Implementation of Nagoya Protocol – the Case Study of Indonesia

Endang Sukara1, Safendrri Komara Ragamustar 2, Ernawati Sinaga 3

1.Professor, Study Center for Environmental Ethics, Universitas Nasional Jakarta, Pejaten Campus 12520,

Jakarta, Indonesia & Indonesian Academy of Sciences (AIPI), Gambir, 10110, Jakarta - Indonesia
(Corresponding author).
Email: endangsukara@gmail.com
2. Universitas Nasional Jakarta, Pejaten Campus 12520, Jakarta, Indonesia. Email: ersinaga2003@yahoo.com.sg

3. School of Government Public Policy, Sentul, 16810, Bogor, West Java, Indonesia.
Email: s.ragamustari@gmail.com


DOI: https://doi.org/10.3329/bioethics.v11i2.49262



Abstract: Indonesia consists of more than 17,000 islands separated for hundreds of thousands of years,

which consequently results in biodiversity and cultural diversity richness. Strong connection between

people and biodiversity form a vast array of traditional knowledges which are related to the conservation

and the use of biological diversity. During the last 3 decades, tremendous advancement in science and

technology has been able to uncover the intrinsic value of biodiversity. Many lead chemical compounds

have been isolated and identified from, and have opened up huge opportunities in developing new

businesses based on biodiversity. The consciousness of the intrinsic value of biodiversity is, however,

only being understood by countries with high science and technology capacity. The intrinsic value of

biodiversity remains abstract to most of the people in the developing and less developed nations. The

Convention on Biological Diversity (UN-CBD), Cartagena and Nagoya Protocol are legal documents

to ensure conservation, sustainable use and sharing of the benefits from the utilization of biodiversity

and its components. Nagoya Protocol dealing with access and benefit sharing from the utilization of

biological materials has open new and better opportunities for the developed nations to study the

potential use of biological resources exist in developing and less develop nations. The implementation

Nagoya Protocol on access, fair and equitable sharing of the benefit from the utilization of biodiversity

very complex and full with ethical dilemmas. Basic principles stipulated in the Universal Declaration

on Human Rights and Bioethics UNESCO 2005 e.g. consent, persons without the capacity to consent,

equality, justice and equity, respect for cultural diversity and pluralism, solidarity and cooperation,

sharing of benefits, protecting future generations, protection of the environment, the biosphere and

biodiversity may be applied in addressing ethical issues.



(Some part of this article was presented at 20th Asian Bioethics Conference, Dhaka, Bangladesh).



Introduction: Biodiversity is the variety of

life on Earth. It is the most complex feature

of our planet and it is the most vital.

Without biodiversity, there is no future for

humanity. Biodiversity is important to

support life systems and to keep our planet

green and healthy. There is no record of the

number of species on Earth, but it is

estimated to be around 10 million. The total

number of species used by human

civilization for food, health and energy is

very limited. The majority of species are

remained untapped 1,2.



It is believed that biodiversity has an

enormous value as genetic resources.

Biodiversity plays an important role in

nutrient cycle, soil formation. Plant

resources and photosynthetic organisms

have a tremendous vehicle as an active

carbon sink and controlling the climate. The

presence of biodiversity is also an important



Bangladesh Journal of Bioethics 2020; 11 (2): 35-41





36



element in controlling diseases, natural

disaster protection, and erosion control.

Biodiversity has a spiritual value, source of

education and knowledge, recreation and

esthetical values3. During the last 2

decades, the advancement of science and

technology, biotechnology growing rapidly

and influence mankind understanding on

the important of biodiversity related to

food, health, and energy. Biodiversity is

now becoming an important asset for

bioeconomy.



Indonesia is a maritime country with more

than 17,000 islands across the equator,

laying between Asia and Australia. The

Islands are separated from each other for

hundreds of thousands of years. It is no

doubt that species exist in the islands

undergone a long period of isolation and

adaptation creating species endemicity of

both flora and fauna. Komodo for example

is only found in Komodo Island while a

single horn Rhino is only found in West

Coast of Java and Maleo bird is endemic to

Sulawesi Island. Indonesia is also blessed

with over 42 terrestrial ecosystem types and

more than 5 ocean ecosystems from ice

landscapes and alpine mountains, to

spectacular coral reefs, sea grass beds and

deep weber seas4. It is obvious that

Indonesia is known as a mega bio-diversity

country source? There are about 1.500

species of algae, 80.000 species of

cryptogrames, 595 species of lichenes,

2.197 species of fern, 30.000 to 40.000

species of plants, 8.157 species of animal

(mammal, birds, herpetofauna, and fish)

and 1.900 butterfly species 5. Among them,

270 species of mammals, 386 species of

birds, 328 species of reptiles, 204 species of

amphibian, and 280 species of fishes are

endemic5. In Indonesian context, the

connection between people, cultures,

traditions and biodiversity is strong. The

vast array of traditional knowledge

accumulated and being embodied in daily

life for hundreds of thousands of years.

Traditionally, biodiversity used as food,

source for medicine, fiber for clothing,

coloring agent, source of energy. The way

of using biodiversity is quite diverse

depending on the tribes in the country.

In relation to food, Indonesians consume

around 100 plant species as carbohydrate

sources, 100 legume plants, 450 species of

fruits and 250 species of vegetables, diverse

species of animals, both terrestrial and

aquatic, mushroom, fungi and microbes 6.

Study in an area of 1 ha of the low land

forest in Sumatera, there are more than 300

species of plant observed. Evaluation using

ethnobotanical analysis, the total number of

51 plants species are used as source of fruit,

21 species as source of vegetable, 6 species

for spices, 77 species as source for

traditional medicine, 2 plants species

containing poison, and 45 species as a

source of energy (firewood), 65 species as

raw material for craft and art, 157 species

for construction and 27 species are suitable

for future pulp, paper and plywood industry 7.

Related to health, the use of diverse plant

species is already embedded to the culture

of Javanese tribes. The mixer of plant

species is blend and sell to the market as

traditional medicine, jamu. Around 75

percent of Indonesians consume jamu on a

regular basis, either to prevent or treat

diseases Jamu has been an integral part of

Indonesia’s socio-cultural identity 8. The

use of diverse plants species as medicine is

already exist since ancient time in

Indonesia.



Bangladesh Journal of Bioethics 2020; 11 (2): 35-41





37



Advancement of Science and Technology

in Utilizing Biodiversity: The

advancement of science and technology has

opened our understanding on the value of

biodiversity unexpectedly. Deep study on

around 200 plant species extracts native to

Indonesia by the Indonesian Institute of

Sciences (LIPI) cooperated with cosmetic

industry, Shiseido in 2007, the total of 30

lead molecules found and may be patented.

Advancement of science and technology

may unlock the intrinsic value of the

Indonesian plant biodiversity and open

opportunities to bring this research output

to commercial. Another example is

Scorodocarpus borneensis (Baill) Becc, a

family of Oleaceae traditionally, the seed and

bark are used as vegetable, root and fruit as

medicine and ritual ceremony 9. This species is

one among 200 rare plant species to Indonesia
10. Using sophisticated equipment, LC-MS and

NMR, supported by DEPT techniques, this

species containing Scorocarpine B which is

leukemia cell inhibitor11. In addition, during

the last 3 decades, tremendous

advancement of science and technology has

been able to continuously uncover the

intrinsic value of biodiversity. In the near

future, many lead chemical compounds

may also be isolated and identified from

microbial genetic resources. Pseudobotyris

terrestris from Wallacea region is a fungal

species reported by Uchida 12 and Fraga 13

has an ability to produce enzymes for lipid

digestion which may important for treating

obesity and atherosclerosis in the future.

Diverse actinomycetes and actinomycetes

non streptomycetes are successfully being

isolated from the regions. The potential

value of non-actinomycetes non

streptomycetes are tremendous for

degrading polylactate resin and plastics, as

a raw material for developing anti-

cholesterol, antibiotics, anti-viral. anti-

tumor, anti-neoplastic, stabilizer for

medicine, food, cosmetics, for the

production of industrial enzymes,

diagnostics, food colorant, and novel paints

coatings 14.

The expedition to Foya Membramo, Papua

– Indonesia, discovered many new species

of reptiles, fishes, birds, and mammals. It is

not only important for taxonomists, but also

as materials in drugs discovery project.

Frog from genera of Xenopus, Silurana,

Hymenochirus, and Pseudhymenochirus in

the family Pipidae containing gene

responsible for the synthesis of small

aphifilic peptide collapsing ion-gradients

and lethal to many microbial pathogens.

Frogs skin are a rich source of genes

important in producing peptides with

varying degrees of antimicrobial activities

and cytotoxicities to mammalian cells.

Magainin, peptide glycine-leucine-amide

(PGLa), caerulein-precursor fragment

(CPF), and xenopsin-precursor fragment

(XPF) peptides have been isolated from

norepinephrine-stimulated skin secretions

from several species of Xenopus and

Silurana. Analogs of the magainins, CPF

peptides and hymenochirin-1B with

increased antimicrobial potencies and low

cytotoxicities have been developed that are

active (MIC < 5 μM) against multidrug-

resistant clinical isolates of Staphylococcus

aureus, Escherichia coli, Acinetobacter

baumannii, Stenotrophomonas maltophilia

and Klebsiella pneumoniae. Despite this,

genes having therapeutic potential in frog

skin as an anti-infective agents for anti-

cancer, anti-viral, anti-diabetic, or

immunomodulatory drugs 15.

Another great achievement is in pain

therapy. A chemical compound called

Ziconotide, which is also known as SNX-



Bangladesh Journal of Bioethics 2020; 11 (2): 35-41





38



111, is a novel non-opioid analgesic drug.

Ziconotide is actually a synthetic version of

ω-conotoxin MVIIA (ω-MVIIA), which is

a peptide that is found in the venom of the

fish-eating marine snail, Conus magus 16.

There are more than 600 different species of

cone snails exist. It belongs to the phylum

of Mollusca and the genus Conus. Most of

the species inhabit the warm water of

tropical reefs. The venom of each species of

cone snail contains its own unique mixture

of chemicals. This increases the likelihood

that some of the chemicals may be useful to

humans in the future. Ziconotide itself

could be up to 1,000 times more effective

than morphine at relieving pain and has the

added advantage of not being addictive. In

addition, it doesn't cause the development

of tolerance in the patient. Tolerance is a

state in which a medication that was once

effective no longer works. Ziconotide is

used after other analgesics have been tried

and have failed to work. It is prescribed

only for people who are suffering from

intense and prolonged pain, such as the pain

that may be experienced by people with

certain types of cancer or for people

experiencing neuropathic pain. Ziconotide

is sold under the brand name of Prialt. Santa

Cruz Biotech News mentioned that

ziconotide is sold as a selective antagonist

of N-Type Voltage Sensitive Calcium

Channels (VSCC) with a current price of

US$ 6.500.000 per gram 17.

Currently, data of entire genome sequences

of organisms can be extracted and saved as

electronic files. The genomic data has the

potential to be used to develop production

systems for fine chemicals without the need

to grow or cultivate the source organism,

known as synthetic biology. Thus, through

synthetic biology, genetic resources, genes

can be utilized readily for economic benefit.

An example of the production of chemical

compounds using synthetic biology is done

by Evolva, a Switzerland-based company.

The company produces vanillin through

synthetic biology. Genes in the vanillin

biosynthetic pathway were inserted in

yeast, and are being used to convert sugar

into vanillin. The fluctuating production

and price of natural vanillin due to climate

change and other factors will most likely

make synthetic biology-vanillin a viable

option in the future.



With those examples, biodiversity could be

used as a good starting point for

establishing bio-based industry including

synthetic biology. Biodiversity is an

important asset in developing a blue-print to

establish production pathways of high-

value chemical compounds using genetic

data from biodiversity which could boost

economic development while increasing

science capacity. Access to biodiversity is

mandatory. Legally binding protocol,

Nagoya Protocol, is in place. The

implementation of this protocol will not be

always easy and need to concider bioethics

principles.



How to proceed: The implementation

Nagoya Protocol on access, fair and equitable

sharing of the benefit from the utilization of

biodiversity is very complex and full with

ethical dilemmas. Basic principles stipulated in

the Universal Declaration on Human Rights and

Bioethics UNESCO 2005 such as consent

(persons without the capacity to consent),

equality, justice and equity, respect for cultural

diversity and pluralism, solidarity and

cooperation, sharing of benefits, protecting

future generations, protection of the

environment, the biosphere and biodiversity

may be applied in addressing ethical issues may

help to smoothen its implementation.



Bangladesh Journal of Bioethics 2020; 11 (2): 35-41





39



The consent of most people in developing

countries and less developed nations on the

intrinsic value of biodiversity is lacking.

For this reason, before access to biological

resources, the capacity to consent the

people in the developing country and less

developed nation own biodiversity should

first be improved.



With an appropriate knowledge on the

intrinsic value of biodiversity, the equality,

justice and equity may be developed through

continues dialog. Respect on cultural and

traditional knowledge should become an

instrument for access to biodiversity. In the

implementation of Nagoya Protocol, solidarity

and cooperation, sharing of benefits are an

important part which should be understood

by all parties involved.

The developed country who owns the

technology need an access to biodiversity,

basic principles of bioethics should be

incorporated in the mechanism of access to

ensure fair and equitable sharing of the

benefit from the utilization of biodiversity

and its components.

When access granted, another basic

principle of bioethics, protecting future

generations, protection of the environment, the

biosphere and biodiversity is mandatory. Over

exploitation should be prevented to ensure that

biodiversity is conserved, used sustainably

while creating the prosperity for all.

Trust between countries rich in biodiversity

and countries having high science and

technology capacity at all levels is

becoming a crucial factor. Greater

transparency and recognition on

comprehensive rights of people providing

biodiversity is a key element in maintaining

trust.

Global community has signed three legally

binding protocol namely the Convention on

Biological Diversity (UN-CBD) signed at

the Earth Summit in Rio de Janeiro, Brazil,

in 1992 and entered into force on 29

December 1993, Cartagena Protocol on

biosafety adopted on 29 January 2000 and

entered into force on 11 September 2003

and Nagoya Protocol on Access to genetic

resources and the Fair and Equitable

Sharing of Benefits Arising from their

Utilization to the Convention on Biological

Diversity which  entered into force on 12

October 2014. Those three legal documents

should be used to properly manage

biodiversity to ensure conservation,

sustainable use and sharing of the benefit

from the utilization of biodiversity and its

components. Those three legally binding

protocols are now ratified by Indonesian by

releasing national legislation namely Act

No. 5 Th 1994, Act No. 21 Th 2004 and Act

No. 11 Th 2013. The CBD, Cartagena and

Nagoya Protocol are in line with the

Indonesian Constitution, which clearly

states that all-natural resources belong to

the state and are to be used for the utmost

welfare/benefit of the people of Indonesia.



In the Preamble of the Convention on

Biological Diversity, it is mandatory for

each contracting party conscious the

intrinsic value of biological diversity and of

the ecological, genetic, social, economic,

scientific, educational, cultural, recreational

and aesthetic values of biological diversity

and its components and on the importance

of biological diversity for evolution and for

maintaining life sustaining systems of the

biosphere. Conservation of biological

diversity must be a common concern of

humankind, and each contracting party is

responsible for conserving their biological

diversity and for using their biological



Bangladesh Journal of Bioethics 2020; 11 (2): 35-41





40



resources in a sustainable manner. Each

contracting party is also fully aware that the

conservation and sustainable use of

biological diversity is of critical importance

for meeting the food, health and other needs

of the growing world population, for which

purpose access to and sharing of both

genetic resources and technologies are

essential. The implementation of such

protocol can not solely depend of rule and

regulation but need ethics/bioethics

considerations.



Trust between countries rich in biodiversity

and countries having high science and

technology is the most crucial factor in

implementing Convention on Biological

Diversity including Cartagena and Nagoya

Protocol. There is also a need for greater

transparency on the possible future value of

biodiversity through research and

development. Access to biodiversity is

subject to negotiation while respecting a

comprehensive right of the local peoples,

their needs and aspirations for sustainable

development and poverty alleviation.

A rights-based approach would be

important to promote people's knowledge

about the existence of their rights and to

develop political strategies to make

people’s rights become reality. Statement

from Australian National Health and

Medical Research Council is fundamental:

The responsibility for maintaining trust and

ethical standards cannot depend solely on

rules or guidelines. Ethical consideration

should be an integral part in the

implementation of such rules and

guidelines. In developing products of both

research and researchers should involve

people transparently and honestly

especially when dealing with values and

principles. The elimination of 'difference

blindness' and a subtlety of judgement is

required to eliminate prejudice and

maintain respect.

Model Legislation should be developed to

provide a comprehensive scheme for

ensuring conservation and sustainable use

of biological resources and to support for

the ‘inalienable rights of local communities

over their biological resources, knowledge

and technologies’. Access to biological

resources subject to prior informed consent

of local communities, fair and equitable

sharing of benefits, effective participation

of local communities and appropriate

institutional mechanisms to ensure effective

implementation of Nagoya Protocol on

Access and Benefit Sharing.



Conclusion and recommendation:

Nagoya Protocol on Access and Benefit

Sharing from the utilization of biological

resources is an important step to get most

benefit from biological resources. The

protocol could be a vehicle for strategic

partnership between country rich in

biodiversity and country with greater

capacity in science and technology. Due to

the nature of biodiversity where the

intrinsic value of the resources is uncertain

and can only be elucidated by advance

science and technology, the implementation

of Nagoya Protocol full of ethical

dilemmas. Rule and regulations is not

sufficient in implementing access and

benefit sharing properly. Ethics/Bioethical

consideration is of importance. Basic

principle stipulated in the Universal

Declaration on Human Right and Bioethics

UNESCO may incorporated to ensure

smooth implementation of the protocol.



Acknowledgements: Greatly acknowledge the

Universitas Nasional and the Indonesian Academy



Bangladesh Journal of Bioethics 2020; 11 (2): 35-41





41



of Sciences for giving me an opportunity to

participate in the 20th Asian Bioethics in Dhaka,

Bangladesh. Acknowledgement also directed to the

Organizing Committee for inviting me to join this

Symposium.



References:

1. Sukara, E. The 4th International Conference on
Sustainable Future for Human Security (SUSTAIN)
2013, Clock Tower Centennial Hall, Kyoto
University, Japan, Kyoto, October 2013; 18-21,

2013
2. Sukara, E. Biodiversity a Common Wealth for a
Crowded Planet. The 2nd GSS Leading Expert

Seminar – Graduate School Programme for

Sustainable Development and Survivable Societies,

Kyoto University – Japan December 19, 2013.
3. Sukara, E. Tropical Forest Biodiversity to provide
food, health, and energy solution of the rapid growth

of modern society. Procedia Environment Sciences
2014; 20: 803 – 808.
4. Sukara, E. 2019.  Capacity Building as Mutual
Benefit in Life Sciences Research Collaborations.

National Workshop: Evaluation of Capacity
Building Measure as Impacts of Research Permits.
Indonesian Ministry for Research and Higher
Education, Jakarta.

5. Widjaja, E. A., Y. Rahayuningsih, J. S. Rahajoe,
R. Ubaidillah, I. Maryanto, E. B. Walujo dan G.
Semiadi. Kekinian  Keanekaragaman Hayati. 2014,
LIPI Press, Jakarta: Indonesia.
6. Walujo, E. B. Keanekaragaman hayati untuk
pangan. Konggres Ilmu Pengetahuan Nasional X
Jakarta, 8 – 10 Nopember 2011.
7. Rahayu, M., S. Susianrti and Y. Purwanto. Kajian

pemanfaatan tumbuhan hutan non kayu oleh
masyarakat local di kawasan konservasi PT Wira
Karya Sakti Sungai Tapa – Jambi. Jurnal
Biodiversitas 2007; 8(1): 73 –78.

8. Ragamustari, K. RLeveraging jamu heritage using
science and technology. The Jakarta Post, Jakarta /
Mon, April 8, 2019 / 03:04 pm.
9. Siagian, M.H., M. Rahayu dan U. Hapid. Telaah
pemanfaatan tumbuhan “bawa hutan”
(Scorodocarpus borneensis) di Daerah Kenohan –
Kalimantan Timur. Prosiding Seminar Nasional

Etnobotani III. Dsnpasar – Bali, Hal” 2000, 270-273.

10. Mogea, J.P.M., D. Gandawidjaja, H.
Wiriadinata, R.E. Nasution dan Irawati. Tumbuhan

Langka Indonesia. Buku Seri Panduan Lapangan.
Pusat Penelitian dan Pengembangan Biologi – LIPI.

Balai Penelitian Botani, Herbarium Bogoriense.
Bogor, Indonesia, 2001.
11. Kartika, R., T. Barus, R. Surbakti, and P.
Simanjuntak. Structure Characterization of Alkaloid

Scorodocarpines derivative from Fruits of
Scorodocarpus borneensis Becc (Olacaceae). Asian
Journal of Chemistry. 2014; 26 (18): 6047-6049.
http://dx.doi.org/10.14233/ajchem.2014.16562.
(Updated on September 23, 2019).
12. Uchida, R., Y. Pil Kim, I Namatame, H. Tomoda
and S Omura. Sespendole, New inhibitor of lipid
droplet synthesis in macrophages, procuced by
Pseudobotrytis terrestis FKA 25. The Journal of

Antibiotics 2006; 59 (2): 93–97.
13. Fraga, B. M. Natural sesquiterpenoids. Natural
Product Report, Stanford University, Stanford,

USA,2007.
14. Sukara E, P. Lisdiyanti, H. Yamamura, J-Y.
Park, Y. Kurihara, N. Sukarno, W. Sjamsuridzal, K.
Ando, and Y. Widyastuti. Potentials of the Wallacea
Biodiversity in Bioprospecting. Berita Iptek 2009;
47 (1): 9- 18.
15. Conlon, J. M. and M. Mechkarska. Host-Defense
Peptides with Therapeutic Potential from Skin
Secretions of Frogs from the Family Pipidae.

Pharmaceuticals 2014, 7, 58-77;
doi:10.3390/ph7010058.
16. McGivern, J. G. Ziconotide: a review of its

pharmacology and use in the treatment of pain.
Neuropsychiatric Disease and Treatment 2007; 3(1):
69–85.
17. Crampton, L. Cone snail venom facts and

potential medical benefits. 2019.
https://owlcation.com/stem/Cone-Snails-
Dangerous-Venom-With-Medicinal-Uses (Updated
on September 23, 2019).













Author contribution: 1st author Endang Sukara

conceived the idea, designed of the manuscript,
performed the literature search, wrote the initial
draft, checked the manuscript meticulously and gave
final approval of the manuscript for submission. 2nd
author Safendrri Komara Ragamustari did the
critical revision of the article, performed the
literature search and gave the final approval of the
manuscript for submission. 3rd author Ernawati

Sinaga performed the literature search, revised the
article critically and checked the manuscript
meticulously and gave final approval of the
manuscript for submission.



Conflict of interests: No conflict of interest in this
study to declare.
