CMI 03 (02), 297−303
MANUSCRIPT CENTRAL 297

Clinical Medicine Insights

DOI:    https://doi.org/10.52845/CMI/2022-3-2-2

CMI 03 (02), 297−303 (2022) ISSN (O) 2694-4626

RESEARCH ARTICLE

Maldi-Tof Analysis of Mitochondrial Peptides

Adam Good
1
, Alicia Wells

1
, Ben Katz

2
, Michael Alexander

1,3
, Dmytro Klokol

3,4
,

Mike K.S. Chan4
, Michelle B.F. Wong4

, Desiree C.T. Cox
3
, Jonathan R.T. Lakey

1,4

Corresponding Author: Jonathan RT Lakey

PhD, MSM, Professor Emeritus University of California Irvine

1
University of California,

Irvine- Department of

Surgery,

2
University of California,

Irvine- Department of

Chemistry,

3
BioPep, 4621 Technology

Drive, Golden, CO, 80403,

USA

4
European Wellness Group,

Klosterstrasse 205ID, 67480,

Edenkoben, Germany

5
University of California,

Irvine- Department of

Biomedical Engineering

Introduction

Peptides are linear polymers formed by a series of

amino acid residues that are linked together

through peptide bonds [1]. In comparison to

proteins, which typically contain between 50 and

2000 amino acid residues and have a mean

molecular weight between 5.5 and 22 kDa,

peptides have fewer than 50 residues and a

reduced weight. A unique set of proteins and

peptides are produced in each cell line and these

play a part in the regulation of biological

homeostasis [2]. Peptides have been demonstrated

to play an important role in modulating

transcription, transmission of biological

information, and in restoring the genetic

alterations that occur with age [3, 4]. These

peptides are signaling molecules that act as

regulatory factors through their interaction with

DNA and histone proteins. Moreover, the

physiological process of aging is highly

influenced by the peptidergic regulation of

homeostasis. As part of the aging process, the

frequency and strength of signals to the

mitochondria declines, causing signals to be sent

back to the nucleus that cause the arrest of cell

proliferation and initiation of apoptosis (Haas,

2019; Akbari, Kirkwood, and Bohr, 2019) [5-6].

Abstract

Short peptides are known to play an important role in modulating

transcription, in transmitting biological information and in restoring the

genetic alterations that occur with aging. This paper aims to describe a

method of identifying the population of peptides within a peptide cocktail

formulation. A sample of lung-derived Mito Organelle (MO) Peptides

(LBS) of specific pathogen free (SPF) mammalian rabbits sourced from

Charles River Labs were analyzed by mass spectrometry and

chromatograms were generated for further examination. The experimentally

derived peaks were compared between two batches of LBS MO peptides

using MALDI-ToF mass spectroscopy. The following report outlines the

experimental methods and the results from performing MALDI-ToF mass

spectrometry on various peptides from the company European Wellness

(EW).

Keywords: peptides, Mito Organelles (MO) Peptides, mass spectrometry,

MALDI-ToF

Copyright : © 2021 The Authors. Published by Medical Editor and

Educational Research Publishers Ltd. This is an open access article under

the CC BY-NC-ND license (https://creativecommons.org/lic enses/by-nc-

nd/4.0/).

https://creativecommons.org/lic%20enses/by-nc-nd/4.0/
https://creativecommons.org/lic%20enses/by-nc-nd/4.0/


CMI 03 (02), 297−303
MANUSCRIPT CENTRAL 298

Peptide therapy aims to renew the strength of

signals received by cells to either induce peptide

production or renew normal signaling processes,

thereby rejuvenating and revitalizing tissues as

well as the organism as a whole [3, 4, 7-9].

Although the content of peptides is similar

between cells, the function and morphology of

each cell defines the contents of its biologically

active substances and unique ultrastructures.

Moreover, certain biologically active substances

are predominantly synthesized or accumulated in

specific tissues. Since the signaling activity and

function of peptides is largely based on the cell

type, peptide therapy utilizes organ-specific

extracts to target diseased or aging tissue. Due to

the short lengths of peptides (<45 residues) and

their low molecular weights, their biosynthesis

and extraction processes permit mass production

and distribution for use in therapeutic treatments

[3]. Through years of research and extensive

global practice, MF-Plus has manufactured two

products, Nano Organo Peptides (NOPs) and Mito

Organelles (MO) Peptides, which are intended for

use in both animals and humans as a revitalization

therapy [10].

Mito Organo (MO) peptides are biologically

extracted mixtures of cellular peptides that have

predominantly mitochondria-specific functions

[11]. Although cells of different organ systems

have similar functions, variations in cellular

functions between organs creates the differential

expression of peptides, which can be utilized for

various therapeutic purposes. MO peptides are

organ-specific extracts that are aimed at

revitalizing and rejuvenating mitochondrial

activity, thereby regenerating cells and organisms

as a whole [12,13].

Despite the numerous studies highlighting the

therapeutic effectiveness of MO peptides, little is

known of the exact makeup of these formulations.

Matrix-assisted laser desorption/ionization time of

flight (MALDI-ToF) mass spectrometry has been

able to identify and quantify analytes in complex

solutions and allows for highly sensitive, fast and

high-throughput analysis [14,15]. In addition, it is

thought to be able to identify the population of

peptides derived from peptide cocktail

formulations. The mass spectrometer produces a

readout of peaks plotted in relative abundance

against mass-to-charge ratios. By searching the

experimentally-derived peaks against a database

of known proteins, it may be possible to identify

the peptides. The following report outlines the

experimental methods and the results of

performing MALDI-ToF mass spectrometry on

various EW peptides.

2. Materials and Methods

Two batches of LBS MO201901 EW peptides

were suspended in saline solution upon collection.

Formulations with the characterization LBS were

extracted from lung samples in specific pathogen

free (SPF) mammalian rabbits sourced from

Charles River Labs. All samples were kept on ice

throughout the duration of the experiment and

were handled using good laboratory practices.

Sample Preparation

The ThermoFisher Scientific BCA Protein Assay

protocol was utilized to determine the protein

concentrations of the unknown peptide solution.

Triplicate sample readings were obtained for the

peptide solution using the Tecan Infinite F200

microplate reader at a wavelength of 570 nm.

Sample Preparation of LBS MO Samples

Peptides from the LBS MO samples were

withdrawn at a volume of 30 µg/mL and pipetted

into auto column tubes in an agarose gel. Sample

mixtures were separated by molecular weight with

SDS-PAGE and Coomassie™ blue staining to

visualize the proteins. An individual protein band

was cut out from the gel and placed into a low-

binding, siliconized microcentrifuge tube. Proteins

were then de-stained in the tube with 100μl of a

1:1 methanol and water solution and vortexed.

The gel piece was further washed by removing the

de-stained solution in the tube and adding 400μl

of water. Tubes were shaken for 15 minutes at

room temperature, and the de-staining was

continued until the gel became colorless with a

minimum of 3 repeats. After destaining, 400μl of

100% acetonitrile was added to dehydrate the gel

for 10 minutes and dried by vacuum

centrifugation after removal of the supernatant.

Disulfide bonds were removed with the addition

of 100μl of 10mM dithiothreitol (DTT) to the gel

and then the gel was incubated for 45 minutes at

55°C. The solution was removed and 100μl of

55mM iodoacetamide was added to the gel and

then incubated for an additional 30 minutes at



CMI 03 (02), 297−303
MANUSCRIPT CENTRAL 299

room temperature under low light conditions,

allowing trypsin to access cleavage sites. The

solution was then added to 400μl of the gel and a

wash solution (50% per volume acetonitrile,

25mM ammonium bicarbonate) was added. The

gel was then incubated at room temperature and

vortexed three times for 15 minutes. The gel was

subsequently dehydrated with 400μl of 100%

acetonitrile for 10 minutes and dried in a vacuum

centrifuge after removal of the supernatant.

Enzyme Digestion

A pH 8 protease trypsin solution diluted 1:1000

with 25mM ammonium bicarbonate was prepared

and diluted to a final concentration of 10 - 20

μg/ml. Trypsin was added to the gel and it was

incubated on ice for 1 hour. The solution was

removed and replaced with 25mM ammonium

bicarbonate to cover the gel. The gel was then

incubated at 37°C overnight.

Peptide Extraction

The supernatant containing the peptides was

transferred to a new microcentrifuge tube. A gel

extraction solution of 50% per volume

acetonitrile, 1% trifluoroacetic acid (TFA) and

49% water was added, which was followed by

incubation at room temperature and a vortex cycle

of 20 minutes. This solution was combined with

the supernatant from the peptides in the new

microcentrifuge tube.

Analysis
10μl of a 1:1 solution of 0.1% TFA and 100%

acetonitrile was added to 10μl of each sample. 1μl

of DMP was added onto the MALDI plate. 1μl of

sample solution was then applied with 1:1 0.1%

TFA and 100% acetonitrile onto the same spot as

the DMP and the spot was allowed to dry. The

samples were run on MALDI in triplicate and the

peaks were compared against a database to

identify the key peptides and amino acids found in

the samples.

Data Analysis

Data was analyzed using the chromatogram tool in

MassLynx software. Replicates for each batch

were analyzed together and chromatograms for

each were generated. The masses of the three most

prominent peaks were deconvoluted and the key

peptides and amino acid components were

determined against open-source databases.

3. Results

The concentration of peptides in each batch was

initially determined via the ThermoFischer™

Scientific BCA Protein Assay (Figure 1). The

average protein concentration of 252.0 μg/mL

( 12.83μg/mL) and 260.6μg/mL ( 32.23μg/mL)

was determined for Batch 1 and Batch 2

respectively. There were no statistically

significant differences between batches (p = ns).

Figure 1. Average protein concentration (ug/mL) of Batch 1 and 2 LBS MO201901 peptides.

Standard error bars are included. No statistically significant differences were found between batches (p=ns).

MANUSCRIPT CENTRAL
Jonathan RT Lakey et al.



CMI 03 (02), 297−303
MANUSCRIPT CENTRAL 300

The samples were then separated by molecular

weight with SDS-PAGE and digested with the

protease trypsin. Once prepared, the samples were

run on MALDI-Tof in triplicate and

chromatograms were generated (Figure 2). The

deconvoluted masses of Batch 1 (Figure 3) and

Batch 2 (Figure 4) of LBS MO show similarity in

major protein components. The deconvoluted

masses in Batch 1 represent five major

components with sizes of 14,969 Da, 15,300 Da,

8,449 Da, 8,294 Da and 4,618 Da respectively.

Batch 2 results showed six major protein masses

of 14,969 Da, 15,301 Da, 8,294 Da, 8,449 Da,

5,436 Da, and 6,214 Da respectively.

Figure 2. Chromatograms obtained from Batch 1 (A) and Batch 2 (B) of LBS MO201901.

Red arrows pointing upwards on the x-axis of

each chromatogram identify peaks that correspond

to differing peptide components in the solution.

The green, blue, and red chromatograms

associated with both Batch 1 and Batch 2 illustrate

different runs of the sample.

Figure 3. Deconvoluted mass spectrometry data obtained from LBS MO Batch 1.

Five peptide fragments are ordered from left to

right in decreasing order of abundance within the

sample. The relative sizes of peptides from left to

right are 14,969 Da, 15,300 Da, 8,449 Da, 8,294

Da and 4,618 Da respectively.



CMI 03 (02), 297−303
MANUSCRIPT CENTRAL 301



Figure 4. Deconvoluted mass spectrometry data obtained from LBS MO Batch 2.

Six peaks representing six major peptide

fragments are ordered from left to right in

decreasing order of abundance within the sample.

The relative sizes of peptides from left to right are

14,969 Da, 15,301 Da, 8,294 Da, 8,449 Da, 5,436

Da, and 6,214 Da respectively.

4. Discussion

Short peptides are known to play a critical role in

modulating the transmission and transcription of

biological information and have been shown to

decline throughout the natural process of aging

[2]. Peptide therapy aims to either reinstate normal

signaling patterns by renewing the strength of the

signals received by cells or induce the cells to

begin to produce peptides of their own [16]. Since

different tissue types produce different peptides,

peptide therapy utilizes organ-specific extracts to

target aging or diseased tissue with the goal of

revitalizing normal peptidergic signaling in these

regions and improving overall health and

wellbeing [17].

Through years of testing and development,

European Wellness (EW) and MF-Plus have

manufactured Mito Organelles (MO) peptides that

are intended for use in peptide therapy in both

animals and humans [18]. Despite numerous

studies demonstrating the potential of MOs in

therapeutic applications such as cosmetics [19]

and regenerative organ repair [11], little research

has been done to investigate and identify the key

peptides in these solutions. Mass spectrometry

(MS) is a chemical analysis technique that enables

the direct identification of molecules based on

their mass-to-charge ratios and fragmentation

patterns [20]. By comparing experimental MS

data with that of well-established open-source

databases, the identity of the molecules, peptides,

or proteins can be found within a solution. Due to

the low-cost and rapid application of MS in

identifying the components of unknown solutions,

our study employed MS as our primary method of

identification.

MALDI-TOF utilizes a protein fingerprinting

method in which the sample is digested by a

proteolytic enzyme such as trypsin and used to

generate an MS spectrum that can be searched

against existing databases [21, 22]. Matched hits

are ranked according to a scoring method in which

the candidate protein that contains more

proteolytic peptides has a higher score and

generally represents the most probable

protein/peptide. The desirability of MALDI-TOF

also includes the speed at which each run is

performed– often less than one minute to obtain–

and the speed at which analysis can be performed

against a database.

Conclusion:

The results of our study using MALDI-TOF to

analyze the MO LBS sample indicated that there

were five major peptide products of interest in

Batch 1 and six major peptide products in Batch 2

(Figure 3 and 4). Following deconvolution, five

MANUSCRIPT CENTRAL
Jonathan RT Lakey et al.



CMI 03 (02), 297−303
MANUSCRIPT CENTRAL 302

peptides were identified in Batch 1 (Figure 3) with

masses of 14,969 Da, 15,300 Da, 8,449 Da, 8,294

Da and 4,618 Da. Batch 2 identified four of the

same peptides– 14,969 Da, 15,301 Da, 8,294 Da,

8,449 Da in size– and two additional peptides of

5,436 Da, and 6,214 Da in size (Figure 4). Slight

differences in peptide products between batches is

likely due to the heterogeneous nature of

cellularly-derived solutions and differences that

occurred during the extraction process. Further

research must be conducted to confirm the identity

of the peptides and discover their significance in

peptide therapy.

Supplementary Materials: The following

supporting information can be downloaded at:

www.mdpi.com/xxx/s1, Figure S1: title; Table S1:

title; Video S1: title.

Author Contributions: Conceptualization, J.L.,

M.W., M.C., D.K., D.C.; methodology, B.K.,

M.A.; validation, B.K.; formal analysis, B.K.;

investigation, A.W., A.G., B.K.; data curation,

A.W., A.G., B.K.; writing—original draft

preparation, A.W., A.G.; writing—review and

editing, A.W., A.G., J.L.; visualization, J.L.,

M.W., M.C., D.K.; supervision, J.L., M.W., M.C.,

D.K., D.C., B.K., A.M.; project administration,

J.L., M.W., M.C., D.K., D.C., B.K.; funding

acquisition, J.L., M.W., M.C., D.K., D.C.. All

authors have read and agreed to the published

version of the manuscript.

Funding: This research was funded by a grant to

the University of California, Irvine from European

Wellness Biomedical Group.

Institutional Review Board Statement: Not

applicable

Data Availability Statement: The data presented in

this study are available in the study outlined.

Acknowledgments: The authors wish to

acknowledge the support of the Department of

Surgery and the Core Mass Spectrometry

laboratory of the University of California, Irvine

for their support.

Conflicts of Interest: The funders had no role in

the design of the study; in the collection, analyses,

or interpretation of data; in the writing of the

manuscript, or in the decision to publish the

results.

References

1. Berg, J. M.; Tymoczko, J. L.; Stryer, L.,

Primary Structure: Amino Acids Are Linked

by Peptide Bonds to Form Polypeptide

Chains. In Biochemistry. 2002; 5.

2. Caputi, S.; Trubiani, O.; Sinjari, B.;

Trofimova, S.; Diomede, F.; Linkova, N.;

Diatlova, A.; Khavinson, V., Int J

Immunopathol Pharmacol. 2019;33:2058738

419828613.

3. Khavinson, V. K., Lin'kova, N. S., &

Tarnovskaya, S. I. Short Peptides Regulate

Gene Expression. Bulletin of experimental

biology and medicine. 2015; 162(2):288–292.

4. Apostolopoulos, V., Bojarska, J., Chai, T. T.,

Elnagdy, S., Kaczmarek, K., Matsoukas, J.,

New, R., Parang, K., Lopez, O. P., Parhiz, H.,

Perera, C. O., Pickholz, M., Remko, M.,

Saviano, M., Skwarczynski, M., Tang, Y.,

Wolf, W. M., Yoshiya, T., Zabrocki, J.,

Zielenkiewicz, P., … Toth, I. A Global

Review on Short Peptides: Frontiers and

Perspectives. Molecules (Basel, Switzerland).

2015; 26(2):430.

5. Haas R. H. Mitochondrial Dysfunction in

Aging and Diseases of Aging. Biology. 2019;

8(2):48.

6. Akbari, M., Kirkwood, T., & Bohr, V. A.

Mitochondria in the signaling pathways that

control longevity and health span. Ageing

research reviews. 2019;54:100940.

7. Klokol, D., Nallenthiran, L., Chan, M.K.S.,

et al. Cell therapy as the main stratagem of

anti-aging and regenerative medicine. Europ J

Pharm Med Res. 2019; 6(6):295–299.

8. Lee, A. C., Harris, J. L., Khanna, K. K.,

Hong, J. H. A comprehensive review on

current advances in peptide drug development

and design. International journal of molecular

sciences. 2019; 20(10):2383.

9. De La Torre, B. G., Albericio, F. Peptide

therapeutics 2.0. Molecules (Basel,

Switzerland). 2020;25(10):2293.

10. Klokol, D.; Chan, M.; Wong, M.; Tullina, D.;

Chernykh, V.; Wah, Y. K.; Rivera-Dugenio,

J., Journal of Stem Cell Research and

Medicine. 2017; 2(2):1-5.

11. Lee, C., Zeng, J., Drew, B. G., Sallam, T.,

Martin-Montalvo, A., Wan, J., Kim, S. J.,

Mehta, H., Hevener, A. L., de Cabo, R., &

Cohen, P. The mitochondrial-derived peptide

MOTS-c promotes metabolic homeostasis and



CMI 03 (02), 297−303
MANUSCRIPT CENTRAL 303

How to cite this article: Good, A. ., Wells, A. .,

Katz, B. ., Alexander, M. ., Klokol, D. ., Chen, M.

K. ., Wong, M. B. ., Cox, D. C. ., & Lakey, J. R. .

(2022). MALDI-ToF Analysis of Mitochondrial

Peptides. Clinical Medicine Insights, 3(2), 297–303.

https://doi.org/10.52845/C MI/2022-3-2-3

reduces obesity and insulin resistance. Cell

metabolism. 2016;21(3):443–454.

12. Wu, D., Kampmann, E., Qian, G. Novel

insights into the role of mitochondria-derived

peptides in myocardial infarction. Frontiers in

Physiology. 2021;12.

13. Krejcova, G., Patocka, J., and Slaninova, J.

Effect of humanin analogues on

experimentally induced impairment of spatial

memory in rats. J. Pept. Sci. 2004;10: 636–63

9.

14. Hopfgartner G.r., Bourgogne E. Quantitative

high-throughput analysis of drugs in

biological matrices by mass spectrometry.

Mass Spectrometry Reviews. 2003;

22(3):195–214.

15. Szaéjli, Emiélia et al. Investigating the

Quantitative Nature of MALDI-TOF MS

Molecular & Cellular Proteomics. 2008;

7(12):2410 - 2418

16. Bruno, B. J., Miller, G. D., & Lim, C. S.

Basics and recent advances in peptide and

protein drug delivery. Therapeutic delivery.

2013; 4(11):1443–1467.

17. Järvinen, T. A., May, U., & Prince, S.

Systemically Administered, Target Organ-

Specific Therapies for Regenerative

Medicine. International journal of molecular

sciences. 2015; 16(10):23556–23571.

18. Chan, M. K. S., Wong, M. B. F., Béguin, A.,

Teppone, M., Tukhvatullina, D., Klokol, D. In

Efficacy of the MFIII placenta extracts

softgels supplementation: a randomized

double-blind placebo-controlled study, 2016.

19. Chan, M. K., Michelle, W. B., Klokol, D.,

Pong, H., Wolodymyr, C., International

Journal of Current Medical and

Pharmaceutical Research. 2017;3(1): 1278-

1281.

20. Padoan A, Basso D, Zambon CF, et al.

MALDI-TOF peptidomic analysis of serum

and post-prostatic massage urine specimens to

identify prostate cancer biomarkers. Clin

Proteomics. 2018;15:23.

21. Singhal, N., Kumar, M., Kanaujia, P. K.,

Virdi, J. S. MALDI-TOF mass spectrometry:

an emerging technology for microbial

identification and diagnosis. Frontiers in

microbiology. 2015; 6: 791.

22. Urban P. L. Quantitative mass spectrometry:

an overview. Philosophical transactions.

Series A, Mathematical, physical, and

engineering sciences, 2016; 374(2079): 20150

382.













MANUSCRIPT CENTRAL
Jonathan RT Lakey et al.
