Review on Molecular Modelling in Chemistry Education

Itendra Singh Rajpoot, Hemant Patel, Rahul Singh Thakur, Basant Khare,  Anushree Jain, Prateek Kumar Jain,
Bhupendra Singh Thakur*

Adina College of Pharmacy, ADINA Campus Rd, Lahdara, Sagar, MP, 470001

Article Info:
_______________________________________
Article History:

Received 11 Sep 2022
Reviewed 06 Nov 2022
Accepted 23 Nov 2022
Published 15 Dec 2022

_______________________________________
Cite this article as:

Rajpoot IS, Patel H, Thakur RS, Khare B, Jain A,
Jain PK, Thakur BS, Review on Molecular
Modelling in Chemistry Education, Asian
Journal of Dental and Health Sciences. 2022;
2(4):55-58

DOI: http://dx.doi.org/10.22270/ajdhs.v2i4.26

_______________________________________

*Address for Correspondence:

Bhupendra Singh Thakur, Adina College of
Pharmacy, ADINA Campus Rd, Lahdara, Sagar,
MP, 470001

Abstract
___________________________________________________________________________________________________________________

Molecular models derived from results of quantum-chemical calculations present an important category
of didactic instruments in chemistry education. These models can be used especially as tools for
supporting the students’ understanding by visual learning, which can adequately address complexity of
many chemical topics, incorporate appropriate didactic principles, as well as utilize the benefits brought
up by the actual information technology. The proposed molecular models are non-trivial examples of
didactic application of computational chemistry techniques in illustration of electron interactions in
amidic group, namely the interaction of the free electron pair on the nitrogen atom with the carbonyl
group and also the interaction of atoms in the amide group with other surrounding atoms in the
molecule. By these molecular models it is possible to explain acid-base properties of amides applying
knowledge of electron density distribution in the molecules and the resulting electrostatic potential.
Presentation of the structure and properties of the amides within education is important also for the
reason that amidic functions are involved in many important natural substances (e.g. proteins, peptides,
nucleic acids or alkaloids), synthetic macromolecular substances (e.g. Silon) or pharmaceutical
preparations (e.g. paracetamol). This paper investigated the effect of using different types of models
while teaching organic chemistry on student understanding of new concepts and the spatial structure of
new molecules, as well as preference of a particular model type and illustrates the possibilities of
computer-assisted molecular modelling in supporting chemistry teaching and learning.

Keywords: Molecular models, Acidity, Amides, Basicity, Electrostatic potential



Introduction

Chemical concepts are abstract by nature and therefore
challenging to illustrate in an understandable way. The triple
mode of representation brings more challenge to chemistry
learning on the macro level, the submicroscopic level and the
symbolic level1. At the macro level one can see and observe
chemical phenomena. The submicroscopic level justifies and
illustrates the visible properties of a substance with atoms,
molecules and ions (for example with molecular modelling).
The symbolic level shows the macro level and micro level
phenomena using chemical symbols, formulas and equations.
It is important that teachers understand the threefold
relationship so that it can be conveyed to their students2.
While a teacher moves smoothly from one level to another, a
student might be confused and get a fragmented vision of
chemistry. According to Gabel (1999), the primary barrier in
understanding chemistry is that chemistry instruction occurs
predominantly on the most abstract level, the symbolic level.
The unobservable submicroscopic level, in which phenomena
and concepts are difficult to be combined with the students'
perceptions and the living environment, produces also
problems for students 3. Therefore students need to use
different models, analogies or computer graphics to make
invisible into visible4. Since models and modelling are
essential in chemical thinking and in the development of
scientific knowledge they should also be included in chemical
education. Students should: learn about the nature of models
and their usage as thinking tools; learn about the scope and
the limitations of specific chemical models; be encouraged to

use multiple models for a given phenomenon5. Visualizations
help students to build mental models when learning about
difficult concepts and submicroscopic level phenomena. That
is why the students' visualisation skills, spatial ability
particularly, should be developed. Computer-based molecular
modelling has helped a variety of learners to improve their
visualisation skills and helped them to understand the concept
of the model, three-dimensional molecular structure and
chemical bonds6. Molecular modelling software and computer-
assisted learning materials enable new learning environments
where chemistry concepts and phenomena can be viewed and
perceived in a new manner. At the same time computer-
assisted methods create new approaches enabling challenging
chemistry topics to be clarified and simplified. Virtual models
and visualisations can be modified according to the needs of
teaching and learning7. Computer-based molecular modelling
provides a tool for teaching and learning in order to support
the visualisation of chemical phenomena and the development
of chemistry teaching8-11. The computer enables to perceive
things through visual experience which helps memorise things
and improves learning outcomes9. According to the
experiences of Finnish school teachers, computer-based
molecular modelling helps teachers to illustrate and students
to learn difficult concepts in chemistry in a new way, it
develops students’ visualisation skills and makes students
interested in chemistry12. Finnish school teachers have used
molecular modelling to illustrate the spatial structure of
molecules, isomerism, atomic and molecular orbitals, chemical
bonds, electron density, IR-spectroscopy, energy and its

                       Open Access                                                                                                                                                                                                          Review Article

http://jddtonline.info/
http://dx.doi.org/10.22270/ajdhs.v2i4.26


Rajpoot et al                                                                                                                                Asian Journal of Dental and Health Sciences. 2022; 2(4):55-58

[56]                                                                                                                                                                                                                                                 AJDHS.COM

changes in chemical processes and chemical reactions.
Molecular modelling can also be applied to biochemistry,
biology and biotechnology education. According to Pernaa,
Aksela and Lundell (2009) 10, high school teachers
experienced that molecular modelling supports the drawing of
conclusions and the understanding of three-dimensional
structures and it provides added value for teaching of orbitals,
chemical bonds and biomolecules. Teachers and students
generally have positive attitudes towards molecular
modelling8, 12. The teacher has an important role in the success
and effectiveness of teaching chemistry through computer-
based molecular modelling, because the use of modelling
programs should not remain merely as a funny trick, instead
working with a computer should be tied into teaching. The
instructions and questions direct the learner's interest and
activities in order to support learning tasks as well as it is
possible and to train higher-order thinking skills13. The
current learning theories highlight learning as a socially
interactive process based on the students’ experiences. By
using computer-based molecular modelling it is possible to
support the understanding of scientific concepts, practice
different learning skills and to motivate students to investigate
in an authentic research environment9. There are commercial
molecular modelling programs e.g. Spartan
(www.wavefun.com) and HyperChem (www.hyper.com), and
free programs e.g. ChemSketch (www.acdlabs.com), ArgusLab
(www.arguslab.com), Symyx Draw (www.symyx-
draw.en.softonic.com), Avogadro
(www.avogadro.en.softonic.com) and MarvinSketch
(www.chemaxon.com). Edumol (www.edumol.fi) is an open,
web-based environment for molecular modelling and
visualisation. Findings indicate that molecular modelling has
helped students to understand concepts in molecular
geometry and bonding8 as well as in model concept,
isomerism and functional groups14. In the ongoing doctoral
study, the meaningful teaching model for covalent bonds (as
opposed to rote learning) is being developed.

Brief history of the development of molecular
models

The history of models15-18 can be traced back to Plato (482-
347 BC), who conceived of the four elements- soil, water, air
and fire. Nothing much happened in terms of model
development until in 1808 Dalton published the New System of
Chemical Philosophy- the first substantial discourse on atomic
theory. At the same year Malus discovered polarized light.
Wollaston related it to tetrahedron, but noted that "It is
perhaps too much to hope that the geometrical arrangement of
primary particles will ever be perfectly known". In 1811 Dalton
had a set of models of atoms and simple diatomic molecules
constructed to help illustrate his ideas. In 1815 Biot observed
several organic compounds that enable light polarization and
realized that the rotation of light was due to a property of the
individual molecule. In 1848 Pasteur found that crystals can
be separated into two types, and in solution they rotated the
plane of polarized light equally, but in opposite directions.
This discovery could not be explained at that time due to lack
of a proper model. The next indication of actual model
construction was by Kekule in 1867, who proposed the
tetrahedral structure of carbon bonds. In 1874 Van’t Hoff used
models- tetrahedra joined at the apex, sides or faces to
describe the optical isomers of tartaric acid, which raised
widespread objection. Sachse was one of the few chemists
who around 1890 used molecules to make predictions, and
predicted the ‘boat’ and ‘chair’ forms of cyclohexane. During
1900-1920 the use of ball-and-stick models became more
widespread. In 1934 Stuart developed space-filling models
that gave precise indications of the van der Waals radii of the
atoms in a molecule. These were preferred over the earlier

type, and opened the ‘golden age’ of molecular models. In
1947 Pitzer computed the energy barrier to carbon-carbon
bond in butane. Later, Pitzer and Hazel, who won Nobel Prize
in chemistry, demonstrated the axial and equatorial chair form
of cyclohexane ring. Space filling models were considered an
indispensable tool for organic chemists during the next 30
years and enabled the prediction of structural conformations,
strereochemistry, reactivity and physical properties. Most
notable was the double helix structure of DNA proposed by
Watson and Creek in 1953, who later won Nobel Prize in
chemistry.

Models in science and science education

Modeling and simulation are used in research and education
to describe, explain and explore phenomena, processes and
abstract ideas. Scientists, engineers and science educators use
models to concretize, simplify and clarify abstract concepts, as
well as to develop and explain theories, phenomena and rules.
A model is considered useful if it is simpler than the natural
object that it represents. An important value of models in
science and science education is their contribution to
visualization of complex ideas, processes and systems. A virtue
of a good model is that it stimulates its creators and viewers to
pose questions that take us beyond the original phenomenon
to formulate hypotheses that can be examined
experimentally19,20. Experimentation, however, is rarely
presented as a way of developing, interpreting or evaluating
explanatory models for the investigated phenomenon21. Ben-
Zvi and Genut (1998) 22 recommended teaching high school
students about interconnections of history and philosophy of
science on one hand and the usefulness and limitations of
scientific models, such as the Periodic Table, on the other
hand. Gilbert and Boulter (1998) 23 distinguish between target
systems, mental models, expressed models, consensus models
and teaching models. Other researchers underscored the need
for models as enablers of students’ mental transformation
from two-dimensional to three dimensional representations24-

26. One of the problems that arise while using concrete models
is that insufficient emphasis is placed on the fact that models
are theory-based simulations of reality. The theory of
molecular structure is a kind of intellectual model27. Harrison
and Treagust (1996) 28 claimed that the use of term "model" is
a source of considerable semantic variation for science
students and teachers. Models are often oversimplified and
therefore cannot tell humans all they may wish to know about
the real physical system that is being modeled. Teachers and
students should, therefore, be made aware of the fact that
models, employed in a variety of research, study and design
contexts, are not complete representations of the realities they
are supposed to represent29. Applied to chemistry, physical
ball and stick models derived from polystyrene spheres and
plastic straws are not merely enlargements of the molecules
they are intended to represent. These are analogue models
that are used to explain new and abstract concepts. Some of
the properties are similar to aspects of the target they are
representing. For example, the relative diameter of the
spheres represents the size of the different atoms. Other
aspects, however, are not reflected in the model. For example,
in a ball-and-stick model type, all sticks (straws) are of equal
length, while "real" molecular bond lengths are not. Other
analog models focus on different properties of the molecule,
thereby creating multiple ways of representing the same
molecule. Teachers frequently use just one type of model,
limiting students' experience with models and causing their
model perceptions to be partially or completely inadequate.

Computerized molecular modelling

The use of concrete molecular models (made of plastic, wood
and/or metal) to illustrate phenomena in chemistry teaching



Rajpoot et al                                                                                                                                Asian Journal of Dental and Health Sciences. 2022; 2(4):55-58

[57]                                                                                                                                                                                                                                                 AJDHS.COM

has been widespread for a relatively long time30. The choice of
model type has an impact on the image students create
concerning the ways in which particles are shaped and how
they function in the "real" world from a scientific viewpoint.
Simulating different model types quickly and efficiently is
achieved in a computerized environment, of which theoretical
chemists, experimentalists and educators are taking
advantage. Information technology helps relieving present-
day researchers and students from the laborious task of data
collection and enables them to engage in creative thinking and
problem solving. Nakhleh and Krajcik (1994) 31 investigated
how different levels of information presented by various
technologies affect secondary students’ understanding of acid,
base and pH concepts. They found that students using
microcomputer-based laboratories exhibited a positive shift in
their concept map scores, indicating greater differentiation
and integration of their knowledge. The development of
computerized molecular modeling (CMM) made traditional
models less favorable in the late 1960’s. Not only are
computers capable of drawing and manipulating molecules in
three dimensions. They are also powerful tools for predicting
molecular spatial structure through energy minimization
calculations based on quantum mechanics. These capabilities
have opened the way for advanced research in chemistry,
resulting, among other things, winning Nobel Prize in
chemistry (1998). Among the advantages of using information
technology in science education are the options of providing

for individual learning, simulation, graphics, and the
demonstration of models of the micro and macro world32.
Computer aided instruction enables students to solve a variety
of problems while carrying out their own research at their
own pace. The use of computerized models places more
emphasis on the creation of mental models by students and
their use to make prediction23. Students need more experience
with models as intellectual tools that provide contrasting
conceptual views of phenomena, and more discussion of the
roles of models in the service of scientific inquiry. Raghavan &
Glaser (1995) 33 recommend that science educators become
less concerned with the presentation of facts and concentrate
on showing the centrality of models in research and education.
However, most educators use a limited number of static
models, and do not emphasize the way in which models are
created, their essential role in science learning, or their
advantages and limitations. Williamson and Abraham (1995)

34 studied the effect of computer animations on college student
mental models of chemical phenomena. Animations were used
in two treatment situations: as a supplement in large group
lectures and as both the lecture supplement and an assigned
individual activity. Both treatments increased the students’
understanding. They attributed the improvement to the
superior formation of dynamic mental models of chemical
processes that were made possible by the computer
animation.





                                                (a)



                                                (b)



                                                 (c)

Figure 1 (a) Hand-Made primitive cubic unit cell; (b) Hand-Made body centered cubic unit cell; (c) Hand-Made face
centered cubic unit cell.



Rajpoot et al                                                                                                                                Asian Journal of Dental and Health Sciences. 2022; 2(4):55-58

[58]                                                                                                                                                                                                                                                 AJDHS.COM

Conclusion

Interpretation of symbols, as well as understanding the
particulate nature of matter and spatial structures are
essential skills students need for solving problems in organic
chemistry. However, model perception and understanding the
spatial structure of organic molecules has been a source of
difficulty for many chemistry students. A computerized
molecular modeling (CMM)-based collaborative learning
environment has been shown to be an effective means to
overcome certain learning difficulties in chemistry.

References

1. Johnstone A H. The development of chemistry teaching: a changing
response to a changing demand. Journal of Chemical Education.1993;
70(9):701-705. https://doi.org/10.1021/ed070p701

2. Gabel D. Improving teaching and learning through chemistry education
research: a look to the future. Journal of Chemical Education.1999;
76(4):548-554. https://doi.org/10.1021/ed076p548

3. Hinton M E, Nakhleh MB. Student's microscopic, macroscopic and
symbolic representations of chemical reactions. The Chemical
Educator.1999; 4(4):1-29. https://doi.org/10.1007/s00897990325a

4. Barnea N, Dori Y J. Computerized molecular modeling as a tool to
improve chemistry teaching. Journal of Chemical Information and
Computer Sciences.1996; 36(4):629-636.
https://doi.org/10.1021/ci950122o

5. Justi R, Gilbert JK. Models and Modelling in Chemical Education. In J. K.
Gilbert, O. De Jong, R. Justi, D. F. Treagust, & J. H. Van Driel (Eds.),
Chemical Education: Towards Research-based Practice.2002; pp. 47-
68. https://doi.org/10.1007/0-306-47977-X_3

6. Barnea N. Teaching and Learning about Chemistry and Modelling with a
Computer managed Modelling System. In J. K. Gilbert, & C. J. Boulter
(Eds.), Developing Models in Science Education. 2000; pp. 307-323.
https://doi.org/10.1007/978-94-010-0876-1_16

7. Jalonen E, Lundell J, Aksela M. Molekyylimallinnus lukion kemian
opetuksessa. (Molecular modelling in the chemistry teaching of upper
secondary school). In M. Aksela & M. Montonen (Eds.), Uusia
lähestymistapoja kemian opetukseen perusopetuksesta
korkeakouluihin. 2007; 148-154.

8. Barnea N, Dori YJ. Computerized molecular modeling as a tool to
improve chemistry teaching. Journal of Chemical Information and
Computer Sciences 1996; 36(4): 629-636.
https://doi.org/10.1021/ci950122o

9. Lundell J, Aksela M. Molekyylimallinnus kemian opetuksessa, osa 1:
Molekyylimallinnus ja kemian opetus, Dimensio. 2003; 67(5):47-49.

10. Pernaa J, Aksela M, Lundell J. Kemian opettajien käsityksiä
molekyylimallinnuksen käytöstä opetuksessa. (Finnish school
teachers' views about the usage of molecular modelling in teaching). In
M. Aksela & J. Pernaa (Eds.), Arkipäivän kemia, kokeellisuus ja
työturvallisuus kemian opetuksessa perusopetuksesta
korkeakouluihin: IV Valtakunnalliset kemian opetuksen päivät. 2009;
195-204.

11. Jain M, Jain A, Khare B, Jain DK, Khan R, Jain D. An Update on the Recent
Emergence of Candida auris. Asian Journal of Dental and Health
Sciences. 2022; 2(1):14-9. https://doi.org/10.22270/ajdhs.v2i1.11

12. Aksela M, Lundell J. Computer-based molecular modelling: Finnish
school teachers' experiences and views. Chemistry Education Research
and Practice. 2008; 9:301-308. https://doi.org/10.1039/B818464J

13. Aksela M, Lundell J. Kemian opettajien kokemuksia
tietokoneavusteisesta molekyylimallinnuksesta. (Finnish school
teachers' experiences about computer-based molecular modelling). In
M. Aksela & M. Montonen (Eds.), Uusia lähestymistapoja kemian
opetukseen perusopetuksesta korkeakouluihin. 2007; 226-247.

14. Dori YJ, Barak M. Virtual and physical molecular modeling: fostering
model perception and spatial understanding. Educational Technology
and Society. 2001; 4(1): 61-74.

15. Walton A. A Review of the use of both skeletal and space-filling models.
Progress in Stereochemistry. 1968; 4:335-336.

16. Khatri S, Jain DK. Autism spectrum disorder (ASD): past, present and
future. CIBTech Journal of Pharmaceutical Sciences. 2018; 7(4):1-25.

17. Hardwicke AJ. Using molecular models to teach chemistry. Part 1:
modeling molecules. School and Science Review. 19995; 77:59-64.

18. Clarke FH. New Skeletal space-filling models: a model of an enzyme
active site. Journal of Chemical Education. 1997; 54:230-235.
https://doi.org/10.1021/ed054p230

19. Toulmin S. The Philosophy of Science: An Introduction. New York:
Harper and Row.1953.

20. Bagdonis AS, Salisbury DF. Development and validation of models in
instructional design. Educational Technology. 1994; 34:26-32.

21. Tamir P. Traning Teachers to Teach Effectively in the Laboratory.
Science Education. 1989; 73:59-69.
https://doi.org/10.1002/sce.3730730106

22. Ben-Zvi N. Genut S. Uses and limitations of scienctific modls: the
perioduc table as an inductive tool. International Journal of Science
Education. 1998; 20; 351-360.
https://doi.org/10.1080/0950069980200307

23. Gilbert JK, Boulter CJ. Learning science through models and modeling.
in Fraser BJ and Tobin, KG (eds). International Handbook of Science
Education. Kluwer Academic Publisher, Dordrecht/Boston/London.
1998; 53-66. https://doi.org/10.1007/978-94-011-4940-2_4

24. Baker RS, Talley HL. Visualization skills as a component of aptitude for
chemistry - A construct validation study. Journal of Research in
Science Teaching. 1974; 11: 95-97.
https://doi.org/10.1002/tea.3660110203

25. Barak M, Dori YJ. Model Perception and understanding the spatial
structure of organic molecules by high school chemistry students.
Science teacher's education toward the new millenium, Technion,
Haifa, Israel. 1999.

26. Eliot JK, Hauptman A. Different dimensions of spatial ability. Studies in
Science Education. 1981; 8:45- 66.
https://doi.org/10.1080/03057268108559886

27. Hammond GS, Osteryoung J, Crawford TH, Gray HB. Models in Chemical
Science. Benjamin Inc., 2nd Edition, Menlo Park, CA.1972.

28. Harrison AG, Treagust DF. Mental Models. Science Education. 1996;
80:508- 534. https://doi.org/10.1002/(SICI)1098-
237X(199609)80:5<509::AID-SCE2>3.0.CO;2-F

29. Osborne RJ, Gilbert JK. The Use of Models in Science Teaching. The
School and Science Review. 1980; 62:57-67.

30. Peterson QR. Some reflections on the use and abuse of molecular
models. Journal of Chemical Education. 1970; 47(1):24-29.
https://doi.org/10.1021/ed047p24

31. Nakhleh MB, Krajcik SJ. Influence of levels of information as presented
by different technologies on students' understanding of acid, base and
ph concepts. Journal of Research in Science Teaching. 1994; 31:1077-
1096. https://doi.org/10.1002/tea.3660311004

32. Dori YJ, Hameiri M. The mole environment study ware: applying
multidimensional analysis to quantitative chemistry problems.
International Journal of Science Education. 1998; 20:317-333.
https://doi.org/10.1080/0950069980200305

33. Raghavan K, Glaser R. Model based analysis and reasoning in science:
the MARS curriculum. Science Education. 1995; 79:37-61.
https://doi.org/10.1002/sce.3730790104

34. Williamson VM, Abraham MR. The Effects of computer animation on the
particulate mental models of college chemistry students. Journal of
Research in Science Teaching. 1995; 32:521-534.
https://doi.org/10.1002/tea.3660320508



https://doi.org/10.1021/ed070p701
https://doi.org/10.1021/ed076p548
https://doi.org/10.1007/s00897990325a
https://doi.org/10.1021/ci950122o
https://doi.org/10.1007/0-306-47977-X_3
https://doi.org/10.1007/978-94-010-0876-1_16
https://doi.org/10.1021/ci950122o
https://doi.org/10.22270/ajdhs.v2i1.11
https://doi.org/10.1039/B818464J
https://doi.org/10.1021/ed054p230
https://doi.org/10.1002/sce.3730730106
https://doi.org/10.1080/0950069980200307
https://doi.org/10.1007/978-94-011-4940-2_4
https://doi.org/10.1002/tea.3660110203
https://doi.org/10.1080/03057268108559886
https://doi.org/10.1002/(SICI)1098-237X(199609)80:5%3C509::AID-SCE2%3E3.0.CO;2-F
https://doi.org/10.1002/(SICI)1098-237X(199609)80:5%3C509::AID-SCE2%3E3.0.CO;2-F
https://doi.org/10.1021/ed047p24
https://doi.org/10.1002/tea.3660311004
https://doi.org/10.1080/0950069980200305
https://doi.org/10.1002/sce.3730790104
https://doi.org/10.1002/tea.3660320508
