63   |  Vol. 3   No. 2 ,  July   202 2





P-ISSN : 2715-2448 | E-ISSSN : 2715-7199

Vol.3 No.2 July 2022

Buana Information Tchnology and Computer Sciences (BIT and CS)



A Time Series Based Gene Expression Profiling Algorithm for Stomach
 Cancer Diagnosis





Teresa Kwamboka Abuya1
Study Program

Computer Science
Kisii University, Kenya tkwambokaa@gmail.com











‹β›

Bayu Priyatna 2

Study Program
Information System

Universitas Buana Perjuangan Karawang

bayu.priyatna@ubpkarawang.ac.id







Abstrak— Eksperimen biologis telah menghasilkan sejumlah besar

data ekspresi gen yang memiliki nilai sangat besar untuk diagnosis,

pengobatan, dan pencegahan penyakit. Namun, kelemahan yang

cukup besar memang ada dalam pemanfaatan yang tepat dari data

ini karena skala yang besar dan kerumitannya. Sejumlah algoritma

telah dikembangkan untuk menginterpretasikan data ini dalam

bentuk profil gen untuk tujuan diagnosis. Diantaranya K-means,

pengelompokan hierarkis, pengelompokan berbasis kepadatan,

pengelompokan subruang, dan peta yang mengatur sendiri.

Sayangnya, algoritme ini mengabaikan ketergantungan berurutan

di antara titik waktu yang berurutan, tidak memadai dalam

penemuan pola untuk mengubah aktivitas selama interval terbatas

dari kerangka waktu eksperimen, dan tidak mampu membedakan

antara pola faktual dan acak. Dengan demikian, ada kebutuhan

untuk algoritme pembuatan profil gen yang mengatasi kekurangan

yang dibatasi waktu dalam algoritme saat ini dan karenanya

memfasilitasi pembuatan profil gen yang efisien untuk

mendiagnosis kanker perut secara dini. Selama bertahun-tahun,

eksperimen ekspresi gen deret waktu telah banyak digunakan untuk

mempelajari berbagai proses biologis seperti siklus sel,

perkembangan, dan respons imun. Dalam makalah ini

dikembangkan algoritma profil gen berdasarkan deret waktu untuk

diagnosis awal kanker lambung. Dengan menetapkan gen ke satu

set profil model yang telah ditentukan sebelumnya yang menangkap

pola potensial yang berbeda, signifikansi masing-masing profil ini

dapat ditetapkan. Profil signifikan ini kemudian dapat dianalisis

lebih lanjut dan digabungkan untuk membentuk cluster yang

kemudian dapat dimanipulasi oleh algoritma clustering. Idenya

adalah untuk mengukur aktivitas gen selama rentang waktu yang

singkat sehingga dapat menghasilkan gambaran universal tentang

fungsi seluler. Singkatnya, ini termasuk mendeteksi pola berulang

dalam data biologis. Pola-pola ini kemudian digunakan untuk

mengungkapkan informasi diagnostik yang mungkin penting bagi

praktisi medis. Desain penelitian eksperimental digunakan untuk

mencapai tujuan penelitian. Data yang berkaitan dengan genom

biologis digunakan untuk pekerjaan penelitian ini. Karena

perkembangan penyakit kanker saat ini, hasil dari penelitian ini

diharapkan dapat menjadi signifikan dalam diagnosis dini kanker

lambung sehingga pengobatan yang tepat dapat diberikan..

Kata kunci: Data microarray, respon imun, clustering, profil

signifikan, diagnosis kanker.

Abstract— Biological experiments have produced enormous

amount of gene expression data that possess enormous value for

the diagnosis, treatment, and prevention of diseases. However,

considerable drawbacks do exist in the appropriate utilization of

this data due to its massive scale and intricacy. A number of

algorithms have been developed to interpret this data in form of

gene profiling for diagnosis purposes. They include K-means,

hierarchical clustering, density-based clustering, subspace

clustering, and self-organizing maps. Unfortunately, these

algorithms ignore the sequential dependency among successive

time points, are inadequate in the discovery of patterns for

changing activity over a restricted interval of an experiment’s time

frame, and are incapable of discriminating between factual and

random patterns. As such, there is a need for a gene profiling

algorithm that addresses the time-constrained shortcomings in the

current algorithms and hence facilitating efficient profiling of

genes for early stomach cancer diagnosis. Over the years, time

series gene expression experiments have been widely used to study

a range of biological processes such as the cell cycle, development,

and immune response. In this paper a gene profiling algorithm

based on time series for early stomach cancer diagnosis is

developed. By assigning genes to a predefined set of model profiles

that capture the potential distinct patterns, the significance of each

of these profiles can be established. These significant profiles can

then be analyzed further and combined to form clusters that can

then be manipulated by clustering algorithms. The idea is to

measure the genes’ activities over a short period span so as to come

up with a universal depiction of the cellular functionality. In a

nutshell, this includes detecting recurring patterns in biological

data. These patterns are then employed to reveal diagnostic

information that may be important for the medical practitioners.

An experimental research design was utilized to achieve the study

objectives. Data pertaining to biological genomes was employed

for this research work. Due to the upsurge of cancer in the current

times, the outcomes of this research work is anticipated to be

significant in the early diagnosis of stomach cancer so that

appropriate medication can be administered.



Keywords: Microarray data, immune response, clustering,

significant profiles, cancer diagnosis.

I. INTRODUCTION









64   |  Vol. 3   No. 2 ,  July   202 2



Functional genomics is the discipline in which genes are

utilized in the determination of their function whereas gene

expression is an approach employed to examine the

functional changes in these genes. According to [1], the

expression level for a given gene across different

experimental conditions are collectively referred to as the

gene expression profile and the expression levels for all the

genes under an experimental condition are jointly referred to

as the sample expression profile.

One of the goals in microarray data analysis is the identification

of genes for which the expression level is significantly changed

under different experimental conditions. Another objective is

to cluster the expressed genes or samples having similar

expression profiles to make a meaningful biological inference

from the set of genes or samples (Martin et.al., 2016).

The field of bioinformatics essentially deals with biological

information processing. One of the requirements for effective

bioinformatics is an extensive range of computational models

that helps in representation and computation of massive

biological data. As [2] point out, biological experiments and

processes analysis require too much effort. Additionally, this

process can prove to be very slow. This can be attributed to the

ever-growing intricacy of the processes and fiery growth of

biological data emerging from laboratories universally. The

recent drawback, as [3] noted, is on how to convert this

enormous data repository into knowledge that can facilitate

understanding of biological processes and experiments

pertaining to both health and diseases. According to [4]

timeseries gene expression analysis allows for principled

estimation of unobserved time-points, clustering, and dataset

alignment. In this technique, every expression profile is

modeled as a piecewise polynomial which is estimated from the

observed data and every time point sways the overall smooth

expression curve. Gene expression experiments carried out

using time series show that unobserved timepoints can be

reconstructed with 10-15% less error when compared to other

profiling methods. The time series-based clustering algorithm

operates directly on the continuous representations of gene

expression profiles. This is particularly effective when applied

to non-uniformly sampled data.

Stomach Cancer (SC) is the fourth most frequently diagnosed

malignancy and the second leading cause of cancer death

worldwide (Yang et.al.,2018). Although the incidence of SC

has declined for decades, the prognosis of SC remains very

poor, especially in China. At present, the pathogenesis of SC is

unclear, thereby necessitating effective biomarkers and

targeted therapeutics. Traditionally, clinic pathological

parameters were used in risk stratification of SC outcomes.

However, a number of advanced SC patients remained stable

for a couple of years, whereas some early-stage patients

progressed rapidly [5]. Therefore, reliable biomarkers or

stratification systems that can be used for more accurate

prediction are highly essential [6].

The greatest challenge in cancer diagnosis is the identification

of a subset of genes with crucial roles in diverse stages of these

diseases’ progression from early stages of carcinogenesis to its

final stage of metastasis. As [7] explains, reliable identification

of molecular determinants of clinical outcomes can facilitate

the discovery of functional biomarkers predictive of therapy

response or disease progression. In addition, this can provide

insights into new therapeutic targets in this aggressive disease.

[8] further point out that the complexity of genomic networks

and the vast volume of genes present increase the challenges of

understanding and interpreting the resulting mass of data. The

problem is compounded by the vagueness, imprecision, and

noise present in this data. According to [9], the current

algorithms such as Hierarchical gene profiling algorithm, Self-

Organizing Maps (SoM), Support Vector Machines (SVM) and

K-means algorithm, can only detect relationships where there

is sufficient variability in gene expressions and as such,

functional interactions are only detectable if they induce

changes in transcriptional state that persist over a reasonable

timescale. To address this problem, algorithms for visualizing

high-throughput single-cell datasets and identifying putative

functional relationships between genes are required [10].

Due to the potential of time series to unravel biological

processes that take place over short time duration, this

research work employed this nonconventional data type to

come up with a gene profiling algorithm that is instrumental

in disease diagnosis in human beings. In this paper, a time

series - based gene profiling algorithm for early stomach

cancer diagnosis was developed. Early and accurate

diagnosis of stomach cancer can significantly improve the

design of personalized therapy and enhance the success of

therapeutic interventions. Since time series has the potential

of identifying significant chronological expression profiles

and the genes associated with this profile, it can enable the

comparison of cancer infected genes behavior across

multiple conditions over short time duration. Specifically,

the response of gastric epithelial cells infected with the

vacAmutant strain of the pathogen Helicobacter pylori was

investigated [11].

The contributions of this paper include the derivation of

mathematical parameters that were shown to help in the

generations of gene profiles over a limited duration of time.

The rest of this paper is organized as follows. Section 2

presents the related work while section 3discusses gene

profiles derivation. Section 4 gives a presentation of results

and discussion while part 5 concludes the paper.

II. METHOD

This paper adopted an experimental research design to

develop an algorithm that aided in the derivation of gene

profiles. The approach involved the derivation of gene

profiling parameters which were then employed to develop

a time-series based algorithm. This algorithm was then

experimented on sample genomic data described in section

A below, to provide the required gene profiles visualization

in the form of graphs. This visualization provided a straight

forward means of establishing the sequential dependency

among successive time point. In addition, the visualization

facilitated the discovery of patterns for changing activity

over a restricted interval of an experiment’s time frame.









65   |  Vol. 3   No. 2 ,  July   202 2



3.1 Data Set

The genomics data employed in this paper were from two

experiments measuring the response of gastric epithelial

cells infected with the vacA-mutant strain of the pathogen

Helicobacter pylori. The data is sampled at five time points

0 h, .5 h, 3 h, 6 h, and 12 h. A sample of these data is shown

in Figure 1 for G27 TC1 trial 4.






Figure 1. Sample G27 TC1 Trial 4 Data

This Figure 1 shows TC1 gastric epithelial (AGS) cells infected

with wild type H. pylori (G27) and isogenic mutants in cagA

and vacA for 0, 0.5, 3, 6, and 12 hours. Figure 2.0 shows the

G27 TC1 trial 5 data.






Figure 2. Sample G27 TC1 Trial 5 Data



In these data samples, hybridizations of G27 (trial 4) and cag

A- (trial 3) time-courses are accomplished in parallel. A

technical replicate of the G27 time course (trial 5) and

hybridization of vacA- (trial 3) time course is also

accomplished in parallel. The cag A 6- and 12-hour time points

technically replicated (trial 4) (the cag A 6-hour sample of trial

3 are lost).



3.2 Gene Profiling Modeling Process

This research dealt with the profiling, comparing and

visualizing gene expression data from short time series of two

experiments measuring the response of gastric epithelial cells

infected with the vacA-mutant strain of the pathogen

Helicobacter pylori. The gene expression profiling comprised

of four major steps as shown in Figure 3. As show in this figure,

the steps included the generation and normalization of

expression signals, testing each probe for its differential or

association with the phenotype, the application of proper

statistical significance criteria to identify the gene expression

profile, and the investigation of the functions and pathways of

the genes in the expression profile.












Figure 3. Gene Profiling Steps



Thereafter, a number of statistical significance criteria such

as Pearson correlation, P-value, Euclidean distance,

Logistic regression, Bonferroni correction, False discovery

rate and Time Points Permutation were applied to help

identify specific list of genes differentially expressed or

associated with the phenotype.

Although mutual information (MI) measure is superior over

simpler measures such as Pearson correlation as it is

capable of capturing complex non-linear and non-

monotonic dependencies. In addition, it can reflect the

dynamics between pairs or groups of genes, computing MI

involves estimating pair-wise joint probability distributions

which requires density estimation or data discretization,

with the accuracy of these estimates depending on sample

sizes. As this measure was not deployed in this research

study. Table 2 gives a summary for the deployment of the

various performance metrics.



Table 2 Performance Metrics Deployment



SNO  Statistical

Measure

Deployment

1.  Pearson

correlation

Weighted Relation

between all genes

2.  P-value  Significance of gene

coexpressions

3.  Euclidean

distance

Correlation distance

between gene profiles

4.  Logistic

regression

Estimate of cancerous

probability

5.  Bonferroni

correction

Adjustment to the

confidence levels







66   |  Vol. 3   No. 2 ,  July   202 2



6.  False discovery

rate

Adjustment to the

confidence levels

7.  Time Points

Permutation

Optimize the number of

required profiles





3.3 The Algorithm of modeling gene profiles The first

step was the commencement of the algorithm while the

second step in the processing activities was the input of the

genomics data as shown in Figure 4.0. in the next page. In

step three, validation is done against empty genomic file

upload such that if this field is empty, then an error message

is generated for this effect in the fourth step. During the fifth

step, the validation against spot IDs not included is done

such that if these IDs are not included, then they are

computed in the sixth step. The value of the spot ID is

initialized to 1 which are thereafter incremented by one

until the value of 24192 is reached, which is equivalent to

the number of genes in the file that were investigated.

Whereas spot IDs were unique for each gene entry, the same

gene symbol may appear multiple times in the data file

corresponding to the same gene appearing on multiple

spots.



The seventh step was the computation of the average value for

the expression values for the same gene. This was

accomplished using the median before further analysis on the

data was carried out. The eighth step was that option of filtering

some specific genes using P-value metric. In situations where

a gene was filtered, then it was excluded from further analysis.

Gene filtering was accomplished for those genes that did not

show a sufficient response to experimental conditions, those

genes that had too many missing values, or the gene expression

pattern over repeats was too inconsistent as dictated by the

minimum correlation between repeats. The ninth step was the

usage of additional parameters namely the maximum Pearson

correlation and maximum number of candidate model profiles

to dictate the selection of model profiles along with the

maximum number of model profiles and maximum unit change

in model profiles between time points as shown in Figure 5.0.

In this algorithm, the candidate model profiles were designed

to be nonconstant profiles which started at zero and increased

or decreased an integral number of units that was less than or

equal to the value of the maximum unit change in model

profiles between time points.



Figure.4. Gene Profiling Algorithm Pseudo-Code



When this parameter was set to zero, all permutations were

used. In the eleventh step, the P-value based significance

level was utilized to set the connotation level at which the

number of genes assigned to a model profile as compared

to the expected number of genes assigned was regarded as

significant. During the twelfth step, the permutation test

was set to permute all time points including time point zero

when computing the expected number of genes assigned to

a profile.



In this case, the developed algorithm located profiles with

significantly more genes assigned than expected on

condition that all the input columns had been randomly

reordered. On the other hand, during the thirteenth step, the

permutation test was configured not to permute at time

point zero and as such, the algorithm found profiles with

more genes assigned than expected on condition that all the

columns except for the first column had been randomly

reordered. In the developed algorithm, permuting time point

zero was preferred since it was the only test that took into

account the significant changes that took place between

time point zero and the immediate next time point (0.5 h).









67   |  Vol. 3   No. 2 ,  July   202 2





In the fourteenth step, the correction method was utilized to

adjust the significance level since this algorithm was meant

to test multiple profiles for significance. Two types of

corrections were utilized in this algorithm. The first one was

the Bonferroni correction while the second one was the

conservative false discovery rate (FDR) control. In the third

scenario, no correction was made for the multiple

significance tests.





Figure 5. Modeling Gene Profiling Process



In the fifteenth step, two parameters namely the minimum

correlation and the minimum correlation percentile were

utilized to control the grouping of significant model profiles

into clusters. In so doing, these parameters served to control

how similar two model profiles had to be if they were grouped

together. For the case of the minimum correlation, any two

model profiles assigned to the same cluster of profiles had to

have a correlation above this parameter's value.  On its part, the

minimum correlation percentile was employed in cases there

were repeat data from different time periods. It was used to

specify that any two model profiles assigned to the same cluster

of profiles had to have a correlation in their expression greater

than the correlation of this percentile in the distribution of gene

expression correlations between the repeats. The last step was

the display of the gene profiles based on the Euclidean distance

after which the algorithm halted in the seventeenth step.  Figure

6 gives a diagrammatic representation of the gene profile

derivation process. As this figure shows, the process gene

profile derivation process involves the input of the genomic

data containing the gene expressions to be profiled.



These data items are analyzed using parameters such as Pvalue,

Pearson correlations, permutations, logistic regression and

median to yield probable profiles as already discussed above.

Correction methods are then employed to adjust the

significance level to permit the testing of multiple profiles for

significance.





Figure 6. Schematic Gene Derivation Process



The output gene groupings are then clustered using minimum

correlation and minimum correlation percentile before

Euclidean distance is applied to them to distinguish the various

gene profiles. The final outputs are the gene profiles in form of

graphs.



The logic here was that when the number of candidate

model profiles exceeded the p - value of seeing t more genes

in the intersection, then instead of explicitly generating al l

candidate model profiles, a subset of candidate model profiles

of this size was randomly selected. In the tenth step, the

number of permutations per gene parameter was employed to

specify the number of permutations of time points that were

randomly selec ted for each gene when computing the

expected number of genes assigned to each of the model

profiles.











68   |  Vol. 3   No. 2 ,  July   202 2



III.RESULTS AND DISCUSSION

In this section a time series-based gene profiling algorithm is

developed. To test the derived parameters and their gene

profiling abilities, the algorithms and statistical computations

were put into use to achieve some functionality as shown in

Table 3. The genomics data from two experiments measuring

the response of gastric epithelial cells infected with the vac A-

mutant strain of the pathogen Helicobacter pylori were then fed

as input to this algorithm.





Table 3. Gene Derivation Process
Step  Parameter  Activity
1  n/a  -Commence gene derivation process
2  n/a  -Input genomic data
3  n/a  -Validation is done against empty genomic file upload
4  n/a  -Prompt genomic data input error
5  n/a  -Validation against spot IDs
6  n/a  -If not included in file compute spot IDs
7  Median  -Computation of the average value for the expression values for the same

gene
8  P-value  -Filtering specific genes
9  Pearson correlation, p-value  -Model profiles selections.
10  Permutation  -Computation of  the expected number of genes assigned to each of the

model profiles
11  P-value, Logistic regression


-Setting the connotation level at which the number of genes are assigned

to a model profile

12  Permutation  -Compute the expected number of genes assigned to a specific profile
13  Permutation  -Configure  permutation test not to permute at time point zero
14  Bonferroni, FDR  -Adjust the significance level to test multiple profiles for significance
15  Minimum correlation, minimum correlation  -Control grouping of significant model profiles into clusters

percentile
16  Euclidean distance  -Display generated gene profiles
17  n/a  -Halt gene derivation process



The minimum absolute expression change was any value

more than -0.05. As an illustration, using the maximum

number of missing values to be 2, the minimum correlation

between repeats to be 0, and the minimum absolute

expression change to be 0.05 yielded the information in

Table 4.0 for the sample filtered genes. Table 4. Sample

Filtered Genes



The genes that were devoid of these three characteristics

were regarded as standard genes and were the ones that took

part in further analysis. Table 5 gives information on the

sample genes that passed the classification criteria.

Table 5. Sample Genes Passing Classification Criteria





Afterwards, eight parameters were utilized for the

computational derivation of gene profiles from this set of data:

maximum correlation, maximum number of candidate model

profiles, maximum number of model profiles and maximum

unit change in model profiles between time points, number of

permutations per gene, significance level, and correction

method as shown in Table 6 below.

Table 6. Gene Profiles Evaluation Metrics
Gene Profiling Option  Value

Maximum correlation  1
Maximum number of candidate model profiles  1,000,000

Number of permutations per gene(0 for all permutations)  0
P-value significance level  0.05

Maximum Number of model profiles  50
Maximum unit change in model profiles between time points  2

Correction method  None
Minimum Correlation  0.7



Based on the evaluation metrics of Table 6.0, the algorithm was

run to yield the proposed gene profiles.

3.1 Time Series-Based Gene Profiling.

In this profiling, the maximum correlation specified the value

that the maximum correlation between any two model profiles

had to be below, and was therefore employed to guarantee that

two very similar profiles were not selected. The maximum

value for this parameter was set to 1 in order to prevent two

perfectly correlated model profiles from being selected. It was

observed that lowering this parameter led to the number of

model profiles selected being less than the maximum number

of model profiles even in situations where more candidate

model profiles were available.



On the other hand, the maximum number of candidate model

profiles represented  non-constant profiles which commenced

at 0 and increased or decreased an integral number of units that

was less than or equal to the value of the maximum unit change

in model profiles between time points. The number of

permutations per gene parameter specified the number of

permutations of time points that were randomly selected for

each gene when computing the expected number of genes

assigned to each of the model profiles.









69   |  Vol. 3   No. 2 ,  July   202 2



When this parameter was set to 0, all permutations were used.

It was also important to set permutation test to permute time

point 0 or not. When computing the expected number of genes

assigned to a profile, if the permutation test for time point 0 was

set, the permutation test permuted all time points including time

point 0. It was observed that doing this led to profiles with

significantly more genes being assigned than expected if all the

input columns had been randomly reordered. On the contrary,

if the permutation test was not set for 0, the permutation test

permuted all time points except for time point 0. In this

scenario, profiles with more genes were assigned than expected

if all the columns except for the first column had been randomly

reordered.



Permuting time point 0 was preferred since only this test took

into account significant changes that occurred between time

point 0 and the immediate next time point. However in some

cases based on experimental design a gene's expression value

before transformation at time point 0 was expected to be known

more accurately than the other time points, and because of this

asymmetry, not permuting time point 0 was also be useful.



It was observed that increasing the maximum number of

model profiles increased the number of candidate models as

shown in Table 7.



Table 7. Maximum Number of Gene Model Profiles Viz.

Significant Gene Models
Maximum Number of Model Profiles  Resulting Sig. Number of Gene Models
50  14
60  16
70  18
80  20
100  21
120  23
140  24



Based on the values in Table 7, a graph was plotted for

maximum number of model profiles against the resulting

significant number of gene models as shown in Figure 7.






Figure 7. Maximum No. of model profiles Viz. Resulting

Significant. No. of Gene Models



The graph of Figure 7.0 shows that the resulting significant

number of gene models increase nearly exponentially as the

maximum number of model profiles was increased.

Consequently, to get fine grained gene model profiles, the

maximum number of model profiles had to be increased and

vice versa. Table 8.0 gives the shift in the resulting

significant number of gene profiles as the maximum unit

change in model profiles between time points was adjusted.



Table 8. Maximum Unit Change in Model Profiles Viz.

Significant Gene Models
Maximum Unit Change in  Model Profiles  Resulting Sig. Number of Gene Models
1  13
2  14
3  15
4  13
5  14
6  15
7  15
8  16
9  16
10  15



As shown in this table, generally as the maximum unit change

in model profiles is increased, the resulting significant number

of gene models is increased. This is due to the pronounced

Euclidean distances between the gene models. Regarding

maximum correlation, the value of minimum correlation was

set to zero (0) and the value of maximum correlation was

slowly reduced from 1 to zero. The results obtained are shown

in Table 9 are observed.



Table 9. Maximum Correlations Viz. Significant Gene  Models


 Maximum Correlation  Resulting Sig. Number of Gene Models Number of Genes Assigned

1  12  1005
0.9  12  1005
0.8  9  993
0.7  6  1185
0.6  4  1216
0.5  3  1243
0.4  3  1348
0.3  3  1348
0.2  3  1470
0.1  3  1470
0  1  1275



Generally, as the value of maximum correlation is reduced from

one to zero, the number of resulting significant number of gene

models reduced to unity (1) while the number of genes assigned

to these gene models increased from 1005 to a maximum value

of 1275. This implies that when the correlation value is small,

gene models are basically indistinguishable hence at

correlation zero, there is only one resulting significant model.

On the other hand, at maximum correlation, the genes can be

clearly distinguished and hence the resulting significant gene

models are many.



Concerning the number of genes assigned to models, at low

correlation coefficients, genes profiles are indistinguishable

and hence a large number of genes are assigned to the few

available models. However, as the correlation coefficients are

increased, the gene profiles become increasing disparate and







70   |  Vol. 3   No. 2 ,  July   202 2



few genes are assigned to each of the many models now

available as the rest are discriminated due to their large pvalues.



3.2 Prediction Power of the Developed Algorithm In the

developed algorithm, sequences of gene expressions were

listed in order of occurrence, starting at time point 0h to 12h.

The aim was to collect and investigate precedent observations

of gene expressions at various time points in order to come up

with ideal models to express the intrinsic structure of the

underlying genomic data. Based on these models, it was

possible to predict future gene expressions. To put this into

perspective, profile ID 17 was considered whose gene

expressions are shown in Figure 8.



Figure 8. Gene Expressions for Profile ID 17



A total of 54 genes were assigned to this model profile

whose individual expressions are shown in Figure 8. By

sketching a line of best fit through these gene expressions

and performing some extrapolations, the future expressions

beyond the 12h time point can be obtained as shown in

Figure 9 below.


Figure 9. Gene Profile Prediction



The white thick line through the gene expressions is the line

of best fit while the thick red line represents the

extrapolated gene expressions for the 54 genes assigned to

profile ID 17 for the future 18h and 30h time points.

Suppose that the stomach cancer patient gene expressions

are as shown in Figure 10 below.




Figure 10. Stomach Cancer Patient Gene Expressions over

30h Duration



Comparing the hypothesized gene expressions over the 30h

duration and the gene models in Figure 11.0 below, then

considering the first few gene expressions, model profile

IDs 13, 14,15,16,17 and 18 are candidates’ models that the

stomach cancer patient gene expressions can fit in.

However, taking into account the preceding time points

eliminates model profiles 14(experiences near exponential

growth followed by plateau), 15(experiences linear growth

followed by plateau), 16 (portrays linear growth, linear

decay and plateau), and 18 (presents linear growth followed

by plateau). This leaves profile ID 13 and 17 as the most

probable model profiles. By drawing a horizontal line

through these two profiles as shown in Figure 11, it is

possible to discern which of them perfectly fits the patient

gene expressions.







Figure 11. Gene Model Fitting



Based on this line and considering time-points at which troughs

and crests appear, it is clear that model profile ID 17 perfectly

fits the patient gene expressions for a duration of 30h time

points. As such, it can be implied that the developed algorithm

led to accurate diagnosis of stomach cancer patients within 12h

time points since the commencement of the cancerous gene

expressions. In the next section, this algorithm is validated

against some well-known gene profiling algorithms.



3.3 Validation of the Developed Algorithm In this section,

the time series-based algorithm that was developed is validated









71   |  Vol. 3   No. 2 ,  July   202 2



against other gene profiling algorithms such as Hierarchical

gene profiling algorithm, Support Vector Machine, Self-

organizing maps, and K-means algorithm. In Hierarchical gene

profiling algorithm, genes with related expression patterns are

grouped together and connected by a series of branches to form

a dendrogram. Unfortunately, this algorithm considers each

gene as an individual cluster and genes that are similar to each

other form nested clusters based on the pair-wise distances.



On the other hand, the time series-based algorithm developed

in this research study considered a group of genes with similar

expressions as profile clusters. For instance, in Figure 6.6, a

total of 155 genes were represented by a single model profile

with ID 40 and 90 genes were represented by model profile ID

37. These two model profiles formed a cluster with a total of

245 genes. As such, the developed algorithm is operationally

faster during gene profiling compared to Hierarchical gene

profiling algorithm, rendering it ideal for large genomic data

set. The genomic data that was utilized in this research

consisted of 24192 gene symbols observed under 5 time points,

making the total gene expressions 120960, a very big data set

for the rather slow Hierarchical gene profiling algorithm.



To effectively apply the Support Vector Machine gene profiling

algorithm, it requires training using the same members of each

model profile that have to be identified. This training takes time

and hence compared to the developed algorithm, it is slow and

hence inefficient for large data sets such as the 120960 gene

expressions that were under investigation in this research.



Although Self-organizing maps algorithm has been employed

to group 1,036 genes into 24 categories, this algorithm is slow

in training, hard to train against slowly evolving data and are

not so intuitive since neurons close on the map (topological

proximity) may be far away in feature space. Additionally,

these maps do not behave so gently when using categorical

data, or mixed data. Comparing the 1036 genes that

Selforganizing maps algorithm profiled into 24 categories with

the 24192 genes that were profiled using the developed time

series-based algorithm, it is clear that the proposed algorithm is

efficient.



Regarding SVM algorithm, this algorithm has been used for

cancer classification with microarray data where it served as a

powerful classifier together with four effective feature

reduction methods namely principal components analysis

(PCA), class-separability measure, Fisher ratio and t-test to the

problem of cancer classification based on gene expression data.

Although it very high classification accuracies, it requires

feature reduction methods which renders it structurally

complex compared to the time series-based algorithm

implemented in this research.



On its part, the K-means algorithm operates on a series of

microarray experiments measuring the expression of a set

of genes at regular time intervals in a common cell line. It

requires that data be normalized to permit for comparisons

across these microarrays. The output produced is in form of

clusters of genes which vary in similar ways over time and

hence it is possible to infer that genes which vary in the

same way may be co-regulated and or participate in the

same pathway. Unfortunately, the numbers of clusters need

to be specified which may be unknown in some instances,

and figuring out the right number of clusters that represent

the true number of clusters in the population is quite

subjective. As such, the profiles obtained using K-means

can vary greatly depending on the location of the

observations that are randomly chosen as initial centroids.

However, the developed time series-based algorithm

employs statistical metrics such as p-value, Pearson

correlation, logistics regression and Euclidean distance

whose significance levels are well known.



The K-means clustering algorithm assumes that the

underlying clusters in the population are spherical, distinct,

and are of approximately equal size and hence tends to

identify clusters with these characteristics. Therefore, this

algorithm is incapable of yielding good results when

clusters are elongated or not equal in size like the genomic

data used in this research where some gene expressions

were negative, zero and others positive. The K- algorithm

is also sensitive to initial conditions, implying that different

initial conditions produce varying result of gene profiles. It

is also possible for a very far data from the centroid to pull

the centroid away from the real one as shown in Figure 12.

below. Here, 5 genes are assigned to cluster ID 55 and it is

clear from the gene.






Figure 12. K-Means Based Profiling



Expressions that the profiling is not such accurate especially

after the 0.5h time point. Whereas 4 gene expressions have

negative gradients, one of them has a positive gradient.

During the 3h time-point, some gene profiles are at the

rough, others are at the crest, plateau while others are still

on their descent. The same is observed during the 6h time

point. These varying result of gene profiles give

contradicting depiction of gene activities and hence may

lead to inaccurate stomach cancer diagnosis.



IV.CONCLUSION

The aim of this paper was to develop a gene profiling

algorithm based on time series to help in early stomach cancer

diagnosis. Based on a number of derived gene profiling







72   |  Vol. 3   No. 2 ,  July   202 2



parameters, an algorithm was developed that was then

experimented on sample genomic data. The results of this paper

included a number of gene profiles that obtained from the

underlying pathogen Helicobacter pylori data. The significance

of this research lies on the fact that it helped generate gene

profiles using very short time points. This feature is very

critical in early stomach cancer diagnosis as it facilitates

necessary preventive measures that curtail the cancerous cells

advancement to other fatal phases. Since this research was

purely based on stomach cancer, future work in this area lies on

the implementation of this algorithm for other types of cancer

or diseases.


REFERENCES

[1] Sanchita & Ashok S. (2015). Future Challenges in

Application of Algorithms and Tools for Clustering of

Gene Expression Data. Biotechnology Division,

CSIRCentral Institute of Medicinal and Aromatic Plants.

Lucknow 22601. (pp. 515-531)5 India.

[2] Brohée S., Barriot R., &  Moreau Y. (2015).Biological

knowledge bases using Wikis: combining the flexibility of

Wikis with the structure of databases. Bioinformatics,

Oxford Journals.

[3] Wong  K.    (2016).Computational

 Biology  and

Bioinformatics: Gene Regulation. CRC Press.

[4] Ziv B., Georg G., David K., & Tommi S. (2015). A New

Approach to Analyzing Gene Expression Time Series

Data. Whitehead Institute for Biomedical Research.

[5] Wang, H., Wang, X., Xu, L. et al. (2020).High expression

levels of pyrimidine metabolic rate–limiting enzymes   are

adverse prognostic factors in lung adenocarcinoma: a

study based on The Cancer Genome Atlas and Gene

Expression Omnibus datasets. Purinergic Signalling 16,

347–366 (2020). https://doi.org/10.1007/s11302-020-

09711-4.

[6] Wenhui, Y.,  Zhiyong L.., Yuan, Li.,  Jianbing, M.,

Mudan, Yang., Jun, X.(2019).Immune    signature

profiling  identified prognostic factors for gastric cancer.

Chinese journal of cancer research. Https// doi:

10.21147/j.issn.1000-9604.2019.03.08.[7] Abolfazl R.,

Fatemeh A., Salendra S., and Vinay V.

(2016).NetworkBased Enriched Gene Subnetwork

Identification: A Game-Theoretic Approach. Biomed Eng

Comput Biol. Vol. 7, Issue 2, pp. 1–14.

[8] Oyelade J., Itunuoluwa I., Funke O., Olufemi A., Efosa

U., Faridah A., Moses A.,  and Ezekiel A. (2016).

Clustering Algorithms: Their Application to Gene

Expression Data. Bioinformatics and Biology

Insights,10, 237–253.

[9] Thalia E.C.,  Michael P.H., and Ann C. (2017).Gene

Regulatory Network Inference from Single-Cell Data

Using Multivariate Information Measures. Cell

Systems,  5, 251–267.

[10] Gwang H., Peter S., Sung J., & Joo H. (2016). Screening

and surveillance for gastric cancer in the United States:

Is it needed? American Society for Gastrointestinal

Endoscopy. Volume 84, No. 1, pp. 18-28.

[11] Siregar, Amril Mutoi, et al. "Perbandingan Algoritme

Klasifikasi Untuk Prediksi Cuaca." Jurnal Accounting

Information System (AIMS) 3.1 (2020): 15-24.
