BASIC MICROPHONE TECHNNIQUES FOR

 LIVE PERFORMANCE AND MUSIC RECORDING IN NIGERIA.



Udeozor, Vincent Chukwuma

Music Department, NnamdiAzikiwe University, Nigeria.

Email- vincezzo4u@yahoo.com



Abstract:

This study exploits several ways by which microphone can be

positioned/placed during live performance and recording in Nigeria.

Musical performance cannot be appreciated without proper

microphone techniques. Participation, observation as well as literature

reviews from the research methodology are used in carrying out the

research. Challenges facing this work would be highlighted as well as

possible solutions and recommendations.





Introductions

We cannot digest this discourse without knowing the meaning of this

instrument called microphones. From the acoustic point of view,

microphones are familiar, and almost ubiquities piece of sound

equipment that changes sound energy into electrical energy. A lay

man‟s understanding will have it as an instrument for singing. Perhaps

the best way to emphasise the importance of the microphone is to say

that without it, with the exception of electronic instruments and

computers, audio in the recording would not exist. Going to the

historical lain, it should be noted that the earliest recordings were

made through a horn; sounds were emitted into horn and recorded

directly onto a cylinder or disc. This type of acoustic recording was

supplanted by electrical recording around 1925, and then microphone

took over, in 1876, Emile Berliner invented the first microphone used

as a telephone voice transmitter. At the US centennial exposition,

Emile Berliner had seen a bell company telephone demonstrated and

 Awka Journal of Research in Music and the Arts (ARMA) Vol. 10 2014








183

was inspired to find ways to improve the newly invented telephone. In

1878, the carbon microphone was invented by David Edward Hughes,

and later developed during the 1920‟s.Hughes‟s microphone was the

early model for the various carbon microphones now in use. The ribbon

microphone was invented in 1942 for radio broadcasting.In1964, Bell

laboratories researchers James West and Gerhard Sessle, invented

electro acoustic transducers, an electric microphone. The electric

microphones offered greater reliability, higher precision lower cost

and a smaller size. It revolutionized the microphone industry with

almost one billion manufactured each year. During the 1970‟s, dynamic

and condensermics were developed allowing for a lower sound level

sensitivity and a clearer sound recording.



Operating Principles

The recording industry which is changing rapidly has one area where

the technology is almost the same as it always was and this area is

microphones. When choosing a microphone, there are three things to

consider: operating principles, directional characteristics and sound

response, cost and durability may be two other considerations. Going

back to our physics class, microphones are transducers. They change

sounds acoustics energy (variations in air pressure) into electrical

energy (variations in voltage) from a technical design standpoint;

therefore, the most basic way to classify different types of micsis by

the methods they use to do this. Microphones use a diaphragm usually

of twin, lightweight material, that is struck by sound waves and

vibrates accordingly into an analogous pattern of varying voltage and

the electrical signal is then available for recording and processing.

Based on this way we can break microphones down into the following

categories:

 Dynamic moving –coil designs (the diaphragmis attached to a coil

of wire)

 Ribbon (actually, dynamics as well, but with a ribbon of a moving

coil)

Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma






184

Condenser (i.e capacitor mics, where the diaphragm is part of

capacitor)

Dynamic moving- coil microphones designs, better known as dynamic

mics, use the principal of electromagnetic induction to convert

acoustic energy to electrical. The diaphragm is attached to a coil,

which lies in a magnetic field (generated by a magnet incorporated

into the mic).When sound waves strike the diaphragm, it vibrates

accordingly, and this causes the attached coil to move within the

magnetic field generating a voltage which varies in accordance with

the pattern of the original sound wave (a typical loudspeaker works by

the same principle, only in reverse) moving-coil designs are usually

sturdy and rugged and so are popular for live use, especially hand –

held applications. Moving-coil microphones are rugged, generate low

self-noise, tend to be less susceptible to humidity and a wide

temperature variations, and handle high sound –pressure levels

without distortion.  They are less expensive than other professional

microphones.



Ribbon Microphone is another type of mic design that uses

electromagnetic induction. People refer to this design as „‟ribbons‟‟. A

thin (usually) corrugated ribbon of metal foil is used as diaphragm

again suspended in a magnetic field, inducing a voltage whose pattern

is analogous to the original acoustic sound wave‟s as above. In older

ribbon designs, the ribbon material itself was extremely fragile,

making these mics more suitable for studio use than live. Ribbon

microphones are not widely used today, except in music recording and

for the speaking voice. They are more expensive than many moving-

coilmics and have to be handled with care particularly when it comes

with loud sound levels. Recently developed ribbon microphone

technology is the active ribbon microphone which uses an amplifier

system that requires phantom power. Phantom power is a method of

remotely powering an amplifier or impedance converter by sending

voltage along the audio cable.

Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma






185

Among the advantages of the active ribbon microphone over

conventional ribbons are higher output and sensitivity, wider and

flatter frequency response and the ability to handle higher sound

levels before distortion (Alten: 1981)





Performance Characteristics

Microphones have their individualistic approach for a particular

application. Moving-coil microphones are rugged, generate low self-

noise, tend to be less susceptible to humidity and wide temperature

variations and handle high sound pressure levels without distortion.

They are usually less expensive than the other professional types and

come in a wide variety of makes and models. The element of a moving-

coil mic has more mass than that of a ribbon of capacitor microphone

and, therefore, has greater inertia in responding to sound variations.

This results in a slower response to transients sounds that begin with

a quick attack, such as a drum hit, breaking glass, and then quickly

decay. Ribbon microphones are not widely used today, except in music

recording and for the speaking voice. They are more expensive than

many moving coil mics and have to be handled with care, particularly

when it comes to loud sound levels. Ribbon mics generally have low

self-noise, but they also have the lowest output level of the three

major types. This means a power signal-to-noise ratio if the mic is too

far from the sound source or if the cable runs us too long. Capacitor

microphones are highly-performance instruments. They reproduce

clear, airy, detailed sound and are the choice among professional-

quality microphones when it is necessary to record sounds rich in

harmonics and overtones. Capacitor mics have high sensitivity, which

make them the preferred choice for distant miking: high-end response

is not hampered by extended mic-to-source distances. The capacitor

microphones are generally more expensive than moving coil and ribbon

microphones.

Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma






186



Behavioural Characteristics

The way in which a microphone responds to sound in the air around it

is expressed as the mic‟s pattern. This describes the microphone‟s

sensitivity to sound coming at it from the front, sides and rear of the

diaphragm-in other words, the microphones directional

characteristics.



Microphones Has Three Basic Directional Characteristics

A. Omni-directional: the mic responds with equal sensitivity to

sounds from all directions (front, rear, sides).

B. Bi-directional: the mic is sensitive to sounds from the front and

rear (00 and 1800 respectively) but rejects bounds from sides

within 900-2700.

C. Uni-directional: the mic is primarily sensitive to sounds from

one direction (cardioids, super-cardioids, and hyper-cardioids)

and rejects sounds from the rear.

As mentioned earlier, an omni-directional mic which picks up sounds

from everywhere consists of a disc-shaped diaphragm in a sealed

enclosure, open only at the front. That means all sound is picked up by

direct pressure on the (front of the) diaphragm. Omnimics can be

referred to as pressure mics. When sound waves from the side (900-

2700) strike, both sides of the diaphragm at the same time resulting

in equal but opposite pressure on the front and rear, the sounds from

the sides will be cancelled, that is to say that the mic therefore picks

up sound waves from the front and rear and rejects sound from the

side, this is a pressure gradient design, also known as a bi-directional

mic. The microphone that falls under this category is condenser

microphone and are mostly used for choir applications, they are

generally more capable of flat, wide-range frequency response rather

than one microphone per sound source the object is to pick up multiple

sound sources (or a „‟large” sound source) for one microphone picking

Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma






187

up a typical choir, the suggested placement is a few feet in front of,

and a few feet above, the heads of the first row, it should be centred

in front of the choir and aimed at the last low. A cardioids microphone

can cover up to 15-20 voices, arranged in a rectangular or wedge-

shaped section, for larger or unusually shaped choirs, it may be

necessary to use more than one microphone.





Uni-Directional

Unidirectional comes into play where a more restricted pick up

characteristics would be desirable. Sound waves arriving at the rear

of the diaphragm are delayed, usually by rear entry ports (acoustic

chambers) in the body of the mic. This delays the arrival of a sound

wave relative to its arrival at the front of the diaphragm-in other

words it puts the sound coming in at the rear out of phase with the

same sound coming in at the front. This type of mic is very sensitive

to the sound coming from the front, and which rejects sounds from

the rear. When the pattern of this kind of unidirectional design is

plotted, it looks like a heart shape and so is commonly referred to as a

cardioids pattern from the latin word for „‟heart‟‟. This type of mic can

be used in mixing a bass drum since it has its concentration in the

front. Also close mixing guitar cups, drum kits, close on trumpet bells.





Vocal Mixing Techniques

Some singers, even professional find it very hard to perform with

microphones especially during live recording or performance. These

bad techniques often times result in some fantastic voices being over

looked due to poor sound quality.









Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma








188

Things to Bear in Mind While Handling the Microphone

1. Pointing the microphone towards a speaker when you are two

close causes a high pitched noise called FEEDBACK.

2. Aiming the volumes too high will cause FEEDBACK and

DISTORTION.

3. Holding the microphone too close or too far from your mouth.

This results in your singing sounding multiple and distorted.



Set your volume controls so that the backing track is lower than

your singing. To avoiding, ensure the mic is held no closer than 2 to

3 inches from your mouth during normal singing. Also, when aiming

for high notes, avoid moving the microphone closer to your mouth.

Furthermore, point the mic at about a 45 degree angle above;

below; or to the side of the performer‟s mouth, depending on the

mic‟s pick up pattern‟. Cardioidsmics are best suited for this.

Ideally, hand held mic should be positioned 6 to 12 inches from the

performers mouth at an angle of 45 degrees or less. Positioning

the microphone at the angle of about 90 degrees may result in

popping sounds when consonants like P and T are pronounced.



Snare Drum

Use a capacitor mic which makes snare to sound richer or crisper

or moving coil mic that tends to give it a harder edge in mixing the

snare drum. Point your mic 6 to 10 inches from the drum head and

aim the mic so that its pick up pattern is split between the head

and side of the drum.



Bass Drums

This drum purpose in most music is to provide transient, low-

frequency energy burst that help establish the primary rhythmic

pattern of a song.The kick drum‟s energy is primarily focused in

two areas:low-end timbre and “attack”. Although this varies by

individual drum, the attack tends to be in the 2.5-5khz range.

Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma








189



Tom Tom

 The kick and snare establish the low and high rhythmic functions

the toms are multiple drums that will be tuned from high to low

between the snare and kick. They are primarily used for fills

during performance, but may also be consistent parts of the

rhythmic structure. The attack range is similar to snare drum, but

often with more sustain. An individual directional mic on the top

head near edge can be used on each drum and panned to create

some spatial image.





Hi Hat Cymbal

the hi-hat cymbal produces too sounds; a clap and shimmer;

depending on how important these accents are to the music, the hi-

hat can either can either share the snare drum‟s mic or have a

microphone of its own. If it shares, place the mic between the hi-

hat and snare and adjust the sound balance through mic placement.

If your miking only the hi-hat place the mic at the edge of the hi-

hat to produce a brighter sound.





Acoustic Guitar

When recording an acoustic guitar, place your microphone about 6

inches above the bridge and even within the front of the guitar

brightens the natural sound of the instrument. Aiming a

microphone at the centre of the guitar hole 2 to 3 feet away

produces a sound with balanced highs, middles, and lows.







Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma








190

Congas This is a special instrument in Africa, miking such an

instrument that has its sound concentration both in the middle and

at the edge of the instrument would require a special skill in the

sense that the instrument is play with the expression of the body

as part of its skill. Miking the instrument from top may engage the

player and microphone in a “fight” but not that a good result may

not be achieved miking from the top, but to achieve a more

desirable result, is preferably good to mic beneath the instrument.





Conclusion

 Trying to exhaust the microphone technique of all the instruments

may not be possible in this discourse as we have numerous musical

instruments. The basic thing or aim of this work is to create

consciousness in the use of microphones especially in the vocal

technique. We should also bear in mind that mixing something that

makes sound; use a microphone with a frequency response that is

suited to the frequency range of the sound, if possible, or filter

out frequencies above and or below the highest and lowest

frequencies of the sound.

















Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma








191



References

Internet Sources

www.recordingmag.com/resources

www.adorama.com/basic-miking

www.music.tutsplus.com

Benade, A. H. Fundamentals of Musical Acoustics.

Parker, S. P Acoustics Source

Huber & Runstein Modern Recording Techniques.

Everest, F. A (1981).The Master Hand book Of Acoustics

Alten, S R. Audio in Media 7th Edition

Hornby, M S. Production in Pro Tools

Kristin, P & Reil, K. R (2014).Basic Miking Techniques for Recording

Pop\Rock Music.



Basic Microphone Technniques During Live…           Udeozor, Vincent Chukwuma



http://www.recordingmag.com/resources
http://www.adorama.com/basic-miking
http://www.music.tutsplus.com/
