DNA Variations between Medicago truncatula Symbiotic

Mutant Line and Native Variant Using Fluorescence-

Based AFLP Marker


Asmaa H. Hassan

1
, Mohamed A-bouzeid

2
, and Ghada Abu El-Heba *

1




Abstract

      Genetic mutagenesis is a very efficient tool in studying genes

function. Because of great benefits of legumes as human food and animal

feed worldwide, we used a model plant Medicago truncatula for

identification gene function related to nitrogen fixation process. Our

mutant is a Medicago mutant line contains a tobacco Tnt1 retro-

transposon mobile element with the two Long Terminal Repeats (LTR)

inserted within the genome. Our mutant is predicted to contain a mutation

in gene/s belonging to symbiotic interaction between legume and

rhizobia. A novel technique was used based on using fluorescent

oligonucleotide primers against oligonucleotide primers for Tnt1-LTRs

of our mutant. This novel protocol was very successful in detection the

polymorphism between our mutant line and the wild variant R108 using

Biosystems 310 Genetic Analyzer. Electropherograms of the mutant line

and wild type gave a total of 561 well- resolved AFLP peaks, 357of

which were polymorphic peaks and 204 were monomorphic peaks. This

novel technique enables the calculation percentage of polymorphism

between the mutant line and the wild type. Additionally primers

combinations amplified more bands from others to detect polymorphism

between the plants.



Keywords: Medicago truncatula, AFLP, Polymorphism, Symbiotic mutant,

Nitrogen fixation.



Introduction

Legumes played vital roles in improving agriculture and considered as one-

third of the world’s major crop production. They represent about 27% of the

world’s crop production. Human consumes approximately 33% of the dietary

protein needs in the form grains. Many food industries based on legumes like

treated vegetable, oil production, and chicken industry. Animals depend on

forage legume plants as major source of food like Medicago stavia and Trifolium

spp (1).

This group of plants has unique character as they have ability to make

symbiotic relationship with soil bacteria called rhizobia. Rhizobia are beneficial

soil bacteria that belong to gram negative group (2)

. In this relation legumes can

fix nitrogen in specific organ called root nodule (1,3). Nitrogen fixation process

occurs naturally during growing this family of plants and so we can decrease our

usage of industrial nitrogen fertilizers and related ecosystem pollution (1).

Many studies focused on genes responsible for nitrogen fixation in legumes

and rhizobia (4-9). Lotus japonicus and Medicago truncatula are considered as

more suitable two plants for studying genes responsible for symbiotic relationship

between both organisms.







Hassan et al., 2020                                                                                                                                              Medicago truncatula symbiotic mutant analysis





Highlights in BioScience                                                                                                                                                                           April 2020| Volume 3

http://bioscience.highlightsin.org/

Page 2 of 5

Numerous technological platforms like; ethyl

methanesulfonate (EMS) mutagenesis (10), fast neutron

bombardment and g-rays (11)

were developed and used for

model plants genome studying. DNA-insertion

mutantgenesis populations save a rapid method for isolating

genes responsible for symbiotic nitrogen fixation through

both reverse and forward genetics (12-14).

Retrotransposon is a type of mobile elements (class I)

that transpose to new sites in the genome via an RNA

intermediate. Their primary transcripts are retro-transcribed

into DNA copies by a reverse transcriptase (15). Tobacco

retrotransposon Tnt1 is an effective mutagen in M.

truncatula that is used for molecular studies worldwide (16).

This transposone element (Tnt1) belongs to retrotransposon

elements family (17) , its transposition was induced during

tissue culture of tobacco protoplast(18) and during in vitro

transformation of A. thaliana. Tnt1 insertions of  are stable

in the plant and transfer to the progeny because of the

replication cycle of LTR retrotransposons (19).

Samuel Roberts Noble Foundation has the largest

collection of DNA-insertion mutants of all legumes specially

Tnt1-insertion mutant populations in Medicago truncatula.

Numerous mutant phenotypes have been screened such as

mutant loss the ability to form nodules, mutants produce

dysfunctional nodules, mutants produce large number of

nodules and mutants with delayed and decreased nodulation

but efficient in nitrogen fixation (9).

Among molecular technique, AFLP protocol provides

a very powerful DNA finger printing method for nucleic

acid of any organism (20). Fluorescence-labeled PCR

products were sensed on an automated DNA sequencer

instead of the standard polyacrylamide gel electrophoresis

tool (21-22). Capillary electrophoresis has more advanced

characters from slab gels in speed, resolution and

availability of numerical information in an electronic format

following the end of a reaction. In this study, the genetic

polymorphism between Medicago truncatula symbiotic

mutant line and the wild type of the same plant has been

estimated using amplified fragment length polymorphism

(AFLP) marker analyses. This mutant contains Tnt1

reterotrasposon element that have mutation in the gene/s

involving in nitrogen fixation process.

Materials and Methods

Plant materials

The mutant line of Medicago truncatula was provided

from Noble Foundation Tnt1 mutant collection that

transformed from M. truncatula R108-1 ecotype (23). The

wild type plant R108has been used in this study as a

reference.

Seed sterilization and germination
Seeds of Medicago truncatula wild type and mutant

line were scratched with sand paper and surface sterilize

with 6.25% (v/v) sodium hypochlorite for 10 minutes. After

seven washes using sterilize water, seeds were put on

Murashige and Skoog (MS) basal medium (Murashige and

Skoog 1962) supplemented with 0.8% agar (Grade J3,

Gelita) in dark over night at 29° C. Seedlings were

transferred to growth chamber with this condition at stable

21° C during a 16-h and 8-h night photon flux density of

100 ϻ mol m
-2

s
-1

(24).

 DNA isolation and quantification

Total genomic DNA was extracted from mutant plants

and control for using in AFLP analysis. Healthy leaves from

both line were used for DNA isolation using Qiagen

Genomic DNA isolation kit, (Qiagen Science,Valence ,  CA

, USA). The quality and quantity of Genomic DNA were

estimated using spectrophotometric measurement of ultra

violet absorbance at wave length 260 and 280 nm in thermo

scientific Nanodrop 2000™) and were electrophoresed at

0.5% agarose gel electrophoresis.

AFLP protocol

a) Genomic DNA digestion and ligation

Amount of genomic DNA from mutant line and wild

type were digested   with 10u EcoR1 and 10u Mfe1 (New

England Biolabs, Ipswich, MA, USA). The total volume was

incubated for three hrs at 37°C then the enzymes were

inactivated by incubation for 20 mins at 65°C. To assess the

digestion, 5 μl from each sample were electrophoresed on a

1.5 % agarose gel. The digested fragments DNA were

ligated by ECO and ASE adaptor ligation using T4 DNA

ligase (New England biolabs) to produce modified digested

fragments that were used as a template DNA for

amplification.

c) Pre-selective amplification reaction

The reaction was performed on ligated DNA using two

AFLP oligonucleotide primers using TakaRa LA Taq kit.

Then the product was run on 1.5% agarose gel.

d) Selective amplification reaction

Selective amplification was performed using two

AFLP oligonucleotide primers. The first one was

fluorescence-labeled primer: Eco (Dye-primer-AXX) and

unlabeled primer (LTR4&LTR6). Three primer

combinations were used: E-ACC (Ned)/LTR4, E-ACC

(Ned)/LTR6, E-AAG (6-Fam)/LTR4, E-AAG (6-Fam)/

LTR6, E-AAC (Hex)/LTR4 and E-AAC (Hex)/LTR4. AFLP

procedure was applied according to (25) with a modification

which is using three florescence labeled oligonucleotide

primers (E-AAC, E-AAG, and E-ACC) (20). 1ul of selective

amplified product was added to 12ul Hi-Di formamide and

0.5 microliter of GeneScan500 ROX internal size standard

(Applied Biosystems, Foster City, California, USA). The

mixture of these components was denatured and inoculated

to the single capillary of Applied Biosystems 310 Genetic

Analyzer. Gene mapper analysis software version 4.1

(Applied Biosystems) was used for analyzing the generated

electropherograms for mutant and R108 from the raw date

according to AFLP system analysis getting started guide.







Hassan et al., 2020                                                                                                                                              Medicago truncatula symbiotic mutant analysis





Highlights in BioScience                                                                                                                                                                           April 2020| Volume 3

http://bioscience.highlightsin.org/

Page 3 of 5

Results

Pre-selective amplification was achieved using pre-

selective oligonucleotide primer pair and the product was

run on 1.5% agarose gel. Successful pre-selective

amplification was confirmed as a smear product that was

interrupted by a number of bands and the polymorphism

cannot be detectable at this stage. AFLP electropherograms

of mutant line and wild type selectively amplified using

primer combination as illustrated in (Table 1).

Oligonucleotide primer combinations examined for selective

amplification of DNA fragments of mutant line and wild

type gave a total of 561 well- resolved AFLP peaks of which

357 were polymorphic peaks and 204 were monomorphic

peaks. The highest number of amplified DNA fragments was

218 peaks were obtained with primer combination (E-

AGG/LTR4); however the lowest number of amplified DNA

fragments was 31 peaks from combination (E-ACC/LTR6).

AFLP electropherograms of both lines were produced using

the illustrated primer combination E-ACG/LTR4 (as an

example) was shown in (Figure 1).



Table 1: Showing that the total number of peaks (TNP),

number of polymorphic peaks (NPP) and number of

monomorphic peaks (NMP) were produced by each primer

combination (PC).





Discussion

Legumes have a fundamental role in sustainable

agriculture for decades. They are able to reduce the

atmospheric N2 to ammonia through symbiosis interaction

with rhizobia which is nitrogen-fixing bacteria. This

criterion enables legumes to propagate well in soils poor

with nitrogen without any fertilizer addition. Symbiotic

Nitrogen Fixation (SNF) in legumes produces nitrogen

about fifty million tons into the agricultural systems every

year.  Both legumes and non-legumes production is

sustained by such nitrogenous compound in the soil (21).

Legumes are essential source for food and feed (1).

In our research we used Medicago truncatula which is

a model plant for studying SNF because it has a small

diploid genome, short life cycle and it performs symbioses

with (Sinorhizobium meliloti and Sinorhizobium medicae).

Mutant collections production was necessary to identified

genes function.

Large scale mutagenesis was generated in M.

truncatula via Tnt1 retrotransposon (23). Tnt1 is a Ty1-

copia type retrotransposon with long terminal repeat (LTR),

isolated from tobacco (26). Tnt1 transpose via copy & paste

mechanism
.
Each mutant line has from four to fifty

insertions per genome (23). Retrotransposon mediated

mutagenesis was used in the other plant species like rice

(27), lettuce (19)
,
 and soybean (28). Samuel Roberts Noble

Foundation has produced about 21,000 Tnt1 mutant lines

(23). We used AFLP-type protocol in combination with ABI

310 Genetic Analyzer to determine the genetic

polymorphism between our mutant line which is putatively

defects in nodule development and R108 wild type.



Figure 1: AFLP electropherograms of R108 and mutant line amplified selectively by the primer combination E-AAG/lTR6.

Red row indicates a polymorphic peak example that is present in mutant line and absent in R108.









Hassan et al., 2020                                                                                                                                              Medicago truncatula symbiotic mutant analysis





Highlights in BioScience                                                                                                                                                                           April 2020| Volume 3

http://bioscience.highlightsin.org/

Page 4 of 5

AFLP electropherograms of both lines produced a total

of 561 AFLP peaks were recorded, 357 of which were

polymorphic and 204 were monomorphic .This corresponds

to a level of polymorphism of 63.7%. [The percentage of

polymorphism was calculated as [(the total No. of

polymorphic peaks / the total No. of peaks) x 100].

AFLP has the capability to discover the

polymorphisms between these types of plants without

knowing the sequence of genome. So, this is one of the best

advantages of using AFLP technique. The established

website (http://bioinfo4.noble.org/mutant/) encloses

information about 11,000 Tnt1 mutant lines with images of

diverse phenotypes. Our perspective work will include

AFLP-type PCR to isolate all the Tnt1-flanking sequence

tags (FTS) for more mutant characterization and

identification. All fragments will be analyzed and the

mutated gene/s will be recognized.

Acknowledgement

The authors appreciate Dr. Pascal Ratet for providing

mutant line & R108 wild type.

References

1. Graham PH, Vance CP. Legumes : Importance and

Constraints to Greater Use Update on Legume

Utilization Legumes : Importance and Constraints to

Greater Use. Plant Physiol. 2003;131:873–7.

2. Zakhia F, De Lajudie P. Taxonomy of Rhizobia. EDP

Sci. 2001;21:569–76.

3. Smil. Nitrogen in crop production : An account of

global flows adds recycled in organic up by harvested

and Quantification of N losses from crop to 26-60.

Glob Biogeochem CYCLES,. 1999;13(2):647–62.

4. Fuhrmann  ‎‎M. Hennecke H. Rhizobium japonicum

Nitrogenase Fe Protein Gene (nifH). J Bacteriol.

1984;158(3):1005–11.

5. Roche P. Maillet F. Plazanet C. Debellé F.Ferro M  et

al. The common nodABC genes of Rhizobium meliloti

are host-range determinants.  Proc Natl Acad Sc.

1996;93(December):15305–10.

6. Radutoiu S. Madsen LH.Madsen EB. Felle HH.

Umehara Y. Grønlund M.et al. Plant recognition of

symbiotic bacteria requires two LysM receptor-like

kinases. Nature. 2003;425:585–92.

7. ArrighiJ-F, Barre A, BenAmorB, BersoultA, Soriano

LC, Mirabella R, de CarvalhoNiebel F, Journet E-P,

GhérardiM, Huguet T  et al. The Medicago truncatula

Lysine Motif-Receptor-Like Kinase Gene Family

Includes NFP and New. Plant Physiol. 2006;142:265–

79.

8. Mergaert  P, Uchiumi T, Benoıt A E, Cheron A,

Catrice O, Mausset A-E, et al. Eukaryotic control on

bacterial cell cycle and differentiation in the

Rhizobium – legume symbiosis. pnas. 2006;

9. Pislariu CI D. Murray J, Wen J, Cosson V, Muni RRD,

Wang M, et al. A Medicago truncatula Tobacco

Retrotransposon Insertion Mutant Collection with

Defects in Nodule Development and Symbiotic

Nitrogen Fixation. Plant Physiol [Internet].

2012;159(4):1686–99.

10. Penmetsa RV, Cook DR. Production and

Characterization of Diverse Developmental Mutants of

Medicago truncatula 1. Plant Physiol.

2000;123(August):1387–97.

11. Rogers C, Wen J, Chen R, Giles O. Deletion-Based

Reverse Genetics in. Breakthr Technol Deletion-

Based. 2009;151(November):1077–86.

12. Tadege M, Ratet P, Mysore KS. Insertional

mutagenesis : a Swiss Army knife for functional

genomics of Medicago truncatula. Trends Plant Sci.

2005;10(5):229–35.

13. Young ND, Udvardi M. Translating Medicago

truncatula genomics to crop legumes. 2008;12:193-

201.

14. Urban´ ski D F, Małolepszy A, J Stougaard , Andersen

SU. Genome-wide LORE1 retrotransposon

mutagenesis and high-throughput insertion detection in

Lotus japonicus. plant J. 2012;69:731–41.

15. Wessler SR. Transposable elements and the evolution

of eukaryotic genomes. Nat Rev Genet.

2006;103(47):17600–1.

16. Erfurth I, Cosson V, Eschstruth A, Lucas H, Kondorosi

A, Ratet P. Ef ficient transposition of the Tnt1 tobacco

retrotransposon in the model legume Medicago

truncatula. Plant J. 2003;34(1):95–106.

17. Grandbastien, Marie-Angele AS& MC, Laboratoire.

Tntl, a mobile retroviral-like transposable element of

tobacco isolated by plant cell genetics. nature,.

1989;337:5–9.

18. Pouteau S, Huttner E, Grandbastien M A, Caboche M.

Specific expression of the tobacco Tntl in protoplasts.

EMBO. 1991;10(7):1911–8.

19. Mazier M, Botton E, Flamain F, Bouchet J-P , Courtial

´, et al. Successful Gene Tagging in Lettuce Using the

Tnt1 Retrotransposon from Tobacco.

2007;144(May):18–31.

20. Thom‎as CM, Vos P, Zabeau M, Jones DA, Norcott

KA, Chadwick BP, et al. Identification of amplified

restriction fragment polymorphism (AFLP) markers

http://bioinfo4.noble.org/mutant/






Hassan et al., 2020                                                                                                                                              Medicago truncatula symbiotic mutant analysis





Highlights in BioScience                                                                                                                                                                           April 2020| Volume 3

http://bioscience.highlightsin.org/

Page 5 of 5

tightly linked to the tomato Cf‐ 9 gene for resistance to

Cladosporium fulvum. Plant J. 1995;8(5):785–94.

21. Weising K, Nybom H, Wolff K KG. DNA

fingerprinting in plants: principles, methods, and

applications, 2nd edn. Boca Raton: CRC Press. 2005.

472-477 p.

22. Karudapuram S, Larson S. Identification of Hedysarum

Varieties Using Amplified Fragment Length

Polymorphism on a Capillary Electrophoresis System.

J biomlecular Tech. 2005;16(4):316–24.

23. Tadege M, Wen J, He J, Tu H, Kwak Y, Eschstruth A,

et al. Large-scale insertional mutagenesis using the

Tnt1 retrotransposon in the model legume Medicago

truncatula. Plant J. 2008;54:335–47.

24. Shao C, Russinova E, Iantcheva A, Atanassov A,

Mccormac A, Chen D, et al. Rapid transformation and

regeneration of alfalfa ( Medicago falcata L .) via

direct somatic embryogenesis. 2000;31:155–66.

25. Ratet P, Porceddu A, Mysore KS. Insertional

mutagenesis in M . truncatula using Tnt1

retrotransposon Insertional mutagenesis in Medicago

truncatula using Tnt1 retrotransposon . 2010;1-12.

26. Kumar, Bennetzen JL. plant Retrotransposons. Annu

Rev Genet. 1999;33:479–532.

27. Greco R, Ouwerkerk PBF, Sallaud C, Kohli A,

Colombo L, Puigdome P, et al. Resources and

Opportunities Transposon Insertional Mutagenesis in

Rice 1 , 2. Plant Physiol. 2001;125:5–7.

28. Cui Y, Barampuram S, Stacey MG, Hancock CN,

Findley S, Mathieu M, et al. Tnt1 Retrotransposon

Mutagenesis : A Tool for Soybean. 2013;161:36–47.
