Intradermal Injection of Bleomycin
Shows Preliminary Evidence of

Dermal Fibrosis in a Mouse Model
!arun Potluri, Cameron S. D'Orio, BS, Lauren T. Mo"att,

PhD, Je"rey W. Shupp, MD, Bonnie C. Carney, PhD

Volume Four
Edition One
Spring 2024


GEORGETOWN SCIENTIFIC
RESEARCH JOURNAL

20



����
�������������	������������������
�
�

����

���
�������������������������	�������������
������
�����
�������
��������������
���������
���
�
TThhaarruunn  PPoottlluurrii11,,22,,  CCaammeerroonn  SS..  DD’’OOrriioo,,  BBSS22,,  LLaauurreenn  TT..  MMooffffaatttt,,  PPhhDD22,,33,,  JJeeffffrreeyy  WW..  SShhuupppp,,  MMDD22,,33,,44,,55,,
BBoonnnniiee  CC..  CCaarrnneeyy,,  PPhhDD22,,33
1 Department of Human Science, School of Health, Georgetown University, Washington DC, USA
2 Firefighters’ Burn and Surgical Research Laboratory, MedStar Health Research Institute, Washington DC,
USA
3 Departments of Surgery and Biochemistry and Molecular & Cellular Biology, Georgetown University School of
Medicine, Washington DC, USA
4 Department of Plastic Surgery, Georgetown University School of Medicine, Washington DC, USA
5 Department of Surgery, The Burn Center, MedStar Washington Hospital Center, Washington DC, USA
Email: tp600@georgetown.edu
hhttttppss::////ddooii..oorrgg//1100..4488009911//ggssrr..vv33ii22..7700�
AAbbssttrraacctt
Burn wounds can result in the development of hypertrophic scar (HTS). A problematic characteristic of
HTS is dyschromia, which is often distressing to patients and has been shown to impact quality of life.
There are currently no viable, non-surgical treatment methods for dyschromia, and the mechanisms of its
etiology are not well understood. We aimed to test if the fibrotic microenvironment of the dermis plays a
contributing role in the development of epidermal dyschromia. To do this, we focused on reproducing a
previously published model of bleomycin-induced dermal fibrosis to add to the replicability of previous
findings and establish a reliable model to serve as a basis for understanding post-burn dyschromia
development. By treating C57BL/6 mice with intradermal injections of three varying doses of bleomycin
for two weeks and conducting histological and molecular analyses of collected data, we were able to assess
the adequacy of dermal fibrosis development. Collected data showed evidence of hair follicle obliteration,
dermal thickening, and other characteristics of fibrotic architecture within all three bleomycin-treated
groups, bust mostly profoundly in the high-dose group. However, qRT-PCR data did not reveal any
significant trends in differential expression of genes of interest. In future work, additional qRT-PCR
analysis, immunofluorescence visualization, and other molecular assays should be conducted to obtain
further molecular confirmation of bleomycin-induced dermal fibrosis before we can attempt to understand
the mechanistic relationship between dermal fibrosis and epidermal dyschromia.

Keywords: hypertrophic scar, dyschromia, fibrosis, bleomycin

11..  IInnttrroodduuccttiioonn
Recent advances in the management and

treatment of burn-related injuries have led to a
significant decrease in mortality rates, especially
for large total body surface area full-thickness
burns.1 With an increasing patient survival rate,
attention is now being turned to managing the

after-effects of burn injury. Burn wounds and
other cutaneous trauma can result in the
development of hypertrophic scar (HTS), among
other physiological complications such as muscle
wasting, contractures, infection, and more.2 HTS
is typically raised, thick, non-pliable,
erythematous, pruritic, and painful.3 Irregular
inflammatory processes in the dermis contribute to

21



����
�������������	������������������
�
�

�

HTS pathophysiology. HTS forms as a result of
excess collagen deposition and abnormal fibroblast
proliferation. The abnormal functioning of these
fibroblasts results in excess amounts of
extracellular matrix components that cause
elevated and stiff skin characteristic of HTS.4 The
bulk of HTS tissue is composed of the dermis layer
which is primarily made up of type 1 collagen,
fibroblasts, and endothelial cells.5 A number of
proteins, such as collagen 1 alpha 1 (COL1A1),
COL1A3, transforming growth factor beta-1
(TGFB1), and galectin-1 (LGALS1), have been
shown to be differentially overexpressed in fibrotic
skin characteristic of HTS.6 Additionally, HTS
typically has thickened dermis and epidermis layers
and a change in collagen architecture that causes
the increased skin stiffness.

In addition to the physical impacts of post-
burn HTS development, patients with HTS
frequently suffer from the psychosocial impacts of
altered appearance and restricted range of motion
that often results due to HTS.7 Almost all HTSs
display dyschromia, which appears as hypo- or
hyperpigmentation of the skin. More severe scars
with extreme dermal pathology (increased
thickness, hyper-vasculature, hyper-cellularity,
non-pliability, contracture) often exhibit the most
profound dyschromia. Dyschromic HTS, which
develops pervasively amongst patients with skin of
color, is often distressing to patients and has been
shown to impact quality of life metrics such as
stigmatization, sexual health, and physiological
health.8-12 While some therapies have led to
modest improvements in HTS symptoms for some
patients, HTS and its psychosocial impact
continues to be challenging to treat. Finding
viable, non-surgical treatment methods for
dyschromia could significantly improve the quality
of life for patients with HTS.

Before testing treatment methods, however,
the mechanistic processes behind dyschromia must
first be understood. There is currently a large gap
in knowledge as to how post-burn dyschromia
actually develops, which is underscored by the
paucity of literature surrounding the topic. One
hypothesis is that dyschromia develops due to
abnormalities in the paracrine signaling between

melanocytes and surrounding cell types.13 In
fibrotic skin, fibroblasts are in an altered state of
inflammation that could influence melanocyte
function, which can be quantifiably assessed by
melanin index.14 However, it is also possible that
fibroblasts do not contribute to dyschromia at all,
and that keratinocytes play a more significant role.
Understanding the cellular abnormalities that
cause dyschromia is a crucial first step in the effort
to develop treatments for dyschromic HTS. Thus,
a reliable and repeatable model for HTS must be
established by which dyschromia can be studied.

Not only does skin fibrosis develop as a result
of burn wounds (HTS), but it can also occur due
to various disease processes. A common disease
that results in skin fibrosis is systemic sclerosis.15
Patients with this disease have thickened skin that
looks similar to burn scars and often exhibits
dyschromia classified as “salt-and-pepper” skin.16
An approach that has previously been taken by
other researchers is to study non-HTS dermal
fibrosis by synthetically inducing fibrosis with a
commonly used antineoplastic drug called
bleomycin. A study conducted by B!yszczuk et al.
showed the efficacy of bleomycin-induced dermal
fibrosis in a mouse model through regular
injections of bleomycin.14

This study aims to reproduce this published
model of bleomycin-induced dermal fibrosis in an
effort to establish the utility of this model for the
study of HTS dyschromia.
22..  MMeetthhooddss

In this study, two groups of mice were tested.
Following the completion of Group 1 mice, data
was collected and analyzed before starting the next
group. Using lessons learned from the Group 1
mice, Group 2 mice had a refined experimental
procedure in an effort to produce more conclusive
results.

All animal work was approved by the MedStar
Health Research Institute’s Institutional Animal
Care and Use Committee. Facility standard
operating procedures under an animal care and use
program accredited by the Association for
Assessment and Accreditation of Laboratory
Animal Care International were strictly followed

22



����
�������������	������������������
�
�

�

for handling and care of all the animals used in this
study.
22..11  GGrroouupp  SSeelleeccttiioonn,,  AAnneesstthheessiiaa,,  aanndd
PPrreettrreeaattmmeenntt  PPrroocceedduurreess

FFiigguurree  11..  Dorsal demarcation of the injection site.
The 1cm x 1cm demarcated square is where all
injections occurred. This square was drawn 3cm
below the midline of the ears on each mouse for
standardization. A 2cm x 2cm square was
demarcated as a “buffer zone” to account for
spreading of bleomycin or saline control outside of
the 1cm x 1cm injection square.

Female C57-BL/6 mice (22-45±6.59g) were
used in Group 1 (n=3 in control, high-dose, mid-
dose, n=4 in low-dose groups). In Group 2, female
C57-BL/6 mice (19-23±1.11g) were used (n=5 in
control, n=4 in high-dose, mid-dose, low-dose
groups). Anesthesia was induced by placing the
mice into a box with 3-5% isoflurane. Once a plane
of anesthesia was established by confirming
absence of corneal and pedal reflexes, anesthesia
was continued via nose cone administration of 1-
4% isoflurane. Ophthalmic ointment was used in
cases of prolonged anesthesia. Thermoregulation
was achieved with a warming blanket during
anesthesia procedures. During the pre-injury
timepoint, the dorsum of the mouse was shaved
using standard veterinary clippers and depilated
using a commercial agent for 90 seconds with
massage of the agent into the skin with a cotton
swab (Nair, Church & Dwight Co., Ewing, NJ).
In Group 1 mice, a 1 cm x 1 cm square was
demarcated 3 cm below the midline of the ears
using a surgical marker (Figure 1). In Group 2
mice, a 2 cm x 2 cm square was demarcated around

the 1 cm x 1 cm square (Figure 1). In addition to
baseline weights, non-invasive skin probe
measurements (elasticity, trans-epidermal water
loss, erythema, melanin) (Delfin Technologies,
Kuopio, Finland) were also taken within the
demarcated area. Mice were placed on their sides
with their hind legs facing the same direction
during probe measurements to reduce the pressure
of the probe on the spine.

22..22  BBlleeoommyycciinn  IInnjjeeccttiioonn  aanndd  MMoonniittoorriinngg
 Lyophilized bleomycin sulphate (Sigma-
Aldrich, St. Louis, MO) was dissolved in normal
saline. 100 µl of bleomycin or saline control was
injected on days 1, 2, 4, 5, 8, 9, 11, and 12 for
Group 1, and days 1, 2, 5, 6, 8, 9, 12, and 13 for
Group 2. Injections were administered
intradermally into the 1 cm x 1 cm square at
different positions on different days (Figure 2). On
day 1, injections were performed at position 1, on
day 2 at position 2, continuing in this fashion
throughout the time course. After position 5,
injections were further continued cyclically starting
again at position 1. This injection pattern, which
was based off of previously published literature,
ensured that the bleomycin was distributed equally
across the entire demarcated treatment zone.14

Three different dosages of bleomycin were
tested in each group. In Group 1 mice, low-dose
(0.5 U/mL), mid-dose (1.0 U/mL), and high-dose
(5 U/mL) bleomycin was used. In Group 2, the
high-dose concentration was adjusted to 2.5
U/mL. After injection, mice were removed from
anesthesia and monitored until ambulatory. Non-
invasive skin probe measurements of the treated
zone and normal skin were taken periodically
throughout the study and were collected in
triplicate for each probe. Animal checks were
conducted twice a day at minimum and mice
weights were obtained each day. Mice with weight
loss of 5% compared to their initial weight or with
obvious signs of distress were given a 1 mL
intraperitoneal injection of lactated ringers daily in
addition to DietGel dietary supplements
(ClearH2O, Westbrook, ME). In Group 2 mice,
all mice were given DietGels on day 1

23



����
�������������	������������������
�
�

�

prophylactically. The mice were never subjected to
more than two days of back-to-back isoflurane
anesthesia to prevent a negative reaction to
cumulative anesthesia.
22..33  TTeerrmmiinnaall  TTiimmeeppooiinntt
 On day 15, all mice were placed under
anesthesia and euthanized via exsanguination and
cervical dislocation. Terminal weights and non-
invasive probe measurements were obtained prior
to euthanasia. Treated zone skin and normal skin
were collected and preserved in Allprotect Tissue
Reagent (Qiagen, Germantown, MD) and 10%
neutral buffered formalin (NBF). Blood was
collected and placed in RNAprotect tubes
(Qiagen, Germantown, MD) and K2EDTA
tubes, and was spun down to isolate plasma. Lungs
were dissected and preserved in Allprotect Tissue
Reagent (Qiagen, Germantown, MD) and NBF.






FFiigguurree  22..  Injection pattern for intradermal
injection of bleomycin or saline control. Injections
were administered from positions 1 to 5
throughout the time course. After position 5,
injections were further continued cyclically starting
again at position 1.
2.4 HHiissttoollooggiiccaall  AAnnaallyyssiiss
 Formalin-fixed skin and lung samples collected
at the terminal timepoint were paraffin embedded,
sectioned at 4 µm thickness onto slides, and
stained with hematoxylin and eosin (H&E) as
previously described.17 Tile images were taken at
10X magnification to assess dermal architecture,
dermal cellularity, and dermal and epidermal
thickness using an Axio imager M2 microscope
with motorized stage (Carl Zeiss Inc.,
Oberkochen, Germany) and an Axiocam 208 color

camera. Zen blue software was used to export
images (Carl Zeiss Inc., Oberkochen, Germany).
ImageJ software was used to quantify dermal and
epidermal thickness and 10 replicates were taken
at different positions across the biopsy for each
sample.
22..55  CCoonnffiirrmmaattoorryy  qqRRTT--PPCCRR  AAnnaallyyssiiss
 RNA from collected skin biopsies was isolated
and purified for molecular assays using an
automated protocol for the RNeasy fibrous tissue
mini kit (Qiagen, Germantown, MD) with the
Qiacube. RNA quality and quantity determined by
spectro-photometry (Nandrop2000,
ThermoFisher, Waltham, MA) and all samples
were diluted to 1 ng/uL prior to running.
Confirmatory qRT-PCR was conducted using a
one-step reverse transcription and SYBR green kit
(BioRad Laboratories Inc., Hercules, CA) to
measure differential expression of COL1A1,
COL1A3, TGFB1, and LGALS1 as previously
described.17 Glyceraldehyde 3-phosphate
dehydrogenase (GAPDH) and ribosomal protein
L13A (RPL13A) were used as housekeeping
genes. Fold changed was assessed using
!!Ct analysis.
22..66  SSttaattiissttiiccss
 For non-invasive probe measurements and
PCR data, a two-way ANOVA with multiple
comparisons was run to compare differences across
treatment groups and time points. Data was also
analyzed as fold change at various time points to
compare treatment to control at similar time
points, or as fold change over time compared to the
day of treatment initiation. For all analyses, p<0.05
was considered statistically significant. For qRT-
PCR, fold change > or < 2 was established as the
significance threshold. Outliers were excluded
using Grubb’s outlier test. GraphPad Prism 10 was
used for data visualization.
33..  RReessuullttss
33..11  BBlleeoommyycciinn  TTrreeaattmmeenntt  RReessuulltteedd  iinn  DDeeccrreeaasseedd
SSkkiinn  EEllaassttiicciittyy

The high-dose bleomycin group showed a
significant decrease in skin elasticity at the

24



����
�������������	������������������
�
�

�

terminal timepoint (day 15) compared to baseline
measurements (day 1-4), indicating decreased skin
pliability (58±22.9 vs 135.8±57.9 N/m) (Figure
3A). The low-dose group showed a similar
decrease in skin elasticity over time (50.1±17.9 vs
91.1±34.1 N/m). However, there was no
significant difference in skin elasticity over time in
the mid-dose and control groups.
33..22  MMeellaanniinn  IInnddeexx  IInnccrreeaasseedd  TThhrroouugghhoouutt  tthhee
DDuurraattiioonn  ooff  tthhee  SSttuuddyy  iinn  AAllll  GGrroouuppss
 Non-invasive probe data showed a 4-fold
increase in melanin at the terminal timepoint (day
15) compared to baseline measurements (day 1-4)
for the control group (628.7±42.4 vs 882.9±81.8)
(Figure 3B). Similar trends were present for the
low-dose group (648.4±60.6 vs 850.2±56.5) and
mid-dose group (658.2±116.5 vs 867.2±52.6). The
high-dose group did not show any significant
difference in melanin index (746.6±132 vs
806.9±108.7).











�

FFiigguurree  33..  Elasticity and melanin measurements
using non-invasive skin probes. (A) In the low-
dose and high-dose groups, there was a significant
increase in stiffness between days 1-4 and day 15
(P < 0.05). (B) Control, low-dose, and mid-dose
groups showed significant increase in melanin

index between days 1-4 and day 15. Values
presented as mean ± SEM.
33..33  HHiissttoollooggiiccaall  AAnnaallyyssiiss  SShhoowweedd  CChhaannggeess  ttoo
DDeerrmmaall  AArrcchhiitteeccttuurree

Analysis of H&E-stained biopsies of the
normal and treated zone in high-dose mice showed
areas of dermal and epidermal thickening, hair
follicle obliteration, and evidence of fibrotic
architecture (Figure 4A). Mid- and low-dose mice
showed similar dermal thickening, however
changes to epidermal thickness and hair follicle
architecture were less prominent than in the high
dose group. Control mice treated zone skin
appeared the same as normal skin, as expected.

Quantitative assessment of epidermal
thickness (Figure 4B) and dermal thickness
(Figure 4C) confirmed thickening of the epidermis
(14.1±0.19 vs 38.8±4.83 µm) and dermis
(104.7±11.1 vs 231±52.5 µm) in treated zone skin
compared to normal skin for high-dose mice,
however this difference did not reach significance
(p > 0.05). Control, low-dose, and mid-dose skin
not show any significant difference in epidermal or
dermal thickness in the treated zone skin
compared to normal skin.






FFiigguurree  44..  Effects of bleomycin treatment on
dermal and epidermal architecture in a mouse
model. (A) Biopsies of normal skin and treatment
zone skin taken at the terminal timepoint were
sectioned and H&E stained to be assessed for
dermal thickness (red arrows), epidermal thickness
(yellow arrow), hair follicle presence (blue arrow),

25



����
�������������	������������������
�
�

�

and other changes to dermal architecture.
Quantitative measurements of (B) epidermal and
(C) dermal thickness analyzed from H&E stained
images. Values presented as mean ± SEM.
33..44  PPCCRR  AAnnaallyyssiiss  DDiidd  NNoott  SShhooww  SSiiggnniiffiiccaanntt
DDiiffffeerreennttiiaall  EExxpprreessssiioonn  ooff  GGeenneess  ooff  IInntteerreesstt
 Analysis of COL1A1, COL3A1, and TGFB1
qRT-PCR data between the normal skin and
treated zone skin for each group did not show any
significant differential expression (Figure 5A-C).
Though there was an increase in expression of
LGALS1 in the treated zone skin compared to
normal skin in the low-dose, mid-dose, and high-
dose mice, none of the comparisons reached
significance (Figure 5D).










FFiigguurree  55..  COL1A1 (A), COL3A1 (B), TGFB1
(C), and LGALS1 (D) expression in normal skin
compared to treated zone skin for each group.
RNA was isolated and purified from skin biopsies
for confirmatory qRT-PCR analysis. Fold change
was assessed using !!Ct analysis. P < 0.05 is
considered statistically significant.
33..55  BBlleeoommyycciinn  TTrreeaattmmeenntt  RReessuulltteedd  iinn  AArreeaass  ooff
HHaaiirr  LLoossss  WWiitthhiinn  tthhee  TTrreeaatteedd  ZZoonnee
 Images taken at the terminal timepoint for
each mouse revealed a trend of hair loss within the
demarcated treated zone for the high-dose mice
(Figure 6). A similar pattern of hair loss was also
present in the mid- and low-dose groups, though
not as prominent and widespread. Control mice
did not show any evidence of hair loss within the
treated zone.

















FFiigguurree  66..  Representative images of the dorsal
surface of high-dose, mid-dose, low-dose, and
control mice at the terminal timepoint. Red arrows
indicate areas of hair loss within the demarcated
treated zone.
33..66  HHiigghh--DDoossee  BBlleeoommyycciinn  NNeeggaattiivveellyy  AAffffeeccttss
MMiiccee  WWeeiigghhttss
 All mice used in Groups 1 and 2 were weighed
daily throughout the duration of the study. Group
1 high-dose mice lost a large amount of weight
throughout the study duration, ending with a
percent difference of -23.6% at the terminal
timepoint compared to baseline measurements
(Figure 7A). Group 1 control mice also dropped
weight, though not as severely (-13.4%) at the
terminal timepoint). Low-and mid-dose mice
weights stayed relatively consistent. Group 2
control, low-, and mid-dose mice weights stayed
relatively consistent, however high-dose mice lost
a large amount of weight (-7.8% at the terminal
timepoint) (Figure 7B).








26



����
�������������	������������������
�
�

�

FFiigguurree  77..  Mice weights for each group throughout
the study duration. (A) Group 1 mice weights. (B)
Group 2 mice weights. Mice weights were
obtained each day. Percent difference calculations
were obtained by comparing to initial mice weights
on day 1. Mice with weight loss of 5% compared
to their initial weight or with obvious signs of
distress were given a 1 mL intraperitoneal injection
of lactated ringers daily in addition to DietGel
dietary supplements. All Group 2 mice were given
DietGels on day 1 prophylactically. Values
presented as mean ± SEM.
44..  DDiissccuussssiioonn
 This study aimed to confirm the experimental
methods of a previously proven model of
bleomycin-induced dermal fibrosis in mice within
our laboratory. The eventual goal of being able to
synthetically induce dermal fibrosis is to ascertain
if there is a causal relationship between dermal
fibrosis and epidermal dyschromia. Following
regular injections of three different bleomycin
doses and saline control into the dorsal skin of
C57-BL/6 mice, data from non-invasive skin
probes, histological analysis, and qRT-PCR
analysis were used to determine if bleomycin
injection induced dermal fibrosis.

One of the more promising markers of skin
fibrosis is known to be skin elasticity.17 Elasticity
measurements were collected by non-invasive skin
probes throughout the duration of this study.
Analysis of probe data showed a significant
decrease in skin elasticity at the terminal timepoint
compared to baseline measurements for high-dose
and low-dose groups, suggesting an increased skin
thickness characteristic of dermal fibrosis.
Interestingly, the mid-dose group did not show
any significant difference in elasticity. One
explanation for this finding is that the mid-dose
mice had an increased presence of self-mutilated
skin (caused by stress, irritation, etc.) which could
have affected elasticity measurements.   Imaging of
H&E-stained skin biopsies showed clear
epidermal and dermal thickening indicative of
fibrotic architecture in the high-dose, mid-dose,
and low-dose mice, though less prominent in the
latter two groups. Differences in treated zone
versus normal skin thickness might not have

reached significance due to improper collection of
normal skin. Normal skin was collected directly
outside of the 2cm x 2cm demarcated outer square.
As a result, some of the bleomycin could have
spread outside of the demarcated injection site and
caused changes to the skin outside of the treated
zone, potentially influencing skin thickness
measurements. Collection of normal skin further
away from the treated zone should be performed in
future studies to account for this problem. High-
dose skin biopsies showed clear obliteration of hair
follicles in the dermis caused by the bleomycin
treatment, providing further evidence supporting
the efficacy of the drug. Hair loss within the
treated zone could also be seen on the images taken
of the dorsal surface of the bleomycin-treated
groups.
 Collected qRT-PCR data did not show any
statistically significant differences in differential
expression in the treated zone skin compared to
the normal skin for genes of interest. A potential
explanation for this lack of significance is that the
bleomycin destroyed tissue architecture and
cellular function to such an extent that cells were
unable to undergo gene transcription. However, an
increase in expression of LGALS1 in the low-,
mid-, and high-dose mice was observed. Increased
presence of LGALS1 provided some molecular
evidence of fibrotic development within the
treated zone, though perhaps other genes should
be assessed for further confirmation of fibrosis.18 In
future work, immunofluorescence visualization of
�-SMA-positive myofibroblasts should be
conducted and assessed for further molecular
confirmation.19

In addition to affecting the dermal and
epidermal histoarchitecture of the mice, bleomycin
also seemed to have systemic effects on the mice as
observed by changes in their weights. Group 1
high-dose mice were injected with a 5 U/mL
concentration of bleomycin, whereas Group 2
high-dose mice were injected with a 2.5 U/mL
concentration. These dosages were arbitrarily
chosen and were not based on previously proven
models as the literature did not report specific
dosage values for study replication. This problem
was the main issue we faced when attempting to

27



����
�������������	������������������
�
�

�

replicate the previously proven model. The dosage
of bleomycin was adjusted for Group 2 due to the
significant weight loss that was observed in Group
1 mice. Group 1 high-dose mice lost more weight
overall than Group 2 high-dose mice. However, in
addition to receiving a lower dosage of bleomycin,
Group 2 mice were also prophylactically given
Dietgels at the beginning of the study in an effort
to mitigate weight loss. These two changes to the
study protocol clearly helped reduce the amount of
weight the mice lost throughout the study. In
future work, RNA from lung biopsies and blood
samples should be isolated and analyzed via qRT-
PCR to look for evidence of systemic impacts of
bleomycin.

The C57-BL/6 mice used in this study lack
melanocytes within the skin, however melanin
index significantly increased in control, low-dose,
and mid-dose mice throughout the study duration.
An explanation for this finding is that hair
regrowth influenced melanin measurements in the
mice. This would also explain why the high-dose
mice did not show a significant difference in
melanin index because the high-dose mice
experienced hair loss as a result of bleomycin,
limiting the extent to which melanin
measurements were falsely influenced. The
application of Nair during depilation seemed to
induce hair follicle neogenesis or induction of the
hair cycling pathway, which further affected
melanin measurements. Further investigation
needs to be conducted on the influence on
depilating agents on hair follicle neogenesis and
induction of cycling to better understand how to
account for this problem in future work.
Additionally, melanin content can be assessed via
Fontana Masson staining techniques instead of
non-invasive probes measurements for more
accurate results. Fontana-Masson staining allows
for visual-ization of melanin within the epidermis
of the skin.

Elasticity measurements and H&E-stained
skin biopsies showed evidence of bleomycin-
induced dermal fibrosis in all three drug treatment
groups, but most profoundly in the high-dose
group. However, additional qRT-PCR analysis,
immuno-fluorescence visualization, and other

molecular assays should be conducted to obtain
significant molecular confirmation of fibrosis.
Further evidence is needed to confirm the efficacy
of bleomycin-induced dermal fibrosis before
attempting to understand the mechanistic
relationship between dermal fibrosis and
epidermal dyschromia.
RReeffeerreenncceess
1.�Aarabi, S., Longaker, M.T., & Gurtner, G.C.

(2007). Hypertrophic scar formation following
burns and trauma: new approaches to
treatment. PLoS Med. 4(9), 1464-70.
https://doi.org/10.1371/journal.pmed.0040234

2.�Finnerty, C.C., Jeschke, M.G., Branski, L.K.,
Barret, J.P., Dziewulski, P., & Herndon, D.N.
2016. Hypertrophic scarring: the greatest
unmet challenge after burn injury. Lancet.
388(10052), 1427-36.
https://doi.org/10.1016/S0140-6736(16)31406-4

3.�Chiang, R.S., Borovikova, A.A., King, K.,
Banyard, D.A., Lalezari, S., Toranto, J.D.,
Paydar, K.Z., Wirth, G.A., Evans, G.R., &
Widgerow, A.D. (2016). Current concepts
related to hypertrophic scarring in burn injuries.
Wound Repair Regen. 24(3), 466-77.
https://doi.org/10.1111/wrr.12432

4.�Van der Veer, W.M., Bloemen, M.C., Ulrich,
M.M., Molema, G., van Zuijlen, P.P.,
Middelkoop, E., & Niessen, F.B,. (2009).
Potential cellular and molecular causes of
hypertrophic scar formation. Burns. 35(1), 15-
29.
https://doi.org/10.1016/j.burns.2008.06.020

5.�Huang, C., Murphy, G.F., Akaishi, S., &
Ogawa, R. (2013). Keloids and Hypertrophic
Scars: Update and Future Directions. Plastic
and Reconstructive Surfery. 1(4), e25.
https://doi.org/10.1097/GOX.0b013e31829c4597

6.�Limandjaja, G.C., van den Broek, L.J.,
Waaijman, T., van Veen, H.A., Everts, V.,
Monstrey, S., Scheper, R.J., Niessen, F.B., &
Gibbs, S. (2020). Increased epidermal thickness
and abnormal epidermal differentiation in
keloid scars. Dermatologic Surgery. 176(1),
116-126. https://doi.org/10.1111/bjd.14844

7.�Ni!escu, C., Calot", D.R., St"ncioiu, T.A.,
Marinescu, S.A., Florescu, I.P., & Lasc"r, I.

28



����
�������������	������������������
�
�

�

(2012). Psychological impact of burn scars on
quality of life in patients with extensive burns
who received allotransplant. Romanian Journal
of Morphology & Embryology. 53(3), 577-83.

8.�Zeitlin, R.E. (1997). Long-term psychosocial
sequelae of paediatric burns. Burns. 23(6), 467-
472.
https://doi.org/10.1016/s0305-4179(97)00045-4

9.�Ross, E., Crijns, T.J., Ring, D., & Coopwood,
B. (2021). Social factors and injury
characteristics associated with the development
of perceived injury stigma among burn
survivors. Burns. 47(3), 692-697.
https://doi.org/10.1016/j.burns.2020.07.022

10.�Stoddard, F.J. Jr., Ryan, C.M., & Schneider,
J.C. (2014). Physical and psychiatric recovery
from burns. Surgical Clinics of North America.
94(4), 863-78.
https://doi.org/10.1016/j.suc.2014.05.007

11.�Taal, L., & Faber, A.W. (1998). Posttraumatic
stress and maladjustment among adult burn
survivors 1 to 2 years postburn. Part II: the
interview data. Burns. 24(5), 399-405.
https://doi.org/10.1016/s0305-4179(98)00053-9

12.�Wisely, J.A., Hoyle, E., Tarrier, N., &
Edwards, J. (2007). Where to start? Attempting
to meet the psychological needs of burned
patients. Burns. 33(6), 736-46.
https://doi.org/10.1016/j.burns.2006.10.379

13.�Baugh, E.G., Anagu, O., & Kelly, K.M.
(2022). Laser Treatment of Hypopigmentation
in Scars: A Review. Dermatologic Surgery.
48(2), 201-206.
https://doi.org/10.1097/DSS.0000000000003330

14.�B!yszczuk, P., Kozlova, A., Guo, Z., Kania,
G., & Distler, O. (2019). Experimental Mouse
Model of Bleomycin-Induced Skin Fibrosis.
Current Protocols in Immunology. 126(1), e88.
https://doi.org/10.1002/cpim.88

15.�Jawitz, J.C., Albert, M.K., Nigra, T.P., &
Bunning, R.D. (1984). A new skin
manifestation of progressive systemic sclerosis.
Journal of the American Academy of
Dermatology. 11(2), 265.
https://doi.org/10.1016/s0190-9622(84)70163-0

16.�Sakamoto, T., Kaburaki, M., & Shimizu, T.
(2021). Salt-and-pepper skin appearance and
systemic sclerosis. QJM. 114(8), 599-600.

https://doi.org/10.1093/qjmed/hcab070
17.�Carney, B.C., Chen, J.H., Luker, J.N.,

Alkhalil, A., Jo, D.Y., Travis, T.E., Moffatt,
L.T., Simbulan-Rosenthal, C.M., Rosenthal,
D.S., & Shupp, J.W. (2019). Pigmentation
Diathesis of Hypertrophic Scar: An
Examination of Known Signaling Pathways to
Elucidate the Molecular Pathophysiology of
Injury-Related Dyschromia. Journal of Burn
Care & Research. 40(1), 58-71.
https://doi.org/10.1093/jbcr/iry045

18.�Kirkpatrick, L.D., Shupp, J.W., Smith, R.D.,
Alkhalil, A., Moffatt, L.T., & Carney, BC.
(2021). Galectin-1 production is elevated in
hypertrophic scar. Wound Repair &
Regeneration. 29(1), 117-128.
https://doi.org/10.1111/wrr.12869

19.�Tejiram, S., Zhang, J., Travis, T.E., Carney,
B.C., Alkhalil, A., Moffatt, L.T., Johnson,
L.S., & Shupp, J.W. (2016). Compression
therapy affects collagen type balance in
hypertrophic scar. Journal of Surgical Research.
201(2), 299-305.
https://doi.org/10.1016/j.jss.2015.10.040










29



30
