The influence of projectile impact velocity and target characteristics on
the terminal ballistics parameters of small-caliber projectile

Faris Memić1*, Alan Ćatović2

1 Defense Technologies Department, Mechanical Engineering Faculty, University of Sarajevo, Bosnia and Herzegovina
2 Defense Technologies Department, Mechanical Engineering Faculty, University of Sarajevo, Bosnia and Herzegovina



*Corresponding author E-mail:  farismemic04@gmail.com

Received: Jun. 5, 2024
Revised: Jul. 18, 2024
Accepted: Jul. 20, 2024
Online: Jul. 25, 2024

Abstract
The study examines the results of numerical simulations of the penetration of a

7,62 mm x 63, AP, M2 projectile through a target. Model validation involved a

numerical simulation of 7,62mm x 63, AP, M2 projectile penetration through an

AA5083H116 target, for which experimental results were available in the

literature. The results of the numerical simulation were used for regression

analysis - to calibrate the Recht-Ipson model for the given projectile.

Furthermore, penetration analyses of 7,62 mm x 63, AP, M2 projectiles through

various target materials were performed at consistent projectile velocities and

mesh sizes. As expected, bainitic steels exhibited the highest resilience,

demonstrating that increased material hardness and tensile strength correlate with

enhanced projectile penetration resistance.

© The Author 2024.
Published by ARDA.

Keywords: numerical simulation, penetration, 7,62mm x 63, AP, M2, Ansys,
Autodyn

1. Introduction

Projectile penetration through a target is a highly significant research topic for applications in defense
technologies (i.e. ref [32]). Research on projectile penetration is crucial for understanding the fundamental
mechanisms of protection against projectile impacts and armor design, as well as for enhancing the
effectiveness of munitions against specific types of targets. There are three methods for analyzing projectile
penetration: experimental, analytical, and numerical simulation methods. The experimental method is the most
reliable, but it is also the most expensive and time-consuming. A drawback of the experimental method is that
the results cannot be extrapolated to different ranges of variables beyond those used in the tests.

The analytical method can be used to perform certain analyses that yield usable results, such as the Recht-
Ipson method. However, due to the complexity of modern systems, the analytical method is primarily used to
gain insight into the nature of the penetration process. It can also be employed prior to conducting
experiments; for example, a preliminary analytical approach can be used to establish a starting point and
reduce the total number of experiments needed. Parametric analytical analysis is useful if the appropriate
constants for the given target material and projectile type are known.



 DSS Vol. 5, No. 1, 2024, pp. 46-64

47

The numerical simulation method, which will be used in this study, has the capability to handle very complex
geometries without any difficulties. Depending on the complexity of the material models used, results can
range from the accuracy level of analytical models to that of experimental models. By setting up an adequate
material model, any penetration simulation can be conducted seamlessly, yielding reliable results. Parameters
such as impact velocity, target thickness, and impact angle (3D simulation is required for impact angle) can be
varied as desired. Given the current advancements in hardware and software, numerical simulations can be
conducted very quickly and at a much lower cost than experimental methods, while still providing high-
accuracy results (provided the conditions for good accuracy are met, as outlined below). Accuracy depends on
many parameters: the accuracy of the material model and constants in the models, the numerical model (mesh,
solver, initial and boundary conditions), the type of simulation software used, etc.

2. Data on 7.62mm x 63, AP, M2 ammunition (USA: .30, AP, M2) and the weapons used with this
type of ammunition

The American .30-06 AP, M2 / 7.62 mm x 63 ammunition was introduced in 1906 as an evolution of the US
Army’s short-lived use of the .30-03 cartridge, which was originally adopted in 1903 with a round-nosed
bullet. The .30-06 cartridge has a slightly different case than the .30-03 and, more importantly, features an
ogive-shaped projectile, providing significantly better aerodynamic performance. The 7.62 mm x 63 AP, M2
ammunition has a projectile mass of 10.8 grams, a muzzle velocity of 830 m/s, and a muzzle energy of 3730 J
[1]. This ammunition is used against lightly armored vehicles, protective shelters, and infantry [2]. The basic
data on this ammunition is provided in Table 1.

Table 1. The basic data on ammunition .30-06, AP, M2 [3]

DODAC 1305-A202

UNO proper shipping name Cartridges for weapons, inert projectile

Mass (g) 27,5

Length (mm) 84,8 mm

Primer Impact

Propellant type WC 852

Propellant weight (g) 3,6

Projectile weight (g) 10,8

Performance

Chamber pressure (MPa) 372

Velocity (m/s) 827,5; at 23,8 m from muzzle

Shipping and Storage Data

Quantity-distance class/SCG 1.4S

Storage code Class V

DOT shipping class C

Figure 1 shows the 7.62mm x 63 (.30-06) AP, M2 ammunition and its cross-section. In the cross-section, the
components of the ammunition can be seen: the brass jacket and case, the lead cap, and the steel core. The tip
of the projectile is painted black to indicate armor-piercing ammunition.

Ammunition 7.62mm x 63, AP, M2 is fired from 7.62 mm machine guns, models: M37, M1919A4 and
M1919A6, and a .30 caliber rifle, M1 [3]. In military service, the 30-06 was used in the bolt-action M1903
Springfield rifle, the bolt-action M1917 Enfield rifle, the semi-automatic M1 Garand rifle, the semi-
automatic M1941 Johnson rifle, the Famage Mauser, the Browning Automatic Rifle (BAR), and numerous
machine guns, including the M1917and M1919 series [4].



 DSS Vol. 5, No. 1, 2024, pp. 46-64

48


Figure 1. Ammunition .30-06, AP, M2

3. Numerical simulations

3.1. Basics of the Autodyn software

The ANSYS Workbench platform enables interaction with ANSYS solvers. ANSYS Workbench is composed
of different modules, eg: Explicit Dynamics, Meshing, Autodyn, etc. In ANSYS solvers, the terms "implicit"
and "explicit" refer to two types of time integration methods used to perform dynamic simulations. Explicit
time integration is more stable, but the simulation takes longer due to the small time-step (due to the high
velocities, fine mesh, and high velocity of sound that are used in the materials) and is more efficient for
simulations involving [5]:

 spreading of the shock wave,

 large deformations and stretching,

 non-linear behavior of material,

 complex contact between certain components

 fragmentation of material, etc.

Explicit methods calculate the state of the system in the next step based on the current state of the system,
while implicit methods try to arrive at a solution by solving an equation involving the current state and the
state of the system in the next step. Implicit methods require more computer resources and are much more
difficult to implement. Compared to explicit, implicit methods have better stability, so larger time steps can be
used with them. However, implicit methods require solving a large system of coupled equations for each time
step, which significantly complicates the problem [5].

A typical application of the explicit dynamics module includes i.e. [5]:

 simulation of an object falling from a height

 impact and penetration process

 fragmentation

 explosions, etc.



 DSS Vol. 5, No. 1, 2024, pp. 46-64

49

The AUTODYN programs are general-purpose engineering software packages that use finite difference, finite
volume, and finite element techniques to solve a wide variety of non-linear problems in solid, fluid, and gas
dynamics. AUTODYN has a wide range of uses, eg: street explosions, building explosions, mine explosions,
improvised explosive devices (IEDs), mining explosions, warhead design (cumulative charges),
missile/warhead impact, aircraft impact, body armor, drop tests, destruction, etc. AUTODYN can be
characterized as "many codes in one", and includes both structural mechanics and fluid mechanics regimes.
Each of these "codes" in AUTODYN represents a specific numerical solver, for example [6]:

 Lagrange processor for modeling solid continua and structures

 Euler processors for modeling fluids, gases, and large distortion. These processors include first-order
and second-order accurate schemes.

 ALE (Arbitrary Lagrange Euler) processor for specialized flow models
 Shell processor for modeling thin structural elements

 SPH (Smooth Particle Hydrodynamics).

Compared to the Eulerian approach, discussed below, the Lagrange formulation tends to be faster
computationally as no transport of material through the mesh needs to be calculated. Moreover, material
interfaces, free surfaces, and history-dependent material behavior are generally easier to follow in the
Lagrange framework. The major disadvantage of Lagrange is that if excessive material movement occurs, the
numerical mesh may become highly distorted leading to an inaccurate and inefficient solution. Further, this
may ultimately lead to a termination of the calculation [6]. The calculations performed at each incremental
time step (or cycle) in the Lagrange solver are shown schematically in Figure 2.



Figure 2. Lagrange Computation Cycle [6,31]

AUTODYN utilizes the differential equations governing unsteady material dynamic motion to express the
local conservation of mass, momentum, and energy. In order to obtain a complete solution, in addition to
appropriate initial and boundary conditions, it is necessary to define a further relation between The flow
variables. The relations between the hydrostatic pressure, the local density (or specific volume), and the local
specific energy (or temperature) are known as an equation of state [6].

The Rankine-Hugoniot equations for the shock jump conditions can be regarded as defining a relation
between any pair of the variables ρ, p, e, up, and U. Here, U is the velocity of the shock wave in the material,
and up is the velocity of the particles of the material. In many dynamic experiments making measurements of
up and U, it has been found that for most solids and many liquids over a wide range of pressure, there is an
empirical linear relationship between these two variables, viz. [6]:


𝑈 = 𝑐 + 𝑠𝑢  (1)

where c0 is the speed of sound, and s is an empirically determined constant.



 DSS Vol. 5, No. 1, 2024, pp. 46-64

50


AUTODYN uses the Mie-Gruneisen form of the equation of state, based on the so-called Hugoniot shock (an
empirical curve showing the dependence of U(up), P(up), or P(V)), in the form [6]:


𝑝 = 𝑝 + Γ𝜌(𝑒 − 𝑒 )    (2)

where Γ is the Gruneisen constant (for most materials it has a value of 1.25 ± 0.75). Also applies:


𝑝 =
𝜌 𝑐 𝜇(1 + 𝜇)

[1 − (𝑠 − 1)𝜇]



(3)

𝑒 =
1

2

𝑝

𝜌

𝜇

1 + 𝜇



(4)

The Johnson-Cook model is a constitutive model that aims to model the strength behavior of materials
subjected to large strains, high strain rates, and high temperatures. Such behavior might arise in problems of
intense impulsive loading due to high-velocity impact and explosive detonation. The model defines the yield
stress σy as [6]:



𝜎 = 𝐴 + 𝐵𝜀 1 + 𝐶 log 𝜀 ̇ [1 − 𝑇 ]


(5)

where:
εp – effective plastic strain, 𝜀 ̇  – normalized effective plastic strain rate (the ratio of the current strain rate to
the reference strain rate 𝜀 ̇ ), TH – homologous temperature (T-Troom)/(Tmelt-Troom). The five material constants
are A, B, C, n, and m.

Johnson-Cook failure model is also an empirical model based on the tests with several metallic
materials. It implements the effects of temperature softening and strain rate hardening. The
basic form of the model, using the damage accumulation, can be seen in Equation [7]:


𝐷 =
∆𝜀

𝜀


(6)

where:
D – damage, ∆ε - Increment of equivalent plastic strain during 1 integration cycle, εf  - failure strain

Failure strain is defined as follows:


𝜀 = 𝐷 + 𝐷 e( ∗)  1 + 𝐷 ln 𝜀̇ [1 + 𝐷 𝑇 ]


(7)

where:
D1-D5 – material constants, σ* - the ratio of stress to equivalent stress, 𝜀̇  - normalized rate of plastic
deformation, 𝑇  - homologous temperature.

When D in Equation (7) becomes unity, failure occurs and the element is removed (eroded)
from the computational grid [7].

Although AUTODYN can calculate with both Lagrangian and Eulerian subgrids it may sometimes be the case
that materials have to be defined on Lagrangian subgrids even though it is clear that these materials will be
subjected to very large distortions arising from the gross motion of the Lagrange grid [6].
During the subsequent calculation some of these Lagrangian cells can become grossly distorted and, unless
some remedial action is taken, can seriously impair the progress of the calculation. Therefore, procedures have
been incorporated into AUTODYN (both 2-D and 3-D) to remove such Lagrangian cells from the calculation
if a pre-defined strain (either instantaneous geometric strain, incremental geometric strain, or effective plastic
strain) exceeds a specified limit. When a cell is removed from the calculation process in this way the mass



 DSS Vol. 5, No. 1, 2024, pp. 46-64

51

within the cell can either be discarded or distributed to the corner nodes of the cell. If the mass is retained,
conservation of inertia and spatial continuity of inertia are maintained. However, the compressive strength and
internal energy of the material within the cell are lost whether or not the mass is retained. This discard
procedure is known as erosion [6].

3.2. The numerical model validation

Validation of the numerical model was performed using available experimental data (T. Borvik [8]) - from
which data on the dimensions and material of the target, and the material of the projectile parts were also
collected. A target of dimensions 150 mm x 150 mm and thickness 20 mm, AA5083H116, was used, for
which experimental data are available in [8].
The target and the 7.62mm x 63 projectile were first modeled in the "SolidWorks" software (Figure 3) and
then exported as a .iges file for insertion into the Ansys Workbench Explicit Dynamics module (Figure 4). A
2D model, axial symmetry, was used in the calculation, which was made on the basis of a 1/4 3D model in
SolidWorks and using options in Geometry Modeler.



Figure 3. Layout of the 1/4 3D model in SolidWorks


Figure 4. Layout of the 2D model of projectile 7,62mm x 63 and target in Ansys Workbench Explicit

Dynamics module



 DSS Vol. 5, No. 1, 2024, pp. 46-64

52


In order to perform a sensitivity analysis of the numerical model grid, a 2D axisymmetric model with several
different grids was discretized using the Lagrange solver (Figure 5). A comparison of the results was made for
the following grids (mech element size): 0.1; 0.15; 0.2; 0.25; 0.3; 0.35; 0.4; 0.45 and 0.5 mm. The mesh was
the same size for both the projectile elements and the target.
The condition of impact velocity in the y-axis direction (in the direction of penetration of the projectile
through the target) of 822.4 m/s was set as stated in the reference [8]. Also, the target is fixed on the outer
edge parallel to the axis of symmetry.



Figure 5. Layout of the 0,1 mm grid placed to projectile and target

Projectile material models (jacket, cup, core, and lead filling) were collected from the Ansys Autodyn library
and combined with additional literature data [8]. The material models for the target were taken from the Ansys
Autodyn library in combination with additional data from the literature [9].
For the plate that was used as a target (aluminum alloy AA5083H116), the Gruneisen shock equation of state
with the following constants was used: Γ=1,97; ρ=2700 kg/m3; c0=5340 m/s and s=1,4. Also, the Johnson-
Cook model (strength model) was used, with the following constants: A=167 MPa; B=596 MPa; n=0,551;
C=0,001 and m=0,859. The material failure model (Johnson-Cook) was also used on the target, with the
following constants: D1=0,0261; D2=0,263; D3=-0,349; D4=0,147; D5=16,8.
The projectile is composed of a steel core, a brass jacket and cup, and a lead tip. No failure model was used
for the projectile parts. The Johnson-Cook strength model was used, the constants of the model are given in
Table 2, as well as other material properties in Table 3.


Table 2. Johnson-Cook constants for materials of projectile parts

Material A (MPa) B (MPa) n C ε0* (1/s) m Tm (K)

Steel
(core)

1200 50000 1 0 0,0005 1 1800

Lead (tip) 24 300 1 0,1 0,0005 1 760

Brass
(jacket

and cup)
206 505 0,42 0,01 0,0005 1,68 1189






 DSS Vol. 5, No. 1, 2024, pp. 46-64

53

Table 3. The main mechanical characteristics of the materials of projectile parts

Material
Density
(kg/m3)

Young’s
modulus
(MPa)

Poisson’s
ratio

Bulk modulus
(Pa)

Shear modulus
(Pa)

Specific heat
capacity
(J/kgK)

Steel
(core)

7850 210000 0,33 2,0588∙1011 7,8947∙1010 452

Lead (tip) 10660 1000 0,42 2,0833∙109 3,5211∙108 124
Brass

(jacket and
cup)

8520 115000 0,31 1,0088∙1011 4,3893∙1010 385


In the reference [8], the initial velocity (vi = 822.4 m/s) and the experimentally obtained exit velocity (vr =
694.3 m/s) are given for the penetration test of the AA5083-H116 target material. The results of exit velocities
obtained by numerical simulations as part of this validation are compared with the given projectile exit
velocity obtained in the test. The relevant exit velocity is taken from the projectile element at the bottom of
the projectile core because these elements are mostly used in the literature.
Exit velocities in the period from 90 to 100 μs for different grids from 0.1 to 0.5 mm were analyzed. Because
the values of the obtained exit velocities fluctuate around some mean value, the mean values of the velocity
for a given bottom element and for each grid, in the time period from 90 to 100 μs (when the projectile leaves
the target), were calculated.

Figure 6 shows a diagram showing that the exit velocity settles at around 705.8 m/s, and considering that the
0.1 mm mesh has approximately the same velocity value, the 0.2 mm mesh gives sufficiently accurate
simulation results. Also, the numerical simulation itself with a mesh of 0.2 mm takes much less time
compared to a mesh of 0.1 mm. By comparing the exit velocity obtained by numerical simulation for a 0.2
mm mesh with the exit velocity obtained by the test in the literature [8], a relative error of 1.65% is obtained,
which is a satisfactory result. Considering the small relative error, the 0.2 mm grid seems satisfactory and is
adopted for further analysis in the paper.
The appearance of the penetration process of AP 7.62mm x 63 projectile at a time-frame of 50 μs in the Ansys
Workbench Explicit Dynamics module is shown in Figure 7, and in Figure 8 at a time-frame of 100 μs.
Qualitatively, the penetration simulation process is shown to resemble the penetration process presented also
in the paper [8].



Figure 6. Display of the relationship between projectile exit velocity and mesh size and polynomial regression

curve

y = -691.48x3 + 433.49x2 - 87.543x + 711.09
R² = 0.8555

650.0

660.0

670.0

680.0

690.0

700.0

710.0

720.0

0 0.1 0.2 0.3 0.4 0.5 0.6

Ve
lo

ci
ty

 (m
/s

)

Mesh size (mm)

Vaverage in the period 90-100 microseconds

Poly. (Vaverage in the period 90-100 microseconds)



 DSS Vol. 5, No. 1, 2024, pp. 46-64

54


Figure 7. Display of the numerical simulation of the penetration of a 7.62mm x 63 caliber projectile through a

target at the moment when the projectile is in the target



Figure 8. Display of the numerical simulation of the penetration of a 7.62mm x 63 projectile through the target

at the moment when the projectile passed through the target

Figure 7. and Figure 8. shows that the core of the 7.62mm x 63 projectile remained almost undamaged during
the penetration of the target. This is also recored in ref. [8] that served in validation process.

3.3. Influence of projectile impact velocity and target material on the process of projectile penetration

In this sub-chapter 3.3.1, an analysis of the influence of the variation in the impact velocity of the projectile on
the exit velocity of the projectile was performed. The analysis was performed for the 0.2 mm mesh size
(which was adopted earlier as the reference in the numerical model validation process) and the AA5083H116
target for different projectile impact velocities.



 DSS Vol. 5, No. 1, 2024, pp. 46-64

55


In the sub-chapter 3.3.2, the influence of the variation in the target material on the projectile penetration
process was performed. The analysis was performed also for a mesh size of 0.2 mm and a projectile impact
velocity of 822.4 m/s for different target materials.

3.3.1. The effect of changing the impact velocity of the projectile

In this part of the research, numerical simulations of the penetration of the 7.62mm x 63 projectile through the
AA5083H116 target were carried out for different impact velocities of the projectile at a mesh size of 0.2 mm.
The projectile and target materials, as well as the material models used, are the same as in the validation of the
numerical model. The projectile and target geometry are also the same. For an impact velocity of 400 m/s, the
projectile does not pass through the target.

The ballistic limit velocity is the input velocity at which the exit velocity obtained by numerical simulation is
equal to 0. This ballistic limit velocity is obtained as the average velocity between the highest velocity of the
projectile that does not penetrate the target and the lowest velocity of the projectile that completely passes
through the target. In our case, the ballistic limit velocity was Vbl = 401 m/s. After estimating the ballistic
limit velocity, the calculation for the exit velocity of the projectile corresponding to the given input velocity
was also carried out using the Recht–Ipson model. Output velocities were calculated based on the following
empirical model originally proposed by Recht and Ipson [9]:

                                            𝑣 = 𝑎 ∙ (𝑣 − 𝑣 )


(8)
where:
vi – impact velocity, vr – exit velocity, vbl – ballistic limit velocity, a and p – Recht constants of the model.

Regression analysis (of data obtained by simulations) was used to determine the parameters a and p from the
Recht-Ipson model as accurately as possible. The determination of these parameters was performed using the
"Matlab" program ("Curve Fitting Tool" option, the values of the projectile's impact and exit velocity obtained
by simulation are used).
Figure 9 shows a graph of projectile exit velocity versus projectile impact velocity for numerical simulations
and the Recht-Ipson model with obtained constants.



Figure 9. Diagram of exit velocity of the projectile as a function of projectile impact velocity (simulation

results and Recht-Ipson curve)

0

100

200

300

400

500

600

700

800

350 450 550 650 750 850

Ex
it

ve
lo

ci
ty

 (m
/s

)

Impact velocity (m/s)

Recht-Ipson
model

Simulation



 DSS Vol. 5, No. 1, 2024, pp. 46-64

56

By using the equation of the Recht-Ipson model curve whose constants are obtained by regression based on
the results of the numerical simulation, the output velocity of the projectile can be determined for different
values of the input velocity of the projectile without starting the simulation. This model is most often used for
cases of projectile impact at a normal angle to a thin target. The disadvantage of this model is that in order to
obtain the constants, experimental testing or numerical simulation must be carried out in order to obtain the
constants by regression of the test/simulation results.

3.3.2. The effect of changing the target material

Numerical simulations in this part of the research were performed for the same conditions as in the previous
chapters. The material of the projectile parts is also unchanged, the only variation is in the 20 mm thick target
material. It is assumed that the equation of state for all steels is the same and the constants of this equation are
listed in Table 4. Tables 5 and 6 lists the Johnson-Cook strength model constants and fracture model constants
for various target materials.


Table 4. Coefficients of the Gruneisen shock equation of state for the target material [10]

Material Density (g/cm3)
Gruniesen
coefficient

c0 (m/s) s

Steel/iron 7,85 1,93 4570 1,49


Table 5. Johnson-Cook strength model constants for various target materials
Material A (MPa) B (MPa) n C m

Steel 4340 [Autodyn library] 792 510 0,26 0,014 1,03
Armox 500T [11] 1372,4 835 0,2467 0,0617 0,84

Mild steel [11] 304,3 422 0,345 0,0156 0,87
RHA steel [12] 1193 500 0,676 0,00435 1,17

Weldox 460E steel [13] 490 807 0,73 0,012 0,94
Weldox 700E steel [14] 859 329 0,579 0,0115 1,071
Weldox 900E steel [4] 992 364 0,568 0,0087 1,131

Iron Armco [Autodyn library] 175 380 0,32 0,06 0,55
Bainite steel [15] 1517 1575 0,35 0,01 1

Nanos-BA steel [12] 1303 1420 0,195 0,075 1,17
Steel Tenax [16] 1440 492 0,24 0,011 1,03

Steel 2P [16] 1210 773 0,26 0,014 1,03


Table 6. Johnson-Cook failure model constants for different target materials
Material D1 D2 D3 D4 D5

Steel 4340 [Autodyn library] 0,05 3,44 -2,12 0,002 0,61
Armox 500T [11] 0,04289 2,1521 -2,7575 -0,0066 0,86

Mild steel [11] 0,1152 1,0116 -1,7684 -0,05279 0,5262
RHA steel [12] 0,21 7,2 -5,44 0 0

Weldox 460E steel [13] 0,0705 1,732 -0,54 -0,0123 0
Weldox 700E steel [14] 0,361 4,768 -5,107 -0,0013 1,333
Weldox 900E steel [14] 0,294 5,149 -5,583 0,0023 0,951

Iron Armco [Autodyn library] -2,2 5,43 -0,47 0,016 0,63
Bainite steel [15] 0,047 0,165 -2,7 0 0

Nanos-BA steel [12] 0,047 0,165 -2,7 0 0
Steel Tenax [16] 0 1,07 -1,22 0,000016 0,63

Steel 2P [16] 0,1 0,93 -1,08 0,000014 0,65

Numerical simulation results, i.e. the penetration process of the 7.62mm x 63 projectile through targets made
of different steels at a projectile impact velocity of 822.4 m/s and a mesh size of 0.2 mm are shown in Figure
10. The material of the target in the figure is given in the legend and is marked in blue.




 DSS Vol. 5, No. 1, 2024, pp. 46-64

57








Figure 10a. Numerical simulation results: penetration process of projectile 7.62mm x 63 through targets made

of different steels at projectile impact velocity 822.4 m/s and mesh size 0.2 mm



 DSS Vol. 5, No. 1, 2024, pp. 46-64

58








Figure 10b. Numerical simulation results: penetration process of projectile 7.62mm x 63 through targets made

of different steels at projectile impact velocity 822.4 m/s and mesh size 0.2 mm – continued



 DSS Vol. 5, No. 1, 2024, pp. 46-64

59








Figure 10c. Numerical simulation results: penetration process of projectile 7.62mm x 63 through targets made

of different steels at projectile impact velocity 822.4 m/s and mesh size 0.2 mm – continued

Table 7 shows the penetration depths of the 7.62mm x 63 projectile through targets made of different steels at
an impact velocity of 822.4 m/s. In Figures 10a-c and Table 7, it can be noted that the most durable steels are
bainite steels (Nanos-BA steel and bainite) as well as Armox 500T steel.



 DSS Vol. 5, No. 1, 2024, pp. 46-64

60

The 2P and Tenax steels also showed relatively good performance against the 7.6 2mm x 63 projectile,
retaining the projectile in the target after penetrating a little more than half the thickness of the target.
RHA and 4340 steels did not perform as well, where the 7.62 mm x 63 projectile penetrated almost the entire
target, but remained stuck the target. They have shown better durability than the materials listed below.
Weldox 460E, Weldox 700E, Iron Armco, and mild steel showed lower effectiveness than the previous steels
in penetration of the 7.62mm x 63 projectile at 822.4 m/s and the projectile completely penetrated targets with
these materials. Mild steel showed the weakest performance as the projectile completely exited the target,
while with the materials mentioned before (bainite steels, Armox 500T, 2P, 4340 and Tenax steels, RHA,
Weldox 700E and Weldox 900E) the projectile remained stuck in the target.


Table 7. The penetration depth of the projectile 7.62 mm x 63 through a target made of different steels at a
projectile impact velocity of 822.4 m/s

Target material Penetration depth (mm)

Nanos-BA steel 4,5

Armox 500T 7,7

Bainite steel 9

Steel 2P 11

Steel Tenax 12

Steel 4340 18

RHA 18

Weldox 900E 19,5

Mild steel 20 (perforation)

Iron Armco 20 (perforation)

Weldox 460E 20 (perforation)

Weldox 700E 20


The data required for the analysis of the influence of mechanical characteristics on the penetration depth of the
7.62x63 mm projectile through the target are set out in Table 8.
The hardness of a material is a measure of the material’s resistance to indentation, abrasion, and wear. For
metals, the hardness of a material can be related to a material’s UTS (ultimate tensile strength) with a linear
relationship, which is shown in the diagram of tensile strength as a function of hardness (figure 11).
In the diagram in Figure 11, approximately mean values are used for parameters whose exact value is not
known, but the range of values is known. It can be seen in Table 8 that a material with a higher hardness has a
higher tensile strength. Increasing the hardness of steel leads to an increase in the ballistic protection of armor
materials. High hardness contributes the most to the reduction of penetration depth. This is evident in
materials such as Armox 500T and bainite steel, which have relatively small penetration depths. Materials
with relatively high hardness (eg Weldox 900E) resist projectile penetration better than materials with lower
hardness (eg Iron Armco). This can be seen from the fact that although the Weldox 900E and Weldox 700E
steels have approximately the same penetration depth of 20 mm, the projectile in these cases failed to
completely penetrate them, while it completely penetrated the softer Iron Armco and Weldox 460E steels.




 DSS Vol. 5, No. 1, 2024, pp. 46-64

61

Table 8. Mechanical properties of the target material and penetration depth of the 7.62 mm x 63 projectile

Material
Hardness
(BHN)

Tensile strength
(MPa)

Penetration depth
(mm)

Nanos-BA steel 590-640 [18] 1800-2000 [18] 4,5
Armox 500T 480-540 [10] 1450-1800 [10] 7,7
Bainite steel 373-627 [20] 1770-2200 [19] 9
Steel 4340 321 [21] 1100 [21] 18
RHA steel 302-400 [22] 1170 [23] 18
Mild steel 105 [24] 365 [24] 20 (perforation)

Iron Armco 74-83 [25] 290 [25] 20 (perforation)
Weldox 460E 171-181 [26] 530-720 [17] 20 (perforation)
Weldox 700E 210-240 [27] 780-930 [27] 20
Weldox 900E 280-330 [28] 940-1100 [29] 19,5




Figure 11. Diagram of tensile strength as a function of hardness

High strength and ductility are assumed to be vital parameters in order to absorb energy during structural
impact [14]. Ductility is the ability of a material to withstand plastic deformation without breaking. The more
a material is capable of withstanding greater deformation without brittle fracture, the more ductile the material
is. For materials that are subjected to relatively high strain rates (when compared to quasi-static values), their
strengths can change and, for most materials, increase markedly. Generally speaking, metals will get stronger
but less ductile at elevated strain rates, but unlike some non-metals, their stiffness is relatively unaffected by
increased deformation rates. The reason for the increased strength with strain rate is due to complex
microstructural behavior that is dependent on the nature of the material (at high deformation rates,
dislocations accumulate within the material structure and the material hardens) [17].
In addition to hardness and ductility, the mechanical properties to pay attention to are also yield strength,
tensile strength, and toughness. The area under the curve on a Hooke diagram (stress diagram) is a measure of
the strain energy absorbed per unit volume, V, and is an indication of the toughness of the material. For an
armor designer, toughness is a desirable property because a tough material requires more energy to cause
fracture. High tensile strength and yield strength allow steel to resist deformation and maintain structural
integrity under high stress [17]. A material such as RHA steel, while not the hardest of the given steels, has a
high tensile strength, which helps to better absorb and dissipate projectile energy.
It is noticeable that the steels with the highest resistance to projectile penetration are the steels with the highest
hardness and tensile strength. Because of this, targets such as mild steel and Iron Armco suffer full penetration
compared to bainitic steels and Armox 500T steel. The iron-Armco has 7-8 times lower hardness than Nanos-
BA steel and 5 times lower tensile strength.


y = 3.1231x + 76.429
R² = 0.9857

0

500

1000

1500

2000

2500

0 100 200 300 400 500 600 700

Te
ns

ile
 S

tr
en

gt
h

[M
Pa

]

Hardness [HB]



 DSS Vol. 5, No. 1, 2024, pp. 46-64

62

The diagram of penetration depth as a function of tensile strength in Figure 12 was obtained on the basis of
data from Table 8, where approximately mean values were used for material properties whose exact value is
not known, but the range of values is known. Looking at the plot of penetration depth as a function of tensile
strength, it can be concluded that tensile strength is a good indicator of armor performance. It can be clearly
seen that the penetration depth decreases with increasing tensile strength, with a small deviation for the
Armox 500T steel.
The diagram of penetration depth as a function of hardness (Figure 13) was obtained in the same way as the
diagram from Figure 12. On the diagram of the depth of penetration as a function of hardness, as well as on
the diagram from Figure 12, it is seen that increasing the hardness decreases the depth of penetration. Similar
results and conclusions about the influence of tensile strength and hardness are given in reference [30].



Figure 12. Diagram of penetration depth as a function of tensile strength


Figure 13. Diagram of penetration depth as a function of hardness

4. Conclusions

The study evaluates the penetration capability of small-caliber projectiles using numerical simulation
methods. Numerical simulations were performed using Ansys Autodyn software, simulating the penetration of
a 7.62mm x 63, AP, M2 projectile through targets made of different materials. For model validation, reference
[8] was used to confirm the model's validity, as the results of the projectile's exit velocity from the numerical

Nanos-BA steel

Armox500t steel

Bainite steel

4340 steel

RHA steel

Mild steel

Iron Armco Weldox460E steel

Weldox700E steel

Weldox900E steel

0

5

10

15

20

25

0 500 1000 1500 2000

Pe
ne

tr
at

io
n

de
pt

h
[m

m
]

Tensile Strength [MPa]

Nanos-BA steel

Armox500t steel

Bainite steel

4340 steel

RHA steel

Mild steel

Iron Armco

Weldox460E steel

Weldox700E steel

Weldox900E steel

0

5

10

15

20

25

0 100 200 300 400 500 600 700

Pe
ne

tr
at

io
n

de
pt

h
[m

m
]

Hardness [HB]



 DSS Vol. 5, No. 1, 2024, pp. 46-64

63

simulation closely matched the experimental results reported in the literature [8] (a relative error of 1.65% was
obtained).
After validating the model, an analysis was conducted on the impact of varying the projectile's input velocity
and changing the target material for the same input velocity. The projectile exit velocities obtained from
numerical simulations showed good agreement with the exit velocities calculated using the Recht-Ipson
model. It was also observed, as expected, that the reduction in the projectile's exit velocity as a function of
impact velocity is nearly linear. The projectile's exit velocity can be determined for different input velocities
without running additional simulations by using the Recht-Ipson model.
Material hardness is a measure of a material's resistance to indentation, abrasion, and wear, and can be
correlated with its maximum tensile strength through a linear relationship. It is assumed that high strength and
ductility are key parameters for the target material's ability to absorb energy upon impact. For armor
designers, toughness is also a desirable property, as a tough material requires more energy to fracture. The
analysis of changing the target material for the same input projectile velocity (822.4 m/s) showed that bainitic
steels (with the highest hardness) were the most resilient, followed by Armox 500T steel. Examining the
effect of changing the target material for the same input projectile velocity, it can be concluded that ballistic
protection can be increased by increasing the material's hardness and tensile strength, with a clear reduction in
penetration depth as the hardness and tensile strength of the target material increase.
For future work, further research is recommended to expand the analysis of the influence of various factors on
projectile penetration. Special attention should be paid to variations in projectile and target geometry, as well
as the possibilities for optimizing materials to increase resistance to penetration. Additionally, research should
encompass a wider range of calibers and types of projectiles to gain a more comprehensive understanding of
penetration dynamics in different situations. The study could be expanded by using multi-layer targets and
varying target thickness, allowing for the measurement of maximum projectile penetration depths. Investing in
computer equipment would enable the performance of 3D numerical simulations, facilitating high-quality
testing of projectile impacts on angled targets set at specific angles relative to the direction of fire. Investing in
computer equipment could also save money compared to the costs required for conducting experimental tests.
In experimental studies, systems such as high-speed cameras could be implemented where feasible.

Funding information

No funding was received from any financial organization to conduct this research.

Declaration of competing interest

The authors declare that they have no known competing financial interests or personal relationships that could
have appeared to influence the work reported in this paper.

References

[1] https://modernfirearms.net/en/cartridge/30-06-us-306-7-62x63mm-30-cal-1906/
[2] NIJ Standard-0101.06:200 - Ballistic Resistance of Body Armor, U.S. Department of Justice Office of

Justice Programs, Washington, USA.
[3] Army Ammunition Data Sheets - Small Caliber Ammunition FSC 1305 TM-43-0001-27 Headquarters,

Department of the Army, April 1994.
[4] https://www.goofygoatgifts.com/product-page/30-06-bullet-pendant
[5] A. Ćatović, Numerical simulations in ballistics, Mechanical Engineering Faculty, Sarajevo, 2024.
[6] AUTODYN® – Explicit Software for Nonlinear Dynamics, Theory Manual – Revision 4.3., 2005.
[7] G. Ozturk, “Numerical and experimental investigation of perforation of ST-37 steel plates by oblique

impact [MS thesis]”, The graduate of School of Natural and Applied Sciences of Middle East Technical
University, 2010.

[8] T. Borvik, L. Olovsson, S. Dey, M. Langseth, “Normal and oblique impact of small arms bullets on
AA6082-T4 aluminum protective plates”, International Journal of Impact Engineering, vol 38, pp. 577-
589, 2011.



 DSS Vol. 5, No. 1, 2024, pp. 46-64

64

[9] M. A. Iqbal, K. Senthil, P. Bhargava, N. K. Gupta, “The characterization and ballistic evaluation of mild
steel”, International Journal of Impact Engineering, vol. 78, pp. 98-113, 2015.

[10] A. Mubashar, E. Uddin, N. Arif, S. W. Ul Haq, M. Chowdhury, “Ballistic response of 12.7 mm armour
piercing projectile against perforated armour developed from structural steel”, Proceedings of the
Institution of Mechanical Engineers, Part L: Journal of Materials: Design and Applications, vol. 233,
Issue 10, October 2018.

[11] K. Senthil, M. A. Iqbal, S. Rupali, “Influence of impactor nature, mass, size and shape on ballistic
resistance of mild steel and Armox 500 T steel”, International Journal of Protective Structures, pp. 1-24,
2018.

[12] T. Fras, A. Murzyn, P. Pawlowski, “Defeat mechanisms provided by slotted add-on bainitic plates
against small-calibre 7,62x51 AP projectiles”, International Journal of Impact Engineering, vol. 103, pp.
241-253, 2017.

[13] T. Borvik, M. Langseth, O. S. Hopperrstad, K. A. Malo, “Ballistic Penetration of Steel Plates”,
International Journal of Impact Engineering, vol. 22, No. 9-10, pp. 855-886, 1999.

[14] S. Dey, T. Borvik, M. Langseth, O. S. Hopperrstad, J. R. Leinum, “The effect of target strength on the
perforation of steel plates using three different projectile nose shapes”, International Journal of Impact
Engineering, vol. 30, No. 8-9, pp. 1005-1038, 2004.

[15] W. Burian, P. Zochowski, M. Gmitrzuk, J. Marcisz, L. Starczewski, B. Juszczyk, M. Magier, “Protection
effectiveness of perforated plates made of high strength steel”, International Journal of Impact
Engineering, 2018.

[16] J. Buchar, J. Voldrich, S. Rolc, J. Lisy, “Ballistic performance of the dual hardness armour”, Proceedings
of 20th International Symposium on Ballistics, Orlando, pp. 23-27, 2020.

[17] P. Hazell, Armour - Materials, Theory and Design, Second Edition, CRC Press, 2023.
[18] B. Garbarz, W. Burian, J. Marcisz, A. Wisniewski, “The Nano-Duplex NANOS-BA Steel for Application

in Construction of Armours”, Problems of mechatronics, Armament, Aviation, Safety Engineering, vol. 4,
No. 10, pp. 7-22, ISSN 2081-5891, 2012.

[19] C. M. Garcia, F. G. Caballero, H. K. D. H. Bhadeshia, “Mechanical properties of low-temperature
bainite”, Materials Science Forum, vol 500, pp. 495-502, 2005.

[20] https://www.totalmateria.com/en-us/articles/bainite-hardening-of-steel-1
[21] https://www.techsteel.net/alloy/steel/4340
[22] https://www.chapelsteel.com/mil-a-12560.html
[23] https://home.agh.edu.pl/~jrichert/Tablica_Ti.htm
[24] https://www.xometry.com/resources/materials/mild-steel/
[25] https://www.aksteel.nl/files/downloads/172888_armco_pure_iron_pdb_euro_final_secured_92.pdf
[26] P. A. Prabowo, I. Haryanto, “Analisa keceptan sisa proyektil berhidung tumpul yang ditembakkan pada

baja Weldox 460 E”, Jurnal Tehnik Mesin S-1, vol. 2, No. 1, Tahun, 2014.
[27] https://blog.thepipingmart.com/grades/weldox-700e-composition-properties-and-uses/
[28] Weldox 900: High-Strength Structural Steel Plate, Alloy Digest, ASM International, vol. 56, 2007.
[29] Weldox 900 Datasheet, SSAB Oxelösund AB, Version 2005-10-15
[30] K. L. Phelps, “Material properties affecting the penetration of metal targets by copper linear shaped

charges [MS thesis]”, Missouri University of Science and Technology, 2016.
[31] A. Catovic, “Research of influence of different shaped charge liner materials on penetration depth using

numerical simulations”, Periodicals of Engineering and Natural Sciences, vol 11, No. 4, pp. 1-26, 2023.
[32] A. Catovic, “Estimation of terminal ballistics parameters for several 7.62×51 mm projectiles using

numerical simulations”, The Journal of Defense Modeling and Simulation: Applications, Methodology,
Technology, 2024.
