Evaluating ultrastructural preservation quality in banked brain tissue

Macy Garrood1*, Alicia Keberle1*, Allison Sowa2, William Janssen2, Emma L. Thorn3,4, Claudia De Sanctis3,4,
Kurt Farrell3,4, John F. Crary3,4, Andrew T. McKenzie1

1 Apex Neuroscience, Salem, Oregon, USA

2 Microscopy and Advanced Bioimaging Core, Icahn School of Medicine at Mount Sinai, New York, New York, USA

3 Friedman Brain Institute, Departments of Pathology, Neuroscience, and Artificial Intelligence & Human Health,
Icahn School of Medicine at Mount Sinai, New York, New York, USA

4 Neuropathology Brain Bank & Research Core and Ronald M. Loeb Center for Alzheimer's Disease, Icahn School
of Medicine at Mount Sinai, New York, New York, USA

 The authors contributed equally to this work.

Corresponding author:
Andrew T. McKenzie · Apex Neuroscience · 3265 Marietta St SE · Salem · OR 97317 · USA
amckenzie@apexneuro.org

Submitted: 06 May 2025 · Accepted: 09 June 2025 · Copyedited by: Alessia Sciortino · Published: 25 June 2025

Abstract

The ultrastructural analysis of postmortem brain tissue can provide important insights into cellular architecture
and disease-related changes. For example, connectomics studies offer a powerful emerging approach for
understanding neural circuit organization. However, electron microscopy (EM) data is difficult to interpret when
the preservation quality is imperfect, which is common in brain banking and may render it unsuitable for certain
research applications. One common issue is that EM images of postmortem brain tissue can have an expansion
of regions that appear to be made up of extracellular space and / or degraded cellular material, which we call
ambiguous interstitial zones. In this study, we report a method to assess whether EM images have ambiguous
interstitial zone artifacts in a cohort of 10 postmortem brains with samples from each of the cortex and thalamus.
Next, in matched samples from the contralateral hemisphere of the same brains, we evaluate the structural
preservation quality of light microscopy images, including immunostaining for cytoskeletal proteins. Through this
analysis, we show that on light microscopy, cell membrane morphology can be largely maintained, and neurite
trajectory visualized over micrometer distances, even in specimens for which there are ambiguous interstitial
zone artifacts on EM. Additionally, we demonstrate that synaptic structures can be successfully traced across
serial EM sections in some postmortem samples, indicating the potential for connectivity studies in banked
human brain tissue when appropriate preservation and visualization protocols are employed. Taken together,
our analysis may assist in maximizing the usefulness of donated brain tissue by informing tissue selection and
preparation protocols for various research goals.


Keywords: Brain banking, Postmortem changes, Perfusion fixation, Neurofilaments, Ultrastructural quality, Connectomics

Original Paper

https://doi.org/10.17879/freeneuropathology-2025-6763
https://creativecommons.org/licenses/by/4.0/
https://creativecommons.org/publicdomain/zero/1.0/
mailto:amckenzie@apexneuro.org


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 2 of 27





Abbreviations

AIZ - Ambiguous Interstitial Zones, EM -
Electron Microscopy, GFAP - Glial Fibrillary Acidic
Protein, h - Hour, H&E - Hematoxylin and Eosin, IRR
- Inter-Rater Reliability, LM - Light Microscopy, NBF
- Neutral Buffered Formalin, PMI - Postmortem
Interval, WSI - Whole Slide Image.

Introduction

Since the 1950s, when the synapse was first
visualized with an electron microscope, the ultra-
structural analysis of brain tissue has enabled many
critical discoveries about the structure of the brain
(Sotelo, 2020; Nahirney and Tremblay, 2021). In
recent years, EM-based connectomics, in particular,
has enabled key insights into larger-scale neural
circuitry across diverse species (Lichtman et al.,
2014; Shiu et al., 2024). Expanding connectomics to
a larger set of human brains may allow us to answer
fundamental questions about our brains in health
and disease. However, data collection for connec-
tomics relies on high-quality tissue preservation that
enables the reliable tracing of neuronal processes
and identification of synaptic connections. These
requirements are challenging to achieve in human
brain tissue samples, which generally have quality
limitations due to agonal factors, the postmortem
interval (PMI), and impediments in preservation
methods (McKee, 1999; McFadden et al., 2019;
McKenzie et al., 2022). To date, most volume
electron microscopy studies have been performed
on non-human brain tissue (Chiappini et al., 2025).
The successful volume electron microscopy and
connectomics studies on human brain tissue have
been limited to tissue that is selected for having
ideal preservation quality, such as surgical biopsy
tissue or deceased donor tissue with very low PMI
(Shapson-Coe et al., 2024; Plaza-Alonso et al., 2025).

While mapping an entire human brain with
electron microscopy far exceeds our current techno-
logical capabilities, the ability to image nanoscale
neural connectivity in tissue from a wider set of
banked brains would still be valuable for several
reasons. First, brain banks serve diverse research
communities, and investigators require access to
tissue from different brain regions and with

different donor characteristics, which may not
always be possible to acquire from surgical biopsies.
Second, larger sample sizes are critical for statisti-
cally robust inferences regarding the structural
correlates of disease, as the history of genomics has
shown (Uffelmann et al., 2021). Third, advances in
imaging and computing technologies are rapidly
improving our ability to analyze neural circuits at
scale. As these tools continue to develop, having
access to more banked brain tissue whose ultra-
structure can be profiled may enable increasingly
larger-scale connectomics studies of the human
brain. Given these considerations, there is a critical
need to investigate whether current techniques
used in brain banking are sufficient to maintain the
structural integrity needed for future connectome
analyses, despite the fact that our present connec-
tome imaging and reconstruction capabilities are
still limited.

There is a lack of standardized methods to
assess brain preservation quality, which means
that it may be useful to consider first principles
(McFadden et al., 2019; Wahyudi et al., 2025).
Structural changes can occur prior to fixation, during
fixation, and during subsequent tissue processing,
and may include membrane blebbing, vacuoles,
cytoplasmic washout, and chromatin alterations
(Garman, 2011; Krassner et al., 2023; McKenzie et
al., 2024). Some of these artifacts, such as blebbing
or vacuoles, may not prevent us from tracing the
connectome, instead only leading to the expansion
or compression of certain cellular structures, which
can still be adequately visualized. A more significant
challenge arises from the observed phenomenon in
some samples of enlarged, electron-lucent, non-
membrane-bound regions between cells, which we
call ambiguous interstitial zones (AIZs). Crucially,
these AIZs are usually also associated with an
apparent decrease in the density of visualized
cellular structures, such as thin neurites. Instead,
the AIZs often contain what appears to be poorly
defined structures, possibly cellular debris. These
poorly defined structures are not usually visible in
tissue that has been preserved with a negligible
duration of ischemia prior to preservation. These
AIZs and associated poorly defined structures have
been described in previous literature, for example,
as causing a “lacey” appearance in postmortem

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 3 of 27





brain tissue (Palay et al., 1962; Liewald et al., 2014;
Lewis et al., 2019).

Mechanistically, very early in the PMI, the
extracellular space is actually expected to shrink due
to ischemic cell swelling (Nicholson and Syková,
1998). As the PMI becomes prolonged, biomolecular
structures break down and cell membrane integrity
is eventually lost, leading to passive fluid redistribu-
tion and an expected expansion of the apparent
extracellular space (Krassner et al., 2023). This
excess fluid may affect fine neural structures in
various ways, from complete dissolution in severe
cases to preservation of some elements but with
insufficient compactness for visualization in others.
The difficulty in visualization may be in part because
microscopy depends on biomolecules being densely
aggregated enough to maintain their structural
integrity during tissue processing and bind
adequately with staining chemicals (Wang and
Minassian, 1987). However, during prolonged PMI,
these biomolecular networks progressively dissoci-
ate, reducing their density.

Previous studies have found that fixation and
sample preparation methods can influence the
visualized ultrastructure of brain tissue (Schiff and
Gennaro Jr., 1979; Small, 1981; Sele et al., 2019;
Eberhardt et al., 2022; Shafiei et al., 2024). For
example, one study reported that there can be
significant extraction of proteins and lipids during
EM preparation, creating large empty spaces, which
is an issue that worsens with longer PMI (Lewis
et al., 2019). They found that adding 0.1 %
glutaraldehyde to their formalin fixative partially
rescued this. Another study found that the use of
embedding techniques for EM at room temperature,
which is standard for the field, introduced ultra-
structural artifacts such as swollen mitochondria,
disrupted membranes, and extraction of cellular
components (Sosinsky et al., 2008). However, these
artifacts were avoided when fixation was instead
followed by a high-pressure freezing protocol,
which led to images with smoother cell membranes
and more dense cytoplasm. Finally, one study
tested more than one hundred protocol variations
on human brain tissue and found that even
subtle differences in fixation, washing, dehydration,
and embedding can affect the ultrastructural

appearance, including the preservation of extra-
cellular space (Karlupia et al., 2023).

Our working hypothesis is that the observed
artifacts on ultrastructural imaging may result solely
from structural degradation due to decomposition
prior to fixation, and / or may be partially accounted
for by our current methods of sample preparation,
staining, and imaging, which are not optimized for
decomposed tissue. If true structural loss is the
dominant factor, then strict constraints on PMI and
preservation procedures may be necessary for
selecting samples that are suitable for connectome
imaging. On the other hand, if enough morpho-
molecular markers are still theoretically present to
reconstruct the cellular skeleton but are not visual-
ized with current methods due to insufficient
optimization for this purpose, then improved
postfixation, embedding, staining, imaging, and
analysis methods could potentially recover them.

In this study, we attempt to address the
challenge of distinguishing true structural degrada-
tion from visualization artifacts in postmortem brain
EM images. We develop a metric to assess the
extent of AIZs in the EM images as an index for
evaluating preservation quality. We also analyze
matched samples from the contralateral hemi-
sphere stained with hematoxylin and eosin (H&E)
and via immunohistochemistry, to attempt to
identify cases where cellular structures remain
intact on light microscopy. Our goal is to help
improve our methods for assessing ultrastructural
preservation quality and explore the differences
between the measured preservation quality at the
light and electron microscopy levels.

Methods

Brain banking procedures

Anatomical whole-body donations were
performed by a partner whole-body donation
organization operating under Oregon Health
Authority regulations. Additionally, through our
canine brain bank program, we were donated the
body of one deceased canine following euthanasia
by a licensed veterinarian, with signed owner
consent for research use (Sándor et al., 2021). The
Apex Neuroscience Brain and Tissue Bank operates

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 4 of 27





under an exemption determination issued by the
Pearl Institutional Review Board (IRB) after the
submission of our protocols for review.

The PMI was calculated as the time elapsed
between death and the initiation of the preservation
procedure. When the day of death but not the hour
was known, the time of death was estimated at
the middle of the day (12 pm) to provide a standard-
ized approach for PMI calculation in cases with
incomplete time data. During the PMI, the donor
bodies were generally stored in refrigeration, for
example, in a hospital morgue. However, we do not
have the exact durations of this refrigerated storage
period for each donor, which is a potential
confound, as higher temperatures during the PMI
are associated with more structural breakdown.

One of the brain specimens (donor #57) was
fixed by immersion in 10 % neutral buffered
formalin (NBF, Azer Scientific NBF55G) alone. Note
that 10 % NBF contains 3.7 % formaldehyde (Snyder
et al., 2022). The rest of the human brains were
perfused in situ with the use of a peristaltic
pump, following cannulation of the bilateral carotid
arteries with 10 % NBF. For several of the donors
(donors #7, 30, 34, and 37), the carotid arteries were
accessed via dissection in the anterior cervical
region. For the remaining human donors, the
cephalon was isolated via dissection at the
approximate spinal level of C4-C5 (Turkoglu et al.,
2014). This allowed for cannulation of the bilateral
internal carotid arteries and clamping of the
vertebral arteries to prevent outflow through them.
The one canine brain was from a 2.3 kg Miniature
Pinscher whose brain was perfused in situ with 10 %
NBF via cannulation of the left ventricle and the use
of a peristaltic pump.

The brains were removed from the skull
following standard procedures (Adams and Murray,
1982). They were then immersed in 10 % NBF at 4 °C
for at least one month prior to further processing
(McKee, 1999). Small samples were taken from grey
matter of the sensorimotor cortex and the grey
matter of the thalamus, from one hemisphere for
light microscopy and the contralateral for EM.

Electron microscopy

Tissue for EM was post-fixed in a solution of
2 % paraformaldehyde and 2.5 % glutaraldehyde in
0.1M sodium cacodylate buffer. A version of the
National Center for Microscopy and Imaging
Research (NCMIR) protocol was adapted to
provide enhanced contrast (Deerinck et al., 2010).
Specifically, after fixation, the tissue underwent a
multi-step enhanced contrast protocol at room
temperature including sequential treatments with
tannic acid, reduced osmium, thiocarbohydrazide,
osmium, and uranyl acetate. This was followed by
lead aspartate staining at 60 °C. The brain sample
was then dehydrated through a graded ethanol
series, infiltrated with Embed 812 epoxy resin
(EMS), and polymerized for 72 h at 60 °C. Semithin
sections (0.5 μm) were cut using a Leica UC7 ultra-
microtome (Leica, Buffalo Grove, IL) and
counterstained with 1 % toluidine blue to identify
the regions of interest within layers. Images were
taken on a HT7500 transmission electron micro-
scope (Hitachi High-Technologies, Tokyo, Japan)
using an AMT NanoSprint12 12-megapixel CMOS
TEM Camera System, software version 7.0.1.485
(Advanced Microscopy Techniques, Danvers, MA).
Images were only adjusted for contrast on the AMT
software. For three of the samples, we performed
serial section transmission electron microscopy
(ssTEM), using ultra-thin sections of 80 nm
thickness, collected onto nickel slot grids. There
were 6 image series from the identified region of
interest across 10 serial sections.

We first performed fine-scale manual
annotation of a subset of EM images, including one
high-magnification image from all 20 unique brain
samples (from different donors and brain regions).
We annotated the boundaries of four mutually
exclusive classes of structures across the image: (a)
cell bodies, (b) membrane-bound structures with
electron-dense interior, (c) membrane-bound
structures with electron-lucent interior, and (d)
myelinated axons. Category (c) is expected to
include fluid-filled, swollen astrocyte processes,
which is a common artifact seen in postmortem


https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 5 of 27





brain tissue, but is not necessarily expected to make
it more difficult to trace neural processes (Krassner
et al., 2023). Notably, category (b) could include
neurites as well as astrocyte, oligodendrocyte, or
microglia processes. Because we only have 2D
images for most of the EM data, we cannot more
definitively annotate these on the basis of their 3D
structure. The remainder of the image is designated
as AIZs. These extracellular spaces may or may
not contain partially degraded cellular membranes
or other structural elements that cannot be
reliably visualized due to postmortem changes or
preparation artifacts. To assess inter-rater reliability
for the fine-scale manual annotation, two independ-
ent raters annotated the same image. The
spatial agreement between their annotations was
quantified using the Dice similarity coefficient, with
the median pairwise Dice score calculated across all
polygons that were identified as having the most
similar coordinates between the annotations.

We next graded two-dimensional EM images
on whether or not they had AIZ artifacts, rating
each image as either having or not having both (a)
extensive AIZs and (b) a low degree of cell
membrane intactness. We added the additional
criterion of (b) to ensure that the images did not
merely have expanded extracellular space, which
could theoretically occur in conjunction with clearly
delineated, well-preserved lipid membranes, for
example depending upon the osmolarity of the
preservative solutions (Pallotto et al., 2015). Two
raters worked together to determine the grade for
each image and resolved any discrepancies via
consensus review. We calculated the percentage of
images graded as having AIZ artifacts across each of

the 5 medium-magnification EM images available
for all 20 samples.

Light microscopy

Brain tissue sampled for light microscopy was
placed into cassettes for processing and embedded
in paraffin. Paraffin-embedded brain sections 6 µm
thick were baked, deparaffinized, and stained for
H&E. Chromogenic immunohistochemistry was
performed on Ventana Discovery Ultra according to
the manufacturer’s directions (Neuropathology
Brain Bank and Research CoRe, at Mount Sinai). The
slides 6 µm thick were baked, deparaffinized, and
pretreated using Cell Conditioning (CC1) antigen
retrieval buffer (Tris / Borate/ EDTA buffer, pH
8.0–8.5, 950-224, Roche Diagnostics). Primary anti-
bodies (Table 1) were diluted in antibody dilution
buffer (ADB250, Ventana Medical System Inc.,
Roche Diagnostics). SMI-311 and SMI-312 are anti-
body cocktails that target neurofilament heavy
(NF-H) and medium (NF-M) chain proteins (Ulfig et
al., 1998). SMI-311 recognizes non-phosphorylated
epitopes and therefore primarily stains dendrites
and perikarya, while SMI-312 targets the highly
phosphorylated epitopes predominantly found in
axons. The detection was performed using the ultra-
View Universal DAB Detection Kit (760-500, Roche
Diagnostics). Hematoxylin and Bluing reagent
(760-2021, 760-2037, Roche Diagnostics) were used
as a nuclear counterstain. Digital images of the
stained sections were captured at 40X as whole slide
images (WSIs) using the Aperio GT450 high-resolu-
tion scanner (Leica Biosystems). WSIs were viewed
using the default display settings in QuPath (v.
0.4.3).

Table 1: List of antibodies used in this study.

Antibody Company Catalog # Dilution

Vimentin (V9) Roche, Cell Marque 05278139001 2.5 ug/ml

GFAP (EP672Y) Roche, Cell Marque 5269784001 1 ug/ml

SMI-311 BioLegend 837904 1/1000

SMI-312 BioLegend 837801 1/1000

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 6 of 27





For the H&E- and immunohistochemically
stained WSIs, we first performed a qualitative
assessment of preservation quality, examining the
images for whether cell membrane morphology
appeared intact across samples and also for
common postmortem artifacts. For semi-quantita-
tive grading of the samples, two raters collabora-
tively evaluated each sample and decided upon
consensus grades. Perfusion quality on H&E staining
was graded on a 0-3 scale by examining for the
presence of intravascular material (including blood
cells) across the WSI, with 0 indicating minimal intra-
vascular material and 3 indicating extensive intra-
vascular material. This analysis was done with the
raters blinded to the preservation method used. We
attempted to perform a grading scale for Glial
Fibrillary Acidic Protein (GFAP), SMI-311, and
SMI-312 immunostaining. However, for GFAP
immunostaining, we determined that variability in
staining could reflect multiple factors, including
pre-mortem influence, the region sampled, and the
fixation time, making it unsuitable as a reliable
metric for preservation quality assessment. For
SMI-311 and SMI-312, we were unable to identify
enough variability between the samples, as
they all appeared to have robust and consistent

immunoreactivity, with the exception of SMI-311 for
the two canine samples, which had negligible
immunostaining.

Results

Preservation quality in electron microscopy images

Our cohort consisted of nine human brains and
one canine brain, which we selected following their
preservation to have a wide range of PMIs, from 1.5
hours to 4 days (Table 2). For each brain, small
samples were obtained from the grey matter of the
sensorimotor cortex and thalamus.

Qualitatively, we observed varying degrees of
ultrastructural preservation across the specimens.
Across all samples, we detected several artifacts
commonly found in postmortem brain tissue,
including cellular swelling and shrinkage, vacuoliza-
tion, myelin disbanding, and partially disrupted cell
membranes whose potential shapes could still be at
least partially distinguished (Krassner et al., 2023).
The canine brain, which had the shortest PMI of 1.5
hours, was found to have the lowest burden of these
postmortem artifacts.

Table 2: Characteristics of brain donors included in this study.

Donor ID Age Sex PMI Reported cause of death Preservation method Fixation time

7 78 Male 4.25 hours Cancer* Perfusion fixation 5 months

30 77 Male 17 hours Kidney failure, failure to thrive  Perfusion fixation 4 months

34 88 Male 20 hours Cancer* Perfusion fixation 4 months

37 70 Male 72 hours Myocardial infarction Perfusion fixation 4 months

55 70 Male 36 hours Cardiac causes Perfusion fixation 3 months

57 75 Male 96 hours Leukemia Immersion fixation 3 months

59 41 Female 91 hours Leukemia  Perfusion fixation 2.5 months

65 17** Female 1.5 hours Euthanasia (Donated canine) Perfusion fixation 2 months

66 89 Female 61 hours Sepsis and acute renal failure Perfusion fixation 2 months

78 89 Male 2.5 hours Failure to thrive Perfusion fixation 1 month

Fixation time refers to the amount of time in 10 % neutral buffered formalin at 4 °C. *: This donor utilized medical aid in dying (MAID) for
end-of-life care. **: Canine brain. PMI: Postmortem interval



https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 7 of 27





We next performed fine-scale manual
annotation of ultrastructural components in the
images (Figure 1). To assess the reproducibility of
our annotation approach, two independent raters
annotated the same image, which was from the
cortex sample of donor #66. Inter-rater reliability

was quantified by calculating the Dice similarity
coefficient for each pair of matching polygons,
yielding a median Dice score of 0.79 (Figure 2). In
one high-magnification image from each unique
sample, we also quantified the percentage of area
occupied by AIZs (Figure 3, Table 3).


Figure 1. Fine-scale annotation of ultrastructural components in one representative EM image from the cortex of donor #7. Color coding
identifies distinct cellular structures: Green: membrane-bound structures with electron-dense interior (e.g., organelle-rich neurites);
Purple: membrane-bound structures with electron-lucent interior (e.g., swollen astrocytic processes); Blue: myelinated axons; Yellow: cell
bodies. Non-colored regions represent ambiguous interstitial zones (AIZs) that lack clearly defined membrane boundaries. Upper scale
bar: 2 µm. Lower scale bar: 1 µm.

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 8 of 27






Figure 2. Overlap of annotations of a sample from the cortex of donor #66 by independent annotators. The top and middle image were
done by two independent annotators. The bottom image is a combination of the overlays to compare how alike the two annotations are.
Color coding identifies distinct cellular structures: Green: membrane-bound structures with electron-dense interior (e.g., organelle-rich
neurites); Purple: membrane-bound structures with electron-lucent interior (e.g., swollen astrocytic processes); Blue: myelinated axons;
Yellow: cell bodies. Non-colored regions represent ambiguous interstitial zones (AIZs) that lack clearly defined membrane boundaries.
Scale bars: 1 µm.

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 9 of 27







Figure 3. Fine-scale manual annotation of ambiguous interstitial zones (AIZs) from one EM image across all samples. Samples are sorted
by the percentage of ambiguous interstitial zones (AIZs), from the lowest to the highest: 7-C (a), 37-T (b), 34-C (c), 65-C (d), 59-C (e), 55-C
(f), 37-C (g), 78-C (h), 57-C (i), 30-C (j), 65-T (k), 57-T (l), 55-T (m), 78-T (n), 30-T (o), 34-T (p), 66-C (q), 7-T (r), 66-T (s), 59-T (t), where the
number is the donor ID number, and then “-T” indicates that it is from the thalamus and “-C” from the cortex. Color coding identifies
distinct cellular structures: Green: membrane-bound structures with electron-dense interior (e.g., organelle-rich neurites); Purple:
membrane-bound structures with electron-lucent interior (e.g., swollen astrocytic processes); Blue: myelinated axons; Yellow: cell bodies.
Non-colored regions AIZs that lack clearly defined membrane boundaries. Scale bars: 500 nm.


https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 10 of 27





Table 3: Summary of tissue preservation quality metrics by donor and brain region.

Donor ID PMI Fixation time Region AIZ percentage (in
one annotated image)

Percentage of images with AIZ
artifacts (count/total)

7 4.25 hours 5 months
Thalamus 37.18 % 100 % (5/5)

Cortex 7.97 % 0 % (0/5)

30 17 hours 4 months
Thalamus 33.14 % 100 % (5/5)

Cortex 17.76 % 100 % (5/5)

34 20 hours 4 months
Thalamus 34.79 % 80 % (4/5)

Cortex 8.91 % 60 % (3/5)

37 72 hours 4 months
Thalamus 8.46 % 100 % (5/5)

Cortex 10.61 % 0 % (0/5)

55 36 hours 3 months
Thalamus 24.51 % 100 % (5/5)

Cortex 17.52 % 100 % (5/5)

57 96 hours 3 months
Thalamus 21.51 % 20 % (1/5)

Cortex 17.52 % 40 % (2/5)

59 91 hours 2.5 months
Thalamus 40.44 % 100 % (5/5)

Cortex 11.29 % 100 % (5/5)

65 1.5 hours 2 months
Thalamus 20.95 % 0 % (0/5)

Cortex 9.57 % 0 % (0/5)

66 61 hours 2 months
Thalamus 39.37 % 100 % (5/5)

Cortex 35.31 % 20 % (1/5)

78 2.5 hours 1 month
Thalamus 27.49 % 100 % (5/5)

Cortex 15.65 % 40 % (2/5)

The “AIZ percentage” column shows the proportion of area occupied by AIZs in one high magnification, annotated EM image, representing
electron-lucent, non-membrane-bound regions that may contain degraded cellular structures. The “Percentage of images with AIZ
artifacts” column indicates how many EM images were graded as having AIZ artifacts, with the raw number of affected images shown in
parentheses (out of 5 total images evaluated per sample). PMI: Postmortem interval; AIZ: Ambiguous interstitial zone.

We next developed a grading method to rate
EM images for AIZs that could both be performed
more rapidly by trained annotators and could also
take into account the degree of cell membrane
intactness. Specifically, the images were graded as
having AIZ artifacts if they displayed both (a)
extensive AIZs and (b) poor delineation of cellular
membrane boundaries (Figure 4). This combined
assessment is meant to distinguish artifactual AIZs
from potential scenarios with non-artifactual extra-
cellular space expansion. The frequency of images
meeting these criteria for having AIZ artifacts was
calculated for each sample (Table 3). We found that

samples from a donated canine preserved after a
PMI of 1.5 hours yielded EM images with no AIZ
artifacts in either brain region. The brains from two
of the human donors, one with a PMI of 4.25 hours
(donor #7) and one with a PMI of 72 hours (donor
#37), also yielded EM images with no AIZ artifacts in
the cortical samples, but both of these brains had
AIZ artifacts detected in images from the thalamus
samples. The cortex and thalamus samples from the
other 7 brains produced EM images graded as
having AIZ artifacts in at least one of the five
available EM images.

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 11 of 27






Figure 4. Representative EM images graded as having or not having ambiguous interstitial zone (AIZ) artifacts. Five examples images are
shown that were graded as having AIZ artifacts: 30-T (b), 39-C (d), 59-C (f), 59-T (h), 66-T (j), as well as five examples that were not: 7-C
(a), 57-C (c), 65-C (e), 65-T (g), 66-C (i), where the number is the donor ID number, and then “-T” indicates that it is from the thalamus and
“-C” from the cortex. Scale bars: 1 µm.

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 12 of 27





We found that there was no significant rank
correlation between the PMI and the annotated AIZ
percentage in the images from either the cortex
(rho = 0.35, p = 0.327) or the thalamus (rho = 0.09,
p = 0.811). Similarly, we found no significant rank
correlation between the PMI and the percentage of
images graded as having AIZ artifacts in the samples
from either the cortex (rho = 0.27, p = 0.454) or the
thalamus (rho = 0.10, p = 0.790). We also found that
there was no significant rank correlation between
the fixation time and either of these metrics related
to the percentage of AIZs in either brain region (all
p-values > 0.1). Next, we found that there was a
significantly higher annotated AIZ percentage in
images from the thalamus than the cortex (mean in
thalamus = 28.8 %, mean in cortex = 15.2 %, t-test

p-value = 0.004). This result may reflect differences
in preservation quality, baseline differences
between the regions, or other factors. There was
also a non-significant regional trend in the
percentage of images graded as having AIZ artifacts,
which was higher in the thalamus than the cortex
(mean in thalamus = 80 %, mean in cortex = 46 %,
t-test p-value = 0.074).

We next performed a qualitative analysis of
the ssTEM data, which was derived from cortical
samples. First, synapses were identified in the
available image stacks, all of which could be traced
through the image stack until synapse termination
or the end of the image stack, without apparent loss
of structure (Figure 5). Next, we attempted to trace


Figure 5. Representative images in the serial section TEM data sets showing that synapses can be traced. Samples from the cortex of
donor IDs #7 (a), #35 (b), #65 (c). Synapses are highlighted in color. Scale bars: 1 µm.

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 13 of 27







Figure 6. Representative serial section image stack with annotations for afferent neurites from one synapse. All images are from a serial
section from the cortex sample of donor #65. Scale bars: 1 µm.

the neural connections arising from synapses to
their associated dendrites and axons across the
image stacks. Qualitatively, we found that for the
sample from donor #35, which had a more extensive
burden of AIZ artifacts on the 2D EM images, it was
more difficult to manually trace the neurite
structures. For the other two samples imaged with
ssTEM (donor IDs #7 and #65), we successfully

identified traceable neurites across the image stack
in at least some instances (for example, Figure 6).
However, we were unable to rigorously quantify the
traceability due to two key limitations: (a) an
insufficient sample size to establish reliable
metrics, and (b) technical constraints related
to our section thickness. Specifically, the resolution
between sequential images made it challenging to

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 14 of 27





differentiate between potential structural damage
and normal morphological variations where
processes might naturally terminate or significantly
change direction.

Preservation quality in light microscopy images

We next set out to compare preservation
quality between modalities. We started by perform-
ing an analysis of H&E-stained light microscopy
sections. These samples were obtained from the
contralateral hemisphere of the same brain
regions that were examined by electron microscopy.
We detected expected postmortem changes in
all images, including pericellular rarefactions,
perivascular rarefactions, and neuropil vacuolization
(Krassner et al., 2023). Qualitatively, the extent of
pericellular rarefaction and neuropil vacuolization
appeared to potentially be more pronounced in
some cases with longer PMIs. However, no obvious
differences in the preservation quality of cell
membrane morphology were observed that
corresponded with the PMI on these H&E-stained
images (Figure 7). Additionally, the postmortem
artifacts visualized did not have obvious qualitative
differences based on the fixation time. Taken
together, these findings suggest that basic cellular
morphology remains largely intact at the light
microscopy level in the samples from these brains,
despite the range of PMIs.

Notably, in cases where perfusion fixation was
performed, the extent to which perfusate was
successfully delivered to the brain regions examined
varied across cases, as evidenced by differences in
brain stiffness and the extent of blood clearance
from surface vessels. This variability is consistent
with previous findings on postmortem brain
perfusion (McFadden et al., 2019). As one additional
way to measure this, we assessed H&E-stained
images to measure the degree to which blood
vessels were cleared of material such as red blood
cells (Figure 8, Table 4). These data demonstrate
that blood vessels were not fully cleared, and
therefore, perfusion was not complete, in the

majority of the brains. This is further supported by
the observation that the immersion-fixed brain
(donor #57) had a similar grade for intravascular
material clearance as several of the perfusion-fixed
samples. To address a possible confounding
variable, we also found that there was no significant
rank correlation between the fixation time and the
intravascular material grade on the H&E images, in
the data from either the cortex (rho = 0.04,
p = 0.92) or the thalamus (rho = 0.24, p = 0.51).
Taken together, these results suggest that in cases
where a perfusion procedure was performed, the
fixative may not have fully penetrated the
vasculature throughout the brain, perhaps instead
only traversing through a subset of blood vessels.

We next performed immunohistochemical
staining to evaluate the preservation of specific
neural components across our samples.
Staining for SMI-312, a pan-axonal stain targeting
highly phosphorylated neurofilaments, revealed
consistent preservation of axonal architecture
across samples with varying PMIs (Figure 9) (Ulfig et
al., 1998). Even in samples with PMIs exceeding 60
hours, we observed well-defined axonal processes
with clear continuity and distinct morphology. In the
cortical samples, neurofilament-positive axons were
readily identifiable traversing throughout the
neuropil, with minimal disruption of their trajectory
detected on qualitative analysis.

Staining for SMI-311, an antibody targeting
non-phosphorylated neurofilaments that are
primarily located in the dendrites and perikarya, also
revealed consistent staining quality across samples
with varying PMIs (Figure 10) (Ulfig et al., 1998).
Dendritic morphology appeared to be largely intact,
without the diffuse staining that would be expected
with widespread breakdown of the dendritic
cytoskeleton. A key exception was the canine brain,
which did not stain adequately for this antibody in
either brain region, possibly reflecting molecular
differences in neurofilaments between human and
canine brains (Dimakopoulos and Mayer, 2002).

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 15 of 27







Figure 7. Representative H&E-stained images demonstrate that cell membrane morphology is generally intact across a wide range of
PMIs. Samples from the thalamus of donor IDs #7 (a, b), #65 (c, d), #57 (e, f), and #59 (g, h) with PMIs of 4.25 h, 1.5 h, 96 h, and 91 h,
respectively. Insets on the lower magnification images correspond to the regions shown in the higher magnification images. Scale bars:
(a, c, and g) 1 mm; (e) 2 mm; (b, d, f, and h) 50 μm.

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 16 of 27







Figure 8. Representative H&E-stained images from the thalamus showing variable vascular clearance. a, b: Images from donor #30 show
extensive intravascular material. c, d: Images from donor #59 show minimal intravascular material. Scale bars: (a, c) 2 mm; (b, d) 200 μm.

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 17 of 27







Figure 9. Representative SMI-312-stained images demonstrate that axonal morphology is generally intact across a wide range of PMIs.
Samples from the thalamus of donor IDs #65 (a), #78 (b), #7 (c), #37 (d), #59 (e), and #57 (f) with PMIs of 1.5 h, 2.5 h, 4.25 h, 72 h, 91 h,
and 96 h, respectively. Scale bars: 50 μm.

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 18 of 27







Figure 10. Representative SMI-311-stained images demonstrate that dendritosomatic morphology on light microscopy is generally intact
across a wide range of PMIs in human brains. Samples from the thalamus of donor IDs #78 (a), #7 (b), #30 (c), #37 (d), #59 (e), and #57 (f)
with PMIs of 2.5 h, 4.25 h, 17 h, 72 h, 91 h, and 96 h, respectively. Scale bars: 50 μm.


https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 19 of 27





Table 4: Semi-quantitative grades to evaluate preservation quality on light microscopy.

Donor ID PMI Fixation time Region Intravascular material grade on H&E images

7 4.25 hours 5 months
Thalamus 1

Cortex 1

30 17 hours 4 months
Thalamus 3

Cortex 1

34 20 hours 4 months
Thalamus 2

Cortex 2

37 72 hours 4 months
Thalamus 2

Cortex 2

55 36 hours 3 months
Thalamus 2

Cortex 1

57 96 hours 3 months
Thalamus 2

Cortex 2

59 91 hours 2.5 months
Thalamus 0

Cortex 2

65 1.5 hours 2 months
Thalamus 2

Cortex 1

66 61 hours 2 months
Thalamus 2

Cortex 2

78 2.5 hours 1 month
Thalamus 1

Cortex 1

The presence of intravascular material was graded on a scale of 0–3, where 0 indicates minimal intravascular material and 3 indicates
extensive intravascular material. PMI: Postmortem interval.


We next assessed immunostaining for the

astrocyte marker GFAP (Figure 11). In samples from
the thalamus, we observed that GFAP staining was
generally lower compared to the cortical samples,
with the exception of the subependymal area, which
consistently showed higher immunoreactivity. In the
cortical samples, the subpial area consistently had
the highest density of staining, which is expected
given previous findings about GFAP staining
patterns (Halliday et al., 1996). The density of GFAP
staining in the cortex appeared to be lower in some
cases with longer PMIs, which had very few
astrocytes stained by anti-GFAP (for example, see
Figure 11e). However, there was no robust trend for
lower GFAP staining with longer PMIs, as evidenced

by strong staining in some samples that had
relatively longer PMIs, such as one brain with
a PMI of 96 hours (Figure 11f). Moreover, when
GFAP-positive astrocytes were visible in the longer
PMI cases, the individual cells that were stained
appeared to still have intact morphology without
obvious signs of partial decomposition, arguing
against cellular decomposition playing the major
role in mediating staining differences. However,
given our relatively small sample size, we cannot
clearly distinguish the reasons for variability in GFAP
staining across samples.

In a subset (n = 6) of the samples, we also per-
formed immunostaining with vimentin (see data

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 20 of 27





availability for access to these WSIs). While this
marker did stain around blood vessels, its staining
for astrocytes appeared highly sensitive to the
duration of fixation, more so than GFAP, showing

only weak and inconsistent staining in samples fixed
for longer than one month. Due to this limitation of
vimentin staining, we did not extend the vimentin
staining to the full cohort.



Figure 11. Representative GFAP-stained images of the cortex show intact subpial astrocyte morphology in images from samples with a
wide range of PMIs. Samples from donor IDs #65 (a), #78 (b), #7 (c), #37 (d), #59 (e), and #57 (f) with PMIs of 1.5 h, 2.5 h, 4.25 h, 72 h, 91
h, and 96 h, respectively. Scale bars: 50 μm.



https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 21 of 27





Discussion

In this study, we first present a framework for
evaluating preservation quality in postmortem brain
tissue through the assessment of ultrastructural
integrity in EM images. We found that AIZ artifacts
occurred in at least one of the available EM images
from our tested samples, with the exception of a
canine sample with a relatively shorter PMI of 1.5
hours and two cortical samples from human donors.
Notably, in the cortical sample from the canine and
one of these two human cortical samples, we were
able to trace the neurites arising from synapses
across ssTEM image stacks in some instances,
though technical limitations and insufficient sample
volumes prevented rigorous quantification. Our
observations suggest that samples without AIZ
artifacts on 2D images may be a proxy for the degree
of ultrastructural integrity that could potentially
support connectomics studies, though this
requires more imaging and larger sample sizes for
corroboration. We also detected a trend towards a
higher percentage of AIZs in thalamic samples
compared to cortical ones. Given that our perfusion
quality was far from perfect, these observed
regional differences could be due to the deeper
thalamic structures being preserved more slowly by
the post-perfusion immersion fixation of the entire
brain, potentially leading to a longer period of
autolysis prior to preservation. Alternatively, the
result may also be due to statistical noise, baseline
differences between the regions, or other factors.
Next, we performed light microscopy on samples
from the same brains, using both non-specific
morphological staining as well as immunostaining
for neurofilaments and GFAP. The subjective quality
of the morphological staining and neurofilament
staining appeared similar across samples from all 10
brains, despite the varying PMIs and differences
observed on EM images. Our data suggests a
complex relationship between the imaging findings
and the underlying tissue preservation depending
on the imaging modality used, which warrants
further investigation.

Although our study identified several
challenges in this field, it is important to emphasize
the significant potential value that EM-based
connectomics could provide. While a complete
human brain connectome remains technologically

unfeasible, volume EM imaging of targeted brain
regions or circuits could complement emerging
whole-brain volumetric methods (Hillman et al.,
2019). Such focused volume EM studies could
be particularly valuable for investigating disease-
specific alterations in synaptic connectivity patterns.
For example, alterations in dendritic spine density
and synaptic connectivity have been reported in
schizophrenia, which has potentially significant
implications for the development of treatments for
this disorder (Glausier and Lewis, 2013). However,
pharmaceutical companies may not be confident
enough in existing ultrastructural biomarkers of
disease to pursue them as therapeutic targets, as
these findings have often been primarily reported in
relatively small tissue samples and in studies with
modest sample sizes. Studies with larger volumes
and larger sample sizes may be useful to corroborate
existing ultrastructural correlates of disease and
discover new ones, which could potentially be
achieved through the improved use of banked brain
samples.

An important variable in brain banking is the
agonal state of the donor, which includes factors
such as fever, hypoxia, acidosis, and alterations in
metabolism. Variability in the agonal state is often
found to have an even larger effect on brain tissue
quality than the PMI, and can affect cellular
morphology (Williams et al., 1978; Hardy et al.,
1985; Ohm and Diekmann, 1994; Paasila et al.,
2019). In addition to the direct effect on brain
structure, a prolonged or severe agonal phase is
likely to lead to the accumulation of thrombi and
other factors promoting impairment of postmortem
perfusion of the brain (McFadden et al., 2019). We
note that the canine brain sample was donated after
the canine was euthanized by a licensed
veterinarian, which entails effectively a negligible
agonal duration. This is likely another reason that
this brain had the highest ultrastructural quality, in
addition to the shorter PMI. Although the agonal
state is more difficult to quantify than the PMI, a
better understanding of how the agonal state
affects the quality of the tissue for downstream
research applications is a critical goal for brain
banking, in order to make the field more rigorous.

There is an extensive literature on the visuali-
zation of extracellular space in brain tissue, with

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 22 of 27





many aspects of the preservation procedure,
including the delivery technique, fixative, buffer,
and osmolarity, all significantly affecting it (Van
Harreveld and Malhotra, 1967; Cragg, 1980; Fix and
Garman, 2000; Korogod et al., 2015; Fulton and
Briggman, 2021). Living brain tissue generally
contains around 20 % extracellular space (Nicholson
and Syková, 1998). Standard methods of perfusion
fixation in laboratory animals, which involve a
minimal duration of ischemia prior to preservation,
can decrease the extracellular space (ECS) in an
artifactual manner from its typical in vivo volume
(Pallotto et al., 2015). Our findings suggest that
although there may be an initial decrease in the ECS
from in vivo levels with minimal PMI, which may
involve ischemic cell swelling, as the PMI progresses,
the ECS may once again grow to in vivo levels and
beyond as fluid redistributes. Indeed, one would
expect that given a sufficiently long PMI, the brain
would be entirely “extracellular,” as all of the
cellular structures would eventually break down and
the brain liquefy. Although we expect that molecular
decomposition and fluid redistribution are the most
likely explanation for AIZs, there are several
non-mutually exclusive explanations for the AIZs we
observed in our samples with longer PMIs. Some
degree of extracellular space is expected even in
ideally preserved tissue, and may in fact be desirable
as this better reflects in vivo conditions and can aid
in neurite tracing (Korogod et al., 2015; Pallotto et
al., 2015). However, the appearance of potential
debris alongside the expansion of the extracellular
space suggests a significant change from normal
tissue architecture. This is why our grading method
for AIZ artifacts takes into account both the
presence of AIZs and a qualitative determination of
poor cell membrane intactness.

One notable pattern we observed in our data is
that the occurrence of AIZ artifacts qualitatively
appears to coincide with other postmortem changes
involving fluid shifts. For example, images with AIZ
artifacts also tend to exhibit increased astrocyte
process swelling, vacuolization, and cytoplasmic
washout. This pattern is evident in both our images
and in other publicly available electron microscopy
data sets of postmortem human brain tissue (Oost
et al., 2023). These observations suggest that there
may be a generalized “excess fluid” phenomenon in
some postmortem brain tissue, with AIZ artifacts

being just one manifestation of this. Theoretically,
one possibility is that it may be possible to develop
sample preparation, staining, or analysis methods
that can partially adjust for the consequences of
excessive fluid accumulation, including AIZ
artifacts, potentially allowing for inference of neural
morphology despite these artifacts. A previous
approach to address extracellular space shrinkage in
EM images classified the space into sheet-like and
tunnel-like regions, then used computational
models to redistribute volume between these
compartments (Kinney et al., 2013). However, it is
highly questionable that approaches designed for
controlled shrinkage artifacts could be sufficient for
adjustment of postmortem brain EM images, as the
AIZ artifacts present are anisotropic, haphazard, and
enigmatic. Instead, more complex computational
approaches, developed in consideration of the
physiology of agonal and postmortem degradation,
would likely be required, to the extent that it is
feasible at all.

Our light microscopy findings provide
complementary data to help interpret the EM
results. H&E and immunohistochemical staining
revealed relatively well-preserved cellular
morphology in samples from the same brains that
had substantial changes on EM images. Particularly
notable was the integrity of neurofilament staining,
which allowed for visualization of axonal and
dendritic trajectories across substantial distances
despite varying PMIs. This is consistent with
previous data showing the robustness of
neurofilament antigen staining to extended PMI
(Ulfig et al., 1998; Blair et al., 2016; Bouvier et al.,
2016). As a result, our findings corroborate previous
observations that electron microscopy is more
sensitive to postmortem changes than light
microscopy (Krassner et al., 2023). One obvious
potential explanation for this difference is simply
that EM has better resolution and is therefore better
able to detect early, minute aspects of tissue
decomposition. It is also possible that relative
differences in the sensitivity of light microscopy and
EM staining procedures to postmortem changes
could help to explain the inconsistency between the
modalities. For example, osmium tetroxide, a key
staining agent for EM, has been found to bind
primarily to unsaturated fatty acids arranged in lipid
membranes (Wigglesworth, 1957, 1981; Belazi et al.,

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 23 of 27





2009; Li et al., 2024). Autolysis causes a rapid
release and redistribution of membrane lipids,
including unsaturated fatty acids, via the activity of
phospholipase A2 (van der Vusse et al., 1989; Pueyo
et al., 2000). If unsaturated fatty acids in lipid
membranes degrade relatively faster than proteins
in the PMI, then this would disproportionately affect
visualization following standard EM protocols,
compared to other methods that target protein
antigens. Notably, previous data has found that the
more lipid-dense myelinated axons are more
recognizable than unmyelinated axons via EM after
postmortem disintegration prior to fixation (Liewald
et al., 2014). As another possibility, cellular
structures might remain partially present during
the postmortem period, but their constituent
biomolecules could become insufficiently compact
for adequate visualization by non-specific morpho-
logical stains alone. Immunostaining, in particular,
may be better able to amplify partially intact
structures and therefore not be affected as rapidly
by the postmortem breakdown of gel-like
biomolecular networks as the typical non-specific
EM staining methods (Krassner et al., 2023). This
possibility would parallel light microscopy
studies on postmortem brain tissue, showing that
immunostaining can sometimes reveal cellular
structures not visible with non-specific morphologi-
cal stains (Monroy-Gómez et al., 2020). Further
research using complementary methods, such as
immunoelectron microscopy, correlative light and
electron microscopy, or expansion microscopy, may
help to clarify the reasons for the differences in
results between light and electron microscopy.

Several limitations should be considered when
interpreting our findings. First, our sample size of
ten brains obviously does not capture the full
spectrum of preservation quality variation seen in
brain banking. Information about the donors, such
as the PMI, may have inaccuracies, which becomes
a bigger problem with smaller sample sizes. As a
result, our findings will require larger subsequent
studies for corroboration. Second, our analysis of
the contralateral hemispheres for light and electron
microscopy introduces obvious potential confound-
ing factors. Preservation quality, including the
quality of perfusion, can clearly vary between the
hemispheres, which might affect our results. Third,

although formaldehyde alone has been used
successfully for fixation in some studies, others
recommend the addition of glutaraldehyde
(Gonzalez Aguilar and De Robertis, 1963; Westrum
and Lund, 1966; Lewis et al., 2019). On initial fixation
we used formaldehyde alone without the addition
of glutaraldehyde, which may have reduced the
ultrastructural quality of our resulting EM images. A
future study comparing post-perfusion immersion
fixation of small samples from the same brain with
either paraformaldehyde-glutaraldehyde or neutral
buffered formalin could directly test the relative
contribution of fixative composition to ultrastruc-
tural preservation quality. Fourth, our semi-quanti-
tative grading systems for the EM and immunohisto-
chemically stained images represent a simplified
assessment of complex data. Further, our analysis of
the light microscopy images was largely qualitative,
which renders this more vulnerable to bias. We
encourage any interested readers to analyze the raw
image data, all of which we have made available, to
come to their own conclusions. Lastly, our study
focused primarily on 2D ultrastructural features. The
implications for 3D connectivity reconstruction
remain speculative without more direct volumetric
data and analysis. These limitations highlight the
need for future studies with larger sample sizes and
more direct comparisons via multiple imaging
techniques.

Conclusions

Our study provides insights into the
relationship between preservation quality, PMI, and
imaging modality in banked brain tissue. We found
that the level of ultrastructural preservation
required for performing connectomics studies
appears to be achievable in some postmortem
samples. These findings suggest that under close to
optimal brain banking conditions, postmortem
human brain tissue could potentially be suitable for
connectomics studies using current EM methods.
However, in at least a subset of EM images from the
other samples, our analysis revealed the presence of
AIZ artifacts, which may indicate significant
challenges for the reliable tracing of neural
processes. These AIZ artifacts may result from true
structural degradation prior to fixation, inadequate

https://doi.org/10.17879/freeneuropathology-2025-6763


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 24 of 27





visualization of thin axons and other cellular
components, or both. Notably, our light microscopy
data from these same brains indicates that many
cellular structures remain intact and potentially
traceable at this level of resolution via
neurofilament staining. This suggests a difference
between preservation quality as observed via
different imaging modalities. However, this is not
necessarily surprising, because while both light and
electron microscopy can provide windows into cell
membrane morphology, they examine structures at
different resolutions and thus can be considered
complementary. To advance connectomics research
using banked brain tissue, further methodological
development may be valuable. Current approaches
can only reliably visualize key ultrastructural
features in a small subset of banked brain samples,
constraining the possible sample sizes. It is not yet
clear if these are the true biological limits to ultra-
structural visualization. Future research could
focus on optimizing fixation protocols, staining
techniques, and computational methods specifically
for postmortem brain tissue. Such research may be
critical for realizing the full potential of human brain
connectomics as a tool for understanding neural
circuit organization in both health and disease.

Author contributions

A.K., M.G., K.F., J.C., and A.T.M. conceptualized
the article. A.S. and W.J. performed electron
microscopy experiments. E.T. and C.D.S. performed
light microscopy experiments. A.K., M.G., and
A.T.M. performed data analysis. A.T.M. wrote the
initial draft of the manuscript. All authors reviewed
the manuscript. All authors approved the final
manuscript.

Acknowledgements

We would like to acknowledge the technical
assistance of Laura Paredes and Alexander Parra,

and we would like to thank Kenneth Hayworth for
helpful personal communications on this topic. We
acknowledge the Neuropathology Brain Bank &
Research CoRE at the Icahn School of Medicine at
Mount Sinai for their histology and tissue processing
services. Electron microscopy tissue preparation
and imaging were performed at The Microscopy and
Advanced Bioimaging CoRE at the Icahn School of
Medicine at Mount Sinai. The Icahn School of
Medicine at Mount Sinai provided access to library
resources.

Funding statement

This work was supported by the Rainwater
Charitable Foundation as well as NIH grants P30
AG066514, K01 AG070326, RF1 AG062348, P30
AG066514, RF1 NS095252, U54 NS115266, and RF1
MH128969. The funders had no role in the design of
the study or in the collection or interpretation of the
data.

Conflict of interest statement

Alicia Keberle, Macy Garrood, and Andrew
McKenzie are employees of Oregon Brain
Preservation, a non-profit brain preservation
organization. Andrew McKenzie is a director of Apex
Neuroscience, a non-profit research organization.

Data availability

Code used for data analysis is available here:
https://github.com/andymckenzie/Ultrastructure_
quality_manuscript. All raw image data can be
accessed in a public repository on Zenodo, available
here: https://zenodo.org/communities/evaluating
ultrastructuralpreservationqualityinbankedbraintis-
sue/



https://doi.org/10.17879/freeneuropathology-2025-6763
https://github.com/andymckenzie/Ultrastructure_quality_manuscript
https://github.com/andymckenzie/Ultrastructure_quality_manuscript
https://zenodo.org/communities/evaluatingultrastructuralpreservationqualityinbankedbraintissue/
https://zenodo.org/communities/evaluatingultrastructuralpreservationqualityinbankedbraintissue/
https://zenodo.org/communities/evaluatingultrastructuralpreservationqualityinbankedbraintissue/


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 25 of 27





References

Adams, J.H., Murray, M.F., 1982. Atlas of post-mortem techniques in
neuropathology. Cambridge University Press.
https://doi.org/10.1017/CBO9780511735479

Belazi, D., Solé-Domènech, S., Johansson, B., Schalling, M., Sjövall, P.,
2009. Chemical analysis of osmium tetroxide staining in adipose tissue
using imaging ToF-SIMS. Histochem. Cell Biol. 132, 105–115.
https://doi.org/10.1007/s00418-009-0587-z

Blair, J.A., Wang, C., Hernandez, D., Siedlak, S.L., Rodgers, M.S., Achar,
R.K., Fahmy, L.M., Torres, S.L., Petersen, R.B., Zhu, X., Casadesus, G., Lee,
H.G., 2016. Individual Case Analysis of Postmortem Interval Time on
Brain Tissue Preservation. PloS one 11, e0151615.
https://doi.org/10.1371/journal.pone.0151615

Bouvier, D.S., Jones, E.V., Quesseveur, G., Davoli, M.A., A Ferreira, T.,
Quirion, R., Mechawar, N., Murai, K.K., 2016. High Resolution Dissection
of Reactive Glial Nets in Alzheimer’s Disease. Sci Rep 6, 24544.
https://doi.org/10.1038/srep24544

Chiappini, V., Castillo, M.F.V., Biancardi, F., Di Cunto, F., Magistretti, P.J.,
Vercelli, A., Agus, M., Calì, C., 2025. Ultrastructure of astrocytes using
volume electron microscopy: A scoping review. J Physiol.
https://doi.org/10.1113/JP287455

Cragg, B., 1980. Preservation of extracellular space during fixation of the
brain for electron microscopy. Tissue Cell 12, 63–72.
https://doi.org/10.1016/0040-8166(80)90052-x

Deerinck, T.J., Bushong, E.A., Thor, A., Ellisman, M.H., 2010. NCMIR
methods for 3D EM: a new protocol for preparation of biological
specimens for serial block face scanning electron microscopy. Micro-
scopy 1, 6–8. https://api.semanticscholar.org/CorpusID:136219796

Dimakopoulos, A.C., Mayer, R.J., 2002. Aspects of neurodegeneration in
the canine brain. J Nutr 132, 1579S–82S.
https://doi.org/10.1093/jn/132.6.1579S

Eberhardt, F., Bushong, E.A., Phan, S., Peltier, S., Monteagudo, P.,
Weinkauf, T., Herz, A.V.M., Stemmler, M., Ellisman, M., 2022. A uniform
and isotropic cytoskeletal tiling fills dendritic spines. eNeuro ENEURO.
0342-22.2022. https://doi.org/10.1523/ENEURO.0342-22.2022

Fix, A.S., Garman, R.H., 2000. Practical aspects of neuropathology: a
technical guide for working with the nervous system. Toxicol Pathol 28,
122–131. https://doi.org/10.1177/019262330002800115

Fulton, K.A., Briggman, K.L., 2021. Permeabilization-free en bloc
immunohistochemistry for correlative microscopy. eLife 10, e63392.
https://doi.org/10.7554/eLife.63392

Garman, R.H., 2011. Common Histological Artifacts in Nervous System
Tissues, in: Fundamental Neuropathology for Pathologists and
Toxicologists. John Wiley & Sons, Ltd, pp. 191–201.
https://doi.org/10.1002/9780470939956.ch13

Glausier, J.R., Lewis, D.A., 2013. Dendritic spine pathology in
schizophrenia. Neuroscience 251, 90–107.
https://doi.org/10.1016/j.neuroscience.2012.04.044

Gonzalez Aguilar, F., De Robertis, E., 1963. A Formalin-Perfusion Fixation
Method for Histophysiological Study of the Central Nervous System
With the Electron Microscope. Neurology 13, 758–771.
https://doi.org/10.1212/wnl.13.9.758

Halliday, G.M., Cullen, K.M., Kril, J.J., Harding, A.J., Harasty, J., 1996. Glial
fibrillary acidic protein (GFAP) immunohistochemistry in human cortex:
a quantitative study using different antisera. Neurosci Lett 209, 29–32.
https://doi.org/10.1016/0304-3940(96)12592-1

Hardy, J.A., Wester, P., Winblad, B., Gezelius, C., Bring, G., Eriksson, A.,
1985. The patients dying after long terminal phase have acidotic brains;
implications for biochemical measurements on autopsy tissue. J Neural
Transm 61, 253–264. https://doi.org/10.1007/BF01251916

Hillman, E.M.C., Voleti, V., Li, W., Yu, H., 2019. Light-Sheet Microscopy
in Neuroscience. Annu Rev Neurosci 42, 295–313.
https://doi.org/10.1146/annurev-neuro-070918-050357

Karlupia, N., Schalek, R.L., Wu, Y., Meirovitch, Y., Wei, D., Charney, A.W.,
Kopell, B.H., Lichtman, J.W., 2023. Immersion Fixation and Staining of
Multicubic Millimeter Volumes for Electron Microscopy-Based
Connectomics of Human Brain Biopsies. Biol Psychiatry 94, 352–360.
https://doi.org/10.1016/j.biopsych.2023.01.025

Kinney, J.P., Spacek, J., Bartol, T.M., Bajaj, C.L., Harris, K.M., Sejnowski,
T.J., 2013. Extracellular Sheets and Tunnels Modulate Glutamate
Diffusion in Hippocampal Neuropil. J Comp Neurol 521, 448–464.
https://doi.org/10.1002/cne.23181

Korogod, N., Petersen, C.C., Knott, G.W., 2015. Ultrastructural analysis
of adult mouse neocortex comparing aldehyde perfusion with cryo
fixation. eLife 4, e05793. https://doi.org/10.7554/eLife.05793

Krassner, M.M., Kauffman, J., Sowa, A., Cialowicz, K., Walsh, S., Farrell,
K., Crary, J.F., McKenzie, A.T., 2023. Postmortem changes in brain cell
structure: a review. Free Neuropathol 4, 4–10.
https://doi.org/10.17879/freeneuropathology-2023-4790

Lewis, A.J., Genoud, C., Pont, M., van de Berg, W.D., Frank, S., Stahlberg,
H., Shahmoradian, S.H., Al-Amoudi, A., 2019. Imaging of post-mortem
human brain tissue using electron and X-ray microscopy. Current
Opinion in Structural Biology 58, 138–148.
https://doi.org/10.1016/j.sbi.2019.06.003

Li, R., Wildenberg, G., Boergens, K., Yang, Y., Weber, K., Rieger, J.,
Arcidiacono, A., Klie, R., Kasthuri, N., King, S.B., 2024. OsO2 as the
Contrast-Generating Chemical Species of Osmium-Stained Biological
Tissues in Electron Microscopy. Chembiochem 25, e202400311.
https://doi.org/10.1002/cbic.202400311

Lichtman, J.W., Pfister, H., Shavit, N., 2014. The big data challenges of
connectomics. Nat Neurosci 17, 1448–1454.
https://doi.org/10.1038/nn.3837

Liewald, D., Miller, R., Logothetis, N., Wagner, H.-J., Schüz, A., 2014.
Distribution of axon diameters in cortical white matter: an electron-
microscopic study on three human brains and a macaque. Biol Cybern
108, 541–557. https://doi.org/10.1007/s00422-014-0626-2

McFadden, W.C., Walsh, H., Richter, F., Soudant, C., Bryce, C.H., Hof,
P.R., Fowkes, M., Crary, J.F., McKenzie, A.T., 2019. Perfusion fixation in
brain banking: a systematic review. Acta Neuropathol Commun 7, 146.
https://doi.org/10.1186/s40478-019-0799-y

McKee, A.C., 1999. Brain banking: basic science methods. Alzheimer Dis
Assoc Disord 13 Suppl 1, S39-44. PMID: 10369517

McKenzie, A.T., Nnadi, O., Slagell, K.D., Thorn, E.L., Farrell, K., Crary, J.F.,
2024. Fluid preservation in brain banking: a review. Free Neuropathol 5,
5–10. https://doi.org/10.17879/freeneuropathology-2024-5373

McKenzie, A.T., Woodoff-Leith, E., Dangoor, D., Cervera, A., Ressler, H.,
Whitney, K., Dams-O’Connor, K., Wu, Z., Hillman, E.M.C., Seifert, A.C.,
Crary, J.F., 2022. Ex situ perfusion fixation for brain banking: a technical
report. Free Neuropathology 3, 22–22.
https://doi.org/10.17879/freeneuropathology-2022-4368

https://doi.org/10.17879/freeneuropathology-2025-6763
https://doi.org/10.1017/CBO9780511735479
https://doi.org/10.1007/s00418-009-0587-z
https://doi.org/10.1371/journal.pone.0151615
https://doi.org/10.1038/srep24544
https://doi.org/10.1113/JP287455
https://doi.org/10.1016/0040-8166(80)90052-x
https://api.semanticscholar.org/CorpusID:136219796
https://doi.org/10.1093/jn/132.6.1579S
https://doi.org/10.1523/ENEURO.0342-22.2022
https://doi.org/10.1177/019262330002800115
https://doi.org/10.7554/eLife.63392
https://doi.org/10.1002/9780470939956.ch13
https://doi.org/10.1016/j.neuroscience.2012.04.044
https://doi.org/10.1212/wnl.13.9.758
https://doi.org/10.1016/0304-3940(96)12592-1
https://doi.org/10.1007/BF01251916
https://doi.org/10.1146/annurev-neuro-070918-050357
https://doi.org/10.1016/j.biopsych.2023.01.025
https://doi.org/10.1002/cne.23181
https://doi.org/10.7554/eLife.05793
https://doi.org/10.17879/freeneuropathology-2023-4790
https://doi.org/10.1016/j.sbi.2019.06.003
https://doi.org/10.1002/cbic.202400311
https://doi.org/10.1038/nn.3837
https://doi.org/10.1007/s00422-014-0626-2
https://doi.org/10.1186/s40478-019-0799-y
https://pubmed.ncbi.nlm.nih.gov/10369517/
https://doi.org/10.17879/freeneuropathology-2024-5373
https://doi.org/10.17879/freeneuropathology-2022-4368


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 26 of 27





Monroy-Gómez, J., Santamaría, G., Sarmiento, L., Torres-Fernández, O.,
2020. Effect of Postmortem Degradation on the Preservation of Viral
Particles and Rabies Antigens in Mice Brains. Light and Electron
Microscopic Study. Viruses 12, E938.
https://doi.org/10.3390/v12090938

Nahirney, P.C., Tremblay, M.-E., 2021. Brain Ultrastructure: Putting the
Pieces Together. Front Cell Dev Biol 9, 629503.
https://doi.org/10.3389/fcell.2021.629503

Nicholson, C., Syková, E., 1998. Extracellular space structure revealed by
diffusion analysis. Trends Neurosci 21, 207–215.
https://doi.org/10.1016/s0166-2236(98)01261-2

Ohm, T.G., Diekmann, S., 1994. The use of Lucifer Yellow and Mini-Ruby
for intracellular staining in fixed brain tissue: methodological
considerations evaluated in rat and human autopsy brains. J Neurosci
Methods 55, 105–110. https://doi.org/10.1016/0165-0270(94)90046-9

Oost, W., Huitema, A.J., Kats, K., Giepmans, B.N.G., Kooistra, S.M.,
Eggen, B.J.L., Baron, W., 2023. Pathological ultrastructural alterations of
myelinated axons in normal appearing white matter in progressive
multiple sclerosis. Acta Neuropathol Commun 11, 100.
https://doi.org/10.1186/s40478-023-01598-7

Paasila, P.J., Davies, D.S., Kril, J.J., Goldsbury, C., Sutherland, G.T., 2019.
The relationship between the morphological subtypes of microglia and
Alzheimer’s disease neuropathology. Brain Pathol 29, 726–740.
https://doi.org/10.1111/bpa.12717

Palay, S.L., McGee-Russell, S.M., Gordon, S., Grillo, M.A., 1962. Fixation
of neural tissues for electron microscopy by perfusion with solutions of
osmium tetroxide. J Cell Biol 12, 385–410.
https://doi.org/10.1083/jcb.12.2.385

Pallotto, M., Watkins, P.V., Fubara, B., Singer, J.H., Briggman, K.L., 2015.
Extracellular space preservation aids the connectomic analysis of neural
circuits. Elife 4, e08206. https://doi.org/10.7554/eLife.08206

Plaza-Alonso, S., Cano-Astorga, N., DeFelipe, J., Alonso-Nanclares, L.,
2025. Volume electron microscopy reveals unique laminar synaptic
characteristics in the human entorhinal cortex. Elife 14, e96144.
https://doi.org/10.7554/eLife.96144

Pueyo, E., Martínez-Rodríguez, A., Polo, M.C., Santa-María, G.,
Bartolomé, B., 2000. Release of lipids during yeast autolysis in a model
wine system. J Agric Food Chem 48, 116–122.
https://doi.org/10.1021/jf990036e

Sándor, S., Czeibert, K., Salamon, A., Kubinyi, E., 2021. Man’s best friend
in life and death: scientific perspectives and challenges of dog brain
banking. Geroscience 43, 1653–1668.
https://doi.org/10.1007/s11357-021-00373-7

Schiff, R.I., Gennaro Jr., J.F., 1979. The role of the buffer in the fixation
of biological specimens for transmission and scanning electron
microscopy. Scanning 2, 135–148.
https://doi.org/10.1002/sca.4950020304

Sele, M., Wernitznig, S., Lipovšek, S., Radulović, S., Haybaeck, J., Birkl-
Toeglhofer, A.M., Wodlej, C., Kleinegger, F., Sygulla, S., Leoni, M.,
Ropele, S., Leitinger, G., 2019. Optimization of ultrastructural
preservation of human brain for transmission electron microscopy after
long post-mortem intervals. Acta Neuropathol Commun 7, 144.
https://doi.org/10.1186/s40478-019-0794-3

Shafiei, N., Stӓhli, D., Burger, D., Fabrizio, M.D., Heuvel, L. van den,
Daraspe, J., Böing, C., Shahmoradian, S.H., Berg, W.D. van de, Genoud,
C., Stahlberg, H., Lewis, A.J., 2024. Correlative light and electron
microscopy for human brain and other biological models.
https://doi.org/10.1101/2024.06.11.598271

Shapson-Coe, A., Januszewski, M., Berger, D.R., Pope, A., Wu, Y., Blakely,
T., Schalek, R.L., Li, P.H., Wang, S., Maitin-Shepard, J., Karlupia, N.,
Dorkenwald, S., Sjostedt, E., Leavitt, L., Lee, D., Troidl, J., Collman, F.,
Bailey, L., Fitzmaurice, A., Kar, R., Field, B., Wu, H., Wagner-Carena, J.,
Aley, D., Lau, J., Lin, Z., Wei, D., Pfister, H., Peleg, A., Jain, V., Lichtman,
J.W., 2024. A petavoxel fragment of human cerebral cortex
reconstructed at nanoscale resolution. Science 384, eadk4858.
https://doi.org/10.1126/science.adk4858

Shiu, P.K., Sterne, G.R., Spiller, N., Franconville, R., Sandoval, A., Zhou,
J., Simha, N., Kang, C.H., Yu, S., Kim, J.S., Dorkenwald, S., Matsliah, A.,
Schlegel, P., Yu, S.-C., McKellar, C.E., Sterling, A., Costa, M., Eichler, K.,
Bates, A.S., Eckstein, N., Funke, J., Jefferis, G.S.X.E., Murthy, M., Bidaye,
S.S., Hampel, S., Seeds, A.M., Scott, K., 2024. A Drosophila
computational brain model reveals sensorimotor processing. Nature
634, 210–219. https://doi.org/10.1038/s41586-024-07763-9

Small, J.V., 1981. Organization of actin in the leading edge of cultured
cells: influence of osmium tetroxide and dehydration on the
ultrastructure of actin meshworks. J Cell Biol 91, 695–705.
https://doi.org/10.1083/jcb.91.3.695

Snyder, J.M., Radaelli, E., Goeken, A., Businga, T., Boyden, A.W.,
Karandikar, N.J., Gibson-Corley, K.N., 2022. Perfusion with 10 % neutral-
buffered formalin is equivalent to 4 % paraformaldehyde for
histopathology and immunohistochemistry in a mouse model of
experimental autoimmune encephalomyelitis. Veterinary pathology 59,
498. https://doi.org/10.1177/03009858221075588

Sosinsky, G.E., Crum, J., Jones, Y.Z., Lanman, J., Smarr, B., Terada, M.,
Martone, M.E., Deerinck, T.J., Johnson, J.E., Ellisman, M.H., 2008. The
combination of chemical fixation procedures with high pressure freezing
and freeze substitution preserves highly labile tissue ultrastructure for
electron tomography applications. J Struct Biol 161, 359–371.
https://doi.org/10.1016/j.jsb.2007.09.002

Sotelo, C., 2020. The History of the Synapse. Anat Rec (Hoboken) 303,
1252–1279. https://doi.org/10.1002/ar.24392

Turkoglu, E., Seckin, H., Gurer, B., Ahmed, A., Uluc, K., Pulfer, K., Arat,
A., Niemann, D., Baskaya, M.K., 2014. The cadaveric perfusion and
angiography as a teaching tool: imaging the intracranial vasculature in
cadavers. J Neurol Surg B Skull Base 75, 435–444.
https://doi.org/10.1055/s-0034-1386653

Uffelmann, E., Huang, Q.Q., Munung, N.S., de Vries, J., Okada, Y., Martin,
A.R., Martin, H.C., Lappalainen, T., Posthuma, D., 2021. Genome-wide
association studies. Nat Rev Methods Primers 1, 1–21.
https://doi.org/10.1038/s43586-021-00056-9

Ulfig, N., Nickel, J., Bohl, J., 1998. Monoclonal antibodies SMI 311 and
SMI 312 as tools to investigate the maturation of nerve cells and axonal
patterns in human fetal brain. Cell Tissue Res 291, 433–443.
https://doi.org/10.1007/s004410051013

van der Vusse, G.J., de Groot, M.J., Willemsen, P.H., van Bilsen, M.,
Schrijvers, A.H., Reneman, R.S., 1989. Degradation of phospholipids and
triacylglycerol, and accumulation of fatty acids in anoxic myocardial
tissue, disrupted by freeze-thawing. Mol Cell Biochem 88, 83–90.
https://doi.org/10.1007/BF00223428

Van Harreveld, A., Malhotra, S.K., 1967. Extracellular space in the
cerebral cortex of the mouse. J Anat 101, 197–207. PMID: 6040073

Wahyudi, D.P., Makkiyah, F.A., Buana, G.R., 2025. A comparative
analysis of transcardial perfusion techniques for brain fixation in
rodents: A call for standardization of transcardial perfusion. The Health
Researcher’s Journal 2, 7–13. https://doi.org/10.00000/6nrjth51



https://doi.org/10.17879/freeneuropathology-2025-6763
https://doi.org/10.3390/v12090938
https://doi.org/10.3389/fcell.2021.629503
https://doi.org/10.1016/s0166-2236(98)01261-2
https://doi.org/10.1016/0165-0270(94)90046-9
https://doi.org/10.1186/s40478-023-01598-7
https://doi.org/10.1111/bpa.12717
https://doi.org/10.1083/jcb.12.2.385
https://doi.org/10.7554/eLife.08206
https://doi.org/10.7554/eLife.96144
https://doi.org/10.1021/jf990036e
https://doi.org/10.1007/s11357-021-00373-7
https://doi.org/10.1002/sca.4950020304
https://doi.org/10.1186/s40478-019-0794-3
https://doi.org/10.1101/2024.06.11.598271
https://doi.org/10.1126/science.adk4858
https://doi.org/10.1038/s41586-024-07763-9
https://doi.org/10.1083/jcb.91.3.695
https://doi.org/10.1177/03009858221075588
https://doi.org/10.1016/j.jsb.2007.09.002
https://doi.org/10.1002/ar.24392
https://doi.org/10.1055/s-0034-1386653
https://doi.org/10.1038/s43586-021-00056-9
https://doi.org/10.1007/s004410051013
https://doi.org/10.1007/BF00223428
https://pubmed.ncbi.nlm.nih.gov/6040073/
https://doi.org/10.00000/6nrjth51


Free Neuropathology 6:13 (2025) Garrood et al
DOI: https://doi.org/10.17879/freeneuropathology-2025-6763 page 27 of 27





Wang, N.S., Minassian, H., 1987. The formaldehyde-fixed and paraffin-
embedded tissues for diagnostic transmission electron microscopy: a
retrospective and prospective study. Hum Pathol 18, 715–727.
https://doi.org/10.1016/s0046-8177(87)80243-5

Westrum, L.E., Lund, R.D., 1966. Formalin perfusion for correlative light-
and electron-microscopical studies of the nervous system. Journal of
Cell Science 1, 229–238. https://doi.org/10.1242/jcs.1.2.229

Wigglesworth, V.B., 1981. The distribution of lipid in the cell structure:
an improved method for the electron microscope. Tissue Cell 13, 19–34.
https://doi.org/10.1016/0040-8166(81)90035-5

Wigglesworth, V.B., 1957. The use of osmium in the fixation and staining
of tissues. Proc R Soc Lond B Biol Sci 147, 185–199.
https://doi.org/10.1098/rspb.1957.0043

Williams, R.S., Ferrante, R.J., Caviness, V.S., 1978. The Golgi rapid
method in clinical neuropathology: the morphologic consequences of
suboptimal fixation. Journal of neuropathology and experimental
neurology 37, 13–33.
https://doi.org/10.1097/00005072-197801000-00002





https://doi.org/10.17879/freeneuropathology-2025-6763
https://doi.org/10.1016/s0046-8177(87)80243-5
https://doi.org/10.1242/jcs.1.2.229
https://doi.org/10.1016/0040-8166(81)90035-5
https://doi.org/10.1098/rspb.1957.0043
https://doi.org/10.1097/00005072-197801000-00002

	Original Paper
	Abbreviations
	Introduction
	Methods
	Brain banking procedures
	Electron microscopy
	Light microscopy

	Results
	Preservation quality in electron microscopy images
	Preservation quality in light microscopy images

	Discussion
	Conclusions
	Author contributions
	Acknowledgements
	Funding statement
	Conflict of interest statement
	Data availability
	References
