79

GeoPlanning
Journal of Geomatics and Planning                          Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94



Original Research

Post-Seismic Surface Deformation of The

Tarakan Earthquake in 2015 Using the DInSAR

Technique

Imanuela Indah Pertiwi 1*, Trismahargyono 2, Marniati 3, Joshua

Purba 4

1. Kendari Class IV Geophysical Station – BMKG, Indonesia

2. Center of Earthquake and Tsunami – BMKG, Indonesia

3. Makassar Region IV Meteorology, Climatology, and Geophysics Center – BMKG, Indonesia

4. Gowa Class II Geophysical Station – BMKG, Indonesia



DOI: 10.14710/geoplanning.12.1.79-94

Abstract

Deformation can help predict the presence and severity of an earthquake. SAR image data can be used to calculate post-

seismic surface deformation using the InSAR and DInSAR methods. DInSAR (Differential Interferometric Synthetic

Aperture Radar) is a well-established technology for monitoring subsidence and uplift with millimeter precision. This study

uses SAR imagery to detect surface deformation caused by a magnitude M 6.1 earthquake on December 21, 2015, at 01:47:37

WIB in Tarakan Regency, North Borneo. The data used is Sentinel-1 satellite imagery in SLC (single-look complex) format,

with a master image from December 18, 2015 (3 days before the earthquake), and a slave image from January 11, 2016 (21

days after). The interferogram generated by the Tarakan earthquake shows deformation patterns radiating in three

directions: northeast, southeast-southwest, and southwest-northwest. Tarakan City, located south-southwest of the

epicenter, experienced the highest subsidence deformation of 0.001–0.035 meters. On December 21, 2015, the Tana Tidung

I Regency area, 33 kilometers southwest of the epicenter, showed the highest uplift deformation (0.019–0.079 meters). The

largest uplift in Tana Tidung II Regency (0.069 meters), about 10 kilometers north of the epicenter, occurred near the fault

zone. Surface deformation due to the Tarakan earthquake contributes to seismic hazard assessment in North Borneo and

indicates other locally active faults. Uplift to the east and subsidence to the west of the epicenter suggest an oblique-normal

fault, with dominant strike-slip motion and normal (downward) fault blocks to the west.

Copyright © 2025 by Authors,

Published by Universitas Diponegoro Publishing Group.

This open access article is distributed under a

Creative Commons Attribution 4.0 International license



1. Introduction

Seismotectonic processes triggered by plate movements produce seismic and volcanic activity (Hanifa et

al. 2019). Earthquake events typically alter the shape or position of the earth's surface (deformation) (Panuntun

et al. 2018). An earthquake typically causes the surrounding earth's crust to deform in both vertical and

horizontal directions (Sari et al. 2014). This deformation consists of three components: change in location

(translation), change in orientation or direction (rotation), and force (strain and stress). Deformation can be a

major factor in determining the presence and severity of an earthquake (Puspita et al. 2024). Deformation caused

by a big earthquake has a severe influence on the infrastructure and buildings above it. It is commonly recognized

that all macro earthquakes (e.g. events whose M > 3.0) cause crustal deformation, but only earthquakes over a

particular magnitude usually cause surface rupture (Gürpinar et al. 2017). The amount of deformation can be

calculated from SAR picture data (Cahyaningrum, 2024) using the InSAR and DInSAR methods. The worth of

e-ISSN: 2355-6544

Received:  23 December 2024;
Revised:  28 January 2025;
Accepted:  28 February 2025;
Available Online: 14 May 2025;
Published:  26 May 2025.

Keywords:
SAR Imagery, DinsSAR,
Deformation, Subsidence, Uplift,
Fault

*Corresponding author(s)
email: imanuela.indah@gmail.com





https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



80

surface changes can be determined by subtracting or differential InSAR (DINSAR) from three or more radar

pictures or by applying a topographic surface model (Kurniawan et al. 2016). DInSAR (Differential

Interferometric Synthetic Aperture Radar) is a well-developed technology for measuring subsidence with

excellent precision in millimeters (Islam et al. 2017). This technique employs more than two radar pictures

(multitemporal radar images), resulting in temporal decorrelation and atmospheric dishomogeneities that affect

interferogram quality.

The Tarakan earthquake is a rare occurrence, as Borneo is Indonesia's sole island with a low frequency of

seismic activity. However, the Tarakan earthquake of magnitude M 6.1 damaged several houses, including two

(two) houses in Selumit Village, Central Tarakan Subdistrict Beach, four (four) houses damaged and experiencing

landslides in Juata Kerikil Village, and one (one) house under construction that was damaged or collapsed in

Juata Laut Village (North Borneo Regional Disaster Management Agency, 2016). Based on damage data from

different sub-districts affected by the earthquake, this study uses SAR satellite image data to evaluate vertical

surface deformation information (Souza et al. 2024; Gourmelen et al. 2010; Bedini 2020) in the form of subsidence

and uplift produced by the Tarakan earthquake on December 21, 2015.

In this study, SAR pictures were utilized to detect surface deformation induced by an earthquake that

struck most of North Borneo Province on Monday, December 21, 2015, at 01:47:37 a.m., including Tarakan,

Nunukan, and Tanjung Selor. The BMKG (Meteorology, Climatology, and Geophysics Agency) analysis

indicates that this earthquake has a magnitude of 6.1 (update). The earthquake's epicenter was on land at

coordinates 3.61oLS and 117.67oBT, or 29 kilometers northeast of Tarakan City in North Borneo, with a

hypocenter depth of 10 kilometers. Earthquake shocks were felt in various locations, including Tarakan and

Nunukan IV-V MMI and Tanjung Selor III-IV MMI. The earthquake that occurred was an intraplate-type

shallow crustal earthquake with a shallow hypocenter caused by active fault activity (Center of Earthquake and

Tsunami BMKG, 2016). The earthquake has a land epicenter does not have the ability to create a tsunami.

Lu et al. 2025 successfully identified the fault movement that caused the 2025 Dapu earthquake, as

indicated by the presence of ground cracks and water ejection in the DInSAR analysis results. Research on the

use of the DInSAR method in determining potential seismic hazard areas has been conducted on the 2017 Poso

earthquake, the area in the Southern part of North Lore District is dominated by maximum uplift deformation

values and subsidence deformation values which are quite large, causing many buildings to sufferlight to heavy

damage (Puspita et al. 2024). The DInSAR method was also conducted to determine surface defromation and its

implications for land degradation after the 2021 Flores earthquake (Purba et al. 2024) on Kalatoa island. The

results showed land subsidence of up to 12 cm in Garaupa Raya Village and land uplift of up to 10 cm in Lembang

Mate'ne Village. The total area that experienced land subsidence was 39.4 km2 (50.50%), while the area that

experienced land uplift was 38.2 km2 (49.02%). Calvet et al. 2023 research proves that the DinSAR technique to

be useful and powerful for the observation and analysis of surface deformation caused by the release of stress

during the Mw 8.3 Illapel earthquake. It proved to be an efficient tool to detect and map the surface deformation

with high spatial resolution in an approximate area of 20,000 km².

There has been little research into the potential earthquake hazard on Borneo Island. The island of Borneo

has long been known as one of the areas in Indonesia that is safe from earthquake disasters. Previous research

on the Tarakan earthquake on December 21, 2015 identified micro-faults that caused the earthquake. The results

of this research show the direction of fault movement based on the distribution of aftershocks (Sriyanto et al.

2016). This research combines Differential Interferometric Synthetic Aperture Radar (DInSAR) analysis, focal

mechanism analysis, and correlation with local geological conditions. The results of SAR image processing were

analysed to determine the value of surface deformation due to the Tarakan earthquake. The surface deformation

that occurred in the area around the earthquake can provide information related to seismic hazard in the North

Borneo region, as well as identify the characteristics of the fault that caused the Tarakan earthquake. The results

of this study are expected to be a reference in improving future earthquake preparedness strategies in the North

Borneo region. The identification of fault characteristics using the DInSAR method can be a verification of the

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



81

results of previous research. The surface deformation caused by the earthquake is a visual representation of the

fault movement that causes the earthquake.

2. Data and Methods

2.1. Research Location

This research is being conducted in the province of North Borneo, which has geographical coordinates of

3°18' 00"– 4°24' 00" North Latitude and 115°30'00"–118°00' 00" East Longitude. The North Borneo region is

made up of one city and four regencies: Bulungan, Malinau, Nunukan, Tana Tidung, and Tarakan City. The

study focused on locations in North Borneo province that experienced surface deformation following the

December 21, 2015 earthquake.

2.2. The Geological Structure of Borneo Island and Seismo-Tectonics of North Borneo

Borneo formed through the accretion of microcontinental fragments, ophiolite terranes, and island-arc

crust onto a Paleozoic continental core during the Mesozoic era. At the beginning of the Cenozoic era, Borneo

formed part of the promontory of Sundaland, which was partly separated from the Asian mainland by the proto-

South China Sea (Balaguru et al. 2003). The Barito Basin in southern Borneo is underlain by accreted crust from

the Meratus Mountains in the east and Schwaner bedrock of continental origin in the west, and contains a thick

and well-exposed succession of Cenozoic sediments (Witts et al. 2012). To the north, the Kutai Basin is limited

by accreted crust from the Kucing Plateau (part of the Central Range) and Mangkalihat continental bedrock to

the west and north. Tarakan Basin is farther northerly than Kutai and is surrounded by the Dent-Semporna

accreted crust, the Sekatak-Berau Plateau, and the Mangkalihat continental basement. The links between these

basement terranes are not entirely clear. The Tarakan Basin is located offshore North-East Borneo Island, in a

structurally complex zone of continental convergence involving subduction of Northern Sulawesi (Hall, 2013;

2019); Watkinson et al. 2017).

The dominant characteristic of the Tarakan Basin is the presence of fine to coarse-grained clastic

sedimentary rocks with carbonate deposits (Hendardi et al. 2024). The temporal and spatial evolution of Neogene

deformation in the shelf-edge to upper slope region of the Tarakan Basin reflects the interaction between

variations in sediment accumulation rates, the progradation of deltaic sedimentary wedges, mobile shale flows

and the growth and linkage of extensional faults. Evidence of Neogene deformation in the Tarakan Basin includes

growth normal faults, shale rollers and anticlines, mud pipes and volcanoes. Deformation was controlled by

mobile shale flow across varying dips in the base of the mobile shale surface, gravitational loading and gliding.

Growth faults formed through tip propagation and segment linkage, as well as late-stage tip retreat and

reactivation. The dipping of the base of the mobile shale controls the position, timing and evolution of the growth

faults and their associated depocentres (Erdi et al. 2023). The Barito, Kutai and Tarakan basins shared a similar

tectonic history during the Tertiary, characterized by an extensional regime in the Paleogene and a

compressional regime in Neogene and Pleistocene time. However, their tectonic origins and styles are dissimilar.

Several of the Borneo deltas (Tarakan, Baram, West Luconia) exhibit large coupled extensional-compressional

deformation systems (Gorsel, 2018). The Kutai Basin formed during the Early Tertiary period, filling up with

clastic sediments from west to east (Permana et al. 2018). The Geological Map of North Borneo (Figure 1) shows

that the majority of the region is made up of alluvium deposits, particularly in Nunukan, Tana Tidung, and parts

of Tarakan City. Other areas of Tarakan City include the Sejau Formation, which contains sedimentary, clastic,

and flish rock formations (Indonesia Geospasial, 2020).

The eastern half of Borneo Island has complicated tectonic conditions, making it the most earthquake-

prone area on the island. The existence of many descending fault geological formations, as well as several

horizontal fault structures, contributes to the zone's earthquake vulnerability. Three horizontal faults run across

the Nunukan-Tarakan zone and its environs. To the south are two southwest-southeast trending faults, the

Mangkalihat Fault Zone and the Maratua Fault Zone. The Mangkalihat Fault Zone is a continuation of the Palu

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



82

Koro Fault, which runs near Tanjung Redep. The occurrence of the Maratua Fault Zone is significant because

its terminus is located in the ocean near Tanjung Selor town. Meanwhile, to the north of Tarakan Island, the

Sempurna Fault Zone extends from the Sulawesi Sea to Sabah, Malaysia, crossing the area around Sebatik Island.

Borneo Island also contains the Tarakan and Meratus faults. The Tarakan, Mangkalihat, and Meratus faults are

more than 100 kilometers long and have the potential to create earthquakes of magnitude 7. The Tarakan

horizontal fault may be seen in the northern portion of the island (Figure 2), which extends from the mainland

to the offshore. The Mangkalihat fault, a horizontal fault, is located on the east coast of Borneo Island. In the

southern half of Borneo Island, there is a stepping fault zone known as the Meratus Fault, which runs from

north-east to south-west (National Center for Earthquake Studies, 2017). However, it remains unclear which

fault structure caused the earthquake that struck the majority of East Borneo on December 21, 2015.

































Source: Modified from Google Earth, accesed, 2023

Source: (Indonesia Geospasial, 2020)

Figure 1. North Borneo's Geological Structure

Tarakan, North Borneo, has a very short history of significant earthquakes. Tarakan City has seen four

significant and devastating earthquakes. The Tarakan earthquake on April 19, 1923, had an estimated magnitude

of 7.0. The earthquake reached a magnitude of VII–VIII MMI, inflicting damage to several homes and ground

cracks. Second, on February 14, 1925, the Tarakan earthquake caused very powerful shaking with an intensity

scale of VI–VII MMI, causing numerous buildings to be damaged. The third was the Tarakan earthquake on

February 28, 1936, which had a magnitude of 6.5 and damaged a number of structures; (North Borneo Regional

Disaster Management Agency, 1956) the fourth was the Tarakan earthquake on December 21, 2015. According

to the focal mechanism analysis from the Global CMT database (Figure 3), the Tarakan earthquake had a normal-

oblique fault source mechanism. Focal mechanisms of earthquakes are essential for identifying fault planes and

characteristics of faults (Purba et al. 2025). These characteristics are determined by analysing the strike, dip and

Information:

KTib : Long Bawan Formation

(fish, coastal, lagoon,
clastic, sedimentary
structure)

KTme :Mentarang Formation
(sedimentary structure,
clastic, fish, neritic,
continental slope)

Mzb :Bengara Formation
(sedimentary structures,
clastics, fish, deep sea)

Qa : Alluvium deposits
(sedimentary structures,
clastics, alluvium)

Qpi :Quarter Intrusions
(intermediate intrusive
rocks, breakthrough
igneous rock bodies)

TQps : Sajau Formation (sedimentary structures, clastics, terrestrial fish, fluvial, delta)
Tes1 : Sedimentary, clastic, littoral sandstone.
Tomi : Breakthrough rock (extrusive rock, intermediate, lava, volcanic)
Tomj : Karamuan Formation (limestone sediments, reefs)
Tomj1 : Barley volcanic rocks (intermediate extrusive rocks, volcanic polymics)
Tps : Sinjin Formation (volcanic pyroclastic intermediate extrusive rock)

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



83

slip parameters of an earthquake, which helps to identify its source and cause. The history of Tarakan

earthquakes of such magnitude suggests that the region contains active tectonic formations.


Source: (National Center for Earthquake Studies, 2017).

Figure 2. Fault Structure in Borneo



Source: BMKG Data Catalog and Global Centroid-Moment Tensor Catalog Web Search

Figure 3. Spatial Distribution of the North Borneo Earthquake Epicenters Period 1980 – 2021 and Focal

Mechanism of the Tarakan Earthquake

2.3. SAR Image Data

SAR is a microwave-based imager that can penetrate clouds. Active SAR sensors send pulses and listen

for echoes. These echoes are captured in terms of phase and amplitude. The phase is utilized to calculate the

distance between the sensor and the target, while the amplitude provides information about the roughness and

dielectric constant of the target. Several factors influence the interferogram, including earth curvature,

topographic effects, atmospheric delay, surface motion, and noise (Castaneda et al. 2011). Sentinel-1 SAR photos

can identify changes in the earth's surface on a centimeter scale with adequate processing. In addition, it can be

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



84

used to assess volcanic deformation, subsidence, landslides, and earthquakes. SAR data is a digital record of

waves (energy) emitted by a radar sensor from a satellite to the Earth's surface and reflected back

(backscattering) to the satellite's receiving sensor.

The Sentinel-1 satellite's SAR sensor transmits a C-band signal with a wavelength of 5.6 cm. The

wavelength of the signal influences its penetration ability; hence, it is critical to understand the wavelength of

the sensor when working with SAR datasets. C-band SAR signals penetrate further into the canopy or surface

(NASA’s Earth Science Data System) than X-band signals, but not as deeply as L-band SAR signals, which have

a wavelength of approximately 25 cm and are better able to penetrate the canopy and return signals from the

forest floor. Different wavelengths are also sensitive to various degrees of deformation. To detect very minor

changes in a relatively short period of time, signals with shorter wavelengths (such as the X-band) are necessary.

Signals of shorter wavelengths, on the other hand, are more prone to decorrelation caused by minor changes in

surface conditions, such as vegetation development. Longer wavelengths (such as the L-band) may be required

for slower processes that detect motion over longer time periods. The C-band's central position can detect small

changes in a short period of time, but it is not as sensitive to small changes as the X-band or as capable of

monitoring surface dynamics under the canopy as the L-band.

To detect surface deformation induced by an earthquake, at least two SAR photos of the same object taken

at different times are required: after and before the earthquake. The SAR picture at time t before the earthquake

is referred to as the master, whereas time t1 after the earthquake is referred to as the slave. The phase value is

acquired from both the first and second pass images (Figure 4). If the first and second trajectory images have a

phase difference, the interferogram will show displacement fringes. The interferogram has two basic fringes:

displacement fringes induced by shifting topographic surfaces and topographic fringes caused by topographic

forms (Campbell et. al 2011).


Source: Analysis, 2025

Figure 4. Two SAR Imaging Trajectories Obtained at Time t (Before the Earthquake) and t1 (After the

Earthquake) will Provide Ground Surface Movement with a Phase Shift of the SAR Signal Caused by the

Earthquake).



Sentinel-1 satellite imagery in single-look complex (SLC) format, also known as 2017 Copernicus

Sentinel data (ASF HyP3 Sentinel-1 Burst InSAR Product Guide), consists of two satellites, Sentinel-1A and

Sentinel-1B, each carrying a C- band Synthetic Aperture Radar (SAR) instrument for round-the-clock global

photography, eventhrough cloud cover. Both satellites orbit in tandem, 180° apart. Each satellite may repeat

every 12 days, and Sentinel-1 can repeat every 6 days thanks to the constellation of two satellites (Azhari et al.

2020; Braun et al., 2020 Téllez-Quiñones et al. 2020) Sentinel-1 has four observation modes, the main one on

land being the Interferometric Wide Swath (IW) mode, which has a spatial resolution of around 5 m x 20 m

(Islam et al. 2017).

Surface deformation induced by an earthquake can be detected if there is a phase difference between the

master (the first picture acquired) and slave (the second image acquired), as seen in the interferogram created by

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



85

multiplying the amplitude by the phase difference of the signals (Hogenson et al., 2020). In this study, two

Sentinel-1 SAR pictures were utilized to assess surface deformation induced by the Tarakan earthquake on

December 21, 2015. The master data was recorded on December 18, 2015, three days before the earthquake, and

the slave data was recorded on January 11, 2016 (21 days later).

2.4  DInSAR Method

Differential interferometric synthetic aperture radar (DInSAR), as an extension of InSAR, has become a

mature method for monitoring deformations in mining areas (Manconi, 2021; Jiang et al. 2023; Govil  et al.

2023). DInSAR techniques can be used to monitor topographic change, surface deformation or terrain

displacement induced by different phenomena, like earthquakes or seismic activity, magma accumulation due to

volcanic lava flow, and particularly, glacier or ice-flow dynamic (Téllez-Quiñones et al. 2025) using two SAR

images. The basic purpose of DInSAR is to extract the full phase caused exclusively by deformation while

deleting or minimizing other contributing components. If a topographic surface module serves as a reference or

if three or more radar images are employed, differential InSAR can be used to determine the changes. The

DInSAR approach relies on DEM (Digital Elevation Model) data to execute differential 2-pass interferometry

operations. The DEM used is GLO-30 (Fahrland et al. 2020), with an initial pixel spacing of 1 arcsecond (about

30 meters). The Copernicus DEM Glo-30 is a global digital surface model (DSM) built on the WorldDEM.

WorldDEM is based on radar satellite data gathered by the TanDEM-X mission, which has been modified to

flatten water bodies, provide steady river flows, and change beaches, coasts, and distinguishing features. The

phase information contained in the interferograms of the two SAR observations taken at different periods

comprises topography, orbital drift, surface deformation, atmospheric influences, and thermal noise (Castaneda

et al. 2011). This interferogram will show whether there is land subsidence or rising in a specific area. Phase

wrapping is the result of calculating the height difference that depends on the phase difference between the

interferogram intervals (-π, π).

The phase change of the signal (∆φ) (Equation 1) is affected by the wavelength (λ), displacement (δR),

and phase change due to the difference in atmospheric conditions (Castaneda et al. 2011) during acquisition by

the two radars (α). The phase difference value can be formulated by the following equation (Equation 2):

∆𝜑 = 4𝜋
𝛿𝑅

𝜆
+  𝛼………………….………….……………….……..(Equation. 1)

∆𝜑 = ∆𝜑𝑓𝑙𝑎𝑡 + ∆𝜑𝑒𝑙𝑒𝑣𝑎𝑠𝑖 + ∆𝜑𝑑𝑒𝑓𝑜𝑟𝑚𝑎𝑠𝑖 + ∆𝜑𝑎𝑡𝑚𝑜𝑠𝑓𝑒𝑟 + ∆𝜑𝑛𝑜𝑖𝑠𝑒 …..….(Equation. 2)

where ∆𝜑𝑓𝑙𝑎𝑡 is the phase due to topographic influences. Using the above equation, the ∆𝜑𝑓𝑙𝑎𝑡 (Equation 3) was
computed using:

∆𝜑𝑓𝑙𝑎𝑡 = −
4𝜋

𝜆


𝐵𝑛

𝑅𝑡𝑎𝑛𝑡𝑎𝑛 𝜃
 …………….……...………............….…….(Equation. 3)

where ∆𝜑𝑒𝑙𝑒𝑣𝑎𝑠𝑖  is the phase influenced by height. Using the above equation, the ∆𝜑𝑓𝑙𝑎𝑡 9 (Equation 4) was
computed using:

∆𝜑𝑒𝑙𝑒𝑣𝑎𝑠𝑖 = −
∆𝑞

𝑠𝑖𝑛𝑠𝑖𝑛 𝜃
 .

𝐵𝑛

𝑅
 .

4𝜋

𝜆
 ………………………..….....……….(Equation. 4)

where ∆𝜑𝑎𝑡𝑚𝑜𝑠𝑓𝑒𝑟  is the phase due to atmospheric influences. Using the above equation, the ∆𝜑𝑓𝑙𝑎𝑡 (Equation 5)
was computed using:

∆𝜑𝑎𝑡𝑚𝑜𝑠𝑓𝑒𝑟 =
4𝜋

𝜆
 𝑑 ………………………………………….......……(Equation. 5)

with (Bn) is the baseline perpendicular to the slope (perpendicular baseline) (m), (R) is the radar distance to target

(m), and (𝜃) is the angle of incidence (degrees).
This study used SNAP software for Sentinel-1 SAR image data processing and visualization, Google Earth

software for virtually visualizing research data on the earth's surface, and ArcGIS software version 10.8 for

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



86

raster data operations and data representation. The majority of Sentinel-1 image data is processed using the

SNAP program (ESA, 2021). Furthermore, data is visualized and represented using Google Earth and ArcGIS

10.8 software. The picture data processing yielded a surface deformation map (LOS displacement) from the

December 21, 2015 Tarakan earthquake.

3. Result and Discussion

3.1. Interferogram Phase

The phase interferogram is able to show areas that experienced surface resolution due to the Poso

earthquake on May 29, 2017 (Puspita et al. 2024). Processing the SAR image observation data yields color-

differentiated interferograms displaying the phase shifts of radar waves before and after the earthquake (Figure

5). The colorful contours show the interference fringes between the two datasets. The distance between each

interference fringe denotes ground motion. The phase difference in the interferogram is represented by blue-to-

pink pixels in the positive phase and blue-to-yellow pixels in the negative phase. The denser the interferogram

fringes, the higher the strain on the ground during the earthquake. The Tarakan earthquake's interferogram is

centered on the main earthquake and extends north-northeast, southeast-southwest, and southwest-northwest.

The contrast of the interferogram color repetition (fringe) is not clearly evident, which could be due to air noise,

topography influences, or the region's dense vegetation. Although the margins are not easily apparent, the

distorted portions can still be distinguished.


 Source: Analysis, 2025

Figure 5. Tarakan Earthquake Interferogram, December 21, 2015

3.2. Coherence Value Map

Coherence value ranges from 0 to 1, with higher values indicating better interferogram quality. The

interferometry procedure is considered good and accurate if the image's coherence value ranges between 0.5 and

1.0. If the value is less than 0.5, the image produced from the interferometry process still contains useful

information, (Kurniawan et al. 2016) but the image with the coherence value also exhibits an increase in noise

level proportionate to the smaller coherence value. Areas with high coherence will have clear color contours,

whereas freckles areas show very low coherence and noise. Typically, a surface that remains constant throughout

the difference time picture acquisition produces a very high coherence (Jaya et al. 2021). An interferogram's

coherence is affected by several factors, including the angle and orientation of the topographic slope (steep slopes

lead to low coherence), the nature of the land, the time spacing of the images (longer time intervals lead to lower

coherence), and the baseline.

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



87


(a) (b)

Source: Analysis, 2025

Figure 6. (a) SAR Coherence Distribution Map (b) DEM (Digital Elevation Model) Map of North Borneo

Figure 6(a) depicts the range of coherence values in the North Borneo region, namely the areas surrounding

the Tarakan earthquake, with coherence values ranging from 0.4 to 0.9. Topographic characteristics and forest

density influence both high (white) and low (dark gray) coherence values in the North Borneo region (Figure

6(b)). Due to the region's flat topography, white dominates the coherence map in places near the epicenter. Some

locations with low coherence values (less than 0.4) are generated by sentinel imaging that employs a C-band

with a wavelength of 5.4 cm; therefore, the radar waves are insufficient to penetrate the vegetation canopy,

resulting in poor interferogram accuracy. Areas with coherence greater than 0.8 are situated northeast,

southwest, north, south, west, and southeast of the main earthquake, as shown by white pixels. These findings

indicate that these places are largely flat with no substantial topographical changes, resulting in numerous

reflections of radar signal interference. If deformation happens, areas with high coherence values will produce

more interferograms, with fringe lines that are more regular than those with low coherence values.

3.3. Deformation Phase (Wrapped and Unwrapped Phase)

The resulting deformation value remains a deformation phase (wrapped phase) with both negative and

positive phase values. Figure 7(a) depicts the deformation phase throughout the co-seismic period of the main

Tarakan earthquake, with an updated magnitude of M 6.1 (yellow star). Negative phase values indicate

subsidence-related deformation, which is illustrated in red. Positive phase values indicate areas of uplift, as

illustrated in blue (Cahyaningrum, 2024). Areas that are white in color, as well as phase points, are often very

stable and do not undergo modifications or deformation. The deformed areas are all located some distance from

the main earthquake.

To measure the amount of deformation in a metric, a computation must be performed using the

displacement of the earth's surface formula along the Line of Sight (LOS) sensor, as shown in (Equation 1). After

unwrapping the interferogram, as shown in Figure 7(b), the area deformation pattern can be determined even if

it is still in phase units. Line of Sight (LOS) analysis indicates the satellite's flying direction. If the value is

positive, it means that the axis is stretched towards the satellite, indicating land subsidence. If the result is

negative, it indicates that the axis is shorter towards the satellite, implying an increase in land level (uplift)

(Cahyaningrum, 2024). Based on this image, the largest land surface rise (uplift) deformation value is 0.117618

meters, which is highlighted in red around the main earthquake. Areas undergoing ground subsidence

deformation are depicted in blue, with a maximum deformation value of 0.0649612 meters, which is also near the

main earthquake. The deformation was directly tied to aftershock activity following the primary earthquake.

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



88


(a) (b)

Source: Analysis, 2025

Figure 7. (a) Tarakan Earthquake Deformation Phase December 21, 2015 (b) Los Displacements (Changes in
Deformation) Related to the Tarakan Earthquake on December 21, 2015.


The Loss Displacement Map in Figure 7(b) depicts the magnitude of deformation change data in various

districts and cities in North Borneo following the Tarakan earthquake on December 21, 2015. Tarakan City,

located to the south of the main earthquake (yellow star), appears on the map as blue to yellow, suggesting that

the deformation change that happened was subsidence (lowering of the land surface), with the deformation value

nearly reaching its maximum. Tana Tidung Regency, located just southwest of the main earthquake, is primarily

colored red, suggesting that there is deformation change in the form of uplift (an increase in land level) with a

value close to its maximum. The same pattern is seen in the Tana Tidung Regency area, which is directly north

of the main earthquake, with yellow to red indicating a change in maximum uplift deformation. Nunukan

Regency, located northwest of the main earthquake, displays blue to light orange, suggesting changes in

subsidence deformation. The Bulungan Regency area, located southeast of the major earthquake (Bunyu Island),

appears to be dominated by yellow to orange colors, indicating that uplift deformation has occurred in this

location.

3.4. Cross Section Deformation

To estimate the deformation value in the areas surrounding the epicenter (Gabriel et al. 1989) of the

Tarakan earthquake on December 21, 2015, a vertical cut (cross-section) was performed in each district area to

demonstrate the influence of changes in deformation. The cross section formed generates a cross-section graph,

with the Y axis representing the value of changes in land surface (deformation) in meters and the X axis

representing the length of the cross section in the Regency area in kilometers. According to (Petersen et al.

2011), the risk of ruptures occurring off-fault is significantly lower than the risk close to the fault. However, the

data show that adjacent faults at least 10 km (km) away from the principal fault and with a meter-scale offset on

the primary fault can cause displacements of up to 35 cm (cm).

The Tarakan City area, located around 22 kilometers south of the earthquake’s epicenter (Figure 9)

exhibits subsidence deformation ranging from 0.001-0.035 meters in the northwest-southeast cross section. The

graph along the cross section depicts the subsidence deformation that dominates the Tarakan City area, namely

the area directly south-southwest of the earthquake’s epicenter.

The Tana Tidung I Regency area, located 33 kilometers southwest of the earthquake epicenter, has uplift

deformation ranging from 0.019 to 0.079 meters in the northwest-southeast cross section (Figure 10). Uplift

deformation dominates this region, with the highest value displayed by the graph occurring directly southwest

of the location of the Tarakan earthquake on December 21, 2015. Figure 11 depicts a cross-section graphic

showing the northwest-southeast cross-section in the Bulungan Regency area, which is located around 11

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



89

kilometers southeast of the earthquake epicenter. Based on graphic pictures, uplift deformation dominates this

area, with major deformations ranging from 0.008 to 0.075 meters. The highest uplift deformation value occurs

in the southeastern Bulungan region, or precisely to the southeast of the earthquake's epicenter.


Source: Analysis, 2025

Figure 8. Cross Sections were Conducted in each District Region Near the Epicenter of the Tarakan

Earthquake on December 21, 2015




 Source: Analysis, 2025

Figure 9.  Vertical Cross-section Graph of AA' at Tarakan City




 Source: Analysis, 2025

Figure 10.  Vertical Cross-section Graph of BB’ in Tana Tidung I Regency

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



90


Source: Analysis, 2025

Figure 11. Vertical Cross-section Graph of CC’ in Bulungan Regency.


Source: Analysis, 2025

Figure 12. Vertical Cross-section Graph of DD’ in Tana Tidung II Regency




Source: Analysis, 2025

Figure 13. Vertical Cross-section Graph of EE’ in Nunukan Regency


Figure 12 illustrates the cross-section graph of the northwest-southeast cross section in the Tana

Tidung II Regency area, where the Tarakan earthquake occurred. The graph shows that uplift deformation

dominates the east segment of this region. The uplift deformation value in this area ranges from 0.001 to 0.069

meters. The largest uplift deformation value is found 10 kilometers north of the earthquake’s epicenter. Nunukan

Regency's Southwest-Northeast (EE') cross section (Figure 13) shows uplift deformation in the southwest and

subsidence in the northeast. The uplift deformation range is 0.001–0.062 meters, whereas the subsidence

deformation range is 0.001–0.029 meters. Maximum uplift and subsidence deformation values occur northwest

of the earthquake’s epicenter.

The surface deformation values due to the Tarakan earthquake on December 21, 2015 provide

information on the seismic hazard in the North Borneo, especially in Tarakan City, Nunukan Regency, Bulungan

Regency, Tana Tidung I Regency (southwest of the earthquake epicentre), and Tana Tidung II Regency (north

of the earthquake epicentre). Previously thought to be an earthquake-safe region, this is no longer the case. The

epicentre of the Tarakan earthquake, which was located far from the Tarakan Fault, provides evidence of other

locally active faults. In the past year, the Indonesian Meteorology, Climatology and Geophysics Agency (BMKG)

recorded several earthquakes in the North Borneo region. On August 10, 2024, at 16:20:23 WITA, an earthquake

magnitudo M 4.6 occurred on land to the southeast of Tarakan City, precisely at 63 km southeast of Tarakan

City, with a shallow depth of 11 km. The earthquake was felt by people in Tarakan City, Tanjung Selor Regency,

Berau Regency, and Tana tidung Regency with an intensity scale of III-IV MMI (Mercally Modified Intensity).

At this intensity scale, the earthquake was felt quite strongly by many people, the windows/doors rattled, and

walls rang. The source of the fault that caused the earthquake was a locally active fault.

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



91

Subsidence and uplift deformation due to the earthquake through the DInSAR method successfully

identified the fault slip characteristics that caused the Tarakan earthquake on December 21, 2015. Figure 3 is

the focal mechanism of the Tarakan earthquake obtained from the Global CMT catalogue. The focal mechanism

parameters show the strike, dip and slip values of two fault planes, where only one fault plane is selected as the

main fault plane. Research that has been conducted on the distribution of aftershocks from the Tarakan

earthquake, shows the earthquake slip moves from the epicentre of the main earthquake to the south (Sriyanto

et al. 2016).  Based on the results of this study, the main fault plane that caused the Tarakan earthquake has a

strike value: 3o, dip: 86o, and slip: 169o. The strike, dip, and slip values represent the hanging wall of the fault to

the west, and the foot wall of the fault to the east. The slip value on the fault indicates that the fault has an

oblique fault mechanism dominated by strike-slip movement. The results of SAR image processing using the

DInSAR method, which shows the surface deformation caused by the Tarakan earthquake (Figure 8), show that

the area east of the epicentre of the earthquake (parts of the eastern part of Tana Tidung II Regency and

Bulungan Regency) experienced uplift deformation (red colour), and the area west of the epicentre (the western

part of Tana tidung II Regency, Nunukan Regency, and Tarakan City) experienced subsidence deformation (blue

colour). There is a correspondence between the source of the Terakan earthquake and the surface deformation

caused by the Tarakan earthquake. The characteristics of the fault that caused the Tarakan earthquake are

oblique-normal faults dominated by strike-slip fault movements and normal (downward) fault blocks located to

the west. The downward movement of the main fault plane to the west of the epicentre of the Tarakan earthquake

corresponds to the record of the greatest level of shaking and damage caused by the earthquake, namely Tarakan

City and Nunukan Regency on the IV-V MMI shaking level scale.

Subsidence and uplift deformation will certainly have an impact on the damage to buildings and other

infrastructure. Earthquake preparedness strategies need to be known by the community and local government

in areas prone to subsidence and uplift. Moreover, the geological structure in the Borneo region can exacerbate

the value of subsidence and uplift. The geological structure of North Borneo, which is dominated by alluvium

deposits and sedimentary rocks, contributed to the land surface deformation that occurred in various regions

near the epicenter of the Tarakan earthquake on December 21, 2015. Alluvium deposits and sedimentary rocks

are very soft structures, causing seismic waves to flow more slowly, resulting in larger earthquake shocks.

Several measures can be taken by the community and local government to reduce the risk of disasters caused by

earthquakes, including ensuring that buildings where people live or work have structures that are resistant to

earthquake shocks, and are not located close to highlands such as hills, because changes in earthquake

deformation can cause landslides.

4. Conclusion

The interferogram produced by the Tarakan earthquake on December 21, 2015, focuses on the primary

earthquake in the North-Northeast, Southeast-Southwest, and Southwest-Northwest directions. The Tarakan

earthquake caused the highest land rise (uplift) deformation value of 0.117618 meters, as well as the highest land

subsidence deformation value of 0.0649612 meters. Both of these deformations happen around the main

earthquake. Northwest-southeast cross sections were taken in Tarakan City, Tana Tidung I, Bulungan, and

Tana Tidung II districts. A cross-section graph showing a northwest-southeast cross section in the Tana Tidung

I area, 33 kilometers southwest of the earthquake epicenter, shows considerable uplift deformation of 0.019 to

0.079 meters. Significant uplift deformation in the Bulungan Regency area, which is approximately 11 kilometers

southeast of the earthquake epicenter, ranges between 0.008 and 0.075 meters. The Tana Tidung II Regency

area, which is the epicenter of the Tarakan earthquake, shows that uplift deformation dominates the southeast

half of the region. The uplift deformation value in this area ranges between 0.001 and 0.069 meters. The

maximum uplift deformation value occurs 10 kilometers north of the earthquake's epicenter.

The cross-section graph of Nunukan Regency from southwest to northeast indicates uplift deformation in

the southwest and subsidence in the northeast. The uplift deformation range is 0.001-0.062 meters, and the

subsidence deformation range is 0.001-0.029 meters. The highest uplift and subsidence deformation values occur

northwest of the earthquake's epicenter. The surface deformation values due to the Tarakan earthquake on

https://doi.org/10.14710/geoplanning.12.1.79-94


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



92

December 21, 2015 provide information on the seismic hazard in the North Borneo, and provide evidence of

other locally active faults. Uplift deformation due to the Tarakan earthquake on December 21, 2015 occurred

more to the east of the epicentre, while subsidence deformation occurred more to the west. This is consistent

with the focal mechanism of the Tarakan earthquake, which indicates oblique-normal faults, with strike-slip fault

movements dominating, and normal (downward) fault blocks located to the west. The geological structure of

North Borneo, which is dominated by alluvium deposits and sedimentary rocks, causes seismic waves to flow

more slowly, resulting in greater earthquake shaking, which can increase ground surface deformation.



5. References

 Azhari, M F, Karyanto, K., Rasimeng, S., & Mulyanto, B. S. (2020). Analysis of surface deformation using dinsar method

(differential interferometry synthetic aperture radar) in case study lombok earthquakes on august 2018. J. Geof.

Ekspl, 6, 131-144..  [Crossref]

ASF HyP3 Sentinel-1 Burst InSAR Product Guide. URL https://hyp3-docs.asf.alaska.edu/hyp3-

docs/guides/burst_insar_product_guide/

Balaguru, A., Nichols, G., & Hall, R. (2003). The origin of the'circular basins' of Sabah, Malaysia.

Badan Meteorologi Klimatologi Geofisika (BMKG) Data Catalog. URL  https://bmkg.go.id

Bedini, Bedini, E. (2020). Persistent Scatterer Interferometry of Sentinel-1 time series to detect ground subsidence in the

city of Recife, Brazil. Journal of Hyperspectral Remote Sensing, 10(1), 1–9. https://doi.org/10.29150/jhrs.v10.1.p1-9.

[Crossref]
Braun, A., & Veci, L. (2020). Sentinel-1 toolbox TOPS interferometry tutorial. Waterloo, ON, Canada: European Space Agency.

Cahyaningrum, A. P., (2024). Analisis Deformasi Berbasis Citra SAR. Pelatihan Teknis Analisis Data Science BMKG

Calvet, A., Balbarani, S., & Gende, M. (2023). DinSAR coseismic deformation measurements of the Mw 8.3 Illapel

earthquake (Chile). Journal of Geodetic Science, 13(1), 20220154.[Crossref]

Campbell, J. B., & Wynne, R. H. (2011). Introduction to remote sensing. Guilford press.

Castaneda, C., Pourthie, N., & Souyris, J. C. (2011). Dedicated SAR interferometric analysis to detect subtle deformation in

evaporite areas around Zaragoza, NE Spain. International Journal of remote sensing, 32(7), 1861-1884.[Crossref]

Center of Earthquake and Tsunami BMKG., (2016). Buletin Gempabumi dan Tsunami Indonesia Tahun 2015. Book ISSN:

2477 – 0035.

Erdi, A., Jackson, C. A. L., & Soto, J. I. (2023). Extensional deformation of a shale‐dominated delta: Tarakan Basin, offshore

Indonesia. Basin Research, 35(3), 1071-1101.[Crossref]

Fahrland, E., Jacob, P., Schrader, H., & Kahabka, H. (2020). Copernicus digital elevation model product handbook. Airbus

Defence and Space—Intelligence: Potsdam, Germany.

Gabriel, A. K., Goldstein, R. M., & Zebker, H. A. (1989). Mapping small elevation changes over large areas: Differential

radar interferometry. Journal of Geophysical Research: Solid Earth, 94(B7), 9183-9191.[Crossref]

Global Centroid-Moment Tensor Catalog Web Search. URL https://www.globalcmt.org/CMTsearch.html.

Gorsel, J. T. V. (2018). Bibliography of the Geology of Indonesia and Surrounding Areas, IV. Borneo (incl. Makassar Straits)

7.0. www.vangorselslist.com

Gourmelen, N., Amelung, F., & Lanari, R. (2010). Interferometric synthetic aperture radar–GPS integration: Interseismic

strain accumulation across the Hunter Mountain fault in the eastern California shear zone. Journal of Geophysical

Research: Solid Earth, 115(B9).[Crossref]

Govil, H., & Guha, S. (2023). Underground mine deformation monitoring using Synthetic Aperture Radar technique: A case

study of Rajgamar coal mine of Korba Chhattisgarh, India. Journal of Applied Geophysics, 209, 104899.. [Crossref]

Gürpinar,  A., Serva, L., Livio, F., & Rizzo, P. C. (2017). Earthquake-induced crustal deformation and consequences for fault

displacement hazard analysis of nuclear power plants. Nuclear Engineering and Design, 311, 69-85. [Crossref]

Hall, R. (2013). Contraction and extension in northern Borneo driven by subduction rollback. Journal of Asian Earth

Sciences, 76, 399-411.[Crossref]

Hall, R. (2019). The subduction initiation stage of the Wilson cycle..” [Crossref]
Hanifa, R. N., Anantasena, Y., Sadly, M., & Ito, T. (2019, June). Ground deformation identification related to 2018 lombok

earthquake series based on Sentinel-1 data. In IOP Conference Series: Earth and Environmental Science (Vol. 280, No. 1,

p. 012004). IOP Publishing. [Crossref]

https://doi.org/10.14710/geoplanning.12.1.79-94
https://doi.org/10.23960/jge.v6i2.68
https://hyp3-docs.asf.alaska.edu/hyp3-docs/guides/burst_insar_product_guide/
https://hyp3-docs.asf.alaska.edu/hyp3-docs/guides/burst_insar_product_guide/
https://bmkg.go.id/
https://doi.org/10.29150/jhrs.v10.1.p1-9
https://doi.org/10.1515/jogs-2022-0154
https://doi.org/10.1080/01431161003631584
https://doi.org/10.1111/bre.12747
https://doi.org/10.1029/JB094iB07p09183
https://www.globalcmt.org/CMTsearch.html
http://www.vangorselslist.com/
https://doi.org/10.1029/2009JB007064
https://doi.org/10.1016/j.jappgeo.2022.104899
https://doi.org/10.1016/j.nucengdes.2016.11.007
https://doi.org/10.1016/j.jseaes.2013.04.010
https://doi.org/10.1144/SP470.3
https://doi.org/10.1088/1755-1315/280/1/012004


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



93

Hendardi, R. P., Hidajat, W. K., Setyawan, R., Kurniasih, A., Qadaryati, N., Khorniawan, W. B., ... & Ringga, A. G. (2024).

Evaluation of Reservoir Characteristics of Wells X, Y, Z in the Pliocene Interval of the Tarakan Sub-Basin, Tarakan

Basin, North Kalimantan. Journal of Applied Geology, 9(2), 126-138.. [Crossref]

Hogenson, K., Arko, S. A., Buechler, B., Hogenson, R., Herrmann, J., & Geiger, A. (2016, December). Hybrid Pluggable

Processing Pipeline (HyP3): A cloud-based infrastructure for generic processing of SAR data. In Agu fall meeting

abstracts (Vol. 2016, pp. IN21B-1740).[Crossref]

Indonesia Geospasial: Sistem Informasi Geografi dan Penginderaan Jauh., (2020). Shapefile (SHP) Geologi Provinsi Borneo

Utara. URL https://www.indonesia-geospasial.com/2020/03/download-data-shapefile-shp-geologi-se.html.

Islam, L. J. F., Prasetyo, Y., & Sudarsono, B. (2017). Analisis penurunan muka tanah (Land subsidence) kota semarang

menggunakan citra sentinel-1 berdasarkan metode dinsar pada perangkat lunak SNAP. Jurnal Geodesi Undip, 6(2), 29-

36.[Crossref]

Jaya, L. M. G., Simatupang, M., Kadir, A., & Saleh, F. (2021). Using DInSAR to map ground deformation on road

infrastructure (case study: North Buton, Southeast Sulawesi). In IOP Conference Series: Earth and Environmental

Science (Vol. 871, No. 1, p. 012019). IOP Publishing.[Crossref]

Jiang, X., Min, X., Ye, T., Li, X., & Hu, X. (2023). Monitoring the subsidence at different periods in high underground water

level coal mine areas using differential interferometric synthetic aperture radar (D-InSAR). Geocarto

International, 38(1), 2215730.. [Crossref]

Kurniawan, R., & Anjasmara, I. M. (2016). Pemanfaatan Metode Differential Intermerometry Synthetic Aperture Radar

(DInSAR) untuk Pemantauan Deformasi Akibat Aktivitas Eksploitasi Panasbumi. Jurnal Teknik ITS, 5(2), B331-

B336.

Lu, C. H., Huang, S. Y., Hsu, Y. C., Yen, I. C., Tung, H., & Kuo, Y. T. (2025). Fast report: the 2025 M6. 4 Dapu earthquake:

preliminary field observation and surface deformation analysis. Terrestrial, Atmospheric and Oceanic Sciences, 36(1),

14.[Crossref]

Manconi, A. (2021). How phase aliasing limits systematic space-borne DInSAR monitoring and failure forecast of alpine

landslides. Engineering Geology, 287, 106094.[Crossref]

Nasa’s Earth Science Data System (ESDS). https://www.earthdata.nasa.gov/.

North Borneo Regional Disaster Management Agency. URL https://kaltim.tribunnews.com

Panuntun, H., Miyazaki, S. I., Fukuda, Y., & Orihara, Y. (2018). Probing the Poisson's ratio of poroelastic rebound following

the 2011 M w 9.0 Tohoku earthquake. Geophysical Journal International, 215(3), 2206-2221.[Crossref]

Permana, A. K., Sendjaja, Y. A., Panggabean, H., & Fauzely, L. (2018). Depositional Environment and Source Rocks

Potential of the Miocene Organic Rich Sediments, Balikpapan Formation, East Kutai Sub Basin, Kalimantan. Jurnal

Geologi dan Sumberdaya Mineral, 19(3), 171-186.[Crossref]

Petersen, M. D., Dawson, T. E., Chen, R., Cao, T., Wills, C. J., Schwartz, D. P., & Frankel, A. D. (2011). Fault displacement

hazard for strike-slip faults. Bulletin of the Seismological Society of America, 101(2), 805-825.[Crossref]

Purba, J., Priadi, R., Amelia, R., Dwilyantari, A. A. I., Jaya, L. M. G., Ode Restele, L., & Gana Putra, I. (2024). Surface

deformation and its implications for land degradation after the 2021 Flores earthquake (M7. 4) using differential

interferometry synthetic aperture radar. Journal of Degraded & Mining Lands Management, 12(1).[Crossref]

Purba, S. M., Alyssa, Y. F., Nadia, M., Asra, N., & Muksin, U. (2025, April). The Influence of Seismometer Coverage on the

Earthquake Focal Mechanism Solution (Case Study: Toba Swarm Earthquake). In IOP Conference Series: Earth and

Environmental Science (Vol. 1479, No. 1, p. 012014). IOP Publishing.[Crossref]

Puspita, A., Pertiwi, I. I., & Sinki, K. P. (2024, July). Surface deformation analysis due to the Poso earthquake on May 29,

2017 using the DInSAR method. In IOP Conference Series: Earth and Environmental Science (Vol. 1373, No. 1, p. 012049).

IOP Publishing.[Crossref]

Sari, A. R., Handayani, H. H., & Agustan, A. (2014). Penerapan metode Dinsar untuk analisa deformasi akibat gempa bumi

dengan validasi data GPS Sugar (Studi kasus: Kepulauan Mentawai, Sumatera Barat). Geoid, 10(1), 26-31.

https://journal.its.ac.id/index.php/geoid/article/view/1431

Souza, W. D. O., de Moura Reis, L. G., da Silva Pereira Cabral, J. J., Ruiz-Armenteros, A. M., Quental Coutinho, R., da

Penha Pacheco, A., & Ramos Aragão Junior, W. (2024). Analysis of Urbanization-Induced Land Subsidence in the

City of Recife (Brazil) Using Persistent Scatterer SAR Interferometry. Remote Sensing, 16(14), 2592.

Sriyanto, S. P. D., & Ifantyana, I. (2016). Identifikasi Patahan Mikro Penyebab Gempa Bumi Tarakan 21 Desember 2015.

In Prosiding Seminar Nasional Fisika, V, SNF2016-EPA-79-SNF2016-EPA-84.[Crossref]

https://doi.org/10.14710/geoplanning.12.1.79-94
https://doi.org/10.22146/jag.86053
https://doi.org/10.5281/zenodo.15498989
https://www.indonesia-geospasial.com/2020/03/download-data-shapefile-shp-geologi-se.html
https://doi.org/10.14710/jgundip.2017.16253
https://doi.org/10.1088/1755-1315/871/1/012019
https://doi.org/10.1080/10106049.2023.2215730
https://doi.org/10.1007/s44195-025-00099-5
https://doi.org/10.1016/j.enggeo.2021.106094
https://www.earthdata.nasa.gov/
https://kaltim.tribunnews.com/
https://doi.org/10.1093/gji/ggy403
https://doi.org/10.33332/jgsm.geologi.v19i3.407
https://doi.org/10.1785/0120100035
https://doi.org/10.15243/jdmlm.2024.121.6819
https://doi.org/10.1088/1755-1315/1479/1/012014
https://doi.org/10.1088/1755-1315/1373/1/012049
https://journal.its.ac.id/index.php/geoid/article/view/1431
https://doi.org/10.21009/0305020415


Pertiwi et al. / Geoplanning: Journal of Geomatics and Planning, Vol. 12, No. 1, 2025, 79 - 94
DOI: 10.14710/geoplanning.12.1.79-94



94

Téllez-Quiñones,  A., Salazar-Garibay, A., Valdiviezo-Navarro, J. C., Hernandez-Lopez, F. J., & Silván-Cárdenas, J. L. (2020).

DInSAR method applied to dual-pair interferograms with Sentinel-1 data: a study case on inconsistent unwrapping

outputs. International Journal of Remote Sensing, 41(12), 4664-4683.[Crossref]

Téllez-Quiñones, A., Salazar-Garibay, A., Cruz-Sánchez, B. I., Carlos-Martínez, H., Valdiviezo-Navarro, J. C., & Soto, V.

(2025). Three-Dimensional Ice-Flow Recovery from Ascending–Descending DInSAR Pairs and Surface-Parallel

Flow Hypothesis: A Simplified Implementation in SNAP Software. Remote Sensing, 17(7), 1168. [Crossref]

Watkinson, I. M., & Hall, R. (2017). Fault systems of the eastern Indonesian triple junction: evaluation of Quaternary

activity and implications for seismic hazards.[Crossref]

Witts, D., Hall, R., Nichols, G., & Morley, R. (2012). A new depositional and provenance model for the Tanjung Formation,

Barito Basin, SE Kalimantan, Indonesia. Journal of Asian Earth Sciences, 56, 77-104.[Crossref]







https://doi.org/10.14710/geoplanning.12.1.79-94
https://doi.org/10.1080/01431161.2020.1727056
https://doi.org/10.3390/rs17071168
https://doi.org/10.1144/sp441.8
https://doi.org/10.1016/j.jseaes.2012.04.022
