Original Paper

Ultra Flexible Nanocarrier for Enhanced the Ocular Delivery of

Quercetin in Management of Macular Edema
Sahu Seema1, Shah Gulab Chand2, Manigauha Ashish1, & Gupta Vandana1

1 MITTAL INSTITUTE OF PHARMACY Opposite to Bhopal Memorial Hospital and Research Center

(BMHRC) Nbibagh, Karond, Bhopal-462038 (M.P)
2 School of Biotechnology RGPV BHOPAL, 462033 (M.P)
* Sahu Seema, MITTAL INSTITUTE OF PHARMACY Opposite to Bhopal Memorial Hospital and

Research Center (BMHRC) Nbibagh, Karond, Bhopal-462038 (M.P)



Received: December 22, 2020    Accepted: January 14, 2021   Online Published: December 14, 2021

doi:10.22158/eshs.v3n1p9                         URL: http://dx.doi.org/10.22158/eshs.v3n1p9



Abstract

Quercetin (Que) and its derivatives are naturally taking place phytochemicals with promising bioactive

belongings. The antidiabetic, anti-inflammatory, antioxidant, antimicrobial, anti-Alzheimer’s,

antiarthritic, cardiovascular, and wound-healing possessions of Que have been extensively investigated,

as well as its anticancer commotion against different cancer cell lines has been newly reported. Que

and its derivatives are found predominantly in the Western starve yourself, and people might benefit

from their defensive effect just by taking them via diets or as a food enhancement.

Bioavailability-related drug-delivery systems of Que have also been markedly exploited, and Que

nanoparticles become visible as a promising proposal to enhance their bioavailability. The present

review aims to make available a brief overview of the therapeutic things, new insights, and forthcoming

perspectives of Que. Plants and plant parts are used for its aroma, flavor, or therapeutic properties.

There are a number of recompense associated with using plants and plant phytoconstituents as

contrasting to pharmaceutical merchandise.

Keywords

Quercetin (Que), Ultraviolet(UV), Thermogravimetric Analysis (TGA), Solid lipid Nanoparticle (SLN),

Polyethylene Oxide (PEO), Isotonic Phosphate Buffer Saline (IPBS)











www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


10

Published by SCHOLINK INC.

1. Introduction

With increased age comes declining health conditions and increased prevalence in diseases. Included in

this broad category is the deterioration of vision due to a variety of factors contributing to a number of

ophthalmic diseases. These diseases can include age-related macular degeneration, cataracts, diabetic

retinopathy, and glaucoma. According to statistics by the National Eye Institute, several millions of

people above the age of forty are affected by one of these conditions. From the total population of those

above age forty in the 2010 U.S. Census (n = 142,648,393), 36,883,997 adults suffered from vision

impairment due to all of the ophthalmic diseases listed above combined (NEI “Prevalence”, 2016). This

is approximately over a quarter (25.9%) of adults over age forty who are affected with vision

impairment. As age increases, the prevalence rates of all vision impairment also increase, rising

significantly around ages 75-79 in all ethnicities, as shown in Figure 1.




Figure 1. 2010 U.S. Prevalence Rates: All Vision Impairment

Source: National Eye Institute. All Vision Impairment. Available at:

https://nei.nih.gov/eyedata/vision_impaired#1. Accessed March 27, 2020



Over the course of ten years, starting from the year 2000, the prevalence of vision impairment has

increased by almost 130% (NEI “Vision”, 2016). These trends are expected to continue with each

subsequent year so that by the year 2030, there will be almost a two-fold increase in prevalence of

vision impairment compared to that in 2010, and by 2050, there will be more than a 3-fold increase in

prevalence, as shown in Table 1 and Figure: 2.









www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


11

Published by SCHOLINK INC.

Table 1. Table Projections for Vision Impairment (2010-2030-2050)

Year All White Black Hispanic Other

2010 4,195,966 3,398,977 330,644 290,781 175,564

2030 7,169,680 5,277,689 618,110 840,497 433,383

2050 13,026,870 9,019,189 1,0470,986 2,000,853 958,842

Total

Population

142,648393 103,846,437 15,190,777 14,901,369 8,709,810

Source: National Eye Institute. Vision Impairment Tables. Available at: https://nei.nih.gov/

eyedata/vision_impaired/tables. Accessed March 27, 2020



Figure. 2 Chart Projections for Vision Impairment (2010-2030-2050)

Source: National Eye Institute. All Vision Impairment. Available at:

https://nei.nih.gov/eyedata/vision_impaired#1. Accessed March 27, 2020



One cause of vision impairment is due to uncontrolled exposure to reactive oxidative species, or ROS.

These are species that are produced naturally in the body as a byproduct of adenosine triphosphate, or

ATP, production, the energy source that is used for every day function and processes (Prunty, 2015).

They are free radicals that contain oxygen and are the most common type produced in tissues (NCI,

2014). They can affect cells by damaging important cellular components, such as DNA, proteins, and

membranes. The mitochondria, an efficient organelle found abundantly in the body’s cells and tissues,

produce the largest quantities of ROS as it is the largest contributor to ATP synthesis (90% of the

body’s energy) [UMDF, 2017]. The body has natural antioxidant mechanisms to protect against ROS,

but when ROS are overproduced, these mechanisms are overwhelmed (Prunty, 2015). This leads to



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


12

Published by SCHOLINK INC.

oxidative stress cascades on cells and tissues, which causes them to become damaged and eventually

die off. In the eye, ROS damage the cells of the retina, which plays an important role in converting

visual images into electrical impulses for the brain to interpret. As the photoreceptor cells of the retina

die off, vision worsens as the eye has less capability to convert those images to impulses. The longer

the period of exposure to ROS, the more damage is done to the retina. Prolonged damage to the retina

exacerbates retinal degradation and degeneration, further impairing vision and may even lead to

permanent blindness. This is why as a person ages, their vision becomes progressively worse.

A protective measure against ROS is the use of antioxidant treatments. Antioxidants can be used to

slow the rate of retinal degradation by counteracting damage from the reactive oxidative species. The

body produces some antioxidants endogenously, but they can also be obtained outside of the body.

They can be found in a variety of antioxidant-rich foods, such as fruits, leafy green vegetables, and

grains, and can also be obtained through dietary supplements. These include carotenoids like

beta-carotene, lycopene, and vitamins A, C, and E (NCI, 2014). There are a variety of substances that

act as antioxidants, like the ones mentioned before, in addition to glutathione, coenzyme Q10, lipoic

acid, flavonoids, phenols, polyphenols, phytoestrogens, etc., all having different properties and roles

against ROS (Harvard, 2017). In the case of preventing retinal degradation to improve outcomes in

terms of vision integrity and function, antioxidants can be employed to protect against the damage from

reactive oxidative species. However, because of physiological barriers, antioxidants cannot simply be

taken orally and expected to be able to reach its target, i.e. the retina, to enact its protection.



2. Quercetin

Quercetin, which has the chemical name of

2-(3,4-Dihydroxyphenyl)-3,5,7-trihydroxy-4H-1-benzopyran-4-one, is a bioflavonoid aglycone,

specifically of the flavonol subclass, meaning that it has a 3- hydroxyflavone backbone and lacks

attached sugars, as shown in Figure 3 (Kelly, 2011).





Figure 3. Quercetin Structure





www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


13

Published by SCHOLINK INC.

It is a crystalline solid that has a bright citron yellow color. It is lipophilic and hydrophobic in nature so

its solubility in water is poor to nonexistent (poor in hot water and entirely insoluble in cold water). A

way to improve its solubility in water is to convert it to a glycoside. This can be done by replacing one

of the hydroxyl groups, commonly the one at position 3, with a glycosyl group, which can be any sugar

such as glucose, rhamnose, or rutinose (see Figure 6). A glycoside group at position 3 is known as

isoquercitin. The addition of a glycosyl group changes the chemical properties of the drug, including

solubility, absorption, and in vivo effects. Specifically, the addition of the glycosyl group increases the

water solubility of quercetin.



3. Materials

Quercetin was purchased from Tocris Bioscience. Glycerol monostearate and Compritol ATO 888®

were graciously donated by Gattefossé. Miglyol 812® was purchased from Dr Reddy lab Hyderabad

India. Tween 80 and methyl-beta-cyclodextrin were purchased from Acros Organic. Poloxamer 188

was purchased from Spectrum. Glycerin was purchased from PCCA. Acetonitrile and dimethyl

sulfoxide were purchased from Fisher Chemical. Whole rabbit eye globes were purchased from

Pel-Freez Biologics. The rabbit eye globes were dissected in lab to collect the corneas for use in the

permeability studies.



4. Methods

A. Solid Lipid Nanoparticles

Quercetin solid lipid nanoparticles, or SLNs, were prepared by probe sonication method. The lipid

phase was prepared with a solid lipid (0.7% w/v Glycerol monostearate) in combination with 1.3% w/v

Compritol ATO 888® and heated on a hot plate at 80oC. Quercetin was dissolved in 100 μL of

dimethyl sulfoxide and added to 2.25% w/v glycerin. This mixture was added to the melted lipid phase.

The aqueous phase was prepared using 0.75% w/v Tween 80®, Poloxomer 188®, and filtered water

and heated on the hot plate at 80oC. The aqueous phase was then added to the lipid phase while stirring

at 600 rpm for 2 minutes. The final concentration of quercetin was 0.1% w/v. The premix was

homogenized with an Ultra-Turrax® at 16,000 rpm for 3 minutes to form a coarse emulsion. This

coarse emulsion was then subjected to probe sonication at a 15-second pulse rate for 3 minutes. The

final emulsion was allowed to cool to form the nanoparticles.

B. Nanostructured Lipid Carriers

Quercetin nanostructured lipid carriers, or NLCs, were also prepared by probe sonication method. The

method is almost exactly the same as that for the SLN formulation, except that the lipid phase was

prepared with a liquid lipid (0.7% w/v Miglyol 812®) in combination with 1.3% w/v Compritol ATO

888®, which was then heated on a hot plate at 80oC. Quercetin was dissolved in 100 μL of dimethyl

sulfoxide and added to 2.25% w/v glycerin. This mixture was then added to the melted lipid phase. The



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


14

Published by SCHOLINK INC.

aqueous phase was prepared using 0.75% w/v Tween 80®, Poloxomer 188®, and filtered water and

heated on the hot plate at 80oC. The aqueous phase was added to the lipid phase while stirring at 600

rpm for 2 minutes. The final concentration of quercetin was 0.1% w/v. The premix was homogenized

with an Ultra-Turrax® at 16,000 rpm for 3 minutes to form a coarse emulsion, which was then

subjected to probe sonication at a 15-second pulse rate for 3 minutes. The final emulsion was allowed

to cool to form the nanoparticles.

C. Hot Melt Cast Films

Quercetin films were prepared by melt-cast method. Polyethylene oxide N10 was used as the matrix

forming polymer. Quercetin and PEO N10 were mixed via geometric dilution to prepare the physical

mixture. The drug load in the film was 10% w/w. A 10 mm die was placed over a brass plate and heated

on a hot plate at 75°C for at least one minute. The physical mixture was poured into the center of the

die and compressed for a few seconds to form a flat matrix surface. The film was heated on the hot

plate for an additional minute so that the mixture was completely melted and then removed to cool.

When completely cooled, the film was cut to collect samples that weighed approximately 8 mg each.

D. Characterization of Nanoparticles

Mobile phase of acetonitrile:water (ACN:H2O, 40:60) was prepared. Quercetin was dissolved in

dimethyl sulfoxide (DMSO) to make a 1 mg/mL stock solution for the standards. Varying volumes of

the stock solution were diluted with the mobile phase to make standards of the following

concentrations: 1 μg, 2 μg, 5 μg, 10 μg, and 20 μg. The standards were analyzed using UV analysis at a

wavelength of 369 nm to determine the light absorbance trend, or calibration curve, of quercetin to

which the nanoparticle emulsions will be compared. The SLN and NLC formulations were diluted 500

times with purified water and analyzed using a zetasizer (Malvern Instruments, Ltd.) to determine the

size, polydispersity index, and zeta potential of the particles. The goal was to have small particle sizes,

low polydispersity index, and high magnitude of zeta potential for the most stable and homogeneous

formulation.

Entrapment efficiency, which is a measure of how much drug is entrapped in the nanoparticles, was

performed by centrifuging 500 μL of each formulation with a filter for 15 minutes. 100 μL of the

centrifuged filtrate was drawn, diluted with 900 μL of the mobile phase, and then vortexed to ensure

thorough and homogeneous mixing. Assay was performed to determine quercetin content in the

nanoparticles. For each formulation, 100 μL of formulation were added to 900 μL of a mixture of

DMSO and methanol (50:50) and sonicated for 10 minutes. After sonication, the mixture was

centrifuged for 15 minutes. From this, 100 μL of the supernatant was drawn and diluted with 900 μL of

the mobile phase before being vortexed to ensure thorough and homogeneous mixing. All samples

collected from entrapment efficiency and assays were analyzed in triplicates using HPLC-UV method

with a Kinetex® 5 μm EVO C18 100 Å LC column (250 x 4.6 mm).





www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


15

Published by SCHOLINK INC.

E. Characterization of Films

Mobile phase of acetonitrile:water (ACN:H2O, 40:60) was prepared. Quercetin was dissolved in

dimethyl sulfoxide (DMSO) to make a 1 mg/mL stock solution for the standards. Varying volumes of

the stock solution were diluted with acetonitrile to make standards of the following concentrations: 1

μg, 2 μg, 5 μg, 10 μg, and 20 μg. The standards were analyzed using UV analysis at a wavelength of

369 nm to determine the calibration curve of quercetin to which the film samples will be compared.

Samples of approximately 8 mg were cut from quercetin films and added to 2 mL of acetonitrile. This

mixture was then sonicated for 5 minutes until the film was completely dissolved. After sonication, the

stock was diluted by a factor of 20. All samples were collected and analyzed in triplicates using UV

analysis at a wavelength of 369 nm.

F. Permeability Studies

Release and permeability of quercetin from the nanoparticles were studied using a vertical dialysis

cassette with a 10,000 Dalton MWCO membrane. Isotonic phosphate buffer saline, or IPBS, was made

with 5% methyl-beta-cyclodextrin. IPBS served as the receiver medium. 18 mL of IPBS was filled into

the vial, and 1 mL of formulation was filled into the cassette. Measurements were taken at 15, 30, 60,

90, 120, 150, and 180-minute time points, at which time 1 mL of the receiver medium was drawn and 1

mL of IPBS was added into the vial. All samples collected were analyzed in triplicates under

HPLC-UV method.

Permeability of quercetin from NLCs and films was studied using fresh rabbit cornea in a side-by-side

diffusion apparatus, maintained at 34°C using a circulating water bath. IPBS with 5%

methyl-beta-cyclodextrin was made. Spectra/Por® membrane (10,000 Daltons MWCO) were cut and

soaked in IPBS for 30 minutes. Side-by-side diffusion cells were set up so that the fresh rabbit cornea

and Spectra/Por® membrane were sandwiched between the cells. For the film studies, the films were

cut to approximately 45 mg and wetted with IPBS. They were then sandwiched between the rabbit

cornea and Spectra/Por® membrane, in the following order: donor cell Spectra/Por® membrane

quercetin film cornea recipient cell (see Figure 4).





www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


16

Published by SCHOLINK INC.



Figure 4. Side-by-Side Diffusion Apparatus Setup

Source: Adelli GR, Hingorani T, Punyamurthula N, et al. Evaluation of topical hesperetin matrix film

for back-of-the-eye delivery. European Journal of Pharmaceutics and Biopharmaceutics 2015;

92:74-82



Both the donor and recipient cells for the film studies were filled with 3.2 mL of IPBS. For the NLC

formulations and the control, which was 3 mg of pure quercetin mixed with IPBS, 3.2 mL of each

formulation were added into their respective donor cells, and 3.2 mL of IPBS were added to the

recipient cells. Measurements were taken at 30, 60, 90, 120, 150, and 180-minute time points. After

flushing a few times to mix the receiver medium, 0.6 mL samples were drawn from the recipient cell,

except for the films, for which samples were collected from both donor and recipient cells, and 0.6 mL

of IPBS was added to the cells to replace the volume removed. The samples were analyzed in

triplicates using UV analysis at a wavelength of 369 nm.



5. Result and Discussion

5.1 Characterizations of Nanoparticles and Films

The solid lipid nanoparticles demonstrated an average particle size of 65.4 r.nm, polydispersity index of

0.29, and zeta potential of -12.3 mV. Assay and entrapment efficiency results were 78.4 ± 1.6% and

90.9

± 0.3%, respectively. Drug release across the Spectra/Por® membrane was 33.3 ± 1.5%. These

parameters are summarized below in Table 2. Particle size distribution is shown in Figure 5.













www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


17

Published by SCHOLINK INC.

Table 2. Physicochemical Characterization of SLN Formulations
Parameters Solid Lipid Nanoparticles

Particle Size (r.nm) 65.4

Polydispersity Index 0.29

Zeta potential (m V) -12.3

Assay 78.4±1.6

Entrapment Efficiency 90.9±0.3

%Release across

Spectra/Por® Membrane

33.3±1.5





Figure 5. SLN Particle Size Distribution by Intensity



The nanostructured lipid carriers demonstrated an average particle size of 46.1 r.nm, polydispersity

index of 0.18, and zeta potential of -16.2 mV. Assay and entrapment efficiency results were 86.6 ±

0.2% and

93.4 ± 0.1%, respectively. Drug release across the Spectra/Por® membrane was 47.1 ± 7.9%. These

parameters are summarized below in Table 3, and particle size distribution is shown below in Figure 6.

The comparison of the particle size distributions for the SLN and NLC formulations is shown below in

Figure 7.















www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


18

Published by SCHOLINK INC.

Table 3. Physicochemical Characterization of NLC Formulations

Parameters Solid Lipid Nanoparticles

Particle Size (r.nm) 46.1

Polydispersity Index 0.18

Zeta potential (m V) -16.2

Assay 86.6±0.2

Entrapment Efficiency 93.4±0.1

%Release across Spectra/Por® Membrane 47.1±7.9



Figure 6. NLC Particle Size Distribution by Intensity





www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


19

Published by SCHOLINK INC.



Figure 7. SLN vs. NLC Size Distributions by Intensity



Hot melt cast films demonstrated assay results of 76.3 ± 4.1%. Particle size, polydispersity index, zeta

potential, and entrapment efficiency are parameters designed more for nanoparticle systems and were

not evaluated with the hot melt cast films. Drug release across Spectra/Por® membranes was also not

evaluated with the films.



5.2 Corneal Permeability Studies

All samples were analyzed via UV analysis at a wavelength of 369 nm, at which the standard

calibration curve had an R2 value of 0.9989. TGA data indicated that physical mixtures were stable

under the utilized processing temperature. Permeability across the rabbit cornea for quercetin films,

NLCs, and control are shown in Figures 8, 9, and 10, respectively.



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


20

Published by SCHOLINK INC.



Figure 8. Permeability of Quercetin Films





Figure 9. Permeability of Quercetin NLCs



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


21

Published by SCHOLINK INC.



Figure 10. Permeability of Quercetin Control



The results from the permeability studies, in terms of rate, flux, and permeability, are summarized in

Table 4 and Figure 11. Transcorneal flux, which is the amount of drug that crosses the cornea per

minute per area squared (in this case, the area of the cornea is 0.636 cm), of quercetin control, NLCs,

and films were 0.026 ± 0.002, 0.036 ± 0.006, and 0.144 ± 0.009, respectively. Permeability was

calculated as flux normalized by assay.



Table 4. Results for Permeability Studies (Rate, Flux, Permeability)

 Rate (µg/min) Flux (µg/min/cm2) Permeability X 106 (cm/sec)

Control 0.0165±0.002 0.0260±0.002 0.135±0.012

NLCs 0.0227±0.004 0.0357±0.006 0.186±0.030

Films 0.1435±0.006 0.1435±0.009 0.747±0.047



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


22

Published by SCHOLINK INC.

Figure 11. Transcorneal Permeability of Quercetin in Different Formulations



The goal parameters for the nanoparticle formulations were to have small particle sizes, low

polydispersity index, and high magnitude of zeta potential. Both the solid lipid nanoparticles and the

nanostructured lipid carriers successfully met and fit well within these goal parameters. Particle sizes

for both formulations were well below 500 nm. The peak of the particle size distribution for the

NLC formulation was higher and narrower compared to the peak for the SLN formulation, as the

intensity was noticeably greater and the particle sizes were less variable. Polydispersity indices for both

were close to zero (0), which is the most ideal polydispersity index in order to have a completely

uniform formulation. Zeta potentials for both were relatively high in magnitude as well (between -10

and -20 mV). Both entrapment efficiencies were at least 90% or higher. Drug releases across the

Spectra/Por® membrane for both formulations, on the other hand, were relatively low (around 30-50%).

When comparing assays for all three formulations (SLNs, NLCs, and films), film assay results were the

lowest (by 2%), and NLCs were the highest (by about 8%), with SLNs in between the two. In all

regards, the NLC formulation had better physicochemical characteristics compared to the SLN

formulation. This is due to the nature of the lipid matrix shells of the nanoparticles. Because solid lipid

nanoparticle formulations use only solid lipids, the matrix shells are completely solid and continuous,

which has limited permeability. Not only does this affect how much drug can be encapsulated in the

nanoparticles, but it also affects how the drug diffuses out of the nanoparticles. Specifically, this

structure results in a relatively low drug load, limited drug release, and drug expulsion during storage.

With nanostructured lipid carriers, on the other hand, the incorporation of a liquid lipid to the solid lipid



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


23

Published by SCHOLINK INC.

matrix results in a disrupted and highly permeable nanoparticle shell. This structure allows for a higher

drug load, greater drug release, and long term drug stability. Thus, from these differences (summarized

in Figure 12), we would expect to see that the NLC formulation would show better characteristics than

the SLN formulation, which it did.




Figure 12. Advantages of NLC Structure over SLN Structure

Source: Beloqui A, Solinis MA, Rodríguez-Gascón A, Almeida AJ, Préat V. Nanostructured lipid

carriers: promising drug delivery systems for future clinics. Nanomedicine: Nanotechnology, Biology

and Medicine 2016; 12:143-161



To compare how well quercetin permeates from the hot melt cast film across corneas as opposed to

permeation from the nanoparticles, we used a control of pure quercetin in addition to the NLC

formulation, which was chosen because it demonstrated better parameters and physicochemical

characteristics compared to the SLNs. The three main parameters tested in the permeability studies

were rate, flux, and permeability. Rate was determined by how much drug, in micrograms (μg), crossed

the cornea from the donor to the receiver cells, per minute, with concentrations extrapolated from the

calibration curve based on the absorbance of the samples. The rate of drug release permeation for the

control was the slowest, and the rate for the films was the highest by a significant margin (7-14x

higher), with the rate of the NLCs in between the two. Flux was calculated as the amount of drug in

micrograms that crosses the cornea per minute per area squared (area = 0.636 cm). Again, the flux for

the control was the lowest, and the flux for the films was the highest by a good margin (4-5x higher).



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


24

Published by SCHOLINK INC.

Flux for NLCs was in between the other two flux values. Lastly, permeability was calculated as flux

normalized by assay and reported as centimeters per second. These results showed the same trends as

with the other two parameters. The permeability of the control across the cornea was the lowest, the

permeability of the drug from the NLCs was second highest, and the permeability of the drug from the

films was the highest, once again by a good margin (4-6x higher). In total, both formulations (NLCs

and films) were more successful compared to the control in drug permeability across the cornea.

However, the hot melt cast film formulation showed significantly better parameters in all respects

compared to both the control and the NLC formulation.



References

Abraham, M., & Acree, W. (2014). On the solubility of quercetin. Journal of Molecular Liquids, 197,

157-159.

Adelli, G. R., Balguri, S., & Majumdar, S. (2015). Effect of cyclodextrins on morphology and barrier

characteristics of isolated rabbit corneas. AAPS PharmSciTech, 16, 1220-1226.

Adelli, G. R., Hingorani, T., & Punyamurthula, N. (2015). Evaluation of topical hesperetin matrix film

for back-of- the-eye delivery. European Journal of Pharmaceutics and Biopharmaceutics, 92,

74-82.

Aditya, N. P., Macedo, A. S., & Doktorovova, S. (2014). Development and evaluation of lipid

nanocarriers for quercetin delivery: A comparative study of solid lipid nanoparticles (sln),

nanostructured lipid carriers (nlc), and lipid nanoemulsions (lne). LWT—Food Science and

Technology, 59, 115-121.

Balguri, S. P., Adelli, G. R., & Majumdar, S. (2016). Topical ophthalmic lipid nanoparticle formulations

(sln,nlc) of indomethacin for delivery to the posterior segment ocular tissues. European Journal of

Pharmaceutics and Biopharmaceutics, 109, 224-235.

Beloqui, A., Solinis, M. A., Rodríguez-Gascón, A., Almeida, A. J., & Préat, V. (2016). Nanostructured

lipid carriers: Promising drug delivery systems for future clinics. Nanomedicine: Nanotechnology,

Biology and Medicine, 12, 143-161.

Bentz, A. B. (2009). Review of quercetin: chemistry, antioxidant properties, and bioavailability.

Journal of Young Investigators.

Crowley, M., Feng, Z., & Martin, C. (2007). Pharmaceutical applications of hot-melt extrusion: Part I.

Drug Development & Industrial Pharmacy, 33(9), 909-926. Business Source Complete, Ipswich,

MA.

Dan, N. (2016). Compound release from Nanostructured Lipid Carriers (NLCs). Journal of Food

Engineering, 171, 37-43.

Dhawan, S., Kapil, R., & Singh, B. (2011). Formulation development and systematic optimization of

solid lipid nanoparticles of quercetin for improved brain delivery. Journal of Pharmacy and



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


25

Published by SCHOLINK INC.

Pharmacology, 63, 342-351.

Douroumis D. (2012). Hot-Melt Extrusion: Pharmaceutical Applications. Oxford: John Wiley & Sons,

Incorporated.

Ehrlich, S. D. (2015). Quercetin. University of Maryland Medical Center. Retrieved March 27, 2017,

from http://umm.edu/ health/medical/altmed/supplement/quercetin

Flavonoids. (2017). Wako Laboratory Chemicals. Retrieved March 27, 2017, from

http://www.wako-chem.co.jp/english/labchem/ product/life/Flavonoid/index.htm

Gaudana, R., Ananthula, H. K., Parenky, A., & Mitra, A, K. (2010). Ocular drug delivery. The AAPS

Journal, 12(3), 348-360.

Harvard, T. H. (2017). Chan. Antioxidants: Beyond the hype. Retrieved March 27, 2017, from

https://www.hsph.harvard.edu/nutritionsource/antioxidants/#age-related%20eye%20disease%20an

d%20antioxidants

He, Y., He, Z., He, F., & Wan, H. (2012). Determination of quercetin, plumbagin and total flavonoids in

drosera peltata smith var. glabrata y.z.ruan. Pharmacognosy Magazine, 8(32), 263-267.

Hippalgaonkar, K., Adelli, G. R., & Hippalgaonkar, K. (2013). Indomethacin-loaded solid lipid

nanoparticles for ocular delivery: Development, characterization, and in vitro evaluation. Journal

of Ocular Pharmacology & Therapeutics, 29(2), 216-228.

Kaufman, P. L., Alm, A., & Levin, L. A. (2011). Adler’s Physiology of the Eye. Philadelphia: Saunders.

Kelly, G. S. (2011). Quercetin. Alternative Medicine Review, 16, 172-194.

Kumari, A,, Yadav, S. K., & Pakade, Y. B. (2010). Development of biodegradable nanoparticles for

delivery of quercetin. Colloids and Surfaces B: Biointerfaces, 80, 184-192.

Mehnert, W., & Mäder, K. (2012). Solid lipid nanoparticles: production, characterization and

applications. Advanced Drug Delivery Reviews, 64, 83-101.

National Cancer Institute. (2017). Antioxidants and cancer prevention. Retrieved March 27, 2017, from

https://www.cancer.gov/about-cancer/causes-prevention/risk/diet/antioxidants-fact-sheet

National Eye Institute. (2017). All vision impairment. Retrieved March 27, 2017, from

https://nei.nih.gov/eyedata/ vision_impaired#1

National Eye Institute. (2017). Prevalence of adult vision impairment and age-related eye diseases in

America. Retrieved March 27, 2017, from https://nei.nih.gov/eyedata/adultvision_usa

National Eye Institute. (2017). Vision impairment tables. Retrieved March 27, 2017, from

https://nei.nih.gov/ eyedata/vision_impaired/tables

Prunty, M. C., Aung, M. H., & Hanif, A. M. (2015). In vivo imaging of retinal oxidative stress using a

reactive oxygen species—activated fluorescent probe. Investigative Ophthalmology & Visual

Science, 56(10), 5862-5870.

Quercetin (ab120247). (2017). Abcam. Retrieved March 27, 2017, from

http://www.abcam.com/quercetin-ab120247.html



www.scholink.org/ojs/index.php/eshs              Education, Society and Human Studies             Vol. 3, No. 1, 2022


26

Published by SCHOLINK INC.

Quercetin [product insert]. (2016). Ann Arbor, MI: Cayman Chemical Company.

Repka, M. A., Battu, S. K., & Upadhye, S. B. (2007). Pharmaceutical applications of hot-melt extrusion:

Part II. Drug Development & Industrial Pharmacy [serial online], 33(10),1043-1057.

Salunkhe, V. R., & Patil, S. J. (n.d.). UV spectrophotometric and hplc method development of quercetin

and curcumin in polyherbal churna and its validation. International Journal of Pharmaceutical

and Phytopharmacological Research, 1-16.

Srirangam, R., Hippalgaonkar, K., Avula, B., Khan, I., & Majumdar, S. (2012). Evaluation of the

intravenous and topical routes for ocular delivery of hesperidin and hesperetin. Journal of Ocular

Pharmacology and Therapeutics [serial online], 28(6), 618-627.

United Mitochondrial Disease Foundation. (2017). What is mitochondrial disease? Retrieved March 27,

2017, from https://www.umdf.org/what-is-mitochondrial-disease/

Weingerl, V. (2012). A comparative study of analytical methods for determination of polyphenols in

wine by hplc/uv-vis, spectrophotometry and chemiluminometry. In Macro to Nano Spectroscopy

(pp. 357-370). Croatia: InTech.

Wu, T. H., Yen, F. L., & Lin, L.T. (2008). Preparation, physicochemical characterization, and

antioxidant effects of quercetin nanoparticles. International Journal of Pharmaceutics, 346,

160-168.

http://www.umdf.org/what-is-mitochondrial-disease/
http://www.umdf.org/what-is-mitochondrial-disease/

	D. Characterization of Nanoparticles
	F. Permeability Studies
