Challenges to Global
Implementation of Infrared
Thermography Technology:
Current Perspective

Michael Shterenshis1


1Department of Sciences, Alexander
Muss Institute for Israel Education











Vol. 6, No. 1 (2017)   |   ISSN 2166-7403 (online)
DOI 10.5195/cajgh.2017.289 |   http://cajgh.pitt.edu

http://www.library.pitt.edu/
http://www.pitt.edu/
http://www.library.pitt.edu/articles/digpubtype/index.html
http://www.upress.pitt.edu/upressIndex.aspx
http://creativecommons.org/licenses/by/3.0/us/




SHTERENSHIS



This work is licensed under a Creative Commons Attribution 4.0 United States License.


This journal is published by theUniversity Library System of the University of Pittsburgh as part

of its D-Scribe Digital Publishing Program and is cosponsored by the University of Pittsburgh Press.


Central Asian Journal of Global Health
Volume 6, No. 1 (2017) |  ISSN 2166-7403 (online) | DOI 10.5195/cajgh.2017.289|http://cajgh.pitt.edu




Abstract

Medical infrared thermography (IT) produces an image of the infrared waves emitted by the human body as part of the
thermoregulation process that can vary in intensity based on the health of the person. This review analyzes recent developments in
the use of infrared thermography as a screening and diagnostic tool in clinical and nonclinical settings, and identifies possible future
routes for improvement of the method. Currently, infrared thermography is not considered to be a fully reliable diagnostic method.
If standard infrared protocol is established and a normative database is available, infrared thermography may become a reliable
method for detecting inflammatory processes.

Keywords: Infrared Thermography; Mass Screening; Epidemics

Challenges to Global Implementation
of Infrared Thermography
Technology: Current Perspective

Michael Shterenshis1


1Department of Sciences, Alexander Muss
Institute for Israel Education

Research

  Medical infrared thermography (IT)
produces an image of the infrared waves emitted by the
human body as part of the thermoregulation process that
can vary in intensity based on the health of the patient.1
While the technology was originally developed in the
1950s, its development was much slower than
ultrasonography, despite the fact that both methods are
potentially highly informative, non invasive, and
radiation free. On PubMed, there are 1,820 articles on the
term “infrared thermography” dating from May 1963 to
2017, while 398,932 articles on “ultrasound” were
published during the same period. The IT finally gained
more attention in the 2000s with the emergence of avian,
swine, and H1N1- influenza outbreaks, and other similar
pandemics. The first articles describing IT
implementation for mass blind fever screening in
international airports appeared in 2004.2,3  Detection of
febrile passengers by IT scanning in airports became a

common trend and several more reports supporting the
use of this technology were published.4-6 However, other
published reports questioned reliability of the IT
technology as a fever screening procedure, specifically
citing technical errors leading to low sensitivity of the
screening procedure.7,8

  Recent progress in improvement of infrared
camera technology sensitivity, excellent time resolution,
as well as calibration according to heat emissivity, room
temperature, humidity, and distance to the object of
interest, caught practitioners unprepared to take full
advantage of the IT capacities that exist today.

Currently published research papers on IT do
not provide complete and detailed descriptions of how
the camera and/or the software were calibrated and what
settings have been used. In 2013, Choi et al. detected the
mean temperature of healthy cheeks to be 26-27°C,11
which is about 4°C lower than normal. The article does
not report room humidity or the distance between the
camera and the investigated face.

Another study reported the surface skin
temperature of a healthy knee as median 36°C and
maximum of 38.1°C. 12 This reading is about 6-7°C
higher than normal and the article provides minimal
detail about the data acquisition process (including room
temperature, humidity, distance to object, and heat
emissivity preset).13 While some papers clearly report
laboratory room temperature and a relative air humidity,
they may omit other important variables.13,14 For

http://www.library.pitt.edu/
http://www.pitt.edu/
http://www.library.pitt.edu/articles/digpubtype/index.html
http://www.upress.pitt.edu/upressIndex.aspx
https://www.ncbi.nlm.nih.gov/pubmed/20920098
https://www.ncbi.nlm.nih.gov/pubmed/20920098
https://www.ncbi.nlm.nih.gov/pubmed/20920098
https://www.ncbi.nlm.nih.gov/pubmed/20920098





CENTRAL ASIAN JOURNAL OF GLOBAL HEALTH




This work is licensed under a Creative Commons Attribution 4.0 United States License.


This journal is published by theUniversity Library System of the University of Pittsburgh as part
of its D-Scribe Digital Publishing Program and is cosponsored by the University of Pittsburgh Press.


Central Asian Journal of Global Health

Volume 6, No. 1 (2017) |  ISSN 2166-7403 (online) | DOI 10.5195/cajgh.2017.289|http://cajgh.pitt.edu




example, an article describing the IT assessment of joints
with active arthritis reported ambient room temperature
and skin emissivity, but did not indicate the precise
distance to the object ("the camera was positioned
directly over the hands") and the room humidity.15

Out of 200 recently published (May 2013-May
2017) PubMed research on IT implementation as a
screening and diagnostic tool for various clinical
conditions, only 13 articles (6.5 percent of total articles)
have complete data acquisition methodology (correct
calibration of the IT device and/or software for skin heat
emissivity, distance to object, air humidity, air
temperature, etc.).

General thermography guidelines, standards,
and protocols, were introduced in 2002 and were
followed by specific guidelines for
neuromusculoskeletal, dental-oral, and systemic
disorders in 2015 and 2016.16-18 These guidelines
articulate that the room temperature range should be
maintained between 18 and 23°C during the investigation
and that a minimum equilibration period of 15 minutes
should be observed for patient acclimation to the room.
Given varying temperatures at airports and inability to
achieve 15 minutes acclimation periods for every
passenger, the guidelines may suggest that IT cannot be
used as an accurate screening method at the airports. The
guidelines do not indicate that an IT technician or a
practitioner must calibrate the camera for human skin
heat emissivity (0.98), existing room temperature and
humidity, and distance between the camera and the
region of interest. Most modern IT cameras have the
program for this preset in their menu.19-21 Even without
proper camera calibration, the data for these variables can
be put into software program directly before image
analysis. The time of day during investigation should be
indicated as well to accommodate human temperature
changes due to circadian rhythm.22-25 With normal
circadian rhythm, the human body has its lowest
temperature at 4 AM and its highest temperature at 6 PM.
This variation needs to be adjusted for with proper

correction index in order to correctly interpret
measurement results.

An individual approach to each subject is
warranted if IT is used for screening. The necessary
primary step in any proper IT investigation is to establish
a normative range of surface skin temperature changes of
a given person because of interpersonal
vasoconstriction/vasodilatation variations. This scale
will provide an IT practitioner with an understanding of
what is normal and what is abnormal for a given patient.
Sympathetic skin response and the vasomotor reflex vary
in different cases and these variations can be detected by
the IT.26

Review articles on IT provide either
favorable27,28 or unfavorable29,30 feedback about its
applicability for mass screening. The favorable reviews
suggest that for certain applications, thermal imaging is
shown to provide objective measurement of temperature
changes that are clinically significant for the detection of
local inflammatory processes, skin lesions, benign and
malignant tumors, vasoactivity, and vascular diseases.
With properly calibrated IT cameras and improved
knowledge of normative skin temperatures on various
body surfaces, practitioners will be able to assess
cutaneous vasoactivity.  Thus, the IT method might be
reliable in the clinical settings but not recommended as a
screening procedure at the airports. A portable, radiation-
free, inexpensive, non-contact, and non-invasive IT
device could become a welcomed addition to the hospital
armamentarium in many developing countries assuming
the development and implementation of proper standard
guidelines.



References
1. Diakides NA, Bronzino JD., eds. Medical Infrared Imaging.
London – New York: Taylor & Francis, 2008.

2. Chan LS, Cheung GT, Lauder IJ, Kumana CR, Lauder IJ.
Screening for fever by remote-sensing infrared thermographic
camera. J Travel Med. 2004;11(5):273-9.

http://www.library.pitt.edu/
http://www.pitt.edu/
http://www.library.pitt.edu/articles/digpubtype/index.html
http://www.upress.pitt.edu/upressIndex.aspx
https://www.ncbi.nlm.nih.gov/pubmed/15544710
https://www.ncbi.nlm.nih.gov/pubmed/15544710



SHTERENSHIS


This work is licensed under a Creative Commons Attribution 4.0 United States License.


This journal is published by theUniversity Library System of the University of Pittsburgh as part

of its D-Scribe Digital Publishing Program and is cosponsored by the University of Pittsburgh Press.


Central Asian Journal of Global Health
Volume 6, No. 1 (2017) |  ISSN 2166-7403 (online) | DOI 10.5195/cajgh.2017.289|http://cajgh.pitt.edu




3. Ng EY, Kaw GJ, Chang WM. Analysis of IR thermal imager
for mass blind fever screening. Microvasc Res. 2004;68(2):104-
9.

4. Nishiura H, Kamiya K. Fever screening during the
influenza (H1N1-2009) pandemic at Narita International Airport,
Japan. BMC Infect Dis. 2011;11:111. doi: 10.1186/1471-2334-
11-111.

5. McBride WJ, Buikstra E, FitzGerald M. Investigation of
febrile passengers detected by infrared thermal scanning at an
international airport. Aust N Z J Public Health. 2010;34(1):5-10.
doi: 10.1111/j.1753-6405.2010.00466.x.

6. Sun G, Saga T, Shimizu T, Hakozaki Y, Matsui T. Fever
screening of seasonal influenza patients using a cost-effective
thermopile array with small pixels for close-range thermometry.
Int J Infect Dis. 2014;25:56-8. doi: 10.1016/
j.ijid.2014.03.1398.

7. Bitar D, Goubar A, Desenclos JC. International travels and
fever screening during epidemics: a literature review on the
effectiveness and potential use of non-contact infrared
thermometers. Euro Surveill. 2009;14(6). pii: 19115.

8. Canadian Agency for Drugs and Technologies in Health.
Mass Thermography Screening for Infection and Prevention: A
Review of the Clinical Effectiveness [Internet]. Ottawa (ON);
2014 Nov 19.

9. Diakides NA, Diakides M, Lupo JC, Paul JL, Balcerak R.
Advances in medical infrared imaging. In: Diakides NA, Bronzino
JD., eds. Medical Infrared Imaging. London – New York: Taylor
& Francis, 2008, p. 1-1.

10. Fujita K, Noguchi M, Yuzuriha S, Yanagisawa D, Matsuo K.
Usefulness of infrared thermal imaging camera for screening of
postoperative surgical site infection after the Nuss procedure.
Case Rep Surg 2013; 2013:946156. doi: 10.1155/2013/946156

11. Choi HG, Kwon SY, Won JY, Yoo SW, Lee MG, Kim SW,
Park B. Comparisons of Three Indicators for Frey's Syndrome:
Subjective Symptoms, Minor's Starch Iodine Test, and Infrared
Thermography. Clin Exp Otorhinolaryngol 2013; 6(4): 249-53.
doi: 10.3342/ceo.2013.6.4.249.

12. Romanò CL, D'Anchise R, Calamita M, Manzi G, Romanò
D, Sansone V. Value of digital telethermography for the diagnosis
of septic knee prosthesis: a prospective cohort study. BMC
Musculoskelet Disord. 2013; 14: 7. doi: 10.1186/1471-2474-14-
7.

13. Denoble AE, Hall N, Pieper CF, Kraus VB. Patellar surface
skin temperature reflects knee osteoarthritis severity. Clin Med
Insights: Arthritis and Musculoskeletal Disorders 2010;3:69-75,
doi: 10.4137/CMAMD.S5916

14. Balbinot LF, Canani LH, Robinson CC, Achaval M, Zaro MA.
Plantar thermography is useful in the early diagnosis of diabetic
neuropathy. Clinics (Sao Paulo) 2012; 67(12): 1419-25.

15. Spalding SJ, Kwoh CK, Boudreau R, et al. Three-
dimensional and thermal surface imaging produces reliable
measures of joint shape and temperature: a potential tool for
quantifying arthritis. Arthritis Res Ther. 2008; 10(1): R10. doi:
10.1186/ar2360.

16. Thermography guidelines, Standards and Protocols in
Clinical Thermographic Imaging (September 2002)
[http://www.iactorg.org/professionals/thermog-
guidelines.html#/imaging]

17. American Academy of Thermology – AAT. Guidelines For
Dental-Oral And Systemic Health Infrared Thermography. Pan
Am J Med Thermol 2015:2(1): 44-53, DOI:
http://dx.doi.org/10.18073/2358-4696/pajmt.v2n1p44-53

18. American Academy of Thermology – AAT. Guidelines for
Neuromusculoskeletal Infrared Thermography Sympathetic Skin
Response (SSR) Studies. Pan Am J Med Thermol 2016:2(1): 35-
43, DOI: http://dx.doi.org/10.18073/2358-
4696/pajmt.v2n1p35-43

19. ThermoVision SC6000 Science-grade infrared camera.
FLIR Systems, Inc., 2008.

20. ThermaCAM RTools/HSDR high-spped data recorder. FLIR
Systems, Inc., 2005.

21. Fluke SmartView IR analysis and reporting software.
Everett, USA: Fluke Corporation, 2007.

22. Refinetti R. The circadian rhythm of body temperature.
Front Biosci (Landmark Ed) 2010; 15: 564-94.

23. Cermakian N, Boivin DB. The regulation of central and
peripheral circadian clocks in humans. Obes Rev 2009; 10 Suppl
2: 25-36. doi: 10.1111/j.1467-789X.2009.00660.x.

24. Burton AC. Temperature of skin; measurement and use as
index of peripheral blood flow. Methods Med Res 1948; 1: 146-
66.

25. Scully CG, Karaboué A, LiuWM, Joseph Meyer J,
Innominato PF, Chon KH, Gorbach AM, Lévi F. Skin surface
temperature rhythms as potential circadian biomarkers for
personalized chronotherapeutics in cancer patients. Interface
Focus 2011; 1: 48–60. doi:10.1098/rsfs.2010.0012.

26. Park ES, Park CI, Jung KI, Chun S. Comparison of
sympathetic skin response and digital infrared thermographic
imaging in peripheral neuropathy. Yonsei Med J 1994; 35(4):
429-37.

http://www.library.pitt.edu/
http://www.pitt.edu/
http://www.library.pitt.edu/articles/digpubtype/index.html
http://www.upress.pitt.edu/upressIndex.aspx
https://www.ncbi.nlm.nih.gov/pubmed/15313119
https://www.ncbi.nlm.nih.gov/pubmed/15313119
https://www.ncbi.nlm.nih.gov/pubmed/21539735
https://www.ncbi.nlm.nih.gov/pubmed/21539735
https://www.ncbi.nlm.nih.gov/pubmed/21539735
https://www.ncbi.nlm.nih.gov/pubmed/20920098
https://www.ncbi.nlm.nih.gov/pubmed/20920098
https://www.ncbi.nlm.nih.gov/pubmed/20920098
https://www.ncbi.nlm.nih.gov/pubmed/24858901
https://www.ncbi.nlm.nih.gov/pubmed/24858901
https://www.ncbi.nlm.nih.gov/pubmed/24858901
https://www.ncbi.nlm.nih.gov/pubmed/19215720
https://www.ncbi.nlm.nih.gov/pubmed/19215720
https://www.ncbi.nlm.nih.gov/pubmed/19215720
https://www.ncbi.nlm.nih.gov/pubmed/19215720
https://www.ncbi.nlm.nih.gov/pubmed/25520988
https://www.ncbi.nlm.nih.gov/pubmed/25520988
http://www.ncbi.nlm.nih.gov/pubmed/23878757
http://www.ncbi.nlm.nih.gov/pubmed/23878757
http://www.ncbi.nlm.nih.gov/pubmed/24353866
http://www.ncbi.nlm.nih.gov/pubmed/24353866
http://www.ncbi.nlm.nih.gov/pubmed/24353866
http://www.ncbi.nlm.nih.gov/pubmed?term=Roman%C3%B2%20CL%5BAuthor%5D&cauthor=true&cauthor_uid=23289768
http://www.ncbi.nlm.nih.gov/pubmed?term=D'Anchise%20R%5BAuthor%5D&cauthor=true&cauthor_uid=23289768
http://www.ncbi.nlm.nih.gov/pubmed?term=Calamita%20M%5BAuthor%5D&cauthor=true&cauthor_uid=23289768
http://www.ncbi.nlm.nih.gov/pubmed?term=Manzi%20G%5BAuthor%5D&cauthor=true&cauthor_uid=23289768
http://www.ncbi.nlm.nih.gov/pubmed?term=Roman%C3%B2%20D%5BAuthor%5D&cauthor=true&cauthor_uid=23289768
http://www.ncbi.nlm.nih.gov/pubmed?term=Roman%C3%B2%20D%5BAuthor%5D&cauthor=true&cauthor_uid=23289768
http://www.ncbi.nlm.nih.gov/pubmed?term=Sansone%20V%5BAuthor%5D&cauthor=true&cauthor_uid=23289768
http://www.ncbi.nlm.nih.gov/pubmed/?term=Romano+Calamita+Manzi##
http://www.ncbi.nlm.nih.gov/pubmed/?term=Romano+Calamita+Manzi##
http://www.ncbi.nlm.nih.gov/pubmed?term=Balbinot%20LF%5BAuthor%5D&cauthor=true&cauthor_uid=23295596
http://www.ncbi.nlm.nih.gov/pubmed?term=Canani%20LH%5BAuthor%5D&cauthor=true&cauthor_uid=23295596
http://www.ncbi.nlm.nih.gov/pubmed?term=Robinson%20CC%5BAuthor%5D&cauthor=true&cauthor_uid=23295596
http://www.ncbi.nlm.nih.gov/pubmed?term=Achaval%20M%5BAuthor%5D&cauthor=true&cauthor_uid=23295596
http://www.ncbi.nlm.nih.gov/pubmed?term=Zaro%20MA%5BAuthor%5D&cauthor=true&cauthor_uid=23295596
http://www.ncbi.nlm.nih.gov/pubmed/?term=Balbinot+Canali+Achaval##
http://www.ncbi.nlm.nih.gov/pubmed?term=Spalding%20SJ%5BAuthor%5D&cauthor=true&cauthor_uid=18215307
http://www.ncbi.nlm.nih.gov/pubmed?term=Kwoh%20CK%5BAuthor%5D&cauthor=true&cauthor_uid=18215307
http://www.ncbi.nlm.nih.gov/pubmed?term=Boudreau%20R%5BAuthor%5D&cauthor=true&cauthor_uid=18215307
http://www.ncbi.nlm.nih.gov/pubmed/?term=Three-dimensional+and+thermal+surface+imaging+produces+reliable##
http://dx.doi.org/10.18073/2358-4696/pajmt.v2n1p44-53
http://www.ncbi.nlm.nih.gov/pubmed/20036834
http://www.ncbi.nlm.nih.gov/pubmed/19849799
http://www.ncbi.nlm.nih.gov/pubmed/19849799
http://www.ncbi.nlm.nih.gov/pubmed/18888764
http://www.ncbi.nlm.nih.gov/pubmed/18888764





CENTRAL ASIAN JOURNAL OF GLOBAL HEALTH




This work is licensed under a Creative Commons Attribution 4.0 United States License.


This journal is published by theUniversity Library System of the University of Pittsburgh as part
of its D-Scribe Digital Publishing Program and is cosponsored by the University of Pittsburgh Press.


Central Asian Journal of Global Health

Volume 6, No. 1 (2017) |  ISSN 2166-7403 (online) | DOI 10.5195/cajgh.2017.289|http://cajgh.pitt.edu




27. Ring EF, Ammer K. Infrared thermal imaging in medicine.
Physiol Meas. 2012; 33(3): R33-46.

28. Chojnowski M. Infrared thermal imaging in connective
tissue diseases. Reumatologia. 2017;55(1):38-43. doi:
10.5114/reum.2017.66686Fitzgerald A, Berentson-Shaw J.
Thermography as a screening and diagnostic tool: a systematic
review. NZ Med J 2012; 125(1351): 80-91.

29. de Jesus Guirro RR, Oliveira Lima Leite Vaz MM, das Neves
LMS, et al. Accuracy and Reliability of Infrared Thermography in

Assessment of the Breasts of Women Affected by Cancer. J Med
Syst. 2017;41(5):87. doi: 10.1007/s10916-017-0730-7

30. Fitzgerald A, Berentson-Shaw J. Thermography as a
screening and diagnostic tool: a systematic review. NZ Med J
2012; 125(1351): 80-91





http://www.library.pitt.edu/
http://www.pitt.edu/
http://www.library.pitt.edu/articles/digpubtype/index.html
http://www.upress.pitt.edu/upressIndex.aspx
http://www.ncbi.nlm.nih.gov/pubmed?term=Ring%20EF%5BAuthor%5D&cauthor=true&cauthor_uid=22370242
http://www.ncbi.nlm.nih.gov/pubmed?term=Ammer%20K%5BAuthor%5D&cauthor=true&cauthor_uid=22370242
http://www.ncbi.nlm.nih.gov/pubmed/22370242##
https://www.ncbi.nlm.nih.gov/pubmed/28386141
https://www.ncbi.nlm.nih.gov/pubmed/28386141
http://www.ncbi.nlm.nih.gov/pubmed?term=Fitzgerald%20A%5BAuthor%5D&cauthor=true&cauthor_uid=22426613
http://www.ncbi.nlm.nih.gov/pubmed?term=Berentson-Shaw%20J%5BAuthor%5D&cauthor=true&cauthor_uid=22426613
http://www.ncbi.nlm.nih.gov/pubmed/22426613##
https://www.ncbi.nlm.nih.gov/pubmed/28405947
https://www.ncbi.nlm.nih.gov/pubmed/28405947
http://www.ncbi.nlm.nih.gov/pubmed?term=Fitzgerald%20A%5BAuthor%5D&cauthor=true&cauthor_uid=22426613
http://www.ncbi.nlm.nih.gov/pubmed?term=Berentson-Shaw%20J%5BAuthor%5D&cauthor=true&cauthor_uid=22426613
http://www.ncbi.nlm.nih.gov/pubmed/22426613##
http://www.ncbi.nlm.nih.gov/pubmed/22426613##

	Challenges to Global Implementation of Infrared Thermography Technology: Current Perspective
	Abstract
	Keywords: Infrared Thermography; Mass Screening; Epidemics
	Research
