

prostheses were made, supported by 100 implants. Before the operation, plaster

models of the jaws were obtained and fixed in an Asa dental articulator using a facial
arch. In the dental laboratory, a wax composition with artificial polymer teeth (before

the surgical template) was prepared, an individual template-spoon made of

transparent plastic for the subsequent impression of the prosthetic bed during the
operation with simultaneous registration of the central ratio.

Fig. 1. Planning dental implantation using the DICOM program.





Art of Medicine           Volume-1

International Medical Scientific Journal       Issue-2

10.5281/zenodo.5533441

130


According to the obtained X-ray template, a surgical template was made using the

DICOM program (Fig. 2).

Fig. 2. Carrying out an operation using a surgical template


Fig. 3. Template fixed with a screw to the implants





Art of Medicine           Volume-1

International Medical Scientific Journal       Issue-2

10.5281/zenodo.5533441

131

Fig. 3. Template fixed with a screw k During observation (6-18 months) after

prosthetics, signs of peri-implant mucositis in the form of hyperemia, edema were
observed in the area of 4 out of 100 (4.00%). Such patients were prescribed Traumeel

S. During the study of suppuration, the presence of ulcerations, fistulas, pain was not

noticed, and complaints of these manifestations were absent, the phenomena of

mucositis could be quickly stopped. No cases of peri-implantitis were diagnosed.
Radiographically vertical bone atrophy, i.e. the appearance of peri-implant pockets

was not detected. Insignificant horizontal atrophy was observed in 2 implants by the

end of 18 months (2.00%) and averaged 0.62 ± 0.13 mm.

In the control group (39 patients), 39 complete removable prostheses were made,
supported by 98 implants.

The preliminary prosthesis was fixed on the day of taking the impression using

transitional elements - temporary support heads made of titanium alloy, having been
carefully previously carefully finished, ground and polished

implants.

Fig. 4. Temporary support heads fixed to implants.


Since these patients did not undergo dental computed tomography using the

DICOM program, and the results were assessed only using an orthopantomogram, the

patients were prescribed antibiotic therapy for 5-7 days (Ampiox 250 mg, 1 table 3

times a day), NSAIDs (Ketorol Pro ) to reduce soft tissue edema. The sutures were

removed on day 14 by removing the prosthesis and washing the implant shafts with
antiseptic solutions.

During follow-up (6-18 months after prosthetics), signs of peri-implant

mucositis in the form of hyperemia and edema were observed in the area of 8
implants (8.10%). At the same time, loosening was determined in 4 of them (4.08%).

During the study, no suppuration, the presence of fistulas, or pain was detected. There

were no complaints about these manifestations. The phenomena of mucositis could



Art of Medicine           Volume-1

International Medical Scientific Journal       Issue-2

10.5281/zenodo.5533441

132

be quickly stopped. But it should be added that 1 case of peri-implantitis was

diagnosed in this group.
Conclusions. The loss of bone tissue in the main group was at the level of 0.54 ±

0.21 mm, while in the control group it was 0.74 ± 0.32 mm. Moreover, foreign

studies have shown that in the presence of 3 implants, bone loss ranged from 0.5 ±

0.46 mm to 0.7 ± 0.76 mm. These values are comparable to those obtained by us in
the main group.





Art of Medicine           Volume-1

International Medical Scientific Journal       Issue-2

10.5281/zenodo.5533441

133



References.

1. A method of quantifying overall satisfaction of complete denture patients / Y.

Sato [et al.] // J Oral Rehabil. – 2000. – № 27. – Р. 952-957.

2. A  new  treatment  concept  for  rehabilitation  of  the  edentulons  mandible.

Preliminary results from a prospective clinical follow-up study / P.-I. Bränemark [et
al.] // Clin. Impl. Dentistry and Related Res. – 1999. – Vol. 1,  № 1. – P. 2-16.

3. A  systematic  review  and  meta  analysis  of  removable  and  fixed  implant

supported prostheses in edentulous jaws: Post loading implant loss / J. S. Kern [et al.]

// Clin. Oral Implants Res. – 2016. – № 27. – P. 174-195
4. A systematic review of the survival and compliation rates of all-ceramic and

metal-ceramic  reconstructions  after  an  observation  period  of  the  last  3  years.

Part  I: Single crowns // P. Pjetursson [et al.] // Clin. Oral Implants Res. – 2007. –
Vol. 18, № 3. – P. 73-85

5. A systematic review of the survival and complication rates of all-ceramic

and metal-ceramic reconstructions after an observation period of at least 3 years. Part

II: fixed dental prostheses / B. E. Sailer [et al.] // Clin. Oral Implants Res. – 2007. –
№ 18(3). – P. 86-96.

6. Allen, P. A patient-based assessment of implant-stabilized and conventional

complete dentures / P. Allen, A. McMillan, D. Walshaw // J. Prosth. Dent. – 2001. –
Vol. 85, № 2. – P. 141-147.

7. Alsabecha,  N.  Mandibular  single-implant  overdentures:  a  review  with

surgical and prosthodontic perspectives of a novel approach / N. Alsabecha // Clinical

Oral Implants Research. – 2009. – № 20. – P. 357.
8. Bränemark  Novum®:  A  new  treatment  concept  for  rehabilitation  of  the

edentulons mandible. Preliminary results from a prospective clinical follow-up study

/ P.-I. Bränemark [et al.] // Clin. Impl. Dentistry and Related Res. – 1999. – Vol. 1, №
1. – P. 2-16.

9. Chen,  S.  Esthetic  ontcomes  following  immediate  and  early  implant

placement in the anterior maxilla: a systematic review / S. Chen, D. Buser // Int. J

Oral Maxillofac. Implants. – 2014. – Vol. 29. – P. 186-215.
10. Consensus  statements  and  clinical  recommendations  for  prevention  and

management of biologic and technical implant complications / L. Heitz-Mayfield [et

al.] // Int. J Oral Maxillofac. Impl. – 2014. – Vol. 29. – № l. – P. 346-350.
11. Critchlow, S.  B.  Prognostic  indicators  for  conventional  complete  denture

therapy: a review of the literature / S. B. Critchlow, J. S. Ellis // J Dent. – 2010. – №

38. – P. 2-9.

12. De Lima, E. Patients expectation of and satisfaction with implant-supported
fixed partial dentures and single crowns / E. De Lima, M. Dos Santos, L. Marchini //

Int. J Prosthodont. – 2012. – Vol. 25, № 3. – P. 484-490.

13. Degidi,  M.  A  10-year  follow-up  of  immediately  loaded  implants  with
TiUnite porous anodized surface / M. Degidi, D. Nardi, A. Piattelli // Clin. Implant

Dent. Relat Res. – 2012. – Vol. 14. – P. 828-838.



Art of Medicine           Volume-1

International Medical Scientific Journal       Issue-2

10.5281/zenodo.5533441

134

14. Do implant overdentures improve dietary intake? A randomized clinical trial /

N. Hamdan [et al.] // J Dent. Res. – 2013. – Vol. 92, № 12. – P. 146-153
15. Does  immediate  loading  affect  clinical  and  patient  centered  outcomes  of

mandibular 2 unsplinted implant overdenture? A 2 year within case analysis / E.

Emami [et al] // J of Dent. – 2016. – № 50. – P. 30-36.

16. Duvernay, E. Dental appearance and personality trait judgment  of elderly
persons / E. Duvernay [et al.] // Int. J Prosthodont. – 2014. – Vol. 27, № 4. – P. 348-

354.

17. Esposito,  M.  Agreement  of  quantitatire  subjective  evaluation  of  esthetic

changes in implant dentistry by patients and practitiovers / M. Esposito, M. Crusovin,
H. Worthington // Int. J Oral. Maxillofac. Implants. – 2009. – Vol. 24. – P. 309-315.

18. Five  year  study  of  mandibular  overdentures  on  stud  abutments:  Clinical

outcome, patient satisfaction and prosthetic maintenance – Influence of bone
resorption and implant position / C. Matthys [et al.] // Clin. Oral Impl. Res. – 2019. –

№ 30(9). – P. 940-951.

19. Functional  and  esthetic  comparison  of  metal-ceramic  and  all-ceramic

posterion three-unit fixed dental prostheses / M. Nicolaisen [et al.] // Int. J
Prosthodont. – 2016. – Vol. 29, № 5. – P. 473-481.

20. Gallucci  Success  criteria  in  implant  dentistry:  a  systematic  review  /  P.

Papaspyridakos [et al.] // J Dent Res. – 2012. – № 91. – P. 242-248.
21. General well-being as an important co-factor of self-assessment of dental

appearance / S. Wolfart [et al.] // Int. J Prosthodont.  – 2006. – Vol. 19. – P. 449-454.

22. Immediate rehabilitation of the edentulous jaws with full fixed prostheses

supported by four implants: interium results of a single cohort perspective study / E.
Agliardi [et al.] // Clin Oral Implants Res. – 2010. – Vol. 21. – P. 459-465.

23. Impact of crestal bone resorption on quality of life and professional main

tenance with conventional dentures or Locator retained mandibular implant
overdentures / C. Matthys [et al.] // J of Pros. Dent. – 2017. – № 120. – P. 886-894.

24. Impact  of  patient  characteristics  on  edentulous  subjects'  preferences  for

prosthodontics rehabilitation with implants / C. R. Leles [et al.]  // Clin Oral Implants

Res. – 2019. – № 30(3). – P. 285-292.
25. Influence  of  controlled  immediate  loading  and  implant  design  on  peri-

implant bone formation / K. Vandamme [et al.] // J Clin. Periodontol. – 2007. – Vol.

34. – P. 172-181.
26. Koldsland, O. Prevalence of peri-implantitis related to severity of the disease

with different degrees of bone loss / O. Koldsland, A. Scheie, M. Aass // J

Periodontol. – 2010. – Vol. 81. – P. 231-238.

27. Layton,  D.  Patient-evaluated  dentistry:  development  and  validation  of  a
patient  satisfaction  questionnaire  for  fixed  prosthodontic  treatment  /  D.  Layton,

T. Walton // Int. J Prosthodont. – 2011. – Vol. 24, № 4. – P. 332-341.

28. Liddelow, G. The immediately loaded single implant-retained mandibular
overdenture: A 36-month prospective study / G. Liddelow, P. Henry // Int. J

Prosthodont. – 2010. – Vol. 23, № 1. – P. 13-21

29. Longitudinal study  of  quality  of  life  of  elderly  with  mandibular  implant-



Art of Medicine           Volume-1

International Medical Scientific Journal       Issue-2

10.5281/zenodo.5533441

135

supported fixed prostheses / G. Berretin-Felix [et al.] // Clin. Oral Implants Res. –

2008. – Vol. 7. – P. 704-708.
30. Long-term changes in oral health-related quality of life over a period of 5 years

in patients treated with narrow diameter implants: A prospective clinical study / D. R.

Reissmann [et al.]  // J of Dent. – 2018. – Vol. 75. – P. 84-90.

31. Long-term  results  of  mandibular  implants  supporting  and  overdenture:
implant survival, failures, and crestal bone level changes / T. Ueda [et al.] // Int. J

Oral Maxillofac. Implants. – 2011 – Vol. 26. – P. 365-372.

32. Malo,  P.  Implants  placed  in  immediate  function  in  periodontally

compromised sites: a five-year retrosrective and one-year prospective study / P.
Malo, M. de Araujo Nobre, B. Rangert // J Prothet. Dent. – 2007. – Vol. 97, № 6. – P.

86-95.

33. Mandibular  two-implant  overdentures:  prosthodontic  maintenance  using
different  loading  protocols  and  attachment  systems  /  A.  Mackie  [et  al.]  //  Int.

J Prosthodont. – 2011. – Vol. 24, № 5. – P. 405-416.

34. Maryod, W. H.  Immediate versus early loading of mini-implants supporting

mandibular overdentures: a preliminary 3-year clinical outcome report / W. H.
Maryod, S. M. Ali, A. F. Shawky // Int. J Prosthodont. – 2014. – Vol. 27, № 6. – P.

553-560.

35. Mericske-Stern,  R.  Optimal  number  of  oral  implants  for  fixed
reconstructions: A review of the literature / R. Mericske-Stern, A. Worni // Eur. J

Oral Implantol. – 2014. – Vol. 7, № 2. – P. 133-153.

36. Mombelly, A. The diagnosis and treatment of peri-implantitis / A. Mombelli,

N. Lang // Periodontol. – 2000. – Vol. 17. – P. 63-76.
37. Nogueira, T. E. Changes in masticatory performance of edentulous patients

treated with single-implant mandibular overdentures and conventional complete

dentures / T. E. Nogueira, M. Schimmel, C. R. Leles // J Oral Rehabil. – 2019. – №
46(3). – P. 268-273

38. Patient Eligibility for Standardized Treatment of the Edentulous Mandible:

A Retrospective CBCT-Based Assessment of Mandibular Morphology / W. Aouini

[et.al.] // J Clin. Med. – 2019. – № 8(5). – P. 616.
39. Patient  satisfaction  versus  retention  of  implant  overdentures  with  two

attachment systems: A randomized trial / R. F. de Albuquerque [et al.]  // Clin.

Implant Dent. Relat. Res. – 2018. – № 21. – Р. 21-31.
40. Patient-reported  outcome  measures  of  edentulous  patients  restored  with

implant-supported removable and fixed prostheses: A systematic review / C. J. Yao

[et. al.] // Clin. Oral Implants Res. – 2018. – № 29(16). – P. 241-254.
