Management of dental erosive using composite layering technic and biomimetic efficiency






Management of dental erosive using composite layering technic and biomimetic efficiency

Rafalimino HN1,2, Rakotonirina FP1,3, Radadisolo MEF4,5,Randriamalala NC1,6,
Andrianjafinoro TH1,2,Ramaroson J1.

1Sub-section of Conservative Odontology Endodontic at the Tropical Odonto-Stomatological Institute
of Madagascar (IOSTM), University of Mahajanga

² University Hospital Profesora Zafisaona Gabriel Androva Mahajanga Madagascar,
3Oral Health Center, Ministry of Industrialization, Trade and Consumption Antananarivo,

Madagascar,
4Sub-section Odontology Pediatric at the Tropical Odonto-Stomatological Institute of Madagascar

(IOSTM), University of Mahajanga
5Military Hospital Ampahibe,Antananarivo, Madagascar

6 University Hospital Joseph Dieudonné Rakotovao, Befelatanana Antananarivo,


Corresponding author: Rafalimino Holy Nasandratra

Sub-section of Conservative Odontology Endodontic at the Tropical Odonto-Stomatological Institute
of Madagascar (IOSTM), University of Mahajanga



Abstract

In the world, in 2006, the prevalence of dental wear was 46.9% among individuals aged 14 to

88 years. According to Schlueter N and colleagues, by calculating an approximate average

from available data, they estimated the average prevalence of dental erosion to be between

30 and 50% for deciduous teeth and between 20 and 45% for permanent teeth worldwide.

They found that patients with gastro esophageal reflux (GERD) and eating disorders

associated with vomiting had a clear impact on the prevalence of erosion. Regardless of the

type of dental substance loss in the anterior sector, composite crown restoration remains

the most chosen restorative therapy by dentists. Located in the anterior region, these types

of dental substance losses affect aesthetics and make the smile unattractive. The individual's

personality is disturbed as well as their communicative life. The objective of this article was

to present the case of a patient with dental erosions in the anterior sector, managed by the

composite layering technique, and to demonstrate the biomimetic efficiency of the

restoration.



Keywords: Biomimetic, dental erosion, layering, direct technique



1. Introduction

Faced with dental substance loss due to decay or tooth wear, composite crown restoration

remains the primary restorative therapeutic option chosen by the dentist. Dental erosion is a

chemical process characterized by acid dissolution of dental hard tissue not involving acids

IJO JOURNALS

Volume 07 | Issue 04 | April 2024 | https://ijojournals.com/index.php/hsn/index 7



IJO - INTERNATIONAL JOURNAL OF HEALTH SCIENCES AND NURSING
 ( ISSN: 2814-2098 )                                                                       Rafalimino Holy Nasandratra1*

https://ijojournals.com/                                                     Volume 07 || Issue 04 || April, 2024 ||

Management of dental erosive using composite layering technic and biomimetic efficiency






of bacterial origin. Erosive demineralization can result in progressive, irreversible loss of

tooth mineral substance, and may be caused by intrinsic factors like acid reflux and excessive

vomiting[1].Located in the anterior region, these types of dental substance loses diminish

aesthetics and make the smile unattractive. The individual's personality is disturbed as well

as their communicative life. The objective of this article was to present the case of a patient

with dental erosions in the anterior sector, managed by the composite layering technique,

and to identify the factors determining the biomimetic success of the restoration.

2. Observation

This concerns a 44-year-old female patient, working as a client manager, who came to

consult us at the specialized Odontostomatology center in Mahajanga. Her reason for

consultation was an aesthetic concern. Upon examination of her general condition, the

patient appears to be in good health, except that she frequently experiences almost daily

gastro esophageal reflux. In order to limit this gastric problem, the patient frequently drinks

lemon juice outside of meals. On physical examination, the extra-oral examination showed

the absence of palpable or painful adenopathy in the submandibular, jugular-carotid, and

supraclavicular areas. The intra-oral examination of the patient's hard tissues showed the

presence of blatant erosive dental substance loss on the upper right and left central incisors.

The dental wear was of moderate erosive type, with a BEWE score of 2, an ACE class IV, with

a yellowish background indicating dentin exposure. The extent of the involvement includes

the vestibular surface, the central incisal angle, one-third of the proximal surfaces, and one-

third of the palatal surface of each tooth. The percentage of hard dental tissue involvement

was less than 5%. Aggravated by the patient's dietary habits, this dental erosion was

observed to be actively progressing and requires immediate management to prevent further

wear to other sextants. After a refined analysis of the remaining dental tissues, we opted for

management by composite layering. Our therapeutic choice was motivated by the

importance of adhering to the therapeutic gradient developed by Tirlet and colleagues and

the biomimetic dental restoration principle presented by Pascal M and colleagues. Referring

to the literature data, we adapted our therapeutic protocol according to the available

technical resources. The technical setup used included a visual aid, a conservative dentistry

examination tray, a mouth opener, a full-arch impression tray, type A alginate, high-viscosity

silicone, a wax-up plate, a PKT-type instrument, a Heidemann® spatula, a dental wedge,

some micro-applicators, a turbine, a green-band contra-angle, diamond ball burs, composite

finishing burs, an etching system, an MR3-type adhesive system, a Micerium® Enamel Plus

HFO enamel composite, a Micerium® Enamel Plus HRi enamel composite, a Charm Fill Plus®

dentin composite in shade A3.5, a Charm Fill Plus® composite in shade A3, a celluloid matrix,

composite restoration spatulas, 40µm thick articulating paper, a silicone composite finishing

kit, a 12-megapixel camera. The therapeutic protocol presented was consented to by the

IJO JOURNALS

Volume 07 | Issue 04 | April 2024 | https://ijojournals.com/index.php/hsn/index 8



IJO - INTERNATIONAL JOURNAL OF HEALTH SCIENCES AND NURSING
 ( ISSN: 2814-2098 )                                                                       Rafalimino Holy Nasandratra1*

https://ijojournals.com/                                                     Volume 07 || Issue 04 || April, 2024 ||

Management of dental erosive using composite layering technic and biomimetic efficiency






patient. In addition to patient clinical observation, eight steps were developed, including

pre-stratification analysis of the causative tooth, making a silicone guide key, preparing the

tooth for restoration, etching, applying the adhesive system, composite placement,

composite finishing, and composite polishing. Pre-stratification analysis of the teeth to be

restored was performed based on the anatomical shape and color of adjacent teeth. A visual

chromatic analysis was performed in the absence of a spectrophotometer. A personalized

shade taking was made using the chosen composites for restoration, which helped us assess

the difference in dental tissue saturation. In addition to photography, a chromatography

card of the two teeth to be restored was useful in guiding us on the choice of composites to

use for each tissue to be restored. Brightness, enamel and dentin color, and intensity

presence were noted on our chromatographic card. For shades, the dentin body was

restored with Charm Fill® composite shade A3.5 at the cervical 2/3, the incisal 1/3 part was

restored by Charm Fill composite shade A3, the dentin nipple was restored by Charm Fill®

composite shade A2, the enamel on the vestibular and palatal surfaces was restored by HFO

type OBN® enamel composite, and characterization was restored by Enamel Plus HRi

composite by Micerium®. After the patient's consent to the therapeutic proposal, an

impression was taken with type A alginate followed by pouring the positive model in plaster.

Modeling of the desired morphology of the teeth to be restored was performed with CERA

Reus Dental® modeling wax, followed by an impression of the positive model with high-

viscosity putty silicone. To obtain the silicone guide key, the hardened silicone was cut in

such a way that only the palatal part was preserved. Its adaptation was checked in the

mouth. Prior to composite placement, a tooth preparation step was developed by forming a

vestibular chamfer limit and a palatal "butt margin". We then opted for a two-step etching

and bonding system by applying 37% phosphoric acid for 15 seconds at the enamel level

followed by rinsing, and bonding with CharmBond® photopolymerizable mono-component.

The curing time was 30 seconds. The actual stratification began with the palatal aspect, then

the proximal surfaces, the dentin body, and was finalized by the vestibular enamel. Our goal

was to build walls from the restorations to transform the lack of dental substance into a

simple cavity. To do this, the previously prepared silicone key was placed on the palatal side

after applying the non-photo-polymerized palatal enamel composite layer with the

Heidemann spatula. Photo polymerization was activated after checking the key's positioning.

Then the proximal walls were restored using a matrix system such as celluloid strip. Dentin

masses in different shades were applied while respecting their respective positions recorded

in the chromatography card. We ensured that the composite thickness did not exceed 2mm

before each photopolymerization. Part of the characterization was reproduced at the dentin

nipple edge using Enamel Plus HRi® composite. Before polymerization, while respecting the

surrounding tissues, the vestibular enamel layer was finally placed by tapping without

IJO JOURNALS

Volume 07 | Issue 04 | April 2024 | https://ijojournals.com/index.php/hsn/index 9



IJO - INTERNATIONAL JOURNAL OF HEALTH SCIENCES AND NURSING
 ( ISSN: 2814-2098 )                                                                       Rafalimino Holy Nasandratra1*

https://ijojournals.com/                                                     Volume 07 || Issue 04 || April, 2024 ||

Management of dental erosive using composite layering technic and biomimetic efficiency






compressing the composite. As we did not have Modeling resin®, smoothing was done with

a micro-brush soaked in adhesive. The superficial enamel composite layer was checked to

ensure it covers the vestibular chamfer to mask the tooth-restoration junction, and the

thickness and optical effect were verified. Primary and secondary anatomies were recreated

based on adjacent teeth using diamond flame burs and round-ended cylindrical burs. After

checking for occlusal discrepancies, the polishing step was performed, with decreasing grit

size Pop-on discs mounted on blue-band contra-angle used. The operative procedure lasted

60 minutes for the restoration of each tooth. Biomimetic effectiveness was assessed after 24

hours of composite restoration rehydration and then after twenty-nine months of

restoration. Simultaneously, the patient was advised to discontinue acidic dietary habits.

Dietary hygiene education was provided to the patient. For the management of gastro

esophageal reflux, she was referred to a gastroenterologist.

3. Results

After twenty-four hours of restoration, the tooth was checked, and rehydration was

achieved, comparing it with the adjacent natural tooth considered as reference (figure 11).

After 29 months of tooth restoration, we found that the biomimetic efficiency obtained was

maintained, and we concluded that the ultra-conservative approach and the composite

layering principle were effective and sustainable for our clinical case (figure 12).



IJO JOURNALS

Volume 07 | Issue 04 | April 2024 | https://ijojournals.com/index.php/hsn/index 10



IJO - INTERNATIONAL JOURNAL OF HEALTH SCIENCES AND NURSING
 ( ISSN: 2814-2098 )                                                                       Rafalimino Holy Nasandratra1*

https://ijojournals.com/                                                     Volume 07 || Issue 04 || April, 2024 ||

Management of dental erosive using composite layering technic and biomimetic efficiency








4. Discussion

According to the literature, the aesthetic success of a composite layering restoration has

depended on the following factors: the choice of composite shades, the type of composite

used, and the composite layering system.



4.1 Aesthetic effectiveness of layering depending on the choice of composite shade

During the pre-stratification stage, the choice of shade and the recording of the five

dimensions of tooth color for a composite restoration have been discussed depending on

the type of shade guide used. According to Vanini, the use of the VITA® shade guide

combined with the concept of chromatography has served as a means of communication for

practitioners, refining and noting all parameters contributing to tooth color restoration[3-

5].For our clinical case, our shading concept was based on two principles: the use of a

custom shade guide combined with the chromatography concept. This custom shade guide,

made with the same types of composites used, helped us achieve precise shades for each

composite layer to be restored and yielded an optimal and aesthetic result. This finding is

consistent with the study by Magne B and colleagues in 2010 and the study by Manauti and

IJO JOURNALS

Volume 07 | Issue 04 | April 2024 | https://ijojournals.com/index.php/hsn/index 11



IJO - INTERNATIONAL JOURNAL OF HEALTH SCIENCES AND NURSING
 ( ISSN: 2814-2098 )                                                                       Rafalimino Holy Nasandratra1*

https://ijojournals.com/                                                     Volume 07 || Issue 04 || April, 2024 ||

Management of dental erosive using composite layering technic and biomimetic efficiency






colleagues in 2014, which evaluated the effectiveness of the custom shade guide for

choosing composite shades compared to ceramic shade guides. The use of the

chromatography guide was a very effective reference tool to avoid errors in placing each

type of composite [6-8]. Using these two principles simultaneously yielded an aesthetically

pleasing and biomimetic result.



4.2 Aesthetic effectiveness depending on the use of the silicone key

In terms of composite layering, we opted for using a single silicone guide key, which has

been affirmed by Kleeberger B and colleagues in 2008 and Callin D and colleagues in 2014 as

a key factor for aesthetic success and longevity of the restoration[9-10].



4.3 Aesthetic effectiveness depending on tooth form restoration

Regarding the form of tooth-restoration boundary, the use of a chamfer margin on the

vestibular aspect and a butt margin on the proximal and palatal aspects has been suggested

by Vanini and colleagues to combine aesthetic appearance with mechanical performance of

the restoration[4]. For our clinical case, using chamfer margin on the vestibular aspect and

butt margin on the palatal aspect, combined with adequate polishing, resulted in optimal

aesthetic effectiveness.The ability to delimit the thickness of composite layers has been cited

as a determining factor for the success of a restoration. In their layering practice,

Dionysopoulos and colleagues in 2020 and Alleman and colleagues in 2017 emphasized the

importance of limiting the thickness of the composite layers to less than 2mm to avoid the

grayish effect of the restoration. For our clinical case, to reduce stress during polymerization,

the thickness of the increment was limited to less than 2mm during the application of the

dentin body and superficial dentin layers. The longevity of our therapeutic success marked

this observation[11-12].



4.5 Aesthetic effectiveness depending on composite mounting technique

The layering technique chosen for our case was the modern three-layer histological layering

technique. Our therapeutic choice was motivated by the principle of layering respecting the

natural arrangement of dental tissues. According to clinical practice of this principle by

several authors, its aesthetic effectiveness has been affirmed[13-14].



Conclusion

According to the philosophy of the author Magné P, biomimetic restorative dentistry

involves respecting the natural structure and using it as a guide for restoration. The objective

of this article was to present the case of a patient with dental erosions in the anterior sector,

managed by the composite layering technique, and to discuss the expected results. The main

IJO JOURNALS

Volume 07 | Issue 04 | April 2024 | https://ijojournals.com/index.php/hsn/index 12



IJO - INTERNATIONAL JOURNAL OF HEALTH SCIENCES AND NURSING
 ( ISSN: 2814-2098 )                                                                       Rafalimino Holy Nasandratra1*

https://ijojournals.com/                                                     Volume 07 || Issue 04 || April, 2024 ||

Management of dental erosive using composite layering technic and biomimetic efficiency






factors that optimized the aesthetic success of our restoration were: the use of a custom

shade guide combined with the concept of chromatography, chamfer margin on the

vestibular aspect and butt margin on the palatal aspect, the use of a single silicone guide key

for mounting the palatal and proximal walls, adherence to the thickness of each composite

layer not exceeding 2mm, and the composite layering system in three layers respecting the

natural structure of dental tissues. These principles helped us achieve biomimetic efficiency

of the crown restoration and the longevity of the restoration. In order to consolidate the

benefits obtained through biomimetic practice, an effective matrix system should be

analyzed.



Conflicts of interests

We, the authors of this manuscript, declare no conflicts of interest regarding the publication

of this article.



Patient consent
The patient has given full permission for the publication other use of his clinical case and

photographs.



References
1. Herman K. Wpływ diety wegetariańskiej na występowanie erozji zębów. Dent Med Probl.

2005;42(3):457-63

2. Gandara BK, Truelove EL. Diagnosis and management of dental erosion. J Cont Dent Pract.

1999;1(1):1-17

3. Vanini L, Mangani F. The five color dimension of the teeth: a new way of determination and

communication of the color in composite resin restorations. Practical Periodontology an Aesthetic

Dentistry. 2001 : 19-6.

4. Vanini L. Restauration au composite des secteurs antérieurs. Technique de stratification

anatomique. Information dentaire.2006 ; 88 (37) : 22-91.

5. Dietschi D, Fahl N. Shading concepts and layering techniques to master direct anterior composite

restorations: an udapte. Br Dent J. 2016 ; 765 – 71.

6. Bazos P, Magne P. Bio-emulation: biomimetically emulating nature utilizing a histoanatomic

approach; visual synthesis. The Int J of esthetic Dent. 2014 : 330 – 52.

7. Magne P. adhesion, biomatériaux, CFAO. Biomimétique restauratrice sans tenons ni couronnes.

Biomatériaux Clin. 2017 ; 1 (1) : 16 – 25.

8. Manauti J, Salat A, Putignan W, Devoto W, Paolones G, Hardan LS. Stratification in anterior teeth

using one dentine shade and predefinied thickness of enamel : a new concept in composite

layering – Part II. Tropical Dental Journal. 2014 : 5-12.

IJO JOURNALS

Volume 07 | Issue 04 | April 2024 | https://ijojournals.com/index.php/hsn/index 13



IJO - INTERNATIONAL JOURNAL OF HEALTH SCIENCES AND NURSING
 ( ISSN: 2814-2098 )                                                                       Rafalimino Holy Nasandratra1*

https://ijojournals.com/                                                     Volume 07 || Issue 04 || April, 2024 ||

Management of dental erosive using composite layering technic and biomimetic efficiency






9. Kleeberger B. Restauration esthétique et fonctionnelle à l’aide de résine composite direct. JADC.

2008 : 345 -50.

10. Callin D, Mitrea M. Anatomical and histological stratification of composite resin in Esthetic

anterior restoration. Clinical anatomy. 2014 ; 404 – 06.

11. Dionysopoulus D, Gerasimidou O. Biomimetic dentistry : basic principles and protocols. Journal

ARC dental research. 2020; 1-3.

12. Alleman DS, Nejad MA. The protocols of biomimetic restorative dentistry : 2002 to 2017. Inside

Dentistry. 2017 : 64-70.

13. Dietschi D. Layering concepts in anterior composite restorations. J Adhesiv Dent. 2001 ; 1-3.

14. Roux T, Cazier S, romain C. La stratification des composites esthétiques. Quelles méthodes pour

quel résultat ? Information dentaire. 2012 ; 2-6.

IJO JOURNALS

Volume 07 | Issue 04 | April 2024 | https://ijojournals.com/index.php/hsn/index 14
