DEVELOPMENT OF A MATHEMATICAL MODEL FOR ANGLE OF SOIL

FAILURE PLANE IN CASE OF 3-DIMENSSIONAL CUTTING



Moayad B. Zaied1 --- Mohammed H. Dahab2 --- Ahmed M. El Naim3
1Department of Agric. Eng., Faculty of Natural Resources, University of Kordofan, Elobied, Sudan

2Department of Agric. Eng., Faculty of Agriculture, University of Khartoum, Sudan

3Department of crop Sciences, Faculty of Natural Resources, University of Kordofan, Elobied, Sudan



ABSTRACT

The interaction between tillage tools and soil is of a primary interest to the design and use of these tools for

soil manipulation. A new explicit mathematical model to calculate the angle of soil failure plane when soil is

cut with narrow tine was developed. Equations of Soil cohesion and soil adhesion cutting factors were

partially differentiated with respect to angle of soil external friction, were maximized; Values of angle of

soil failure plane were calculated by the model for tine rake angle range from 00 to 900 operated at 0.3 m

depth and 0.15 m width in soils with different mechanical properties. It was found that angle of soil failure

plane is acute and its values were used for calculating soil frictional cutting factor, soil overburden cutting

factor, soil cohesion cutting factor, soil adhesion cutting factor, rupture distance, width of side crescent and

soil resistance force. It was found that the force values were realistic. Therefore, the model is valid.

Keywords: Mathematical modeling, Soil failure plane, 3-D soil cutting.



Contribution/ Originality

The study originates new explicit formula for angle of soil failure plane (β) with respect to

tool rake angle (α), external frictional angle at a soil–tool interface (δ), soil internal angle of

friction (ϕ), tool operating depth (d) and tool operating width (w) in case of 3-D soil cutting



1. INTRODUCTION

The dynamic response of soil to farm implements is a main factor in determining their

performance. The interaction between tillage tools and soil is of a primary interest to the design

and use of these tools for soil manipulation. The definition of notations is as a follow:



C Soil cohesion, kPa
Ca Adhesion force at a soil–metal interface, kPa
d Tool working depth, m
Fs Soil resistance force, kN



Current Research in Agricultural Sciences
2014 Vol. 1, No. 2, pp. 42-52
ISSN(e): 2312-6418
ISSN(p): 2313-3716
© 2014 Conscientia Beam. All Rights Reserved.









Current Research in Agricultural Sciences, 2014, 1(2): 42-52




43

© 2014 Conscientia Beam. All Rights Reserved.

g Acceleration due togravity, m / s2
Kp Soil pressure cutting factor, dimensionless
Kc Soil cohesion cutting factor, dimensionless
Kca Soil adhesion cutting factor, dimensionless

Nγ Soil frictional cutting coefficient, dimensionless

Nq Soil overburden cutting coefficient, dimensionless
Nc Soil cohesion cutting coefficient, dimensionless
Nca Soil adhesion cutting coefficient, dimensionless
r Rupture distance, m
w Tool working width, m
Ws Width of side crescent, m

α  Tool rake angle, deg.

β Angle of soil failure plane, deg.

δ External frictional angle at a soil–tool interface, deg.

ϕ  Internal frictional angle, deg.

ρd Soil bulk density, g / cm3

σn Normal stress, kPa

τ Shear strength, kPa



The force acting on a failure surface in the soil body can be determined by Mohr–Coulomb

equation as follows

)1...(....................................................................................................tan nC 


 The forces acting at a metal-soil interface are determined by the following equation

)2.........(..........................................................................................tan naC 

 Limit equilibrium is one of the most important approaches used to analyze soil–tool systems.

Two most important factors in the approach are the shape of soil failure surface, and equilibrium

equations, which are two or three dimensional cases. Grisso and Perumpral [1] reviewed four

narrow tillage tool models, discussed assumptions, capabilities and limitations associated with

each model, predicted tillage tool performance under two different soil conditions using the four

models and compared simulated results with the experimental results.

Many models for prediction of soil pressure coefficients, cutting factors, soil forces and draft

were developed. Terzaghi [2] and Hettiaratchi and Reece [3] established a two-dimensional

model and evaluated soil loads and soil resistance to tillage tools. They reported that the soil in

front of tool and above the failure surface is assumed to consist of Rankine passive zone and a

complex shear zone bounded by part of logarithmic spiral as shown in Fig. 1.

Payne [4] developed a three-dimensional soil failure model depending on the upward

movement of soil in front of the tool during tillage. In this model a failure zone includes a

triangular center wedge, a center crescent and two side blocks called wings of the crescent (Fig.

2). It is proposed that failure wedge ahead of a cutting blade and the failure wedge consists of

center wedge, two side crescents and straight rupture plane at the bottom [5], [6] as shown in

Fig. 3. Zeng and Yao [7] developed a dynamic soil cutting model included the acceleration and



Current Research in Agricultural Sciences, 2014, 1(2): 42-52




44

© 2014 Conscientia Beam. All Rights Reserved.

strain-rate effects. Kuczewsk and Piotrowska [8] introduced a new model for forces on narrow

soil cutting tines taking into account variability of the inclination angle of bottom failure surface

in the side segment and inertial forces for different side segments. Draft force and power

requirement for tillage implements were considerably affected by implement design and

conditions of soil. In terms of effects on draft force and soil disturbance, Kheiralla, et al. [9]

formulated a draft force model for ploughs based on traveling speed and tillage depth. Abo-Elnor,

et al. [10]concluded that the blade cutting width had a significant effect on cutting forces so that

the cutting forces increased but not in linear proportion as the cutting width increased. McKyes

and Maswaure [11] demonstrated that designing a tillage tool for minimum draft requirement

and high soil cutting efficiency called for a shallow operating depth and rake angle of 300. Chung

and Sudduth [12] developed a model for soil failure caused by a vertically operating conical tool

and concluded that the angle of soil failure plane and angle of internal soil friction are negatively

correlated. Kasisira and DuPlessis [13] developed mathematical force models employing limit

equilibrium analysis based on the soil-volume tilled to predict the draft requirements of tillage

tool and reported that such models require a preliminary assumption of the soil failure pattern

ahead of the tool.

Two-dimensional soil cutting model can be valid if the tool working width is larger than its

depth. McKyes [14] mentioned two-dimensional models to calculate soil cutting factors and

angle of soil failure plane as follow:

)3........(..................................................
)sin(2

)sin()cot(cot








PK



)4.........(..................................................
)sin(sin

cos






CK



)5.........(..................................................
)sin(sin

)cos(








CaK



)6.......(....................
)sin(

)cos(
sinsin

)sin()sin(

cot 1


























 












Three-dimensional soil cutting model can be applied if the tool working width is smaller than

its depth. Zhang and Kushwaha [15] mentioned three-dimensional models to predict soil pressure

factors and cutting resistance force as follow



Current Research in Agricultural Sciences, 2014, 1(2): 42-52




45

© 2014 Conscientia Beam. All Rights Reserved.

)7....(....................
)sin(

)sin()cotcot2cot
3

2
1)(cot(cot5.0 2









 w

d

N



)8..(..............................
)sin(

)sin()cotcot2cot1)(cot(cot 2








 w

d

Nq

)9......(..................................................
)sin(

).......cotcot2cot1(cos 2








 w

d

NC

)10.........(......................................................................
)sin(sin

)cos(








CaN

)11.......(................................................................................).........cot(cot   dr

)12.........(......................................................................cotcot2cot2   dWS

)13.......(............................................................)( 2 wdNCCdNNgdF CaaCdS  



2. MODEL DEVELOPMENT METHOD

2.1. Problem

In case of two-dimensional soil cutting, the angle of soil failure plane β is given explicitly as a

function of α, δ and ϕ (equation 6). In three- dimensional soil cutting case, in equations [8-11] all

parameters except angle of soil failure plane (β) are known. The soil failure plane angle can be

identified by solving any of the following equations:

)11......(............................................................0






N


)12.......(............................................................0






qN


)13.......(............................................................0





cN



)14.......(............................................................0





caN



Current Research in Agricultural Sciences, 2014, 1(2): 42-52




46

© 2014 Conscientia Beam. All Rights Reserved.

Since differentiations of these equations are rather complex and result formidable terms, thus,

there is no explicit function for β with respect to α, δ, ϕ, d and w, therefore a numerical procedure

was used to determine the failure plane angle (β). To this regard, the present work aims to look

for a simple explicit model to calculate β whenever α, δ, ϕ, working depth (d) and working width

(w) are known.



2.2. Solution for Model Development

The developed model will be in the form of ),,,,( wdf   . To get that, some

selections should be considered. Equation (7) contains constant values, so, it is excluded while

Equation (8) and Equation (9) have no constant values in their terms, therefore any of them with

Equation (10) can be chosen to conduct the partial derivative. Now Equation (9) is selected:

)sin(

)cotcot2cot1(cos 2








 w

d

NC



The Partial derivative of Nc with respect to δ and maximization will be as follow

)15......(....................0
)(sin

)cos()cotcot2cot1(cos

2

2
















w

d
NC

)16.........(......................................................................0cotcot2cot1 2  
w

d

)17....(......................................................................01cotcot2cot
2

2
2

2

2

 
w

d

w

d



The resulting function is in the form of a quadratic where cot β is in the positive root of equation:

)18....(................................................................................
2

4
cot

2

a

acbb 


Where,

2

2

w

d
a 

cot2
2

2

w

d
b 

1c



Current Research in Agricultural Sciences, 2014, 1(2): 42-52




47

© 2014 Conscientia Beam. All Rights Reserved.

Solving with respect to β will result the following relationship:



)19.(......................................................................cot1cotcot

2

 









w

d

d

w



From equation (10):

)sin(sin

)cos(








CaN



Partial derivative of Nca with respect to δ and maximization will be as follow:

)20.(..................................................0
)(sinsin

)cos(sin)cos(
22
















CaN

Let,

0)cos(  


Then,

)21.(............................................................0)sin(sin)cos(cos  



Dividing by )cos(sin  

)22...(................................................................................0)tan(cot  



Solving with respect to β will result the following relationship:

)23.(................................................................................).........tan(cot  

If   )(  or   090)( , where


 is very small number   then,

)()tan(  

Then β as function of  ,   and   was given as follow:

)24......(................................................................................).........(cot  



Current Research in Agricultural Sciences, 2014, 1(2): 42-52




48

© 2014 Conscientia Beam. All Rights Reserved.

Adding equation (18) to equation (24):

  )25.(........................................cot1cot)(cot2

2

 









w

d

d

w



Then,

)26......(........................................
2

cot1cot

cot

2

















































w

d

d

w

Accordingly,

)27........(........................................
2

cot1cot

cot

2

1































 




w

d

d

w

Therefore, equation (27) is the developed model for calculating the angle of soil failure plane in

case of three-dimensional soil cutting.



2.3. Model Validation Test

Values of angle of soil failure plane (β) are calculated using the developed model for different

tine rake angles and varied soil mechanical properties for narrow tine operated at 0.3 m depth and

0.15 m width. The validity of the model depends on realistic of the results, that, (β) should be

acute angle and real positive number. The resultant values of β were used to calculate soil

frictional coefficient (N), soil overburden coefficient (Nq), soil cohesion coefficient (NC), soil

adhesion coefficient (NCa) as well as rupture distance, width of side crescent and soil resistance

force.



3. RESULTS AND DISCUSSION

Table 1, Table 2 and Table 3 demonstrated the values of angle of soil failure plane, resultant

soil coefficients, rupture distance, width of side crescent and soil resistance force at different soil

mechanical properties and rake angles.

  It was found that angle of soil failure plane (β) is acute and its values are real positive

number. Moreover, it was shown that as the angle of internal soil friction (ϕ) increased, the value

of β decreased and vice versa which agreed with Chung and Sudduth [12].

When values of β were used for calculating rupture distance, width of side crescent, soil

frictional coefficient (Nγ), soil overburden coefficient (Nq), soil cohesion coefficient (NC) and soil



Current Research in Agricultural Sciences, 2014, 1(2): 42-52




49

© 2014 Conscientia Beam. All Rights Reserved.

adhesion coefficient (NCa), the resultant values of these variables were found to be defined and

determined. The values of coefficients were applied to calculate soil resistance force, it was found

that the force values were realistic.



4. CONCLUSIONS

In case of three dimensional soil cutting, there is no explicit function for angle of soil failure

plane (β) with respect to rake angle (α), external frictional angle at a soil–tool interface (δ), angle

of soil internal friction (ϕ), tool operating depth (d) and tool operating width (w), therefore, a

numerical procedures were used to determine the value of angle of soil failure plane.

A new explicit mathematical model to calculate angle of soil failure in case of three-

dimensional cutting was developed. The model was developed by partially differentiating of soil

cohesion and soil adhesion cutting coefficients with respect external frictional angle at a soil–tool

interface and the two resultant equations were maximized and were solved simultaneously for

angle of soil failure plane with respect to rake angle, external frictional angle at a soil–tool

interface, angle of soil internal friction, tool depth and tool width,.

The resultant values of the angle of soil failure plane, correspondent soil cutting coefficients,

rupture distances, width of side crescent and soil resistance forces obtained by the developed

model at different tool rake angles were found to be realistic. Therefore, the model is valid.



REFERENCES

[1] R. D. Grisso and J. V. Perumpral, "Review of models for predicting performance of narrow tillage

tool," Transactions of the ASAE, vol. 28, pp. 1062-1067, 1985.

[2] K. Terzaghi, Theoretical soil mechanics. New York: Wiley, 1959.

[3] D. R. P. Hettiaratchi and A. R. Reece, "Symmetrical three-dimensional soil failure," J. Terramech,

vol. 4, pp. 45–67, 1967.

[4] P. C. J. Payne, "The relationship between mechanical properties of soil and the performance of

simple cultivation implements," J. Agric. Eng. Res., vol. 1, pp. 23–50, 1956.

[5] E. McKyes and O. S. Ali, "The cutting of soil by narrow blades," J. Terramech, vol. 14, pp. 43–58,

1977.

[6] W. C. Swick and J. V. Perumpral, "A model for predicting soil–tool interaction," J. Terramech, vol.

25, pp. 43–56, 1988.

[7] D. Zeng and Y. Yao, "A dynamic model for soil cutting by blade and tine," J. Terramech, vol. 29,

pp. 317–327, 1992.

[8] J. Kuczewsk and E. Piotrowska, "An improved model for forces on narrow soil cutting tines," Soil

Till. Res., vol. 46, pp. 231–239, 1998.

[9] F. A. Kheiralla, A. Yahia, M. Zohadie, and W. Ishak, "Modelling of power and energy

requirements for tillage implements operating on serdang sandy clay loam, Malaysia," Soil Till.

Res., vol. 78, pp. 21–34, 2004.

[10] M. Abo-Elnor, R. Hamilton, and J. T. Boyle, "Simulation of soil–blade interaction for sandy soil

using advanced 3-D finite element analysis," Soil Till. Res., vol. 75, pp. 61–73, 2004.



Current Research in Agricultural Sciences, 2014, 1(2): 42-52




50

© 2014 Conscientia Beam. All Rights Reserved.

[11] E. McKyes and J. Maswaure, "Effect of design parameters of flat tillage tools on loosening of clay

soil," Soil Till. Res., vol. 43, pp. 195–204, 1997.

[12] S. O. Chung and K. A. Sudduth, "Soil failure models for vertically operating and horizontally

operating strength sensor," Transactions of the ASABE, vol. 49, p. 851−863, 2006.

[13] L. L. Kasisira and H. L. M. DuPlessis, "Width Prediction of a side circular crescent failed by a

tillage tool in a sandy clay loam soil," Agricultural Engineering International: The CIGR E Journal.

Manuscript PM 1334, vol. 11, pp. 1-8, 2009.

[14] E. McKyes, Soil cutting and tillage. Developments in agricultural engineering 10. Agricultural engineering

soil mechanics. Amsterdam: Elsevier Science Publishing Company Inc., 1989.

[15] J. Zhang and R. L. Kushwaha, "A modified model to predict soil cutting resistance," Soil Till. Res.,

vol. 34, pp. 157–168, 1995.



Fig-1. Logarithmic spiral failure zone, [3].


Source: [3].



Fig-2. Failure zone of the Payne model [4].



Source: [4].



Current Research in Agricultural Sciences, 2014, 1(2): 42-52




51

© 2014 Conscientia Beam. All Rights Reserved.

Fig-3.Double-wedge failure zone of the McKyes-Ali model (a-rake angle; b-angle of soil failure

plane; r-rupture distance).[5].



Source: [5].



Table-1. First Soil Sample Mechanical Properties, ϕ = 200, δ = 100, ρd = 1.77 g / cm3, C = 3 kPa,

Ca = 1.62 kPa

α0 β0 Nγ Nq Nc Nca r (m) Ws (m) Fs (kN)

5 72.8 29.55 23.73 6.28 1.62 3.52 1.29 7.89

10 70.2 12.88 11.11 5.11 1.09 1.81 0.94 3.79

15 67.8 8.27 7.60 4.68 0.92 1.24 0.78 2.64

20 65.4 6.20 5.99 4.48 0.86 0.96 0.69 2.12

25 63.1 5.05 5.06 4.39 0.83 0.80 0.62 1.84

30 60.8 4.34 4.45 4.37 0.83 0.69 0.57 1.67

35 58.7 3.87 4.01 4.41 0.84 0.61 0.53 1.56

40 56.6 3.55 3.66 4.49 0.86 0.56 0.50 1.50

45 54.5 3.33 3.37 4.60 0.90 0.51 0.47 1.47

50 52.6 3.18 3.11 4.76 0.95 0.48 0.44 1.46

55 50.6 3.09 2.87 4.97 1.01 0.46 0.41 1.47

60 48.7 3.05 2.63 5.23 1.09 0.44 0.38 1.50

65 46.9 3.04 2.37 5.55 1.19 0.42 0.35 1.55

70 45.0 3.08 2.09 5.94 1.31 0.41 0.31 1.62

75 43.2 3.15 1.75 6.43 1.46 0.40 0.28 1.71

80 41.4 3.26 1.32 7.05 1.65 0.39 0.23 1.84

85 39.5 3.42 0.77 7.84 1.89 0.39 0.16 2.00

90 37.7 3.62 0.01 8.86 2.21 0.39 0.02 2.21











Current Research in Agricultural Sciences, 2014, 1(2): 42-52




52

© 2014 Conscientia Beam. All Rights Reserved.

Table-2. Second Soil Sample Mechanical Properties, ϕ = 300, δ = 200, ρd = 1.51 g / cm3, C = 2.5

kPa, Ca = 1.4 kPa

α0 β0 Nγ Nq Nc Nca r (m) Ws (m) Fs (kN)

5 64.2 38.37 48.97 7.66 2.08 3.58 1.42 8.67

10 61.9 16.60 21.55 6.16 1.39 1.86 1.03 4.10

15 59.8 10.73 14.14 5.62 1.19 1.30 0.85 2.85

20 57.7 8.16 10.85 5.40 1.12 1.01 0.75 2.31

25 55.7 6.78 9.02 5.35 1.10 0.85 0.68 2.03

30 53.9 5.96 7.88 5.40 1.11 0.74 0.62 1.87

35 51.9 5.46 7.10 5.55 1.15 0.66 0.57 1.79

40 50.2 5.17 6.55 5.78 1.22 0.61 0.54 1.76

45 48.4 5.03 6.13 6.10 1.30 0.57 0.50 1.77

50 46.8 5.00 5.80 6.53 1.42 0.53 0.47 1.82

55 45.1 5.09 5.53 7.10 1.58 0.51 0.43 1.92

60 43.6 5.30 5.29 7.85 1.78 0.49 0.40 2.06

65 42.0 5.66 5.06 8.87 2.06 0.47 0.37 2.26

70 40.5 6.21 4.79 10.28 2.44 0.46 0.33 2.55

75 38.9 7.05 4.43 12.34 3.00 0.45 0.29 2.99

80 37.4 8.41 3.84 15.55 3.88 0.45 0.24 3.68

85 35.8 10.78 2.73 21.19 5.43 0.44 0.17 4.88

90 34.2 15.87 0.04 33.46 8.82 0.44 0.02 7.49



Table-3. Third Soil Sample Mechanical Properties, ϕ = 320, δ = 230, ρd = 1.42 g / cm3, C = 2.4

kPa, Ca = 1.14 kPa

α0 β0 Nγ Nq Nc Nca r (m) Ws (m) Fs (kN)

5 62.2 41.05 57.21 8.05 2.15 3.59 1.46 8.70

10 60.0 17.78 24.99 6.47 1.46 1.88 1.05 4.12

15 57.9 11.54 16.34 5.92 1.26 1.31 0.87 2.87

20 55.9 8.82 12.51 5.71 1.19 1.03 0.76 2.34

25 54.0 7.38 10.41 5.68 1.18 0.86 0.69 2.06

30 52.2 6.54 9.11 5.77 1.20 0.75 0.63 1.92

35 50.4 6.05 8.25 5.97 1.26 0.68 0.58 1.85

40 48.7 5.79 7.65 6.28 1.34 0.62 0.54 1.84

45 47.1 5.70 7.23 6.70 1.45 0.58 0.51 1.87

50 45.5 5.76 6.93 7.28 1.61 0.55 0.47 1.95

55 43.9 5.97 6.71 8.05 1.81 0.52 0.44 2.09

60 42.4 6.37 6.55 9.11 2.09 0.50 0.41 2.29

65 40.9 7.00 6.44 10.60 2.49 0.49 0.37 2.59

70 39.4 8.02 6.36 12.82 3.08 0.47 0.34 3.05

75 37.9 9.70 6.25 16.36 4.03 0.47 0.29 3.80

80 36.5 12.81 6.01 22.86 5.77 0.46 0.24 5.17

85 35.0 20.19 5.25 38.32 9.92 0.46 0.18 8.44

90 33.5 58.81 0.15 119.86 31.87 0.45 0.02 25.64





Views and opinions expressed in this article are the views and opinions of the author(s), Current Research in Agricultural Sciences

shall not be responsible or answerable for any loss, damage or liability etc. caused in relation to/arising out of the use of the content.
