SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages
01-13

1







Article

Microstructured pebble stone like Ni-NiO

composite as anode of high-performance lithium-

ion batteries
Safina-E-Tahura Siddiqui1, Md. Arafat Rahman1*, Md. Saiful Islam2, Jin-Hyuk Kim3, Nirjhor
Barua1

1Department of Mechanical Engineering, Chittagong University of Engineering and Technology, Chittagong-4349,

Bangladesh
2Department of Glass and Ceramic Engineering, Bangladesh University of Engineering and Technology, Dhaka, Bangladesh
3Clean Energy R&D Department, Korea Institute of Industrial Technology, 89 Yangdaegiro-gil, Ipjang-myeon, Seobuk-gu,

Cheonan-si, Chungcheongnam-do, 31056, Republic of Korea

               A R T I C L E   I N F O


Article history:
Received 10 September 2023
Received in revised form
14 October 2023
Accepted 27 October 2023

Keywords:
Thermal oxidation, NiO, Composite,
Anode, LIBs

*Corresponding author
Email address:
arafat@cuet.ac.bd


DOI: 10.55670/fpll.fusus.2.1.1


A B S T R A C T


Ni-NiO electrodes were synthesized via thermal oxidation of pure nickel

powder and evaluated as anode of lithium-ion batteries (LIBs). The composite

synthesized at 600˚C, 800˚C, and 1000˚C exhibited nanochips, crushed gravel

stone, and pebble stone-like morphology, respectively. The nanochips- and

crushed gravel stone featured-like electrodes exhibited erratic behavior, and

specific capacity faded rapidly from 754.49 mAh g -1 and 101.12 mAh g-1 to

464.04 mAh g-1 and 9.55 mAh g-1, respectively over 10th cycle at a current rate

of 1C as the electrode experiences internal short circuit. The pebble stone-like

Ni-NiO electrode exhibited improved and stable cyclic performance with 1 st

discharge capacity of 365.17 mAh g-1 and reduced to 67.42 mAh g-1 even after

40th cycle at 1C current rate. The improved electrochemical performance of

composite Ni-NiO with a pebble stone-like feature can be attributed to the

mechanical stability of the electrode, which can buffer volume expansion, and

the presence of more nanoparticles on the electrode surface allows more

interaction with Li+.



1. Introduction
Lithium-ion batteries (LIBs) have acquired immense

attention and popularity as rechargeable batteries for
portable consumer electronics applications due to high
gravimetric and volumetric energy density, zero memory

effect, and low self-discharge rate [1]. Besides consumer
electronics, LIBs are being employed in aerospace, military

applications, grid energy storage, electric vehicles (EV),
hybrid electric vehicles (HEV), and plug-in hybrid electric
vehicles (PHEV) [1–4]. The implication of these batteries is

that they mitigate the environmental pollution resulting from

the burning of fossil fuels [5]. It is noted that graphite is

employed as an anode in commercial LIBs as it is inexpensive,
has high reversibility during the charge/discharge process,
and has excellent stability. However, its cycling capacity is

restricted due to possessing low theoretical capacity (372

mAh g-1) [6,7], which cannot fulfill the market demand for

next-generation rechargeable LIBs. Moreover, graphite anode
experiences extensive structural deterioration upon cycling

that leads to drastic capacity fading; high polarization
initiates lithium dendrite formation and low operating
voltage [8]. From that quest, establishing a favorable anode

material with high capacity, environmentally benign, and rate
performance is very crucial to advancing the performance of

LIBs [9–12]. In addition, pure alloys as LIB anodes face some
issues, for instance, volume expansion and electrode
fracturing during the lithiation process, which causes

mechanical fracture of active electrode particles, resulting in

electrical detachment and capacity fade and unstable SEI

formation [13–15]. However, titanium-based oxides are
investigated as the anode; it can eradicate the issues
regarding alloy anodes with a long cycle life since it has no SEI

and just a 1% volume change. Unfortunately, with a 1.5V

versus Li/Li+ operating voltage, as well as a limiting specific

Future Sustainability

Open Access Journal

https://doi.org/10.55670/fpll.fusus.2.1.1

























February 2024| Volume 02 | Issue 01 | Pages 01-13

Journal homepage: https://fupubco.com/fusus


ISSN 2995-0473

mailto:arafat@cuet.ac.bd
https://doi.org/10.55670/fpll.fusus.2.1.1
https://fupubco.com/fusus


SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

2



capacity of 160 Ah kg-1, the battery energy density is reduced
[16]. Among all anode materials, Transition metal oxides

(TMOs) are recognized as the most suitable anode materials

for LIB due to their high theoretical capacity, natural

affluence, eco-friendly nature, cost-effective fabrication
procedure, and chemically durable [17–23]. Moreover, TMOs
as anode material eliminate the problem of lithium dendrite

formation, safety issues, and low specific capacity. It is noted
that TMOs encounter some issues, such as rapid capacity

depletion due to volume-induced strain during
electrochemical cycling, resulting in intense polarization and
electrode pulverization [24–27]. To address these issues,

nanostructured TMOs are being employed because of their
large electrode/electrolyte contact area, short diffusion

length, and efficient strain accommodation [28,29]. NiO is a
competitive candidate among other TMOs and is explored
widely as an alternative electrode material for high-

performance LIBs due to its high theoretic capacity of 718
mAh g-1, cost-effectiveness, environment benignity, and

natural abundance [30]. The density of NiO is 6.81 g cm-3,

which is three times higher as compared with graphite of 2.26
g cm-3. The theoretical energy density of NiO is about 5.8 times

higher than graphite [31]. Nevertheless, the practical
application of NiO in LIBs is still obstructed because of its

excessive volume variation and destruction of the active

electrode material, as well as poor ionic conductivity, which
results in poor electrochemical performance [32, 33]. To

alleviate these issues, various morphologies of NiO are
studied to analyze electrochemical performance, for instance,

porous, mesoporous structures [36],  nanocomposite [31, 37,
38], nanogravel [23], nanosheets [39, 40], nanowalls [41],

nanofibers [42], hollow nanotubes [43], nanofilms [44],

nanowires [45], hierarchical structures [46–50], nanocone
array [51], composited with carbon [52–55] or conductive

polymers [56,57] have been investigated, which in
comparison to graphite and pure NiO exhibited improved

electrochemical performance. In addition, several strategies
such as hydrothermal, microwave hydrothermal, co-
precipitation, sol-gel method, pyrogenation, solvothermal,

chemical emersion, spray pyrolysis, powder metallurgy and
annealing is adopted to fabricate different NiO

nanostructures [58,59]. Among these strategies, thermal

oxidation of Ni powder is considered a facile and cost-
effective process, which can be adapted to synthesize unique

morphological structures. Numerous investigations were
carried out regarding electrochemical performance

evaluation of NiO synthesized through thermal oxidation [31,

51, 60, 61]. In some studies, NiO was combined with carbon
to form composites, which exhibit excellent cycling stability

[62–64]. However, the composite synthesis process is tedious
and the existence of low-density carbon greatly reduces the

volumetric specific capacity. In addition, the inclusion of high-
density metals can contribute to enhancing electrochemical

performances [65,66]. Huang et al. prepared Ni-NiO

nanocomposite through calcination in a tube furnace at 700⁰C
[66]. The nanocomposite constitutes <10 nm of Ni particles

and 100 nm of NiO particles. The enhanced electrochemical
performance of electrodes due to the presence of the metallic

Ni phase facilitates a more reversible reaction during the

charging process. Comparatively, strong polarization was
monitored owing to the presence of crystal defects. The rate

capability and cycling performance were not satisfactory due
to the slow kinetics of NiO particles and the transportation of

electrons. Therefore, considerable research is required to be

done to acquire stable cycling performance and rate

capability of NiO as LIB anode material.  In this specific study,
we synthesized microstructured composite of Ni-NiO through
a single-step thermal oxidation process and mechanical ball

milling. The composite structures were employed as anodes
and provided efficient electrolyte access throughout the

structure, which resulted in high discharge capacity and
excellent cycling performance. In addition, the synthesized
composite electrode exhibited different morphology at

different oxidation temperatures. The presence of the
metallic Ni phase facilitates the reverse decomposition

process and improves electrical conductivity. It can be
foreseen as a high-performance LIB electrode.

2. Experimental
2.1 Synthesis of Ni-NiO nanocomposite

The composite Ni-NiO fabrication involves a single-step

thermal oxidation process in an electric furnace (Nabertherm,

USA) at three distinct temperatures, as shown in Figure 1.





Figure 1. Schematic representation of Ni-NiO composite synthesis
process


Thermal oxidation is the method of growing a thin oxide

layer on the surface of a wafer, which follows Wagner’s

theory, as shown in Figure 2. The commercially available Ni

powder (99.8% purity, maximum limit of impurities are Iron

(Fe): 0.01%, Sulphur (S): 0.001%, Carbon (C): 0.08%, Oxygen

(O): 0.15 %) of 20 gram was heated at 600⁰C, 800⁰C, and

1000⁰C in the furnace for 2 hours. The oxidation of Ni powder

was above 500⁰C [41,67]; hence, at the above temperatures,

nickel was oxidized to NiO. The NiO film growth on the Ni

powder surface was initiated via a step increase in the

temperature of oxidation in the air. The samples were kept for

day-long, and this cooling process was naturally inside the

furnace after finishing the oxidation process. The product of

thermal oxidation, a greenish NiO layer formed on the surface

of Ni, which was mainly a chunk of Ni-NiO. The mass of the

nickel powder before and after oxidation was measured using

a precision electronic balance machine (SCIENTECH Inc.,



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

3



USA) with a readability of 0.001 mg. The chunk of Ni-NiO

nanocomposite was ball-milled into the cylinder of the ball

milling machine, which was filled with crushed oxidized

particles and balls of two diameters in a 10:1 ratio. During the

process of collision between balls and crushed particles, the

particles got crushed, the size of the particles was reduced,

and the ultimate composite powder of Ni-NiO was formed.

The crushed particles were then strained to achieve a smooth

and homogeneous composite powder.

Figure 2. Schematic representation of the thermal oxidation process



2.2 Characterization techniques

An X-ray diffractometer (XRD) (Empyrean, PANalytical-

Netherlands) with radiation from the copper target (kα,

λ=0.15406 nm) was used to evaluate the crystal structure and

composition of the Ni-NiO crystal structure. The diffraction

patterns were recorded over a 2θ range from 10 to 90⁰ at a

step size of 0.1⁰. The morphology and structure of the

nanocomposite Ni-NiO sample were examined using a high-

resolution scanning electron microscope (SEM) (JSM 7600F,

JEOL-Japan) in combination with Energy Dispersive X-ray

Spectroscopy (EDX) at 5 KV with different magnification.

2.3 Electrochemical Measurements
The synthesized and characterized nanostructured

composites of Ni-NiO were employed as an anode of LIBs. The

electrochemical performance of the synthesized anode was

carried out by assembling the electrode into a CR2032-type

coin cell (supplied by Xiamen TOB New Energy Technology

Ltd., China) in the laboratory. The synthesized

nanocomposites of Ni-NiO were used as working electrodes

prepared through a slurry coating procedure, as shown in

Figure 3. It is noted that the slurry constituted 70 wt. % of

active material, 10 wt. % of polyvinylidene fluoride (PVDF)

binder, and 20 wt. % of active carbon powder, which was

dissolved in the required amount of N-methyl pyrrolidone

(NMP) (Sigma-Aldrich). The prepared slurries were then

pasted onto a copper foil (Changzhou DLX Alloy Co., Ltd.,

China). The counter electrode was recycled LiCoO2, and a

porous polymeric separator of polyethylene was employed.

The electrolyte was LiPF6 (supplied by Ximen Tmax Battery

Equipment Ltd., China) of 1.0 M dissolved in ethylene

carbonate (EC) and diethylene carbonate (DEC) at a volume

ratio of 1:1. The assembled coin cells were crimped at 100 psi

pressure using a hydraulic battery crimper (Metrology

Laboratory, Dept. of ME, CUET). The galvanostatic

charge/discharge tests were performed using a LAND-

CT2001A (LANDt Instrument, USA) battery testing system in

a voltage range between 0.02 to 3 V at a 1C current rate.





Figure 3. Schematic view of composite electrode preparation and
coin cell assembly



3. Results and Discussions
3.1 Characterization of nanocomposite Ni-NiO as an

anode of LIBs

Figure 4 shows the XRD pattern of Ni-NiO

nanocomposite at different oxidation temperatures, such as

600̊ C, 800̊ C, and 1000 ̊C, respectively. To compare with the

pure Ni, the XRD pattern of pure Ni is shown. The XRD pattern

of pure Ni powder reveals that a face-centered cubic (FCC)

structure with three main diffraction peaks at 44.54 ,̊ 51.92 ,̊

76.46  ̊corresponding to the (111), (200), and (202) miller

indices of Ni (ICSD: 98-064-6085). The absence of any kind of

impurity phases within the detection limit of the

diffractometer confirms the purity of Ni powder. In addition,

despite the oxidation of Ni at three distinct oxidation

temperatures, no other diffraction peaks corresponding to

the oxide phase are detected. It is noted that the XRD pattern

of Ni shows high intensity and sharp peaks.



Figure 4. XRD pattern of Ni-NiO composite after single-step thermal
oxidation at 600˚C, 800˚C, and 1000˚C.









SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

4



At 600̊ C oxidation temperature, Ni (ICSD: 98-064-6092)

exhibited three peaks at approximately the same 2θ angle

with five additional diffraction peaks at 37.31 ,̊ 43.35 ,̊ 62.97 ,̊

75.49 ,̊ 79.51 ,̊ which reveals the formation of NiO (ICSD: 98-

002-8834). These peaks can be indexed to the (111), (200),

(202), (311), and (222) diffraction planes. In addition, Ni

(ICSD: 98-064-6089) and NiO (ICSD: 98-018-4918) peaks are

observed with an increase in peak intensity of NiO and a

decrease in diffraction peak of Ni due to the thermal oxidation

of Ni powder at 800̊ C. It is noted that more oxidation of Ni

with increasing temperature and the NiO peaks become sharp

with temperature rise which indicates the degree of

crystallinity increase of NiO particles. At the oxidation

temperature of 1000̊ C, there are no obvious peaks of Ni, the

diffraction peaks of NiO (ICSD: 98-018-4918) are observed

with high intensity and sharp peaks, as shown in Figure 4. The

major sharpening of peaks, mainly of 2θ = 37.31 ,̊ 43.35 ,̊

62.97  ̊indicates the increased degree of crystallization [68].

The crystallographic parameters of Ni-NiO composite at

different oxidation temperatures were determined by the

Debey Scherrer equation,

D= 0.94 λ / (βcosθ)                     (1)

where D denotes the average dimension of crystallites, λ

denotes the wavelength of X-ray, and β denotes the full width

at half maximum of a reflation located at 2θ.

The average crystal size of pure Ni before oxidation was 19.93

nm, and after oxidation at 600⁰C and 800⁰C is 19.77 nm and

18.13 nm, respectively. However, there is no visible Ni peak

at the temperature of 1000̊ C. It is noted that, with the

increase in oxidation temperature, the crystal size of Ni

decreases. In contrast, five diffraction peaks of NiO at 600̊ C

were found at 2θ = 37.31 ,̊ 43.35 ,̊ 62.97 ,̊ 75.49 ,̊ and 79.51  ̊

with an average crystal size of 17.13 nm while at 800̊ C and

1000˚C, same five NiO peaks exhibited with average crystal

size of 18.72 nm and 18.86 nm, respectively. Hence, the

crystal size of NiO increases with an increase in oxidation

temperature. The possible reason for the increasing

crystallite size of NiO is due to oxidation, which leads to more

NiO formation. A similar phenomenon was observed as the

crystallite size of the metal oxides exhibited an increment

with an increase in temperature until it achieved a constant

crystal size [68].  Figure 5 shows the low- and high-

magnification images of Ni powder before and after oxidation

at 600⁰C. The SEM of pure Ni, as shown in Figures 5 (a) and

(b), revealed that the particles are spherical in shape as well

as partially agglomerated and smooth, and there are spaces in

between the particles. However, this powder was oxidized in

the electric furnace at 600 ̊C continuously for 2 hours; the

growth of oxide particles occurs in between the spaces

because of the swelling of grains. A significantly different

morphology was observed of Ni powder after oxidation in the

furnace at 600 ̊C. The as-synthesized Ni-NiO composite

showed a randomly ordered interconnected “nanochips” like

structure, as shown in Figures 5 (c), (d), due to the formation

of NiO in Ni powder. At a low oxidation temperature of 600 C̊,

no obvious grain boundary was found, however, the oxide

layer growth occurs due to oxidation. A rough surface was

formed, which is seen in the high magnification SEM image of

the surface, as shown in Figure 5 (d), due to oxide growth. The

EDX spectrum confirms the presence of only the Ni phase

before oxidation, both Ni and O phases after oxidation, as

shown in Figures 5 (e) and (f).


Figure 5. Low and high magnification SEM images and EDX spectra
of Ni powder: (a), (b), (e) pure nickel powder, and (c), (d), (f) after
oxidation at 600 ̊C


Figure 6 shows low and high-magnification SEM

images of nickel powder after oxidation at 800  ̊C and 1000 C̊

temperatures. At 800 ̊C oxidation temperature, the increased

grain swelling causes the grain contact area to enlarge, which

is responsible for the intergranular joint formation [69]. It is

noted that the grains are bonded well as more NiO is formed

when compared to the sample oxidized at 600  ̊C, and grain

boundary is formed as shown in Figures 6 (a), (b). As the

temperature of oxidation increases, more oxygen is diffused

through the porosity of the sample [70,71]; hence, more NiO

is formed in the structure. The surface exhibited a “crushed

gravel stone” like morphology with a 0.855 μm average grain

size. It is noted that there are some cracks and spaces in

between the grains due to the diffusion of nickel as well as

induced thermal stress. These kinds of cracks and spaces

suggest that Li+ transportation could take place easily

because of the access of electrolytes through them.  Figures 6

(c) and (d) represent the low and high-magnification SEM

images of nickel powder after oxidation at 1000 C̊

temperature. The grains are well interconnected with each

other as the swelling of grains due to the oxidation process

causes them to fill up the intergranular spaces. The high

magnification image of the structure, as shown in Figure 6 (d)

reveals that there are no visible pores or voids in the



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

5



structure and it exhibits a “pebble stone” like feature with a

mean diameter of 0.899 μm which is quite different from the

other two oxidized samples. The generation of different

thermal stress is the main reason for different morphology at

different temperatures [72]. At 1000⁰C oxidation

temperature, a visibly smooth surface is observed in the high

magnification image, as shown in Figure 6 (d).


Figure 6. Low and high magnification SEM images and EDX spectra
of Ni powder: after oxidation at (a), (b), (e) at 800 ̊C, and (c), (d), (f)
at 1000 ̊C



The EDX spectra exhibited that there are both nickel (Ni)

and oxygen (O) is present, which confirms the formation of

the NiO phase in the synthesized composite structures.

During EDX measurement different areas were focused, and

the corresponding peaks are shown in Figures 6 (e) and (f). It

is noted that every spectrum confirms the presence of the Ni

and O phases.

3.2 Electrochemical performance of Ni-NiO composite as

anode of LIBs
The electrochemical performances of synthesized Ni-NiO

composites were evaluated to assess their efficiency as

anodes for LIB. The performance evaluation was

accomplished by comparing the galvanostatic charge-

discharge profile for different composite anodes to figure out

the effect of oxidation temperature on the battery

performance. In this study, three types of batteries are

assembled employing three kinds of composite. These three

batteries are assembled by exerting- microchips (600⁰C, B-1),

crushed gravel-stone (800⁰C, B-2), and pebble stone (1000⁰C,

B-3) structured negative electrodes. It is noted that NiO is a

conversion reaction-based anode that captures lithium

possessing high specific capacities by reversibly replacing

redox reactions within Li+ and transition oxide-based cation.

The elementary conversion reaction mechanism of NiO can be

given as NiO + 2Li+ + 2e- ↔ Ni + Li2O. During the discharge

phase, NiO is reduced to highly dispersed metallic Ni

nanoparticles and Li2O. In addition, the disintegration of Li2O

and the reformation of metallic Ni nanoparticles into NiO

nanograins take place during the charge phase.

3.2.1 Electrochemical performance of Ni-NiO

composite at 600⁰C and 800⁰C as anode of LIBs

The galvanostatic charge-discharge voltage profiles

within a potential window of 0.01-3.0V versus Li+ with cyclic

performance and coulombic efficiency for the B-1 and B-2

batteries (synthesis temperature of 600⁰C and 800⁰C) at a

current rate of 1C is shown in Figures 7 (a)-(d). It is noted that

the 1C rate signifies the accomplishment of charge/discharge

in an hour. For battery B-1, the 1st cycle charge-discharge

capacity was observed to be 754.49 mAh g-1 and 464.04 mAh

g-1 with 61.50% coulombic efficiency. In addition, the B-1

battery delivered charge-discharge capacities of 23.59 mAh g-

1 and 11.79 mAh g-1; 10.11 mAh g-1, and 10.67 mAh g-1 at the

5th and 10th cycles, respectively. The consecutive coulombic

efficiencies were observed to be 52.5% and 95%,

respectively. In contrast, the capacities were 101.12 mAh g-1

and 79.78 mAh g-1, with a coulombic efficiency of 127.46%, for

battery B-2. In addition, the battery B-2 exhibited 5th and 10th

cycle charge-discharge capacities of 25.28 mAh g-1 and 28.09

mAh g-1; 7.30 mAh g-1 and 9.55 mAh g-1, respectively. The

coulombic efficiency was observed as 111.11% and 130.77%,

respectively. It is noted that the capacity exhibited drastic

decay with cycling as cycled both batteries. In addition, only

2.29% of the initial discharge capacity was retained for B-1,

whereas 11.97% was retained for B-2 after the 10th charge-

discharge cycle. However, the coulombic efficiency fluctuated

and increased after the 10th charge-discharge cycle of both B-

1 and B-2 batteries. There are a number of reasons why

columbic efficiency exceeds 100%, including an imbalance in

the amounts of Li+ absorbed and released, side reactions, and

measurement error. This may be due to some structural

interruptions that cause an uneven volume of Li+ to be

transported. Particularly, the intercalation of less Li+ during

charging and the de-intercalation of the maximum volume of

Li+ during discharging cause the columbic efficiency to

exceed 100%. The repeated occurrence of such phenomena

causes the active material to fail and affect the battery's

performance adversely [73–75].

It is evident from Figures 7 (a) and (c) that battery B-1

exhibited erratic behavior, and the specific capacities

decreased rapidly from the 1st to 10th charge-discharge cycle.

Moreover, the specific charge/discharge capacity faded

drastically with further cycling, and the battery became out of

order. The predominant reason behind this extreme capacity

fading is the short-circuiting phenomenon of the battery, as

the instantaneous voltage drop occurred from around 1.0 to

0.01V [76,77]. The unanticipated voltage drop is due to the

short circuit of the composite Ni-NiO electrodes and the

recycled LiCoO2 electrode due to swelling or perforation of

the insulating polymeric separator, deflection of electrodes,

or presence of impurities in the cell [78]. The incident of the



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

6



internal short circuit releases 70% of the battery energy

within 60 seconds [79, 80], which causes a rigorous increase

in the local temperature that, in turn triggers the chemical

side reactions and causes thermal runaway [80]. This short-

circuiting tendency became more prominent with further

cycling. Hence, long cycling may lead to thermal runway and

irreparable cell damage. In contrast, for battery B-2 the

charge/discharge curve exhibited improvement as compared

to battery B-1 as shown in Figure 7(b). The curve portrayed

capacitor-like profiles (no potential flat plateaus); however, a

linear variation of the potential in correspondence to the

lithium insertion/extraction. This occurrence indicated the

pseudo-capacitive behavior, which signifies surface storage

nature [81, 82]. The 1st cycle irreversible capacity loss of

21.10% may be ascribed to the formation of a solid electrolyte

interface (SEI) caused by the degradation of electrolytes. This

irreversible capacity loss gradually dropped to 23.53% after

the 10th cycle. The substantial capacity decrease from the 1st

to the 10th cycle may be attributed to the structural collapse

of the composite by large volume change during cycling,

which pointed out the structural inefficiency of the battery.

However, the battery capacity retention ability was higher

than the previous battery, and therefore, the performance

was not worth demonstrating.









3.2.2 Electrochemical performance of Ni-NiO

composite at 1000⁰C as anode of LIBs

Figure 8 shows the galvanostatic charge/discharge

voltage profiles of battery B-3 in a potential window of 0.01-

3.0V Vs. Li+. Interestingly, the initial discharge profile

exhibited no obvious plateau region, similar to the typical

capacitor-like curve where potential increases/decreases

linearly with the lithium insertion/extraction [82]. This

occurrence is attributed to the pseudo-capacitive behavior,

which indicates the bulk surface storage characteristics [81,

82]. The initial charge curve exhibits higher voltage with two

sloping potential ranges at about 2.2 and 2.5V, respectively.

The 1st cycle charge-discharge capacities were exhibited as

292.13 and 365.17 mAh g-1, respectively. There was an

irreversible capacity loss of 18.98% between 1st charge and

discharge, which may be connected to the formation of solid

electrolyte interface (SEI) and amorphous Li2O during the

discharge process, due to the electrochemically driven

electrolyte degradation. It is noted that both the SEI as well as

Li2O are partially decomposed during the subsequent charge

process. This irreversibility of SEI and Li2O formation-

decomposition is responsible for the decrease in the charge

capacity. The aforementioned occurrence is observed in

materials that obey the conversion reaction mechanism [33,

67, 83, 84].









Figure 7. (a, b) Charge-Discharge voltage profiles for 1st to 10th cycle; (c, d) Cycle performance and coulombic efficiency at 1C rate for

battery B-1 and B-2



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

7







In addition, the discharge capacities in the 5 th, 10th and

20th cycles have appeared as 196.62 mAh g-1, 104.49 mAh g-1,

and 95.50 mAh g-1 respectively with corresponding charge

capacities were 162.92 mAh g-1, 123.59 mAh g-1, and 56.17

mAh g-1. The capacities decreased rapidly over cycling and

26.15% of the initial capacity was retained after the 20 th cycle

for B-3. Moreover, the reversible discharge capacity loss for

1st to 5th, 5th to 10th, 10th to 20th, 1st to 20th were 168.55 mAh

g-1, 88.13 mAh g-1, 8.99 mAh g-1, and 269.67 mAh g-1,

respectively. The average capacity loss per cycle was found to

be 13.48 mAh g-1 and 26.15% of initial capacity was retained.

The initial coulombic efficiency of battery B-3 seemed to be

124.80% at a 1C rate. The coulombic efficiency fluctuated in a

random manner throughout the 20 cycles and attained a

value of 90.47% after the 20 th cycle. The aforementioned

performance analysis of B-1, B-2, and B-3 batteries implied

that all three batteries are functional and exhibited some

capacities with coulombic efficiencies. The charge/discharge

profile and cycle performance of B-1 and B-2 clearly indicated

the infeasibility of the battery to be employed in practical

application. The B-1 battery exhibited an error-prone

tendency as an internal short circuit occurred, which was

responsible for extreme capacity decay within a few cycles.

This may be induced by perforation or crack in the separator,

deformity in architecture, and/or defective assembly

procedure. In the case of B-2 battery, low capacity resulted

from conspicuous surface intercalation, which accounted for

structural collapse. However, B-2 battery appeared to have a

slight improvement in performance compared to B-1, the

battery efficiency, which did not meet expectations. It is noted

that the B-3 battery appeared to be a promising one. The B-3

battery exhibited more efficient results than all other

batteries, rather it requires high-temperature processing.

This may be attributed to the well-ordered and highly

crystalline microstructure. Hence, long-term cycling

performance has been executed with B-3. As a consequence,

more than 40 charge/discharge cycles can be achieved with

B-3 at a 1C rate.





Figure 9 exhibits the high cycle charge-discharge profiles for

battery B-3 within the voltage window 0.01-3.0V Vs. Li+. The

25th cycle charge-discharge capacities were 73.03 mAh g-1 and

112.36 mAh g-1. Similarly, the 30th, 35th, and 40th discharge

capacities were 98.88 mAh g-1, 75.84 mAh g-1, and 67.42 mAh

g-1 respectively with corresponding charge capacities of 61.79

mAh g-1, 46.63 mAh g-1, and 35.39 mAh g-1, respectively. A

considerable discharge capacity loss was noticed 13.48 mAh

g-1 from 25th to 30th cycle. For 30th to 35th, 35th to 40th, and 25th

to 40th cycle the discrepancies in discharge capacity became

23.04 mAh g-1, 8.42 mAh g-1, and 76.97 mAh g-1. The average

loss in discharge capacity per cycle was 5.13 mAh g-1, which

was 13.48 mAh g-1 for the first 20 cycles. It is noted that

discharge capacity loss followed a decreasing trend with an

increase in cycle number. Moreover, the battery

demonstrated a long-cycle performance and coulombic

efficiency at the 1C rate as shown in Figure 9 (a). The

coulombic efficiency for the 25th cycle was 95.55%, and the

values were 88%, 88.82%, and 100% for 30 th, 35th, and 40th

cycles. The coulombic efficiency showed a subsequent

decrease up to the 35th cycle and attained 100% in the 40 th

cycle. Furthermore, the retention of initial capacity was

18.46% after the 40th cycle, which was 27.07% and 20.77%

for the 30th and 35th cycles. The long-term cycling caused only

7.69% capacity decay from the 20 th to 40th cycle. It can be

stated that the capacity retention ability manifested a

decreasing tendency with cycling. In order to clarify the

capacity loss of the as cycled batteries, the surface

morphology and elemental analysis of the Ni-NiO composite

electrode were performed. It is noted that disassemble of LIBs

was performed manually in such a way that the process was

not allowed to short-circuit. In addition, Ni-NiO electrode was

not washed after disassembling of LIBs, and its original

morphology after respective cycling was observed with the

presence of an SEI layer. Figure 10 shows the SEM images and

EDX spectra of Ni-NiO electrodes of batteries B-1 and B-3

after charge/discharge for 10 and 40 cycles, respectively.



Figure 8. (a) Charge-Discharge voltage profiles from 1st to 20th cycle; (b) Cycle performance and coulombic efficiency at 1C rate for battery B-3



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

8

















































Figure 9. (a) Charge-Discharge voltage profiles from 25th to 40th cycle; (b) Long cycle performance and coulombic efficiency at 1C rate for battery B-3

Figure 10. SEM and EDX characterization of Ni-NiO electrodes after electrochemical cycling of: (a, b) B-1 and (c, d) B-3



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

9



It is noted that the synthesis temperature of electrodes of B-1

and B-3 is 600oC and 1000 oC, respectively. We didn’t observe

and analyze the SEM images and EDX spectra of the electrode

of B-2, which was synthesized at 800oC due to the similar

electrochemical performances of B-1. The initial

microstructure of Ni-NiO electrode of B-1 enormously

changed to agglomerated and cracked surface, as shown in

Figure 10(a). It is noted that the width of some cracks

increased and subsequently crushed due to the volume

change of NiO and came off the current collector, leading to

the drastic capacity fade of B-1. However, the original pebble

stone microstructure of Ni-NiO electrode of B-3 entirely

changed to a compressed honeycomb-like structure, as

shown in Figure 10(c). It is noted that these both electrodes

exhibited different morphology with few nanometer diameter

pores after charge/discharge cycles at 1 C current rate. This

could be attributed by the structural change during the first

lithiation process when NiO structure converted to Ni

nanoparticle inside Li2O and gel-like matrixes [17, 29, 85]. A

similar morphological change is observed in NiO electrode as

anode after the electrochemical cycling of LIBs [23, 78, 84]. It

is noted that the decomposition of electrolyte is substantial,

which can be another reason for the drastic capacity fading of

Ni-NiO. The EDX spectra of Ni-NiO electrodes after 10 and 40

charge/discharge cycles are shown in Figures 10 (b) and (d),

respectively. It is observed that the presence of elements

fluorine (F) and phosphorus (P) is due to the decomposition

of LiPF6 along with the impurities elements of manganese

(Mn), calcium (Ca), silicon (Si), and sulfur (S). In addition,

carbon (C) is observed due to the decomposition of

carbonate-based organic solvents. A similar decomposition

phenomenon was observed in carbonate-based lithium salt

electrolytes such as 1.2 M LiPF6/EC [86], 1 M LiPF6/EC-DEC

[87], and 1 M LiPF6/EC-DEC-DMC [88]. From the above

discussion, it can be noted that the B-3 has appeared as the

propitious one among other batteries. It is noted that the

synthesis required high-temperature (1000⁰C) processing;

however, it exhibited noteworthy performance. The

contribution of this specific research is to establish a

convenient synthesis technique and undoubtedly unique

architecture. In addition, the battery assembly operation was

simple without any glovebox facility. The achieved capacity is

lower than the NiO itself and other nanostructures; however,

higher than the practical capacity of graphite anode.

Moreover, replacing graphite with Ni-NiO composite will

eliminate the safety issues regarding graphite anode with

considerably high specific capacity. Furthermore, the

remarkable performance stimulated the execution as a

battery anode in practical application with no probable

hazard.

4. Conclusions
In summary, we have fabricated microstructured

composite of Ni-NiO through a simple and single-step thermal
oxidation approach and subsequent mechanical ball milling

process. At three distinct temperatures- 600˚C, 800˚C, and

1000˚C oxidation of Ni powder was performed. The as-
synthesized microstructured composite of Ni-NiO was

employed as an anode of LIBs, and the following conclusions
are drawn from this study:

• It was observed that the electrode synthesized at 600˚C (B-
1) delivered a discharge and charge capacity of 464.04 mAh

g-1 and 754.49 mAh g-1 during 1st cycle which decreased

drastically to 10.67 mAh g-1 and 10.11 mAh g-1 after 10th
cycle at 1C rate. This electrode experiences an internal

short circuit, which was the major reason behind the
capacity fading. Moreover, the insufficient active

nanoparticle loading in the electrode causes less reaction
with lithium. However, the high elasticity of the electrode

causes ease of electrolyte and ion access, and the

brittleness of the electrode causes severe volume
expansion and structural degradation of the electrode

within 10 cycles.

• The electrode synthesized at 800˚C (B-2) exhibited a
specific discharge-charge capacity of 101.12 mAh g-1 and

79.77 mAh g-1 during 1st cycle and faded rapidly to 9.55

mAh g-1 and 7.30 mAh g-1 after the 10th cycle. Though

irreversible capacity loss decreases from the previous
electrode, the electrode cannot sustain long cycling. The
more reversible capacity was due to the presence of Ni

nanoparticles, possessing catalytic activity, facilitating the

decomposition of Li2O and SEI layer during the charging

process. However, the amount of active nanoparticles on
the electrode increases with temperature increase, the
electrode elasticity, and brittleness decrease, and the

electrode was unable to buffer the volume-induced stress
that resulted in the crack on the surface and structural

degradation of the electrode.

• One of the best electrochemical performances was

observed in the electrode synthesized at 1000 C̊
temperature (B-3). The electrode delivered a specific
discharge and charge capacity of 365.17 mAh g-1 and

298.85 mAh g-1 during 1st cycle. A reversible capacity of
67.41 mAh g-1 was achieved after the 40th cycle at a 1C rate.

The discharge/charge capacity fluctuated randomly up to
the 20th cycle as the electrode material became more
ductile due to temperature increase, which impedes the

smooth insertion of Li+. During continuous
charging/discharging, the rapid lithium insertion/de-

insertion causes active electrode materials to get

pulverized. After the 20th cycle, the electrode capacity
fluctuated systematically and retained 18.46% initial

capacity with coulombic efficiency of 100% after the 40 th
cycle.  This may be due to continuous cycling; the structural

reconstruction of the electrode causes a reduction in

particle size of active material, and thus, nano-
crystallization improves the cycling performance. The

prolonged cycling causes pulverization of the electrode, the
active materials detached from the current collector, and

the failure occurs.

Ethical issue

The authors are aware of and comply with best practices in
publication ethics, specifically with regard to authorship
(avoidance of guest authorship), dual submission,
manipulation of figures, competing interests, and compliance
with policies on research ethics. The authors adhere to
publication requirements that the submitted work is original
and has not been published elsewhere.



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

10



Data availability statement
The manuscript contains all the data. However, more data will

be available upon request from the authors.

Conflict of interest

The authors declare no potential conflict of interest.

Funding

This work is co-supported by Chittagong University of
Engineering & Technology (CUET), Bangladesh, through

research grant no. CUET/CHSR-35/17(iii), University Grants

Commission of Bangladesh-grant no. 37.01.
0000.73.06.065.22.1607, and a grant (No. JB230001) from

the Korea Institute of Industrial Technology (KITECH). The
corresponding author is responsible for ensuring that the

descriptions are accurate and agreed upon by all authors.

References

[1]     Zhang J, Terrones M, Park CR, Mukherjee R,
Monthioux M, Koratkar N, et al. Carbon science in
2016: Status, challenges and perspectives. Vol. 98,

Carbon. Elsevier Ltd; 2016. p. 708–32.
[2]     Chemistry of Materials Editorial. Available from:

https://doi.org/10.1021/acs.chemmater.
[3]     Rodrigues MTF, Babu G, Gullapalli H, Kalaga K, Sayed

FN, Kato K, et al. A materials perspective on Li-ion

batteries at extreme temperatures. Nat Energy. 2017
Aug;2(8).

[4] Rahman MdA, Kim J, Hossain S. Recent advances of

energy storage technologies for grid: A
comprehensive review. Energy Storage. 2022 Jan 10;

[5] Nardo M, Saisana M, Saltelli A, Tarantola S, Hoffman
H, Giovannini E. Handbook on constructing composite

indicators: methodology and user guide. Organisation

for Economic Cooperation and Development (OECD).

Statistics Working Paper JT00188147, OECD, France.
2005;

[6] Winter M, Besenhard JO, Spahr ME, Novµk P.

Insertion Electrode Materials for Rechargeable
Lithium Batteries.

https://doi.org/10.1002/(SICI)1521-
4095(199807)10:10<725::AID-ADMA725>3.0.CO;2-Z

[7] Van Schalkwijk WA, Scrosati B. Advances in Lithium-

ion Batteries Kluwer Academic. Plenum, New York;
2002.

[8] Ma D, Cao Z, Hu A. Si-based anode materials for li-ion
batteries: A mini review. Vol. 6, Nano-Micro Letters.
Shanghai Jiaotong University; 2014. p. 347–58.

[9] An Q, Lv F, Liu Q, Han C, Zhao K, Sheng J, et al.
Amorphous vanadium oxide matrixes supporting

hierarchical porous Fe3O4/graphene nanowires as a

high-rate lithium storage anode. Nano Lett. 2014 Nov
12;14(11):6250–6.

[10] Dai R, Wang Y, Da P, Wu H, Xu M, Zheng G. Indirect
growth of mesoporous Bi@C core-shell nanowires for

enhanced lithium-ion storage. Nanoscale. 2014 Nov

7;6(21):13236–41.
[11] Yang C, Jiang Y, Liu X, Zhong X, Yu Y. Germanium

encapsulated in sulfur and nitrogen co-doped 3D
porous carbon as an ultra-long-cycle life anode for

lithium ion batteries. J Mater Chem A Mater.
2016;4(48):18711–6.

[12] Choi JW, Aurbach D. Promise and reality of post-
lithium-ion batteries with high energy densities. Vol.

1, Nature Reviews Materials. Nature Publishing

Group; 2016.

[13] Chan CK, Ruffo R, Hong SS, Cui Y. Surface chemistry
and morphology of the solid electrolyte interphase on
silicon nanowire lithium-ion battery anodes. J Power

Sources. 2009;189(2):1132–40.
[14] Ruffo R, Hong SS, Chan CK, Huggins RA, Cui Y.

Impedance analysis of silicon nanowire lithium ion
battery anodes. The Journal of Physical Chemistry C.
2009;113(26):11390–8.

[15] Li, Si. 648 wileyonlinelibrary.com [Internet]. 2015.
Available from: www.MaterialsViews.com

[16] Ferg E, Gummow RJ d, De Kock A, Thackeray MM.
Spinel anodes for lithium‐ion batteries. J Electrochem
Soc. 1994;141(11):L147.

[17] Zhao Y, Li X, Yan B, Xiong D, Li D, Lawes S, et al.
Recent Developments and Understanding of Novel

Mixed Transition-Metal Oxides as Anodes in Lithium

Ion Batteries. Vol. 6, Advanced Energy Materials.
Wiley-VCH Verlag; 2016.

[18] Li T, Li X, Wang Z, Guo H, Li Y, Wang J. A new design
concept for preparing nickel-foam-supported metal

oxide microspheres with superior electrochemical

properties. J Mater Chem A Mater.
2017;5(26):13469–74.

[19] Hao L, Liang M, Weiwei S, Yong W. Bimetal-Organic
Framework: One-Step Homogenous Formation and

its Derived Mesoporous Ternary Metal Oxide
Nanorod for High-Capacity, High-Rate, and Long-

Cycle-Life Lithium Storage. Adv Funct Mater. 2016

Feb 16;26(7):1098–103.
[20] Chen Z, Zhou M, Cao Y, Ai X, Yang H, Liu J. In situ

generation of few-layer graphene coatings on SnO 2-
SiC core-shell nanoparticles for high-performance

lithium-ion storage. Adv Energy Mater. 2012
Jan;2(1):95–102.

[21] Liu H, Wang G, Liu J, Qiao S, Ahn H. Highly ordered

mesoporous NiO anode material for lithium ion
batteries with an excellent electrochemical

performance. J Mater Chem. 2011 Mar 7;21(9):3046–

52.
[22] Rahman MA, Wong YC, Song G, Zhu DM, Wen C.

Improvement on electrochemical performances of
nanoporous titania as anode of lithium-ion batteries

through annealing of pure titanium foils. Journal of

Energy Chemistry. 2018 Jan 1;27(1):250–63.
[23] Rahman MA, Wen C. Nanogravel structured NiO/Ni

foam as electrode for high-performance lithium-ion
batteries. Ionics (Kiel). 2015 Oct 22;21(10):2709–23.

[24] Zhu Y, Choi SH, Fan X, Shin J, Ma Z, Zachariah MR, et
al. Recent Progress on Spray Pyrolysis for High

Performance Electrode Materials in Lithium and

Sodium Rechargeable Batteries. Vol. 7, Advanced
Energy Materials. Wiley-VCH Verlag; 2017.

[25] Cai Z, Xu L, Yan M, Han C, He L, Mulonda Hercule K, et
al. Manganese Oxide/Carbon Yolk-Shell Nanorod

Anodes for High Capacity Lithium Batteries

[Internet]. 2014. Available from: http://pubs.acs.org



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

11



[26] Wang Y, Xu J, Wu H, Xu M, Peng Z, Zheng G.
Hierarchical SnO 2-Fe 2O 3 heterostructures as

lithium-ion battery anodes. J Mater Chem. 2012 Nov

7;22(41):21923–7.

[27] Rahman MA, Wong YC, Song G, Wen C. A review on
porous negative electrodes for high performance
lithium-ion batteries. Journal of Porous Materials.

2015 Oct 7;22(5):1313–43.
[28] Sun MH, Huang SZ, Chen LH, Li Y, Yang XY, Yuan ZY, et

al. Applications of hierarchically structured porous
materials from energy storage and conversion,
catalysis, photocatalysis, adsorption, separation, and

sensing to biomedicine. Chem Soc Rev. 2016 Jun
21;45(12):3479–563.

[29] Zheng M, Tang H, Li L, Hu Q, Zhang L, Xue H, et al.
Hierarchically nanostructured transition metal oxides
for lithium‐ion batteries. Advanced Science.

2018;5(3):1700592.
[30] Kumar Rai A, Tuan Anh L, Park CJ, Kim J.

Electrochemical study of NiO nanoparticles electrode

for application in rechargeable lithium-ion batteries.
Ceram Int. 2013 Aug;39(6):6611–8.

[31] Li X, Dhanabalan A, Wang C. Enhanced
electrochemical performance of porous NiO-Ni

nanocomposite anode for lithium ion batteries. J

Power Sources. 2011 Nov 15;196(22):9625–30.
[32] Rahman MA, Zhu X, Wen C. Fabrication of

Nanoporous Ni by Chemical Dealloying Al from Ni-Al
Alloys for Lithium-ion Batteries [Internet]. Vol. 10,

Int. J. Electrochem. Sci. 2015. Available from:
www.electrochemsci.org

[33] Wang C, Wang D, Wang Q, Chen H. Fabrication and

lithium storage performance of three-dimensional
porous NiO as anode for lithium-ion battery. J Power

Sources. 2010 Nov 1;195(21):7432–7.
[34] Kim GP, Park S, Nam I, Park J, Yi J. Synthesis of porous

NiO materials with preferentially oriented crystalline
structures with enhanced stability as lithium ion
battery anodes. J Power Sources. 2013;237:172–7.

[35] Du M, Li Q, Pang H. Oxalate-derived porous prismatic
nickel/nickel oxide nanocomposites toward lithium-

ion battery. J Colloid Interface Sci. 2020 Nov

15;580:614–22.
[36] Singh J, Lee S, Kim S, Singh SP, Kim J, Rai AK.

Fabrication of 1D mesoporous NiO nano-rods as high
capacity and long-life anode material for lithium ion

batteries. J Alloys Compd. 2021 Jan 5;850.

[37] Duraisamy E, Sujithkrishnan E, Kannadasan K,
Prabunathan P, Elumalai P. Facile metal complex-

derived Ni/NiO/Carbon composite as anode material
for Lithium-ion battery. Journal of Electroanalytical

Chemistry. 2021 Apr 15;887.
[38] Cheng CF, Chen YM, Zou F, Yang KC, Lin TY, Liu K, et

al. Nanoporous gyroid Ni/NiO/C nanocomposites

from block copolymer templates with high capacity
and stability for lithium storage. J Mater Chem A

Mater. 2018;6(28):13676–84.
[39] Liu L, Li Y, Yuan S, Ge M, Ren M, Sun C, et al.

Nanosheet-based NiO microspheres: Controlled

solvothermal synthesis and Lithium storage

performances. Journal of Physical Chemistry C. 2010
Jan 14;114(1):251–5.

[40] Jae W, Song J, Hong JJ, Kim J. Raspberry-like hollow

Ni/NiO nanospheres anchored on graphitic carbon

sheets as anode material for lithium-ion batteries. J
Alloys Compd. 2019 Oct 15;805:957–66.

[41] Varghese B, Reddy M V., Yanwu Z, Lit CS, Hoong TC,

Rao GVS, et al. Fabrication of NiO nanowall electrodes
for high performance lithium ion battery. Chemistry

of Materials. 2008 May 27;20(10):3360–7.
[42] Bell J, Ye R, Ahmed K, Liu C, Ozkan M, Ozkan CS. Free-

standing Ni-NiO nanofiber cloth anode for high

capacity and high rate Li-ion batteries. Nano Energy.
2015 Nov 1;18:47–56.

[43] Liu L, Guo Y, Wang Y, Yang X, Wang S, Guo H. Hollow
NiO nanotubes synthesized by bio-templates as the
high performance anode materials of lithium-ion

batteries. Electrochim Acta. 2013;114:42–7.
[44] Wu MS, Lin YP. Monodispersed macroporous

architecture of nickel-oxide film as an anode material

for thin-film lithium-ion batteries. Electrochim Acta.
2011 Feb 1;56(5):2068–73.

[45] Su D, Kim HS, Kim WS, Wang G. Mesoporous nickel
oxide nanowires: Hydrothermal synthesis,

characterisation and applications for lithium-ion

batteries and supercapacitors with superior
performance. Chemistry - A European Journal. 2012

Jun 25;18(26):8224–9.
[46] Pang Y, Zhang J, Chen D, Jiao X. 3D hierarchical porous

NiO nanoflowers as an advanced anode material with
remarkable lithium storage performance. RSC Adv.

2016;6(36):30395–400.

[47] Jadhav HS, Thorat GM, Mun J, Seo JG. Self-assembled
hierarchical 3D - NiO microspheres with ultra-thin

porous nanoflakes for lithium-ion batteries. J Power
Sources. 2016 Jan 20;302:13–21.

[48] Yuan YF, Xia XH, Wu JB, Yang JL, Chen YB, Guo SY.
Hierarchically ordered porous nickel oxide array film
with enhanced electrochemical properties for lithium

ion batteries. Electrochem commun. 2010
Jul;12(7):890–3.

[49] Zhu X, Luo B, Butburee T, Zhu J, Han S, Wang L.

Hierarchical macro/mesoporous NiO as stable and
fast-charging anode materials for lithium-ion

batteries. Microporous and Mesoporous Materials.
2017 Jan 15;238:78–83.

[50] Li Q, Yi Z, Cheng Y, Wang XX, Yin D, Wang L.

Microwave-assisted synthesis of the sandwich-like
porous Al 2 O 3 /RGO nanosheets anchoring NiO

nanocomposite as anode materials for lithium-ion
batteries. Appl Surf Sci. 2018 Jan 1;427:354–62.

[51] Wang X, Yang Z, Sun X, Li X, Wang D, Wang P, et al.
NiO nanocone array electrode with high capacity and

rate capability for Li-ion batteries. J Mater Chem.

2011 Jul 21;21(27):9988–90.
[52] Li T, Ni S, Lv X, Yang X, Duan S. Preparation of NiO-

Ni/natural graphite composite anode for lithium ion
batteries. J Alloys Compd. 2013 Mar 15;553:167–71.

[53] Zhu XJ, Hu J, Dai HL, Ding L, Jiang L. Reduced

graphene oxide and nanosheet-based nickel oxide
microsphere composite as an anode material for



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

12



lithium ion battery. Electrochim Acta. 2012 Mar
1;64:23–8.

[54] Mai YJ, Tu JP, Gu CD, Wang XL. Graphene anchored

with nickel nanoparticles as a high-performance

anode material for lithium ion batteries. J Power
Sources. 2012 Jul 1;209:1–6.

[55] Qiu Y, Huang H, Song W, Gan Y, Wang K, Zhang J, et al.

In-situ electrolytic synthesis and superior lithium
storage capability of Ni–NiO/C nanocomposite by

sacrificial nickel anode in molten carbonates. J Alloys
Compd. 2020 Sep 5;834.

[56] Huang XH, Tu JP, Xia XH, Wang XL, Xiang JY, Zhang L.

Porous NiO/poly(3,4-ethylenedioxythiophene) films
as anode materials for lithium ion batteries. J Power

Sources. 2010 Feb 15;195(4):1207–10.
[57] Huang XH, Tu JP, Xia XH, Wang XL, Xiang JY. Nickel

foam-supported porous NiO/polyaniline film as

anode for lithium ion batteries. Electrochem commun.
2008 Sep;10(9):1288–90.

[58] Rahman MdA, Rahman MdM, Song G. A review on

binder‐free NiO‐Ni foam as anode of high
performance lithium‐ion batteries . Energy Storage.

2021 Aug 13;
[59] Sarker B, Rahman MA, Rahman MM, Islam MS.

Fabrication of ni-nio foams by powder metallurgy

technique and study of bulk crushing strength.
Trends in Sciences. 2021 Dec 1;18(23).

[60] Cabanas-Polo S, Bermejo R, Ferrari B, Sanchez-
Herencia AJ. Ni-NiO composites obtained by

controlled oxidation of green compacts. Corros Sci.
2012 Feb;55:172–9.

[61] Xia Q, Zhao H, Teng Y, Du Z, Wang J, Zhang T.

Synthesis of NiO/Ni nanocomposite anode material
for high rate lithium-ion batteries. Mater Lett. 2015

Mar 1;142:67–70.
[62] Huang XH, Tu JP, Zhang CQ, Xiang JY. Net-structured

NiO–C nanocomposite as Li-intercalation electrode
material. Electrochem commun [Internet].
2007;9(5):1180–4. Available from:

https://www.sciencedirect.com/science/article/pii/
S1388248107000185

[63] Zhu H, Zeng X, Han T, Li X, Zhu S, Sun B, et al. A nickel

oxide nanoflakes/reduced graphene oxide composite
and its high-performance lithium-storage properties.

Journal of Solid State Electrochemistry. 2019 Jul
19;23(7):2173–80.

[64] Xu C, Sun J, Gao L. Large scale synthesis of nickel

oxide/multiwalled carbon nanotube composites by
direct thermal decomposition and their lithium

storage properties. J Power Sources. 2011 Jun
1;196(11):5138–42.

[65] Yu Y, Gu L, Zhu C, Tsukimoto S, Van Aken PA, Maier J.
Reversible storage of lithium in silver‐coated three‐

dimensional macroporous silicon. Advanced

materials. 2010;22(20):2247–50.
[66] Huang XH, Tu JP, Zhang B, Zhang CQ, Li Y, Yuan YF, et

al. Electrochemical properties of NiO-Ni
nanocomposite as anode material for lithium ion

batteries. J Power Sources. 2006 Oct 20;161(1):541–

4.

[67] Ni S, Li T, Lv X, Yang X, Zhang L. Designed constitution
of NiO/Ni nanostructured electrode for high

performance lithium ion battery. Electrochim Acta.

2013 Feb 28;91:267–74.

[68] Oh SW, Bang HJ, Bae YC, Sun YK. Effect of calcination
temperature on morphology, crystallinity and
electrochemical properties of nano-crystalline metal

oxides (Co3O4, CuO, and NiO) prepared via ultrasonic
spray pyrolysis. J Power Sources. 2007;173(1):502–9.

[69] Werber T. Joining of nickel powder grains by thermal
oxidation. Vol. 42, Solid State Ionics. 1990.
https://doi.org/10.1016/0167-2738(90)90009-G

[70] Hernández N, Moreno R, Sánchez-Herencia AJ, Fierro
JLG. Surface behavior of nickel powders in aqueous

suspensions. J Phys Chem B. 2005;109(10):4470–4.
[71] Evans HE. Stress effects in high temperature

oxidation of metals. International materials reviews.

1995;40(1):1–40.
[72] Clarke DR. S tress generation during high-

temperature oxidation of metallic alloys. Vol. 6,

Current Opinion in Solid State and Materials Science.
2002.

[73] Huang Y, Sun W, Xu K, Zhang J, Zhang H, Li J, et al.
Robust interphase on both anode and cathode

enables stable aqueous lithium-ion battery with

coulombic efficiency exceeding 99%. Energy Storage
Mater. 2022;46:577–82.

[74] Wang Z, Zhang P, Li J, Zhang C, Jiang JX, Lv M, et al. A
low-cost naphthaldiimide based organic cathode for

rechargeable lithium-ion batteries. Front Chem.
2022;10.

[75] Yasin G, Arif M, Ma J, Ibraheem S, Yu D, Zhang L, et al.

Self-templating synthesis of heteroatom-doped large-
scalable carbon anodes for high-performance lithium-

ion batteries. Inorg Chem Front. 2022;9(6):1058–69.
[76] Lee SH, Harding JR, Liu DS, D’Arcy JM, Shao-Horn Y,

Hammond PT. Li-anode protective layers for Li
rechargeable batteries via layer-by-layer approaches.
Chemistry of Materials. 2014;26(8):2579–85.

[77] Zhao W, Luo G, Wang CY. Modeling nail penetration
process in large-format Li-ion cells. J Electrochem

Soc. 2014;162(1): A207.

[78] Rahman MA, Wen C. A study of the capacity fade of
porous NiO/Ni foam as negative electrode for

lithium-ion batteries. Ionics (Kiel). 2016 Feb
1;22(2):173–84.

[79] Maleki H, Howard JN. Internal short circuit in Li-ion

cells. J Power Sources. 2009;191(2):568–74.
[80] Cai W, Wang H, Maleki H, Howard J, Lara-Curzio E.

Experimental simulation of internal short circuit in
Li-ion and Li-ion-polymer cells. J Power Sources.

2011;196(18):7779–83.
[81] Li B, Zhang H, Wang D, Lv H, Zhang C. Agricultural

waste-derived activated carbon for high performance

lithium-ion capacitors. RSC Adv. 2017;7(60):37923–
8.

[82] Hosono E, Matsuda H, Honma I, Ichihara M, Zhou H.
High-Rate Lithium Ion Batteries with Flat Plateau

Based on Self-Nanoporous Structure of Tin Electrode.

J Electrochem Soc. 2007;154(2): A146.



SET. Siddiqui et al. /Future Sustainability                                                                           February 2024| Volume 02 | Issue 01 | Pages 01-13

13



[83] Huang XH, Tu JP, Zhang CQ, Zhou F. Hollow
microspheres of NiO as anode materials for lithium-

ion batteries. Electrochim Acta. 2010 Dec

1;55(28):8981–5.

[84] Poizot P, Laruelle S, Grugeon S, Dupont L, Tarascon
JM. Nano-sized transition-metal oxides as negative-
electrode materials for lithium-ion batteries. Nature.

2000;407(6803):496–9.
[85] Jin J, Wu L, Huang S, Yan M, Wang H, Chen L, et al.

Hierarchy Design in Metal Oxides as Anodes for
Advanced Lithium‐Ion Batteries. Small Methods.
2018;2(11):1800171.

[86] Nie M, Chalasani D, Abraham DP, Chen Y, Bose A,
Lucht BL. Lithium ion battery graphite solid

electrolyte interphase revealed by microscopy and

spectroscopy. The Journal of Physical Chemistry C.

2013;117(3):1257–67.
[87] Aurbach D, Ein‐Eli Y, Markovsky B, Zaban A, Luski S,

Carmeli Y, et al. The study of electrolyte solutions

based on ethylene and diethyl carbonates for
rechargeable Li batteries: II. Graphite electrodes. J

Electrochem Soc. 1995;142(9):2882.
[88] Lu M, Cheng H, Yang Y. A comparison of solid

electrolyte interphase (SEI) on the artificial graphite

anode of the aged and cycled commercial lithium ion
cells. Electrochim Acta. 2008;53(9):3539–46.



 This article is an open-access article
distributed under the terms and conditions of the Creative
Commons Attribution (CC BY) license

(https://creativecommons.org/licenses/by/4.0/).



https://creativecommons.org/licenses/by/4.0/
https://creativecommons.org/licenses/by/4.0/
