Scale and implementation of the possible solar-

hydrogen system for island communities
Minh Tran*

Department of Mechanical Engineering, Arkansas Tech University, 1811 N Boulder Ave, Russellville, AR, 72801, USA

               A R T I C L E   I N F O


Article history:
Received 28 June 2024
Received in revised form
02 August 2024
Accepted 12 August 2024

Keywords:
Hydrogen fuel, Solar power, Microgrid power,
Photovoltaic, Green hydrogen

*Corresponding author
Email address:
htran2@atu.edu


DOI: 10.55670/fpll.fusus.2.3.3


A B S T R A C T


As technology progresses, there is an increase in possibilities of designing an

independent and self-reliant energy source for small communities. Island and

remote communities often have to rely on fuel transportation and main grid

development for energy supply. By using renewable energy as an alternative

choice for energy sources, small communities can remove hazardous emissions

while saving money on fuels and shipping costs. Solar-to-Hydrogen (StH)

microgrid is a system of solar panels and hydrogen energy systems that can

capture and store solar energy for daily usage without fear of energy disruption

during nighttime. Despite the initial high capital investment, the concept can be

explored and implemented as the long-term economic benefits are present

when the cost of electricity is high for remote locations. This study is dedicated

to researching and designing a microgrid that can sustain a small community

without the presence of 3rd energy source for these communities.



1. Introduction

Since the beginning of the 21st century, renewable
energy has become the main topic and focus of global
development policies to gradually transform into an
alternative source in the event of fossil fuel depletion.  Solar
energy, geothermal energy, wind energy, tidal energy, and
wave energy…  have been the notable energy sources to
generate electricity in a sustainable and self-reliant manner.
As the global population reaches over 8 billion in 2023 and as
the life standard continues to increase, the state of energy
sufficiency becomes more dramatic and problematic and
requires the mass application of renewable energy. Two of
the most successful renewable energy sources are solar
energy and wind energy.  They have been utilized in large-
scale industrial and commercial applications. Solar power has
the greatest potential of all, with 3×1024 MJ of energy released
from the sun to Earth's surface annually [1]. Only a very small
portion is currently exploited by humans, and there are
numerous opportunities along with the development of
future technology. In recent years, solar energy has become
the answer to energy questions for remote and island areas.
These areas, in many cases, do not have access to the main
gridlines or do not have the capability to support such
infrastructure. Because of this, electricity generation costs are
higher in isolated communities, regardless of subsidies from
local governments. For example, in 2023, the electricity cost
in the mainland United States is $0.12/kWh, while on the

island of Hawaii, it is $0.40/kWh, four times the mainland cost
[2].  Instead of relying on fossil fuels, solar energy can pose as
an alternative self-sustaining solution. No transportation of
fuel is required, while the emission is eco-friendly. For small
and isolated communities, solar power microgrids can be a
viable option for long-term energy solutions. A microgrid is a
small electrical generating system that can be independent
and self-reliant. It ensures a stable and reliable energy source
while maintaining a manageable, economical cost for
communities. Microgrid design consists of 4 main
components: the micro-energy source, the distribution
network, the energy storage system (ESS), and the control
module [3]. As it is designed to be compact and flexible for
locations, it can be grid-connected or totally isolated. The
micro-energy source itself can be fully conventional, hybrid
renewable, or fully renewable. As the fossil fuel cost continues
to rise, accompanied by future carbon taxes, the solar power
microgrid offers total independence without the need for
ports and logistic infrastructure development for fossil fuel
transportation. In one of the studies, Ma et al. confirmed the
feasibility of a solar system in combination with wind power
for a remote island [4]. Nonetheless, solar power microgrid
has some disadvantages. It relies on daytime, geographic
conditions, and weather conditions. Solar energy can only be
generated during the daytime; this means that the surplus
energy is either wasted or needs to be stored somehow to
reserve the energy for nighttime. During nighttime, solar

Future Sustainability

Open Access Journal

https://doi.org/10.55670/fpll.fusus.2.3.3

























August 2024| Volume 02 | Issue 03 | Pages 12-23

Journal homepage: https://fupubco.com/fusus


ISSN 2995-0473

mailto:htran2@atu.edu
https://doi.org/10.55670/fpll.fusus.2.3.3
https://fupubco.com/fusus


Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

13



energy generation is almost zero, and fossil fuels or backup
gridlines have to be used to substitute.  Daytime in the
summer is also longer than in the winter. This varies the
amount of energy generation over the seasons. Different
geographic conditions also have negative effects on solar
power. The efficiency of power generation increases as the
location is closer to the equator as shown in the potential
photovoltaic (PV) map Figure 1. Locations such as Hawaii,
Guam, or the Virgin Islands will require fewer solar panels
with greater output when compared with other locations such
as Attu and Nunivak islands. Finally, weather conditions have
significant effects on solar power. Cloudy weather over a long
period of time will hamper the generation output. That is the
reason why an energy storage system is required in the
microgrid system. Most of the time, solar power excess is left
to be wasted if it cannot be integrated back into the main grid
or already exceeds the load capacity. Studies often show the
generated energy curve increases gradually during the day,
overreaching the required load during mid-day, then
gradually decreasing in the afternoon until sunset. In the case
of an ESS, when the generated energy curve and usage load
have intersected, the excess will be converted and stored so
that it can be released when the solar power output can no
longer sustain the energy load. This can be nighttime, bad
weather days, or a black-out emergency. Current ESS types
include the battery model (BESS), the hydrogen model
(HESS), and the hybrid model. The hydrogen model (HESS)
works by converting the electrical power into hydrogen gas
through the process of electrolysis. Hydrogen gas is then
compressed and stored in an external tank. When the solar
power output can no longer sustain the energy load, hydrogen
gas is decompressed and converted back to electricity
through fuel cells (FC). Different from BESS, which is
constrained by the battery size and number, the hydrogen
model is constrained only by its storing capacity. This allows
it to be externally expanded until the hydrogen storage
capacity overcomes the solar power excess. One of the papers
related to the area is Li et al.'s study on the surplus renewable
energy source generation on the island of Kyushu, Japan, to
decrease the energy curtailment [5]. The solar power
curtailment would be converted into a huge amount of
hydrogen gas, adding value to the grid-connected solar and
wind energy. The model of a solar-hydrogen system (SHS) has
been in discussion in the last few decades. Despite the
benefits of hydrogen fuel cell systems, their development has
been limited due to the extremely high cost of the
electrolyzers. The high investment in electrolyzers, in
addition to the renewable energy generator, has often caused
a reduction in design scale. The hydrogen system itself also
has some setbacks in terms of its technology with fuel cells
having only around 40-60% efficiency.  Hydrogen itself is a
highly flammable gas with the chemical characteristics of
metal embrittlement when being stored for a long period of
time.  Making hydrogen even more dangerous is the fact that,
unlike a hydrocarbon flame, human senses cannot easily
detect a hydrogen flame. People who come upon a hydrogen
flame will not see it, even up close. For microgrids, this poses
potential problems if careful maintenance and inspection are
not performed regularly. Some research has proposed to
transport hydrogen gas for external applications, with prices
fluctuating at US$5/kg in 2023 [6]. This comes with a loss of
self-reliance on the microgrid, with the system having to rely
on the main grid at critical hours. Although it can be more
economically viable, this leaves out as the solution for remote

areas where microgrid is supposed to ease the energy

concerns.


Figure 1. Potential for Solar PV energy according to World Bank

Group’s Global Solar Atlas [7]

Most studies have called out these problems and have

often mentioned the compulsory combination of backup

gridlines, fossil fuels, and wind power to substitute for the

power drop. However, the current scale has been minimal in

terms of the research on the possibility of totally independent

microgrid. For example, Shahbazbegian et al. [8] and

Nakamura et al. [9] designed power-to-hydrogen systems

that still rely on the main grid for the load's substitute.

Therefore, this paper dedicates itself to the possible

application of an SHS under a totally independent microgrid

for remote and island areas. This paper also identifies the

optimal model, the size, the cost of installing a hydrogen

system, and the economy of such a model. The goal is to

understand the economic possibilities of the design for

isolated areas.

2.  Methodology

2.1 End-user application

For practical purposes, the microgrid is designed to be

able to sustain a university hall's electrical load. The test

subject is Arkansas Tech University's engineering

department, Corley Hall (Figure 2).  The building occupies an

area of approximately 2,525m2 or 27,190ft2 with four parking

lots, each with a size of 4,000 m2. The possible maximum

infrastructure area for the model includes the roof area as

well as four parking lots with a total area of 16,000m2.

Because Corley has two floors, the generated energy must

satisfy the load of a total of 5,050m2. Since the actual data on

the annual electrical usage is unavailable during the study, the

value for annual energy usage is based on the national

electrical usage data from the U.S. Energy Information

Administration (EIA) (see Table 1). According to EIA, an

average university consumes over 1.2 million kWh annually.

When compared to a small household, this is equivalent to

150 houses or a small community. This can serve as a good

reference for isolated and island communities. The study

chose solar-to-hydrogen microgrid as the main studied

model. The design took into consideration the location of the

University as well as comparing it to different locations to

calculate the scale and capital cost. Regardless of the location,

the minimum energy output must be able to cover the

required energy load during the lowest daytime time frame

without the need for main gridlines integration. The scale of

the power model must fit within the building's precinct and



Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

14



must be optimized for the setup, maintenance, and sustaining.

The total electricity consumed by the building is calculated

through equation (1), in which the area and the power density

are provided.

Edaily load = Atotal.
S

t
                           (1)

where Edaily load is total energy consumption in a day, Atotal is

the total area of all surface floors in the building, S is the

power density or the average consumed power per square

foot (
kWh

m2∗yr
), and t is the time, which, in this case, is 365 days.



Figure 2. Arkansas Tech University's engineering department [10]

Table 1. Annual electricity consumption totals [11, 12]

  per building
(thousand
kWh)

Average size
(Thousand 𝑓𝑡2)

Average
per
square
foot
(kWh)

Median
per
square
foot
(kWh)

Education  345         31.5 11.0         8.7

College or
university

1,202         69.2 17.4         14.4

Small
Household

8 1.4 5.4 -

Average
house

10 2 5.4 -



2.2 Testing Model

The model in this study is a solar-to-hydrogen system

(StH), as shown in Figure 3. Solar power from the sun is

converted to electrical energy through a photovoltaic panel

(PV panel). The solar power gradually increases during

daytime, peaks during midday, and decreases as nighttime

approaches. As it increases, the solar power energy level

passes the demand load, where most of the energy excess is

wasted. In the microgrid system, the excess energy is

transferred to the battery and then to the electrolyzer to

convert electrical energy into hydrogen gas for storage. As

Hydrogen gas is generated through an electrolyzer, it is

compressed and transferred into a storage tank where it is

kept until needed. When solar power decreases below the

demand load, the battery kicks in as a temporary energy

source. After the battery's energy level decreases under a

certain percentage, the fuel cell kicks in and supplies the load

demand until the next solar power cycle. Parra et al. show that

photovoltaic power is generated effectively from 9 a.m. to 5

p.m. during a high-output day [13]. During that time,

electrolyzers began to convert excess electricity to hydrogen

at the rate of 65-70% of the electrical power received from

the PV panels. Electrolyzers' gas is depleted at around 4 p.m.

as the photovoltaic power decreases. At the same time, the

Hydrogen gas was pumped from the storage tank to fuel cells

to generate electricity and continue so after the PV panels

were off. Li et al. [14] show the electrolyzers' output peaked

between 12 p.m. and 2 p.m., while fuel cells' output remained

constant after 7 p.m. in one of the models. Due to efficiency

during hydrogen conversion as well as covering the real-time

demand load, the energy produced by solar PV must be higher

than electrolyzers while the energy produced by the FCs must

be lower than electrolyzers. Figure 4 shows the

representation of energy level of PV, electrolyzers, and FCs

throughout the day if the testing model was to be put into

operation.



Figure 3. Microgrid system schematic



Figure 4. Desired energy level vs. time of microgrid's energy source



2.3 Photovoltaic panel (PV panel)

 For the microgrid to operate independently and without

relying on a 2nd energy source, the energy generated by solar

power must be equivalent to or higher than the demand load or

𝐸𝑃𝑉 ≥ 𝐸𝑙𝑜𝑎𝑑. However, Figure 4 indicates that since the time to

generate solar power is limited according to daytime, the energy

rate or power of the PV must be much higher than the demand

load so it can generate enough excess energy to store for nighttime

or equation (2). The power generated by PV panels or daily

energy is calculated from the product of solar insolation SI

(
𝑘𝑊h

𝑚2.  𝑑𝑎𝑦
 ), the available surface area 𝐴𝑠𝑢𝑟𝑓𝑎𝑐𝑒  (𝑚2) and the

efficiency of commercial solar panels, equation (3).

PPV ≫ Pload                                      (2)

EPV = SI .   Asurface .  η                 (3)





Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

15



The solar insolation SI is generated by measuring the solar

radiation in a set period of time. As it is measured, each location,

depending on the latitude difference and seasons, has a

distinguishing value. Figure 5 shows the average solar energy per

square meter that any location within Arkansas might receive in a

day. Figure 5 also shows the variation in SI between different

months. As seasons change, SI values peak during summer and

plummet during the winter. The SI values are also different when

being compared at different latitudes and different climates.

Figure 6. shows the lowest average SI values in different states of

the United States territory. States that are closer to the South and

near the equator have higher SI values as well as the most stable

trends. The top state is Hawaii, with the lowest value at 3.83

kWh/m2 per day during December and the highest value of 6.6

kWh/m2per day during June and July. In order to design a model

that can sustain and operate fully independently, the minimum

values for SI are used to calculate the generated energy of PV

panels based on a hypothetical area. The obtained values are then

compared to total energy consumption in a day Edaily load in order

to determine the correct scale of the solar panels' area. The goal is

to have a sufficient amount of energy during daytime use and to

store it for nighttime use. The efficiency of most current solar

panels varies between 17% and 20% [16].  However, research has

shown that efficiency can reach the range of 30% in some studies

[17]. For this study, the PV efficiency is set at 20%.

Figure 5. Average solar insolation of Arkansas throughout a year [15]


Figure 6.  Lowest average seasonal solar insolation of states in a day

[15]

2.4 Battery system and model

 The BES has been a subject undergoing intense study

and discussions for usage in a microgrid system. BES is the

traditional method for storing backup energy in an electricity

circuit and has high reliability in power transition during

energy switch [18]. Before HES, BES was the default standard

for storing electrical energy from gas turbines, fossil fuel

engines, and renewable sources. For small independent and

island grids where the load is under 5-200MW, BES has been

very effective in providing and maintaining electricity service

[19]. BES stores energy through an electrochemical process

where the chemicals are contained inside the battery to

absorb the energy. Some batteries have an instantaneous

response time of about 20ms, which allows them to adapt

quickly to any situation [20]. When a high load is required in

the grid, and the battery is no longer charged, the battery

releases the energy back into the system, maintaining the

gridline's operation. BES maintains uninterrupted and stable

power flow to the gridlines as long as there is still power

stored in the chemical. When the system observes a sudden

peak in energy usage in the microgrid, the BES enables

flexibility for the system without the risk of blackout. Despite

its advantages, the battery itself has some minor setbacks. As

it stores energy within its chemical, when storing capacity is

reached, excess energy generated from the renewable energy

source has to be wasted. In order to increase the BES capacity,

another battery must be installed. This increases both the

complexity of integrating the system as well as the required

space for the battery itself. Even though the battery can

discharge 90-100% of its energy, frequent charge and

recharge cycles reduce its lifespan significantly. Hlal et al. [21]

studied the optimum battery depth of discharge of off-grid

solar PV and stated that the range is between 20% and 70%

to maximize the life cycle of BES. Alramlawi et al. [22] claimed

that when comparing the battery lifespan of the dept of

charge between 40% and 90%, there is a decrease of more

than 25% or 15,000h in lifespan. Unlike BES, HES allows more

capacity in energy storage since it stores its energy externally

in the form of hydrogen gas. This allows the microgrid to

expand its capacity by installing more storage tanks for

hydrogen in case of excess energy without increasing the

complexity of the electrical integrating system. However, FC

in HES has a relatively slow response time in comparison with

the traditional battery. Sun et al. [23] tested the PEMFC under

multiple conditions of temperature, pressure, anode, and

cathode humidification and showed that FCs could take

anywhere from 2 minutes to half an hour in order to reach

their capacity and stabilize the released power. In actual

application, this can lead to sudden power drops and

blackouts if the microgrid only relies on HES to supply the

energy. Sudden changes in demand load and short-term loss

in PV power put extreme stress on FCs as well as ELs. In a

cloudy day, both FCs and ELs have to turn on and off

continuously over a long period of time, degrading their

lifespan. Therefore, a battery is needed in the microgrid in

junction with the HES, so the power supply is always stable

and uninterrupted. One of the most optimal setups is the

battery-concentrated system, which charges and releases the

battery first before HES. When BES is charged over 60-70%,

energy is transferred into ELs where it is converted to

hydrogen gas. When BES is depleted under 50%, FCs start to

convert hydrogen back to electricity for long-term usage.

Figure 7 illustrates how the BES-HES system can operate.

Kafetzis et al. [24] proposed the start of FC cycles at the 20%

limit and Els at the >70% limit of the battery's SOC in a

battery-concentrated-hydrogen system. The study also

mentions that the FC should be utilized to maintain the



Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

16



battery's SOC at 50% whenever its SOC reaches the lower

limit to ensure safe operation.  Rey et al studied how the

battery-concentrated system could outlast the HES-

concentrated system [25]. They concluded that the HES-

concentrated system would cost 3 times more in investment

while requiring a replacement of 3 ELs and 8 FCs in the course

of 20 years. The BES-concentrated system would only require

a replacement of 1 battery bank and 1 EL in the same

condition. The BES system is only responsible for supplying

short-term energy during the transition state (~30 minutes)

or during a sudden power surge. This is considered the most

efficient metrology to utilize the HES while optimizing the

best lifespan of the system.



Figure 7.  Possible setting for Battery SOC in junction with EL and FC

cycle

2.5 Electrolyzers

There are currently 2 common types of electrolyzers

widely utilized for commercial applications: Alkaline

electrolyzers and Proton-exchange membrane electrolyzers.

Their compact size and relatively low maintenance cost are

the main reasons and focus for the integration of HES in

microgrid development. In order to decide which electrolyzer

to use, 2 things are taken into account: the ROI cost and the

lifespan of the system. ROI cost must be achieved within the

lifespan of the system in order for the model to be successfully

implemented. Alkaline electrolyzer (AEC) is currently one of

the three most common electrolysis processes, in which

water is split into hydrogen gas for commercial or industrial

usage. It is also the oldest electrolysis method, dated back to

the 1800s [26] AEC consists of a cathode, an anode, a

separator, and an alkaline electrolyte solution. KOH or

Potassium Hydroxide is currently the most common solution

for AECs, other than NaOH or Sodium Hydroxide. The process

requires electricity as an input of energy and releases heat as

a byproduct. The AEC operates at around 60- 80℃  and 1.8-

2.4V of terminal cell voltage with an efficiency of around 62-

82% [27, 28]. For every kWh of electrical energy, AEC

produces around 0.019 kg of hydrogen gas [29]. The cost of

an AEC varies from around $250-400 per kW, which is

cheaper than a PEMEC electrolyzer [30]. It also accepts high

tolerance for impurities and dust in the feedstock. Since its

components are widely available, it does not depend on the

noble metal catalyst like other electrolyzers [31]. In contrast,

it is less efficient than PEMEC and requires higher operating

pressure [32]. AEC generally has a lifetime of 60,000- 90,000

hours or around 8 years. However, due to its alkaline nature,

it is more prone to oxidization and corrosion, which can

reduce its lifespan to below its standard time. It also can take

up to 50 minutes for the AEC to be in full operation mode,

while the PEMEC only takes 5 minutes [33]. Evolving from the

AEC, the proton-exchange membrane electrolyzer (PEMEC)

uses solid polysulfonated membranes as both a separator and

a gateway for ions. The membranes have better gas

permeability, productivity, and pressure characteristics and

require lower thickness. This allows PEMEC electrolyzer

systems to be more compact while producing pure hydrogen

gas at higher rates than others. For every kWh of electrical

energy, PEMEC produces around 0.021 kg of hydrogen gas

[34]. As a result, PEMECs have become more favorable for

pure hydrogen generation.  PEMEC's operating temperature

is the same as AEC at around 60- 80℃ [35]. PEMEC's

efficiency varies between 70% and 80%, with a study

showing a possibility of 94% [35, 36]. Despite its higher

efficiency, the PEMEC structure requires the usage of noble

metals like Platinum, Iridium, and Ruthenium. Currently,

platinum is considered the state-of-the-art electrocatalyst for

the PEMEC cathode [37]. As these materials are rare and

precious metals, the cost of the PEMEC is significantly

increased. The current cost is $500-1100 per kW, and a single

PEMEC costs around $400,000- $870,000. Its lifespan is also

less than AEC, with the durability at around 30,000h -40,000

[38]. This can be traced to PEMEC's higher efficiency, purity,

and ability to produce hydrogen under higher pressure,

which is attributed to its fast degradation [39]. In order to

calculate the amount of hydrogen gas produced by the

electrolyzer, the Gibbs free energy ∆Gd
0 is used to represent

the electrical power required to break the O-H bonds and

generate the hydrogen molecules. The electrolysis process is

represented by equation 4.

H2O → H2 +
1

2
O2                                             (4)

∆Hd
0(H2O(l)) =  + 285,840

kJ

kmol
                (5)

∆Sd
0(H2O(l)) = 163.150

kJ

kmol K
                 (6)

∆Gd
0(water) = ∆Hd

0 − T∆Sd
0                         (7)

where ∆Hd
0 is the enthalpy, ∆Sd

0 is entropy, and T represents

the operating temperature of the electrolyzer. The unit of ∆Gd
0

is under J/mol, so it needs to be converted to kg of hydrogen

gas. ∆Gd
0 is divided to MH2 = 2 kg/kmol to obtain the unit J/g

or kJ/kg as 1 mol of hydrogen gas equals to 2 g hydrogen gas.

The full equation to get mass of hydrogen from PV's energy is

represented by equation 8, where 1kJ= 2.87 × 10−4 kWh and

η is the efficiency of the electrolyzer.

ℳH2 =
ηEC(EPV)(MH2)

∆Gd
0


1

2.87×10−4              (8)



Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

17



For PEMEC with η = 0.7 and operating temperature of 60℃,

the simplified equation is:

ℳH2 =
EPV

47.46
                               (9)

For AEC with η = 0.62  and operating temperature of 60℃,

the simplified equation is:

ℳH2 =
EPV

53.58
                           (10)

Both 47.46 kWh/kg and 53.58 kWh/kg can be validated using

the previously mentioned ratio of mass and electrical power.

2.6 Fuel Cells (FC)

Current technology has propelled the fuel cell system to

be widely used in portable and stationary applications. While

having the same reverse characteristics as the electrolyzer,

the proton membrane fuel cell (PEMFC) has seen greater

advancement in comparison with the alkaline fuel cell (AFC).

Despite its reliability, AFC has a very low lifetime, measured

between 3,000-5,000 hours or around 1 year, due to the

voltage degradation of the individual cells [40]. The main

cause of degradation is due to the corrosion by CO2 where CO2

reacts with free OH- ions to form carbonate CO32- ions and

reacts with Potassium in its electrolyte to form salt [41]. This

reduces the available electrolyte KOH within the FC with the

rate proportional to current density. Hence, the durability of

the AEC degrades over a short period of time. Although the

AFC has a relatively affordable cost of $400-$600 per kW, it is

not considered in this study [42].  On the other hand, PEMFC

has passed the demonstration phase and has been

successfully applied in commercial vehicles and backup

power applications. PEMFC uses perfluorosulfonic acid

membranes in its design to allow hydrogen ions to flow to the

cathode of the FC. It is considered to be low-temperature FCs

that operate around 50-80℃ [43]. As the temperature, FC

loses its efficiency as the energy release is inversely

proportional to temperature. Due to PEMFC's wide

application and design, its efficiency has a wide range

between 40% and 80% [44, 45]. Parra et al. [46] designed a

community hydrogen storage system for end-user

applications and stated that the efficiency of PEMFC is 79%.

For this study, the efficiency of PEMFC is set at 60%. The

current cost of PEMFC has fluctuated a lot based on the

countries and the providers. In the U.S., the price is about

$700 per kW [47]. The lifetime of PEMFC has somewhat

influenced its popularity in research and development.  It is

targeted to last around 60,000-90,000 hours or 8-10 years for

steady-state operation [48]. However, PEMFC has some

minor setbacks. Although PEMFC can provide stable electrical

power for the microgrid, its response time can be too long to

avoid a brief blackout during the transition period. Cheng et

al. investigated the PEMFC dynamic response and affirmed

that it takes about 25 seconds for the power of PEMFC to rise

from 10 kW to 110 kW [49]. In order to counter this setback,

the BES system, therefore, has a decisive role in the microgrid,

ensuring a smooth transition between energy modes. The fuel

cell process is presented by equation 11.  The electrical power

generated by an FC system is due to the changes in the Gibbs

free energy of formation ∆Gf between the products and the

reactants. The theoretical energy generated by a fuel cell has

a value close to 33 kWh/kg under 100% efficiency which

matches with reference [50].

H2 +
1

2
O2 → H2O               (11)

∆Gf = ∆GH2O(l) − ∆GH2(g) − ∆GO2(g)             (12)

where at the temperature of 50℃

∆GH2O(l) = −308,464
kJ

kmol
 ,

 ∆GH2(g) = −42,180
kJ

kmol
,   ∆GO2(g) = −33,130

kJ

mol


EFC = ℳH2
∆Gf

MH2
(2.87 × 10−4)η          (13)

For PEMFC with η=0.6 and operating temperature of 50℃, the

simplified equation in kWh is:

EFC = 20.07(ℳH2)                                  (14)

3. Results and discussion

The total power consumption of the Corley building is

approximately 2,590 kWh/day. The total roof area of the

Corley building is 2,525𝑚2, which can generate a maximum

average of 2570 kWh using equation 3 under the condition

that 80% of the area can be utilized. This figure, however, is

insufficient to allow the microgrid to be self-reliant or sustain

the power grid during the majority of the year. Figure 8 shows

the generated power and the power deficit of the PV grid. The

power deficit decreases during the summer months when

solar radiation is higher. Nonetheless, during winter months,

the available solar power can only supply 35-40% of the load.

Therefore, the roof-top PV is not sufficient to sustain the

building's energy usage.


Figure 8.  Generated power and power deficit under roof-top PV

panel

The alternative is to utilize the four parking lots with a

total area of 16,000𝑚2 instead to see if the generated power

from the parking lots can fulfill the required energy load. The

model for the installation of PV panels is based on parking lots

of the Intel semiconductor factory in Phoenix, Arizona, which

combines the solar panel as the roof for parking spots. The PV

panel generates solar power as well as provides shading areas

for vehicles, as in Figure 9a. If 85% of the area is able to be



Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

18



utilized, the PV grids might see a significant surplus in energy

during operation.

(a)



(b)
Figure 9.   a) Solar PV roof parking lot and b) Generated power and

power deficit under solar PV roof parking lot

According to Figure 10, even in the lowest month of solar

radiation, the microgrid would see a generation of 6,188 kWh,

a surplus of 3596 kWh in comparison with the power

consumption of 139%. This surplus covers HES loss during

the EtH conversion as well as the HtE conversion. Using the

data of load profile for a typical college building in California,

a proportional dataset can be generated to simulate the actual

load at Arkansas Tech University during the day [51]. In order

to define the minimum capacity of the hydrogen tank, its mass

needs to be calculated from the surplus of the PV power. The

average surplus can be calculated by subtracting the demand

load from the generated PV power at the same hour.  Figure

10 shows the effective sun hour per day in each month in

Arkansas. During December, the number of effective sunlight

hours is only 3.5 hours, according to NREL [52].  As a result,

the amount of needed hydrogen for the rest of the day must

be generated in that 3.5-hour frame when the PV energy

generation is maximized.  Figure 11 shows the required

power generation during the 3.5 hours and the estimated

power consumption during the day (total consumption is

2590 kWh). The comprehensive amount of electrical energy

to be converted to hydrogen gas after subtracting it from the

consumed energy is 5,575 kWh or 90% of the generated PV

energy. Using equation (9), the amount of equivalent

hydrogen mass using the PEMEC is 117 kg. For the AEC, the

amount of equivalent hydrogen mass is 104 kg using equation

10. The hydrogen storage tank that the microgrid needs lies

between 120 kg and 150 kg for the minimum value, where the

extra capacity can be used as seasonal or weather backup.


Figure 10. Effective sun hour per day vs. month of Arkansas [52]







Figure 11. Total energy usage and generated solar power vs. hour in

a day in December

When sunlight is no longer available, FCs kick in to

convert the hydrogen gas back to electricity. Using equation

14, the amount of equivalent electricity in a PEMEC-PEMFC is

2348 kWh. In the AEC-PEMFC, the generated electricity is

2087 kWh. The possible total amount of electricity supplied

by the microgrid is 2960 kWh and 2700 kWh for PEMEC-

PEMFC and AEC-PEMFC, respectively. This amount of energy

is sufficient for the microgrid to be independent during the

lowest sunlight month of December. Figure 12 shows the

estimated model for the energy cycle within the microgrid. In

order for the microgrid to be implemented in actual

applications, its ROI must outweigh its cost during its lifespan.

Therefore, it is necessary to generate the balance sheet for 30

years. For every 10 years, both the EC and FC are required to

be replaced due to their lifespan degradation. The estimation

for total cost (excluding battery and grid components) is

shown in Tables 2 and Table 3. The PV panels cost about

$3,060 per kW and are the most expensive investment in the

microgrid due to their scale [53].



Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

19







The Hydrogen tank with compressed pressure costs

around $400-$700 per kg of hydrogen gas and is the least

costly spending [54]. The total capital spending is then

compared with different electrical costs from different

locations, as in Table 4. Arkansas, which is located within the

mainland United States, has a fairly low cost of energy at $0.12

per kWh in 2023 [55]. In contrast, Martinique Island of

France, which is located in the Caribbean Sea, has a high cost

of $1.14 per kWh [56]. Small islands with small populations

tend to not afford to build and maintain large power plants

and therefore, have higher rates of electricity. The island of

Cook and Solomon (island countries), which has less than 1

million inhabitants, have rates around $0.52-$0.69 per kWh.

The cost of electricity of each location is multiplied by the

total power consumption of Corley building of 945,350

kWh/year (2,590 kWh/day *365 days), then added up over

the course of 30 years to determine if and when the spending

savings across the capital spending. Figure 13 and Figure 14

show the spending vs capital spending of 2 microgrid models.

For both graphs, when the cost is below $0.30 per kWh, the

microgrid economy is unable to sustain itself under a 10-year

EC-FC replacement schedule within 30 years. As the PEMEC

lifespan is only 4-6 years, it must be replaced, and its cost

must be added to every 7th year. Hydrogen tank, AEC, and

PEMFC also need to be replaced every 10 years; therefore, the

capital cost rises every 6-10 years, depending on the model of

the microgrid. 30 years also marks the lifespan of the solar

panel to be replaced as its efficiency has decreased to no

longer fit to generate electricity [57- 59]. When the cost is

above $0.50 per kWh, the spending saving crosses the capital

investment within 15 years for the AEC microgrid while it

takes 30 years for the PEMEC microgrid. When the cost is

above $1.00 per kWh, the spending saving crosses the capital

investment within 6-9 years. The choice of AEC microgrid and

PEMEC microgrid lies solely upon the communities based on

their financial capability and requirements. For most

locations with costs under $0.50 per kWh, such as Guam and

Hawaii, the PV-AEC-PEMFC microgrid might be more suitable

as it is significantly cheaper due to the AEC cost. The ROI

might be achieved within 20 years for these locations.







Table 2. The capital spending of PV-PEMEC-PEMFC microgrid

Component   Cost per
KW/
Cost per
kg H2

 Total
Capacity
in kW or
kg H2

 Total Capital
Spending in
US$

Lifespan
(years)

 PEMEC
1,100.00


1,614.00


1,775,400.00

4-6

 Hydrogen tank
(kg)


700.00


117.00


81,900.00

10

PEMFC
600.00


153.00


91,800.00

8-10

 PV
3,060.00


1,768.00


5,410,080.00

30

 Total
7,359,180.00





Table 3. The capital spending of PV-AEC-PEMFC microgrid

Component   Cost per
KW/
Cost per
kg H2

 Total
Capacity
in kWh
or kg H2

 Total Capital
Spending in
US$

Lifespan
(years)

 AEC
400.00


1,614.00


645,600.00

8-10

 Hydrogen tank
(kg)


700.00


117.00


81,900.00

10

 PEMFC
600.00


153.00


91,800.00

8-10

 PV
3,060.00


1,768.00


5,410,080.00

30

 Total
6,229,380.00









Figure 12. Total energy usage and generated solar power vs. hour in a day in December





Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

20

































































4. Conclusion

This paper proposed a design to build a microgrid for

small communities in remote and island areas based on the

high-power consumption of a university building in Arkansas.

This microgrid uses 100% renewable energy without the

reliance on fossil fuels and other means of energy sources.

The StH microgrid consists of PV panels and an HES system

which converts excess solar energy to compressible matter

during the daytime and releases electrical energy during

nighttime. The lifespan and the economic feasibility are then

established and compared to understand the impact of such a

system in the communities. The expectation was that the

































































microgrid would eventually relieve communities of energy

constraints as well as the economic burden in the long-term

plan.

• One of the major conditions for an independent microgrid

is the location of the application and the availability of

space in the area. Location has a crucial role in determining

the scale of the system and the economic cost of the project.

The investment of PV panels is more expensive than other

investments due to its complex system and its sheer scale

in order to generate energy. To generate enough power for

small communities or commercial hubs, an area of

equivalent PV power might be 1.5-4 times the floor area of

the load demand. For this study, the ratio was 3.2 times the



Figure 13. Saving and capital spending over 30 years of PV-PEMEC-PEMFC Microgrid





Figure 14. Saving and Capital Spending over 30 years of PV-AEC-PEMFC Microgrid







Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

21



floor area of the Corley building in order to generate

enough power for the HES system, Different locations with

different climates and latitudes receive distinguished

amounts of solar radiation throughout the year. In turn, the

microgrid requires different areas of PV panels to ensure

sufficient power to the grid. For example, due to its location

and climate, Hawaii receives more sun hours and more

solar radiation per meter square than Arkansas throughout

the year. The fluctuation means that the required PV power

area of Hawaii is less than Arkansas and costs less than

Arkansas; therefore, the economic wise favors areas closer

to the equators. This poses a great challenge in

standardizing capital spending and forecasting accurate

models for PV generators.

• Two different kinds of microgrids are established and

compared based on their lifespan and their economic

feasibility: the PV-PEMEC-PEMFC microgrid and the PV-

AEC-PEMFC microgrid. The PV-AEC-PEMFC microgrid has

a longer lifespan as well as lower initial capital cost than the

alternative, which is suitable for most locations. For the

ROI, the cost of electricity at the local locations has a major

impact on the possibility of regaining the investment

budget or gaining additional income. For areas where the

electrical cost per kWh is below $0.30 -$0.40 per kWh, the

spending saving might not overcome the capital spending

in a 30-year period. This is also due to the increase of

capital spending every 6-10 years for hydrogen tanks,

electrolyzers, and fuel cells due to their efficiency and

safety degradation over time. For areas where the electrical

cost per kWh is above $0.40 per kWh like Hawaii and Guam,

the spending savings might be able to pay off within a 25-

year period under the PV-AEC-PEMFC microgrid.

Meanwhile, for the areas that are above $1.00 per kWh, the

additional income is within 10 years.

• This study did not include the BES system as it is a low-

capacity system that is only required for transition

purposes and only holds 150 kWh in a maximum 0.5-to-1-

hour period. The cost of such a system is relatively cheap

(~$150 per kWh) in comparison with the HES system.

However, the study recognizes the necessity of the BES

system in the case of fluctuation in PV power out and short-

term blackouts. The application of BES also increases the

lifespan of HES systems while decreasing the number of

charging and discharge cycles of electrolyzers and fuel cells

in daily operations. In the case of a major power surge in

the grid, it is favored that the battery system takes up the

stress instead of the HES system to reduce the damage and

replacement cost it might cause to the microgrid system.

• Future development will be able to reduce the cost and

increase the lifespan of both the PV panels and HES system so

that it is more economically viable to mass implement

microgrids for more communities. The reduction in

manufacturing PV panels and electrolyzers, in particular,

PEMEC, will have a determining impact on the microgrid

market. PEMEC has some unique characteristics in producing

higher hydrogen purity and higher efficiency while limiting

the corrosion problem that is observed in the alkaline

electrolyte. Current progress has shown that PEMEC

efficiency can achieve an efficiency of 80%. Along with the

improvement of PEMFC, this will result in lower required PV

panel areas and a reduction in capital cost.

Ethical issue

The author is aware of and complies with best practices in
publication ethics, specifically with regard to authorship
(avoidance of guest authorship), dual submission,
manipulation of figures, competing interests, and compliance
with policies on research ethics. The author adheres to
publication requirements that the submitted work is original
and has not been published elsewhere.

Data availability statement
The manuscript contains all the data. However, more data will

be available upon request from the corresponding author.

Conflict of interest

The author declares no potential conflict of interest.

References

[1]    Hosseini, Seyed Ehsan. Fundamentals of Hydrogen

Production and Utilization in Fuel Cell Systems.

Elsevier, 2023. ISBN: 978-0-323-88671-0 DOI:

https://doi.org/10.1016/C2020-0-03183-X

[2]  Choose Energy. (n.d.). Learn about electricity rates,

providers, &amp; plans: Choose energy®. Learn About

Electricity Rates, Providers, &amp; Plans | Choose

Energy®. https://www.chooseenergy.com/electricity-

rates/

[3]  Mariam, L., Basu, M., & Conlon, M. F. (2016). Microgrid:

Architecture, policy and future trends. Renewable and

Sustainable Energy Reviews, 64, 477–489.

doi:10.1016/j.rser.2016.06.037

[4]  Ma, T., Yang, H., & Lu, L. (2014). A feasibility study of a

stand-alone hybrid solar–wind–battery system for a

remote island. Applied Energy, 121, 149–158.

doi:10.1016/j.apenergy.2014.01.09

[5]  Li, Y., Gao, W., & Ruan, Y. (2019). Potential and

sensitivity analysis of long-term hydrogen production in

resolving surplus RES generation—a case study in

Japan. Energy, 171, 1164–1172.

doi:10.1016/j.energy.2019.01.106

[6]  Office of Energy Efficiency &amp; Renewable Energy.

(2021, September 1). Hydrogen shot. Energy.gov.

https://www.energy.gov/eere/fuelcells/hydrogen-shot

[7]  Solargis. (n.d.). Global solar atlas.

https://globalsolaratlas.info/map

[8]  Shahbazbegian, V., Shafie-khah, M., Laaksonen, H.,

Strbac, G., & Ameli, H. (2023). Resilience-oriented

operation of microgrids in the presence of power-to-

hydrogen systems. Applied Energy, 348.

https://doi.org/10.1016/j.apenergy.2023.121429

[9]  Nakamura, Y., Aoki, M., Kado, Y., & Iki, H. (2021). Study

on operation in microgrid including hydrogen supplying

equipment for contributing power system operation.

Electrical Engineering in Japan, 214(2).

doi:10.1002/eej.23329

[10] Google. (n.d.). Google earth.

https://earth.google.com/web/search/arkansastech+u

niversity/@35.29730806,-

93.13570327,108.25093027a,289.08682634d,35y,-

0.00678014h,67.09981852t,0r/data=CigiJgokCRJqRmp

bn0BAEeyyuZOZnkBAGf9AOr3d91vAIdHEfu-y-

FvAOgMKATA

[11] U.S. Energy Information Administration - EIA -

independent statistics and analysis. Energy Information



Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

22



Administration (EIA)- About the Commercial Buildings

Energy Consumption Survey (CBECS). (n.d.).

https://www.eia.gov/consumption/commercial/data/2

012/c&amp;e/cfm/pba4.php

[12] Almerini, A. (2023, April 12). How many kwh does a

house use?. Solar Reviews.

https://www.solarreviews.com/blog/how-many-kwh-

does-a-house-

use#:~:text=Based%20on%20the%20average%20hom

e,different%2Dsized%20homes%20might%20use

[13] Parra, D., Gillott, M., & Walker, G. S. (2016). Design,

testing and evaluation of a community hydrogen

storage system for end user applications. International

Journal of Hydrogen Energy, 41(10).

https://doi.org/10.1016/j.ijhydene.2016.01.098

[14] Li, B., Roche, R., Paire, D., & Miraoui, A. (2017). Sizing of

a stand-alone microgrid considering electric power,

cooling/heating, hydrogen loads and hydrogen storage

degradation. Applied Energy, 205, 1244–1259.

doi:10.1016/j.apenergy.2017.08.142

[15] Honsberg, C., &amp; Bowden, S. (n.d.). Average solar

radiation. PVEducation.

https://www.pveducation.org/pvcdrom/properties-of-

sunlight/average-solar-radiation

 [16] Walker, E. (2023, May 18). What are the most efficient

solar panels? top brands in 2023. EnergySage.

https://www.energysage.com/solar/what-are-the-

most-efficient-solar-panels-on-the-market/

[17] National Renewable Energy Laboratory. (n.d.). Best

research-cell efficiency chart. Photovoltaic Research.

https://www.nrel.gov/pv/cell-efficiency.html

 [18] AL Shaqsi, A. Z., Sopian, K., & Al-Hinai, A. (2020).

Review of energy storage services, applications,

limitations, and benefits. Energy Reports.

doi:10.1016/j.egyr.2020.07.028

[19] Bizuayehu, A. W., Medina, P., Catalao, J. P. S., Rodrigues,

E. M. G., & Contreras, J. (2014). Analysis of electrical

energy storage technologies’ state-of-the-art and

applications on islanded grid systems. 2014 IEEE PES

T&D Conference and Exposition.

doi:10.1109/tdc.2014.6863361

[20] P. Medina, A. W. Bizuayehu, J. P. S. Catalão, E. M. G.

Rodrigues and J. Contreras, "Electrical Energy Storage

Systems: Technologies' State-of-the-Art, Techno-

economic Benefits and Applications Analysis," 2014

47th Hawaii International Conference on System

Sciences, Waikoloa, HI, USA, 2014, pp. 2295-2304, doi:

10.1109/HICSS.2014.290.

[21] Hlal, M. I., Ramachandaramurthy, V. K., Sarhan, A.,

Pouryekta, A., & Subramaniam, U. (2019). Optimum

battery depth of discharge for off-grid solar PV/battery

system. Journal of Energy Storage, 26, 100999.

doi:10.1016/j.est.2019.100999

[22] Alramlawi, M., & Li, P. (2020). Design Optimization of a

Residential PV-Battery Microgrid with a Detailed

Battery Lifetime Estimation Model. IEEE Transactions

on Industry Applications, 1–1.

doi:10.1109/tia.2020.2965894

[23] Sun, H., Zhang, G., Guo, L., & Liu, H. (2009). A Study of

dynamic characteristics of PEM fuel cells by measuring

local currents. International Journal of Hydrogen

Energy, 34(13), 5529–5536.

doi:10.1016/j.ijhydene.2009.04.06

[24] Kafetzis, A., Ziogou, C., Panopoulos, K. D., Papadopoulou,

S., Seferlis, P., & Voutetakis, S. (2020). Energy

management strategies based on hybrid automata for

islanded microgrids with renewable sources, batteries

and hydrogen. Renewable and Sustainable Energy

Reviews, 134.

https://doi.org/10.1016/j.rser.2020.110118

[25] Rey, J., Segura, F., Andújar, J. M., & Ferrario, A. M. (2023).

The economic impact and carbon footprint dependence

of energy management strategies in hydrogen-based

microgrids. Electronics, 12(17), 3703.

https://doi.org/10.3390/electronics12173703

[26] Carmo, M. (2022, January 26). Introduction to Liquid

Alkaline Electrolysis. Department of Energy.

https://www.energy.gov/sites/default/files/2022-

02/2-Intro-Liquid%20Alkaline%20Workshop.pdf

[27] Ebbesen, S. D., Jensen, S. H., Hauch, A., & Mogensen, M. B.

(2014). High Temperature Electrolysis in Alkaline Cells,

Solid Proton Conducting Cells, and Solid Oxide Cells.

Chemical Reviews, 114(21), 10697–10734.

doi:10.1021/cr5000865

[28] Luo, Y., Shi, Y., &amp; Cai, N. (2021). Bridging a bi-

directional connection between electricity and fuels in

hybrid multienergy systems. Hybrid Systems and Multi-

Energy Networks for the Future Energy Internet, 41–84.

https://doi.org/10.1016/b978-0-12-819184-2.00003-1

[29] Mamlouk, M. (2022). Alkaline anion exchange

membrane (AEM) water electrolysers—current/future

perspectives in electrolysers for Hydrogen.

Comprehensive Renewable Energy, 473–504.

https://doi.org/10.1016/b978-0-12-819727-1.00103-5

[30] Kamaroddin, M. F. A., Sabli, N., & Abdullah, T. A. T.

(2018). Hydrogen Production by Membrane Water

Splitting Technologies. Advances In Hydrogen

Generation Technologies.

doi:10.5772/intechopen.76727

[31] Krishnan, S., Koning, V., Theodorus de Groot, M., de

Groot, A., Mendoza, P. G., Junginger, M., &amp; Kramer,

G. J. (2023). Present and future cost of alkaline and PEM

electrolyser stacks. International Journal of Hydrogen

Energy, 48(83), 32313–32330.

https://doi.org/10.1016/j.ijhydene.2023.05.031

[32] Pozio, Alfonso & Bozza, Francesco & Nigliaccio,

Giuseppe & Platter, Marzio & Monteleone, Giulia.

(2021). Development perspectives on low-temperature

electrolysis. 1. 66-72. 10.12910/EAI2021-014.

[33] Martin, P. (2023, July 5). Green hydrogen: Which type of

electrolyser should you use? alkaline, PEM, solid oxide

or the latest tech?. Hydrogen news and intelligence |

Hydrogen Insight.

https://www.hydrogeninsight.com/electrolysers/green

-hydrogen-which-type-of-electrolyser-should-you-use-

alkaline-pem-solid-oxide-or-the-latest-tech-/2-1-

1480577

[34] Malla, K. (2023, February). Shortage of electrolyzers for

green hydrogen. EY Pathenon.

 https://assets.ey.com/content/dam/ey-sites/ey-

com/en_in/topics/energy/2023/02/ey-shortage-of-

electrolyzers-for-green-hydrogen-v2.pdf



Minh Tran /Future Sustainability                                                                                               August 2024| Volume 02 | Issue 03 | Pages 12-23

23



[35] Shiva Kumar, S., & Himabindu, V. (2019). Hydrogen

Production by PEM Water Electrolysis – A Review.

Materials Science for Energy Technologies.

doi:10.1016/j.mset.2019.03.002

[36] Lewinski KA, van der Vliet DF, Luopa SM (2015) NSTF

Advances for PEM Electrolysis-The Effect of Alloying on

Activity of NSTF Electrolyzer Catalysts and Performance

of NSTF Based PEM Electrolyzers. ECS Trans 69:893–

917

[37] Wang, T., Cao, X. & Jiao, L. PEM water electrolysis for

hydrogen production: fundamentals, advances, and

prospects. Carb Neutrality 1, 21 (2022).

https://doi.org/10.1007/s43979-022-00022-8

[38] Tomić, A. Z., Pivac, I., &amp; Barbir, F. (2023). A review

of testing procedures for proton exchange membrane

electrolyzer degradation. Journal of Power Sources, 557,

232569.

https://doi.org/10.1016/j.jpowsour.2022.232569

[39] Thunder Said Energy. (2023, January 27). Green

hydrogen: Alkaline versus PEM electrolyser? - thunder

said. Thunder Said Energy.

https://thundersaidenergy.com/2023/01/17/green-

hydrogen-alkaline-versus-pem-

electrolysers/#:~:text=(9)%20Longevity%20implicatio

ns.,are%2C%20by%20definition%2C%20acidic

[40] Ferriday, T. B., & Middleton, P. H. (2021). Alkaline fuel

cell technology - A review. International Journal of

Hydrogen Energy, 46(35), 18489–18510.

doi:10.1016/j.ijhydene.2021.02.203

[41] Tomantschger, K., Findlay, R., Hanson, M., Kordesch, K.,

& Srinivasan, S. (1992). Degradation modes of alkaline

fuel cells and their components. Journal of Power

Sources, 39(1), 21–41. doi:10.1016/0378-

7753(92)85003-s

[42] Ni, M. (2005). Current Status of Fuel Cell Technologies.

Energy Exploration & Exploitation, 23(3), 207–214.

doi:10.1260/014459805774852083

[43] Hosseini, Seyed Ehsan, Hydrogen Diplomacy. Future

Publishing LLC, 2024. ISBN: 979-8-9906790-0-9

DOI: https://doi.org/10.55670/fpll.book/1

[44]  Tsuchiya H, Kobayashi O. Mass production cost of PEM

fuel cell by learning curve. Int J Hydrogen Energy

2004;29:985–90.

[45] Luo, Y., Shi, Y., &amp; Cai, N. (2021a). Bridging a bi-

directional connection between electricity and fuels in

hybrid multienergy systems. Hybrid Systems and Multi-

Energy Networks for the Future Energy Internet, 41–84.

https://doi.org/10.1016/b978-0-12-819184-2.00003-1

[46] Parra, D., Gillott, M., & Walker, G. S. (2016). Design,

testing and evaluation of a community hydrogen

storage system for end user applications. International

Journal of Hydrogen Energy, 41(10).

https://doi.org/10.1016/j.ijhydene.2016.01.098

[47] Lipman, T. E., Edwards, J. L., & Kammen, D. M. (2004).

Fuel cell system economics: comparing the costs of

generating power with stationary and motor vehicle

PEM fuel cell systems. Energy Policy, 32(1), 101–125.

doi:10.1016/s0301-4215(02)00286-0

[48] Stropnik, R., Mlakar, N., Lotrič, A., Sekavčnik, M., &amp;

Mori, M. (2022). The influence of degradation effects in

proton exchange membrane fuel cells on life cycle

assessment modelling and environmental impact

indicators. International Journal of Hydrogen Energy,

47(57), 24223–24241.

https://doi.org/10.1016/j.ijhydene.2022.04.011

[49] Cheng, S., Hu, D., Hao, D., Yang, Q., Wang, J., Feng, L.,

&amp; Li, J. (2022). Investigation and analysis of proton

exchange membrane fuel cell dynamic response

characteristics on hydrogen consumption of fuel cell

vehicle. International Journal of Hydrogen Energy,

47(35), 15845–15864.

https://doi.org/10.1016/j.ijhydene.2022.03.063

[50] Agriculture and Horticulture Development Board

(AHDB). (n.d.). Hydrogen electrolysis. AHDB.

https://ahdb.org.uk/knowledge-library/hydrogen-

electrolysis#:~:text=When%20used%20as%20part%2

0of,%2C%20or%20burning%2C%20the%20hydrogen

[51] Business Energy Advisor. (2020, June 15). Business

Energy Advisor.

https://esource.bizenergyadvisor.com/article/colleges-

and-universities

[52] "PV Watts". NREL. Retrieved 11 June 2012.

https://pvwatts.nrel.gov/

[53] How much do solar panels cost? (expert reviewed). This

Old House. (2023, July 26).

https://www.thisoldhouse.com/solar-alternative-

energy/reviews/solar-panel-cost

[54] Cerri, I.; Lefebvre-Joud, F.; Holtappels, P.; Honegger, K.;

Stubos, T.; Millet, P.; Coordination, J.; Pfrang, A.;

Bielewski, M.; Tzimas, E.  Strategic Energy Technology

Plan; European Commission: Brussels, Belgium, 2012

[55] Energy Sage. (n.d.). Compare and save on Clean Home

Energy Solutions. Energy Sage.

https://www.energysage.com/local-data/electricity-

cost/ar/#:~:text=Electric%20rates%20in%20Arkansas

,-

The%20easiest%20way&text=The%20average%20resi

dential%20electricity%20rate,rate%20of%2018%20%

C2%A2%2FkWh.

 [56] U.S. Department of Energy. (2020, August). Martinique

Energy Snapshot. Energy Transitions Initiative.

https://www.nrel.gov/docs/fy20osti/76647.pdf

[57] Howdle, D. (n.d.). Worldwide electricity pricing: Energy

cost per kwh in 230 countries. Cable.co.uk.

https://www.cable.co.uk/energy/worldwide-pricing/

 [58] Walker, E. (2022, December 12). How long do solar

panels last? solar panel lifespan 101. EnergySage.

https://www.energysage.com/solar/how-long-do-

solar-panels-

last/#:~:text=The%20industry%20standard%20for%2

0the,below%20what%20the%20manufacturer%20proj

ected.

[59]  Statista Research Department. (2023, October 19).

Battery price per kwh 2023. Statista.

https://www.statista.com/statistics/883118/global-

lithium-ion-battery-pack-costs/



 This article is an open-access article

distributed under the terms and conditions of the Creative

Commons Attribution (CC BY) license

(https://creativecommons.org/licenses/by/4.0/).



https://creativecommons.org/licenses/by/4.0/
https://creativecommons.org/licenses/by/4.0/
