Asian Journal of Immunology

3(1): 145-159, 2020; Article no.AJI.56272









Structure and Function of COVID-19 Encode
Proteins in the Transcription and Replication
Mechanism with Its Preventive Measures and

Propose Efficacy Treatments: A Critical
Systematic Review


Oguh C. E.1*, Obiwulu E. N. O.2, Oniwon W. O.3, Okekeaji U.4, Ugwu C. V.1,

Umezinwa O. J.5 and Osuji C. A.1


1
Department of Biochemistry, University of Nigeria, Nsukka, Enugu State, Nigeria.

2
Department of Integrated Science, Delta State College of Education, Agbor, Delta State, Nigeria.

3
Department of Biochemistry, Kogi State University, Anyigba, Nigeria.

4
Department of Pharmaceutical Microbiology and Biotechnology, University of Nigeria, Nsukka,

Enugu State, Nigeria.
5
Department of Science Laboratory Technology, University of Nigeria, Nsukka, Enugu State, Nigeria.


Authors’ contributions


This work was carried out in collaboration among all authors. Author OCE designed the study, wrote

the protocol and manage the analyses of the study. Author OENO wrote the first draft of the
manuscript. Authors OWO, OU, UCV and UOJ managed the literature searches. Author OCA read

and edit the final manuscript. All authors read and approved the final manuscript.


Article Information


Editor(s):
(1) Dr. Cynthia Aracely Alvizo Báez, Autonomous University of Nuevo Leon, Mexico.

Reviewers:
(1) Loc Nguyen, Vietnam.

(2) Lívia Garcia Bertolacci-Rocha, Universidade Federal de Goiás, Brasil.
(3) Mujeeb Shittu, Michigan Technological University, USA.

Complete Peer review History: http://www.sdiarticle4.com/review-history/56272





Received 03 April 2020
Accepted 25 April 2020
Published 02 May 2020




ABSTRACT


The sudden occurrence outbreak of coronavirus disease in 2019 (COVID-19) by the severe acute
respiratory syndrome coronavirus2 (SARS-CoV-2) poses a serious harm worldwide and local
economies. Due to high numbers of infection and death, the pandemic calls for an urgent demand
of active, effective, affordable and available drugs to control and diminish the pandemic.
Coronavirus disease 2019 is a public health unexpected and sudden crisis which required action of

Review Article








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





146



international concern. At present there is no generally recognized effective pharmaceutical
treatment to the disease, although it is to a great extent for patient contracting the severe form of
the disease. The development of new strategies to prevent or control the spread of COVID-19
infections and the understanding of the virus replication, and pathogenesis required immediate
action. Therefore, this systematic review was to investigate the biochemical effect of the virus in
human, symptoms, prevention, statistics cases and summarize the evidence regarding chloroquine
and hydroxychloroquine for the treatment of COVID-19.




Keywords: Coronavirus; mechanism; prevention; structure; treatment.


ABBREVIATIONS

COVID-19: Coronavirus disease 2019;
SARS-CoV2: Severe acute respiratory syndrome
coronavirus 2; S: Spike;  M: Membrane;
E: Envelope glycoproteins; HE: Hemagglutinin
Esterase: N: Nucleocapsid protein; RdRp: RNA-
dependent RNA polymerase; MHV: Mouse
hepatitis virus; ACE2: Angiotensin-converting
enzyme 2; 3CLpro: Coronavirus main protease;
PLpro: Papain-like protease; FECV: Feline
Enteric Coronavirus; FIPV: Feline Infectious
Peritonitis Virus; TGEV: Transmissible Gastro-
Enteritis Virus; PEDV: Porcine Epidemic
Diarrhea Virus;  PRCoV: Porcine Respiratory
Coronavirus; CCoV: Canine coronavirus; BCoV:
Bovine Coronavirus;  gRNA: RNA genome; DMV:
Double-Membrane Vesicles; RTC: Replication
and Transcription Complex; nsp3: non-structural
protein3; CQ: Chloroquine; HCQ: Hydroxy-
chloroquine; EEs: Early endosomes; ELs: endo-
lysosomes; Cryo - EM: Cryo electron
microscopy; IFA: Immune fluorescence analysis;
ERGIC: Endoplasmic reticulum-Golgi apparatus
intermediate compartment.


1. INTRODUCTION


Coronavirus is a novel disease that had not been
previously identified in human of recent.
Coronavirus disease 2019 is a respiratory
disease illness that is transitive from one
individual to the other. The type of virus that
causes COVID-19 is a new inventive disease
that was firstly recognize during a survey
outbreak in December. 2019 at Wuhan, China,
this disease has spread to more than 213
countries with 2,931,787 confirmed cases and
over 203,596 confirmed deaths worldwide as of
April 26, 2020 [1] with U.S, Spain, Italy and
France as the most affected countries with
960,896, 223,759, 195,351 and 161,488 confirm
cases respectively. The name coronavirus,
coined in 1968, is derived from the corona-like or
crown-like morphology observed for these
viruses in the electron microscope. The virus is

highly contagious and thousands of new cases
are reported around the world every day. The
risk of infection from the virus that causes
COVID-19 is higher for people who have close
contacts with people with the disease, such as
healthcare workers and household members and
other people at higher risk for this infection are
those who are living in an area with ongoing
spread of COVID-19 or those who traveled to
effected place. Risk of death is only higher in
older people (above an age of 60 years) and
people with pre-existing health conditions.
Coronaviruses infect both animals and humans,
especially animals such as bats, this animal host
the largest variety of corona viruses shows to be
immune to corona virus-induced illness in human
[2]. Researchers have been working to trace the
achievable treatments in order to save lives and
produce vaccines for future prevention and
control. The viruses infect a variety of organisms
such as human and animal host cells, and also
carry out their infection and replication on the
host. Also, many proteins located on the virus
have most important function in the replication
mechanism, although the role is yet to be
defined. In this case, it is important to investigate
the role and importance of these proteins during
mechanism. Therefore; this review explains the
structure, classification, symptoms, prevention,
statistics cases and summarize the evidence
regarding chloroquine and hydroxychloroquine
for the treatment of COVID-19.


1.1 Structure of Covid-19


Coronaviruses are enveloped viruses with round
and sometimes pleiomorphic virions of
approximately 80 to 120 nm in diameter (Fig. 1).
The coronaviruses also contain positive-strand
RNA, which have the largest RNA genome
(approximately 30 kb) reported to date (178,
196). Corona viruses (COVID-19) are mainly
large viruses containing a single-stranded
positive-sense RNA genome protected by
membrane within a membrane envelope within
the virus. The viral membrane is covered with








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





147



glycoprotein spikes that give coronaviruses their
crown like appearance. COVID-19 virus encode
five structural proteins in their genomes. These
are the Spike (S), Membrane (M), Envelope (E)
glycoproteins, Hemagglutinin Esterase HE and
Nucleocapsid N protein, (Fig. 1). The virus
envelope proteins and N protein is embedded in
all virion but HE is only present in some beta
coronaviruses. In addition to that, it is thought the
virus particles are huddled together owing to
interaction between these proteins [3,4].


1. S Glycoproteins: They are located outside
the virion which gives the virion the typical
shape. The S proteins form homotrimers,
which allow the formation of sun-like
morphologies that give the name of
Coronaviruses [5]. S proteins bind to the
virion membrane via the C-terminal
transmembrane regions, also they interact
with M proteins [6]. The Virions is attach to a
specific surface receptors in the plasma
membrane of the host cell through the N-
terminus of the S proteins. This S
glycoprotein initiate host cell invasion by
both SARS-CoV and SARS-CoV-2 via
binding to a receptor protein called
angiotensin-converting enzyme 2 (ACE2)
which is located on the surface membrane
of host cells [7,8]. A study conducted by [9,
10], shows that the invasion process
requires S protein priming which is
accompany by the host cell produced serine
protease. Also the viral genome also
encodes several nonstructural proteins
which include the RNA-dependent RNA
polymerase (RdRp), coronavirus main
protease (3CLpro) and papain-like protease
(PLpro) [9,10].

2. M Glycoproteins: The M Glycoproteins on
the virus have three transmembrane
regions. The proteins are glycosylated in the
organelle called Golgi apparatus [11]. This
reformation of the M protein is important for
the virion to fuse into the cell and to make
protein antigenic. The M protein plays a key
important role in stimulate virions in the cell.
The virus N protein also forms a complex by
binding to genomic RNA and the M protein
elicit the production and formation of
interacting virions in this endoplasmic
reticulum-Golgi apparatus intermediate
compartment (ERGIC) with this complex
[12,13].

3. E Glycoproteins: This are small proteins
that are constitute of just about 76 to 109
different amino acids. Approximately 30

different amino acids in the N-terminus of
the E proteins permit attachment to the
membrane of viruses [14]. In addition,
coronavirus E proteins play a critical
important role in pulling together and
morphogenesis of virions within the cell. A
study of coronavirus E and M proteins were
expressed together with mammalian
expression vectors to form virus-like
structures within the cell [15]. In a study,
there was a great decrease in the ability of
the recombinant mouse hepatitis virus
(MHV) and SARS viruses to elicit E protein
expression in the genome to support this
status [16,17].

4. N Proteins: They are phosphor proteins
that are capable of binding to helix and have
elastic structure of viral genomic RNA. It
plays a crucial role in virion structure,
replication and transcription of
coronaviruses, because the N protein focus
in both the replication and the transcriptional
region of the coronaviruses and the ERGIC
area where the virus is collected [16,17].
(Fig. 2).


1.2 Classification of Coronaviruses

The classification of Coronaviruses is based on
genomic organization, resemblance in genomic
sequence, antigenic properties of viral proteins,
replication strategies and structural character-
istics of virions, pathogenic, cytopathogenic and
physicochemical properties [18]. The
Coronaviruses are species of virus belonging to
the Nidovirales order, which comprises
Coronaviridae, Arteriviridae, Roniviridae and
Mesoniviridae families [19]. The Arteviridae
family consist of swine and equine pathogens,
and the Roniviridae family is composed of
invertebrate viruses. The Coronaviridae family is
the largest among the four families, range from
26 to 32 kb by its genomic sizes of coronaviridae
[20]. Coronaviridae virus family subdivided into
two subfamilies, coronavirinae and torovirinae.
Coronavirinaeis gulf into four genera, Alpha
coronavirus, Beta coronavirus, Gamma
coronavirus and Delta coronavirus (Fig. 3). Alpha
coronaviruses type 1 species are classified into
the porcine TGEV (Transmissible Gastro-
Enteritis Virus), feline FCoV, FECV (Feline
Enteric Coronavirus) and FIPV (Feline Infectious
Peritonitis Virus), Porcine PEDV (Epidemic
Diarrhea Virus), PRCoV (Porcine Respiratory
Coronavirus) and the canine CCoV. Alpha
coronaviruses also agree with human CoVs such








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





148



as HCoV-229E and HCoVNL63, but various bat
Coronaviruses.

Beta coronaviruses infect a wide varieties of
mammalians, with species such as human with
SARS-CoV, mice, HCoV-OC43, HCoV-HKU1,
and MERS-CoV, Bovine Coronavirus (BCoV),
and Murine coronavirus (MHV). Likewise to
SARS-CoV and MERS-CoV, SARS-CoV-2
violence the lower respiratory system to cause
viral pneumonia in human, and may also affect
the heart, kidney, gastrointestinal system, liver,
and central nervous system leading to multiple

organ failure [21,22]. Current information
indicates that SARSCoV-2 is more transmissible
and very contagious than SARS-CoV [23].The
beta coronavirus genome encrypt more than a
few or several structural proteins, including the
glycosylated spike (S) protein that functions as a
major inducer of host immune responses.
Gamma coronaviruses are exact of birds, with
one exclusion of a beluga whale Coronavirus.
The delta coronavirus genus was generated in
2012 and with various groups (HKU11, HKU12,
HKU13) Coronavirus from mammals to birds [24]
Fig. 3.





Fig. 1. Coronavirus virion. (A) Electron micrograph of mouse hepatitis virus MHV particles.

(B) Schematic of virion





Fig. 2. Cartoon illustration of the coronavirus structure and viral receptor ACE2 on the host
cell surface








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





149






Fig. 3. Classification of Covid-19


2. COVID-19 MECHANISM OF ACTION
(REPLICATION AND TRANSCRIPTION)


Coronavirus entry starts with the S protein
binding to a target receptor on the cell surface,
where after fusion is mediated at the cell
membrane, delivering the viral nucleocapsid
inside the cell for subsequent replication. The
action of coronaviruses replication occurs in the
cytoplasm of the host cell. The viruses mainly
bind to the host receptor cell surface through the
spike (S) protein. A conformational structure
occurs in the structure and the process of entry
into the virus cell start when S protein is bound to
the receptor [25]. This process with endocytosis
is reliant of pH through the receptor. The virus
particle releases the RNA genome after going
into the cytoplasm. This genome is a non-
segmented RNA virus with the largest known
RNA genome (gRNA), single-stranded, which is
approximately 26-32 kb. The genome consists of
seven several genes. It is prearranged into 5’
non-structural protein coding regions include the
replicase genes (gene 1), which are two-thirds of
the genome, and 3’ structural and nonessential
accessory protein coding regions including the
gene 2-7 [26]. The replicase gene 1 products are
encoded two very large open reading frames
ORF1a and 1b, which are interpreted or
translated into two large polypeptides pp1a and
pp1b, which are produce and synthesized
directly from the 5’ two-thirds of the genomic
RNA of CoV (Fig. 4).

After the protein have been synthesized, which is
made up of 16 units, non-structural protein (nsp1
to nsp16) is change with the influence of viral

proteases pp1a and pp1b [27]. Same time, the
Double-Membrane Vesicles (DMV) is virus
Replication and Transcription Complex (RTC)
[28,29]. The 16 unit’s proteins form DMV. These
nsp proteins, particularly non-structural protein3
(nsp3), have an important function in the virion
structure, and the replication and transcription of
CoV [30,31]. Genes 2 to 7 are transform from
sub genomic mRNA. Sub genomics RNAs
encode the main viral Envelope protein (E),
structural proteins (S), Membrane protein (M),
Nucleocapsid protein (N), and the accessory
proteins, which are vital for virus-cell receptor
binding. The recently structural synthesized
proteins are released into the endoplasmic
reticulum. All of these proteins, along with the N
protein, are connected to the viral genomic RNA
and localized in the ERGIC region [28,32] as
shown in Fig. 4.

Although, N protein is known to be very essential
for coronavirus replication, the exact function or
role that this protein plays in this process
remains unidentified. But, several research
suggested that N protein interact with nsp3,
which plays a critical and important role in the
virus replication early in infection. The
communication between viral S protein and
Angiotensin-converting enzyme 2 (ACE2) on the
host cell surface is of important interest since it
initiates the infection process. Cryoelectron
microscopy (Cryo-EM) structure analysis has
make known that the binding affinity of SARS-
CoV-2 S protein to ACE2 is approximately 10−20
times higher than that of SARS-CoV S protein
binding to ACE2 [33,34]. It is consider that the
binding affinity may contribute to the reported








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





150






Fig. 4. MHV genome organization and replicase proteins





Fig. 5. Life cycle of coronavirus in a host cell

higher transmissibility spread and
contagiousness of SARS-CoV-2 as compared to
SARS-CoV [23].

The search also exists for discovery a
breakthrough of therapeutic agents such as
drugs and vaccine for targeting the highly
preserved proteins related with both SARS-CoV

and SARS-CoV-2 proteins [34-37]. RNA-
dependent RNA polymerase (RdRp) and
Coronavirus main protease (3CLpro) of SARS-
CoV-2 share over 95 % of sequence similarity
with those of SARS-CoV notwithstanding the fact
that these two viruses shows or demonstrate
only 79 % sequence similarity at the genome
level proteins [34-37]. On the foundation of








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





151



sequence arrangement and homology modeling,
SARS-CoV and SARS-CoV-2 share an
extremely preserved receptor-binding domain
(RBD), a domain of S protein and 76% of
sequence similarity in their S proteins [34-37].
Although the Papain-like protease (PLpro)
sequences of SARS-CoV-2 and SARSCoV are
only 83% similar, they share the same active
sites [35].


3. TRANSMISSION OF COVIDS-19


The virus that causes COVID-19 most likely
emerged or come out from an animal source,
which is now spreading from one person to the
other. Via respiratory droplets generate when an
infected individual sneezes or coughs can extend
the spread of the virus to close contact (within
about 6 feet length). The COVID-19 can also be
contracted by touching a surface or object that

has been contaminated with the virus from an
infected person and then touching their own
mouth, nose, or perhaps their eyes.


3.1 Symptoms of Covid-19

Patients with COVID-19 will eventually have
slight to severe respiratory illness with symptoms
of:

 Fever
 Cough
 Running nose
 Sore throat
 Body Ache
 Shortness or difficulty breathing
 At severe complications from this virus such

as pneumonia in the lungs, multi-organ
failure and in some cases lead to death.






Fig. 6. Common and uncommon symptoms of COVID-19











Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





152



3.2 Preventive Actions and Spreading of
COVID-19 to Others


 People should avoid close by contact with

people sneezing and coughing and people
that are sick.

 Avoid touching face, eyes, nose, and mouth
with unwashed hands.

 Washing of hands regularly with soap
and running water for at least 30 seconds.
Also the use of alcohol-based
hand sanitizer that contains at least 65%
alcohol if soap and water are not
available.

 Stay home when you are sick.
 People with COVID-19 symptoms produce

a respiratory droplets when they cough
or sneezes so, should practice cough
manners or etiquette i.e maintaining
distance when coughing or sneezing, cover
coughs, wear face mask, sneezes with
disposable tissues or clothing, and wash
hands regularly.

 Clean and disinfect frequently all touched
objects and surfaces.

 Limit person-to-person transmission which
include reducing secondary infections
amidst close by contacts and health care

workers, and preventing transmission
amplification.

 Identify, isolate and be concerned for
patients timely, including providing enhance
care for infected patients to avoid spread of
the disease.

 Avoid unprotected contact with wild animals
to Identify and reduce spread of virus from
the animal source.

 Converse critical risk and event information
to all communities and counter
misinformation.

 Address all crucial unknowns regarding
clinical harshness, extent of transmission
and infection treatment options, and
accelerate the development of diagnostics,
therapeutics and vaccines.

 Minimize social and economic impact
through multispectral partnerships.

 People that have traveled from an affected
area, should be isolated and restrictions for
2 weeks. If the patient develop symptoms
during the isolation period with fever, cough,
and trouble breathing, then seek for medical
advice or call the health care provider for
COVID-19 in the community before
telling them about the travel and the
symptoms.






Fig. 7. Countries areas with reported confirmed cases of COVID-19, 26 April 2020 by ECDC









Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





153






Fig. 8. Epidemic curve of confirmed COVID-19, by date of report and WHO region through 25
March 2020






Fig. 9. Distribution of COVID-19 cases worldwide, as at 26 April, 2020 by ECDC


3.3 Summary Situation Worldwide as at
26 April 2020 Reported by ECDC [38]


 Globally: 2,931,787 confirmed cases

worldwide and 203,596 deaths worldwide.

 Asia: 456350 confirmed, and most case
were reported in Turkey, Iran, China, India
and Saudi Arabia with 107773, 89328,
83909, 26496, and 16299 respectively  and
16865 deaths, most death are in Iran,








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





154




Fig. 10. Distribution of COVID-19 death cases worldwide, as at 26 April, 2020 by ECDC


China, Turkey, India and Indonesia with
5650, 4636, 2706, 824 and 720 death
respectively.

 America: 1134686 confirmed, most
reported countries are US, Brazil, Canada,
Peru and Mexico with  939053, 58509,
45341, 25331 and 13842 respectively and
63649 deaths, most death were recorded in
US, Brazil, Canada, Mexico and Peru with
53189, 4016, 2465, 1305 and 700 death
respectively.

 Europe: 1214584 confirmed, five most
confirm case were in Spain, Italy, Germany,
United kingdom and France with 219764,
195351, 154175, 148377 and 124114
respectively and 119306 deaths, most death
were recorded in Italy, France, Spain,
United kingdom and Belgium with 26384,
22614, 22524, 20319 and 6917 death
respectively.

 Oceania: 8080 confirmed, five most cases
were in Australia, New Zealand, Guam,
Frence Polynesia and Fiji with 6703, 1121,
141, 57, 18 death respectively and 106
deaths, with the most death case recorded
in Australia, New Zealand, Guam and
Northern Mariana islands with 81, 18, 5, 2
death respectively.

 African Region: 30316 confirmed cases,
five most countries are  South Africa, Egypt,
morocco, Algeria and Cameroon with 4361,
4319, 3897, 3256 and 1518 respectively
and 1382 deaths, the top most countries are

Algeria, Egypt, morocco, south Africa and
Cameroon with 419, 307, 159, 86 and 53
death cases respectively

 Others: 696 confirmed and 7 deaths


4. TREATMENT

4.1 Efficacy and Safety of Chloroquine,

Remdesivir (GS-5734) and Hydroxy-
chloroquine for the Treatment of
COVID-19


Coronavirus Disease-2019 (COVID-19) is a
public health emergency of international concern.
As of this time there is no recognize exact,
effectual, proven, pharmacological treatment for
the cure of COVID-19. Invitro studies have
suggested that chloroquine, an immune
modulant drug traditionally used to cure malaria,
is effective in reducing viral replication in other
contagion, as well as the SARS-associated
coronavirus (CoV) and MERS-CoV [39,40].
Chloroquine (N4-(7-Chloro-4-quinolinyl)-N1,N1-
diethyl-1,4-pentanediamine) (CQ) has been used
worldwide for above 80 years, and it is part of the
World Health Organization (WHO) model list of
vital medicines. The drug is also inexpensive and
has a set up clinical safety profile. However, the
effectiveness and safety of the drug chloroquine
for treatment of SARS-CoV-2 (the novel virus
causing COVID-19) pneumonia remains
indistinct.









Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





155



A group of Chinese researchers, from literature
have studied the impact of chloroquine in vitro,
using Vero E6 cells contaminated by SARS-CoV-
2 at an array of contagion (MOI) of 0.05. The
study established the  fact  that chloroquine was
extremely effectual in decrease viral N protein
replication, with an effectual dosage (EC) 90 of
6.90 μM that can be easily attainable with normal
standard dosing, due to its advantageous
penetration in tissues, including in the lung. The
authors described that chloroquine is known to
obstruct virus contagion by cumulating
endosomial pH and by meddling with the
glycosylation of cellular receptor of SARSCoV.
Also guesswork on the possibility that the known
immunomodulant effect of the drug may improve
the antiviral effect in vivo [41].

A description letter written by Chinese authors
give an account that a news meeting from the
State Council of China had stated that
chloroquine phosphate had established marked
effectiveness and satisfactory safety in treating
COVID-19 related pneumonia in multi-center
clinical trials conducted in China. The authors
also specified that these discovery came from
more than 100 patients included in the trials [42].
Evidence of such data was sought in the trial
registries to review and was found none. So far
cases had been reported in 213 countries as at
26th April 2020, the low cost of chloroquine is a
main advantage for both the extreme stressed
healthcare systems of involved elevated-income
countries and none funded healthcare systems of
mid-and low-income counties.

The skilled agreement was in print on 20th
February by a multicentre cooperation group of
the Department of Science and Technology of
Guangdong Province and Health Commission of
Guangdong Province paper and have to do with
specifically to the use of chloroquine phosphate.
No information was provided on condition that
the method used to attain agreement [43]. Based
on the in vitro evince and still not published
clinical experience, the board recommended and
endorsed chloroquine phosphate tablet, at a
dose of 500 mg twice per day for 10 days, for
patients diagnosed as slight mild and severe
cases of SARS-CoV-2 pneumonia, on condition
that there were no opposition or contraindication
to the drug.

Research have shown that chloroquine (CQ) and
remdesivir (GS-5734), efficiently inhibited SARS-
CoV-2 contagious in vitro. Remdesivir is a
nucleoside analog pro drug technologically

advanced by Gilead Sciences (USA). A clinical
report in United States showed that treatment
with remdesivir improved and better the clinical
state of the first patient infected by SARS-CoV-2
[44] and a stage III clinical trial of remdesivir in
opposition to SARSCoV-2 was open in Wuhan
on February 4, 2020. Although, as an
experimental drug, remdesivir is not likely to be
largely obtainable for treating a very large
number of patients in a timely way. However, of
the two potential drugs for treating of COVID-19,
CQ happen to be the best drug of choice for
large-scale use because of  its obtainability and
availability, a safety record proven, and a
moderately low in cost.

Chloroquine CQ (N4-(7-Chloro-4-quinolinyl)-N1,
N1-diethyl-1,4-pentanediamine) have been in
used for long in the treatment of  malaria and
amebiasis. However, Plasmodium falciparum
technologically advanced extensive resistance to
it, and with the advancement of new anti-malarial
drugs, CQ has become a choice for the
prophylaxis of malaria. Furthermore, over dose of
CQ can cause acute or severe poisoning and
death [45]. In the past years, due to occasional
use of CQ in clinical practice, its manufacture
and market supply was very much reduced, at
least in China.

Hydroxychloroquine (HCQ) sulfate, is a
derivative of CQ, and was first synthesized in
1946 by initiating a hydroxyl group OH into CQ.
HCQ establish and demonstrated to be much
less (~40%) toxic than CQ in animals [46]. HCQ
is still extensively obtainable and available to
treat autoimmune diseases, such as rheumatoid
arthritis and systemic lupus erythematosus.
Since CQ and HCQ have similar chemical
structures and mechanisms of acting as a feeble
base and immune modulator, HCQ have shown
to be more effective and potent drugs to treat
SARS-CoV-2. In fact, as of February 23, 2020,
seven clinical trial records were found in Chinese
Clinical Trial Registry for using HCQ to treat
SARS-CoV-2. What makes HCQ to be more
efficacious than CQ in treating SARS-CoV-2
infection still be short of experimental prove.

Liu et al. [47] assess the antiviral impact of HCQ
against SARS-CoV-2 infection in comparison to
CQ in vitro. Initially, the cytotoxicity of HCQ and
CQ in African green monkey kidney VeroE6 cells
(ATCC-1586) was determined by standard CCK8
assay. The result demonstrated that the 50%
cytotoxic concentration (CC50) values of CQ and
HCQ were 273.20 and 249.50 μM, respectively,








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





156



which shows a no significant different from each
other. The antiviral activity of CQ versus HCQ
was compared, and the dose–response curves of
the two compounds against SARS-CoV-2 were
evaluated at four several multiplicities of infection
(MOIs) by enumerate of viral RNA copy numbers
in the cell supernatant at 48 h post infection (p.i.).
The result showed that, at all MOIs (0.01, 0.02,
0.2, and 0.8), the 50% maximal effectiual
concentration (EC50) for CQ were 2.71, 3.81,
7.14 and 7.36 μM respectively, and HCQ were
4.51, 4.06, 17.31, and 12.96 μM respectively at
all MOIs. CQ values was lower than that of HCQ.
The differences in EC50 values were statistically
significant at an MOI of 0.01 (P < 0.05) and MOI
of 0.2 (P < 0.001).

Consequently, the selectivity index (SI =
CC50/EC50) of CQ (100.81, 71.71, 38.26, and
37.12) was higher than that of HCQ (55.32,
61.45, 14.41, 19.25) at MOIs of 0.01, 0.02, 0.2,
and 0.8 respectively. These results were verify
by immune fluorescence microscopy as
indication by several expression stage of the
virus nucleoprotein (NP) at the indicated drug
concentrations at 48 h p.i. This study suggest
that the anti-SARS-CoV-2 activity of HCQ appear
to be less strong or potent compared to CQ, at
slightest at certain MOIs. The two drugs CQ and
HCQ are feeble bases that are known to raise
the pH of acidic intracellular organelles, such as
endosomes/lysosomes, vital for membrane
synthesis.

Furthermore, CQ could inhibit SARS-CoV entry
via altering the glycosylation of ACE2 receptor
and spike protein [48]. Extra additional
experiment confirmed that HCQ efficiently
inhibited the entry step, in addition to the post-
entry stages of SARS-CoV-2, which was also
found upon CQ treatment.

To further discover the full mechanism of action
of CQ and HCQ in inhibiting the COVID-19 entry,
co-localization of virions with early endosomes
(EEs) or endo lysosomes (ELs) was examine by
immunofluorescence analysis (IFA) and confocal
microscopy. Quantification examination showed
that, at 90 min p.i. in untreated cells, 16.2% of
adopt virions (anti-NP, red) were detected in
early endosome antigen 1 (EEA1)-positive EEs
(green), whereas more virions (34.3%) were
transfer into the late endosomal–lysosomal
protein LAMP1+ ELs (green) (n > 30 cells for
each group). By difference, in the presence of
CQ or HCQ, significantly more virions (35.3% for
CQ and 29.2% for HCQ; shows a significant P

<0.001) were detected in the EEs, while only
very few virions (2.4% for CQ and 0.03% for
HCQ; P < 0.001) were found to be co-localized
with LAMP1+ ELs (n > 30 cells).

This suggested that both CQ and HCQ obstruct
the transport of SARS-CoV-2 from EEs to ELs,
which happen to be a condition to release the
viral genome as in the case of SARS-CoV [49].
However, CQ and HCQ treatment caused
obvious changes in the number and
size/morphology of EEs and ELs. In CQ and
HCQ-treated cells, unusually increase EE
vesicles were seen, arrows in the upper panels),
many of which are even larger than ELs in the
untreated cells. In the untreated cells, most EEs
were much smaller than ELs. Previous report
study have showed that treatment with CQ
induced the formation of expanded cytoplasmic
vesicles [50].

Within the EE vesicles, virions (red) were
contained around the membrane (green) of the
vesicle. The treatment with CQ did not cause
noticeable changes in the number and size of
ELs; however, the regular vesicle structure
seemed to be disrupted, at least partially. By
difference, in HCQ-treated cells, the size and
number of ELs raised significantly, arrows in the
lower panels. Since acidification is important and
vital for endosome maturation and function, then
surmise that endosome maturation might be
blocked at midway stages of endocytosis,
resulting in failure of additional transport of
virions to the ultimate releasing site. CQ was
reported to elevate the pH of lysosome from
about 4.5 to 6.5 at 100 μM [51].

Research have shown that oral absorption of CQ
and HCQ in humans is very effective in the
treatment of SARS-CoV-2. In animals, both
drugs share similar tissue distribution patterns,
with high concentrations in the liver, spleen,
kidney, and lung spread levels of 200–700 times
higher than those in the plasma [52]. It was
reported that safe dosage (6–6.5 mg/kg per day)
of HCQ sulfate could generate serum levels of
1.4–1.5 μM in Humans. Therefore, with a safe
recommended dosage, HCQ concentration in the
above tissues is likely to be achieved to inhibit
SARS-CoV-2 infection.


5. CONCLUSION


Coronaviruses are diverse family of viruses that
interact at various levels with constituent of host
cells taking this benefit of some of the cellular








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





157



machineries for replication and proliferation. In
conclusion, CQ and HCQ can efficiently inhibit
SARS-CoV-2 infection in vitro and it is more
effective with HCQ. In combination with its anti-
inflammatory function, and was predict that the
drug has a good effect to combat the virus
disease. This possibility awaits confirmation by
clinical trials. HCQ is less toxic than CQ,
prolonged and overdose usage of HCQ can still
cause poisoning. Although the use of chloroquine
can also support expert opinion, clinical use of
this drug in patients with COVID-19 should stick
to the ethical approval as a trial as stated by the
WHO.


CONSENT

It is not applicable.


ETHICAL APPROVAL

It is not applicable.


COMPETING INTERESTS

Authors have declared that no competing
interests exist.


REFERENCES

1. Coronavirus Disease (COVID-2019)

Situation Reports 1−45; World Health
Organization; 2020.
Available:https://www.who.int/emergencies
/diseases/novel-coronavirus-
2019/situation-reports

2. Anthony SJ, Johnson CK, Greig DJ,
Kramer S, Che X, Wells H, Hicks AL, Joly
DO, Wolfe ND, Daszak P, Karesh W,
Lipkin WI, Morse SS, Mazet JAK,
Goldstein T. Global patterns in coronavirus
diversity. Virus Evol. 2017;3(1):vex012.

3. De Haan CA, Rottier PJ. Molecular
interactions in the assembly of
coronaviruses. Adv Virus Res. 2005;64:
165-230.

4. Masters PS. The molecular biology of
coronaviruses. Adv Virus Res. 2006;66:
193-292.

5. Tan YJ, Lim SG, Hong W. Characterization
of viral proteins encoded by the SARS-
coronavirus genome. Antiviral Res. 2005;
65:69-78.

6. Chinese SMEC. Molecular evolution of the
SARS coronavirus during the course of the

SARS epidemic in China. Science. 2004;
303:1666-1669.

7. Wrapp D, Wang N, Corbett KS, Goldsmith
JA, Hsieh CL, Abiona O, Graham BS,
McLellan JS. Cryo-EM structure of the
2019-nCoV Spike in the prefusion
conformation. Science. 2020;eabb2507.

8. Hoffmann M, Kleine-Weber H, Schroeder
S, Kruger N, Herrler T, Erichsen S,
Schiergens TS, Herrler G, Wu NH, Nitsche
A, Muller MA, Drosten C, Pohlmann S.
SARS-CoV-2 cell entry depends on ACE2
and TMPRSS2 and is blocked by a
Clinically Proven Protease Inhibitor. Cell;
2020.
DOI: 10.1016/j.cell.2020.02.052

9. Gorbalenya AE, Snijder EJ, Ziebuhr J.
Virus-encoded proteinases and proteolytic
processing in the Nidovirales. J. Gen. Virol.
2000;81(4):853−879.

10. Baez-Santos YM St. John SE, Mesecar
AD. The SARScoronavirus papain-like
protease: Structure, function and inhibition
by designed antiviral compounds. Antiviral
Res. 2015;115:21−38.

11. Niemann H, Geyer R, Klenk HD, Linder D,
Stirm S, Wirth M. The carbohydrates of
mouse hepatitis virus (MHV) A59:
structures of the O-glycosidically linked
oligosaccharides of glycoprotein E1.
EMBO J.  1984;3:665-670.

12. Narayanan K, Makino S. Characterization
of nucleocapsid-M protein interaction in
murine coronavirus. Adv Exp Med Biol.
2001;494:577-582.

13. Escors D, Ortego J, Enjuanes L. The
membrane M protein of the transmissible
gastroenteritis coronavirus binds to the
internal core through the carboxy-
terminus. Adv Exp Med Biol. 2001;494:
589-593.

14. Raamsman MJB, Locker JK, de Hooge A,
de Vries AA, Griffiths G, Vennema H, et al.
Characterization of the coronavirus  mouse
hepatitis virus strain A59 small membrane
protein E. J Virol. 2000;74:2333-2342.

15. Vennema H, Godeke GJ, Rossen JW,
Voorhout WF, Horzinek MC, Opstelten DJ,
et al. Nucleo capsid-independent assembly
of coronavirus-like particles by co-
expression of viral envelope protein genes.
EMBO J. 1996;15:2020-2028.

16. De Diego ML, Alvarez E,  Almazan  F,
Rejas  MT,  Lamirande  E,  Roberts A, et
al. A severe acute respiratory syndrome
coronavirus that lacks the E gene is








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





158



attenuated in vitro and in vivo. J Virol.
2007;81:1701-13.

17. Kuo L, Masters PS. The small envelope
protein E is not essential for murine
coronavirus replication. J Virol. 2003;77:
4597-4608.

18. Lai MM, Cavanagh D. The molecular
biology of coronaviruses. Adv Virus Res.
1997;48:1-100.

19. Zirkel F, Kurth A, Quan PL, Briese T,
Ellerbrok H, Pauli G, et al. An insect
nidovirus emerging from a primary tropical
rainforest. M Bio. 2011;2:e00077-11.

20. Gorbalenya AE, Enjuanes L, Ziebuhr J,
Snijder EJ. Nidovirales: Evolving the
largest RNA virus genome. Virus
Research. 2006;117:17-37.

21. Su S, Wong G, Shi W, Liu J, Lai ACK,
Zhou J, Liu W, Bi Y, Gao GF.
Epidemiology, genetic recombination, and
pathogenesis of coronaviruses. Trends
Microbiol. 2016;24(6):490−502.

22. Zhu N, Zhang D, Wang W, Li X, Yang B,
Song J, Zhao X, Huang B, Shi W, Lu R,
Niu P, Zhan F, Ma X, Wang D, Xu W, Wu
G, Gao GF, Tan WA. Novel coronavirus
from patients with pneumonia in China,
2019. N. Engl. J. Med. 2020;382(8):
727−733.

23. Tang B, Bragazzi NL, Li Q, Tang S, Xiao
Y, Wu J. An updated estimation of the risk
of transmission of the novel coronavirus
(2019-nCov). Infect Dis Model. 2020;5:
248−255.

24. Susanna KPL, Kenneth SML, Alan KLT,
Chung Tong S, Ming Wang, Garnet, Choi
KV, et al. Recent Transmission of a Novel
Alphacoronavirus, Bat Coronavirus HKU
10, from Leschenault’s Rousettes to
Pomona Leaf- Nosed Bats: First Evidence
of Inter species Transmission of
Coronavirus between Bats of Different
Suborders. J Virol. 2012;86:11906-11918.

25. Bosch BJ, vander Zee R, de Haan CA,
Rottier PJ. The coronavirus spike
proteinisa class Ivirusfusionprotein:
Structural and functional characterization
of the fusion corecomplex. J Virol. 2003;
77:8801-8811.

26. Susan RW, Sonia N. Coronavirus
pathogenesis and the emerging pathogen
severe acute respiratory syndrome
coronavirus. Microbiol Mol Biol Rev. 2005;
69:635-664.

27. Baranov PV, Henderson CM, Anderson
CB, Gestel RF, Atkins JF, Howard MT.
Programmed ribosomal frame shifting in

decoding the SARS-CoV genome.
Virology. 2005;332:498-510.

28. Cynthia SG, Kathleen MT, Thomas GK,
Pierre ER, James AC, et al. Ultra structural
characterization of SARS coronavirus.
Emerg Infect Dis. 2004;10:320-326.

29. Gosert R, Kanjanahaluethai A, Egger D,
Bienz K, Baker SC. RNA replication of
mouse hepatitis virus takes place at
double-membrane vesicles. J Virol. 2002;
76:3697-708.

30. Miller S, Krijnse-Locker J. Modification of
intracellular membrane structures for virus
replication. Nat Rev Microbiol. 2008;6:
363-74.

31. Mark RD. Seeking membranes: Positive-
strand RNA virus replication complexes.
PLoS Biol. 2008;6:e270.

32. Stertz S, Reichelt M, Spiegel M, Kuri T,
Martinez Sobrido L, Garcia Sastre A, et al.
The intracellular sites of early replication
and budding of SARS-coronavirus.
Virology. 2007;361:304-15.

33. Wrapp D, Wang N, Corbett KS, Goldsmith
JA, Hsieh CL, Abiona O, Graham BS,
McLellan JS. Cryo-EM structure of the
2019-nCoV Spike in the prefusion
conformation. Science. 2020;eabb2507.

34. Lu R, Zhao X, Li J, Niu P, Yang B, Wu H,
Wang W, Song H, Huang B, Zhu N, Bi Y,
Ma X, Zhan F, Wang L, Hu T, Zhou H, Hu
Z, Zhou W, Zhao L, Chen J, Meng Y,
Wang J, Lin Y, Yuan J, Xie Z, Ma J, Liu
WJ, Wang D, Xu W, Holmes EC, Gao GF,
Wu G, Chen W, Shi W, Tan W. Genomic
characterization and epidemiology of 2019
novel coronavirus: implications for virus
origins and receptor binding; 2020.

35. Morse JS, et al. Learning from the past:
Possible urgent prevention and treatment
options for severe acute respiratory
infections caused by 2019-nCoV. Chem
BioChem. 2020;21(5):730−738.

36. Chan JFW, Kok KH, Zhu Z, Chu H, To
KKW, Yuan S, Yuen KY. Genomic
characterization of the 2019 novel human-
pathogenic coronavirus isolated from a
patient with atypical pneumonia after
visiting Wuhan. Emerging Microbes Infect.
2020;9(1):221−236.

37. Dong N, et al. Genomic and protein
structure modelling analysis depicts the
origin and infectivity of 2019-nCoV, a new
coronavirus which caused a pneumonia
outbreak in Wuhan, China, bioRxiv;
2020.
DOI: 10.1101/2020.01.20.913368








Oguh et al.; AJI, 3(1): 145-159, 2020; Article no.AJI.56272





159



38. European centre for disease prevention
and control.
Available:https://www.ecdc.europa.eu/en/g
eographical-distribution-2019-ncov-case

39. Savarino A, Boelaert JR, Cassone A,
Majori G, Cauda R. Effects of chloroquine
on viral infections: an old drug against
today’s diseases? Lancet Infect Dis. 2003;
3:722–7.

40. Colson P, Rolain JM, Raoult D.
Chloroquine for the 2019 novel coronavirus
SARSCoV-2. Int J Antimicrob Agents.
2020;105923.

41. Wang M, Cao R, Zhang L, Yang X, Liu J,
Xu M, et al. Remdesivir and chloroquine
effectively inhibit the recently emerged
novel coronavirus (2019-nCoV) in vitro.
Cell Res; 2020.
Available:https://doi.org/10.1038/s41422–
020–0282–0

42. Gao J, Tian Z, Yang X. Breakthrough:
chloroquine phosphate has shown
apparent efficacy in treatment of COVID-
19 associated pneumonia in clinical
studies. Biosci Trends; 2020.
Available:https://doi.org/10.5582/bst.2020.
01047

43. Wu Zhong2, Manli Wang1.
Hydroxychloroquine, a less toxic derivative
of chloroquine, is effective in inhibiting
SARS-CoV-2 infection in vitroCell
Discovery. Cell Discovery. 2020;6:16.
Available:https://doi.org/10.1038/s41421-
020-0156-0

44. Holshue ML, et al. First case of 2019 novel
coronavirus in the United States. N. Engl.
J. Med; 2020.

Available:https://doi.org/10.1056/NEJMoa2
001191

45. Weniger H. Review of side effects and
toxicity of chloroquine. Bull. World Health.
1979;79:906.

46. McChesney EW. Animal toxicity and
pharmacokinetics of hydroxychloroquine
sulfate. Am. J. Med. 1983;75:11–18.

47. Liu Jia 1, Ruiyuan Cao2, Mingyue Xu1,3,
Xi Wang1, Huanyu Zhang1,3, Hengrui
Hu1,3, Yufeng Li1,3, Zhihong Hu 1.
Hydroxychloroquine, a less toxic derivative
of chloroquine, is effective in inhibiting
SARS-COV-2 infection in vitro. Cell
Discovery. 2020;6(16).

48. Savarino A, et al. New insights into the
antiviral effects of chloroquine. Lancet
Infect. Dis. 2006;6:67–69.

49. Mingo RM, et al. Ebola virus and severe
acute respiratory syndrome coronavirus
display late cell entry kinetics: evidence
that transport to NPC1+ endolysosomes is
a rate-defining step. J. Virol. 2015;89:
2931–2943.

50. Zheng N, Zhang X, Rosania GR. Effect of
phospholipidosis on the cellular
pharmacokinetics of chloroquine. J.
Pharmacol. Exp. Ther. 2011;336:661–
671.

51. Ohkuma S, Poole B. Fluorescence probe
measurement of the intralysosomal pH in
living cells and the perturbation of pH by
various agents. Proc. Natl Acad. Sci. USA.
1978;75:3327–3331.

52. Popert AJ. Choloroquine: A review.
Rheumatology. 1976;15:235–238.

_________________________________________________________________________________
© 2020 Oguh et al.; This is an Open Access article distributed under the terms of the Creative Commons Attribution License
(http://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium,
provided the original work is properly cited.









Peer-review history:
The peer review history for this paper can be accessed here:

http://www.sdiarticle4.com/review-history/56272

https://doi.org/10.1038/s41422–020–0282–0
https://doi.org/10.1038/s41422–020–0282–0
https://doi.org/10.5582/bst.2020.01047
https://doi.org/10.5582/bst.2020.01047
https://doi.org/10.1038/s41421-020-0156-0
https://doi.org/10.1038/s41421-020-0156-0
http://creativecommons.org/licenses/by/4.0
