115

A Historical Account on Italian
Mechanism Models
Marco Ceccarelli
LARM2: Laboratory of Robot Mechatronics Dept of Industrial Engineering
Università degli Studi di Roma Tor Vergata (Italy)

doi: https://dx.doi.org/10.7358/elem-2021-0102-cecc
marco.ceccarelli@uniroma2.it

Abstract

This illustration-based paper presents and account of Italian History on the collections
mechanism models that were used and still can be used in design, teaching, and research
activities not only on research and development of mechanical systems. A conceptual
procedure is outlined for the development and use of mechanism models mainly at
reduced scaled size. Main Italian collections of mechanism models are introduced with
their historical values and current status. Those examples are reported also to show the
value of Cultural Heritage that mechanism models and corresponding developments may
have as worthful for preservation and understanding of past achievements in mechanism
design and its application even in other frames.

Keywords: history of mechanisms; history of mechanical engineering; Italian history
of MMS teaching; Italian collections of mechanism models; mechanism models.

Introduction

Modeling and models have been and still are used as basis for activity in
acquiring knowledge and implementing results in design and operation of
systems in general and more specifically in machines. The study of modeling
and models from the historical point of view is generally not approached
with adequate attention and in fact specific historical investigations are
reported in the literature referring to their evolution but only simple
comments are indicated on specific modeling and consequent design solu-
tions only for those machines that had a significant impact on technological

https://www.ledonline.it/elementa
https://dx.doi.org/10.7358/elem-2021-0102-cecc


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

116

and social developments. Even in the context of the history of machines
referring to mechanics teaching and machine design, modeling models are
not mentioned as necessary tools for the introduction and explanation of
the fundamental concepts for training and for practical issues in design and
operation of functional characteristics of machines and mechanisms, so
much so that in historical studies models are very rarely mentioned with
such a characterization and/or aim, even if only for didactic purposes.

However, sometimes, the History of Science and Technology is also
explained by using short mention to models such as in encyclopedic works,
like for example in Capocaccia (1973) and Singer et al. (2012), and in
specific works in conferences and journals, like for example in papers at the
HHM symposia like Zhang and Ceccarelli (2019), as well as in teaching
activities with some entertainment purposes, as for example with LEGO
packages (LEGO, 2019). Some specific attention is addressed to models
of mechanisms when their historical values are considered for museum
exhibitions and historical temporary shows as an attraction to past devel-
opments, as outlined for example in Ceccarelli (2011, 2013 and 2016).

The history of teaching in Italy referring to mechanism design can
be outlined looking at the developments in academic sites where machine
mechanics was/is taught, as for example in Ceccarelli (2014b). The history
of this specific historical development is often attached with an attention to
individual figures, who used models on personal basis and experience in each
teaching academic frame and therefore, it is difficult to get an overview that
the author has partially attempted in the reference Ceccarelli (2016). In the
teaching of design and functionality of mechanisms but also in the analysis
and definition of the mechanical structures of machines and systems, today
in mechatronics domain, the use of modeling and models can be refreshed
of particular importance as it can be recognized in the didactic texts where
formulations and mathematical modeling as well as calculation procedures
for analysis and design are based on graphical schemes that can be also of
a virtual nature requiring very often to be validated by models of a phys-
ical nature, even in prototype form. In this work an attempt is presented
following a previous work in Ceccarelli (2020) to combine an historical
study of the teaching of machine mechanics in Italy with the history of the
use of models not only for teaching but also for other related activities.

1. Mechanism models

A mechanism is defined in the IFToMM terminology (IFToMM, 2003),
as “Constrained system of bodies designed to convert motions of, and

https://www.ledonline.it/elementa


A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

117

forces on, one or several bodies into motions of, and forces on, the
remaining bodies”. From the didactic point of view in many texts, such
as Lopez-Cajùn and Ceccarelli (2013), and Uicker et al. (2017), a mecha-
nism is recognized as a set of rigid bodies or links connected to each other
with the aim of converting the mechanical energy input at a different level
on an output link. Therefore, the purpose of a mechanism is identified
in motion transmission capacity and force transmission capacity with
the characteristics of motion generator and action generator, respectively,
using the output link according to the characteristic imposed at the input.
Thus, in general a mechanism can be considered a key component in a
machine design because of its function in converting mechanical energy
to a proper level for machine operation as also recognized in Ceccarelli
(2018).

Consequently, a mechanism model is represented with a schema-
tization of the structure and its functions with graphical representa-
tions and/or mathematical modeling that can be useful for analysis
and simulation of operation and performance in carrying out the task
for which the mechanism is designed and then applied. A model is
understood as a simplified representation of a system and in the case
of a mechanical design it is an ideal representation of the mechanism
structure preserving the main mechanical characteristics, as indicated in
Ceccarelli (2020).

Considering the above-mentioned understanding for a mechanism
model, it is also possible to recognize the modelling of a mechanism useful
not only for design purposes but also for explaining the functioning with
the peculiar operation performance. Indeed, a mechanism model can be
elaborated for design, simulation and exhibition purposes with representa-
tions that today span from virtual solutions in computer-oriented software
packages to scaled simplified mechanical constructions up to well defined
prototypes or demonstrators, even referring to the same design as an evolu-
tion of the definition of the solution.

An example of a model of a modern mechanism is illustrated in Fig. 1
referring to a mechanical design of LARMbot arm for humanoids (Russo
& Ceccarelli, 2018; Fort, Ceccarelli, & Laribi, 2022) in which the model is
represented as a kinematic diagram in Fig. 1a, as a CAD solution in Fig. 1b
and with a lab prototype in Fig. 1c. The kinematic model is aimed both
to explain the design structure and basic parameters of the conceived solu-
tion, the CAD design is used to define the details of the mechanical design
and to analyze the feasibility of its operation, and the prototype is used
for design validation and testing the operation performance, with activity
spanning from teaching to design up exhibition.

https://www.ledonline.it/elementa


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

118

(a)

(c)(b)

Figure 1. – Example of models for a mechanism solution
of a humanoid arm (Russo & Ceccarelli, 2018; Fort, Ceccarelli, & Laribi, 2022):
(a) kinematic model for design algorithms; (b) CAD model for mechanical design

and simulation; (c) a lab prototype for testing.

https://www.ledonline.it/elementa


A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

119

As mentioned above, in general, mechanism models are aimed and included
in a variety of activities for teaching, study, research, design, demonstrative
illustrations and presentations, simulation, validation operation characteri-
zation, experimental check, and even promotion and market exhibition.
They are used not only for developing mechanical systems, but even as
means or part of systems in activities in other disciplines, with similar aims
or complementary purposes as for example indicated in Ceccarelli (2012)
referring to service applications.

Today mechanism models can be developed as sketches or drawings
(by hand or by computer-graphics tools), mechanical constructions either
in scaled sizes or prototype structures, and virtual computer-based designs
as based on different type of software and visualization with or without
human interaction. Figure 2 outlines the evolution of mechanism models
from historical viewpoints looking at technical constructions as linked to
achievements and technological means (Ceccarelli, 2020).

Figure 2. – A timeline of conceptual evolution of mechanism models (Ceccarelli, 2020).

In Figure 2 the first level of a model refers to a graphical representation in the
form of a drawing that since in Antiquity it has been elaborated as drawing
schemes containing lot of details. Still today the first ideas are sketched with
drawings (either by hand or by graphics software) that can be used as first
step of an activity either in explaining or in designing mechanical systems or
in developing concepts and solutions. A graphical drawing model can have
different formats as well as different levels of accuracy, not only in terms
of graphical representation and it is used in many disciplines other than
in mechanical design. Over the time those drawing models have evolved
from pure line abstraction to naturalistic representation towards technical
synthetic standardized drawing languages (see for example isometric views
and cross-sections with ruled color for material and lines), as for example
referring to gear designs in Ceccarelli and Cigola (2012).

https://www.ledonline.it/elementa


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

120

The second level in Figure 2 named as “model” stresses the modelling
as a mechanical model that can lead to a prototype solution for a machine
design or an experiment whose phenomenon is to be investigated. Histori-
cally for long time mainly during the growing of Science and Technology,
model constructions were widely used before proceeding to further activi-
ties and, after last decades of the success of Informatics today they have
regained significance for a physical experience, mainly with prototypes
with full features that are used before final constructions of machine prod-
ucts. in addition, a mechanical model can be formulated with a mathema-
tization that can give highlight of the mechanical characteristics and can
be further used both for reiteration in design and teaching explanations of
parameters in design and operation issues.

A prototype as a third level model in Figure 2, is considered a full
solution of a mechanical solution and likewise it can be developed in
reduced scale yet. A protype model is understood as a tentative design for
a final product and it is often the model by which the design process and
the operation performance are validated without having the full products
in all its details or manufacturing accuracy, before entering in the market
or in approved invention.

Since constructions of mechanical models and prototypes require
lot of efforts both in manufacturing and cost, the advent of Computer
Science provided alternatives with the fourth level of virtual designs
that are developed, operated, and tested with different level of virtuality
from simple CAD solutions up to haptic-sensed 3D systems. The virtual
models are today extensively used but they can be still developed after
an activity which is based on previous levels of modelling, including
even a first drawing model, that in last decades was somehow ignored
although necessary and indeed worked out. The level of virtual modelling
in Figure 2 emphasizes not only the deepening of functionality analysis
using models even for final design products but also aspects concerning
with the durability and economic convenience of models including
multidisciplinary and integration for different purposes in study, design,
and teaching.

The today virtual models are used also to represent the other type
of models as an expression of their interesting contents not only in the
Science and Technology but also for the History of Mechanical Engineering
with a value of Cultural Heritage when design formulation (graphical or
mathematical representations) and products are worthful to be preserved,
although not completely preserved in the original solutions, as means to
show the historical evolution of knowledge and to stimulate inspiration for
further developments.

https://www.ledonline.it/elementa


A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

121

Mechanism models have been and are still developed in different
formats as above indicated in Figure 2 for different aims and frames of
applications for activities in teaching, analysis, design, experimental activity
and historical investigations with still a key role not only for mechanical
systems, but even as means or part of systems in other disciplines. The
example in Figure 1 illustrates the still current interest in the practice of
model developments in the different forms and formats, as referring to the
very modern domain of Robotics.

2. Italian collections of mechanical models

Examples based on illustrations are discussed below with the aim of
showing the characteristics of the models and of the modeling introduced
above in the context of the Italian historical panorama with the relative
peculiarities.

Since ancient times, the analysis and design of mechanisms was
carried out using examples and models to define characteristics and solu-
tions suited to required tasks. Probably also scale models with perishable
materials were used, which in fact have not reached us, but which have been
illustrated and discussed in treatises or even represented in artistic works.
Figure 3 shows an example from the work of Archimedes (ca. 287-212 BC)
of the third century BC. relating to the schematic of the functioning of the
machines with the basic conceptual principle recognized in the mechanics
of the lever (Ceccarelli, 2014b). Figure 3a shows the graphic representation
reconstructed during the Renaissance as from the work by Guidubaldo
Del Monte (1577) as the re-edition/discover of the Archimedes work
(Commandino, 1558) with an explanation of a text and a synthetic repre-
sentation of the mechanism, whereas Figure 3b shows the scheme still
synthetic but for a mechanical study for the purposes of a formulation
for analysis and design due to Galilei in his explanations during the first
academic lectures on machines of his course held in 1593-98 in Padua
(Galilei, 1964; Ceccarelli, 2006). In this figure it is evident the formulation
of the model in terms of graphic design coming from an ancient text that
could probably have been accompanied by a graphic scheme, but enriched
with the characteristics of an essentially graphic modeling for the char-
acteristics of explanation and design of the functionality of the machine
to which it refers or to the lever mechanism A. D. for a marble cutting
machine with the characteristic of being illustrative in the main mecha-
nisms and with a publicity purpose, even if it was found on the surface of a
sarcophagus near the city of Hierapolis (currently in Turkey) as the tomb of

https://www.ledonline.it/elementa


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

122

Marcus Aurelius Ammianos, a local miller. In this model of an artistic type
as an archaeological finding, the informative and explanatory purposes can
be noted with emphasis, although the design features are not detailed also
in order not to allow readers to reproduce a machine with high techno-
logical value that can be considered of even economic value, not indifferent
for the family of the person housed in the sarcophagus.

 (a) (b)

Figure 3. – The lever model by Galilei (1964):
(a) a natural description model; (b) a kinematic diagram model.

(a)

(b)

Figure 4. – Bas-relief representing the Hierapolis saw (Rossi, Russo, & Russo, 2009):
(a) the archeological finding; (b) a mechanical model.

https://www.ledonline.it/elementa


A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

123

Figure 4b shows a modern mechanical model of the marble cutting
machine formulated with a CAD elaboration with the clear interpretative
intention not only of the archaeological bas-relief of Figure 4a, but also of
the functionality of the machine, highlighting the main elements recogniz-
able in the hydraulic turbine as a source of energy and in the slider-crank
mechanism that guides the saw in the operation against the marble. This
example highlights that already in ancient times the modeling of machines
and mechanisms was used for various purposes, that is, popularization
and commercial and social advertising. It should be noted that the CAD
model of Figure 4b can be used, as indeed it with various solutions that can
be found in websites and museum exhibitions, for a virtual model with
animation of the operation of the entire machine, with emphasis on the
kinematics and the role of the fundamental of slider-crank mechanism.
Figure 4a (Rossi, Russo, & Russo, 2009) shows an example of a model in a
marble bas-relief of the third century.

The explanatory purpose of models of mechanisms with content of
cultural heritage value with today’s attention can be seen in the mechanical
model of Figure 5 of the Roman catapult. Figure 5a shows the graphic
representation reconstructed during the Renaissance in the work of Fra
Giocondo (1433-1515) for the princeps re-edition (Fra’ Giocondo, 1511)
of the treatise De Architettura by Vitruvius (80-15 BC) in which the model
of the war machine structure also explains how machine works as based on
the mechanism consisting of two levers with elastic joints connected by the
launching cable, also with a brief explanation text. Figure 5b shows a scale
wooden model exhibited at the Museum of Roman Civilization in Rome
(2010) with a clear explanatory purpose of the structure both in functional
aspects referring to the mechanisms as in the constructional peculiarities
with assembly of parts that the Roman legionaries could find in the field
during the war campaigns.

Another significant reference referring to the modeling in Antiquity
with reconstructions in the Renaissance and beyond, can be considered
the work of Vitruvius (80-15 BC), whose specific studies on machines and
mechanisms in liber X were then rediscovered during the Renaissance and
republished also with sets of figures and graphic models resulting from
interpretations of the text and the direct experience of the authors of the
reproductions with machine designs that have been a reference for a long
time both at a technical and historiographic level, as discussed in Cigola
and Ceccarelli (2016). This last aspect of historiographical attention has
recently received even greater attention with the creation of virtual models
that have been elaborated and exhibited, also with scenic animations of
various scenography in various occasions and occasions, such as the virtual

https://www.ledonline.it/elementa


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

124

exhibition of Vitruvian machines linked to Leonardo da Vinci in 2019 in
the Malatesta palace in Fano, the birthplace of Vitruvius.

Actually todays, virtual models even with 3D views and animation
are extensively used mainly in exhibitions within museums or events
showing past design of machines and mechanisms with aim to show the
functionality of those past machines with cultural heritage values but also
with modern concepts for design and functionality.

(a)

(b)

Figure 5. – Ancient Roman repeating catapult: (a) a mechanical scheme, by Fra’ Giocondo
(1511); (b) a reconstruction in the Museum of Roman Culture in Rome (2010).

https://www.ledonline.it/elementa


A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

125

 (a) (b)

Figure 6. – Models of the Archimedes pump: (a) graphic diagram of the structure
and functioning of the screw (Galilei, 1964); (b) mechanical model

of 17th century in Florence Museum (Miniati, 1991).

Figure 6, referring to the Archimedes pump for lifting water as an example
of the experimental mechanics that was established since the 17th century,
shows how mechanical models were used for didactic and experimental
purposes. Figure 6a shows a graphic model again from Galilei’s lessons with
a graphical representations as traditional means for a long time in the study
of the functioning of machines and mechanisms while Figure 6b (Miniati,
1991), shows the mechanical model built for research but also used in
teaching for more than a century, in the form that today is preserved at
the museum of the history of science in Florence having also acquired a
character of historical value and cultural heritage of science and technology.
In the mechanical model of Figure 6b it is worth noting the accuracy of the
mechanical construction aimed at representing the main elements for the
functionality of the mechanism with which the screw performs the function
of water lifting pump according to the mechanics and the representative
scheme of Figure 6a. This link between mechanical models and graphical
models is still essentially based on the modeling of the design and func-
tional characteristics useful not only for the analysis of the functioning but
also for the design and use of the examined mechanism. Therefore, it can
be recognized that one type of model completes the other and vice versa.

The use of graphic models has been persistent for a long time and
of practical utility especially in the technical-scientific literature as in the
didactic one with characteristics still considered necessary today both in the
didactic aspects and in the design formulations. Already in the Renaissance

https://www.ledonline.it/elementa


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

126

it can be thought that this graphic modeling was flanked by mechanical
models in scale which, however, have not come down to us not only for
their limited purpose in terms of use and validation of concepts at the time
of design and restricted teaching practice, but also and above all for having
probably been built with perishable materials such as wood.

Subsequently, this didactic-demonstrative purpose of graphic models
of the machines had its success in the Theatrum Machinarum in the form
of catalogs of machines in which the structures of the machines are repre-
sented with a text accompanying as a description of the functionality and
construction peculiarities. This approach can be traced historically starting
from the manual by Francesco di Giorgio Martini (1439-1502) (Ceccarelli
& Molari, 2020), up to the first printing of a real manual of the machines
by Agostino Ramelli (1588). Figure 7 shows an example of such modeling
from the Ramelli catalog (1588) with pedagogical purposes for a wide
audience, also with the intention of attracting possible commitment for
the design and construction of the represented and new machines. This
didactic-illustrative purpose has developed since the first manuals of
machines by Francesco di Giorgio of the early Renaissance up to the elabo-
ration of complex catalogs in the form of the Theatrum Machinarum and
finally also in specific chapters of the didactic texts and reports of research
activities and design during the, 19th century during the developments of
the Industrial Revolution.

Figure 7. – Example of graphic modeling of mechanisms in machines typical
of Theatrum Machinarum from the work of Agostino Ramelli in 1588.

https://www.ledonline.it/elementa


A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

127

During the development of the Industrial Revolution these catalogs special-
ized in the representation of graphic models of mechanisms within treatises
further developed in technical manuals among which the first European
(Italian) manual can be ascribed to the work of Giuseppe Antonio Borgnis
(1781-1863). The example of Figure 8 shows the modeling of the mecha-
nisms with the aim of explaining a classification of the structural and func-
tional possibilities of the various types of mechanisms.

Figure 8. – Graphic modeling of mechanisms for a classification
from the work of Borgnis (1823).

https://www.ledonline.it/elementa


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

128

These aims for design and teaching activities have given rise to a specific
literature and also to a research aimed at discovering unitary principles in
the variety of mechanisms according to the various types also with the help
of small scale models that have seen full success with the production of
modeling designed by Franz Reuleaux (1829-1905) and produced by the
Voigt company (following a well-established tradition in Germany, even if
it also existed in other European countries, including in the states of frag-
mented Italy) with planetary circulation (Kerle, Mauersberger, & Ceccarelli,
2011), which in fact it has also reached the engineering schools in Italy.

In particular, in Italy this activity has seen a production of specific
literature since the first courses dedicated to the training of mechanical
engineers at the University of Turin which later became Polytechnic of
Turin with Professor Carlo Ignazio Giulio (1803-1859) with his work that
follwed didactic study by Gaspard Monge (1747-1818) further developed
by Robert Willis (1800-1875) and continued throughout the nineteenth
century until reaching the work of Francesco Masi (1852-1944) (Cecca-
relli, 2010) at the University of Bologna with its encyclopedic treatise
The theory of mechanisms of 1897 in which the modeling of mechanisms
is treated not only on a graphic level but also on an analytical-formulistic
level as represented in the example of Figure 9.

Figure 9. – Example of graphic-analytical models of mechanisms
from the work of Francesco Masi in Bologna at the end of the 19th century.

https://www.ledonline.it/elementa


A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

129

In Figure 9 it is to note how the mechanism model with its graphic drawing
is used to identify a mathematical model with a innovative formulation,
that can be useful both for analysis and design purposes, as today is imple-
mented with more advance algorithm of informatic expert systems.

This development of graphic models for analytical formulations with
the purpose of analyzing and teaching the functionality of the mechanisms
were also accompanied by products of various types of physical-mechanical
models, both in scale with emulation of Voigt models and models specifi-
cally designed by the Italian teachers.

Figure 10 shows examples of those physical-mechanical models which
were produced starting from the end of the, 19th century up to the 60s of
the, 20th centuries with evident didactic purposes in courses dedicated to
the study of kinematics and design of mechanisms for machines even with
complex structures. Figure 10 shows as an example of the dissemination
throughout the national level models preserved in several Italian academic
institutions with mechanical construction structures respectively in metal,
plastic, wood, and combination of materials to represent as such modeling
also for didactic purposes has been produced with a great variety of solu-
tions.

In the, 1980-90s of the past century, the advent of computers and
related computerized modeling technologies have also produced a bursting
development of virtual models that are still used today in courses to explain
the structures of mechanisms and their functionality with dedicated algo-
rithms for the virtual simulation of their performance and numerical repre-
sentation as a characterization of the principles and solutions proposed and
further developable for even innovative designs. Such virtual models are
frequently also used in other fields, such as those indicated in Figures 4-6
for museum exhibition purposes and preservation of contents of technical-
cultural heritage.

Subsequently, at the beginning of this century didactic techniques for
the study of mechanisms and machines were developed that combine the
various types of modeling described above, i.e. graphic, physical-mechan-
ical, computerized virtual ones, in such a way that a student in training
for not only mechanical engineering of machines with mechatronic solu-
tions can also appreciate the structure and mechanical functionality typical
of man-machine and machine-machine interaction and integration with
further systems from other disciplines that are now essential in the modern
mechatronic structure of a machine and a mechanism when combined
with various types of drives, control systems and sensorization that are
necessary for the regulation of the machines according to the applications
to which they are dedicated and designed.

https://www.ledonline.it/elementa


130

(a) (b)

(c)

(e)

(d)

Figure 10. – Examples of physical-mechanical models of mechanisms for didactic purposes
in the 20th century at: (a) Politecnico di Torino; (b) Politecnico di Milano;
(c) University of Bologna; (d) University of Rome; (e) University of Palermo.



A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

131

Although today the teaching and design techniques are based on computer-
assisted modeling and therefore based on a mathematical and simulation
modeling, the realization of physical-mechanical models is once again
considered necessary and fundamental for a rational and efficient training
to develop adequate knowledge and awareness of the problems of the solu-
tions that an engineer must face for the development and management of
mechanisms and machines with a mechatronic structure real designs for
correct and efficient operation, as shown in the example of Figure 1.

Conclusions

Mechanism models have paid and still pay an important role in explaining
and validating machine design concepts and operation performance in
teaching, research and technological transfer, even in publicity to the
public. An historical evolution is presented looking at main features of
model categories in drawings, mechanical models, protypes, and virtual
solutions. Italian collections are introduced as from main Italian univer-
sity sites with an eye from the very past up todays solutions with the aim
of recognizing an important contribution of using mechanism models in
the development of machine designs and the science of mechanisms over
time.

References

Capocaccia, A. (1973). History of technique: From prehistory to the year one thou-
sand. UTET (in Italian).

Ceccarelli, M. (2004). Classifications of mechanisms over time. In Proceedings of
international Symposium on history of machines and mechanisms – HMM
2004 (pp. 285-302). Kluwer.

Ceccarelli, M. (2006). Early TMM in Le Mecaniche by Galileo Galilei in 1593.
Mechanism and Machine Theory, 41(12), 1401-1406.

Ceccarelli, M. (2008). Renaissance of machines in Italy: From Brunelleschi to
Galilei through Francesco di Giorgio and Leonardo. Mechanism and
Machine Theory, 43(12), 1530-1542.

Ceccarelli, M. (2010). Francesco Masi (1852-1944). In M. Ceccarelli (Ed.),
Distinguished figures in mechanism and machine science: Their contribu-
tions and legacies. Part 2 (pp. 141-162). Springer Nature Switzerland AG
(History of Machines and Machine Science, 7). doi: 10.1007/978-90-481-
2346-9_8. ISBN: 978-90-481-2345-2

https://www.ledonline.it/elementa


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

132

Ceccarelli, M. (2011). Mechanism designs of cultural heritage. In 13th world
Congress in mechanism and machine science IFToMM (Paper no. A21-393).
Guanajuato.

Ceccarelli, M. (2012). An outline of history of mechanism design in servicing
science. In Physics, astronomy and engineering: Critical problems in the
history of science and society (pp. 1-10). Scientia Socialis, UAB.

Ceccarelli, M. (2013). Considerations on mechanism designs as suitable for
cultural heritage evaluation. Advances in Historical Studies, 2(4), 175.

Ceccarelli, M. (2014a). Contributions of Archimedes on mechanics and design of
mechanisms. Mechanism and Machine Theory, 72, 86-93.

Ceccarelli, M. (2014b). Short history of mechanics of machinery in Italy. In
Proceedings of 5th Italian Conference on history of engineering (pp. 87-102).
Cuzzolin Editore (in Italian).

Ceccarelli, M. (2015). Italian landmarks in the history of MMS. In eProceedings
of 2015 IFToMM Workshop on history of mechanism and machine science,
St.-Petersburg, May 26-28, 2015 (Paper no. 20-03).

Ceccarelli, M. (2016). Figures and achievements in MMS as landmarks in history
of MMS for inspiration of IFToMM activity. Mechanism and Machine
Theory, 105, 529-539. doi: 10.1016/j.mechmachtheory.2016.07.012

Ceccarelli, M. (2018). Innovation challenges for mechanism design. Mechanism
and Machine Theory, 125, 94-100.

Ceccarelli, M. (2020). Models of mechanisms for teaching and experimental
activity. In Atti del VIII Convegno annuale Società Italiana degli Storici della
Fisica e dell’Astronomia (pp. 255-266). Pavia University Press. ISBN: 978-
88-6952-7

Ceccarelli, M., & Cigola, M. (2012). On the evolution of graphical representation
of gears. In Mechanisms, transmissions and applications (pp. 3-14). Springer.

Ceccarelli, M., & Molari, P. G. (2020). Francesco di Giorgio (1439-1501). In
M.  Ceccarelli & Y. Fang (Eds.), Distinguished figures in mechanism and
machine science: Their contributions and legacies. Part 4 (pp. 47-66). Springer
Nature Switzerland AG (History of Mechanism and Machine Science, 38).
https://doi.org/10. 1007/978-3-030-32398-1_3

Cigola, M., & Ceccarelli, M. (2016). Machine designs and drawings in renais-
sance editions of de Architectura by Marcus Vitruvius Pollio. In Essays on the
history of mechanical engineering (pp. 291-307). Springer, Cham.

Commandino, F. (1558). Archimedis Opera non nulla à Federico Commandino
Vrbinate nuper in Latinum conuersa, et commentariis illustrata… Apud Pau-
lum Manutium, Aldi f.

Del Monte, G. (1577). Mechanicorum Liber. Apud Hieronymum Concordiam,
Pisauri.

https://www.ledonline.it/elementa
doi: 10.1016/j.mechmachtheory.2016.07.012
https://doi.org/10. 1007/978-3-030-32398-1_3


A Historical Account on Italian Mechanism Models

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

133

Fort, A., Ceccarelli, M., & Laribi, M. A. (2022). Prototype and testing of
LARMbot PK arm. In J. Beran, M. Bílek, M. Václavík, & P. Žabka (Eds.),
Advances in Mechanism Design III. Proceedings of 13th international Confer-
ence on the theory of machines and mechanisms – TMM 2020, Technical
University of Liberec, Czech Republic, September 7-9, 2021 (pp. 210-219).
Springer, Cham.

Fra’ Giocondo, M. (1511). Vitruvius per Iocundum solito castigatior factus cun figu-
ris et tabula et iam legi et intelligi posuit. Giovanni Taccuino, Venezia.

Galilei, G. (1964). Le mecaniche. In F. Brunetti (A cura di), Opere di Galileo Gali-
lei. UTET.

IFToMM (2003). Mechanism and Machine Theory, 38(7-10). Special Issue: Stand-
ardization and terminology.

Kerle, H., Mauersberger, K., & Ceccarelli, M. (2011). Historical remarks on past
model collections of machines and mechanisms in Europe. In 13th world
Congress in mechanism and machine science IFToMM (Paper no. A21-279).
Guanajuato.

LEGO (2019). Lego education. https://education.lego.com/en-gb
Lopez-Cajùn, C. S., & Ceccarelli, M. (2013). Mechanisms: Fundamentals of

kinematics for design and optimization of machinery (2nd ed.). Trillas (in
Spanish).

Miniati, M. (Ed.). (1991). Catalogue of Florence Museum of History of Science. Giunti.
Museo della Civiltà Romana (2009-2010). Exhibition “Machina. Tecnologia del -

l’An  tica Roma”, December 23, 2009 - April 5, 2010.
Ramelli, A. (1588). Le diverse et artificiose machine del capitano Agostino Ramelli

dal ponte della Tresia… nelle quali si contengono varii et industriosi movi-
menti… composte in lingua Italiana et Francese. A Parigi: in casa del’autore,
cõ privilegio del re.

Rossi, C., Russo, F., & Russo, F. (2009). Ancient engineers, & inventions. Springer.
Russo, M., & Ceccarelli, M. (2018). Design and simulation of a parallel-serial

LARMbot arm. In I. Doroftei et al. (Eds.), New advances in mechanism
and machine science. Proceedings of SYROM 2017 (pp. 379-386). Springer,
Cham. http://doi.org/10.1007/978-3-3.19-79111-1_38

Singer, C., et al. (Eds.). (2012). History of technology, Vol. 2. Bollati Boringhieri
(in Italian).

Uicker, J. J., Pennock, G. R., & Shigley, J. E. (2017). Theory of machines and
mechanisms. Oxford University Press.

Zhang, B., & Ceccarelli, M. (Eds.). (2019). Explorations in the history amd heritage
of machines and mechanism. Proceedings of HMM 2018. Springer Nature
Switzerland AG.

https://www.ledonline.it/elementa
http://doi.org/10.1007/978-3-3.19-79111-1_38


Marco Ceccarelli

Elementa. Intersections between Philosophy, Epistemology and Empirical Perspectives – 1 (2021) 1-2
https://www.ledonline.it/elementa

134

Riassunto

Il presente contributo presenta e racconta la storia italiana sulla collezione dei model-
li meccanici che sono stati utilizzati e possono ancora essere utilizzati nelle attività di
progettazione, insegnamento e ricerca, non solo circoscritti alla ricerca e allo sviluppo di
sistemi meccanici. Sono presentate le principali collezioni italiane, con i loro valori stori-
ci e il loro stato attuale. Questi esempi sono riportati anche e soprattutto per dimostrare il
valore del Patrimonio Culturale che questi modelli e gli sviluppi corrispondenti possono
avere, utili per la conservazione e la comprensione dei risultati del passato nella progetta-
zione e la loro applicazione anche in altri contesti.

Copyright (©) 2021 Marco Ceccarelli
Editorial format and graphical layout: copyright (©) LED Edizioni Universitarie

 This work is licensed under a Creative Commons
Attribution-NonCommercial-NoDerivatives 4.0 International License.

How to cite this paper:
Ceccarelli, M. (2021). A historical account on Italian mechanism model. Elementa.
Intersections between Philosophy, Epistemology and Empirical Perspectives, 1(1-2), 115-134.
doi: https://dx.doi.org/10.7358/elem-2021-0102-cecc

https://www.ledonline.it/elementa
https://dx.doi.org/10.7358/elem-2021-0102-cecc

	Elementa_1-2021-1-2_00b_Sommario.pdf
	Editorial
	Pierpaolo Limone

	First Section
	The Vagaries of the Superego
	Slavoj Žižek
	Nature and Pandemic

	Ricardo Espinoza Lolas
	Mask and Otherness
between Recognition and Concealment: Notes on the Self and the You

	Paolo Ponzio
	“Liquid” Identity and Otherness
in the Phenomenon of Religious
Alienation: The Loss of Critical
Thinking and the “Barter” of the Self in the System of Communion

	Daniela Savino
	The Sexistential Vulnerability of Bodies in Contact in the Philosophy
of Jean-Luc Nancy

	Francesca R. Recchia Luciani

	Second Section
	Universal Design for Learning
and Inclusive Teaching: Future
Perspectives
	Martina Rossi
	A Historical Account on Italian
Mechanism Models

	Marco Ceccarelli
	Cyberfeminism: A Relationship
between Cyberspace, Technology,
and the Internet

	Giusi Antonia Toto 1 - Alessia Scarinci 2
	Super-Ego after Freud: A Lesson
not to Be Forgotten

	Luigi Traetta 1 - Federica Doronzo 2
	Functioning of Declarative Memory: Intersection between Neuropsychology and Mathematics

	Federica Doronzo 1 - Gianvito Calabrese 2
	Peer Tutoring and Scaffolding
Principle for Inclusive Teaching

	Giuliana Nardacchione - Guendalina Peconio
