Optimizing Storage and Picking Routes in Dual-Zone Warehouses Using Genetic
Algorithms: A Case Study of YY Company


Jia Hui Ye1
Chang Jun Liu2*

An-Shin Shia3






1,2,3Business School, Lingnan Normal University, Zhanjiang, China.
Email: liuchangjun9009@126.com
( Corresponding Author)


Abstract

This research addresses the optimization of storage locations and picking routes in YY’s dual-
zone warehouse, with the goal of cutting warehousing costs and enhancing operational efficiency.
As the economy shifts and industrial structures upgrade, the logistics industry’s significance in
the national economy grows increasingly evident. The Apriori algorithm discerns order item
associations, informing the reorganization of storage allocations for optimized efficiency. On this
basis, a target optimization model is constructed to further enhance the rationality of the storage
layout. Regarding the optimization of picking paths, this paper presents a path optimization model
tailored for multi-vehicle operations, based on the layout characteristics of YY’s warehouse. This
paper validates the improved genetic algorithm’s effectiveness and practicality in optimizing
double-zone warehouse storage and picking paths through Matlab simulations and comparisons
with traditional methods.


Keywords: Apriori algorithm, Genetic algorithm, Picking path optimization, Storage location optimization, YY Company (YY’s).

JEL Classification: L9; M.M10; M19.


1. Introduction
1.1. Background of this Study

As China’s economy grows, the logistics industry, vital for development, faces rising demands for efficiency and
service quality. The double-zone warehouse, a typical layout, is crucial for accommodating diverse goods and
enhancing logistics efficiency. Confronted with the escalating market demand, the double-zone warehouse is
encountering increasingly significant challenges in cargo space allocation and picking path planning, which exert a
direct influence on warehousing costs and operational efficiency.

In China, rising social logistics costs are significantly driven by warehousing, particularly in double-zone
warehouses where inefficient management exacerbates cost inefficiencies. The increasing proportion of
warehousing costs in China’s total social logistics expenses suggests potential for cost control optimization in
double-zone warehouses. This research aims to tackle the challenges faced by double-zone warehouses and devise
efficient optimization strategies.


1.2. Research Significance
The strategic value of storage optimization: This study aims to boost warehouse space efficiency and

streamline item handling by optimizing storage locations in dual-zone warehouses. An optimized storage layout
minimizes inefficient activities, boosts goods circulation, and consequently reduces warehousing expenses. In
addition, scientific storage management helps to improve the accuracy of inventory management, bringing more
standardized and efficient warehousing services to enterprises.

The value of picking path optimization: Optimization of the picking path is crucial for improving the
operational efficiency of double-zone warehouses. Implementing genetic algorithms for picking path optimization
significantly reduces picker walking distances and times, boosts picking efficiency, and ultimately enhances the
overall warehouse operation efficiency. Moreover, optimizing picking paths contributes to lower labor and training
costs, thereby enhancing a company’s market competitiveness.


1.3. Current Research Status
Research in warehouse optimization commonly encompasses two essential components: storage location

optimization and path optimization. Recent years have seen significant advancements in warehouse optimization by
scholars worldwide:

Regarding storage location optimization, Bortolini., et al (2015) introduced a novel integer linear programming
model tailored for earthquake-prone industrial zones. Chou.,  et al (2012) developed a storage location allocation
strategy, grounded in recursive properties and significant proximity, specifically tailored for tiered warehouse

https://doi.org/10.55220/25766759.429


Asian Business Research Journal, 2025, 10(5): 30-50

31
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





architectures. Liu (2020) applied an enhanced Apriori algorithm coupled with an immune genetic algorithm to
optimize and resolve issues within storage management. Zhang and Li (2022) introduced a hybrid approach
leveraging deep learning and genetic algorithms to optimize storage locations in automated warehouses, thereby
enhancing storage efficiency.

Regarding path optimization, Chen., et al (2013) developed a picking congestion path algorithm rooted in Ant
Colony Optimization (ACO) and carried out an extensive simulation research. Xu and Ma (2021) developed a
mixed integer programming model focused on minimizing costs, employing an enhanced simulated annealing
algorithm to optimize shelf storage locations. Furthermore, Xu., et al (2021) developed a mathematical model for
the vehicle routing problem involving splittable demands, employing heuristic algorithms to optimize the solution.

Wang and Xu (2023) leveraged the integration of machine learning techniques and optimization algorithms to
concurrently optimize the configuration of goods and picking paths within warehouses, thereby reducing
operational duration and augmenting precision. Li and Qin (2024) harnessed reinforcement learning to create a
dynamic storage location optimization strategy capable of self-adjusting storage locations in response to real-time
inventory fluctuations.

Overall, while prior research has advanced model construction and algorithm application, this paper integrates
the Apriori association rule model from SPSS MODEL with an enhanced genetic algorithm to optimize warehouse
storage locations, subsequently refining picking paths based on this foundation. Leveraging Matlab for
computational analysis, this study aims to articulate a more efficient and pragmatic warehouse optimization
strategy.


1.4. Methods
1.4.1. Field Research

Initially, this research implemented field research to gather operational data and pertinent information from
YY’s warehouse. Throughout the working period, the researcher engaged directly in the warehouse’s daily
operations, acquiring firsthand data. This data encompasses goods access frequency, warehouse layout, and picking
task characteristics. Upon completion of the work, the gathered data was methodically arranged and analyzed,
laying the groundwork for subsequent model development and algorithmic simulations.


1.4.2. Virtual Simulation Research
In order to validate and refine the proposed genetic algorithm, this research employed Matlab for data

simulation purposes. By creating a simulated warehouse environment, this research replicated various storage
location and picking path setups, utilizing genetic algorithms to identify the best or nearly optimal solutions.
Virtual simulation permits not only the observation of the algorithm’s dynamic progression but also facilitates the
assessment of its performance and efficacy through comparison with real-world operational data. Additionally, this
research substantiated the superiority of the enhanced genetic algorithm in addressing double-zone warehouse
optimization issues via comparative analysis against other optimization techniques.


2. Related Theoretical Foundations
2.1. Basic Concepts

Regarding warehouse layouts, domestic enterprises typically employ single-zone, double-zone, and multi-zone
configurations, with this paper concentrating specifically on the double-zone variant. Figure 1 illustrates the
typical warehouse layouts:



Figure 1.  Common Warehouse Layouts.



2.1.1. Storage
Storage involves the process of enterprises retaining items in designated spaces to fulfill future requirements in

production, sales, or logistics. This encompasses activities like the receipt and categorization of goods, while
serving a crucial function within the supply chain for preservation, safeguarding, processing, and distribution


2.1.2. Storage Location
A storage location in a warehouse refers to a designated area with defined capacity and dimensions, designed

for storing specific types, quantities, and sizes of goods. Storage locations are categorized into temporary and fixed
types: temporary locations facilitate short-term storage and goods distribution, whereas fixed locations are



Asian Business Research Journal, 2025, 10(5): 30-50

32
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





optimized for long-term storage of homogenous goods. Efficient storage location management is essential for
enhancing warehouse operational efficiency and minimizing inventory costs, serving as a pivotal element in the
smooth functioning of the supply chain.

The commonly employed storage location management approaches and prevalent storage strategies are
detailed in Table 1.


Table 1. Storage Location Strategy.




2.1.3. Picking Path
Basic Definition: The picking path is the route taken by warehouse staff to fulfill order picking tasks within the

facility, and enhancing warehouse picking efficiency and reducing picking costs can commence with the
optimization of the picking path.

A well-structured picking path should encompass several key elements:
1).Shortest Path: The optimized path should be the shortest, reducing the total walking distance and picking

time for the picker to minimize picking costs to the greatest extent.
2).Simplicity and Practicality: The picking path must be free of design flaws, such as culs-de-sac and

crossroads, ensuring ease of operation for pickers equipped with picking devices to minimize the risk of errors.
Furthermore, operability and controllability must be considered, with the logistics system overseeing and

managing the path. These aspects will not be extensively discussed in this paper. Designing a well-structured
picking path can significantly enhance warehouse picking efficiency and reduce operational costs.


2.1.4. Picking Path

（1）Definition and Optimization Goals: The picking path is the route that warehouse personnel take to fulfill
order picking tasks. The primary goal of optimizing this path is to enhance efficiency and reduce costs, focusing on:

1) Shortest Path: Minimize walking distance and time to reduce costs.
2) Practicality: Avoid dead ends and intersections to ensure smooth operations and minimize errors.
A well-designed picking path can substantially enhance warehouse operational efficiency.

（2）Types of Picking Paths:
1) Cross-type Path: The picker enters from one end of the aisle, selects items from both sides, and proceeds

without returning, ideal for high-density picking. As illustrated in Figure 2:



Figure 2. Cross-type Path.






Asian Business Research Journal, 2025, 10(5): 30-50

33
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





2) Loop Path: In the loop path mode, the picker enters from one end of the aisle, selects items from one side,
returns along the same path, and then picks items from the other side, eventually exiting from the same end. This
method is ideal for situations where goods are concentrated at one end of the shelves, effectively reducing the total
walking distance. As illustrated in Figure 3:



Figure 3. Loop path.

2.2. Related Algorithm Theories
2.2.1. Basic Principles of Genetic Algorithms

Concept: Genetic algorithms are adaptive optimization techniques extensively applied in search, optimization,
and machine learning domains. Their strength lies in their capacity to adaptively seek the optimal solution,
irrespective of the specific form of the problem. Algorithm Flow:

1）Population Initialization: The problem parameters are encoded, often in binary form, to facilitate computer
processing.

2）Fitness Function: A measure used to assess the quality of chromosomes.

3）Selection Process: Chromosomes are chosen based on their fitness using techniques like roulette wheel
selection.

4）Crossover and Mutation: Parent chromosomes are randomly selected for crossover (such as single-point
crossover, with a crossover rate typically between 0.6 and 1) and mutation (with a mutation rate usually not
exceeding 0.1) operations to produce offspring. As illustrated in Figure 4, the OX crossover method is frequently
employed, yet there remains potential for enhancement.



Figure 1. OX crossover.



The OX crossover involves the following steps: Two individuals are selected from the parent population, and
two gene nodes are randomly chosen in parent 1 to extract a segment of the chromosome. The extracted segment
is duplicated onto the proto-child chain. In parent 2, the chromosome numbers corresponding to the extracted
segment are removed. The leftover chromosome numbers in parent 2 are sequentially filled into the gaps of the
offspring.

Enhanced Genetic Algorithm: Enhanced Selection Operation. The enhanced genetic algorithm employs
random traversal sampling in place of the conventional roulette wheel selection. This approach employs multiple
equally spaced gene selection points, enabling selection to be accomplished in a single rotation, thereby enhancing



Asian Business Research Journal, 2025, 10(5): 30-50

34
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





efficiency and ensuring fairness in the selection process. Table 2 contrasts the differences between the traditional
roulette wheel selection and random traversal sampling.


Table 1. Roulette Wheel vs. Random Traversal Sampling Method.




In the random traversal sampling, individuals are selected via multiple nodes, with equal spacing between these

nodes. The formula for equal distance is as depicted below:

𝐷𝑖𝑠 = 𝐹𝑡/𝑁

𝑟𝜖[0,
𝐹𝑡

𝑁
)

In this context, 𝑫𝒊𝒔 represents the equal distance between nodes，𝑭𝒕 denotes the cumulative fitness of the

individual，𝑵𝒖𝒎 indicates the quantity of individuals to be chosen，𝒓 represents the position of the starting point

in the node，That is, the starting point is randomly generated within the range[𝟎,
𝑭𝒕

𝑵
). Figure 5 is an illustration of

the random traversal sampling:



Figure 2. Random Traversal Sampling.

Enhancement in Crossover Operation: To overcome the limitation of the traditional OX crossover, which may
not always produce new individuals, the improved approach involves randomly selecting two nodes at identical
positions in two parent individuals and extracting the corresponding gene segments.

The extracted gene segments are positioned before and after the original parent individuals, respectively.
Duplicate gene segments are eliminated, resulting in the formation of new individuals. This enhancement
guarantees the generation of new child individuals even when the gene segments are identical, as illustrated in
Figure 6.



Figure 6. Crossover Process.



2.2.2. Basic Principles of Apriori Algorithm
Apriori Association Analysis is a technique employed to identify correlations between different data sets within

extensive datasets. The pertinent indicators and their definitions are presented in Table 3:




Asian Business Research Journal, 2025, 10(5): 30-50

35
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





Table 3. Related Indicators and Definitions.



An association rule is typically structured as:

X → Y，X ∩ Y = ∅

（1）For the rule X → Y，its rule（𝑆𝑢𝑝𝑝𝑜𝑟𝑡）is defined as:

𝑆𝑋→𝑌 =
𝑁(𝑋 ∩ 𝑌)

𝑁


Here, 𝑁(𝑋 ∩ 𝑌) denotes the total count of transactions where both X and Y are present. 𝑆𝑢𝑝𝑝𝑜𝑟𝑡, reflects the
commonality of the association rules that are obtained.

（2）For the association rule X → Y，its rule（𝐶𝑜𝑛𝑓𝑖𝑑𝑒𝑛𝑐𝑒）is defined as:

𝐶𝑋→𝑌

𝑁(𝑋 ∩ 𝑌)

𝑁(𝑋)
=

𝑆𝑋→𝑌

𝑆𝑋


Confidence is actually the probability of the latter occurring given that the former has occurred. In other

words, the 𝐶𝑜𝑛𝑓𝑖𝑑𝑒𝑛𝑐𝑒 of X → Y= 𝑆𝑢𝑝𝑝𝑜𝑟𝑡 of {X，Y}/𝑆𝑢𝑝𝑝𝑜𝑟𝑡 of {𝑋}。


2.2.3. Genetic Algorithm Combined with Apriori Algorithm
This study employs a hybrid approach of genetic algorithms and the Apriori algorithm for warehouse storage

location optimization, following this process:
Genetic Algorithm Solves Optimization Model: 1) Input data, set parameters (e.g., population size, number of

iterations).2) Initialize the population, assess individual fitness. 3) Conduct selection, crossover, and mutation
operations. 4) Iterate calculations until the termination condition is met, then output the optimal solution.

Apriori Algorithm for Selecting Associated Product Combinations: 1) Import customer order data, conduct
data preprocessing. Label data types, filter key values. 2) Utilize the Apriori algorithm for association rule analysis.

Adjust Storage Locations Based on Association Rules, Construct Optimization Model: 1) Utilize the results of
the Apriori algorithm to place highly associated products in adjacent storage locations. 2) Construct a storage
location optimization model with the goal of maximizing outbound rate and minimizing aisle distance.


3. Current Challenges in YY’s Warehouse Management
3.1. YY’s Overview

YY’s is a chemical enterprise focused on adhesive production, situated in the High-tech Development Zone,

boasting a production base of around 12,00㎡. The company represents internationally renowned brands and is
among the leading domestic enterprises in the field of neoprene adhesives. Embracing the concept of technological
innovation, YY’s continually refines its product line through industry-academia-research collaboration, catering to
industries like automotive, furniture, and decoration, and has developed new water-based adhesives, which have
become a new growth area for the company.


3.2. Analysis of YY’s Warehouse Operation Status
3.2.1. Overview of YY’s Warehouse

YY’s warehouse, operational since 2001, spans 4,600 ㎡ and is equipped with comprehensive facilities. The
warehouse features a double-zone structure, consisting of north and south zones, and is equipped with 16 rows and
32 columns of shelves. Each column of shelves contains 20 storage compartments, each measuring 2.4m x 1m. The
warehouse is equipped with 8 aisles, with entrances and exits situated on the right side of the main aisle, close to
the sorting area. Figure 7 presents the warehouse layout.




Asian Business Research Journal, 2025, 10(5): 30-50

36
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA






Figure 7. Warehouse Layout Plan.



3.2.2. Analysis of Warehouse Inventory Product Characteristics
YY’s manufactures four main series of adhesive products, which include: 1) Porsche Series: including

transparent nails, electronic white glue, etc. 2) Industrial Adhesives: such as grafting spray glue, SBS spray glue,
etc. 3) Adhesives for decoration and renovation: including Porsche adhesive, Baodeli 208, etc. 4)Water-based
adhesives (environmental series): such as Porsche water-based spray glue, etc.

The product features encompass a wide variety of types and substantial quantities of goods for storage and
retrieval. The four major categories are further divided into over 60 subcategories, with some products classified
under multiple categories. The detailed product classification is presented in Table 4.


Table 4. Partial Product Subcategory.




High Volume of Product Inbound and Outbound: YY’s finished product warehouse handled an average
monthly inbound volume of 80,000 units and an outbound volume of 25,000 units in December 2022, with a daily
outbound weight of 9 tons and a monthly outbound weight of 270,000 tons. The data indicates that the company
has a significant number of outbound shipments and the goods are heavy, but the turnover rate of the goods is
relatively low.


3.2.3. Analysis of the Current Status of YY’s Warehouse Management
Storage Location Strategy: YY’s employs a random storage location system, where warehouse personnel place

goods based on their entry and exit sequence, and the storage locations for the same type of goods are not fixed.
The details of the storage location arrangement are depicted in Figure 8.



Asian Business Research Journal, 2025, 10(5): 30-50

37
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA






Figure 8. Storage Location Map of Goods.


Picking Method: The company uses a manual picking method, where employees pick goods from the shelves

according to the orders and then perform centralized sorting.
Picking Path: In YY’s double-zone warehouse, the main aisle is 6 meters wide, and the aisles are 4 meters wide.

The picking path combines cross-type and return-type paths, and during peak hours, the picking behavior is
relatively disorganized.


3.3. Problems in the Management of YY’s Finished Product Warehouse
Improper Storage Location Management: The disorganized stacking of goods makes it difficult to locate them;

the lack of skills among warehouse personnel leads to longer picking paths due to experiential picking, which
reduces efficiency; unclear management systems lack standardized operations.


3.3.1. Low Picking Efficiency
Picking Efficiency (E) is determined by the quantity of goods picked and the time taken to pick them. The

specific measurement standard is the ratio of the number of goods picked (N) to the time taken (T). The longer the
time taken to pick the goods, the lower the efficiency. By analyzing the process of picking operations, a formula for
calculating the time consumed can be derived:

𝑇𝑡 =
𝐿𝑤

𝑆
+ 𝑇𝑎 × 𝑁 + 𝑇𝑤

Where Tt denotes the total time spent on picking, Lw denotes the path length, Sdenotes the walking speed, Ta

denotes the average time spent on picking a single item, N denotes the number of items picked, Tw denotes the time
window caused by external constraints. The above formula indicates that the picking efficiency of YY is affected by
several factors:

Inappropriate Storage Strategy Selection: The random storage strategy employed by YY is not conducive to
outbound inventory checks. Goods with high turnover may be stored in locations far from the In/Out gates,
leading to the same type of goods not being stored in the same area. Therefore, the random storage method can

lead to an increase in the average time spent on picking a single item（Ta）,  When there is a large volume of
goods in and out of storage, the lack of equipment can cause sequential waiting at each stage, increasing the time

cost（Tw）.
Inappropriate Picking Method Selection: The manual picking method employed by YY’s warehouse pickers,

when completing goods order picking, can lead to unnecessary repeated picking paths（Lw）due to the diverse
quantity of goods, resulting in low picking efficiency.

Random Picking Path: YY’s warehouse employs a picking path method that integrates both cross-type and
return-type paths. In situations where order demands are large and diverse, the random combination of picking

paths and non-standardized operations by pickers can lead to relatively unnecessary increases in the picking path（

Lw）, resulting in reduced picking efficiency.


4. Construction and Solution of YY’s Storage Location Optimization Model

This study aims to optimize storage locations in two stages: initially, conduct goods association analysis based
on order data to guide storage location allocation; subsequently, optimize the allocated storage locations through
modeling.


4.1 Goods Association Application
4.1.1. Goods Association Analysis

This study aims to uncover customer purchasing behavior and identify combinations of goods purchased
simultaneously. Using the Apriori algorithm in SPSS Modeler to analyze customer order data, Table 5 presents
some customer order records within a week.






Asian Business Research Journal, 2025, 10(5): 30-50

38
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





Table 5. Customer Weekly Order Data.

 Product
Customer

28 11 32 4 5 18 27 48 9 57 44 12 63 14

A 4 1 1 2 1 1 3 3 1 1 1 0 0 0

B 3 0 0 2 0 0 0 1 1 2 0 1 1 1

C 0 0 0 2 0 0 0 0 1 0 0 0 0 0

D 6 0 2 5 1 0 4 4 0 2 2 1 1 3

E 2 0 1 0 1 0 1 0 2 4 2 4 2 0

F 1 0 0 1 0 0 3 0 3 0 2 1 0 0

G 2 0 1 4 0 3 5 1 2 2 1 1 0 0

H 2 0 0 1 0 0 0 0 1 2 0 2 2 0

I 3 0 0 0 2 0 0 0 0 1 0 0 0 0

J 1 0 0 1 0 1 2 1 1 5 1 1 1 2

K 1 1 1 1 6 0 5 2 2 2 0 0 3 0

L 0 1 0 3 2 0 0 1 3 1 1 2 3 0

M 0 0 0 0 0 0 0 0 0 2 4 2 2 0

N 0 0 0 0 0 0 4 3 2 0 1 0 0 0

O 3 0 0 3 0 0 0 1 0 1 1 1 1 0

P 3 1 1 5 0 0 0 2 2 1 1 0 0 1

Q 1 0 0 3 0 1 0 0 0 2 0 0 0 0

R 5 1 1 3 0 0 3 2 2 0 0 2 1 2

S 0 0 0 2 0 0 8 1 2 3 0 0 1 0

T 0 0 0 5 0 0 1 0 3 0 0 0 0 0



The Apriori association rule model actually uses data information from 113 customers and 64 types of  ordered
products. However, Table 5 only presents partial information on the order quantities of  20 customers and 14
product categories. Based on customer order data, the Apriori model is used to solve and analyze the association
rules of  outbound product categories. In this study, the relevant rules are set as shown in Table 6:


Table 6. Association Rule Parameter Setting.




4.1.2. Analysis of  Association Degree Results
Due to space constraints, a selection of  association rules is presented in Table 7.


Table 7. Association Rule.

Rule(Support, Confidence)

1→12  (71.43%,97.56%) 1→14 , 7   (71.43%,96.23%) 16→13 , 1 , 7  (75%,90.48%)

15→14 , 1  (71.43%,90.3%) 16→14 , 1 , 7(71.43%,90%) 16→15 , 1 , 7  (75%,90.88%)

16→12 , 1  (71.43%,91.2%) 1→15 , 7   (75%,93.67%) 1→7      (92.86%,92.78%)

7→14  (71.43%,92.6%) 7→16 , 1   (85.71%,90.23%) 15→14    (71.43%,90%)

16→1  (92.86%,92.31%) 1→16 , 7   (85.71%,91.74%) 16→14    (71.43%,90.47%)

7→15  (75%,90.44%) 16→13 , 7  (75%,90.48%) 1→14     (71.43%,94.71%)

1→16  (85.71%,90.12%) 7→13     (78.57%,95.45%) 16→12, 7  (71.43%,90.69%)

16→7  (92.86%,92.31%) 1→15     (75%,96.23%) 7→12     (71.43%,90.74%)

7→1  (92.86%,90.85%) 7→16     (85.71%,91.44%) 15→14 , 7  (71.43%,90%)

16→12  (71.43%,90%) 16→1 , 7   (92.86%,92.31%) 7→13 , 1   (75%,90.47%)

16→14 , 1  (71.43%,90%) 7→12 , 1   (71.43%,90.64%) 16→14, 7  (71.43%,90.96%)

1→13 , 7  (75%,91.42%) 16→13 , 1  (75%,90.48%) 16→12 , 1 , 7 (71.43%,90%)

16→15  (75%,90.48%) 1→13     (78.57%,95.45%) 15→14 , 1 , 7 (71.43%,90%)

1→12 , 7  (71.43%,92.61%) 16→15 , 1  (75%,90.48%) 7→15 , 1   (75%,91.47%)

7→14 , 1  (71.43%,90.49%) 16→15 , 7  (75%,90.48%) 16→13 , 1 , 7 (75%,90.48%)



Asian Business Research Journal, 2025, 10(5): 30-50

39
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA








Figure 9. Association Network Diagram.



Based on the above table, the derived goods association rules are as follows: when purchasing goods 1, goods 12 will
also be purchased; when customers purchase goods 15, they will also purchase goods 14 and 1; and so on for the rest.
The network diagram illustrating the specific association rules is presented in Figure 9:

Based on the above association analysis, the following suggestions can be made: sort and combine the items based on
the level of  association, and adjust the original storage locations to place items with high association in adjacent areas, so
that high-association items can be picked together, thereby improving picking efficiency. The storage locations optimized
based on the association rules are as depicted below:



Figure 10. Partial Goods Storage Location Optimization Diagram.



4.2. Constructing the Storage Location Optimization Model
4.2.1. Problem Description

In a warehouse with 64 types of goods, 32 shelves, and 8 aisles, it is necessary to optimize storage location
allocation based on the average outbound rate of goods and the distance from the aisles to the entrance/exit to
minimize the picking distance.


4.2.2. Conditions for Applying Genetic Algorithm
The frequent itemsets identified by the Apriori algorithm serve as the genes for the genetic algorithm,

providing key information for establishing the initial population and genetic operations to achieve optimization
objectives.

The Apriori algorithm reduces non-frequent itemsets through pruning, enhancing the search efficiency of the
genetic algorithm, which aids in rapidly identifying the optimal solution.

Therefore, the data processed by Apriori is suitable for the genetic algorithm, with the expectation of achieving
good optimization results.



Asian Business Research Journal, 2025, 10(5): 30-50

40
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





4.2.3. Construction and Solution of the Mathematical Model
Model Assumptions: Based on the goods association analysis in 4.1, goods are combined, and on this basis, the

objective function is established with the outbound rate and aisle distance as the criteria. Adjusting Goods Storage
Locations: The higher the frequency of goods being taken out, the closer the adjusted storage location is to the
warehouse entrance and exit. Based on the layout of YY’s warehouse, the following model assumptions are made:

(1) Each order is picked by a single picker, and the number of vehicles and weight are known；
(2) The same SKU is stored in only one storage location, with the same quantity stored, and the weight is

known；
Symbols and Variables Description: To establish a mathematical model for warehouse storage location

allocation, the following variables are defined:

1）Index

n：The product category number, n=1，…，N；

t：The aisle number, t=1，…，T；

2）Symbol

N：The total number of product categories;

R：The outbound rate of goods, 𝑅𝑛: The outbound rate of the nth category of goods;

𝑑𝑡0：The distance from the tth aisle to the warehouse In/Out gate;

𝑆𝑖𝑔𝑛𝑛(𝑡0）：The association degree value between product n and aisle t, with a value range of 0-1.

Model Construction: Based on theoretical assumptions and storage location optimization objectives, a model is
established to determine the optimal allocation of goods that allows pickers to achieve the shortest distance:

𝑚𝑖𝑛𝐹 = ∑ ∑ 𝑅𝑛
𝑇
𝑡=1

𝑁
𝑛=1 𝑑𝑡0𝑆𝑖𝑔𝑛𝑛(𝑡0）（1）

𝑠. 𝑡: 𝑆𝑖𝑔𝑛𝑛(𝑡0） = {
0, The 𝑛𝑡ℎ type of goods is not allocated to aisle 𝑡；

1, The 𝑛th type of goods is allocated to aisle 𝑡.
2）

∑ 𝑆𝑖𝑔𝑛𝑛(𝑡0)
𝑁
𝑛=1 ≥ 1, 𝑡 = 1,2,3 … , 𝑇（3）

∑ 𝑆𝑖𝑔𝑛𝑛(𝑡0）
𝑇
𝑡=1 ≥ 1, 𝑛 = 1,2,3 … , 𝑁（4）

Equation（1）is the model’s objective function, which represents the shortest distance for all combinations of

goods to the In/Out area; Equation（2）is the decision variable in the model, indicating whether the nth type of
goods has been allocated in aisle t; Equation (3) indicates that a single aisle can store one or multiple categories of
goods; Equation (4) indicates that the same type of goods must be stored in the same aisle.

Solving the Storage Location Optimization Model Using the Enhanced Genetic Algorithm:

1）Algorithm Design: Based on the objective model listed above, and considering the overall layout and goods
situation of YY’s warehouse, the software is used to optimize and solve the problem. Some parameters in the
algorithm are shown in Table 8.


Table 8. Algorithm Parameter.




2）Optimization Effect Analysis: Based on the parameter settings mentioned above, input the specific
information data of warehouse goods, and the output results are shown in Table 9. Due to space constraints, only a
portion of the data is displayed. This table represents the storage location allocation derived from the optimization
mathematical model.












Asian Business Research Journal, 2025, 10(5): 30-50

41
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





Table 9. Output Results.

Variable Value Reduced Cost

C( 1, 8) 1.000000 5.016000

C( 2, 6) 1.000000 5.376000

C( 3, 7) 1.000000 4.752000

C( 4, 4) 1.000000 6.480000

C( 5, 7) 1.000000 4.752000

C( 6, 6) 1.000000 6.384000

C( 7, 1) 1.000000 1.100000

C( 8, 6) 1.000000 5.040000

C( 9, 6) 1.000000 4.704000

C( 10, 5) 1.000000 6.348000

C( 11, 5) 1.000000 5.796000

C( 12, 7) 1.000000 5.148000

C( 13, 1) 1.000000 1.220000

C( 14, 6) 1.000000 5.712000

C( 15, 2) 1.000000 2.960000

C( 16, 2) 1.000000 3.440000

C( 17, 1) 1.000000 1.060000

C( 18, 2) 1.000000 3.280000




The figure indicates that goods 1 should be placed in aisle 8, goods 2 in aisle 6, goods 3 in aisle 7, and so on, with
only a portion of  the data displayed due to space limitations.

To demonstrate the effectiveness of the improved genetic algorithm in solving the storage location
optimization problem, a specific dataset is formed by randomly selecting customer orders, and the path distances
before and after storage location optimization are compared. The random customer orders are shown in Table 10,
and the specific comparison results of the picking paths are shown in Table 11:


Table 10. Random Order Partial Data.

Product Category Original Aisle Number Current Aisle Number

1 3 8

3 3 7

4 1 4

7 7 1

8 4 6

11 2 5

14 4 6

17 2 1

18 1 2


Table 11. Algorithm Effect Comparison Diagram.

Order


S-shaped Path

（m）

Optimized Path

（m）
Difference value(m) Path Distance Savings %

1 603.2 478.2 125.2 20.7%

15 637.8 518.6 119.2 18.7%

26 644 496.4 147.6 22.9%



In summary, the optimized storage location allocation is shown in Figure 11:




Asian Business Research Journal, 2025, 10(5): 30-50

42
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA






Figure 11. Storage Location Optimization Allocation.



5. Construction and Solution of the Picking Path Optimization Model
Building on the storage location optimization, this study further refines the picking strategy and sequence for

YY’s warehouse to minimize the picking path.


5.1. Path Calculation

During the picking process, the quantity of goods and storage location information need to be collected. After
entering the system, computer-aided management of picking operations is implemented. Pickers proceed from the
In/Out gate to the storage location according to the list until the vehicle is fully loaded or the order is completed.
The following briefly describes the shortest path calculation method, considering the characteristics of YY’s
warehouse.


5.1.1. Symbols and Variables Description
Considering the zone-type characteristics of YY’s warehouse, achieving the shortest path requires classifying

and discussing the situation. The warehouse is divided into two zones, upper (north) and lower (south), with a total
of 16 rows of shelves from left to right, numbered 1-16. Each column in the two zones has 20 storage locations
from bottom to top, numbered 1-15, 16-20. The specific layout is shown in Figure 12, and the specific symbols and
variables are described as follows:

（1） 𝑎𝑖：The upper (north) and lower (south) 2 zones of the warehouse,

𝑎𝑖 = {
1, 𝑛𝑜𝑟𝑡ℎ
0, 𝑠𝑜𝑢𝑡ℎ

 ；

（2）𝑖 , 𝑗 : Storage location. 𝑖 , 𝑗 = 1, ,2,3, … , 𝑍；

（3）X：Goods. A good in a specific aisle is represented as 𝑋𝑡, with the storage location being 𝑋𝑖 and 𝑋𝑗;

（4）Any storage location in the warehouse to be picked is represented as 𝑃𝑖(𝑇𝑖  , 𝑎𝑖, 𝑐𝑖) , 𝑖 = 1,2,3, … , 𝑍 ;

Where 𝑇𝑖  represents the aisle number, 𝑇𝑖𝜖{1,2,3 … , 𝑎} ; 𝑐𝑖 represents the storage compartment number,

𝑐𝑖𝜖{1,2,3 … , 𝑚}, The maximum storage compartment number is m, 1 → 𝑚 ×
15

20
 represents the southern half of the

warehouse, 𝑚 ×
15

20
+ 1 → 𝑚 represents the northern half of the warehouse;

（5）Z: The total number of storage compartments in the warehouse, in this paper Z=320;

（6）𝑙1 is the length of the storage compartment, 𝑙2 is the length of the storage compartment, 𝑙3 is the width

of the aisle, 𝑙4 is the width of the middle passage, 𝑙5 is the width of the main passage. In this paper, 𝑙1=2.4m, 𝑙2=1m

，𝑙3=4m，𝑙4=5.6m，𝑙5=6m；




Asian Business Research Journal, 2025, 10(5): 30-50

43
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA






Figure 12. Warehouse Layout Diagram.



5.1.2. Analysis of Picking Path Scenarios
For the picking of goods in the warehouse, the scenarios can be roughly categorized into the following types:

（1）When goods A and B are distributed in the same aisle, there are two situations: the first is that the goods

are in the same area (either both in the upper zone or both in the lower zone), 𝑎𝐴, 𝑎𝐵 = 1 𝑜𝑟 𝑎𝐴, 𝑎𝐵 = 0; The

second is that the goods are distributed in different areas, 𝑎𝐴 = 1, 𝑎𝐵 = 0 𝑜𝑟 𝑎𝐴 = 0, 𝑎𝐵 = 1.

（2）When two goods to be picked are in the same area but different aisles, there are three major situations:

the first is when the goods are in the same area, 𝑎𝐴 = 𝑎𝐵 = 0；The second is when the goods are in the same area,

𝑎𝐴 = 𝑎𝐵 = 1；The third is when two goods to be picked are in different areas, 𝑎𝐴 ≠ 𝑎𝐵。

（3）Additionally, when goods A,B are in the same area, there are two walking paths, as shown in the specific
process diagram in Figure13. In the path calculation, these two walking paths each have a 50% probability, as
reflected in the specific case analysis in 5.1.3.






Asian Business Research Journal, 2025, 10(5): 30-50

44
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA






Figure 13. Walking Path Schematic Diagram.


5.1.3. Specific Case Analysis

（1）When any two goods 𝑋𝑖 and 𝑋𝑗 in the picking area are distributed in the same aisle, 𝑋𝑇𝑖 = 𝑋𝑇𝑗  (𝑖 ≠ 𝑗）,

there are several situations:

1). When the goods are in the same area (𝑎𝑖 = 𝑎𝑗), 1 ≤ 𝑐𝑖 , 𝑐𝑗 ≤ 15𝑚 20⁄  𝑜𝑟  15𝑚 20⁄ + 1 ≤ 𝑐𝑖, 𝑐𝑗 ≤ 𝑚，


2). When the goods are in different areas (𝑎𝑖 ≠ 𝑎𝑗),




（2）When two goods to be picked are in the same area but different aisles, 𝑋𝑇𝑖 ≠ 𝑋𝑇𝑗 , there are several

situations:

1).When the goods are in the same area, 𝑎𝑖 = 𝑎𝑗 = 0, the distance between goods in the southern area is:

①1 ≤ 𝑐𝑖 ≤ 15𝑚 40⁄  and 1 ≤ 𝑐𝑗 ≤ 15𝑚 40⁄



𝑑𝑖𝑗 =|𝑐𝑖 − 𝑐𝑗 | × 𝑙1

1 ≤ 𝑐𝑖 ≤ 15𝑚 20, 15𝑚 20⁄ + 1 ≤ 𝑐𝑗⁄ ≤ 𝑚      𝑜𝑟    15𝑚 20⁄ + 1 ≤ 𝑐𝑖 ≤ 𝑚, 1 ≤ 𝑐𝑗 ≤ 15𝑚 20⁄

𝑑𝑖𝑗 =|𝑐𝑖 − 𝑐𝑗 | × 𝑙1 + 𝑙5



Asian Business Research Journal, 2025, 10(5): 30-50

45
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





②15𝑚 40⁄ + 1 ≤ 𝑐𝑖 ≤ 𝑚 and 15𝑚 40⁄ + 1 ≤ 𝑐𝑗 ≤ 𝑚（50%）


③1 ≤ 𝑐𝑖 ≤ 15𝑚 40⁄ , 15𝑚 40⁄ + 1 ≤ 𝑐𝑗 ≤ 15𝑚 20⁄  or 1 ≤ 𝑐𝑗 ≤ 15𝑚 40⁄ , 15𝑚 40⁄ + 1 ≤ 𝑐𝑖 ≤ 15𝑚 20⁄


2).When the goods are in the same area, 𝑎𝑖 = 𝑎𝑗 = 1，the distance between goods in the northern area is:

①15𝑚 40⁄ + 1 ≤ 𝑐𝑖 ≤ 35𝑚/40 and 35𝑚 40⁄ + 1 ≤ 𝑐𝑗 ≤ 35𝑚/40:



②
35𝑚

40
+ 1 ≤ 𝑐𝑖 ≤ 𝑚 and 35𝑚/40 + 1 ≤ 𝑐𝑗 ≤ 𝑚:


③15𝑚 20⁄ + 1 ≤ 𝑐𝑖 ≤ 35𝑚/40, 35𝑚/40 + 1 ≤ 𝑐𝑗 ≤ 𝑚      or      35𝑚/40 + 1 ≤ 𝑐𝑖 ≤ 𝑚,15𝑚 20⁄ + 1 ≤

𝑐𝑗 ≤ 35𝑚/40：


（3）When two goods to be picked are in different areas, 𝑎𝑖 ≠ 𝑎𝑗, the distance between goods across the half

areas is:


（4）The distance from a storage location in the warehouse to the In/Out gate:

1).1 ≤ 𝑐𝑖 ≤ 15𝑚 20⁄ ：


2). 15𝑚 20⁄ + 1 ≤ 𝑐𝑖 ≤ 𝑚:



5.2. Problem Statement and Description

Optimizing picking paths is crucial for improving warehouse efficiency. Currently, most companies rely on the
intuition and experience of employees for picking. This section aims to improve the picking efficiency of YY’s
through scientific planning.

YY’s Warehouse Overview: The warehouse is divided into two levels, with 16 rows of shelves on each level,
numbered 1-16; each column in the north and south areas has 20 storage locations, numbered 1-20; the aisles are
numbered 1-8, close to the In/Out gate. The storage compartments are quadrilaterals with dimensions of

2.4m×1m, with a length (𝒍𝟏) of 2.4m, a width (𝒍𝟐) of 1m, an aisle width（𝒍𝟑）of 4m, a middle passage width（𝒍𝟒）

of 5.6m, and a main passage width（𝒍𝟓）of 6m.
The problem addressed in this paper is similar to the Vehicle Routing Problem (VRP), which is to choose the

best path from the In/Out gate to minimize the picking distance under given constraints.


5.3. Model Construction

5.3.1. Model Assumptions

（1）The source point (the In/Out gate), and the storage locations of the goods to be picked are known;

（2）The cost of the cart and the number of times the cart is used are not considered;

（3）In the same aisle, it is allowed to pick goods from both sides of the storage locations simultaneously;

（4）The order requires y trips to pick, and all y trips start from the In/Out gate.

5.3.2 Symbols and Variables Description

（1）𝑄𝑦𝑧：The quantity of goods picked from the zth storage location on the yth trip’s sub-circuit;

（2）𝐶𝑦𝑧：The zth storage location on the yth trip’s sub-circuit;

（3）𝐶𝑦：The path corresponding to the yth trip’s cart;

（4）𝑙𝑦：The number of storage locations on the yth sub-circuit;

（5）Q（K）：The total weight of the goods to be picked in the order;

（6）y：The corresponding serial number of the cart; Wi：The max of load capacity of the cart；

（7）D：The total distance to be traveled;

（8）t0： In/Out gate；S：The number of cart trips required;

（9）m：The number of storage locations for the goods in the order;



Asian Business Research Journal, 2025, 10(5): 30-50

46
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





（10）𝑑𝑦(𝑧−1)𝑧：In the yth trip’s corresponding route, the shortest picking distance between the (z-1)th storage

location and the zth storage location;

（11）𝑑𝑦(𝑙𝑦)(0)：The shortest picking distance between the 𝑙𝑦
th storage location in the yth trip’s corresponding

route and the warehouse in/Out gate t0.

5.3.3. Model Construction
In multiple trips, each trip forms a separate circuit, and the path planning and scheduling of the cart within

each circuit are determined to minimize the total travel distance D of the entire circuit.

min 𝐷 = ∑ [∑ 𝑑𝑦(𝑧−1)𝑧
𝑙𝑦

𝑧=1 + 𝑑𝑦(𝑙𝑦)(0) × 𝑠𝑖𝑔𝑛(𝑙𝑦)]𝑆
𝑦=0 （5-1）

𝑠. 𝑡.     𝑠𝑖𝑔𝑛(𝑙𝑦) = {
1, 𝑙𝑦 > 0

0, else
            （5-2）

∑ ∑ 𝑄𝑦𝑧
𝑙𝑦

𝑧=1
𝑆
𝑦=1 = Q(K）                      （5-3）

∑ 𝑄𝑦𝑧
𝑙𝑦

𝑧=1 ≤ 𝑊𝑖                     （5-4）

0 ≤ 𝑦 ≤ 𝑆                               （5-5）

∑ 𝑙𝑦
𝑆
𝑦=1 = 𝑚（5-6）

𝐶𝑦 = {𝐶𝑦𝑧|𝐶𝑦𝑧 ∈ {𝑆1, 𝑆2, … , 𝑆𝑚, 𝑍 = 1,2, … , 𝑙𝑦}             （5-7）

𝐶𝑦 ∩ 𝐶𝑧 = ∅, ∀𝑦 ≠ 𝑧                                （5-8）

In the above model, the objective optimization function is the shortest total walking distance; Table 5-2
indicates whether the yth cart is assigned to the picking task; Table 5-3 indicates that all goods required for the
order must be picked; Table 5-4 represents the capacity constraints of the transport tool (handcart), meaning the
total quantity of goods picked from each sub-circuit by the handcart must not exceed the maximum load capacity of
the handcart; Table 5-5 indicates that the handcart’s identification number must be constrained within the required
number of trips; Table 5-6 indicates that the sum of storage locations on the y sub-circuit must equal the number of
storage locations for the goods in the order; Table 5-7 to Table 5-8 indicate that in each storage location to be
picked, goods can only be picked once.

5.4. Model Solution Based on Genetic Algorithm
5.4.1. Algorithm Flow

Based on the introduction of the improved genetic algorithm and considering YY’s actual situation and the
above mathematical model, the algorithm flowchart for the picking path optimization problem is shown in
Figure14:


Figure 14. Algorithm Process.



5.4.2. Specific Steps in Algorithm Flow Design
Based on the algorithm flowchart, the specific algorithm steps are as follows:

（1）Determine Encoding: Use natural number encoding. For multi-cart goods picking in a single order, this
paper inserts the corresponding 0 in the natural number sequence, with the specific method as follows:

Assume in order A, there are 8 types of goods to be picked, and all 8 types of goods are distributed in different
8 storage locations. Based on the above content, 0 can be used to represent the warehouse’s In/Out gate, and the
natural numbers 1 to 8 can be used to represent individual storage locations. Now, let’s set the picking path for this
order as follows:



Asian Business Research Journal, 2025, 10(5): 30-50

47
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





Path 1：In/Out gate 0→Location 1→Location 4→Location 8→Location 5→In/Out gate 0

Path 2：In/Out gate 0→Location 2→Location 3→Location 6→Location 7→In/Out gate 0
The natural number sequence represented by the genetic algorithm is: {0 1 4 8 5 0 2 3 6 7 0}.

To better encode the data, the storage locations required for the order are now transformed into a coordinate
axis, with the specific positions of the storage locations represented by x and y coordinates, as shown in Figure 15:



Figure 15. Storage Location Coordinate Axis.



(2）Determine Fitness Function: In this paper, the fitness function is represented by 𝑟 = 76.2 ∗ 𝑚𝑎𝑥𝐷 ∗ 𝑁0.5 to

form a new fitness function 𝐹𝑖𝑥(𝑥) = 𝑟|𝑋.
Where max D is the maximum distance between the storage locations of the goods to be picked in the

customer order, N is the length of the chromosome, which is the number of storage locations passed through in the
picking path (including the In/Out gate), and X is the length of the picking path.

（3）Selection and Crossover Operator Design: Based on the basic principles of the improved genetic
algorithm described earlier, this paper uses a random generation method to produce the initial solution population.
Then, using the random traversal sampling method, two individuals are selected from the parent generation each
time, and crossover and mutation are performed with a set probability.

In the random traversal sampling method, individuals are selected through multiple nodes, with equal
distances between nodes. The expression for equal distance is as follows:

𝐷𝑖𝑠 = 𝐹𝑡/𝑁

𝑟𝜖[0,
𝐹𝑡

𝑁
）

𝐷𝑖𝑠 represents the equal distance between nodes, 𝐹𝑡 represents the cumulative fitness of the individual, 𝑁𝑢𝑚

represents the number of individuals to be selected, and 𝑟 represents the position of the starting point in the node,

which is randomly generated within the range[0,
𝐹𝑡

𝑁
）.

The specific crossover steps are as follows:
In the initial OX crossover method, if the randomly selected gene segments of the two parent individuals are

the same, new child individuals cannot be generated. In this case, the crossover method can be improved: First,
randomly select two nodes in the two parent individuals (the positions of the two nodes must be the same), and
extract the gene segments (crossover sub-path); Second, place the extracted two gene segments in front of and
behind the originally selected parent individuals; Finally, based on the second step, delete the duplicate gene
segments to obtain new individuals. The specific process is shown in Figure 16:




Asian Business Research Journal, 2025, 10(5): 30-50

48
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA






Figure 16. Crossover Process.



(4）Mutation Operation: Employ a continuous and multiple swap mutation technique to significantly adjust
the order of feasible solutions, thereby suppressing the homogenizing effect in “evolutionary reversal”.


5.4.3. Analysis and Comparison of Optimization Results
（1）Optimization Results: Similar to storage location optimization, path optimization also uses software for

simulation calculations, with the following specific settings (Tables12):


Table 12. Algorithm Parameter



Due to space constraints, only a portion of the data is displayed. Based on the above parameter settings, a

random order is selected, and the order data is shown in Tables 13 and 14. The data is input into the algorithm,
and the optimized route is calculated, with the iterative results shown in Figure 17:


Table 13. Customer Order.

Product
Category

Storage
Number

 Goods Weight（kg

） 1 9 56

2 13 13

3 35 47

4 43 53

5 50 45

6 66 47

7 80 31

8 91 6

9 98 32

10 117 12

11 139 29

12 152 47

13 175 62

14 179 19

15 184 46

16 208 58

17 227 41

18 254 42

19 259 7

20 262 57

21 273 15

22 280 46

23 295 34

24 307 44

25 315 11






Asian Business Research Journal, 2025, 10(5): 30-50

49
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





Table 14. Order Required Goods Storage Coordinates.

Storage Number Coordinate Position

9 （0，-19.8）

13 （0，-10.2）

35 （-4，-5.4）

43 （-6，-34.2）

50 （-6，-17.4）

66 （-10，-27）

80 （-10，15）

91 （-11，-15）

98 （-11，10.2）

117 （-17.6，7.8）

139 （-18.6，12.6）

152 （-22.6，-12.6）

175 （-23.6，-5.4）

179 （-23.6，12.6）

184 （-27.6，-31.8）

208 （-28.6，-22.2）

227 （-32.6，-24.6）

254 （-33.6，-7.8）

259 （-33.6，12.6）

262 （-37.6，-36.6）

273 （-37.6，-10.2）

280 （-37.6，15）

295 （-38.6，-5.4）

307 （-42.6，-24.6）

315 （-42.6，-5.4）




Figure 17. Iteration Number Diagram.


In summary, based on the above parameter settings and optimization model, the specific optimized vehicle

picking sequence and the total running distance of the sorting vehicle are as follows:

The path of 1st cart n11=（0  3  2  1  6  8  12  13  23  25  24  0）；

The path of 2nd cart n22=（0  16  17  15  20   4   5  0）；

The path of 3rd n33=（0  7  9  10  11  14  19  22  18  21  0）；
The total running distance of the three sorting carts is: 435.431486m.

（2）Comparative analysis: To demonstrate the effectiveness of the improved genetic algorithm in solving the
storage location optimization problem, a comparison is made between the path distances before and after storage
location optimization, with the comparison results shown in Tables 15 and 16:


Table 15. Algorithm Effect Comparison (S-shaped Path).

Order


S-shaped Path

（m）

Optimized Path

（m）

Difference value

（m）

Path Distance Savings

（%）
1 603.2 351.55 251.65 41.7%

2 538.19 329.46 208.73 38.8%

3 504.01 306.57 197.44 39%



Asian Business Research Journal, 2025, 10(5): 30-50

50
© 2025 by the authors; licensee Eastern Centre of Science and Education, USA





Table 16. Algorithm Effect Comparison (U-shaped Path).

Order


U-shaped Path

（m）

Optimized

Path（m）

Difference value

（m）
Path Distance Savings（%）

1 560.6 351.55 208.45 37.1%

2 518.62 329.46 189.16 36.4%

3 502.41 306.57 195.84 38.9%



Storage location and path optimization play a significant role in improving the efficiency of  picking operations. This
paper first places high-association goods near the warehouse entrance and exit based on the outbound rate of  storage
locations, thereby reducing the picking time and distance for pickers. As shown in the table, the differences before and
after optimization are 167.77, 126.36, 117.78, 125.17, 100.81, and 105.40, with the path savings ratio concentrated
between 20% and 25%, indicating a significant path optimization effect.


6. Summary and Recommendations
6.1. Storage Location Optimization for YY’s

To achieve storage location optimization, the following measures are necessary:
(1) Develop a detailed plan and coordinate with all departments to ensure the continuity of warehouse

operations. The plan should be flexible to accommodate unexpected events.
(2) Consider the weight and quantity of goods, employ suitable equipment, and augment personnel to

streamline the storage location adjustment process.
(3) Enhance staff training to minimize errors and omissions during the storage location optimization process,

with experienced personnel overseeing the implementation.


6.2. YY’s Path Optimization
To optimize picking paths, the following measures are recommended:
(1) Offer operational guidance and training to assist employees in adapting to the new picking paths, thereby

reducing error rates.
(2) Update picking labels to facilitate efficient picking by employees according to the new paths.
(3) Utilize the logistics system to monitor and evaluate the implementation of the new paths, and make real-

time adjustments based on feedback to maintain picking efficiency and accuracy.


References
 Bortolini, M., Botti, L., Cascini, A., Gamberi, M., Mora, C., & Pilati, F. (2015). Unit-load storage assignment strategy for warehouses in

seismic areas. Computers & Industrial Engineering, 87, 481–490.
https://doi.org/10.1016/j.cie.2015.05.023bancadellesoluzioni.org+1docente.unife.it+1

Chen, F., Wang, H., Qi, C., & Xie, Y. (2013). An ant colony optimization routing algorithm for two order pickers with congestion
consideration. Computers & Industrial Engineering, 66(1), 77–85. https://doi.org/10.1016/j.cie.2013.06.006

Chou, Y. C., Chen, Y. H., & Chen, H. M. (2012). Recency-based storage assignment and warehouse configuration for recurrent demands.
Computers & Industrial Engineering, 62(4), 880–889. https://doi.org/10.1016/j.cie.2011.12.013

Li, Y., & Qin, H. (2024). Dynamic slot optimization in warehouses using reinforcement learning techniques. Journal of Intelligent & Robotic
Systems.

Note: As of now, a DOI for this article is not available. Please check the journal's official website or databases like CrossRef for updates.
Liu, X. (2020). Cargo space optimization and picking path optimization based on immunogenetic algorithm [Doctoral dissertation, Anhui

University of Technology].
Note: Doctoral dissertations typically do not have DOIs. You may access this dissertation through the university's repository or contact the university library

for assistance.
Wang, J., & Xu, H. (2023). Simultaneous optimization of storage layout and picking paths in warehouses with machine learning and

optimization algorithms. Expert Systems with Applications.
Note: The DOI for this article is not available in the provided information. Please consult the journal's website or academic databases for the most recent

updates.
Xu, X., & Ma, Z. (2021). RMFS order picking system dynamic cargo space reassignment research. Computer Integrated Manufacturing Systems,

27(4), 1146–1154.
Note: This article appears to be published in a Chinese journal. For access and DOI information, please refer to the journal's official website or contact the

publisher directly.
Xu, X., & Ren, C. (2021). Vehicle path optimization method considering vehicle restriction and packing constraints. Journal of Transport

Information and Safety, 39(3), 77–84. https://doi.org/10.3963/j.jssn.1674-4861.2021.03.010jtxa.net+1jtxa.net+1
Zhang, L., & Li, S. (2022). Automated warehouse slot optimization using deep learning and genetic algorithms. International Journal of

Logistics Management.













https://doi.org/10.1016/j.cie.2015.05.023
https://www.bancadellesoluzioni.org/it/documenti?utm_source=chatgpt.com
https://doi.org/10.1016/j.cie.2013.06.006
https://doi.org/10.1016/j.cie.2011.12.013
https://doi.org/10.3963/j.jssn.1674-4861.2021.03.010
https://www.jtxa.net/en/article/doi/10.3963/j.jssn.1674-4861.2022.05.017?utm_source=chatgpt.com
