FORECASTING EQUITY INDEX VOLATILITY: EMPIRICAL EVIDENCE FROM JAPAN,
UK AND USA DATA





 Divine N.
Obodoechi1

 Anthony Orji2

 Onyinye I.
Anthony-Orji3+



1,2,3Department of Economics, University of Nigeria, Nsukka, Nigeria









(+ Corresponding author)

 ABSTRACT

Article History
Received: 17 September 2018
Revised: 22 October 2018
Accepted: 27 November 2018
Published: 20 December 2018



Keywords
Equity market
Volatility
ARCH
GARCH
EGARCH.


JEL Classification:
C53, C58, E17, E44, E47, G17.




Using non-linear models to forecast volatility for three equity index samples, this study
examines weekly returns of three indices; Dow Jones Industrial index, FTSE 100 index,
and Nikkei 225 index. The sample covers a twenty year sample period. The study
employs an in sample and out of sample volatility forecast using standard symmetric
loss functions in order to identify an appropriate model that best forecast volatility.
Using the mean error (ME), root mean square error (RMSE), mean absolute error
(MAE), and mean absolute percentage error (MAPE), the study finds the EGARCH
model to outperform the ARCH, and GARCH model in forecasting volatility.



Contribution/Originality: This is among the first studies that found EGARCH model to outperform the ARCH,

and GARCH model in forecasting volatility using a combination of Japan, UK and US data.



1. INTRODUCTION

Modelling and forecasting volatility has been the subject of most economists, financial experts, researchers,

financial advisors and economic policy makers over the past three decades (Boguth et al., 2011; Constantinides et al.,

2013; Bollerslev et al., 2016; Cipollini et al., 2017; Bollerslev et al., 2018). Volatility forecasting plays a vital role in

the black and Scholes (BS) option pricing theory, providing key function in pricing options in the financial market.

In the Black and Scholes (BS) model, four parameters are observable in this model, with volatility being the only

parameter that is unobservable. This has given Derivative traders and financial dealers difficulties as to how to

observe or predict this parameter accurately. Regulators, Practioners and Academics have embraced Value at Risk

and many view Value at Risk as a vital component of current best practice in risk management. One of the most

common methods of parametric approach in Value at risk requires calculating the volatility of a return series.

In this work, we explore a number of models ranging from the linear models to the more sophisticated

nonlinear models, on weekly volatility of three equity index from three different indices and they include; the Dow

Jones Industrial index, FTSE 100 index and the Nikkei 225 index. The mean square error (MSE), root mean square

Financial Risk and Management Reviews
2018 Vol. 4, No. 1, pp. 1-23
ISSN(e): 2411-6408
ISSN(p): 2412-3404
DOI: 10.18488/journal.89.2018.41.1.23
© 2018 Conscientia Beam. All Rights Reserved.















https://orcid.org/0000-0001-7873-1856
http://www.orcid.org/0000-0003-4032-7051
https://orcid.org/0000-0002-0603-7264
https://www.doi.org/10.18488/journal.89.2018.41.1.23


Financial Risk and Management Reviews, 2018, 4(1): 1-23




2

© 2018 Conscientia Beam. All Rights Reserved.

error (RMSE), mean absolute percentage error (MAPE) and the mean absolute error (MAE) will be employed later

in this work to evaluate the performance of the various models as to how they forecast volatility.



Why Study Volatility?

Volatility plays a crucial role in financial markets and hence it is important to understand this concept, which is

why we model volatility using the non-linear models in this work. Volatility quantifies risk and thus plays a major

role in modern finance. Black and Scholes (1973) evaluated volatility using the option pricing formula. It shows the

relationship between an option’s price and several other factors, including volatility of the underlying asset’s price.

Ye-Hsiang (1993) argued that in order to derive an option’s price from the Black and Scholes formula, the

option is replicated by a portfolio consisting of the underlying asset and a risk free bond. In the Black and Scholes

formula, different expectation of volatility will result in a different option price from this formula. This allows for an

arbitrage opportunity if the option’s market price is different from the initial cost of the portfolio. Thus an option

trader is able to make profit by making superior forecasts of future volatility. With the vast portion of the financial

markets so dependent on the volatility behaviour, there are obvious benefits to understanding volatility better.

Improved forecast would allow traders to price their options more accurately. Using more frequent data provide

better estimation of volatility.

Day and Lewis (1992) proved that volatility can be predictable using the ARCH models and that volatility is

entirely captured by implied volatility within the Black and Scholes model. The reason for this is that

Autoregressive models are still not entirely exploited by the market. However, Kuwahara and Marsh (1992)  argued

that the conditional volatility derived from GARCH and EGARCH models enable researchers to obtain option

values which are very close to those that could be observed by the market. This suggests that conditional volatility

cannot be used as an additional source of information, since it can be observed in the implied values. According to

Michael Minnich, vice president of capital market risk advisor, Value at risk is a very important component of risk

management and also an important part of volatility forecasting.

Furthermore, modelling and forecasting volatility has been subject of interest to many academicians, portfolio

analysis’s and those involved with risk management. There has been growing interest in this area of research as a

result of the current economic crisis hitting most countries of the world. The indices of most countries are

experiencing severe downturn and hence derivative traders, academicians and portfolio managers are more concern

about this problem. The purpose of this paper then is to forecast volatility using the non-linear models and applying

the various standard symmetric loss functions to evaluate which of these models forecast volatility better.

The rest of the paper is structured as follows: section 2 presents a concise review of the various literature on

volatility. Section 3 discusses the methodology while section 4 and 5 is analyses the empirical results and conclusion

respectively.



2. LITERATURE REVIEW

Over the last two decades, there has been an increasing interest in modelling the volatility of stock market

returns (Akgiray, 1989; Dimson and Marsh, 1990; Pagan and Schwert, 1990; Boguth et al., 2011; Constantinides et

al., 2013; Bollerslev et al., 2016; Cipollini et al., 2017; Bollerslev et al., 2018). This is basically due to the highly

volatile movements of prices of stock returns in the financial market. This has led researchers into investigating the

level and stationarity of volatility over time (Day and Lewis, 1992; Tse and Tung, 1992; Figlewski et al., 1993).

Most research has been directed towards examining the accuracy of this forecast. Both linear and nonlinear models

have been applied by different researchers and each of them came out with different conclusions as regards the

accuracy of volatility forecast (Cao and Tsay, 1992; Heynen and Kat, 1994; Brailsford and Faff, 1996; Figlewski,

1997).



Financial Risk and Management Reviews, 2018, 4(1): 1-23




3

© 2018 Conscientia Beam. All Rights Reserved.

Following the outburst of the ARCH models by Engle (1982); Bollerslev (1986) and Nelson (1991) literature

surrounding its emergence has boomed since its discovery. Many researchers have come up with different views as

to how these models forecast volatility better. Such model ranges from the naive (linear models) to the more

sophisticated (nonlinear) models.  Their findings are, however by no means consistent, as their end results differ

even when the same indices and sample period are considered. This can be attributed to the manner in which the

models were evaluated and the evaluation criteria employed.  The review of literature tries to bring different

research findings, how they differ and how they are consistent with one another, but none of the findings gave exact

results, but where able to identify which of the models forecast volatility better (see for example; (Angelidis et al.,

2003; Louis and Guan, 2004; Balaban and Bayar, 2005; Mats and Viman, 2005; Palmquist and Viman, 2005; Abdul

and Shabbir, 2008)).



3. METHODOLOGY

3.1. Data set and Sample Description.

This work uses the daily closing prices of three stock market indices from 3rd April 1989 to 7th April 2009. The

investigated indices are FTSE 100 index from the UK; S&P 500 index from the USA and the Nikkei 225 index from

Japan. These indices have a continuous sequence of around 5034 observations, excluding the non-trading days such

as weekends, public holidays and other exchange closure days. Data are sourced from data stream. The FTSE 100

index comprises of 100 large firms registered in the UK, while the S&P 500 and the NIKKEI 225 comprises of 500

top rated companies and 225 top rated companies, respectively.

The entire sample for each index is divided into two subsample periods, with each representing a 10 year

period. The first subsample period is from 4th April 1989 to 2nd April 1999 with 523 trading weeks and second

subsample from 6th April 1999 to 7th April 2009 with 524 trading weeks. The Daily returns are calculated on each of

the subsample periods on each of the three indices mentioned earlier. This is done by applying the formula

represented below as thus;

                                                                       3.1.1

Where Rt denotes daily index returns, Pt denotes the closing price of the index at time t and Pt-1 refers to the

closing index price at time t-1. The ln represents the logarithm of the relative price index. The daily returns

calculated are then divided by the number of trading days in a week, with holidays excluded from the calculation to

obtain the weekly return of the various series.



3.2. ARCH Methodology

3.2.1. Testing for ARCH Effect

ARCH (Autoregressive conditional heteroskedasticity) models are designed to model and forecast conditional

variance. An indication of ARCH is that the residuals will be uncorrelated, but the squared residuals will show

autocorrelation. The later is once again tested when we consider the autocorrelation function (ACF) and the partial

autocorrelation (PACF) of the squared residuals.

Testing for ARCH effects requires us to test for a reasonable test of the null hypothesis of conditional

homoskedasticity, against the conditional heteroskedasticity. This done basically to make sure that there is no

heteroskedasticity in the ARCH model being estimated. We therefore need to apply the LM test (Lagrangian

multiplier test), using the residual series of the model to test for ARCH effects. According to Brooks (2002) the test

is one of a joint hypothesis that all q lags of the squared residuals have coefficient values that are not significantly

different from zero. If the value of the test statistic is greater than the critical value from the distribution, then



Financial Risk and Management Reviews, 2018, 4(1): 1-23




4

© 2018 Conscientia Beam. All Rights Reserved.

we reject the null hypothesis of no ARCH effects and conclude that there is a presence of ARCH effect. The lag to

implement here depends on the preferences of the researcher.



3.2.2. ARCH (p) Model Specification

ARCH

The result of the lags that proved no ARCH effect from the above section is employed to estimate in the order

of the ARCH model to be adopted.  We used the PACF of square residuals to estimate the order of the ARCH (p)

model. The form of the AR (p) model can be used as the mean equation for the ARCH type model. Other

researchers claim that the PACF of the square residuals can be useful for such applications.

The mean equation is represented as;

                                                                           3.2.1

While the conditional variance is represented as;

                                                                                             3.2.2

GARCH

Following Lamoureux and Lastrapes (1990); Walsh and Tsou (1998) a simple GARCH (1 1) will be employed

and thus there is no need to specify any higher order.



EGARCH

The same principle is applied here as above and this is done following Engle and Ng (1993) and Brooks (2002)

and thus simple EGARCH (1 1) is employed.



3.2.3. ARCH-Type Model Estimation.

The R square and the F statistics are evaluated so as to identify their importance and significance in the ARCH

model. In this particular case, we consider the mean equation only rather than the model as a whole. The R square

most of the time is meaningless and they contribute nothing to the estimation process. R square sometimes is

negative in value and such a value is irrelevant. This is obvious when the residual sum of squares is greater than the

sum of square residual in the model. The R square and the F statistics are meaningful for OLS models but

meaningless for the ARCH models.



3.2.4. Diagnostic Check

ARCH

The stationarity condition for ARCH models is checked here for the non-negativity constraints and the finite

unconditional variance. The alpha coefficients are summed to ensure they sum to less than one and this implies the

non-breach of the stationarity condition of the ARCH (p) model.



GARCH

We also checked for the restrictions of the non negativity constraint as this determine the stationarity of the

GARCH model. The restrictions most of the time are satisfied but this is checked for our model specified in the

above section.



Serial Correlation in Standardised Residuals

We checked whether the serial correlation present in the autoregressive model are removed and are also not

present in the ARCH type models. This is achieved when we tested using the ARCH LM test.



Financial Risk and Management Reviews, 2018, 4(1): 1-23




5

© 2018 Conscientia Beam. All Rights Reserved.

3.3. Forecasting

The study focuses on performing out of sample weekly volatility forecasting and each sample is split into two

sub samples. This work is consistent with those of Figlewski et al. (1993) studied the weekly return of various

return series using the linear and non linear models. Their result proved that the EGARCH model outperformed

other models when evaluated. There are basically two types of forecasting, the static and dynamic forecasting.

These forecasting types have two implications, the dynamic forecasting sets subsequent innovations to zero, while

the static forecasting extends the forward recursion through the end of the estimation sample, allowing for a series

of one step ahead forecasts of both structural model and the innovation. For simplicity, we will thus look at dynamic

forecasting generated in Eviews.



3.3.1. Dynamic Forecasting

According to Tsay (2005) the ARCH model, the one step ahead forecast of   is

=                    3.3.1

The m-step ahead forecast for  is

                                            3.3.2



Where  if



3.3.2. Out of Sample forecast

Forecasting is a very important aspect in Finance as it helps researchers and derivative traders in determining

the risk in portfolio management. In-sample forecasting, is based on parameter estimated using all data in the

sample, and it implicitly assumes parameter estimates are stable across time. In practice, time variation is a critical

issue in forecasting (Poon, 2005).

The in sample forecasting was done using the first 261 weeks to forecast volatility of the model. For the entire

indices, the first subsample was forecasted using the sample period from 1st April 1994 to 1st April to 1999,

representing the first 261 weeks.

For the second sub sample the forecasting is done using the sample period from 6th of April 2004 to 7th of April

2009, representing the first 261 weeks. The result of this will be discussed in section four.



3.3.3. Forecast Evaluation Criteria.

Various evaluation criteria are used to know how best a particular model out performs another. The mean

errors (ME), mean square error (MSE), root mean square error (RMSE), and the mean absolute error (MAE) are

the various error techniques to look at when testing performance. The ones mentioned here are employed so as to

check performance. A forecast error with mean near zero and small variance depicts the more preferred model.

Therefore the model that best forecasts volatility is taken from the criteria discussed above. The model with the

lowest value of the mean error (ME) proves to be the best forecast of volatility and the same applies to the mean

square error (MSE), the root mean square error (RMSE), and the mean absolute error (MAE). (See Poon (2005))

Mean Error (ME)

                                      3.3.3



Financial Risk and Management Reviews, 2018, 4(1): 1-23




6

© 2018 Conscientia Beam. All Rights Reserved.

Root Mean Square Error (RMSE)

                                     3.3.4

Mean Absolute Error (MAE)

                                          3.3.5

Mean Absolute Percentage Error.

                                                 3.3.6

 denotes weekly volatility forecast of the model, while  denote the in sample actual standard deviation and N

the total number of observation (number of weeks).



4. EMPIRICAL RESULTS

4.1. Data Series Statistics.


Table-4.1.1. Descriptive Statistics of return series.

 DJ-IND FTSE 100 NIKKEI 225

Sample: 1989-1999 1999-2009 1989-1999 1999-2009 1989-1999 1999-2009

Size 2517 2515 2524 2531 2469 2461

Mean 0.000576 -0.0000996 0.000441 -0.000188 -0.000286 -0.000250

Median 0.000693 0.000312 0.000530 0.000227 -0.000231 0.00000584

SD 0.008922 0.013067 0.008925 0.013402 0.014946 0.016201

Skewness -0.585097 0.025056 0.069316 -0.126501 0.343934 -0.319098

Kurtosis 9.839083 10.74865 5.302952 9.220919 7.213919 9.553287

JB-Test 5048.935 6292.118 559.7818 4087.958 1875.439 4445.475

Probability 0.000000 0.00000 0.000000 0.000000 0.000000 0.000000
        Source: Eviews’ Result Output



From table 4.1.1, the mean value in the first subsamples seems to be closer but with the exception of those of

the Nikkei 225 suggesting a negative value. In the second subsample, the mean of the various indices are all

negative with that of the FTSE 100 and Nikkei 225 relatively close. In the first subsample, the standard deviation of

Dow Jones Industrial and the FTSE 100 are quite close but that of Nikkei 225 is significantly different. The same

applies to the second subsample, but this time the standard deviation of the Nikkei 225 seems close to those of the

other indices.

The Skewness of Dow Jones Industrial in the first subsample is negative suggesting a longer left tail and a

higher peak in the middle. According to Poon (2005) the implication of this is that for a large part of the time,

financial asset returns fluctuate in a range smaller than that of a normal distribution. On the other hand, FTSE 100

and Nikkei 225 are positively skewed suggesting a longer right tail and a higher peak in the middle. In the second

subsample, Dow Jones Industrial tends to be positive, while that for FTSE 100 and Nikkei 225 is negatively

skewed. The kurtosis for all the samples are positive and in excess of 3 suggesting a flatter and thicker tail and are

very sensitive to outliers.



4.1.1. Jarque-Bera Normality Test.

This test for the normality of the asset returns of the various indices. The low p value and high value of the

Jarque-Bera statistics suggests we reject the null hypothesis of normality for all the samples. These values are lower



Financial Risk and Management Reviews, 2018, 4(1): 1-23




7

© 2018 Conscientia Beam. All Rights Reserved.

than that of the 5% level of significance and this suggests that the financial assets are not normally distributed,

hence are non normal.



4.1.2. Stationarity Test (ADF Test)

Augmented Dickey Fuller Test


Table-4.1.2. Augmented Dickey Fuller Test for all the Return Series

 DJ-Industrial FTSE 100 NIKKEI 225

Lag  1989-1999 1999-2009 1989-1999 1999-2009 1989-1999 1999-2009

0 -3.84951
(0.0000)

-4.15147
(0.000)

-3.580068
(0.0000)

-4.330746
(0.0000)

-4.074043
(0.0000)

-4.230698
(0.0000)

1 2.032284
(0.0000)

2.235980
(0.0000)

1.830214
(0.0000)

2.440101
(0.0000)

2.225083
(0.0000)

2.353054
(0.0000)

2 1.346313
(0.0000)

1.422396
(0.0000)

1.198992
(0.0000)

1.659917
(0.0000)

1.439777
(0.00000

1.607558
(0.0000)

3 0.788079
(0.0000)

0.836214
(0.0000)

0.681636
(0.0000)

0.953854
(0.0000)

0.845688
(0.0000)

0.993646
(0.0000)

4 0.371190
(0.0000)

0.410869
(0.0000)

0.342955
(0.0000)

0.520806
(0.0000)

0.412657
(0.0000)

0.526422
(0.0000)

5 0.112196
(0.0000)

0.120470
(0.0000)

0.112003
(0.0000)

0.203948
(0.0000)

0.146547
(0.0000)

0.194116
(0.00000

             Notes: values in parenthesis are p-values lower than the 1% level of significance.



The return series were tested for stationarity using 36 lags as a result of the weekly returns being employed.

According to Brooks et al. (2005) if the data are monthly, use 12 lags, if the data are quarterly, use 4 lags and so on.

But in order to make our work simple, we decided to illustrate 5 lags in the table above. Based on these, we decided

to use 36 lags being that the data are weekly. From table 4.1.2, since the ADF test statistics has p-values lower than

the 1 % level of significance, we reject the null hypothesis of unit root and conclude that there is no unit root and

hence returns series are stationary.



4.2. AR (m) Model Building

Model Identification

We used the Akaike and the Schwartz information criteria to determine the order of the model to employ. The

rejection of the null hypothesis of non stationarity makes it reasonable to proceed to the model specification.


Table-4.2.1. Akaike and Schwartz Bayesian information criteria of the first subsamples.

 Dow Jones Indus
1989-1999

Ftse 100
1989-1999

Nikkei 225
1989-1999

Lag  AIC SBIC AIC SBIC AIC SBIC

0 -6.600140* -6.597823* -6.599418 -6.597107 -5.568396 -5.566042

1 -6.599403 -6.594769 -6.605291 -6.600667* -5.567375 -5.562665

2 -6.598964 -6.592010 -6.604955 -6.598017 -5.574370* -5.567304*

3 -6.599120 -6.589845 -6.605395 -6.596141 -5.573830 -5.564405

4 -6.598522 -6.586924 -6.604755 -6.593184 -5.572675 -5.560891

5 -6.597365 -6.583443 -6.605677 -6.591787 -5.571529 -5.557382

6 -6.596421 -6.580172 -6.605632 -6.589421 -5.571612 -5.555102

7 -6.598028 -6.579452 -6.607450 -6.588918 -5.570536 -5.551661

8 -6.597738 -6.576834 -6.607472* -6.586616 -5.570540 -5.549299
         The * represents AIC or SBIC with the lowest value.



From table 4.2.1 in the first sub sample, the Akaike and the Schwartz suggest AR (0), since it represents the

value with the lowest AIC and SBIC. The PACF for the Dow Jones Indus suggest AR(1) while the information

criteria suggest AR (0), but following Akgiray (1989) he decided to choose AR(1)for his sample despite the fact that

the AIC and SBIC suggests AR(0).



Financial Risk and Management Reviews, 2018, 4(1): 1-23




8

© 2018 Conscientia Beam. All Rights Reserved.

We therefore modelled our autoregressive model based on the information criteria with the lowest value and in

some cases where the AIC suggest too many lag say AR(8), like in the Dow Jones Industrial index in the second

sample of table 4.2.2, instead we decided to choose AR(2) suggested by the SBIC. The motivation for this is that we

are trying to keep our model as parsimonious as possible and also in some researches, the SIC has proven to suggest

a better order for AR models than the AIC. See (Brooks et al., 2005).


Table-4.2.2. Akaike and Schwartz Bayesian information criteria of the Second subsample.

 Dow Jones Indus
1999-2009

Ftse 100
1999-2009

Nikkei 225
1999-2009

Lag  AIC SBIC AIC SBIC AIC SBIC

0 -5.836983 -5.834665 -5.786470 -5.784164 -5.407093* -5.404732*

1 -5.841630 -5.836992 -5.789847 -5.785234 -5.406985 -5.402263

2 -5.846672 -5.839713* -5.792963 -5.786041 -5.406392 -5.399307

3 -5.848573 -5.839291 -5.800910 -5.791677 -5.406296 -5.396846

4 -5.847438 -5.835833 -5.805403 -5.793858 -5.405245 -5.393429

5 -5.848652 -5.834720 -5.807617 -5.793759 -5.405194 -5.391010

6 -5.847546 -5.831287 -5.810867 -5.794693* -5.404694 -5.388140

7 -5.848213 -5.829625 -5.810481 -5.791991 -5.404949 -5.386024

8 -5.848694* -5.827776 -5.811791* -5.790983 -5.403813 -5.382514
The * represents AIC or SBIC with the lowest value.



4.2.1. AR (m) Model Estimation


Table-4.2.3. AR (m) model- OLS regression coefficient estimates

      Notes: figures in parenthesis are the p-values.

 DJ-Industrial  FTSE 100  NIKKEI 225

Stat/coeff 1989-
1999

1999-
2009

Stat/coeff 1989-
1999

1999-2009 Stat/coeff 1989-
1999

1999-
2009


0.000578
(0.0015)

-0.0001
(0.6524)

0.000441
(0.0227)

-0.000197
(0.3323)

-0.00029
(0.2859)

-0.0025
(0.4237)


0.019919
(0.3179)

-0.082
(0.000)

0.083857
(0.000)

-0.0667
(0.0008)

-0.00886
(0.6585)

-0.03137
(0.1198)


 -0.07676

(0.0001)
 -0.0659

(0.0009)
-0.0905
(0.000)






 -0.0993
(0.000)






 0.06595
(0.0001)






 -0.06246
(0.0018)






 -0.0647
(0.0012)



F-stat 0.9978 14.749 F-stat 17.85108 12.9849 F-stat 10.234 2.4216

R-square 0.00039 0.0116 R-square 0.00703 0.03001 R-square 0.008 0.00098

DW 1.9987 1.990 DW 1.995 1.995 DW 1.995 2.0016

Loglik 8304.05 7349.34 Loglik 8334.574 7343.22 loglik 6878.98 6652.5



4.2.2. Diagnostic Checks

From table 4.2.3, the significance of the p value and the high value of the F-statistics of most of the models

shows equations are well specified. But there are cases where the F-statistics seems not to be statistically significant

and this can be seen with low insignificant F-statistic. Insignificant F-statistics are observed in Dow Jones

Industrial index of the first subsample and the Nikkei 225 index of the second subsample. This does not matter

much as most of the other coefficients were statistically significant.

The R-square of most of the subsamples were less than 1%, except for two cases where they went above 1% to

about 3%. It was 1.1% during the second subsample of the Dow Jones Industrial index and 3% during the second



Financial Risk and Management Reviews, 2018, 4(1): 1-23




9

© 2018 Conscientia Beam. All Rights Reserved.

subsample of the FTSE 100 index. The R-squares tend to increase during the second subsamples of the various

indices, and this might be as a result of the more volatile periods (the September 11 attack of 2001 and the recent

credit crunch of the last three years).



Durbin-Watson

The Durbin-Watson statistic for all most all the models are close to 2, leading to the rejection of the null

hypothesis of no serial correlation of the residuals. This suggests that there is little evidence of serial correlation in

the models (See Brooks et al. (2005)).


Table-4.3.1. ARCH (m) Model regression coefficient parameters.

 Dow Jones Indus               FTSE 100                                Nikkei 225

Stat/coeff 1989-1999 1999-
2009

Stat/coeff 1989-
1999

1999-
2009

Stat/coeff 1989-1999 1999-2009


0.00079
(0.0000)

-0.0001
(0.6524)

0.000441
(0.0227)

-0.000197
(0.3323)

-0.00029
(0.2859)

-0.0025
(0.4237)


0.019919
(0.3179)

-0.082
(0.0000)

0.083857
(0.0000)

-0.0667
(0.0008)

-0.00886
(0.6585)

-0.03137
(0.1198)


 -0.07676

(0.0001)
 -0.0659

(0.0009)
-0.0905
(0.000)






 -0.0993
(0.0000)






 0.06595
(0.0001)






 -0.06246
(0.0018)






 -0.0647
(0.0012)



Variance
Equation

  Variance
Equation

  Variance
Equation



K 0.0000563
(0.0000)

0.000025
(0.0000)

K 0.000046
(0.0000)

0.0000203
(0.0000)

K 0.0000562
(0.0000)

0.0000826
(0.0000)

 Dow Jones Indus   FTSE 100  Nikkei 225

 1989-1999 1999-
2009

 1989-
1999

1999-
2009

 1989-1999 1999-2009


0.09212
(0.0014)

0.03579
(0.1664)

0.112736
(0.0089)

0.10295
(0.0035)

0.180006
(0.0000)

-0.000712
(0.9595)


0.150645
(0.0056)

0.12039
(0.0002)

0.147786
(0.0000)

0.130056
(0.0000)

0.131339
(0.0000)

0.19168
(0.0000)


0.042911
(0.0477)

0.127171
(0.0000)

0.15256
(0.0000)

0.15165
(0.0000)

0.11555
(0.0002)

0.159832
(0.0000)


 0.133670

(0.0000)
 0.14526

(0.0001)
0.14546
(0.0000)

0.13495
(0.0000)


 0.091687

(0.0000)
 0.14147

(0.0000)
0.10737
(0.0011)

0.19271
(0.0000)


 0.04847

(0.0201)
 0.12652

(0.0000)
0.14140
(0.0000)




 0.177484

(0.0000)
 0.053988

(0.0403)



 0.128662

(0.0000)
 0.08182

(0.0008)


Arch LM   Arch LM   Arch LM

F-Test 1.762934 1.518740 F-Test 0.995300 1.125045 F-Test 0.038590 1.538423

P-Value 0.117122 0.180530  P-Value 0.418995 0.344721 P-Value 0.999187 0.174486

R-square -0.000576 -0.00118 R-square -0.000004 -0.001327 R-square -0.00188 -0.000812

Durbin
Watson

1.95889 2.148 Durbin
Watson

1.8321 2.124 Durbin
Watson

2.0123 2.060

loglikhood 8397.664 7897.671 loglikhood 8435.413 7916.169 loglikhood 7138.604 6984.194
           Figures in parenthesis represent the p-values.



The only exception to this is the second subsample of Nikkei 225 index which shows a Durbin-Watson statistic

of 2, suggesting no autocorrelation of residuals in the model. But one should take this with a pinch of salt as

Durbin-Watson is not a perfect measure of the presence of autocorrelation in the residuals.



Financial Risk and Management Reviews, 2018, 4(1): 1-23




10

© 2018 Conscientia Beam. All Rights Reserved.

4.3. ARCH Effect

The residuals of the AR (m) models in the above section were tested for ARCH effect using the ARCH LM test.

The residuals of all the return series were all significant at 1% level of significance, indicating that there is presence

of heteroskedasticity in the residuals of the return series. This means that the autoregressive models cannot

adequately model the return of the series and this therefore means that any result will be biased and the will

produce false estimates and results. As a result of this, we resort to model the ARCH type models in order to take

care of the issue of heteroskedasticity, but this will depend upon the fact that there are no heteroskedasticity in the

model.

From table 4.3.1, significant coefficients of the variance equation can be seen in almost all the return series,

with significance at both 1% and 5% level. This is indicated by the small p-values illustrated in parenthesis. The

only exception to this is the large p-value observed in the first coefficient of the second subsample of the Nikkei 225

index. The insignificance does not matter much as majority of the other coefficients shows significance with low p-

values. The negative value of the R-square makes it impossible to estimate the value of the F-statistic for the entire

sample. R-square is negative for the entire sample; this is explained in section 3.6.3.  The log likelihood is relatively

large for the entire sample suggesting the models employed fits the data well.

According to Brooks et al. (2005) the more parameters there are in the conditional variance equation, the more

likely it is that one or more of them will have negative estimated values. This same result is observed in the second

subsample of the Nikkei 225 index where the first coefficient of the model is negative as a result of ARCH (5) being

estimated. Btu this is not the case in all circumstances even when we estimated ARCH (8) of second subsample of

Dow Jones Industrial index and that of FTSE 100 index.


Table-4.3.2. GARCH (1 1) Model Estimation.

 Dow Jones Indus               FTSE 100                                Nikkei 225
Stat/coeff 1989-1999 1999-2009 Stat/coeff 1989-1999 1999-2009 Stat/coeff 1989-1999 1999-2009


0.00062
(0.0001)

0.000342
(0.0425)

0.000497
(0.0012)

0.000275
(0.1186)

0.000304
(0.1978)

0.000337
(0.1813)

Variance
Equation

  Variance
Equation

  Variance
Equation



K  0.00000798
(0.0005)

0.00000104
(0.0130)

K  0.00000117
(0.0008)

0.00000116
(0.0017)

K  0.0000028
(0.0068)

0.0000301
(0.0001)


0.038544
(0.0010)

0.078135
(0.0000)

0.05663
(0.0000)

0.109349
(0.0000)

0.109291
(0.0000)

0.094202
(0.0000)


0.952471
(0.0000)

0.91678
(0.0000)

0.92875
(0.0000)

0.888057
(0.0000)

0.88482
(0.0000)

0.89690
(0.0000)

ARCH    ARCH    ARCH LM

F-test 0.307995 0.954119 F-test 0.950460 0.564544 F-test 0.038408 1.657808

P-Value 0.908359 0.444729 P-Value 0.447063 0.727279 P-Value 0.999196 0.103763

R-square -0.00024 -0.001142 R-square -0.000039 -0.001198 R-square -0.00156 -0.001313

DW 1.959 2.1482 DW 1.8321 2.1252 Dw 2.012 2.0598

Log
likhood

8479.762 7927.203 Log likhood 8505.963 7939.081 Log
likhood

7183.273 7021.074

Notes: Figures in parenthesis represent the p-values.



From table 4.3.2, we estimated the GARCH (1 1) model and the parameter  represents the lagged squared

residual and  the lagged conditional variance equation. Both parameters are highly statistically significant, with

low p-values significant at all levels of significance. The sum of the coefficients on the lagged squared error and

lagged conditional variance is very close to one for all samples of the return series. That for the Dow Jones

Industrial index is approximately 0.99101 and 0.99491 for both first and second subsamples respectively. The same

issue applies to the rest of the return series, where all the coefficients seem to be very close to unity. This also

implies that the shocks to the conditional variance will be highly persistent. See (Brooks et al., 2005).



Financial Risk and Management Reviews, 2018, 4(1): 1-23




11

© 2018 Conscientia Beam. All Rights Reserved.

Table-4.3.3. EGARCH (1 1) Model Estimation

                       Dow Jones Indus                                             Ftse 100                                                      Nikkei 225

Stat/coef 1989-1999 1999-2009 Stat/coef 1989-1999 1999-2009 Stat/coef 1989-1999 1999-2009

C  0.000468
(0.0032)

-0.000015
(0.9281)

C  0.000399
(0.0099)

-0.000154
(0.3761)

C  -0.000167
(0.4367)

-0.000106
(0.6637)

Varince
Eqution

  Variance
Eqution

  Variance
Equation



C (2) -0.33473
(0.0000)

-0.21708
(0.0000)

C (2) -0.16749
(0.0000)

-0.220353
(0.0000)

C (2) -0.29774
(0.000)

-0.361448
(0.0000)

C (3) 0.112528
(0.0000)

0.099973
(0.0000)

C (3) 0.089652
(0.0000)

0.104704
(0.0000)

C (3) 0.15967
(0.0000)

0.173927
(0.0000)

C (4) -0.006795
(0.0001)

-0.114367
(0.0000)

C (4) -0.04264
(0.0000)

-0.120989
(0.0000)

C (4) -0.10200
(0.0000)

-0.084147
(0.0000)

C (5) 0.97370
(0.0000)

0.984802
(0.0000)

C (5) 0.98984
(0.0000)

0.98495
(0.0000)

C (5) -.97987
(0.0000)

0.973512
(0.0000)

R-square -0.000148 -0.000042 R square -0.000023 -0.000006 R square -0.000064 -0.000079

DW 1.9597 2.1505 DW 1.83213 2.1278 DW 2.0159 2.062440
  Figures in parenthesis represent the p-values.



The coefficients of the constant in the mean equation from table 4.3.3 are not statistically significant, except for

that of the Dow Jones Industrial index of the first subsample which is significant at 5% level. But all the parameters

of the variance equation for all the samples were found to be statistically significant at all level of significance. The

R square here is again negative like that of the other ARCH type models, but the reason for this has been explained

before in section 3.6.3.  This model has an overwhelming advantage over the GARCH model presented in table

4.3.2 above. The reason being that there are no non-negativity restrictions placed on the parameters of the model,

as the negative results found in table 4.3.3 will be taken care of by the log of GARCH represented as the dependent

variable in the above model.



4.4. Diagnostic Checks

The ARCH models in the various subsamples were checked that they don’t breach the stationarity condition

explained in section 3.6.4. For the ARCH model, table 4.5.1 shows that the stationarity conditions for the ARCH

models are fulfilled as the sum of the alpha coefficients are close to unity. This stationarity condition satisfies that

the models in table 4.5.1 are modelled correctly. Table 4.5.1 shows estimates of the GARCH model and the

stationarity condition here is satisfied also as the coefficients of the variance equation were very close to unity,

indicating evidence of stationarity in the model and that the simple GARCH (1 1) model is adequately modelled.

The overwhelming advantage of the EGARCH model makes the stationarity condition satisfied as there are no

restrictions to the model.



Serial Correlation of Standardised Residuals

The ARCH LM test was employed after estimating the ARCH model to check whether the presence of

heteroskedasticity in the autoregressive model are not present in the ARCH models estimated for the various return

series. The ARCH LM test for the various indices in tables 4.5.1 and 4.5.1 suggests p values that are very high and

in most cases close to 100%. We therefore fail to reject the null hypothesis of homoskedasticity and conclude that

there are no heteroskedasticity in the model. This is indicated by the high p values suggested by the ARCH LM

test. This suggests that the ARCH models are adequately modelled and that there are no serial correlations in the

model.



4.4.1. Dynamic Forecasting

Fig 4.5.1A to fig 4.5.1R (at the appendix) illustrates the in sample actual standard deviation of the first and

second sub samples of the three indices under investigation. This represents 521 weeks with week1 to week 261 in

sample conditional standard deviation values, followed by week 262 to week 521 dynamic out of sample forecast.



Financial Risk and Management Reviews, 2018, 4(1): 1-23




12

© 2018 Conscientia Beam. All Rights Reserved.

ARCH type models in most cases seem to better describe samples in which volatility clustering are more

transparent. In all the graphs presented above, the ARCH type models tend to follow the in sample actual standard

deviation quite closely than any other models in most cases.

For the Dow Jones Industrial index, the ARCH model seems to follow the actual in sample standard deviation

quite closely in the first sub sample than those of the GARCH and EGARCH in fig 4.5.1 A to fig 4.5.1C. The second

model that best forecast volatility from the visual investigation is the EGARCH model in fig 4.5.1C as they tend to

follow the actual in sample standard deviation quite closely. For the second sub sample, the EGARCH model

follows the actual in sample better than the GARCH and ARCH model and hence tends to forecast volatility better

from fig 4.5.1D to fig 4.5.1F.

Fig 4.5.1G to fig 4.5.1I at the appendix represents the first sub sample of FTSE 100. The ARCH model in this

case, forecasts volatility better than the GARCH and EGARCH model, as they tend to follow the actual in sample

standard deviation with high peaks. The GARCH model seems to follow the actual in sample quite closely after the

ARCH model. Again for the second sub sample the ARCH model seems to follow the actual in sample better than

the GARCH and EGARCH model. This is illustrated in fig 4.5.1J to fig 4.5.1L where the GARCH model seems to

be second best in terms of volatility forecasting since they follow the actual in sample standard deviation quite

closely.

The Nikkei 225 index shows higher peaks than those of the Dow Jones Industrial and the FTSE 100 indices.

The ARCH model again seems to follow the actual in sample standard deviation quite closely than the other models

in fig 4.5.1M to fig 4.5.1O.  The second sub sample in fig 4.5.1P to fig 4.5.1R has peaks that are lower than those of

the first sub sample explained above. The EGARCH model follows the actual in sample standard deviation quite

closely than the ARCH and GARCH models, followed by the ARCH and then the GARCH model.

The ARCH type models seems to forecast volatility better than the GARCH and EGARCH models in most

cases, but one cannot rush into such conclusion as what will  determine which model forecast volatility better will

be based on the standard symmetric loss function.



4.4.2. Out of Sample Forecast

From fig 4.5.1A to fig 4.5.1R in appendix, the week 262 to week 523 represents the out of sample forecasting

period of the various return series. This shows that the out of sample forecast of the three indices clearly converge

to the long term unconditional values. This is common with all the forecasts of the indices under study.

The in sample forecast and out of sample forecast were analysed using the standard symmetric loss function to

evaluate the performance of the competing models. The forecast was done using the dynamic forecasting,

forecasting multi periods ahead. The in sample forecast period is made up of the first 261 weeks with 1249

observations and an out of sample forecast period of the second 261 weeks with 1264 observations. Returns of the

various indices were calculated weekly and are used in the analysis of this work. This is consistent with those of

Balaban and Bayar (2005). The four standard symmetric loss functions here include; the Mean Error, Root mean

square error, Mean absolute error and the Mean absolute percentage error. The model with the most minimum

forecasting error is regarded as a model that best forecast volatility better.

Table 4.6.1A to 4.6.1C in appendix represents the in sample volatility forecast for the entire sample (first and

second sub samples), with the tables representing the actual error statistics for the non linear models. Using the

four evaluation criteria, the EGARCH model clearly dominates the ARCH and GARCH models by registering the

lowest statistical error for the three indices. The GARCH model seems to have the lowest minimum values of the

errors but it is not enough to outperform those of the EGARCH model as they seem to do so only with the Dow

Jones Industrial index and the FTSE 100 in the first sub samples. EGARCH model has the lowest values and thus

is regarded as the model the best forecast volatility when we consider the in sample forecast. This result is



Financial Risk and Management Reviews, 2018, 4(1): 1-23




13

© 2018 Conscientia Beam. All Rights Reserved.

consistent with those of Najand (2002); Pagan and Schwert (1990) and Figlewski et al. (1993) who all conclude that

the EGARCH model seems to outperform other models in their studies.

For the out of sample forecast (Table 4.6.1D to 4.6.1F in appendix), the EGARCH model again outperformed

the ARCH and the GARCH model. Its dominancy can be seen mostly in the Nikkei 225 index where it

outperformed the ARCH and GARCH models all over the entire sample (in sample and out of sample), registering

the lowest statistical error among other models in the work. EGARCH model outperformed the ARCH and

GARCH models in the second sub sample of the FTSE 100 index. EGARCH model seems to perform very well in

periods of high volatility and it is common mostly in the second sub samples of the various indices. During the

second sub sample of the various indices, there are two major events that led to high and low periods of volatility

and these are the September 11 terrorist attack in 2001 and the ongoing financial crisis that started late 2007. The

result here are again similar to those of Figlewski et al. (1993); Pagan and Schwert (1990) and Najand (2002) who

all found the EGARCH to best forecast volatility than the ARCH and GARCH models.



5. SUMMARY AND CONCLUSION

The purpose of this paper is to evaluate and investigate the forecasting ability of the non-linear models which

include; the ARCH, GARCH and EGARCH models. We also investigated the Autoregressive model but this model

was not used in forecasting volatility of the return series under investigation for simplicity reasons. From our

analysis of the various return indices, we discovered that the return series does not follow a normal distribution,

thus exhibiting fat tails and high peaks which are higher than those of a normal distribution. Evaluation of volatility

forecasting have been investigated both in out of sample and in sample forecast, using the mean error (ME), root

mean square error (RMSE), mean absolute error (MAE) and mean absolute percentage error (MAPE) applied to a

multi-step ahead out of sample weekly volatility forecast.

Among the three non-linear models under investigation, the ARCH type model exhibits relatively a poor

forecast performance under both in sample and out of sample forecast, followed by the GARCH type models. The

EGARCH model was found to outperform other models in forecasting volatility in this analysis. Its superiority was

observed in return series like the Nikkei 225 where the EGARCH model tend to outperform other models both in

out of sample forecast and in sample forecast.



Funding: This study received no specific financial support.
Competing Interests: The authors declare that they have no competing interests.
Contributors/Acknowledgement: All authors contributed equally to the conception and design of the
study.



REFERENCES

Abdul, R. and A. Shabbir, 2008. Predicting stock returns volatility: An evaluation of linear vs. Nonlinear methods. International

Research Journal of Finance and Economics, 20(141-150): 31.

Akgiray, V., 1989. Conditional heteroscedasticity in time series of stock returns: Evidence and forecasts. The Journal of Business,

62(1): 55-80. Available at: https://doi.org/10.1086/296451.

Angelidis, T., A. Benos and S. Degiannakis, 2003. The use of GARCH models in VaR estimation. Discussion Paper, University

of Piraeus.

Balaban, E. and A. Bayar, 2005. Stock returns and volatility: Empirical evidence from fourteen countries. Applied Economics

Letters, 12(10): 603-611. Available at: https://doi.org/10.1080/13504850500120607.

Black, F. and M. Scholes, 1973. The pricing of options and corporate liabilities. Journal of Political Economy, 81(3): 637-654.

Available at: https://doi.org/10.1086/260062.



Financial Risk and Management Reviews, 2018, 4(1): 1-23




14

© 2018 Conscientia Beam. All Rights Reserved.

Boguth, O., M. Carlson, A. Fisher and M. Simutin, 2011. Conditional risk and performance evaluation: Volatility timing,

overconditioning, and new estimates of momentum alphas. Journal of Financial Economics, 102(2): 363-389. Available

at: https://doi.org/10.1016/j.jfineco.2011.06.002.

Bollerslev, T., 1986. Generalized autoregressive conditional heteroskedasticity. Journal of Econometrics, 31(3): 307-327.

Available at: https://doi.org/10.1016/0304-4076(86)90063-1.

Bollerslev, T., B. Hood, J. Huss and L.H. Pedersen, 2016. Risk everywhere: Modeling and managing volatility. Working Paper.

Bollerslev, T., B. Hood, J. Huss and L.H. Pedersen, 2018. Risk everywhere: Modeling and managing volatility. The Review of

Financial Studies, 31(7): 2729-2773. Available at: https://doi.org/10.1093/rfs/hhy041.

Brailsford, T.J. and R.W. Faff, 1996. An evaluation of volatility forecasting techniques. Journal of Banking & Finance, 20(3): 419-

438. Available at: https://doi.org/10.1016/0378-4266(95)00015-1.

Brooks, C., 2002. Introductory econometrics for finance. Cambridge University Press.

Brooks, C., A. Clare, J.W. Dalle Molle and G. Persand, 2005. A comparison of extreme value theory approaches for determining

value at risk. Journal of Empirical Finance, 12(2): 339-352. Available at:

https://doi.org/10.1016/j.jempfin.2004.01.004.

Cao, C.Q. and R.S. Tsay, 1992. Nonlinear time series analysis of stock volatilities. Journal of Applied Econometrics, 7(S1): S165-

S185. Available at: https://doi.org/10.1002/jae.3950070512.

Cipollini, F., G.M. Gallo and E. Otranto, 2017. On heteroskedasticity and regimes in volatility forecasting. Working Paper.

Constantinides, G.M., J.C. Jackwerth and A. Savov, 2013. The puzzle of index option returns. Review of Asset Pricing Studies,

3(2): 229-257. Available at: https://doi.org/10.1093/rapstu/rat004.

Day, T.E. and C.M. Lewis, 1992. Stock market volatility and the information content of stock index options. Journal of

Econometrics, 52(1-2): 267-287. Available at: https://doi.org/10.1016/0304-4076(92)90073-z.

Dimson, E. and P. Marsh, 1990. Volatility forecasting without data-snooping. Journal of Banking & Finance, 14(2-3): 399-421.

Available at: https://doi.org/10.1016/0378-4266(90)90056-8.

Engle, R.F., 1982. Autoregressive conditional heteroscedasticity with estimates of the variance of United Kingdom inflation.

Econometrica: Journal of the Econometric Society, 50(4): 987-1007. Available at: https://doi.org/10.2307/1912773.

Engle, R.F. and V.K. Ng, 1993. Measuring and testing the impact of news on volatility. The Journal of Finance, 48(5): 1749-

1778. Available at: https://doi.org/10.2307/2329066.

Figlewski, S., 1997. Forecasting volatility. Financial Markets, Institutions & Instruments, 6(1): 1-88.

Figlewski, S., R. Cumby and J. Hasbrouck, 1993. Forecasting volatilities and correlations with EGARCH models. The Journal of

Derivatives, 1(2): 51-63. Available at: https://doi.org/10.3905/jod.1993.407877.

Heynen, R.C. and H.M. Kat, 1994. Volatility prediction: A comparison of the stochastic volatility, GARCH (1, 1) and EGARCH

(1, 1) models. The Journal of Derivatives, 2(2): 50-65. Available at: https://doi.org/10.3905/jod.1994.407912.

Kuwahara, H. and T.A. Marsh, 1992. The pricing of japanese equity warrants. Management Science, 38(11): 1610-1641.

Available at: https://doi.org/10.1287/mnsc.38.11.1610.

Lamoureux, C.G. and W.D. Lastrapes, 1990. Heteroskedasticity in stock return data: Volume versus GARCH effects. The

Journal of Finance, 45(1): 221-229. Available at: https://doi.org/10.2307/2328817.

Louis, H. and W. Guan, 2004. Forecasting volatility. Available from https://ssrn.com/abstract=165528 or

http://dx.doi.org/10.2139/ssrn.165528.

Mats, P. and B. Viman, 2005. Forecasting volatility in the Swedish stock market.

Najand, M., 2002. Forecasting stock index futures price volatility: Linear vs. Nonlinear models. Financial Review, 37(1): 93-104.

Available at: https://doi.org/10.1111/1540-6288.00006.

Nelson, D.B., 1991. Conditional heteroskedasticity in asset returns: A new approach. Econometrica, 59(2): 347-370. Available at:

https://doi.org/10.2307/2938260.

Pagan, A.R. and G.W. Schwert, 1990. Alternative models for conditional stock volatility. Journal of Econometrics, 45(1-2): 267-

290. Available at: https://doi.org/10.1016/0304-4076(90)90101-x.

http://dx.doi.org/10.2139/ssrn.165528


Financial Risk and Management Reviews, 2018, 4(1): 1-23




15

© 2018 Conscientia Beam. All Rights Reserved.

Palmquist, M. and B. Viman, 2005. Forecasting volatility in the Swedish stock market; volatility modeling of the OMX-index

using four different models. Available from www.stat.umu.se/kursweb/vt05/stac05mom3/?download=MatsBjorn.pdf?

Poon, S.H., 2005. A practical guide to forecasting financial market volatility. Chichester: Jhon Wiley and Sons, Ltd.

Tsay, R.S., 2005. Analysis of financial time series. 2nd Edn.: John Wiley & Sons.

Tse, Y.K. and S.H. Tung, 1992. Forecasting volatility in the Singapore stock market. Asia Pacific Journal of Management, 9(1):

1-13.

Walsh, D.M. and G.Y.-G. Tsou, 1998. Forecasting index volatility: Sampling interval and non-trading effects. Applied Financial

Economics, 8(5): 477-485. Available at: https://doi.org/10.1080/096031098332772.

Ye-Hsiang, L., 1993. Forecasting daily volatility of foreign exchange markets: A comparison of the ARCH model and a new

model using high frequency data. An Unpublished Msc Project, Submitted to the Sloan School of Management, MIT,

USA. pp: 1-33.



Appendix



4.6. Forecasting



Fig-4.6.1A. A comparison of ARCH model conditional Standard deviation of Dow Jones Industrial index returns versus Actual Standard
deviation (1989-1999) first subsample.
Source: Eviews’ Result Output



http://www.stat.umu.se/kursweb/vt05/stac05mom3/?download=MatsBjorn.pdf?


Financial Risk and Management Reviews, 2018, 4(1): 1-23




16

© 2018 Conscientia Beam. All Rights Reserved.


Fig-4.6.1B. A comparison of GARCH model conditional Standard deviation of Dow Jones Industrial index returns versus Actual Standard
deviation (1989-1999) first subsample.
Source: Eviews’ Result Output



Fig-4.6.1C. A comparison of EGARCH model conditional Standard deviation of Dow Jones Industrial index returns versus Actual Standard
deviation (1989-1999) first subsample.
Source: Eviews’ Result Output



Financial Risk and Management Reviews, 2018, 4(1): 1-23




17

© 2018 Conscientia Beam. All Rights Reserved.


Fig-4.6.1D. A comparison of ARCH model conditional Standard deviation of Dow Jones Industrial index returns versus Actual Standard
deviation (1999-2009) second subsample.
Source: Eviews’ Result Output




Fig 4.6.1E; A comparison of GARCH model conditional Standard deviation of Dow Jones Industrial index returns versus Actual Standard
deviation (1999-2009) second subsample.
Source: Eviews’ Result Output




Fig-4.6.1F. A comparison of EGARCH model conditional Standard deviation of Dow Jones Industrial index returns versus Actual Standard
deviation (1999-2009) second subsample.
Source: Eviews’ Result Output



Financial Risk and Management Reviews, 2018, 4(1): 1-23




18

© 2018 Conscientia Beam. All Rights Reserved.


Fig-4.6.1G. A comparison of ARCH model conditional Standard deviation of FTSE 100 index returns versus Actual Standard deviation (1989-
1999) first subsample.
Source: Eviews’ Result Output




Fig-4.6.1H. A comparison of GARCH model conditional Standard deviation of FTSE 100 index returns versus Actual Standard deviation (1989-
1999) first subsample.
Source: Eviews’ Result Output




Fig-4.6.1I. A comparison of EGARCH model conditional Standard deviation of FTSE 100 index returns versus Actual Standard deviation
(1989-1999) first subsample
Source: Eviews’ Result Output



Financial Risk and Management Reviews, 2018, 4(1): 1-23




19

© 2018 Conscientia Beam. All Rights Reserved.


Fig-4.6.1J. A comparison of ARCH model conditional Standard deviation of FTSE 100 index returns versus Actual Standard deviation (1999-
2009) second subsample.
Source: Eviews’ Result Output




Fig-4.6.1K. A comparison of GARCH model conditional Standard deviation of FTSE 100 index returns versus Actual Standard deviation (1999-
2009) second subsample.
Source: Eviews’ Result Output



Fig-4.6.1L. A comparison of EGARCH model conditional Standard deviation of FTSE 100 index returns versus Actual Standard deviation
(1999-2009) second subsample.
Source: Eviews’ Result Output





Financial Risk and Management Reviews, 2018, 4(1): 1-23




20

© 2018 Conscientia Beam. All Rights Reserved.


Fig-4.6.1M. A comparison of ARCH model conditional Standard deviation of Nikkei 225  index returns versus Actual Standard deviation (1989-
1999) first subsample.
Source: Eviews’ Result Output




Fig-4.6.1N. A comparison of GARCH model conditional Standard deviation of Nikkei 225 index returns versus Actual Standard deviation
(1989-1999) first subsample.
Source: Eviews’ Result Output




Fig-4.6.1O. A comparison of EGARCH model conditional Standard deviation of Nikkei 225 index returns versus Actual Standard deviation
(1989-1999) first subsample.
Source: Eviews’ Result Output





Financial Risk and Management Reviews, 2018, 4(1): 1-23




21

© 2018 Conscientia Beam. All Rights Reserved.


Fig-4.6.1P. A comparison of ARCH model conditional Standard deviation of Nikkei 225  index returns versus Actual Standard deviation (1999-
2009) second subsample.
Source: Eviews’ Result Output




Fig-4.6.1Q. A comparison of GARCH model conditional Standard deviation of Nikkei 225 index returns versus Actual Standard deviation
(1999-2009) second subsample.
Source: Eviews’ Result Output




Fig-4.6.1R. A comparison of EGARCH model conditional Standard deviation of Nikkei 225 index returns versus Actual Standard deviation
(1999-2009) second subsample.
Source: Eviews’ Result Output



Financial Risk and Management Reviews, 2018, 4(1): 1-23




22

© 2018 Conscientia Beam. All Rights Reserved.

4.7. Forecast Evaluation


Table-4.7.1A. In Sample Forecast Evaluation Values.

DJ-INDUS First Sub Sample (In sample Forecast)

 Mean Error Root Mean Square
Error

Mean Absolute
Error

Mean Absolute
Percentage Error

ARCH  0.001010918 0.004470646 0.003201589 0.367176116

GARCH 0.00967646 0.00444766 0.00315545 0.114862607

EGARCH 0.001077527 0.004465665 0.003189905 0.125018067

DJ-INDUS Second Sub Sample (In Sample Forecast)
 Mean Error Root Mean Square

Error
Mean Absolute Error Mean Absolute

Percentage Error

ARCH 0.002107113 0.007660924 0.005507428 0.422727826

GARCH 0.002052513 0.007457126 0.005271119 0.403523888

EGARCH 0.00062735 0.007178554 0.004690626 0.424726446
Notes: Values on bold represents values with lowest errors.



Table 4.7.1B. In Sample Forecast Evaluation values.

FTSE 100 First Sub Sample (In sample Forecast)

 Mean Error Root Mean Square
Error

Mean Absolute
Error

Mean Absolute
Percentage Error

ARCH  0.002984594 0.00395790 0.003690902 0.417200386

GARCH 0.000819442 0.003959491 0.002977073 0.337510323

EGARCH 0.000833467 0.004702743 0.002976499 0.340345209

FTSE 100  Second Sub Sample (In Sample Forecast)
 Mean Error Root Mean Square

Error
Mean Absolute Error Mean Absolute

Percentage Error

ARCH 0.003664441 0.008406874 0.006350382 0.409346787

GARCH 0.003998175 0.008393197 0.00642288 0.409436781

EGARCH 0.00428441 0.006942878 0.004573834 0.416043781
Notes: Values on bold represent the lowest values of the errors.


Table-4.7.1C. In Sample Forecast Evaluation values.

NIKKEI 225 First Sub Sample (In sample Forecast)

 Mean Error Root Mean Square
Error

Mean Absolute Error Mean Absolute
Percentage Error

ARCH  0.003454182 0.007536839 0.006096075 0.3774864

GARCH 0.005049545 0.009189002 0.00751955 0.414153727

EGARCH 0.001579412 0.00698981 0.005360969 0.377098188

NIKKEI 225 Second Sub Sample (In Sample Forecast)
 Mean Error Root Mean Square Error Mean Absolute Error Mean Absolute Percentage

Error
ARCH 0.00170211 0.009122864 0.006194947 0.398395463

GARCH 0.002609161 0.009305596 0.006562385 0.390184292

EGARCH 0.001190273 0.009009175 0.00598187 0.401501728
Notes: Values on bold represent the lowest values of the errors.


Table-4.71D. Out of Sample Forecast Evaluation Values.

DJ-INDUS First Sub Sample (Out sample Forecast)

 Mean Error Root Mean Square
Error

Mean Absolute Error Mean Absolute
Percentage Error

ARCH  0.000651786 0.005216271 0.003634623 0.410702669

GARCH 0.000951028 0.005190626 0.0036393397 0.10880283

EGARCH 0.001157949 0.005267675 0.003800533 0.126536878

DJ-INDUS Second Sub Sample (Out Sample Forecast)
 Mean Error Root Mean Square

Error
Mean Absolute Error Mean Absolute Percentage

Error

ARCH 0.003441605 0.009857653 0.007556308 0.558128635

GARCH 0.003269886 0.009581641 0.007174781 0.530767792

EGARCH 0.000648471 0.009227492 0.006106292 0.569757756
Notes: Values on bold represent the lowest values of the errors.





Financial Risk and Management Reviews, 2018, 4(1): 1-23




23

© 2018 Conscientia Beam. All Rights Reserved.

Table4.7.1E. Out of Sample Forecast Evaluation values.

FTSE 100 First Sub Sample (Out of sample Forecast)

 Mean Error Root Mean Square
Error

Mean Absolute
Error

Mean Absolute
Percentage Error

ARCH  0.004954642 0.005991094 0.005214505 0.584485088

GARCH 0.00086058 0.004675147 0.003659436 0.408896685

EGARCH 0.000891135 0.004699706 0.000368831 0.411908289

FTSE 100  Second Sub Sample (Out of Sample Forecast)
 Mean Error Root Mean Square

Error
Mean Absolute Error Mean Absolute

Percentage Error

ARCH 0.00671887 0.011146005 0.00964341 0.568854013

GARCH 0.007384655 0.011089078 0.009737928 0.554996617

EGARCH 0.00339366 0.008901765 0.006125039 0.584640813
Notes: Values on bold represent the lowest values of the errors.


Table-4.7.1F. Out of Sample Forecast Evaluation values.

NIKKEI 225 First Sub Sample (Out of sample Forecast)

 Mean Error Root Mean Square
Error

Mean Absolute
Error

Mean Absolute
Percentage Error

ARCH  0.005101684 0.009031602 0.007777869 0.44111831

GARCH 0.008373207 0.011082624 0.009987103 0.478706324

EGARCH 0.00191227 0.007670322 0.006108042 0.423331019

NIKKEI 225 Second Sub Sample (Out of Sample Forecast)
 Mean Error Root Mean Square

Error
Mean Absolute Error Mean Absolute Percentage

Error

ARCH 0.002391304 0.011508265 0.007933385 0.496586615

GARCH 0.004129922 0.011874298 0.008791541 0.493609117

EGARCH 0.001330736 0.01133557 0.007444403 0.4997820013
Notes: Values on bold represent the lowest values of the errors.








































Views and opinions expressed in this article are the views and opinions of the author(s), Financial Risk and Management Reviews shall not be responsible or
answerable for any loss, damage or liability etc. caused in relation to/arising out of the use of the content.
