Improvement of Aortic Valve Stenosis Classification in Patients
Through Computational Fluid Dynamics Model

Ioannis Makropoulos, Dimitris Zantzas, Vasilis Gkoutzamanis and Anestis Kalfas*

Aristotle University of Thessaloniki, Polytechnic School, Department of Mechanical Engineering, Thessaloniki, Greece.

* Corresponding Author Email: akalfas@auth.gr

ABSTRACT

Aortic valve stenosis (AS) is a common and severe valvular disease where accurate assessment is essential for determining
prognosis and treatment. Current echocardiographic methods mostly rely on the simplified Bernoulli (SB) equation, which ap-
proximates the peak pressure drop (ΔP), risking poor stratification, especially for low-flow low gradient patients. This study
examines the capabilities of combining computational fluid dynamics (CFD) and imaging techniques for better stratification of
AS patients. Patient-specific geometries of the aortic valve, ascending aorta, and left ventricular outflow tract were reconstructed
from CT and echocardiography data during peak systole. Inlet velocity boundary conditions based on ultrasound data enabled
transient flow simulations. Blood flow was modeled as laminar and Newtonian, with the geometry discretized for computational
efficiency without loss of accuracy. Validation against echocardiography data showed a 4% deviation in velocity predictions.
Results indicated that ΔP and maximum velocity (Vmax) are strongly influenced by aortic valve area size, while leaflet geometry
affects flow jet location. The CFD model revealed that SB overestimates ΔP in non-severe AS, potentially leading to misclassifi-
cation. By combining CFD with precise imaging, detailed hemodynamic insights can be achieved, addressing the limitations of
conventional methods and improving patient stratification for treatment.

Keywords—Aortic valve stenosis, Patient-specific modeling, Stenosis categorization, Leaflet effects, Pressure drop, Maxi-
mum velocity, Hemodynamic flow field, Computational fluid dynamics.

Copyright © 2024. This is an open-access article distributed under the terms of the Creative Commons Attribution License (CC BY): Creative Commons -
Attribution 4.0 International - CC BY 4.0. The use, distribution or reproduction in other forums is permitted, provided the original author(s) and the copyright
owner(s) are credited and that the original publication in this journal is cited, in accordance with accepted academic practice. No use, distribution or reproduc-
tion is permitted which does not comply with these terms.

http://www.globalce.org
http://globalce.org
http://globalce.org
mailto:akalfas@auth.gr
mailto:achat@uom.edu.gr
https://creativecommons.org/licenses/by/4.0/
https://creativecommons.org/licenses/by/4.0/


79 J Global Clinical Engineering Vol.6 Special Issue 6: 2024

INTRODUCTION

Cardiovascular diseases are the leading cause of death
worldwide (32% in 2019)1, and among them, aortic valve
stenosis (AS) is one of the most serious. Initially, the
aortic valve (AV) is one of the four valves of the heart,
situated between the left ventricle (LV) and the ascending
aorta (AA). This valve typically consists of three leaflets2,
which open and close during the cardiac cycle due to the
pressure difference between the LV and AA, ensuring the
unidirectional flow of blood towards the AA.

AS is typically attributed to the calcification of its
leaflets, resulting in an increased workload on the LV.
Specifically, due to the constriction of the cross-sectional
area of the aortic valve area (AVA), the LV is required to
generate higher pressure, thereby ensuring the appropri-
ate pressure drop between the LV and the AA to maintain
the flow of mass at normal levels. The primary method
used for categorizing, i.e., assessing, the severity of AS is
the non-invasive echocardiography. The key parameters
utilized in this measurement include the maximum
measured velocity, calculated AVA and pressure drop.2
Specifically, the pressure drop is estimated using the
simplified Bernoulli equation (SB, ΔPSB = 4 × VVC

2 mmHg,
where Vvc represents the velocity at the vena contracta,
i.e., the maximum velocity). Furthermore, it has been
demonstrated that this equation tends to overestimate
the actual pressure drop3, which could potentially impact
patient assessment. The direct measurement of pressure
drop can be achieved through invasive catheterization;
however, this procedure carries inherent risks.

Accurate patient categorization is of vital importance, as
from the moment AS symptoms appear, the annual survival
rate decreases by 25%.4 Therefore, in recent years, there
has been an increased demand for more effective assess-
ment of individuals with AS and a deeper understanding
of the flow field along the aortic valve. In this context,
the goal of this research is to construct a computational
fluid dynamics (CFD) model for simulating the flow along
the aortic valve, utilizing real patient data. Additionally,
another objective is to conduct a comprehensive analysis
of the impact of aortic valve stenosis on the flow field. In
this manner, this research aims to analyze the flow along
the aortic valve for various constriction configurations,

thereby enhancing our understanding of the phenomenon
and facilitating future investigations in the quest for an
additional index that will serve as a supportive tool in
patient categorization.

MATERIALS AND METHODS

Data from computed tomography (CT) and echocar-
diography (Echo) of a patient were acquired. From the
CT data, the corresponding three-dimensional geometry
was constructed for maximum diastole and systole us-
ing discretization software (Retomo, 2024, BETA CAE
Systems International AG, D4 Business Village Luzern
Platz 4, 6039 Root, Switzerland) (Figure 1 (a)→(b)).
Subsequently, different software (ANSA, Beta) was used
for processing and the improvement of the mesh (Figure
1 (b)→(c)). Additionally, the open AV’s geometry was
not discernible in the CT data at peak systole, likely due
to the rapid nature of systole and the thinness of the
leaflets. In contrast, the closed AV was distinguishable
at maximum diastole. For this reason, the geometry of
the open AV was constructed after processing the closed
AV, and the geometric dimensions were validated using
the echo data (Figure 1 (c)). Specifically, the AVA cross-
section was nearly identical between the model and the
echo (310 mm2). Subsequently, the enhanced geometries
obtained at both maximum diastole and systole were inte-
grated within the left ventricular outflow tract (LVOT) to
facilitate the prescribed motion of the LV (Figure 1 (d)).
However, it was found in the literature that this motion
does not significantly affect pressure drop.5. Therefore,
the prescribed left ventricle motion was chosen to be
removed in order to reduce computational costs, and a
conduit was placed in its position. Additionally, a second
conduit was added to the ascending aorta to minimize
the effect of boundary conditions on the results. The total
dimensions of the two conduits are shown in Figure 1 (d),
measured from the AVA.

To investigate the influence of AS and its valve leaflets
on flow dynamics, a Python code was developed. This
code, in conjunction with ANSA, facilitates the creation
of various aortic valve geometries. Specifically, this code
utilizes some basic geometric characteristics of the original
valve and a user-defined percentage step. In this way, the
desired AVA profiles are automatically generated in the

http://www.globalce.org
http://globalce.org
http://globalce.org


J Global Clinical Engineering Vol.6 Special Issue 6: 2024 80

form of curves. Figure 2 depicts the geometries of the AV
constructed with different AVA values.

The flow simulation was conducted using computational
fluid dynamics software (ANSYS Fluent, R3, 2019). The
simulation was time-varying (transient), and the valvewas
in the fully open position during systole. The time step
chosen was 10−3 seconds (it was found that variations
between 10−3 seconds and 10−4 seconds result in a 0.03%
deviation, while exponentially increasing computational
cost). Incompressible fluid with a density of 1060 kg/m3
and Newtonian fluid with a dynamic viscosity of 0.004
kg·m/s) were considered. The boundary condition for the
inlet referred to mass flow, for which it was assumed to
follow a sin waveform, generating 90 ml (stroke volume,
SV) during systole, which had a duration of 0.35 seconds
(both values were derived from the echo data). The outlet
boundary condition corresponded to a pressure, which
was assumed to remain constant at 120 mmHg.6

An investigation was conducted to assess the impact
of inflation layers and turbulence model on the relevant
parameters, pressure drop (ΔP), and maximum velocity
(Vmax) at peak systole. The pressure drop was calculated
based on the difference in static pressure between the
level 45 mm before the AVA and 90 mm after the AVA.

It was observed that the inflation layers introduced a
deviation of 7.8% and 3.8% in ΔP and Vmax, respectively.
For the investigation of the turbulence model, the low
Reynolds SST model was chosen based on the literature.7
This model was used in conjunction with the volume
mesh containing the inflation layers and produced ymax

+


(t) < 1.7 < 5. Comparing the results between the lami-
nar and turbulent flow models, differences of less than
0.8% were observed for both ΔP and Vmax. Therefore, the
impact of the turbulence model appears to be minimal.
Additionally, the accuracy provided by the introduction of
inflation layers, relative to the additional computational
cost, is considered negligible. For these reasons, and to
reduce computational costs, the laminar flow model and
the volume mesh without inflation layers were chosen.
Additionally, before employing the two-volume meshes
(one with inflation layers and one without), independent
studies of the mesh were conducted. Specifically, for the
volume mesh that was chosen for the simulations (without
inflation layers), five different volume mesh sizes were
examined: 0.4, 0.8, 1.6, 3, 9.6 × 105. Between the 4th and
5th volume meshes, there was a difference of 1.53% in
ΔP and 0.98% in Vmax, while between the 3rd and 4th vol-
ume meshes, the differences were 3.34% and 0.96% for
ΔP and Vmax, respectively. The 4th volume mesh size was
selected to reduce computational costs. The assumptions
made regarding the mesh size, the choice of a volume
mesh without inflation layers, and the use of laminar
flow reduced the computational time for simulating the
entire systolic cycle for one case from approximately 24
hours to 5 hours. The simulations were conducted on a
laboratory computer with 32 GB RAM, a 512 GB SSD, and
an 11th Gen Intel(R) Core™ i7-1165G7 processor.

FIGURE 1. Representation of the methodology followed for
the construction of the computational model. (dAA diameter
of the ascending aorta)

FIGURE 2. Different AVA cross-sections.

http://www.globalce.org
http://globalce.org
http://globalce.org


81 J Global Clinical Engineering Vol.6 Special Issue 6: 2024

RESULTS

For the validation of the model, initially, a comparison
of the results with the measurements from the examined
individual’s echo was performed. The maximum velocity
in the echo at the LVOT ranges from 1.13 to 1.22 m/s,
while the corresponding velocity in the model is 1.27
m/s. Therefore, a 4% deviation in velocity is observed.
Furthermore, at the peak of systole, the pressure drops
and the maximum velocity calculated from the model are
2.79 mmHg and 1.63 m/s, respectively. Figure 3 presents
the results of the AVA’s impact on ΔP and Vmax, as derived
using the AV from Figure 2 and connected with spline
curves.  In the same diagram, the estimated pressure drop
from SB is also depicted. The dashed lines indicate the
thresholds for severe aortic stenosis condition.3

To investigate the effect of each valve’s geometry on
the flow field, four different models with different AVAs
were created (Figure 4). The first model represents the
patient’s initial AVA and serves as the baseline for com-
parison with the other three, which sequentially incor-
porate a dysfunctional valve. These dysfunctional valves
were intentionally designed to achieve nearly identical
AVA cross-sectional areas in all three cases. Simulation
results showed that all three different aortic valves did
not significantly differ in terms of the increase in ΔP and
Vmax. Specifically, the three dysfunctional AVs exhibited
an average increase of +215% in ΔP and +125% in Vmax.

DISCUSSION

The comparison made between the results and the
echo data indicates that the model adequately predicts
the flow field. Moreover, for a more comprehensive
comparison, a comparison was conducted with patients
from the literature5,8 who exhibited similar geometric
and hemodynamic characteristics, including comparable
AVA and stroke volume. From the comparison, deviations
were observed, which can be attributed to the slight differ-
ences in these characteristics. For instance, Vmax literature
= 1.33 m/s, whereas Vmax model = 1.63 m/s. The higher
value in the model can be attributed to the smaller AVA
and the greater maximum flow volume. Based on this
analysis, the methodology utilized for constructing the
three-dimensional model has demonstrated its effective-
ness in calculating the maximum velocity and pressure
drop at peak systole. In Figure 3, the high values of ΔP for
severe AS are attributed to the constant stroke volume
of 90 ml, whereas this volume is affected in cases of AS.

FIGURE 3. Effect of AVA cross-sections on flow characteristics.

FIGURE 4. Models and flow patterns for assessing the impact
of leaflets on the flow field.

http://www.globalce.org
http://globalce.org
http://globalce.org


J Global Clinical Engineering Vol.6 Special Issue 6: 2024 82

was revealed that in the patient’s initial model, the infla-
tion layers have a more pronounced effect on ΔP and
Vmax compared to the turbulence model, while the layers
themselves are considered to provide negligible additional
accuracy compared to the computational cost they intro-
duced. Moreover, it was observed that all three leaflets
exhibited a similar impact on ΔP and Vmax, emphasizing
that these parameters are predominantly influenced by
the size of the AVA, rather than the specific valve geometry.
However, the valve’s geometry, specifically the leaflets,
influences the flow pattern of the jet.

REFERENCES

1. World Health Organization, Cardiovascular diseases (CVDs).
Available online: https://www.who.int/news-room/
fact-sheets/detail/cardiovascular-diseases-(cvds).

2. Ring, L., Shah, B.N., Bhattacharyya, S., et al. Echocar-
diographic assessment of aortic stenosis: a practical
guideline from the British Society of Echocardiogra-
phy. Echo Res Practi. 2021;8(1):G19–G59. https://doi.
org/10.1530/ERP-20-0035.

3. Baumgartner, H., Stefenelli, T., Niederberger, J., et al.
“Overestimation” of catheter gradients by Doppler
ultrasound in patients with aortic stenosis: a predict-
able manifestation of pressure recovery. J American
Coll Cardiol. 1999;33(6):1655–1661. https://doi.
org/10.1016/s0735-1097(99)00066-2.

4. Carabello, B.A. and Paulus, W.J. Aortic Stenosis. Lancet.
2009;373(9667):956–966. https://doi.org/10.1016/
S0140-6736(09)60211-7.

5. Hoeijmakers, M.J.M.M., Silva Soto, D.A., Waechter-Stehle,
I., et al. Estimation of valvular resistance of segmented
aortic valves using computational fluid dynamics. J
biomech. 2019;94:49–58. https://doi.org/10.1016/j.
jbiomech.2019.07.010.

6. Weese, J., Lungu, A., Peters, J., et al. CFD-and Bernoulli-
based pressure drop estimates: a comparison using
patient anatomies from heart and aortic valve segmen-
tation of CT images. Med Phys. 2017;44(6):2281–2292.
https://doi.org/10.1002/mp.12203.

Therefore, the illustrated ΔP values correspond to the
complete preservation of flow (SV = const) in the case
of AS. Similar observations apply to Vmax. Additionally,
in the same figure, a pronounced overestimation of SB
is observed in individuals with non-severe AS.3 Overall,
based on the chart in Figure 3, clinical researchers could
be able to assess the severity of stenosis in the specific
patient for whom the model was created. Additionally,
they could examine potential stenosis cases that may
arise in the future.

Therefore, by applying the methodology presented for
constructing the CFD model and valves, clinical researchers
could create corresponding diagrams for each patient under
examination. This would lead to a more comprehensive
understanding of each examined individual by medical
researchers. However, for this analysis to be applicable in
clinical research, it is imperative to utilize supercomput-
ers to minimize computational costs. Additionally, this
methodology should be fully automated and thoroughly
validated for accuracy across hundreds of patients. Based
on the results obtained from the investigation of the leaf-
lets, it was found that all three leaflets affect ΔP and Vmax
to a similar extent. Therefore, this leads to the additional
conclusion that ΔP and Vmax are not as strongly dependent
on the geometry of the aortic valve as they are on the
size of the AVA. However, the geometry of the AV affects
the flow field, as depicted in Figure 4, where the flow jet
location is different in the four cases. Hence, the valve’s
leaflets impact the location where the flow jet impinges
on the AA, potentially contributing to the development
of an aortic root aneurysm, as the impingement point in
the ascending aorta can influence the Wall Shear Stresses.

 CONCLUSION

In this research, a methodology was presented for con-
structing a patient-specific computational fluid dynamics
model for simulating blood flow along the aortic valve.
It was found that the model construction methodology
is sufficient for calculating ΔP and Vmax. Additionally, the
code developed for automating the process of constructing
various valves from the initial valve proved to be highly
useful, as it can yield significant insights for future cases
of more severe AS in the same patient. Furthermore, it

http://www.globalce.org
http://globalce.org
http://globalce.org
https://www.who.int/news-room/fact-sheets/detail/cardiovascular-diseases-(cvds)
https://www.who.int/news-room/fact-sheets/detail/cardiovascular-diseases-(cvds)
https://doi.org/10.1530/ERP-20-0035
https://doi.org/10.1530/ERP-20-0035
https://doi.org/10.1016/s0735-1097(99)00066-2
https://doi.org/10.1016/s0735-1097(99)00066-2
https://doi.org/10.1016/S0140-6736(09)60211-7
https://doi.org/10.1016/S0140-6736(09)60211-7
https://doi.org/10.1016/j.jbiomech.2019.07.010
https://doi.org/10.1016/j.jbiomech.2019.07.010
https://doi.org/10.1002/mp.12203


83 J Global Clinical Engineering Vol.6 Special Issue 6: 2024

7. Stewart, S.F.C., Paterson, E.G., Burgreen, G.W. et al.
Assessment of CFD performance in simulations of
an idealized medical device: results of FDA’s first
computational interlaboratory study. Cardiovasc Eng
Tech. 2012;3:139–160. https://doi.org/10.1007/
s13239-012-0087-5.

8. Yang, C.S., Marshall, E.S., Fanari, Z., et al. Discrepancies
between direct catheter and echocardiography-based
values in aortic stenosis. Catheter Cardiovasc Interv.
2016;87(3):488–97. https://doi.org/10.1002/ccd.26033.

http://www.globalce.org
http://globalce.org
http://globalce.org
https://doi.org/10.1007/s13239-012-0087-5
https://doi.org/10.1007/s13239-012-0087-5
https://doi.org/10.1002/ccd.26033

	Editor’s Corner
	Biomedical Technology and Clinical Engineering in Greece after the Pandemic: Highlighted Works from the Panhellenic Conference of Biomedical Technology
	Aris Dermitzakis1,2,*, Vasiliki Zilidou1,3, Eleftheria Vellidou1,4, Alkinoos Athanasiou1,3

	Digital Transformation Management in Health Services: Health Professionals Perceptions as an Implementation Factor
	Theodoros S. Tanis*, Chryssoula Chatzigeorgiou, Ioanna Simeli, and Evangelia Stalika

	Validating the ID-GAMING e-Training Toolkit for People with Intellectual Disabilities in Greece
	Niki Pandria*, Anastasia Barboudi, Vasileia Petronikolou, Panagiotis Antoniou and Panagiotis D. Bamidis

	Novel Functional Electrical Stimulation Parameter Optimization for Neurorehabilitation Using Both Conventional and AI Techniques
	Arsenios Arsenidis1, Alexandros Moraitopoulos2, Alkinoos Athanasiou2, Alexandros Vildiridis3, Panagiotis Bamidis2, Petros Stefaneas4 and Alexandros Astaras5

	Leveraging Web Scraping and API Integration for Efficient Medical Device Data Management
	Agapi Konstantina Liontou1,*, Spilios Zisimopoulos2 and Aris Dermitzakis1

	Human Muscle State Machine Using Electromyography Classification with Machine Learning
	George Lyssas1,*, Konstantinos Mitsopoulos1, Dimitris Zantzas2, Anestis Kalfas2, Panagiotis D. Bamidis1

	Kinematic and Dynamic Analysis of Lower Limb Movement: Towards the Design of a Wearable Rehabilitation Assistant Device
	Filippos Margaritis1,*, Konstantinos Mitsopoulos1, Kostas Nizamis2, Alkinoos Athanasiou1 and Panagiotis D. Bamidis1

	A Novel Dermatological Diagnosis Support Device Based on Electrical Impedance Spectroscopy
	Alexandros Moraitopoulos1,*, Konstantinos Mitsopoulos1, Christina Kemanetzi2, Panagiotis Bamidis1 and Alexandros Astaras3

	Software Skills Identification: A Multi-Class Classification on Source Code Using Machine Learning
	Dimitris Bamidis, Ilias Kalouptsoglou, Apostolos Ampatzoglou, Alexandros Chatzigeorgiou*

	Improvement of Aortic Valve Stenosis Classification in Patients Through Computational Fluid Dynamics Model
	Ioannis Makropoulos, Dimitris Zantzas, Vasilis Gkoutzamanis, Anestis Kalfas*

	Kinematic and Dynamic Analysis of the Human Hand’s Articulation for Wearable Soft-Robotic Device Applications
	Paschalina-Danai Sarra, Vasiliki Fiska, Konstantinos Mitsopoulos, Diamanto Mylopoulou, and Panagiotis D. Bamidis*

	Deep Learning Classification of Epileptic Magnetoencephalogram
	Andreas Stylianou1, Lefteris Koumakis2, Maria Hadjinicolaou3, Adam Adamopoulos1,* and Alkinoos Athanasiou4
